Controls
WRP CONTROLS
A COMPLETE RANGE OF CONTROLS SUCH AS HANDLEBARS FOR EVERY KIND OF BIKE AND LEVERS, FOOTPEGS, GRIPS
AND ASSORTED ITEMS FOR OFF-ROAD / SUPERMOTO BIKES
WRP CONTROLS
UNA LINEA COMPLETA DI PRODOTTI QUALI MANUBRI PER OGNI TIPO DI MOTO E LEVE, PEDANE, MANOPOLE E ALTRI VARI
ACCESSORI DEDICATI A MOTO OFF-ROAD E SUPERMOTO
off-road
Controls
APPLICATION BEND COLOUR P/N
MX / ENDURO LOW BLACK WD-9001-014 MX / ENDURO LOW SILVER WD-9001-016 MX / ENDURO MEDIUM BLACK WD-9002-014 MX / ENDURO MEDIUM SILVER WD-9002-016 MX / ENDURO HIGH BLACK WD-9003-014 MX / ENDURO HIGH SILVER WD-9003-016 MX / ENDURO AUBIN REPLICA TITANIUM WD-9005-022 SUPERMOTO SEEL REPLICA BLACK WD-9009-014 PRO-BAR / OVERSIZE Ø 28.6 mm TAPERED HANDLEBAR W/ PAD
MANUBRIO CONICO Ø 28,6 mm COMPLETO DI PARACOLPI
APPLICATION COLOUR P/N
UNIVERSAL SILVER WD-9000
APPLICATION HEIGHT COLOUR P/N
FITS RUBBER MOUNTS STD BLACK WD-9010 FITS RUBBER MOUNTS HIGH (+10 mm) BLACK WD-9020
APPLICATION COLOUR P/N
SILVER WDL-9011 Ø 28.6 mm OVERSIZE HANDLEBARS SILVER WDL-9012
PRO-MOUNT / OVERSIZE Ø 28.6 mm BAR ADAPTER MOUNTING KIT
PRO-CLAMPS / OVERSIZE Ø 28.6 mm BAR MOUNTING KIT ADATTATORI PER MANUBRIO CONICO Ø 28,6 mm
RISERS / HANDLEBARS RISER KITS KIT SPESSORI MANUBRIO Ø 22 mm HANDLEBARS
ATTACCHI MANUBRIO Ø 28,6 mm PER PIASTRE CON SILENT-BLOCK
TÜV APPROVEd
ASK FOR APPLICATIONS
“PRO-BAR” OVERSIZE HANdLEBARS
- MADE FROM ULTRA STRONG AND LIGHTWEIGHT
7075-T6 ALUMINUM WITH TAPER-WALL
CONSTRUCTION
- 28,6 MM. CLAMPING AREA DIAMETER
- ANODIzED SHOT-PEENED FINISH
- LASER-ETCHED POSITION GRID
- KNURLING AT THE LEFT GRIP AREA TO PREVENT GRIP
SLIPPAGE
- PAD INCLUDED
“PRO-MOUNT” KIT AdATTATORI
- PER IL MONTAGGIO DI MANUBRI CONICI
DA 28,6 MM SU PIASTRE ORIGINALI
- ALLUMINIO LAVORATO CNC
- COMPLETI DI BULLONERIA
“PRO-MOUNT” AdAPTER MOUNTING KIT
- FOR INSTALLATION OF OVERSIzED BARS
ON STOCK TRIPLE CLAMPS
- CNC MACHINED ALUMINUM
- COMPLETE WITH ALL MOUNTING BOLTS
“PRO-CLAMPS” HANdLEBARS MOUNTING CLAMPS
- FOR INSTALLATION OF HANDLEBARS ON BIKES WITH DETACHABLE BAR MOUNTS
- CNC MACHINED FROM 7075-T6 BILLET ALUMINUM
- ANODIzED FINISH
- COMPLETE WITH ALL MOUNTING BOLTS Ø 12 MM
“PRO-CLAMPS” KIT ATTACCHI MANUBRIO
- PER IL MONTAGGIO DI MANUBRI SU MOTO CON ATTACCHI SU SILENT-BLOCK
- ERGAL 7075-T6 LAVORATO CNC
- FINITURA ANODIzzATA
off-road
Controls
APPLICATION BEND COLOUR P/N
MX / ENDURO GP LOW BLUE WD-9202-002
MX / ENDURO GP LOW RED WD-9202-003
MX / ENDURO GP LOW SILVER WD-9202-016 MX / ENDURO GP LOW TITANIUM WD-9202-022 MX / ENDURO GP MID TITANIUM WD-9205-022 MX / ENDURO GP REPLICA BLUE WD-9203-002 MX / ENDURO GP REPLICA RED WD-9203-003 MX / ENDURO GP REPLICA BLACK WD-9203-014 MX / ENDURO GP REPLICA SILVER WD-9203-016 MX / ENDURO GP REPLICA TITANIUM WD-9203-022 MX / ENDURO CHIODI 06 REPLICA BLUE WD-9204-002 MX / ENDURO CHIODI 06 REPLICA TITANIUM WD-9204-022 SUPERMOTO SEEL REPLICA BLACK WD-9209-014
TAPER-X / OVERSIZE Ø 28.6 mm TAPERED HANDLEBAR WITH CROSSBAR MANUBRIO CONICO Ø 28,6 mm CON TRAVERSINO COMPLETO DI PARACOLPI
Jonathan Barragan
“TAPER-X” OVERSIZE HANdLEBAR
- TESTED AND DEVELOPED BY TOP GP RIDERS LIKE
WORLD CHAMPIONS jOËL SMETS, ANDREA BARTOLINI,
CHICCO CHIODI AND EDDY SEEL
- MADE FROM ULTRA STRONG AND LIGHTWEIGHT
7075-T6 ALUMINUM
- TAPER-WALL CONSTRUCTION WITH CROSSBRACE
SYSTEM FOR ADDITIONAL STRENGTHENING AND
SUFFICIENT FLEX
- 28,6 MM. CLAMPING AREA DIAMETER
- ANODIzED SHOT-PEENED FINISH
- LASER-ETCHED POSITION GRID
- KNURLING AT THE LEFT GRIP AREA TO PREVENT
GRIP SLIPPAGE
- CROSSBAR PAD INCLUDED
- SVILUPPATI E USATI DA CAMPIONI DEL MONDO
DEL CALIBRO DI jOËL SMETS, ANDREA BARTOLINI,
CHICCO CHIODI, EDDY SEEL
- REALIzzATI CON TUBO IN ERGAL 7075-T6 CONIFICATO
A SPESSORE DIFFERENzIATO
- IL TRAVERSINO CONFERISCE MAGGIORE ROBUSTEzzA
PUR MANTENENDO UNA BUONA FLESSIBILITà
- DIAMETRO MANUBRIO NELLA zONA ATTACCHI: 28,6 MM
- INCISIONI AL LASER PER PRECISIONE DI MONTAGGIO
- FINITURA SABBIATA E ANODIzzATA
off-road
Controls
APPLICATION BEND COLOUR P/N
MANUBRIO ALLUMINIO 6082-T6 Ø 22 mm COMPLETO DI PARACOLPI PRO-ALU / Ø 22 mm 6082-T6 ALUMINUM HANDLEBAR WITH PAD
APPLICATION BEND COLOUR P/N
HONDA CR / CRF 04> DARK GREY WD-1001-025 HONDA CR - UP TO 03 DARK GREY WD-1020-025 HONDA CR - HIGH DARK GREY WD-1030-025 KAWASAKI KX DARK GREY WD-1040-025
SUZUKI RM DARK GREY WD-1050-025
YAMAHA YZ / YZF DARK GREY WD-1060-025 MINI MX 50 DARK GREY WD-1065-016 MINI MX 60 DARK GREY WD-1070-025 MINI MX 80/85 DARK GREY WD-1080-025 MINI MX 80/85 - HIGH DARK GREY WD-1090-025 TRIAL UNIVERSAL DARK GREY WD-3000-025 ATV / QUAD UNIVERSAL DARK GREY WD-3100-025 PRO-TECH / Ø 22 mm 7075-T6 ALUMINUM HANDLEBAR WITH PAD
MANUBRIO ERGAL 7075-T6 Ø 22 mm COMPLETO DI PARACOLPI
“PRO-ALU” HANdLEBARS
- MADE FROM 6082-T6 ALUMINUM ALLOY
- FORGED CROSSBAR CLAMPS
- ANODIzED SHOT-PEENED FINISH
- CROSSBAR PAD INCLUDED
MANUBRI “PRO-ALU”
- REALIzzATI CON TUBO ALLUMINIO 6082-T6
- TRAVERSINO CON BRACCIALETTI FORGIATI
- FINITURA SABBIATA E ANODIzzATA
- PARACOLPI INCLUSO
“PRO-TECH” HANdLEBARS
- MADE FROM 7075-T6 EXTRUDED ALUMINUM ALLOY
- FORGED CROSSBAR CLAMPS
- LASER-ETCHED POSITION GRID
- ANODIzED SHOT-PEENED FINISH
- CROSSBAR PAD INCLUDED
MANUBRI “PRO-TECH”
- REALIzzATI CON TUBO IN ERGAL 7075-T6
- TRAVERSINO CON BRACCIALETTI FORGIATI
- INCISIONI AL LASER PER PRECISIONE DI MONTAGGIO
- FINITURA SABBIATA E ANODIzzATA
off-road
Controls
P/N APPLICATION A [mm] B [mm] C [mm] D [mm] [°]
WD-1001-…/ WD-2001-… HONDA CR / CRF - 04> BEND 802 99 54 160 14
WD-1020-…/ WD-2020-… HONDA CR - >03 BEND 805 80 55 160 14,5
WD-1030-…/ WD-2030-… HONDA CR - HIGH BEND 802 114 50 160 13
WD-1040-…/ WD-2040-… KAWASAKI KX BEND 806 88 58 160 15 WD-1050-…/ WD-2050-… SUZUKI RM BEND 802 65 63 165 16,5 WD-1060-…/ WD-2060-… YAMAHA YZ BEND 798 90 58 135 15 WD-1065-…/ WD-2065-… MINI MX 50 650 84 44 105 16 WD-1070-…/ WD-2070-… MINI MX 60 746 95 85 120 18 WD-1080-…/ WD-2080-… MINI MX 80/85 746 115 42 120 13,5
WD-1090-…/ WD-2090-… MINI MX 80/85 HIGH BEND 800 132 63 105 16,5
WD-3010 TRIAL 810 120 60 140 13
WD-3100 ATV / QUAD 800 132 63 160 16,5
WD-9001-… TAPERED OVERSIZE - LOW 810 60 58 150 15
WD-9002-… TAPERED OVERSIZE - MEDIUM 810 70 60 150 15,5
WD-9003-… TAPERED OVERSIZE - HIGH 805 90 55 145 14
WD-9005-… TAPERED OVERSIZE - AUBIN REPLICA 803 95 54 160 14
WD-9006-… TAPERED OVERSIZE - BMW GS 1200 04-07 770 170 100 130 23
WD-9009-… TAPERED OVERSIZE - SEEL REPLICA 802 99 54 140 14
WD-9202-… "TAPER-X" OVERSIZE - MX-GP LOW 805 83 60 150 15,5
WD-9203-… "TAPER-X" OVERSIZE - MX-GP REPLICA 802 99 54 140 14
WD-9204-… "TAPER-X" OVERSIZE - CHIODI REPLICA 803 95 40 140 12
WD-9205-… "TAPER-X" OVERSIZE - MX-GP MID 805 93 54 150 14
WD-9209-… "TAPER-X" OVERSIZE - SEEL REPLICA 802 99 54 140 14
OFF-ROAD HANDLEBARS MEASURES / DIMENSIONS TABLE
TAVOLA MISURE / DIMENSIONI MANUBRI OFF-ROAD
APPLICATION COLOUR P/N
UNIVERSAL WRP / BLACK-RED WD-4001 UNIVERSAL WRP / BLACK-BLUE WD-4002 UNIVERSAL WRP / ITALIAN FLAG WD-4003 UNIVERSAL WRP / FRENCH FLAG WD-4004 UNIVERSAL WRP / BELGIAN FLAG WD-4006 MINI-X WRP / BLACK-RED WD-4008
APPLICATION COLOUR P/N
UNIVERSAL BLACK / WRP BLACK-RED WD-4900 PAD-FAT / MX OVERSIZE HANDLEBAR PAD PRO-PAD / MX HANDLEBAR CROSSBAR PADS PARACOLPI PER MANUBRIO CON TRAVERSINO
PARACOLPI PER MANUBRIO CONICO
