Separability-Oriented Subclass Discriminant

Analysis

Huan Wan, Hui Wang, Gongde Guo, Xin Wei

Abstract—Linear discriminant analysis (LDA) is a classical method for discriminative dimensionality reduction. The original LDA may degrade in its performance for non-Gaussian data, and may be unable to extract sufficient features to satisfactorily explain the data when the number of classes is small. Two prominent extensions to address these problems are subclass discriminant analysis (SDA) and mixture subclass discriminant analysis (MSDA). They divide every class into subclasses and re-define the within-class and between-class scatter matrices on the basis of subclass. In this paper we study the issue of how to obtain subclasses more effectively in order to achieve higher class separation. We observe that there is significant overlap between models of the subclasses, which we hypothesise is undesirable. In order to reduce their overlap we propose an extension of LDA, separability oriented subclass

discriminant analysis (SSDA), which employs hierarchical clustering to divide a class into subclasses using a separability oriented criterion, before applying LDA optimisation using re-defined scatter matrices. Extensive experiments have shown that SSDA has better performance than LDA, SDA and MSDA in most cases. Additional experiments have further shown that SSDA can project data into LDA space that has higher class separation than LDA, SDA and MSDA in most cases.

Index Terms—Dimensionality reduction, feature extraction, linear discriminant analysis, subclass discriminant analysis, classification

F

1

I

D

ma-chine learning and statistics to reduce the number of variables under consideration, by way of feature selection or feature extraction. Data analysis such as regression or classification can usually be done in the reduced space more accurately than in the original space when the same analysis model is used. This is usually the case for high dimensional data analysis tasks such as image, video, and spectral data analysis.

Dimensionality reduction transforms data from a high-dimensional space into a lower-high-dimensional space. The transformation may be linear as in principal component analysis (PCA), or nonlinear as in kernel PCA and man-ifold learning, or supervised (or discriminant) as in linear discriminant analysis (LDA). LDA is a classical approach to discriminant dimensionality reduction, dating back to Fisher [1]. It has been widely used in many fields of pattern recognition such as face recognition and verification [2], [3], image retrieval [4], and document recognition [5].

There are three limitations with the original LDA. The mathematics of LDA is derived on the assumption that the instances of all classes are generated from Gaussian distributions of same covariance but different means. If the distributions are significantly non-Gaussian, the LDA projections may not preserve complex structure in the data needed for classification. The assumption has significantly restricted the application of LDA, as in real life many data distributions are not Gaussian [6].

• H. Wan, G. Guo and X. Wei are with Key Lab of Network Security and Cryptology, School of Mathematics and Computer Science, Fujian Normal University, P.R. China

• H. Wang is with School of Computing and Mathematics, Ulster Univer-sity, UK; also with Fujian Normal University as a visiting professor.

The mathematics of LDA also implies that LDA pro-duces at most C − 1 feature projections, where C is the number of classes, because the number of projections is constrained by the rank of the between-class scatter matrix which is at most C −1. As a result the original data space can be transformed to a new space of at most C − 1 dimensions. When there are many classes this is not a problem; however, when there are few classes this could be a serious problem. For example, in a binary classification problem there are only two classes. When LDA is applied there will be only one feature projection to represent the data. One feature may be insufficient to describe the class boundary in many cases especially when the class boundary is complex. This is the so-called over-reducing problem [7]. The third limitation is that LDA will fail when the discriminatory information is not in the mean but rather in the variance of the data .

To overcome these limitations, several variants of the original LDA have been proposed in recent years including non-parametric discriminant analysis (NDA) [8], [9], subclass discriminant analysis (SDA) [10] and mixture subclass discrim-inant analysis (MSDA) [11], [12].

Fukunaga [8] argued that LDA is parametric discrimi-nant analysis since it uses the parametric form of the scatter matrix based on the Gaussian distribution assumption [9]. As a result LDA suffers performance degradation in cases of non-Gaussian distribution. Fukunaga then re-defined the between-class scatter matrix1 _{to overcome this}

Gaussian problem and called the resulting LDA as

non-1. Fukunaga defined the new between-class scatter matrix as:SN b =

PN1

j=1w(1, j)(x1j− µ2(x1j))(x1j− µ2(x1j))T+PN2j=1w(2, j)(x2j−

µ1(x2j))(x2j− µ1(x2j))T, wherexij denotes thejth vector of class

i(i = 1, 2)andµi(xij)is the local KNN mean, defined byµi(xij) =

1 k

Pk

p=1N Np(xij, l)where N Np(xij, l)is thepth nearest neighbor

from classl to the vectorxij(i 6= l) andw(i, l) is the value of the

parametric discriminant analysis (NDA). In NDA’s between-class scatter matrix, weighting is introduced to consider the boundary information in the training set. In this way, for any distributions, we can separate classes by maximizing the distance between data instances in one class (especially those instances that stand at the boundary) and the mean of p nearest neighbours from another class. In addition, NDA uses data instances to construct the between-class scatter matrix instead of merely the class centres, therefore it also solves the over-reducing problem (i.e., C − 1 limitation). However, NDA can only deal with the two-class case, so Li et al. [9] extended NDA to address the multiclass case and proposed a series of variants of NDA, such as non-parametric subspace analysis (NSA) and nonnon-parametric feature subspace (NFA), and applied these variants of NDA for face recognition.

Zhu and Martinez [10] argued that classes are usually multimodal so distribution within classes should be consid-ered when constructing between-class scatter matrix. They proposed a variant of LDA, called subclass discriminative analysis (SDA), to address this issue. Based on a nearest neighbor based clustering algorithm and stability criterion they proposed, SDA divides each class into same number of subclasses and computes centres of those subclasses or subcentres of the class. Then SDA uses the differences between the subcentres of one class and the subcentres of the other classes to construct a new between-class scatter matrix and maximizes the new between-class scatter matrix through the LDA optimisation machinery. Since SDA uses subcentres rather than centres of every class to compute between-class scatter matrix, it does not have the C − 1 limitation.

Mixture subclass discriminant analysis (MSDA) [11] uses the same criterion as SDA to obtain optimal number of subclasses for each class but it only divides those classes that do not have Gaussian distribution based on nongaussianity criterion proposed by [11]. MSDA uses the same between-class matrix as SDA so it does not have the C − 1 limitation either.

Although both SDA and MSDA have overcome some of the LDA limitations, they have not answered one im-portant question. Most if not all LDA variants, including SDA and MSDA, perform dimensionality reduction by max-imising the same (Fisher) objective which is the between-class scatter matrix normalised by the within-between-class scatter matrix, with different definitions for the between-class and within-class scatter matrices. What is the true objective of discriminative dimensionality reduction? Fig. 6 shows the subclass distribution of the Iris data obtained by SDA, MSDA and SSDA (to be presented in this paper), where each circle corresponds to one subclass. It is clear that SDA and MSDA have different number of circles thus resulting in

very different LDA dimensions2_{, suggesting that SDA and}

MSDA have different goals in dimensionality reduction. At the same time they have one thing in common – the cir-cles have significant overlap. A research question naturally arises: could reducing the overlap of these circles be a good objective of dimensionality reduction?

More recently a new LDA variant, orLDA, is proposed to address the over-reducing problem associated with LDA [7]. Unlike LDA, which measures the between-class separation by subtracting the mean of every class by the mean of the whole data instances, orLDA does so by subtracting every instance in one class by the mean of another class. In this way, the original data space can be reduced to one with at most min(d, n − 2) dimensions3 _{where d is the number of}

dimensions in the original data space and n is the number of instances.

This has indeed overcome the over-reducing problem. However, when the number of instances and the number of dimensions are both large, the reduced (LDA) space may still have many dimensions, thus dimensionalty reduction being possibly insufficient. This may then affect the overall performance. Furthermore, in its current form, orLDA can only be used for binary classification problems due to its way of computing the between-class scatter matrix.

Inspired by SDA and MSDA, also motivated by the desire to extend orLDA to work on multiclass problems, we present in this paper separability-oriented subclass discriminant analysis (SSDA), a variant of LDA as a result of our effort to answer the above overlapping question. SSDA is aimed to reduce the overlap between models of the subclasses within each class during the LDA dimensionality reduction process. This is achieved by finding the optimal4 _subclasses

for each class and maximising Fisher’s separation objective function using re-defined within-class and between-class scatter matrices – instead of using every instance of one class to subtract the mean of another class (as in orLDA), we use the means of the subclasses in one class to subtract the mean of all data instances. In this way, SSDA is expected to find subclasses for each class that are ‘innate’ to the data, and are not much overlapping in their models. Furthermore the number of dimensions in the reduced LDA space is not restricted by the number of classes or the number of data

2. The number of LDA dimensions is closely related to the number of subclass (i.e. circles). The number of circles denotes the number of sub-classes. When the between-class scatter matrix and within-class scatter matrix are constructed by the centres of subclasses rather the centres of classes, the ranks of between-class scatter matrix and within-class scatter matrix are strongly correlated with the number of subclasses (circles). The number of reduced (LDA) dimensions is given by the rank ofSw−1Sb, where rank(S−1w Sb) 5 min(rank(Sw−1), rank(Sb)).

Therefore, the number of dimensions in the reduced (LDA) space correlates strongly with the number of circles. If we want to quantify the relation precisely, we must know the exact definition ofSbandSw.

Therefore there is no general formula for their relation.

3. According to linear algebra and the formula that we compute the between-class scatter matrixSband within-class scatter matrixSw, we

can obtainrank(Sb) = min(d, N1− 1 + N2− 1)andrank(Sw) =

min(d, N1− 1 + N2− 1), wheredis the number of dimensions,Ni(i =

1, 2) is the number ofith class. Thereforerank(Sb) = min(d, n − 2),

rank(Sw) = min(d, n−2), wherenis the number of instances. Because

the number of dimensions in the reduced space of orLDA is equal to the

rank(Sw−1Sb) andrank(S−1w Sb) 5 min(rank(Sw−1), rank(Sb)), the

original data space can be reduced to one with at mostmin(d, n − 2). 4. Throughout this paper, when we say ‘optimal’ we mean a choice that gives the best prediction performance.

instances. Extensive experiments show SSDA indeed has superior performance.

The rest of the paper is organised as follows. Section 2 presents related work including the classical linear dis-criminant analysis, subclass disdis-criminant analysis, mixture subclass discriminant analysis, and LDA for over-reducing problem. Section 3 presents our separability-oriented sub-class discriminant analysis. Experimental results are pre-sented in Section 4. Section 5 presents further evaluation results about separability. Finally, Section 6 concludes the paper.

2

R

W

To provide the context and to introduce the necessary tech-nical notations we present an overview of related work, including the original LDA and its recent extensions SDA, MSDA and orLDA.

2.1 Linear Discriminant Analysis

Linear discriminant analysis (LDA) is a classical method for discriminant analysis that is used in statistics, pattern recog-nition and machine learning to find a linear combination of features that separates two or more classes of objects. The resulting combination may be used as a linear classifier, or more commonly, for dimensionality reduction before later classification [13]. It has been successfully used in many data centric applications.

LDA uses a between-class scatter matrix Sb to measure

class separability, and uses within-class scatter matrix Swto

measure class compactness. The goal of LDA is to find a projective matrix W that projects data from one data space to a new one, LDA space that is spanned by LDA features (or LDA dimensions), such that a measure of the between-class scatter matrix Sb in the new space is maximsed and

simultaneously the same measure of the within-class scatter matrix Sw in the new space is minimised. Sb and Sw are

defined respectively as: Sb = 1 N C X i=1 Ni(µi− µ)(µi− µ)T (1) Sw = 1 N C X i=1 Ni X j=1 (xij− µi)(xij− µi)T (2)

where N is the number of instances, Ni is the number of

instances in class i, C is the number of classes, µi is the

mean of class i, µ is global mean of all instances, and xij

denotes the jth instance in class i.

LDA is an optimisation process. Its optimisation objec-tive, the Fisher objecobjec-tive, is defined as follows

JLDA(W ) = tr(W T_S bW ) tr(WT_S wW ) (3) where W is a projective matrix that projects data from the data space to the LDA space. The LDA optimisation is to find one projective matrix, W∗, that maximises the Fisher objective; that is

W∗= arg max

W J

LDA_{(W )}

(4)

It turns out the sought-after projective matrix W∗ is com-posed of the eigenvectors corresponding to the largest eigenvalues of Sw−1Sb, based on the assumptions of

nor-mally distributed classes and equal class covariances5_.

Note that Sb is the sum of C matrices of rank ≤ 1 and

the mean vectors are constrained by _C1 PC

j=1µi = µ, so

the rank of Sb is at most C − 1. Therefore the variability

between features will be contained in the subspace spanned by the eigenvectors corresponding to the C − 1 largest eigenvalues. In other words the dimensionality of the (new reduced) LDA space is at most C − 1. If C = 2, the LDA space will have only one dimension thus the over-reducing problem – insufficient number of features are extracted for describing the class boundaries, so there is loss of between-class information.

The terms LDA and Fisher’s linear discriminant (FLD) are often used interchangeably, although Fisher’s original article [1] actually describes a slightly different discriminant, which does not make some of the assumptions of LDA such as normally distributed classes or equal class covariances.

Various variants have been proposed to extend LDA, which fall under two main categories – incremental learning LDA and batch learning LDA. Incremental learning LDA methods focus on processing data streams, which update LDA features based on new ‘burst’ of data. Many of them update LDA features through updating between-class and within-class scatter matrices [14], [15], [16], [17].

Batch learning LDA methods require that all instances are available and construct LDA features with all data instances. Most batch learning LDA methods also address the small sample size (SSS) or singularity problem, which is a well known problem with the original LDA – when the number of features is much larger than the number of instances we cannot use Sw−1Sb to obtain the projective

matrix W . Solutions include using LDA after PCA [18], using random matrix multiplication with scatter matrices to extract the most discriminant information [19], and using regularization [20], [21], [22], [23]. The regularization based methods are an important approach to solving the SSS problem. Its key idea is to find a regularization parameter α and add α to the diagonal elements of the within-class scatter matrix, which will guarantee that the new within-class scatter matrix is positive definite and non-singular. Other batch learning LDA methods include tensor-based LDA [24], heteroscedastic LDA [25], and sparse discriminant analysis [26].

2.2 Subclass Discriminant Analysis

Subclass discriminant analysis (SDA) [10] is a variant of LDA that aims to separate classes at a subclass level rather

5. To show how to obtain W∗, we let f = WT_S

bW and g =

WT_S

wW − α = 0, whereα > 0is any constant. The LDA optimisation

is thus equivalent to finding a projective matrixWto maximizefunder theg constraint. For this we defineL = f − λg, where λ 6= 0is Lagrange’s multiplier. By setting the derivative ofLwith respect to Wto zero, we get

∂L

∂W = 2SbW − 2λSwW = 0 =⇒ SbW = λSwW (5)

If Sw is nonsingular, we obtain Sw−1SbW = λW. Therefore, the

columns of projective matrixW∗_{are the eigenvectors corresponding}

than at a class level, based on the observation that the data distribution in a class may be multimodal (i.e., forming clusters). This is achieved by dividing each class into sev-eral subclasses and then maximising the redefined Fisher objective function, where the original between-class scatter matrix Sb is replaced by a new between-subclass scatter

matrix Sbsb: SbSDA= Sbsb= C−1 X i=1 Ki X j=1 C X l=i+1 Kl X n=1 pijpln(µij−µln)(µij−µln)T (6) where C denotes the number of classes, Ki denotes the

number of subclasses in class i, pij and pln denote priors,

and µij denotes the mean of the jth subclass in class i. The

within-class scatter matrix is the instance covariance matrix SSDA_w = ΣX = 1 N N X j=1 (xj− µ)(xj− µ)T (7)

where N , xj, and µ are the number of instances, the jth

instance and the mean of all instances respectively. The redefined objective function is the following:

JSDA(W ) = tr(W T_SSDA b W ) tr(WT_SSDA w W ) = tr(W T_S bsbW ) tr(WT_{ΣXW )}. (8)

SDA uses a nearest neighbor based clustering algorithm to divide each class into several subclasses, and automati-cally determines the optimal number of subclasses by the leave-one-out-test (LOOT) criterion proposed in [10], or by a faster stability criterion [27]6_.

2.3 Mixture Subclass Discriminant Analysis

Mixture subclass discriminant analysis (MSDA) [11] is an extension of SDA. It adopts SDA’s between-subclass scatter matrix Sbsb, but replaces SDA’s within-class scatter matrix

by a new within-subclass scatter matrix, which is defined as

S_wM SDA= dΣX = Sbsb+ Sws, (9)

where Sbsb is defined as in SDA, and Sws is defined as

follows: Sws= C X i=1 Ki X j=1 pij(xij− µij)(xij− µij)T (10)

where C, Ki, pij, xij and µij are the number of classes,

the number of subclasses in class i, prior, the instances in subclass j of class i, and the mean of subclass j in class i. The Fisher objective function of MSDA is the:

JM SDA(W ) = tr(W T_SSDA b W ) tr(WT_SM SDA w W ) = tr(W T_S bsbW ) tr(WT d ΣXW ) (11) MSDA applies nongaussianity criterion, based on skew-ness and kurtosis, to select a class or subclass that is not Gaussian distribution. It then applies the LOOT criterion (or stability criterion if speed is required) to re-partiton the selected classes or subclasses to getting optimal number of subclasses.

6. The LOOT criterion is computationally expensive so a computa-tionally efficient criterion, the stability criterion, was introduced in order to find the optimal number of subclasses faster.

2.4 LDA for Over-Reducing Problem

LDA for over-reducing problem (orLDA) [7] is a variant of LDA that is aimed to address the over-reducing problem for binary classification by using a new between-class scatter matrix. Instead of using the mean of every class to subtract the mean of the whole data, orLDA uses every instance in one class to subtract the mean of the other class. In this way orLDA can get more LDA features than the original LDA. The new between-class scatter matrix is defined as follows:

SborLDA= N1(N1

PN1

j=1(x1j− µ2)(x1j− µ2)T+

N2PNj=12 (x2j− µ1)(x2j− µ1)T)

where N is the number of instances, Ni is the number of

instances in class i (i = 1, 2) such that P2

i=1Ni = N , µi

is the mean of the instances in class i, and xij is the jth

instance in class i.

3

S

-O

S

D

A

In order to have an insight into LDA in general and to answer the research question on Page 2 specifically, we pro-pose separability-oriented subclass discriminant analysis (SSDA) – an extension of subclass discriminant analysis. The objec-tive is to find those LDA features that together (1) maximise the between-subclass separation within a class (2) minimise the within-class scatterness and (3) maximise the overall between-class scatterness. The between-subclass separation objective is achieved through clustering guided by a sepa-rability criterion. The within-class scatterness objective and the between-class scatterness objective are achieved through re-defined within-class scatter matrix and between-class scatter matrix.

3.1 Between-subclass Separation by Hierarchical Clus-tering

Like SDA and MSDA, we divide each class into subclasses through clustering before the LDA optimisation procedure is applied. We select agglomerative hierarchical clustering7

for this, because hierarchical clustering is stable in that for a given K and a given data set, the same clustering is obtained no matter when the algorithm is run. This is not the case with K-means clustering as it sets the initial clustering randomly.

We are interested in the optimal number, K∗, of clusters (i.e., subclasses) for each class, which gives the best predic-tion performance using SSDA with other parameters being fixed. This is challenging if not impossible. One solution to the problem of finding the optimal K∗ is a wrapper approach8_{, but it is clearly very costly. We therefore need}

7. Hierarchical clustering [28] is a method of cluster analysis which seeks to build a hierarchy of clusters. There are two approaches to hierarchical clustering: agglomerative (bottom up) and divisive (top down). In agglomerative approach each data instance starts in its own cluster, and pairs of clusters are merged as one moves up the hierarchy. In divisive approach all data instances start in one cluster, and splits are performed recursively as one moves down the hierarchy. In both approaches the clustering process continues (in either direction) until the given number (K) of clusters are obtained.

8. A wrapper approach should work this way: for eachK we run SSDA once to get one validation result, and we repeat this process for allKand choose the optimalKbased on the validation results.

to find an efficient heuristic method. One approach is to design a criterion measuring the quality of a clustering for a given K; repeat the clustering process for all K values; and then select the K value that results in a clustering with the best value for the criterion. SDA and MSDA both take this approach and use the leave-one-out criterion or stability criterion.

We consider a different criterion, called separability crite-rion, which is aimed to find the clustering that maximises the average distance between the mean of a class and the means of subclasses in this class. This criterion is defined as follows:

K_i∗= arg max

K (AEDK,i) (12)

where Ki∗ is optimal number of subclasses in class i and

AEDK,iis the average Euclidean distance (AED) between the

mean of the class and the means of its K subclasses, which is given below: AEDK,i= 1 K K X j=1 kµij− µik2 (13)

where µij is the mean of the jth subclass in class i and µiis

the mean of class i. It is clear the bigger the AED, the more separated the subclasses are from each other.

The algorithm for finding the optimal number of sub-classes (i.e., clusters) K∗ for each class, in terms of the separability criterion in Eq.(12) is described in Algorithm 1. Given a max value Kmax, we run the hierarchical clustering

algorithm Kmax times with K = 1 to Kmax, calculating

our separability criterion for every K then taking the K corresponding to the best separability criterion value as the optimal K∗.

Algorithm 1Finding the optimal numberK∗of subclasses automati-cally. In this algorithm, nClass is the number of classes, classMean is the mean of a class, subclassMean is the mean of a subclass,Kmaxdenotes

the maximum number of subclasses to consider for a class,K∗_{is the}

optimal number of subclasses for a class,Kis the number of subclasses, T EDdenotes the total of all Euclidean distances in a class andEDiis

the Euclidean distance between classMean andith subclassMean. Input: A set of training instances and Kmax

Output: K∗

forC = 1 : nClass do Calculate classMean;

forK = 1: Kmaxdo

Apply hierarchical clustering algorithm and obtain subclasses; Calculate subclassMean; T ED = 0; fori = 1:K do Calculate EDi; Calculate T ED = T ED + EDi; end for

Calculate and record AEDK =T ED_K ;

end for

K∗= arg maxK(AEDK);

end for

After the optimal number of subclasses is found for every class, the subclasses are subsequently obtained for every class. We use these subclasses to calculate our new between-class scatter matrix and within-class scatter matrix.

3.2 The Re-defined Within-class Scatterness

The original LDA uses individual instances and the mean of the class in its definition of the within-class scatter matrix (See Fig. 2(a) for an illustration), and MSDA uses instances and means of subclasses. SDA defines the within-class scat-ter as instance covariance matrix.

In SSDA, we use individual instances, means of sub-classes and the mean of the class to define the new within-class scatter matrix (See Fig. 2(b) for an illustration). It mea-sures within-class scatterness at two levels: local scatterness at subclass level and global scatterness at class level. Local scatterness measures the degree to which data instances in a subclass of a class are scattered around the subclass mean, and global scatterness measures the degree to which sub-class means in a sub-class are scattered around the sub-class mean. It should be noted that in most research on LDA, including the original LDA, only global scatterness is considered. Fig. 1 illustrates local scatterness and global scatterness for a class. In classification tasks it is possible that some class may have different modalities (or clusters). One example is face recognition where a person’s face images may be front view or side view, resulting in different modalities when all images are represented in the same data space. The new within-class scatterness represents multimodality informa-tion, therefore optimising this within-class scatterness will separate different modalities more clearly and hopefully the resulting data reduction will have better performance.

Suppose there are N instances xi ∈ Rn for i =

1, 2, . . . , N from C classes, Ni is the number of instances

in class i (i= 1, 2,. . . ,C) such that PC

i=1Ni = N , Ki is

the number of subclasses in class i, Nij is the number of

instances in subclass j of class i, µijis the mean of subclass

j of class i, µi is the mean of class i and xijm is the mth

instance in subclass j of class i. The new within-class scatter matrix for SSDA is defined as follows:

S_wSSDA= Ssw = Ssw1+ Ssw2 (14) where Ssw1 = C X i=1 Ki X j=1 Nij X m=1 (xijm− µij)(xijm− µij)T (15) Ssw2 = C X i=1 Ni N Ki X j=1 (µij− µi)(µij− µi)T (16)

where Ssw1 measures local scatterness and Ssw2 measures

global scatterness.

3.3 The Re-defined Between-class Scatterness

In the original LDA the between-class scatter matrix is defined in terms of the means of classes and the mean of all instances (See Fig. 3(a)). In SDA and MSDA, the between-class scatter matrices are all defined only by the means of subclasses (see Eq.6).

In SSDA we define a new between-class scatter matrix using the means of subclasses and the mean of all instances; that is, we measure between-class scatterness by the differ-ence between subclass means and a single point of referdiffer-ence, i.e., the mean of all data instances (See Fig. 3(b)).

Using the same notation as in Section 3.2, our new between-class scatter matrix for SSDA is defined as follows:

SSSDA_b = Ssb= C X i=1 Ni N Ki X j=1 (µij− µ)(µij− µ)T (17)

It is clear that this breaks the C − 1 limitation. SSSDA

b is similar to the between-class scatter measure

S_bZM 2004=PC

i=1

PKi

j=1pij(µij− µ)(µij− µ)T [29]. There is

however a key difference between them. The subclass prior in SSSDA

b is Ni/N , while the subclass prior in SbZM 2004 is

Nij/N . As a result of this, our approach places emphasis

on subclass separability and increases the contribution of subclasses in separating different classes.

3.4 The LDA Optimisation for SSDA

The LDA optimisation for SSDA is done through the Fisher objective (Eq.3), where we replace Sb, or Swor both by our

new versions, thus resulting in three different versions of SSDA.

3.4.1 SSDA-1

In this version, we use the new between-class scatter matrix and the original within-class scatter matrix so the Fisher objective function is JSSDA−1(W ) =tr(W T_SSSDA b W ) tr(WT_S wW ) =tr(W T_S sbW ) tr(WT_S wW ) . SSDA-1 maximises class separation through maximising subclass separation thus preserving the within-class struc-ture whilst separating different classes. Therefore we expect this to lead to data reductions that have better performance. Additionally our Ssb is defined in terms of subclass means

rather than class means, therefore SSDA-1 is not C − 1 limited. Extensive experiments confirm our hypothesis.

It should be noted that the solution to the LDA opti-misation using the above Fisher objective is the optimal projective matrix whose columns are the eigenvectors cor-responding to the largest eigenvalues of Sw−1Ssbrather than

S−1 w Sb.

3.4.2 SSDA-2

In this version, we use the new within-class scatter matrix Ssw and the original between-class scatter matrix Sb so the

Fisher objective function is JSSDA−2(W ) = tr(W T_S bW ) tr(WT_SSSDA w W ) = tr(W T_S bW ) tr(WT_S swW ) . The new within-class scatter matrix encodes within-class scatterness at two levels – the subclass level and the class level. As discussed earlier, this within-class scatter matrix measures within-class multimodality thus maximisng the above Fisher objective can be expected to result in data re-ductions leading to good classification performance. Again the optimal projective matrix consists of eigenvectors corre-sponding to the largest eigenvalues of Ssw−1Sb.

3.4.3 SSDA-3

In this version we use both new matrices thus the Fisher objective function is JSSDA−3(W ) =tr(W T_SSSDA b W ) tr(WT_SSSDA w W ) = tr(W T_S sbW ) tr(WT_S swW ) . (18) We have argued the advantages of both new matrices, therefore there is reason to expect SSDA-3 to perform well. The optimal projective matrix consists of eigenvectors cor-responding to the largest eigenvalues of Ssw−1Ssb.

3.5 Discussion

The SSDA algorithm has two sub-procedures: (1) between-subclass separation by hierarchical agglomerative cluster-ing, which is equipped with our separability criterion; (2) LDA optimisation using within-class and between-class scattering matrices. Both procedures are known to converge.

Algorithm 1 has a time complexity of PC

i=1(Kmax2 +

Kmax ∗ O(Ni2 ∗ log(Ni))), where C is the number of

classes, Kmax is the maxmum number of subclasses to

consider, Ni is the number of data instances in class i and

O(N2

i ∗ log(Ni)) is the time complexity of the hierarchical

agglomerative clustering algorithm [30].

4

E

E

We have designed a series of experiments to evaluate SSDA. Firstly, we want to compare our new SSDA with its closest counterparts, LDA, SDA and MSDA, and two nonlinear discriminative analysis (nonlinear-DA) methods, GDA and KMSDA, in terms of classification performance and run time. Secondly, we want to compare the three versions of SSDA in order to gain a better understanding of SSDA. Thirdly, we compare SSDA with two SDA versions with different clustering approaches in order to gain an insight into SSDA and to see the reasons behind their behaviours in the experiments.

4.1 The Experiments

Linear Discriminant Analysis (and its variants) has been applied to a wide range of data intensive domains, espe-cially in computer vision, as a data reduction technique. In our experiments, we consider a range of classification tasks from general data mining, imbalanced data mining, to face recognition and face verification.

We select ten data sets from UCI Data Repository [31] for general data mining; eight imbalanced data sets from the KEEL Data Repository [32] for imbalanced data mining; and four face databases in the public domain for face recogni-tion/verification – ORL face database [33], AR face database [34], YouTube face database [35], and Labeled Faces in the Wild (LFW) face database [36].

We use k-Nearest Neighbor (kNN, k=1) as the classi-fier and ten-fold cross-validation as evaluation framework. As evaluation metrics we consider estimated mean accuracy (EMA) and standard error of the mean (SEM): EM A =

P10 i=1pi

10 , where pi denotes the percentage of correct

clas-sification in the ith fold validation; SEM = √δ

10, where

δ = qP10

i=1(pi−EM A)2

General information about the ten data sets from UCI Data Repository [31] is shown in TABLE 1. The same in-formation about the eight imbalanced data sets from KEEL Data Repository [32] is shown in TABLE 2. All data sets are numerical and have no missing information as we need to compute the mean and distance.

Name of data set (Acronym) #Instance #Class #Attribute

WDBC 569 2 30

Iris 150 3 4

Vehicle 846 4 18

Red Wine Quality (RWQ) 1599 6 11

Breast Tissue (BT) 106 6 9

Seeds 210 3 7

Banknote Authentication (BA) 1372 2 4

Leaf 340 30 14

Urban Land Cover (ULC) 675 9 147 Forest Type Mapping (FTM) 523 4 27

TABLE 1General information about ten UCI data sets used in experi-ments

Name of data set #Attribute #Instance #Class # IR

Glass1 9 214 2 1.82 New-thyroid1 5 215 2 5.14 Dermatology 34 366 6 5.55 Hayes-roth 4 132 3 1.7 Led7digit-0-2-4-5-6-7-8-9 vs 1 7 443 2 10.97 Pima 8 768 2 1.87 Vowel0 13 988 2 9.98 Wisconsin 9 683 2 1.86

TABLE 2 General information about the eight imbalanced data sets used in the experiments. IR is short for Imbalanced Ratio.

Face Image Data

Face recognition is a multi-class classification problem. The goal of face recognition is to determine if an image is from someone in the database when we have a collection of images for each person in the database. In our experiments we use three face image databases which are commonly used in face recognition research literature: the YouTube faces database [35], the ORL face database [33] and the AR face database [34].

The YouTube faces database: It contains 3425 videos of 1595 different people collected from the YouTube website. The average length of each video clip is 181.3 frames, there are large variations in expression, pose and illumination in each video. In our experiments, we use the aligned image database which contains aligned face frames taken from videos, which are represented using YouTube’s Center-Symmetric LBP (CSLBP) descriptor [37].

The ORL face database: It consists of a total of 400 images of 40 distinct persons. Each parson has ten different images and the size of each image is 92 by 112 pixels, which will generate a feature space of 10,304 dimensions. All the images were taken against a dark homogeneous background with the subjects in an upright, frontal position (see Fig. 4(a) for some examples).

The AR face database: It contains frontal-view face images of 126 different persons (70 males and 56 females). Each person was photographed under different lighting condi-tions and distinct facial expressions, and some images have partial occlusions (sunglasses or scarf). A total of 13 images were taken in each session for a total of two sessions, which

were separated by an interval of two weeks. Therefore, there are 26 frontal face images per person. In our experiments, we use a subset of AR-face data set. We use face images of 100 persons and 7 nonoccluded face images of each person from the first session. Besides, we crop the face part of the image and then resize all images to a standard image size of 80 by 100 pixels (see Fig. 4(b) for some examples). This yields a 8,000-dimensional feature space.

Labeled Faces in the Wild (LFW) Face Database: We use this database for face verification9_{. The database consists}

of 13,233 images of 5,749 people, which are organised into 2 views: view one is a development set of 3,200 pairs, which is used for building models and selecting features; view two is a ten-fold cross-validation set of 6,000 pairs for evalua-tion. The size of each image is 250 by 250 pixels. All the images in LFW were collected from the Internet with large intra-personal variations (see Fig. 4(c) for some examples). There are three versions of the LFW: original, funneled and aligned. In our experiments, we use the aligned version [38]. Besides, we use a subset of view two of LFW. We randomly choose 200 matched face pairs and 200 mismatched face pairs from view two and crop each image to an image of 80 by 150 pixels as in [3]. We thus have 24,000 features for each image of LFW that we use.

Dimensionality Reduction for Face Recognition/Verification The images are initially represented using pixel-based rep-resentation thus having large numbers of features. Therefore face recognition and verification both have the small sample size problem. To deal with this problem, we use the two-stage PCA + LDA [18]. We use PCA to reduce data dimen-sionality retaining principal components which can explain 95% of variance, before LDA, SDA, MSDA ,GDA, KMSDA and SSDA are used.

4.2 The Results: All Methods

UCI Data: Our experimental results on UCI data are pre-sented in TABLE 3 and TABLE 4. It can be seen that SSDA (SSDA-1, SSDA-2, SSDA-3) have better performance than LDA, SDA, MSDA,GDA and KMSDA on a majority of the data sets. In particular SSDA-1 has better performance than LDA on all ten data sets. This set of results suggests that SSDA captures more discriminant information than LDA, SDA, MSDA,GDA and KMSDA .

Imbalanced Data: Our experimental results on imbalanced data are shown in TABLE 5 and TABLE 6. It can be seen that SSDA has better performance than other methods on most of the imbalanced data sets; in particular, SSDA3 has the best performance on all imbalanced data sets.

Face Image Data: Our experimental results are presented in TABLE 7 and TABLE 8. It can be seen that the SSDA variants have better performance than the other methods on most of the face databases; in particular, SSDA1 has the best performance on 3 out of the 4 face databases.

9. Face verification is a binary classification problem, and its goal is to decide if two given face images are from the same person (i.e. match or not).

Methods

Datasets

BA BT FTM Iris Leaf RWQ Seeds ULC Vehicle WDBC LDA 0.9956 ± 0.0016 0.7164 ± 0.0506 0.8468 ± 0.0142 0.9667 ± 0.0149 0.6912 ± 0.0417 0.6529 ± 0.0085 0.9524 ± 0.0142 0.7749 ± 0.0145 0.7398 ± 0.0168 0.9579 ± 0.0079 SSDA-1 1.0000 ± 0.0000 0.7173 ± 0.0409 0.8621 ± 0.0132 0.9733 ± 0.0109 0.7735 ± 0.0232 0.6716 ± 0.0097 0.9762 ± 0.0106 0.7807 ± 0.0091 0.8050 ± 0.0148 0.9614 ± 0.0078 SSDA-2 0.9971 ± 0.0012 0.7182 ± 0.0335 0.8755 ± 0.0127 0.9733 ± 0.0147 0.7382 ± 0.0242 0.6591 ± 0.0102 0.9429 ± 0.0138 0.7764 ± 0.0115 0.7529 ± 0.0134 0.9579 ± 0.0083 SSDA-3 1.0000 ± 0.0000 0.7164 ± 0.0401 0.8777 ± 0.0095 0.9733 ± 0.0109 0.7500 ± 0.0245 0.6667 ± 0.0110 0.9476 ± 0.0111 0.7734 ± 0.0098 0.8049 ± 0.0148 0.9649 ± 0.0091 SDA 0.9956 ± 0.0016 0.5473 ± 0.0478 0.8794 ± 0.0105 0.9667 ± 0.0149 0.5618 ± 0.0272 0.6360 ± 0.0101 0.9524 ± 0.0142 0.4889 ± 0.0176 0.7245 ± 0.0176 0.9297 ± 0.0070 MSDA 0.9913 ± 0.0026 0.6318 ± 0.0568 0.8546 ± 0.0116 0.9533 ± 0.0142 0.7794 ± 0.0249 0.6754 ± 0.0116 0.9667 ± 0.0073 0.6325 ± 0.0175 0.7812 ± 0.0125 0.9510 ± 0.0060 KMSDA(gaussian) 0.9990 ± 0.0008 0.2082 ± 0.0134 0.3725 ± 0.0188 0.9373 ± 0.0171 0.7585 ± 0.0211 0.6069 ± 0.0118 0.9129 ± 0.0219 0.1483 ± 0.0133 0.2293 ± 0.0140 0.6100 ± 0.0258 KMSDA(linear) 0.9993 ± 0.0007 0.6412 ± 0.0396 0.8677 ± 0.0173 0.9773 ± 0.0140 0.7535 ± 0.0214 0.6732 ± 0.0137 0.9333 ± 0.0150 0.7703 ± 0.0205 0.8136 ± 0.0143 0.9313 ± 0.0103 KMSDA(poly) 0.9727 ± 0.0048 0.5282 ± 0.0527 0.7823 ± 0.0231 0.8740 ± 0.0217 0.7244 ± 0.0198 0.6401 ± 0.0121 0.8490 ± 0.0195 0.5644 ± 0.0210 0.7909 ± 0.0144 0.8442 ± 0.0167 GDA(gaussian) 0.7369 ± 0.0162 0.1800 ± 0.0170 0.2863 ± 0.0380 0.9200 ± 0.0194 0.7588 ± 0.0214 0.5559 ± 0.0130 0.9238 ± 0.0238 0.1706 ± 0.0225 0.2540 ± 0.0151 0.4993 ± 0.0458 GDA(linear) 0.8863 ± 0.0361 0.6400 ± 0.0382 0.7151 ± 0.0179 0.9600 ± 0.0147 0.7706 ± 0.0227 0.5828 ± 0.0143 0.9429 ± 0.0119 0.3009 ± 0.0212 0.4727 ± 0.0168 0.8752 ± 0.0150 GDA(poly) 0.9177 ± 0.0198 0.6400 ± 0.0382 0.7152 ± 0.0160 0.9467 ± 0.0166 0.7706 ± 0.0227 0.5891 ± 0.0131 0.9524 ± 0.0123 0.3009 ± 0.0212 0.4727 ± 0.0168 0.8752 ± 0.0150 TABLE 3EMA±SEM of all methods on ten UCI data sets

Methods

Datasets

BA BT FTM Iris Leaf RWQ Seeds ULC Vehicle WDBC

LDA 0.4608 0.4684 0.4116 0.3469 0.4088 0.4470 0.3726 1.0508 0.3943 0.3931 SSDA-1 13.4603 8.4878 9.0574 4.9063 5.8354 3.7611 5.3393 28.1698 11.5249 7.9278 SSDA-2 13.1489 8.6453 8.9739 5.0511 6.0323 3.7358 5.4260 22.5437 11.4149 7.6538 SSDA-3 13.2278 8.6484 8.9999 4.9841 7.1088 3.9986 5.5386 24.6621 11.5299 7.8622 SDA 14.0491 5.3398 10.9097 3.3197 7.1660 9.6376 9.3230 73.7869 21.2983 20.1334 MSDA 84.7338 44.3218 1197.4534 85.1082 1158.5275 441.1192 176.1178 41389.6441 847.1926 493.4477 KMSDA(gaussian) 2690.3158 30.1266 302.3954 66.6830 4416.8484 3037.8693 112.1421 7065.1503 415.5467 300.1595 KMSDA(linear) 2522.4015 28.3255 380.1810 66.5756 4921.0894 3210.1374 102.2283 6565.1182 733.3666 345.4465 KMSDA(poly) 2812.9827 25.7762 414.3065 66.7427 4474.3195 3068.0893 96.6440 8139.9187 586.9152 339.9491 GDA(gaussian) 73.4912 0.2170 4.6560 0.3143 1.6497 114.3346 1.0386 9.8661 16.1372 7.6408 GDA(linear) 34.0265 0.1945 1.3793 0.1394 1.5265 53.4882 0.3356 8.0627 4.9252 6.2217 GDA(poly) 34.4164 0.1598 1.3974 0.1416 1.4434 52.3882 0.2470 7.3010 4.5603 5.5423

TABLE 4Run time, in second, of all methods on ten UCI data sets

4.3 The Results: SSDA-1, SSDA-2 and SSDA-3

Although all versions of SSDA have better performance than LDA, SDA, MSDA, KMSDA and GDA in most of the cases, SSDA-1 appears to be the best of the three versions in many cases. To validate this further, a comparative study is conducted on the three versions of SSDA. We varied Kmax

from 1 to 15 and, for each Kmax value, we run the three

SSDA algorithms on 10 UCI data sets and 3 face databases, and we counted how many times each algorithm obtained the best performance. These counts are charted in Fig. 5. It should be noted that the sum of the counts for each Kmax

may be higher than 13 due to ties. It is clear that SSDA-1 is a clear winner especially for bigger Kmax.

This evaluation suggests that combining Ssb and Sw

can get more discriminant information than other ways of combination.

4.4 The Results: SDA Versions Using Different Cluster-ing Approaches

We modified the SDA implementation by replacing SDA’s NN-clustering by the separability criterion based hierarchical clustering as used for SSDA – named SSDA clustering. We conducted experiments with the two versions of SDA (SDA with NN-clustering and SDA with SSDA clustering) and SSDA on 10 UCI data sets. Experimental results are shown in TABLE 9. It can be seen that SDA with SSDA clustering is

Methods

Datasets

Glass1 New-thyroid1 Dermatology Hayes-roth Led7digit Pima Vowel0 Wisconsin LDA 0.6119 ± 0.0226 0.9483 ± 0.0150 0.9645 ± 0.0134 0.7725 ± 0.0499 0.9390 ± 0.0067 0.6782 ± 0.0216 0.9393 ± 0.0067 0.9635 ± 0.0090 SSDA-1 0.8316 ± 0.0175 0.9859 ± 0.0072 0.9700 ± 0.0075 0.8022 ± 0.0435 0.9390 ± 0.0067 0.6874 ± 0.0196 1.0000 ± 0.0000 0.9649 ± 0.0082 SSDA-2 0.6175 ± 0.0236 0.9814 ± 0.0124 0.9670 ± 0.0089 0.7582 ± 0.0478 0.9391 ± 0.0067 0.6808 ± 0.0207 0.9433 ± 0.0064 0.9590 ± 0.0093 SSDA-3 0.8374 ± 0.0244 0.9952 ± 0.0048 0.9700 ± 0.0027 0.8176 ± 0.0449 0.9391 ± 0.0067 0.6938 ± 0.0172 1.0000 ± 0.0000 0.9692 ± 0.0067 SDA 0.5799 ± 0.0412 0.9810 ± 0.0105 0.9589 ± 0.0085 0.7725 ± 0.0499 0.9345 ± 0.0070 0.6886 ± 0.0182 0.9393 ± 0.0067 0.9590 ± 0.0065 MSDA 0.7623 ± 0.0273 0.9905 ± 0.0063 0.9370 ± 0.0158 0.6429 ± 0.0519 0.9345 ± 0.0062 0.5896 ± 0.0244 1.0000 ± 0.0000 0.8902 ± 0.0107 KMSDA(gaussian) 0.7402 ± 0.0281 0.8802 ± 0.0216 0.3558 ± 0.0426 0.7764 ± 0.0455 0.9265 ± 0.0106 0.6475 ± 0.0236 0.9993 ± 0.0006 0.9053 ± 0.0266 KMSDA(linear) 0.7680 ± 0.0321 0.9765 ± 0.0112 0.9661 ± 0.0094 0.7553 ± 0.0399 0.9388 ± 0.0067 0.6789 ± 0.0179 0.9986 ± 0.0012 0.9517 ± 0.0071 KMSDA(poly) 0.7408 ± 0.0282 0.9381 ± 0.0144 0.9609 ± 0.0078 0.8117 ± 0.0363 0.9368 ± 0.0084 0.6442 ± 0.0168 1.0000 ± 0.0000 0.9442 ± 0.0078 GDA(gaussian) 0.6965 ± 0.0152 0.6881 ± 0.0327 0.1532 ± 0.0321 0.7357 ± 0.0589 0.9345 ± 0.0070 0.5131 ± 0.0546 0.9160 ± 0.0105 0.8042 ± 0.0424 GDA(linear) 0.7433 ± 0.0376 0.8883 ± 0.0244 0.5795 ± 0.0375 0.7495 ± 0.0651 0.9391 ± 0.0067 0.6444 ± 0.0211 0.9717 ± 0.0039 0.9590 ± 0.0094 GDA(poly) 0.7528 ± 0.0374 0.8879 ± 0.0245 0.5902 ± 0.0433 0.7198 ± 0.0615 0.9390 ± 0.0058 0.6560 ± 0.0222 0.9787 ± 0.0053 0.9561 ± 0.0092 TABLE 5EMA±SEM of all methods on eight imbalanced data sets

Methods

Datasets

Glass1 New-thyroid1 Dermatology Hayes-roth Led7digit Pima Vowel0 Wisconsin LDA 0.6590 0.0643 0.1265 0.0597 0.1355 0.1429 0.2050 0.1257 SSDA-1 7.4430 6.2264 21.9584 8.9783 8.8396 12.7986 28.3226 12.5941 SSDA-2 7.3851 6.4622 20.3601 8.9707 8.3202 10.6121 26.0256 10.5545 SSDA-3 7.7689 6.3447 20.6194 9.0347 8.8047 11.9960 27.0266 12.0818 SDA 14.8135 10.2511 48.5555 10.7161 14.8995 23.9342 32.0563 23.8213 MSDA 14.2680 8.9955 162.0084 34.5359 14.8178 5.2682 15.4729 7.6626 KMSDA(gaussian) 91.7083 78.0098 785.2526 52.7884 428.1921 896.2775 2245.4591 853.9795 KMSDA(linear) 75.1814 65.2564 964.5750 54.4705 241.8900 762.5810 1401.7950 437.2513 KMSDA(poly) 70.6793 62.1042 834.6825 51.0337 350.5261 983.0632 1799.6884 779.3523 GDA(gaussian) 1.1456 1.5269 2.6936 0.2528 1.4012 25.1368 28.4806 9.0260 GDA(linear) 0.6904 0.3037 1.4987 0.1497 0.7809 8.0520 15.3227 4.7597 GDA(poly) 0.6404 0.3240 1.5158 0.1678 0.7831 8.4522 15.9725 5.1790

TABLE 6Run time, in second, of all methods on eight imbalanced data sets

Methods Datasets YouTube LFW AR ORL LDA 0.9790±0.0043 0.5450±0.0298 0.9157±0.0105 0.9700±0.0122 SSDA-1 0.9830±0.0030 0.7100±0.0155 0.9471±0.0068 0.9725±0.0058 SSDA-2 0.9800±0.0045 0.5900±0.0369 0.9200±0.0080 0.9725±0.0115 SSDA-3 0.9800±0.0045 0.7000±0.0144 0.9114±0.0090 0.9725±0.0115 SDA 0.9790±0.0043 0.7075±0.0247 0.9157±0.0105 0.9700±0.0122 MSDA 0.9830±0.0037 0.6600±0.0208 0.8720±0.0129 0.9775±0.0096 KMSDA(gaussian) 0.9830±0.0047 0.5000±0.0000 0.0000±0.0000 0.0250±0.0000 KMSDA(linear) 0.9790±0.0038 0.6750±0.0227 0.9200±0.0105 0.9625±0.0125 KMSDA(poly) 0.9800±0.0049 0.6900±0.0292 0.9443±0.0065 0.9825±0.0065 GDA(gaussian) 0.9730±0.0060 0.5000±0.0000 0.0014±0.0014 0.0250±0.0000 GDA(linear) 0.9790±0.0043 0.5575±0.0140 0.9157±0.0105 0.9700±0.0122 GDA(poly) 0.9800±0.0039 0.5625±0.0136 0.9157±0.0105 0.9700±0.0122

Methods Datasets AR LFW ORL YouTube LDA 3.8463 4.1128 2.6092 7.7797 SSDA-1 54.9050 367.5684 32.4669 523.2413 SSDA-2 57.0464 301.0679 30.4252 609.9837 SSDA-3 59.2389 318.6475 36.1923 628.6595 SDA 363.7470 1179.4425 654.5643 8761.0927 MSDA 1042403.8487 6639.7915 382253.9291 609021.1228 KMSDA(gaussian) 416208.2398 2225.8405 162803.3881 — KMSDA(linear) 256660.7750 2547.5120 144394.6722 — KMSDA(poly) 479095.5967 2276.5896 131822.3761 — GDA(gaussian) 22.8550 8.5004 6.6577 61.8623 GDA(linear) 14.1721 8.9017 5.6373 29.1588 GDA(poly) 13.6173 8.2842 5.7491 29.5443

TABLE 8Run time, in second, of all methods on four face databases. The missing entries indicate the respective algorithms ran for too long.

not consistently different to SDA with NN clustering. Fur-thermore SSDA is better than both versions of SDA on most of the data sets. This suggests that the good performance of SSDA should be due to the new separability-oriented scatter-ness proposed in this paper.

4.5 The Results: Runtime Performance

Runtime results of these algorithms are presented in TABLE 4, TABLE 6, and TABLE 8. It is clear that all versions of SSDA are slower than LDA but faster than SDA and MSDA in most of the cases.

5

S

In this section we evaluate the separability of LDA, SDA, MSDA and SSDA in terms of two measures: (1) visually, the overlapping of the subclasses obtained and (2) the extent to which the classifying of data in the LDA space are compact (the variance between members of a class is small) and are also well separated (the means of different classes are sufficiently far apart). We select SSDA-1 in this evaluation as it is the best of the three versions of SSDA.

For measure (1) we create charts, Fig. 6, showing subclass structures sought after by SDA, MSDA and SSDA-1 in the original data space. We can see subclass structure of SSDA-1 has much less overlapping than SDA and MSDA.

For measure (2) we use the well known Dunn index10

[40]. TABLE 10 shows the Dunn index value for the classify-ing of data in the original data space and the LDA spaces. It is clear that SSDA-1 has highest Dunn index value in 8 out of 13 data sets used in this experiment.

To show their difference in the LDA space further we take a closer look at a data set that has two classes – Banknote Authentication, which has 1372 instances and 4 features. We divide it equally into two parts – one for training and another for testing with 686 instances each. We apply LDA, SDA, MSDA and SSDA-1 to the training data to map them to the LDA space. The distributions of the training data in these LDA spaces are shown in Fig. 7. Note that LDA and SDA reduced the training data to

10. The Dunn index is a metric for evaluating clustering algorithms. It measures the “clusterness” of a clustering (i.e. partition) of a data set – the extent to which the “clusters are compact, with a small variance between members of the cluster, and well separated, where the means of different clusters are sufficiently far apart, as compared to the within cluster variance” [39]. For a given data set, a higher Dunn index indicates better clustering.

1 LDA dimension thus the data distribution is a straight line, MSDA to 2 LDA dimensions, and SSDA-1 to 4 LDA dimensions where we select the first two components to show the data distribution. It is clear that using the first two LDA components, the training data can not be completely separated by their class memberships. There is no more LDA component to use in all cases but SSDA-1. When we consider the third LDA component in SSDA-1, the training data can be completely separated as shown in Fig. 7(d).

We also apply nearest neighbour classifier to the test data set, using the projected training data set in the LDA space as the model. The classification accuracies are: 99.13%, 99.13%, 99.27%, and 100.00% for LDA, SDA, MSDA and SSDA-1 respectively.

6

C

In this paper we propose a new LDA variant, separability oriented subclass discriminant analysis (SSDA), which uses a separability criterion we devise to divide every class into sub-classes. This subclass structure has much less overlapping than those obtained by SDA and MSDA, and is used as the basis of constructing an LDA projection (from the original data space to the LDA space) using new scatter matrices we defined here. The projected data in the LDA space have con-sistently higher Dunn index values than LDA/SDA/MSDA, meaning they have higher within-class compactness and higher between-class separation. Extensive experimentation has shown that in most cases SSDA outperforms the original LDA as well as SDA and MSDA, the two state of the art subclass-based LDA variants. SSDA is also faster than SDA and MSDA in most cases.

The difference between SSDA and LDA is the fact that SSDA has exploited the subclass structure within classes. The difference between SSDA and SDA/MSDA is the fact that, although they all exploit the subclass structure, they use different criteria to divide a class into subclasses and they use different scatter matrices. SSDA aims to separate different subclasses within every class as well different classes whereas SDA and MSDA do not have the same aim. It is well known that reducing variance (as a means of reducing overefitting) under given learning bias is one way of reducing generalisation errors. The usual approach is to control the size of hypothesis space by e.g. keeping the dimensionality of the hypothesis space small or keeping the norm of the hypothesis space small. SSDA advocates separating different subclasses within every class as well as

Datasets

Methods SDA with NN clustering

SDA with

SSDA clustering SSDA-1 SSDA-2 SSDA-3 BA 0.9956 ± 0.0016 0.9964 ± 0.0012 1.0000 ± 0.0000 0.9971 ± 0.0012 1.0000 ± 0.0000 BT 0.5473 ± 0.0478 0.6691 ± 0.0436 0.7173 ± 0.0409 0.7182 ± 0.0335 0.7164 ± 00.0401 FTM 0.8794 ± 0.0105 0.6895 ± 0.0721 0.8621 ± 0.0132 0.8755 ± 0.0127 0.8777 ± 0.0095 Iris 0.9667 ± 0.0149 0.9733 ± 0.0109 0.9733 ± 0.0109 0.9733 ± 0.0147 0.9733 ± 0.0109 Leaf 0.5618 ± 0.0272 0.5824 ± 0.0297 0.7735 ± 0.0232 0.7382 ± 0.0242 0.7500 ± 0.0245 RWQ 0.6360 ± 0.0101 0.6492 ± 0.0129 0.6716 ± 0.0097 0.6591 ± 0.0102 0.6667 ± 0.0110 Seeds 0.9524 ± 0.0142 0.9524 ± 0.0142 0.9762 ± 0.0106 0.9429 ± 0.0138 0.9476 ± 0.0111 ULC 0.4889 ± 0.0176 0.4950 ± 0.0227 0.7807 ± 0.0091 0.7764 ± 0.0115 0.7734 ± 0.0098 Vehicle 0.7245 ± 0.0176 0.6608 ± 0.0319 0.8050 ± 0.0148 0.7529 ± 0.0134 0.8049 ± 0.0148 WDBC 0.9297 ± 0.0070 0.9121 ± 0.0109 0.9614 ± 0.0078 0.9579 ± 0.0083 0.9649 ± 0.0091

TABLE 9EMA±SEM of SDA with NN-clustering, SDA with SSDA clustering, and SSDA on 10 UCI database.

Datasets Original LDA SSDA-1 SDA MSDA BA 0.0395 0.0000 0.0914 0.0000 0.0043 BT 0.0001 0.0285 0.0062 0.0001 0.0254 FTM 0.0280 0.0093 0.0445 0.0468 0.0001 Iris 0.0585 0.0146 0.0817 0.0819 0.0176 Leaf 0.0050 0.0140 0.0490 0.0074 0.0106 RWQ 0.0007 0.0051 0.0096 0.0040 0.0049 Seeds 0.0456 0.0068 0.0767 0.0466 0.0014 ULC 0.0068 0.0382 0.0570 0.0245 0.0113 Vehicle 0.0095 0.0058 0.0325 0.0235 0.0185 WDBC 0.0025 0.0001 0.0080 0.0027 0.0005 AR 0.1741 0.2497 0.2689 0.2497 0.2562 LFW 0.2288 0.0000 0.0808 0.0000 0.0632 ORL 0.4299 0.8119 0.4791 0.4743 0.3140 TABLE 10Dunn index for a classifying of data in the original data space, and an LDA space by LDA/SSDA-1/SDA/MSDA on all ten UCI data sets and the AR/LFW/ORL face data sets.

separating different classes. In other words, SSDA advocates within-class multimodality to classification in contrast to within-class unimodality. In the case of multimodality, each modality has small hypothesis space whereas in the case of unimodality, the single modality has large hypothesis space. As a result the multimodality approach is expected to have lower variance than the unimodality approach. In practice the unimodality approach may still result in more than one modality in the model, depending on the data and the learning algorithm, and the multimodality approach may end up with only one modality. A thorough investigation of multimodality/unimodality will involve a lot of testing and validating using both artificial and real data, which is clearly beyond the scope of this paper and is a direction for future work.

Other future work on SSDA will focus on two

direc-tions: further increase of classification accuracy and further reduction in computation time. In the first direction we will explore other (possibly nonlinear) ways of processing data to increase Dunn index of data. In the second direction we will redesign the whole SSDA pipeline to speed up the clustering process of finding the optimal K∗. Due to the way hierarchical clustering works, we can run the hierarchical clustering algorithm once (instead of Kmax times in the

current SSDA pipeline) from K = n (when every data instance is a cluster) to K = 1 (when all data instances are merged into a single cluster), calculating our separability criterion for every K thus being able to find the optimal K∗_{that has the best separability criterion value at a lower}

computational cost. .

R

[1] R. A. Fisher, “The use of multiple measurements in taxonomic problems,” Annals of eugenics, vol. 7, no. 2, pp. 179–188, 1936. [2] L. Zhang, M. Yang, Z. Feng, and D. Zhang, “On the dimensionality

reduction for sparse representation based face recognition.” in ICPR, 2010, pp. 1237–1240.

[3] M. Kan, D. Xu, S. Shan, W. Li, and X. Chen, “Learning prototype hyperplanes for face verification in the wild,” Image Processing, IEEE Transactions on, vol. 22, no. 8, pp. 3310–3316, 2013.

[4] X. He, D. Cai, and J. Han, “Learning a maximum margin subspace for image retrieval,” Knowledge and Data Engineering, IEEE Trans-actions on, vol. 20, no. 2, pp. 189–201, 2008.

[5] C. L. He, L. Lam, and C. Y. Suen, “Rejection measurement based on linear discriminant analysis for document recognition,” Interna-tional Journal on Document Analysis and Recognition (IJDAR), vol. 14, no. 3, pp. 263–272, 2011.

[6] Z. Fan, Y. Xu, and D. Zhang, “Local linear discriminant analysis framework using sample neighbors.” IEEE Transactions on Neural Networks, vol. 22, no. 7, pp. 1119–1132, 2011.

[7] H. Wan, G. Guo, H. Wang, and X. Wei, A New Linear Discriminant Analysis Method to Address the Over-Reducing Problem. Springer International Publishing, 2015.

[8] K. Fukunaga, Introduction to statistical pattern recognition. Aca-demic press, 2013.

[9] Z. Li, D. Lin, and X. Tang, “Nonparametric discriminant analysis for face recognition,” Pattern Analysis and Machine Intelligence, IEEE Transactions on, vol. 31, no. 4, pp. 755–761, 2009.

[10] M. Zhu and A. M. Martinez, “Subclass discriminant analysis,” Pattern Analysis and Machine Intelligence, IEEE Transactions on, vol. 28, no. 8, pp. 1274–1286, 2006.

[11] N. Gkalelis, V. Mezaris, and I. Kompatsiaris, “Mixture subclass discriminant analysis,” Signal Processing Letters, IEEE, vol. 18, no. 5, pp. 319–322, 2011.

[12] N. Gkalelis, V. Mezaris, I. Kompatsiaris, and T. Stathaki, “Mixture subclass discriminant analysis link to restricted gaussian model and other generalizations,” Neural Networks and Learning Systems, IEEE Transactions on, vol. 24, no. 1, pp. 8–21, 2013.

[13] Wikipedia, “Linear discriminant analysis,” https://en.wikipedia. org/wiki/Linear discriminant analysis, accessed: 2015-09-5. [14] S. Pang, S. Ozawa, and N. Kasabov, “Incremental linear

discrimi-nant analysis for classification of data streams,” Systems, Man, and Cybernetics, Part B: Cybernetics, IEEE Transactions on, vol. 35, no. 5, pp. 905–914, 2005.

[15] T.-K. Kim, B. Stenger, J. Kittler, and R. Cipolla, “Incremental linear discriminant analysis using sufficient spanning sets and its applications,” International Journal of Computer Vision, vol. 91, no. 2, pp. 216–232, 2011.

[16] D. Chu, L.-Z. Liao, M.-P. Ng, and X. Wang, “Incremental linear discriminant analysis: A fast algorithm and comparisons,” Neural Networks and Learning Systems, IEEE Transactions on, vol. 26, no. 11, pp. 2716–2735, Nov 2015.

[17] Y. A. Ghassabeh, F. Rudzicz, and H. A. Moghaddam, “Fast in-cremental lda feature extraction,” Pattern Recognition, vol. 48, pp. 1999–2012, 2015.

[18] P. N. Belhumeur, J. P. Hespanha, and D. J. Kriegman, “Eigenfaces vs. fisherfaces: Recognition using class specific linear projection,” Pattern Analysis and Machine Intelligence, IEEE Transactions on, vol. 19, no. 7, pp. 711–720, 1997.

[19] A. Sharma and K. K. Paliwal, “A new perspective to null linear discriminant analysis method and its fast implementation us-ing random matrix multiplication with scatter matrices.” Pattern Recognition, vol. 45, no. 6, pp. 2205–2213, 2012.

[20] Y. Guo, “Regularized linear discriminant analysis and its applica-tion in microarrays,” Biostatistics, vol. 8, no. 1, pp. 86–100, 2007. [21] A. Sharma, K. K. Paliwal, S. Imoto, and S. Miyano, “A feature

selection method using improved regularized linear discriminant analysis,” Machine vision and applications, vol. 25, no. 3, pp. 775– 786, 2014.

[22] A. Sharma and K. K. Paliwal, “A deterministic approach to regu-larized linear discriminant analysis,” Neurocomputing, vol. 151, pp. 207–214, 2015.

[23] X. Shu and H. Lu, “Linear discriminant analysis with spectral regularization,” Applied intelligence, vol. 40, no. 4, pp. 724–731, 2014.

[24] M. Li and B. Yuan, “2d-lda: A statistical linear discriminant analy-sis for image matrix,” Pattern Recognition Letters, vol. 26, no. 5, pp. 527–532, 2005.

[25] R. P. Duin and M. Loog, “Linear dimensionality reduction via a heteroscedastic extension of lda: the chernoff criterion,” Pattern Analysis and Machine Intelligence, IEEE Transactions on, vol. 26, no. 6, pp. 732–739, 2004.

[26] L. Clemmensen, “Sparse discriminant analysis,” Technometrics, vol. 53, no. 4, pp. 406–413, 2011.

[27] A. M. Martinez and M. Zhu, “Where are linear feature extraction methods applicable?” Pattern Analysis and Machine Intelligence, IEEE Transactions on, vol. 27, no. 12, pp. 1934–1944, 2005. [28] S. C. Johnson, “Hierarchical clustering schemes,” Psychometrika,

vol. 32, no. 3, pp. 241–254, 1967.

[29] M. Zhu and A. M. Martnez, “Optimal subclass discovery for discriminant analysis,” in Computer Vision and Pattern Recognition Workshop, 2004. CVPRW ’04. Conference on, 2004, pp. 97–97. [30] L. Rokach and O. Maimon, “Clustering methods,” in Data mining

and knowledge discovery handbook. Springer, 2005, pp. 321–352. [31] C. Blake and C. J. Merz, “{UCI}repository of machine learning

databases,” 1998.

[32] J. Alcal´a, A. Fern´andez, J. Luengo, J. Derrac, S. Garc´ıa, L. S´anchez, and F. Herrera, “Keel data-mining software tool: Data set repos-itory, integration of algorithms and experimental analysis frame-work,” Journal of Multiple-Valued Logic and Soft Computing, vol. 17, no. 2-3, pp. 255–287, 2010.

[33] F. S. Samaria and A. C. Harter, “Parameterisation of a stochastic model for human face identification,” in Applications of Computer Vision, 1994., Proceedings of the Second IEEE Workshop on. IEEE, 1994, pp. 138–142.

[34] A. M. Mart´ınez and A. C. Kak, “Pca versus lda,” Pattern Analysis and Machine Intelligence, IEEE Transactions on, vol. 23, no. 2, pp. 228–233, 2001.

[35] L. Wolf, T. Hassner, and I. Maoz, “Face recognition in uncon-strained videos with matched background similarity,” vol. 42, no. 7, pp. 529–534, 2011.

[36] G. B. Huang, M. Ramesh, T. Berg, and E. Learned-Miller, “Labeled faces in the wild: A database for studying face recognition in unconstrained environments,” Technical Report 07-49, University of Massachusetts, Amherst, Tech. Rep., 2007.

[37] M. Heikkil, M. Pietikinen, and C. Schmid, “Description of interest regions with center-symmetric local binary patterns,” in Computer Vision, Graphics and Image Processing, Indian Conference, Icvgip 2006, Madurai, India, December 13-16, 2006, Proceedings, 2006, pp. 58–69. [38] L. Wolf, T. Hassner, and Y. Taigman, “Similarity scores based on

background samples,” in Computer Vision–ACCV 2009. Springer, 2010, pp. 88–97.

[39] Wikipedia, “Dunn index,” https://en.wikipedia.org/wiki/Dunn index, accessed: 2015-12-21.

[40] J. C. Dunn, “A fuzzy relative of the isodata process and its use in detecting compact well-separated clusters,” Journal of Cybernetics, vol. 3, no. 3, pp. 32–57, 1973.

Huan Wan received the bachelor of engineering degree in computer science and technology from Shangrao Normal University, Jiangxi, China, in 2013. She is currently pursuing the M.S. degree in computer application and technology in the School of Mathematics and Computer Science, Fujian Normal University, China. Her current re-search interests are feature extraction and face verification.

Fig. 1Illustration of local scatterness and global scatterness of a class of data.

(a)Sw in the original LDA –Sw is covariance of every

instance of one class and the mean of the class. It is calculated as: PN2

j=1(x2j − µ2)(x2j − µ2)

T_{, where x} 2j

denotes thejth instance of Class 2,N2 is the number of

instances in Class 2.

(b)Sswin our SSDA –Ssw= Ssw1+ Ssw2.Ssw1is

covari-ance of subclass instcovari-ances and corresponding subclass mean, which is calculated as:PN23

m=1(x23m− µ23)(x23m−

µ23)T, where Subclass 23 denotes the 3th subclass in

Class 2,x23m denotes themth instance in Subclass 23

andµ23 is the mean of Subclass 23.Ssw2 is covariance

of subclass means and class mean. It is calculated as: P3

j=1(µ2j−µ2)(µ2j−µ2)T, whereµ2jis thejth subclass

mean in Class 2 andµ2is the mean of Class 2.

Fig. 2Illustration ofSwandSsw.

Hui Wang is Professor of Computer Science at Ulster University, and is Visiting Professor at Fu-jian Normal University. His research interests are machine learning, logics and reasoning, combi-natorial data analytics, and their applications in image, video, spectra and text analysis. He has over 200 publications in these areas.

He played a pivotal role in the development of a new algebraic framework for machine learn-ing, Lattice Machine. He proposed the original concept of contextual probability, which can be used for uncertainty reasoning/quantification, probability estimation and machine learning. He also proposed a generic similarity measure, neighbourhood counting, and its specialisations on multivariate data, sequences, tree and graph structures. The contextual probability and neighbourhood counting similarity bear strong similarity to kernel meth-ods, and were independently developed.

He is an associate editor of IEEE Transactions on Cybernetics, and an associate editor of International Journal of Machine Learning and Cyber-netics. He is the Chair of IEEE SMCS Northern Ireland Chapter, and a member of IEEE SMCS Board of Governors (2010-2013). He is principal investigator of a number of regional, national and international projects in the areas of image/video analytics (Horizon 2020 funded DESIREE, FP7 funded SAVASA, Royal Society funded VIAD), text analytics (INI funded DEEPFLOW, Royal Society funded BEACON), and intelligent content management (FP5 funded ICONS); and is co-investigator of several other EU funded projects.

(a) Sb in original LDA – Sb is the covariance of class

means and the mean of whole instances. It is calculated as:P3

i=1(µi− µ)(µi− µ)T, whereµiis the mean of class

iandµis the mean of whole instances.

(b)Ssbin our SSDA –Ssbis covariance of subclass means

and the mean of whole instances, which is calculated as: P3

i=1

Pki

j=1(µij − µ)(µij − µ)T, ki is the number of

sublcasses in classiandµijis the mean of subclassj

in classi.

Fig. 3Illustration ofSbandSsb.

Gongde Guo received the bachelor of engineer-ing degree in computer software from Zhejiang University, China in 1985 and PhD degree in computer science from University of Ulster in 2004. He is currently working at School of Math-ematics and Computer Science, Fujian Normal Univeristy as a professor. His research interests include data mining and machine learning.

Xin Wei received the bachelor of engineering degree in computer science and technology from Shangrao Normal University, Jiangxi, China, in 2013; and the master degree in computer appli-cation and technology from the School of Math-ematics and Computer Science, Fujian Normal University, China. He is currently pursuing his PhD at Ulster University, UK. His current re-search interests are face recognition and image representation.

(a) Images in ORL face database

(b) Images in AR face database

(c) LFW face database: matched face pairs in the left; mismatched face paris in the right

Fig. 4Sample images from the face databases

T imes of Obtaing Best Classification Performance

Maximum Number of Subclasses in Each Class

Fig. 5Number of wins by SSDA-1, SSDA-2 and SSDA-3 for different Kmax on all10UCI data sets and3face databases – AR, ORL and

LFW.

(a) Distribution of Iris data in the first two dimensions

(b) Subclass structure by SDA (c) Subclass structure by MSDA (d) Subclass structure by SSDA-1

Fig. 6Iris data: subclass structures sought after by SDA, MSDA and SSDA-1. Every circle represents one cluster, which is centred at the mean of the cluster and has a radius as the distance between the centre and furtherest point in the cluster.

(a) LDA and SDA by only one component

(b) MSDA by all two compo-nents

(c) SSDA-1 by first two com-ponents

(d) SSDA-1 by first three components
