Chapter 7
Analytics for the IT Expert
Standardization of software is the norm with cloud delivery, but there are still situations in which you may want more control over underlying development objects. SAP S/4HANA provides robust capabilities for addressing this scenario, especially for the role of an administrator or an IT user in an on-premise system, as we’ll discuss in this chapter.
SAP S/4HANA provides significant content out of the box for organizations to start with, but in most projects, organizations want to extend the standard SAP-delivered models and objects. In the previous chapter, we addressed extensibility from the perspective of the analytics specialist, including a comprehensive set of key user tools that can be used without any coding skills. However, for certain project requirements—especially for SAP S/4HANA—the requirements for extensibility become quite complex and the ability to code custom logic becomes important. For such scenarios, organizations need an inter-face to write their own CDS views.
In this chapter, we’ll explore the SAP S/4HANA system from the perspective of the administrator or the IT user. In general, this user is required to develop new data mod-els by combining existing modmod-els with custom modmod-els and creating their own CDS views. They also need to consume these views for developing KPIs and reports in SAP Fiori or maybe in business intelligence tools like SAP Analytics Cloud. To this end, we explore the standard CDS views for procurement and sales. We highlight the important annotations required for custom models and how to set up authorizations via data control language (DCL) objects. Analysis of the top-level CDS views can be done right down to the basic tables. This enables users to customize minimally and only for the views or tables required. Finally, the service activation and the testing of the OData ser-vice can be done in the SAP Gateway client.
7.1 The IT Expert Role
As outlined in previous chapters, the behavior for the business user and the key user is similar when they’re using a cloud system or an on-premise system. However, when we explore the role of the IT user, we find significant differences in the capabilities avail-able for cloud versus on-premise users.
This arises predominantly because of the deployment and administrative roles possi-ble in a cloud versus on-premise system. For example, in an on-premise system a user can access the backend and the frontend SAP S/4HANA system from an SAP GUI inter-face, which isn’t available in the cloud. An IT user in the on-premise system can access the system directly by using the SAP-standard transactions for administrators. An IT user in an on-premise landscape also can access the ABAP CDS views in the ABAP per-spective of Eclipse, which isn’t available in the cloud.
For a company using SAP S/4HANA Cloud, extensibility options are available through a set of extensibility apps—primarily the Custom CDS app and the Custom Analytical Query app. Organizations using on-premise SAP S/4HANA can also use the additional capabilities available to IT users.
In this section, we’ll describe the additional capabilities available for IT users leveraging their direct access to the backend and frontend systems.
An IT user can create or extend an existing CDS view based on his requirements in the ABAP perspective in Eclipse. Because the user has access to the modeling environment and can program the CDS views, this is the highest extensibility option for the IT user. An IT user can copy the SAP-delivered CDS views into their namespace and use this as a base for customizing.
In this environment, the IT user also has access to all the views delivered by SAP, which includes the unreleased views as well. Caution needs to be exercised while modifying the unreleased views because the interface for these views could be changed by SAP in any future release. During this phase, data modeling is done to create specific views that meet your requirements. While in this environment, the IT user can modify or extend any CDS views. We recommend starting the extensions from the top-level views or con-sumption views and only extending the basic CDS views in special cases.
After the data-modeling step and the definition of the CDS views, the IT user can change or add annotations to the CDS views. These annotations can include exposing the CDS view as a consumption view so that it can be evaluated by the analytical engine. Another important annotation is odata.publish=true, which generates the OData service that, when activated in the frontend server, is ready for creating all SAP Fiori artifacts. The SAP S/4HANA system contains an embedded analytical engine, which is the key component that enables the consumption of the CDS views in analytical tools like SAP Analytics Cloud or in other BI tools like SAP Lumira, discovery edition, SAP Analysis for Microsoft Office, or SAP Lumira, designer edition.
Once the backend configurations are completed, the IT user can activate the services in the frontend system. The required authorizations can also be set in the frontend sys-tem, and role-based access can be configured in the frontend system. Once required roles and catalogs are configured, the end user and the IT user can access the custom artifacts created in the backend.
7
7.2 Creating and Consuming CDS Views
In this section, we’ll look at navigating and creating CDS views. We’ll also look at two ways of consuming CDS views: with the analytical engine and with OData services.
7.2.1 Exploring CDS Views
In the previous chapters, we created artifacts like KPIs, analytical list pages, multidi-mensional reports, and others. These artifacts were based on a predefined data model already available as a CDS view. In this section, we’ll explore the standard CDS views for areas like purchasing analytics, sales, and finance.
Although the key user can analyze the CDS view definition in the View Browser and can modify the CDS views in the Custom CDS app, IT users have much more analytical flexi-bility when they’re using the ABAP perspective in Eclipse. To explore these options, we’ll create an ABAP project in Eclipse and add the packages we’d like to explore, as follows: 1. First, connect the backend SAP S/4HANA system in Eclipse. You’ll need the system
ID, SAP S/4HANA backend server details, and a user in the backend system to set up the configuration (see Figure 7.1).
2. Once the connection to the server is established, add the packages in which the stan-dard CDS views are available for analysis. This can be done by creating a new ABAP project, as shown in Figure 7.2.
7 Analytics for the IT Expert
Figure 7.2 Creating ABAP Project for Standard CDS Views
3. In the ABAP project, add the packages you’d like to analyze. As shown in Figure 7.3, you can add the package option to the project and continue to add the required packages containing the CDS views. All CDS views related to the purchasing analytics are available in the ODATA_MM_ANALYTICS package. A free text search for “odata_mm” lists all the packages meeting the selection criteria, and then you can choose the desired package (see Figure 7.3).
Figure 7.3 Add Package for Purchasing Analytics
4. Add the packages containing the SAP-delivered standard content for sales analytics by searching for “vdm_sd” and adding the VDM_SD_ANALYTICS package, as shown in Figure 7.4. The Incoming Sales Order app, Sales Volume Analysis app, and other sales analytics apps are based on the CDS views contained in this package.
5. Next, you can add the packages containing the SAP-delivered standard content for finance applications to explore the delivered CDS finance views in. A search for “FINS_FIN” will return all the required packages, as shown in Figure 7.5. The Accounts Receivables, Account Payables, and Cash Application apps are based on the finance CDS packages listed in Figure 7.5.
7.2 Creating and Consuming CDS Views
7
Figure 7.4 Add Package for Sales Analytics Figure 7.5 Add Package Related
to Finance Analytics
6. Once all the required packages are added to the project, open the project in the ABAP perspective to analyze the details for individual CDS views in the packages. You can navigate through the package hierarchy for analyzing the individual CDS views. In this case, navigate to ODATA_MM_ANALYTICS 폷 Core Data Services 폷 Data Definitions 폷
C_PURGSPENDOFFCONTRACT, as shown in Figure 7.6.
Figure 7.6 CDS View Explorer
This CDS view is used to create the standard SAP-delivered purchasing analytics con-tent for the Off-Contract Spend app. Also, you can find other CDS views, like C_PUR-CHASEORDERVALUE, on which the KPI created in Chapter 6 was based.
7. Next, associated with each data definition in the CDS view, we have access control options found under Core Data Services 폷 Access Control, where you can navigate to the DCL associated with each of the CDS views. The associated DCL structure is shown in Listing 7.1. The DCL views are responsible for authorization propagation for access to the data by the end users.
@EndUserText.label ‘Auto assigned mapping role for C_PurgSpendOffContract @MappingRole: true
define role C_PurgSpendOffContract2 { grant select on C_PurgSpendOffContract2 where ( PurchasingGroup ) =
aspect pfcg_auth ( M_BEST_EKG, EKGRP,
actvt = ‘O3’ )
and ( PurchasingOrganization ) = aspect pfcg_auth (M_BEST_EKO, EKORG,
actvt = ‘O3’ ) and ( Plant ) =
aspect pfcg_auth (M_BEST_WRK, WRKS,
actvt = ‘O3’ ) and ( CompanyCode ) =
aspect pfcg_auth (F_BKPF_BUK, BUKRS,
actvt = ‘O3’ ); }
Listing 7.1 DCL View Associated with CDS Views
8. The most important aspect to note when inspecting the data definition for the CDS view is the annotations associated with it. The classification of the CDS view is set with the @VDM.viewType annotation. If a view is marked as consumption view, it can be evaluated by the analytical engine. The classifications in the View Browser for the CDS views are based on this annotation. The CDS view in Listing 7.2 can be marked as a query with the @Analytics.query:true annotation. A CDS view marked as a query can be used in the View Browser using the Show Content button to create a multidi-mensional report.
The @Odata.publish:true annotation enables the creation of the OData services, which are then ready to create the SAP Fiori-based artifacts when activated in the SAP Gateway server.
@ClientHandling.algorithm: #SESSION_VARIABLE //Inserted by VDM CDS Suite Plugin @ObjectModel.usageType.dataClass: #MIXED
@ObjectModel.usageType.serviceQuality: #D
7
@ObjectModel.usageType.sizeCategory: #L @AbapCatalog.sqlViewName: 'CMMSPNDCNTRT2' @EndUserText.label: 'Off Contract Spend Cube' @VDM.viewType : #CONSUMPTION
@Analytics.dataCategory: #CUBE
@AccessControl.authorizationCheck: #CHECK
@AccessControl.personalData.blocking: #NOT_REQUIRED
Listing 7.2 Annotations for Off-Contract Spend CDS View
9. Listing 7.3 presents an example CDS script written with the ABAP Development Tools. In the initial section, important annotations relevant for the view are defined, after which the parameters required by the views are defined. The input parameters also can be enhanced with field-level annotations. For consumption views, the select con-dition defines the measures and the dimensions as part of the data model.
@ClientHandling.algorithm: #SESSION_VARIABLE // Inserted by VDM CDS Suite Plugin
@ObjectModel.usageType.dataClass: #MIXED @ObjectModel.usageType.serviceQuality: #D @ObjectModel.usageType.sizeCategory: #L @AbapCatalog.sqlViewName: 'CMMSPNDCNTRCT'
//Commented by VDM CDS Suite Plugin:@ClientDependent: true @Analytics.dataExtraction.enabled: true
@VDM.viewType: #CONSUMPTION @Analytics.query: true @OData.publish: true
@EndUserText.label: 'Off Contract Spend'
@AccessControl.authorizationCheck: #PRIVILEGED_ONLY @AccessControl.personalData.blocking: #NOT_REQUIRED define view C_PurgSpendOffContract
with parameters P_DisplayCurrency : displaycurrency, @Consumption.hidden : true @Environment.systemField : #SYSTEM_LANGUAGE P_Language : sylangu, @Consumption.derivation: { lookupEntity: 'C_SglGregorianCalDateFunction',
resultElement: 'DateFunctionStartDate', binding: [ {
targetParameter: 'P_DateFunction', type: #PARAMETER, value : 'P_DateFunction' },
7 Analytics for the IT Expert '#SYSTEM_LANGUAGE' } ] } @Consumption.hidden: true P_StartDate: bedat, @Consumption.derivation: { lookupEntity: 'C_ SglGregorianCalDateFunction',
resultElement: 'DateFunctionEndDate', binding: [ {
targetParameter: 'P_DateFunction', type: #PARAMETER, value : 'P_DateFunction' },
{ targetParameter : 'P_Language' , type : #SYSTEM_FIELD, value : '#SYSTEM_LANGUAGE' } ]
}
@Consumption.hidden: true P_EndDate: bedat,
P_DateFunction : datefunctionid
as select from C_PurgSpendOffContract2(
P_DisplayCurrency : $parameters.P_DisplayCurrency, P_StartDate : $parameters.P_StartDate, P_EndDate : $parameters.P_EndDate ) { /* keys */ key PurchaseOrder, key PurchaseOrderItem, key AccountAssignmentNumber, /* Supplier */ Supplier, _Supplier.SupplierName, SupplierCountry,
_Country._Text[1: Language = $parameters.P_Language].CountryName,
Listing 7.3 CDS Data Definition for Off-Contract Spend
10. You can analyze the CDS view in Eclipse by right-clicking the CDS data definition, then selecting the Open With option. You can use the Graphical Editor, Data
Pre-view, and Dependency Analyzer features to get details of the CDS view. Figure 7.7
shows the options available to the IT user for analysis.
11. An important analysis performed by the IT user lets them understand the structure of the VDMs that form the CDS view, including navigating across the different lay-ers of the CDS views, starting from the consumption view to the basic views. You can visually inspect the data model behind the CDS view and can identify the join
7.2 Creating and Consuming CDS Views
7
conditions and the associations used. This analysis is required for scenarios in which the standard CDS views delivered by SAP may need to be modified; you can analyze which view needs to be enhanced for your business scenario. A graphical display of the CDS view is shown in Figure 7.8.
Figure 7.7 Analysis Option for CDS View
12. Associated with the graphical view is another important feature: the dependency analyzer. Navigate to the dependency analyzer via Open With 폷 Dependency
Ana-lyzer, as shown in Figure 7.7. This tool shows the entire hierarchy of the model, and
you can navigate to the tables that form the CDS views. You can click any item in the hierarchy to open the related view or table for further analysis of the object. As shown in Figure 7.9, the dependency analyzer lists the entire view structure, starting from the consumption view and carrying through the basic tables. Clicking any node in the tree opens the definition of the corresponding CDS view.
Figure 7.9 Dependency Analyzer for CDS View
13. You may want to run the CDS view directly in SAP HANA. To do so, first provide all the input parameters for the CDS view, then execute the SQL statement. An exam-ple is shown in Figure 7.10, with the result set of the query shown in Figure 7.11. You can also analyze the performance in the SQL Console. The generated SQL also can be accessed by clicking the SQL Console tab. You can analyze the result in the SAP HANA database layer and can validate the results shown in the UI layer and identify any data aggregation error.
7
Figure 7.10 Providing Input Parameters for Query Execution in SAP HANA
Figure 7.11 Result Set from SAP HANA SQL Execution
You can start by adding a package delivered by SAP and analyze the standard CDS view either graphically or in a detail view in the dependency analyzer. Then you can identify the structures that need to be enhanced for your requirements. Once enhancements are completed, you can test the CDS view and click Data Preview to check if the results are correct and are performant. In case of any issues, you can revisit the CDS model and make changes so that the performance can be enhanced.
7.2.2 Consuming CDS Views with the Analytical Engine
Once the CDS view is created, you can consume it either via the analytical engine avail-able in SAP S/4HANA or through OData services generated in the frontend or the SAP Gateway server. In this section, we’ll detail the functionality of the analytical engine contained within embedded SAP BW. A CDS view defined with the @Analytics.query= true annotation is evaluated by the analytical engine automatically, creating the tran-sient providers that form the basis for the execution of the queries. The execution of the CDS in the analytical engine makes the CDS available to SAP Analytics Cloud and
7 Analytics for the IT Expert
SAP’s BI tools like SAP Lumira, designer edition; SAP Analysis for Microsoft Office; and SAP BusinessObjects. You can use Transaction RSRT to test the query, as shown in Fig-ure 7.12.
You also can execute the query in different formats. Execution of the query in the Web Dynpro grid is shown in Figure 7.13. This execution is the basis of the query execution for apps like Incoming Sales Order Analysis, for previewing in the Custom Analytical Query app, or for using the Show Content button in the View Browser.
Figure 7.12 Executing Query in Embedded SAP BW in SAP S/4HANA Backend
Figure 7.13 Query Results in Multidimensional Grid
You can also execute other queries already created in the system by clicking the value help and navigating to the InfoAreas section, as shown in Figure 7.14. This analysis is required to identify the integration of the query with the SAP Analytics Cloud or the SAP BusinessObjects BI toolsets.
7.2 Creating and Consuming CDS Views
7
Another important transaction the analytical user executes is Transaction RSRTS_ ODP_DIS. This displays the transient provider preview generated for the ABAP CDS view. You can use the value help to select the Operational Data Provider (ODP), as shown in Figure 7.15.
Figure 7.14 InfoAreas and Queries Available via Analytical Engine
You can perform a metadata check for the transient provider or can execute the query. In Figure 7.16, the transient provider associated with the off-contract spend cube is shown. The transactions mentioned in this section are the most frequently used ones for working with embedded SAP BW.
Figure 7.16 Transient Provider Display for Off-Contract Spend
7.2.3 Consuming CDS Views with OData Services
In the previous section, we detailed the analysis for consumption via transient provid-ers. In this section, we’ll detail the steps required for consumption of the CDS view via OData services.
As outlined earlier, when the CDS view is defined with the odata.publish=true annota-tion, the service is generated in the frontend server and you need to activate these ser-vices. You can use Transaction IWFND/MAINT_SERVICES to activate and maintain the services available. However, to access the service, you need to define an RFC connection to the SAP S/4HANA backend. Once the connection is established, you can activate the services using the Add Service button. The transaction with filtered services is shown in Figure 7.17.
You can filter based on the activated services and then can test the result either in a browser or in an SAP Gateway client, as shown in Figure 7.18.
7
Figure 7.17 Activate and Maintain Services
Figure 7.18 Execute Results in SAP Gateway Client
In the SAP Gateway client, you can test the OData service: if the execution returns with the status code set to 200, the service is ready for use and creation of the KPIs, reports, and analytical list pages described in Chapter 6. The results can be evaluated in JSON format or can be viewed in the standard XML format. Also, the response time can be used for performance analysis. Figure 7.19 shows the execution of the service in the SAP Gateway client; the result is shown in JSON format. You can perform analysis and checks before using the result for the definition of the KPIs.
You can test the metadata of the service and can write extensive OData calls in the
Request URI area to test the results from the services. This is a useful feature for
debugging the services if the desired result isn’t shown in the UI. In Figure 7.20, we executed an OData call with the input parameters and the selected dimensions to test the results.
7 Analytics for the IT Expert
Figure 7.19 Execution in SAP Gateway Client
Figure 7.20 Forming OData Calls in SAP Gateway Client
The results available in the JSON format also can be inspected manually. As shown in Figure 7.21, you’ll have access to the supplier and the purchase order value data received from the OData call.
Figure 7.21 Results in JSON Format
7.3 Summary
7
Using this OData, the CDS service is available for consumption with just a URL. This fea-ture makes the data in the underlying CDS view available in an open format that can be consumed in any tool. SAP has invested heavily in key user tools, by means of which these OData services are consumed and analytical artifacts like KPIs, tiles, and reports are made available just through configuration in SAPUI5 technology, without any cod-ing requirements.
7.3 Summary
In this chapter, we analyzed the set of tables joined to create a virtual data model (VDM), which is scripted in ABAP in Eclipse and enhanced with annotations that provide im-portant metadata. The analytical engine embedded in the SAP S/4HANA backend sys-tem generated the transient providers consumed as queries in SAP Analytics Cloud and other SAP on-premise tools. Then, we looked at the activation of the services in the SAP S/4HANA frontend server or in SAP Gateway. This service enablement allows all the data of the underlying CDS view to be discoverable via OData in a browser. OData ser-vices are consumed in the key user tools set to create custom tiles and reports. In a nut-shell, we explored the journey of the data from the tables to the tiles.
We explored the extensibility options for the IT user in this chapter, but we want to explore additional extensibility options that exist in SAP S/4HANA in the next chapter, in which we’ll cover additional options for creating custom fields and enhancing the existing UIs.
