The specialist for mobile space solutions

Offi

ce cabin • Modular buildings

Sanitary cabin • WC cabin

A variety of space solutions ready to be used

CONTAINEX offi

ce cabin in package = Transpack Container

Offi

ce cabin

Individual design features due to panel construction

Up to ten cabins per truck Single unit

Easy D.I.Y. assembly

Meeting room Double unit as sales offi ce Finished offi ce

Single container 20’ as exhibition stand

Double unit

Double unit as showroom

• Offi ce cabins can also be supplied as fl at packed Transpack Cabins

• Up to ten cabins can be loaded onto one truck • Easy interchangeable wall panels

made of galvanised metal sheet profi les • Excellent heat and sound insulation • Various extra equipment available

• Cost saving due to DIY assembly

• Quick and easy D.I.Y. assembly with standard tools • Expandable at any time

• Robust steel frame with container corners and forklift pockets • CEE exterior sockets, embedded in the container frame

Type BM 24’ Transpack cabin

Type BM 16’ Type BM 30’

Your advantages:

• Buildings up to 3 storeys high • Individual floor layout

• Equipment for various applications • Painting according to CTX-RAL-chart

Office containers can be combined to container units

Modular buildings

Choose

_{your wall panels}

Corridor in container unit Changing rooms Additional space in operation

Technical solutions which convince

• A robust construction is guaranteed by the massive steel frame • Easily interchangeable wall panels with galavanised steel skins provide for an excellent appearance over years

• High-quality heat and sound insulation guarantee comfort • Double glazed PVC windows with integrated roller shutters are exceptionally user-friendly

• The external dimensions of the CTX cabins match the ISO standard and can therefore easily be transported

Full Window Sanitary window Door with fixed glazing Door

Air conditioning Fixed glazing Double glazing Double winged door

Different colours according to CTX-RAL-chart Recessed CEE power connectors

Assembly and disassembly of the wall panels can be carried out easily and quickly.

Alternative office space Staff accommodation Construction office

Air conditioning Hatch

Feature options allow customisation to suit the desired purpose

Choose

your desired features

External staircase Canopy roof / Fascia Door / Window grill

Plywood or cement-bonded particle board fl oor Interior stairs Isolation options Mini kitchen

Full glazing with skylights Category 2 light fi ttings

Highly abrasion-resistant fl ooring Fixed glazing Sliding window

Fire rated components

PIR sensor for light

Window with sliding part

Interior decor (white or light oak)

TYPE

EXTERIOR INTERIOR

Length Width Height ¹ (assembled)

Height ¹

(package) Length Width Height ¹

Weight ² (assembled) Weight ² (packaging) BM 10’ 2,989 2,435 2,591 648 2,795 2,240 2,340 from 1,290 from 1,350 BM 16’ 4,885 2,435 2,591 648 4,690 2,240 2,340 from 1,690 from 1,750 BM 20’ 6,055 2,435 2,591 648 5,860 2,240 2,340 from 1,930 from 1,990 BM 24’ 7,355 2,435 2,591 648 7,140 2,240 2,340 from 2,250 from 2,310 BM 30’ 9,120 2,435 2,591 648 8,925 2,240 2,340 from 2,710 from 2,770

Optimum glazing

Panel with fi xed glazing

• Exchange and combination with standard panels (full, window, door) possible

• Attractive price-performance ratio • Toughened safety glass (ESG) 4-16-4 gas fi lled (u = 1,1), white pvc profi le • Delivery possible for internal heights 2,350 mm, 2,540 mm and 2,700 mm

Cabin glazing with skylight * • Attractive appearance

• ESG glass 6-16-6 gas-fi lled (u = 1.1), white PVC profi le • Optional glass types available (VSG, TVG)

• Optional double wing door with fi xed glazing • Optional tilting lever for skylight

• Available for spaces with internal heights of 2,540 mm and 2,700 mm

* The cabin glazing is available in the standard specifi cation as discribed only. It is fi xed to the frame and a later alteration isn't possible. For each building a technical review and clearance is required. ¹ Also available with external height 2,800 mm / internal height 2,540 mm ² Depending on layout

Additionally we off er 16’ / 24’ corridor cabins and staircase cabins – details upon request

DIMENSIONS (mm) AND WEIGHTS (kg):

ENER GY SAV

• Quick assembly on site • Promptly usable

• Robust steel construction • High quality insulation

• Complete and comfortable equipment • Fresh water instead of chemicals • Various equipment options possible • Steel interior design (optional)

Hygiene and cleanliness at the highest level

Sanitary cabin

Sanitary cabin 10’

Sanitary cabin interior view

Sanitary containers with hand basins and shower cabins Use at an event

Hand basins (set of 2 / 4) Shower cubicle with folding door Shatter-proof metal mirror

Flushing cistern with water saving device Disabled WC Non slip fl oor (elevated)

Stop & Go fi tting

Water connection, embedded in the wall

Hygrostatic controlled ventilator

Type SA 20’

Type SA 10’ Type SA 30’

TYPE EXTERIOR INTERIOR

Length Width Height ¹ Length Width Height ¹ Weight ² SA 10’ 2,989 2,435 2,591 2,815 2,260 2,340 from 1,490 SA 16’ 4,885 2,435 2,591 4,710 2,260 2,340 from 2,000 SA 20’ 6,055 2,435 2,591 5,880 2,260 2,340 from 2,490 SA 24’ 7,355 2,435 2,591 7,140 2,260 2,340 from 3,000 SA 30’ 9,120 2,435 2,591 8,925 2,260 2,340 from 3,490 WC 5’ 1,200 1,400 2,540 1,055 1,255 2,200 350 WC 8’ 2,400 1,400 2,540 2,255 1,255 2,200 570

DIMENSIONS (mm) AND WEIGHTS (kg):

¹ Also available with external height 2,800 mm / internal height 2,540 mm ² Depending on layout

ENER GY SAV ING ENER GY SAV ING

• Quick assembly on site • Promptly usable

• Solid steel construction • High quality insulation

For trade fairs, events and in public areas, authori-ties increasingly require WC containers that are accessible for disabled people.

Then CONTAINEX has the right solution for you! The new version of the accessible WC cabin from CONTAINEX is certifi ed in accordance with DIN 18040-1 (“accessible construction”). This container meets the highest expectations. • Comfortable equipment in various versions

• Fresh water instead of chemicals

• Various options available (e.g. including showers)

Your advantages:

• Certifi ed to DIN18040-1 (reg.nr. P1B064) • Stable and high-quality features

• Ideal for temporary or long term use

• Also can be delivered with other combinations (eg. 20 ft female / male / barrier-free)

• Alternative options are available

The hygienic solution for high demands

Accessible WC cabin with DIN certifi cation

WC cabin

8’ WC cabin Eurokey lock Alarm light Alarm pull cord switch

Interior accessible design according to DIN 18040-1

20’ WC cabin adapted as a car park toilet

20’ WC cabin ladies / men’s at an event 20’ WC cabin accessible men’s / ladies 5’ WC cabin

Type WC 8’

Our factories

• Selection and use of recyclable materials

• Energy effi cient and environmentally friendly production in certifi ed, European production plants

• Continuous quality inspections and environmental audits in the production plants

• Long product life

Made in Europe

GREEN technology stands for

The long term partnership with certifi ed production sites, owned by CONTAINEX, ensures a high and controlled product quality.

We push energy effi cient construction methods, with the usage of recyclable materials and environmental manufacturing methods. The production of the offi ce, sanitary and storage containers is carried out according to the environment and quality standards (Green Technology).

Production of offi ce and sanitary cabins is undertaken according to strict environmental and quality standards.

Further information on environment and quality measures undertaken by CONTAINEX can be found in the CTX-SSHE-Q-report (Safety-Security-Health-Environment-Quality). You can ask your CONTAINEX sales manager for a copy.

THE FACTORIES AT A GLANCE:

FR UT AV 20' AV 20' I I L FR UT FR FR FR FR FR

Floor plan example

Office cabin

Sanitary cabin

Modular buildings

WC cabin

Many other variations and combinations available

Office cabin 20’ standard

Office and sanitary cabin 2 units

Office and sanitary cabin 3 units

Office and sanitary cabin 6 units

Sanitary cabin 10’

WC cabin ladies / mens 20’

WC cabin 5’

Multi-purpose use

Office building Workshop Perfectly adapted surface expansion Production office

Hotel staff accommodation Taxi driver lounge Construction office Canteen

Multi-purpose use

Driving school office Show kitchen Kindergarten Pharmacy

Representative office Functional office space Bedroom Petrol station shop

CONTAINEX Container-Handelsgesellschaft m.b.H.

AT-2355 Wiener Neudorf, IZ NÖ-Süd, Straße 14 Telephone: +43 2236 601-0, E-Mail: [email protected]
