A model based, anatomy dependent method for ultra-fast creation

of primary SPECT projections

Faraz Kalantari1, Hossein Rajabi1, Mohsen Saghari2, Alireza Emami Ardekani2

1

Department of Medical Physics, Tarbiat Modares University, Tehran, Iran 2

Research Institute for Nuclear Medicine, Tehran University of Medical Sciences, Tehran, Iran

(Received 25 August 2011, Revised 14 September 2011, Accepted 22 September 2011)

ABSTRACT

Introduction: Monte Carlo (MC) is the most common method for simulating virtual SPECT projections. It is useful for optimizing procedures, evaluating correction algorithms and more recently image reconstruction as a forward projector in iterative algorithms; however, the main drawback of MC is its long run time. We introduced a model based method considering the effect of body attenuation and imaging system response for fast creation of noise free SPECT projections.

Methods: Collimator detector response (CDR) was modeled by layer by layer blurring of activity phantom using suitable Gaussian functions. Using the attenuation phantom, in each angle, attenuation factor (AF) was calculated for each voxel. This calculated AF is the weight for the emission voxel and states the detection probability of photons that are emitted from that voxel. Finally weighted ray sum of the blurred phantom was driven to create a projection. For the next projection, our phantom was rotated and the procedure was repeated until all projections were acquired.

Results: Root Mean Square error (RMS) between all 60 modelled projection and real MC simulated projections was decreased from 0.58 ± 0.15 using simple Radon to 0.19 ± 0.03 using our suggested model. This value was 0.56 ± 0.16 using blurred Radon without attenuation modelling, and 0.21 ± 0.03 using attenuated Radon without CDR modelling.

Conclusion: Our suggested model that considers the effect of both attenuation and CDR simultaneously results in more accurate analytical projections compared with conventional Radon model. Creation of 60 primary SPECT projections in less than one minute may make this method as a proper alternative for MC simulation. This model can be used as a forward projector during iterative image reconstruction for correction of CDR and attenuation that is necessary for quantitative SPECT.

Keywords: Monte Carlo, SPECT, Projection, Modeling, Attenuation, Collimator detector response

Iran J Nucl Med 2011;19(1):21-29

Corresponding author: Dr. Hossein Rajabi, Department of Medical Physics, Tarbiat Modares University, Tehran, Iran. E-mail:[email protected]

O

r

ig

in

a

l A

r

ti

c

(2)

Downloaded from

Ir

a

n

J

N

u

c

l

M

e

d

2

0

1

,

V

o

l

1

9

,

N

o

1

(

S

e

ri

a

l

N

o

3

5

)

22

INTRODUCTION

With the advent of high speed computers, Monte Carlo (MC) techniques have become powerful and popular tools in different areas of medical physics. They are extensively used to simulate processes with random nature and to quantify physical parameters that are difficult or impossible to calculate analytically. In particular, many dedicated MC programs have been developed and optimized in the field of nuclear medicine

imaging. Source distribution (activity

phantom) and attenuation map (attenuation phantom) are the main components of MC simulation. If the behavior of the imaging system can be described by known probability density functions, then the Monte Carlo simulation trace a photon by sampling from these functions using random numbers (1-3). Photons are generated within the activity phantom and are transported by sampling through the attenuation phantom and detection system.

Monte Carlo techniques are extensively used to evaluate the performance of new collimators and scanners in SPECT (4, 5) and PET (6-8), to find optimum imaging conditions and parameters (9), to investigate the strengths and limits of attenuation, scatter and partial volume correction algorithms, since it is possible to obtain a reference image for comparison (10-12) and to reconstruct images using inverse Monte Carlo techniques by computation of the system probability matrix (13-15).

The main drawback of MC is its very long computation time for tracing photons from their emission points to their final detected pixels in projections. There are a number of studies trying to accelerate MC simulation by applying variance reduction techniques such as force detection (16, 17). This method forces every photon to escape through attenuation phantom and finally assigns a suitable weight (regarding the amount of attenuation in photon path) to the detected event. Therefore all photons are

detected in the projections. This makes MC more efficient with much higher detection efficiency. The other methods try to model the imaging process to calculate projections analytically. There are also methods that combine both modeling and force detection methods to improve the accuracy of

calculated projections. The first and the

simplest assumption for creating primary projection from activity distribution is Radon transform. This transform assumes that a pixel value in a projection is the ray sum of the activities in a column in front of it. However, in this assumption, the attenuation of photons inside the objects and non-ideal collimation is ignored. It has been shown that collimator-detector response (CDR) for low energy photons can be accurately modeled by distance dependent Gaussian functions. There are also some methods that consider the effect of attenuation, but neglect the effect of distance dependent collimator blurring.

In this study we introduced a fully analytical model considers the effect of both body attenuation and CDR for very fast creation of noise free SPECT projections. The accuracy of this model was compared with simple Radon transform, attenuated Radon transform without CDR modelling and CDR modelling without attenuation modelling.

METHODS

Digital phantom

To evaluate the performance of our suggested model in a realistic condition, the 4D nonuniform B-spline (NURBS) based cardiac torso (NCAT) phantom was used (18). This phantom precisely models the torso organs and their motions. The NCAT phantom produces the attenuation map and the activity distribution map automatically

based on the user defined data (Figure 1). In

activity distribution map, 99mTc activity was

(3)

Downloaded from

Ir

a

n

J

N

u

c

l

M

e

d

2

0

1

,

V

o

l

1

9

,

N

o

1

(

S

e

ri

a

l

N

o

3

5

)

23

spleen: lung: background 100: 40: 22: 6: 6)

based on published data for methoxyisobutyl isonitrile (MIBI) bio-distribution (19). The corresponding attenuation map was created at photon energy of 140 keV. The phantom dimension was 40×40×20 and digitized into 128×128×64 voxel arrays.

Fig 1. A transaxial slice of NCAT phantom; Activity distribution (right) and its corresponding attenuation map (left)

MC simulation

The Monte Carlo code, SIMIND version 49, was used to create projections from the phantoms (20). A typical SPECT system (Argus, ADAC, USA) with low energy high

resolution (LEHR) collimator, 3.4mm

intrinsic spatial resolution, 9.7% energy resolution (at 140keV) was modeled in this study. A total number of 64 projections at 128×128 matrix size were acquired in 360 degrees around the phantoms (radius of rotation=30 cm). Since scatter modelling was not aimed in this study, only primary photons were considered to form the projections. Five million photon histories per projection were traced to create almost noise free MC simulated projections. These projections were used as reference images. All of the analytical projections were compared with these reference projections.

Model based projections

Four different mathematical models were applied to create analytical projections from digital phantoms.

Simple Radon transform

Figure 2 illustrates the creation of a 2D

projection described by p



s,n



from the 3D

activity distribution describes by f



r,s,n



using Radon transform.

Fig 2. Creation of a 2D projection from the 3D activity distribution using Radon transform. Each pixel value in the projection is equal to the ray sum of activity in front of it.

This model assumes that the total count detected in a pixel, is the simple ray sum of activity in a column placed in front of that pixel. Mathematically, Radon transform can be described by:







_





L
