Grommets & OFFICE Accessories

(1)

Grommets

&

(2)

DISTRIBUTOR

- high quality furniture fittings

SISO A/S MILEPARKEN 11 DK - 2740 SKOVLUNDE (COPENHAGEN) DENMARK PHONE: (+45) 45 830 900 FAX: (+45) 45 830 444

The technical descriptions and dimensions in this catalogue, also those with the photographs and drawings, are not binding. We reserve the right to make design improvements.

We bear no liability for any misprints or other errors that might occur in the production of the catalogue.

SISO A/S tager forbehold for trykfejl samt ændringer i produktets specifikationer.

(3)

3 GRoMMets

4-16

WiRe

ManaGeRs

17-20

keyboaRd

dRaWeR

”pRofi”

21-23

penCil tRays & Cd/dvd-holdeR

24-26

(4)

“salsa” Cable GRoMMet

The “SALSA” cable grommet is different in

shape, material and design compared to

the traditional round grommets. With its oval

shape and lids in brushed stainless steel, the

grommets not only offer functionality but also

a unique timeless design that enhances the

furniture.

The “SALSA” is available in 3 sizes: Small,

Medium and Large.

Model “Small”

Bore size: Oval 32 mm x 105 mm Depth: 15 mm Outer size: Oval 38 mm x 110 mm Depth: 16 mm Plastic insert available in black, silver & alu colour:

Lids: Brushed stainless steel

Item No.: # 25.20.310 + 320

Model “Medium”

Bore size: Oval 57 mm x 149 mm Depth: 15 mm Outer size: Oval 63 mm x 155 mm Depth: 16 mm Plastic insert available in black colour. Other colours on request. Lids: Brushed stainless steel

Item No.: # 25.20.315

Model “Large”

Bore size: Oval 57 mm x 249 mm Depth: 15 mm Outer size: Oval 63 mm x 255 mm Depth: 16 mm Plastic insert available in black colour. Other colours on request. Lids: Brushed stainless steel

Item No.: # 25.20.316

CNC-cutting requested !

Design by Jesper Møller Hansen

LARGE

MEDIUM

SMALL

“SALSA” cAbLE GRoMMEt

DESIGN REGISTERED IN

_{EU & USA}

110/155/255 mm 38/63 mm 105/149/249 mm 16 mm 15 mm 32/57 mm

(5)

Slot, Black colour

Cross, Red colour

Art, Green colour Small, Alu. anodised

Medium, White powder painted 69,5 x 154,5 x 26 mm Large, Alu. Black anodised

69,5 x 304,5 x 26 mm

“WiRe-pod” Cable GRoMMet

The “WIRE-POD” cable grommet is a combination of aluminium and acrylic. It is

available in 3 sizes, 69,5 x 69, 5 mm, 69,5 x 154,5 mm and 69,5 x 304,5 mm and 3

colours, aluminium anodized, aluminium black anodized and white powder painted.

The acrylic plates are available as standard in 3 different designs, CROSS, SLOT &

ART and 4 different colours, white, black, green and red.

The whole concept behind the “WIRE-POD” is that the acrylic plates can be

custom-ized according to the wishes of the customer. Colour and design is up to the

cus-tomer’s imagination.

CNC-cutting is necessary.

Design by Jesper Møller Hansen

(6)

alUMiniUM GRoMMet “RUMba”

Aluminium cable grommet with lid and brush.

Material: Aluminuim, anodized

Size: 80 x 80 x 23 mm w/brush #25.20.340

80 x 276 x 23 mm w/brush #25.20.345 Other sizes on request

ALUMInIUM GRoMMEt “RUMbA”

263 23 276 67 80 80 67 23 80

(7)

ALUMINIUM GROMMET “fORRO”

ALUMInIUM GRoMMEt “foRRo”

Aluminium cable grommet w/bumber strip & felt for sound reduction. With Ø4,5 mm screw holes if fixing to the table top is needed.

Material: Aluminium, anodized.

Bore size: 256 x 100 x 23,5 mm Outer size: 276 x 120 x 25,5 mm Item No.: 25.20.349 Packing: 40 pcs

Damping felt

Damping bumber

256 ± 0,6 23,5 100 ± 0,6 120 ± 0,6 25,5 100 ± 0,6 23,5 Ø 4,5 mm

(8)

POWER PLUG TRAY f/ “fORRO” CABLE GROMMET

PoWER PLUG tRAY

f/ “foRRo” cAbLE GRoMMEt

To be used when you want your standard power plug close to your working station. Fits only SISO cable grommet “Forro”.

No screws or tools needed. Just click the tray flaps into the groove

in the grommet.

Fix the power plug to the tray by use of velcro strips.

Material: Steel – Black Oxydized

Size: Outer measurements: 83 x 242 x 80 mm (H/L/W)

Inner measurements: 82 x 240 x 77 mm (H/L/W)

Item no.: 25.20.344

Packing: 1 pce pr. box (Incl. 3 pieces of veltro strips. Power plug

not included). 240 77 82 77 3 velcro strips

(9)

plastiC GRoMMet “ Cha-Cha”

& papeR GUide

Rectangular plastic cable grommet with lid. 2 parts

Material: Plastic, dark grey

Size: 90 x 18 x 12 mm

Item No.: #25.20.044

Packing: 500 Pcs per export carton

PLAStIc GRoMMEt “chA-chA”

90 12 3 18 86 15

Rectangular plastic paper guide Material: Plastic

Size: 440 x 30 x 25 mm

Item No.: Black #25.22.010

Dark grey #25.22.013

Other colours on request

PAPER GUIDE

R14,50

411

24,50

(10)

ZaMak GRoMMets

Ø 80 mm Alu look w/brush

Ø 80 mm CPL w/rubber grip

Ø 80 mm Alu look w/rubber grip Ø 60 mm CPL w/brush

Ø 60 mm SS-look w/rubber grip Ø 60 mm SS-look w/brush

Ø 60 x 13 mm w/brush Chrome Pl. #25.20.425

Ø 60 x 13 mm w/brush SS-look #25.20.426

Ø 60 x 13 mm w/brush Alu look #25.20.427 Ø 80 x 13 mm w/brush Chrome Pl. #25.20.428 Ø 80 x 13 mm w/brush SS-look #25.20.429 Ø 80 x 13 mm w/brush Alu look #25.20.430

ZAMAk GRoMMEt, W/bRUSh

Ø 60 x 13 mm w/rubber grip Chrome Pl. #25.20.410 Ø 60 x 13 mm w/rubber grip SS-look #25.20.411 Ø 60 x 13 mm w/rubber grip Alu look #25.20.412 Ø 80 x 13 mm w/rubber grip Chrome Pl. #25.20.415 Ø 80 x 13 mm w/rubber grip SS-look #25.20.416 Ø 80 x 13 mm w/rubber grip Alu look #25.20.417

ZAMAk GRoMMEt, W/RUbbER GRIP

Ø 80 mm or Ø 60 mm Ø 90 mm or Ø 68 mm

13 mm 2,0 mm

(11)

ZaMak GRoMMets ”soUl”

Material: Zamak Top: 90 x 90 mm Drilling: By CNC ø 80 x 13 mm By hand-tool ø 79 x 13 mm Chrome plated # 25.20.460 SS-look # 25.20.461 Alu look # 25.20.462 Packing: 100 pcs per export carton

MoDEL “bUttERfLY”

Material: Zamak Top: 90 x 90 mm Drilling: By CNC ø 80 x 13 mm By hand-tool ø 79 x 13 mm Chrome plated # 25.20.465 SS-look # 25.20.466 Alu look # 25.20.467 Packing: 100 pcs per export carton

MoDEL “REctAnGULAR”

90 90 13 Ø79 80,20 90 80,20

RoUnD DRILLInG foR SQUARE Look !!!!

(12)

Ø60 mm w/brush Ø80 mm w/brush

alUMiniUM & plastiC GRoMMets

Ø85 mm w/brush

Material: Plastic

Size: Ø 60 x 18 mm Chrome Pl. #25.20.420

Ø 60 x 16 mm Alu look #25.20.421

PLAStIc GRoMMEt W/RUbbER GRIP

Ø 60 mm CPL w/rubber grip Ø 60 mm Alu look w/rubber grip

Ø 60 mm Ø 70 mm 16 mm or 18 mm 2,0 mm 22 mm 23 mm Ø 60 mm,Ø 80 mm or Ø 85 mm Ø 70 mm,Ø 85 mm or Ø 90 mm

Material: Aluminium, anodized or

Black anodized Size: Alu Ø 60 x 22 mm #25.20.325 Alu Ø 80 x 22 mm #25.20.330 Alu Ø 85 x 22 mm #25.20.335 Black Ø 60 x 22 mm #25.20.326 Black Ø 80 x 22 mm #25.20.331

(13)

plastiC Cable GRoMMets

W/spRinG lid

Material: Plastic Size: Ø 60 x 21 mm Colour: White #25.20.060 Light grey #25.20.061 Brown #25.20.062 Black #25.20.063 Ivory #25.20.064

PLAStIc cAbLE GRoMMEtS Ø 60 mm

W/ SPRInG LID

Material: Plastic Size: Ø 80 x 21 mm Colour: White #25.20.070 Light grey #25.20.071 Brown #25.20.072 Black #25.20.073 Beige #25.20.074 Silver #25.20.075

PLAStIc cAbLE GRoMMEtS Ø 80 mm

W/ SPRInG LID

Light grey

Ivory

Brown

Black

Beige

White

Silver

95 & 71 mm

80 & 60 mm

(14)

“tanGo” ZaMak Cable GRoMMet

The tango cable grommet has been designed with a nice and smooth surface made of zamak.

Dimensions:

Bore size: Ø 80 mm Depth: 22 mm

Outer size: Oval 88 mm x 138 mm Hight: 8,5 mm

Material:

Cover Zamak

Insert: Black plastic

finish:

Cover finish: Alu finish #25.20.080

Grey anthracite #25.20.090

Packing: 100 pcs per export carton

These flaps can be broken

off to allow larger plugs

*)

“tAnGo” ZAMAk

cAbLE GRoMMEt

DESIGN REGISTERED IN

EU & USA

22 mm Ø 80 mm

(15)

“saMba” plastiC Cable GRoMMet

Material: Plastic, ABS

Dimensions:

Bore size: Ø 60 & Ø 80 mm Depth: 27 mm

Outer size: Oval 88 mm x 138 mm Height: 8,5 mm

Colour:

Black Bore : Ø 60 x 18 mm #25.20.091

Alu. sprayed Bore: Ø 60 x 18 mm #25.20.092

Black Bore : Ø 80 x 22 mm #25.20.106

Alu. sprayed Bore: Ø 80 x 22 mm #25.20.107

Packing: 500 pcs per export carton

“SAMbA” PLAStIc cAbLE GRoMMEt

DESIGN REGISTERED IN

_{EU & USA}

27 mm Ø 60 & Ø 80 mm

(16)

- high quality furniture fittings oak wood beech wood cherry wood Maple wood

Wooden GRoMMets

Material: Wood Size: Ø 80 x 23 mm Maple wood #25.20.401 Ø 80 x 23 mm Beech wood #25.20.404 Ø 80 x 23 mm Oak wood #25.20.406 Ø 80 x 23 mm Cherry wood #25.20.409 Packing: 20 Pcs per export carton

WooDEn GRoMMEt, no LAQUER

Material: Wood Size: Ø 80 x 23 mm Maple wood #25.20.400 Ø 80 x 23 mm Beech wood #25.20.403 Ø 80 x 23 mm Oak wood #25.20.405 Ø 80 x 23 mm Cherry wood #25.20.408 Packing: 20 Pcs per export carton

WooDEn GRoMMEt, cLEAR LAQUER

23 mm mm27 Ø 80 mm

(17)

Cable Channel

WITH ADHESIVE TAPE fOR fLEXIBLE fIXING

With this new plastic cable channel with

adhe-sive tape, the end user can fix the cable chan -nel according to his needs.

the cable channel has two soft lips at the top making it possible to feed a cable out at any point. the soft strips surround the cable and prevent any dirt from getting into the channel. the channels are supplied in length of 2000

x 70 x 24 mm inclusive 6 cable clamps in the

following colors.

White color RAL 9010

Item No. #25.21.100 Light grey color RAL 7035Item No. #25.21.110 Dark grey color (no RAL code)

(18)

Cable hook

Easy to install and user friendly under desk wire management. Provides a simple yet functional way to keep wires tidy.The hook has a self-tapping thread for wood and needs a 5mm drilled hole for installation

Material: Nylon, glass reinforced

Colour: Black

Dimensions: Ø 6 x 75 x 55 mm Item. No.: #25.20.510

Packing: 100 Pcs per Poly bag

cAbLE hook

DESIGN REGISTERED IN

_{EU & USA}

18 6

8

(19)

“WiRe GUide”

WIRE GUIDE is an innovative cable management system for both home and professional use.

WIRE GUIDE provides an elegant aesthetic solution to the problem of unsightly cables.

The system consists of a few simple components that are easy to fit, either vertically or horizontally.

WIRE GUIDE is of course made of enviroment-friendly plastic.

WIRE GUIDE is invented in Denmark and design registered in EU & USA.

Designers: RAUNKJÆR + KJÆRGAARD

Material: Plastic, Eco-friendly

Colour: Black

Packing: Chain of 1000 mm packed in a bag

The series consist of:

Wing part

Connector bone

U-Type attachment clip U-Type clip w/ nose Sinker/weight

Item. No.: #25.20.610 Package without Sinker #25.20.620 Sinker

“WIRE GUIDE”

16 59 28,5 Chain elements

DESIGN REGISTERED IN

_{EU & USA}

Wing part

Connector

Sinker

U-Type clip

(20)

WiRe GUide “oval”

Wire cable manager ”Oval” is a classic cable management system for both home and professional use.

Material: Plastic, silver colour Size: 790mm length Colour: Silver

Packing: Chain of 790mm packing in polybag Item No.: # 25.20.751 Package without Sinker # 25.20.749 Sinker

WIRE GUIDE “oVAL”

Connector Sinker Top 22 44 41 Chain elements

(21)

keyboaRd

dRaWeR

”pRofi”

Features: Pencil box with lid

Holding clamp for keyboards

of different sizes

Steel ball bearing slide with locking action when closed

Tray size: 530 x 185 x 17 mm

(max. keyboard size)

Slide size: 35 X 350 mm

Material:

Tray: Grey & black PP

Slides & angles: Steel, bright zinc plated

Fixation: Under desk top by means

of angled mounting brackets with 3 height positions Chipboard screws ø 4 mm

supplied on request

Item No.: 25.23.185

kEYboARD DRAWER ”PRofI”

235

226

60

35 mm mm travel length 10 4 32 6,50 21,5 Max 87 mm Bottom of keyboard drawer inside 17 Holding clamp

(22)

Features: Pencil box with lid and right

hand mouse pad

Holding clamp for keyboards

of different sizes

Steel ball bearing slide with locking action when closed

Material:

Tray: Black PP

Mouse pad: Black PP with black soft

fabric

Slides & angles: Steel, black zinc plated

supplied on request

Item No.: 25.23.182

kEYboARD DRAWER

”PRofI W/MoUSE PAD

10 4 32 6,50 21,5 Max 87 mm Bottom of keyboard drawer inside 17 Holding clamp

293

226

60

35 mm mm travel length

(23)

keyboaRd

dRaWeR

#444

Features: Pencil and clip holder

Steel ball bearing slide with locking action when open & closed

Material:

Tray: Grey or black PP

Slides & angles: Steel, bright or black zinc plated

supplied on request

Item No.: # 25.23.180 Grey tray

# 25.23.181 Black tray

KEYBOARD DRAWER #444

223

218

40

35 mm mm travel length 10 4 32 6,50 21,5 Max 74 mm Bottom of keyboard drawer inside 27

(24)

Application: Plastic pencil tray

with 12,5 mm flange

Overall size: 170 (W) X 350 (L) X 19 (D)

mm

Inlay size: 159 (W) x 325 (L) x 15 (D)

mm

Material: Black PP, plain

Item No.: # 25.31.120

PENCIL TRAY #431

without flange

mm

Material: Black PP, sparkled

Item No.: # 25.31.080

PEncIL tRAY #806

302 140 19

penCil tRays

350 170 19

(25)

penCil tRay

with 16 mm flange

mm

Inlay size: 127 (W) x 292 (L) x 23 (D)

mm

Material: Black PP, sparkled top &

plain bottom

Item No.: # 25.31.070

PENCIL TRAY #815

_Application: _{Plastic pencil tray for drawers} from 326 - 450 mm

Overall size: Closed:326 (W) X 232 (L) X 28 (D) mm Open: 450 (W) X 232 (L) X 28 (D) mm Inlay size: Closed :290 (W) X 232 (L) X 28 (D) mm

Open: 415 (W) X 232 (L) X 28 (D) mm Material: Black PP, sparkled

Item No.: # 25.31.090

ADJUStAbLE PEncIL tRAY

326 232 124 28 324 ₁₄₀ 25

(26)

penCil tRay & Cd/dvd-holdeR

_Application: _{Plastic pencil tray for drawers}

Overall size: 342 x 267 x 24 mm

Material: Black PS

Item No.: # 25.31.060

PEncIL tRAY “PRoM”

267 342

24

Features: Two-sided

Eliminates all contact between CD’s.

Impact resistant structure Perfect to store CD’s & DVD’s Space for identification

Available in the standard size of filing drawers:

B4 = 10 Cd’s or A4 = 8 CD’s

Material: Plastic in black, transparent,

yellow, orange or red Black B4 = 10 Cd’s # 22.28.010

Black A4 = 8 CD’s # 22.28.020

cD/DVD hoLDER

(27)

notes

(28)

Mileparken 11

DK - 2740 Skovlunde (Copenhagen)

Denmark

Phone: (+45) 45 830 900

Fax: (+45) 45 830 444

E-mail: [email protected] Web: www.siso.dk

SISo A/S

Item No.: 99.00.034

Grommets & OFFICE Accessories

Grommets

&

DISTRIBUTOR

Contents

3

GRoMMets

4-16

WiRe

ManaGeRs

17-20

keyboaRd

dRaWeR

”pRofi”

21-23

penCil tRays & Cd/dvd-holdeR

24-26

“salsa” Cable GRoMMet

The “SALSA” cable grommet is different in

shape, material and design compared to

the traditional round grommets. With its oval

shape and lids in brushed stainless steel, the

grommets not only offer functionality but also

a unique timeless design that enhances the

furniture.

The “SALSA” is available in 3 sizes: Small,

Medium and Large.

“SALSA” cAbLE GRoMMEt

DESIGN REGISTERED IN

EU & USA

“WiRe-pod” Cable GRoMMet

The “WIRE-POD” cable grommet is a combination of aluminium and acrylic. It is

available in 3 sizes, 69,5 x 69, 5 mm, 69,5 x 154,5 mm and 69,5 x 304,5 mm and 3

colours, aluminium anodized, aluminium black anodized and white powder painted.

The acrylic plates are available as standard in 3 different designs, CROSS, SLOT &

ART and 4 different colours, white, black, green and red.

The whole concept behind the “WIRE-POD” is that the acrylic plates can be

custom-ized according to the wishes of the customer. Colour and design is up to the

cus-tomer’s imagination.

CNC-cutting is necessary.

Design by Jesper Møller Hansen

alUMiniUM GRoMMet “RUMba”

ALUMInIUM GRoMMEt “RUMbA”

ALUMINIUM GROMMET “fORRO”

ALUMInIUM GRoMMEt “foRRo”

Damping felt

Damping bumber

POWER PLUG TRAY f/ “fORRO” CABLE GROMMET

PoWER PLUG tRAY

f/ “foRRo” cAbLE GRoMMEt

plastiC GRoMMet “ Cha-Cha”

& papeR GUide

PLAStIc GRoMMEt “chA-chA”

PAPER GUIDE

ZaMak GRoMMets

ZAMAk GRoMMEt, W/bRUSh

ZAMAk GRoMMEt, W/RUbbER GRIP

ZaMak GRoMMets ”soUl”

MoDEL “bUttERfLY”

MoDEL “REctAnGULAR”

RoUnD DRILLInG foR SQUARE Look !!!!

alUMiniUM & plastiC GRoMMets

PLAStIc GRoMMEt W/RUbbER GRIP

plastiC Cable GRoMMets

W/spRinG lid

PLAStIc cAbLE GRoMMEtS Ø 60 mm

W/ SPRInG LID

PLAStIc cAbLE GRoMMEtS Ø 80 mm

W/ SPRInG LID

Light grey

Ivory

Brown

Black

Beige

White

Silver

“tanGo” ZaMak Cable GRoMMet

These flaps can be broken

off to allow larger plugs

*)

_{EU & USA}

_{EU & USA}

_{EU & USA}

_{EU & USA}
