PSMN YSF. 1. Quick reference data. 2. Pinning information. 3. Ordering information. 9 July 2018 Objective data sheet

(1)

9 July 2018

Objective data sheet

1. Quick reference data

Table 1. Quick reference data

Symbol

Parameter

Conditions

Min

Typ

Max

Unit

V

DS

drain-source voltage

25 °C ≤ T

j

≤ 175 °C

-

100 V

I

D

drain current

V

GS

= 10 V; T

mb

= 25 °C

-

75 A

P

tot

total power dissipation T

mb

= 25 °C;

Fig. 1

-

147 W

Static characteristics

R

DSon

drain-source on-state

resistance

V

GS

= 10 V; I

D

= 20 A; T

j

= 25 °C

-

9.9

12.3 mΩ

Dynamic characteristics

Q

GD

gate-drain charge

I

D

= 20 A; V

DS

= 50 V; V

GS

= 10 V;

Fig. 5

-

4 -

nC

Source-drain diode

Q

r

recovered charge

I

S

= 20 A; dI

S

/dt = -100 A/µs; V

GS

= 0 V;

V

DS

= 50 V

-

[tbd]

-

nC

2. Pinning information

Table 2. Pinning information

Pin

Symbol Description

Simplified outline

Graphic symbol

1 S

source

2 S

source

3 S

source

4 G

gate

mb

D

mounting base; connected to

drain

mb 1 2 3 4

LFPAK56;

Power-SO8 (SOT669)

S D G mbb076

3. Ordering information

Table 3. Ordering information

Package

Type number

Name

Description

Version

PSMN013-100YSF

LFPAK56;

(2)

4. Limiting values

Table 4. Limiting values

In accordance with the Absolute Maximum Rating System (IEC 60134).

Symbol

Parameter

Conditions

Min

Max

Unit

V

DS

drain-source voltage

25 °C ≤ T

j

≤ 175 °C

-

100 V

V

DGR

drain-gate voltage

25 °C ≤ T

j

≤ 175 °C; R

GS

= 20 kΩ

-

100 V

V

GS

gate-source voltage

-20

20 V

P

tot

total power dissipation

T

mb

= 25 °C;

Fig. 1

-

147 W

V

GS

= 10 V; T

mb

= 25 °C

-

75 A

I

D

drain current

V

GS

= 10 V; T

mb

= 100 °C

-

53 A

I

DM

peak drain current

pulsed; t

p

≤ 10 µs; T

mb

= 25 °C

-

302 A

T

stg

storage temperature

-55

175 °C

T

j

junction temperature

-55

175 °C

T

sld(M)

peak soldering

temperature

-

260 °C

Source-drain diode

I

S

source current

T

mb

= 25 °C

-

75 A

I

SM

peak source current

pulsed; t

p

≤ 10 µs; T

mb

= 25 °C

-

302 A

Avalanche ruggedness

E

DS(AL)S

non-repetitive

drain-source avalanche

energy

I

D

= 25 A; V

sup

≤ 100 V; R

GS

= 50 Ω;

V

GS

= 10 V; T

j(init)

= 25 °C; Unclamped

[1]

-

158 mJ

I

AS

non-repetitive avalanche

current

V

R

supGS

= 50 Ω

≤ 100 V; V

GS

= 10 V; T

j(init)

= 25 °C;

[1]

-

25 A

[1] Protected by 100% test

Tmb (°C) 0 50 100 150 200 03aa16 40 80 120 Pder (%) 0

(3)

5. Thermal characteristics

Table 5. Thermal characteristics

Symbol

Parameter

Conditions

Min

Typ

Max

Unit

R

th(j-mb)

thermal resistance

from junction to

mounting base

-

0.92

1.02 K/W

Fig. 2

-

[tbd]

-

K/W

R

th(j-a)

thermal resistance

from junction to

ambient

Fig. 3

-

[tbd]

-

K/W

aaa-027933

Copper area 25.4 mm square; 70 µm thick on FR4

board

Fig. 2. PCB layout for resistance from junction to

ambient

aaa-027935

70 µm thick copper on FR4 board

Fig. 3. PCB layout with minimum footprint for thermal

resistance from junction to ambient

6. Characteristics

Table 6. Characteristics

Symbol

Parameter

Conditions

Min

Typ

Max

Unit

Static characteristics

I

D

= 250 µA; V

GS

= 0 V; T

j

= 25 °C

100 -

-

V

(BR)DSS

drain-source

breakdown voltage

_I

D

= 250 µA; V

GS

= 0 V; T

j

= -55 °C

90 -

-

V

I

D

= 1 mA; V

DS

=V

GS

; T

j

= -55 °C

-

3.6 -

V

I

D

= 1 mA; V

DS

=V

GS

; T

j

= 175 °C

-

1.9 -

V

GS(th)

gate-source threshold

voltage

I

D

= 1 mA; V

DS

=V

GS

; T

j

= 25 °C;

Fig. 4

2

3.1

4 V

ΔV

GS(th)

/ΔT

gate-source threshold

voltage variation with

temperature

25 °C ≤ T

j

≤ 175 °C

-

-8

-

mV/K

V

DS

= 100 V; V

GS

= 0 V; T

j

= 25 °C

-

[tbd]

1 µA

I

DSS

drain leakage current

V

DS

= 100 V; V

GS

= 0 V; T

j

= 125 °C

-

100 µA

V

GS

= -20 V; V

DS

= 0 V; T

j

= 25 °C

-

5

100 nA

I

GSS

gate leakage current

(4)

Symbol

Parameter

Conditions

Min

Typ

Max

Unit

V

GS

= 10 V; I

D

= 20 A; T

j

= 25 °C

-

9.9

12.3 mΩ

V

GS

= 7 V; I

D

= 15 A; T

j

= 25 °C

-

12

17.5 mΩ

V

GS

= 10 V; I

D

= 20 A; T

j

= 100 °C

-

[tbd]

mΩ

R

DSon

drain-source on-state

resistance

V

GS

= 10 V; I

D

= 20 A; T

j

= 175 °C

-

[tbd]

25.8 mΩ

R

G

gate resistance

f = 1 MHz

-

2 -

Ω

Dynamic characteristics

I

D

= 20 A; V

DS

= 50 V; V

GS

= 10 V;

Fig. 5

-

31 -

nC

Q

G(tot)

total gate charge

I

D

= 0 A; V

DS

= 0 V; V

GS

= 10 V

-

[tbd]

-

nC

Q

GS

gate-source charge

-

8 -

nC

Q

GS(th)

pre-threshold

gate-source charge

-

[tbd]

-

nC

Q

GS(th-pl)

post-threshold

gate-source charge

-

[tbd]

-

nC

Q

GD

gate-drain charge

I

D

= 20 A; V

DS

= 50 V; V

GS

= 10 V;

Fig. 5

-

4 -

nC

V

GS(pl)

gate-source plateau

voltage

I

D

= 20 A; V

DS

= 50 V;

Fig. 5

-

[tbd]

-

V

C

iss

input capacitance

-

2034

-

pF

C

oss

output capacitance

-

454 -

pF

C

rss

reverse transfer

capacitance

V

DS

= 50 V; V

GS

= 0 V; f = 1 MHz;

T

j

= 25 °C

-

15 -

pF

t

d(on)

turn-on delay time

-

10.7 -

ns

t

r

rise time

-

9.3 -

ns

t

d(off)

turn-off delay time

-

17.4 -

ns

t

f

fall time

V

DS

= 50 V; R

L

= 2.5 Ω; V

GS

= 10 V;

R

G(ext)

= 5 Ω; T

j

= 25 °C

-

10 -

ns

Source-drain diode

V

SD

source-drain voltage

I

S

= 20 A; V

GS

= 0 V; T

j

= 25 °C

-

0.8

1.2 V

t

rr

reverse recovery time

-

[tbd]

-

ns

Q

r

recovered charge

I

S

= 20 A; dI

S

/dt = -100 A/µs; V

GS

= 0 V;

(5)

aaa-011501 0 1 2 3 4 5 10-6 10-5 10-4 10-3 10-2 10-1 VGS (V) ID ID (A) (A)

Fig. 4. Sub-threshold drain current as a function of

gate-source voltage

003aaa508 VGS VGS(th) QGS1 QGS2 QGD VDS QG(tot) ID QGS VGS(pl)

(6)

7. Package outline

References Outline

version _IEC _JEDEC _JEITA Europeanprojection Issue date

SOT669 MO-235 sot669_po 11-03-25 13-02-27 Unit(1) mm maxnom min 1.20 1.01 0.15 0.00 0.25 0.50 0.35 4.41 3.62 2.2 2.0 6.2 5.8 0.85 0.40 A

Dimensions (mm are the original dimensions)

Note

1. Plastic or metal protrusions of 0.15 mm maximum per side are not included.

Plastic single-ended surface-mounted package (LFPAK56; Power-SO8); 4 leads SOT669

A1 A2 1.10 0.95 A3 b b2 b3 0.1 L2 w y 8° 0° θ b4 c c2 D(1) D1(1) E(1) E1(1) 3.3 3.1 e 1.27 H L 0.25 0.19 0.30 0.24 4.20 1.3 0.8 0.25 0.9 0.7 4.10 3.80 5.0 4.8 1.3 0.8 L1 A C 1/2 e w A 0 5 mm scale e E1 b c2 A2 1 2 3 4 mounting base D1 c E b2 b3 b4 H D L2 L1 C X y C q (A3) L A A1 detail X

(7)

8. Soldering

0.6 (3×) 0.7 (4×) 0.25 (2×) 0.25 (2×) 0.6 (4×) 4.2 4.7 0.25 (2×) 1.27 1.1 2 3.81 0.9 (3×) SP opening = Cu - 0.050 SR opening = Cu + 0.075 2.15 2.55 3.45 3.5 3.3 solder lands

solder resist occupied area solder paste 125 µm stencil

Dimensions in mm

SOT669 Footprint information for reflow soldering

sot669_fr

(8)

SOT669 Wave soldering footprint information for LFPAK56 package

sot669_fw solder lands Dimensions in mm Issue date 15-04-13_15-04-16 4.826 0.6 (x4) 1.27 0.635 1.78 1.72 2.1 1.4

(9)
