LAN
mark-OF
Fibre Optic Solutions
Complex Data Centres require fibre solutions
ACCESS SWITCH
CORE SWITCH SERVER SAN SWITCH
LANmark-OF OM3 / OM4 LANmark-OF Single Mode Copper
Infiniband MPO LANmark-OF Slimflex Patch Cords
•
The never ending need for increased bandwidth pushes the limits of data transmission. Data centres are at the
forefront for these advanced applications, most of them are requiring fibre solutions. Multimode remains the fibre
transmission of choice for Data Centres due to the low cost of multi mode transceivers. Nexans OM3/OM4 fibres
and connectivity products support multimode over longer distances than other fibre products, which gives Data
Centres designers more freedom to create an optimal facility. It expands fibre’s ability to link server to SAN, server
to access switch, or access switch to core switch for 10G/40G/100G Ethernet and 8G/16G Fibre Channel.
•
Multiple cross connects manage patching in the more and more complex data centres. As a result more connectors
mean higher attenuation in the optical channel. Therefore low loss connectivity is a key requirement for nowadays
Data Centres and advanced applications.
•
Nexans supports Ethernet and Fibre Channel applications with two kinds of fibre solutions. Traditional connectivity
based on LC connectors provides a cost effective implementation for 10G Ethernet and Fibre Channel without the
possibility to migrate to 40G/100G. The new Plug&Play solution based on an advanced multifibre connector
allows fast installations and quick changes for the current 10G needs and provides in addition a migration path to
40G.
Plug&Play solution: Scalable and fast to install solution
for your current and future needs
•
Very fast installation based on MPO technology
•
Most flexible Data Centre solution
•
Investment secured: migration to 40G/100G possible
•
Guaranteed performance for 10G and 40G Ethernet,
8G and 16G Fibre Channel in complex Data Centre
configurations with multiple cross connects
•
Modular system and no fibre arrangement required
Cost effective Data Centre solution for your current needs
based on LC connectivity
•
Fast installation based on traditional technology
•
Fibres connected one by one
•
Extended distances for advanced applications due to
less connectors
•
Bandwidth up to 10G
•
Cost effective solution
Save rack space with LANmark-OF
high density panels.
Rack space is at a premium. With Nexans patch panel solutions individual patch cord managers are eliminated. This effectively doubles the rack capacity. The integrated patch guide of the straight preloaded patch panel guides the patch cords to the side. The introduction of the angled patch panel takes this even a step further and eliminates the patch guide completely. The patch panels have a medium capacity of 24 LC ports or a high density of 48 ports within one height unit.
High density reduces required rack space, but making changes becomes a challenge. The LANmark-OF patch cord removal tool facilitates the patch cord operation in such environments.
Save installation times
with expertly designed assemblies
Pre-terminated fibre cable assemblies with single fibre connectors like LC or multi fibre connectors like MPO accelerate panel to panel connections because they are ready for immediate installation and have been pre-tested for reliable performance. Installation time is reduced by 80 % compared to conventional termination methods and site interruption is limited.
Large Data Centres can be installed in a short time with reduced specialised manpower.
These assemblies are supported by preloaded patch panels and MPO modules that facilitate a quick and reliable start up of the data centre.
Reduce influence of cabling on cooling
Flexible, tight diameter cables for Pre-Term are lightweight and pliable, making them easy to arrange in patch panels and cable trays. Their small diameter also reduces the valuable space needed to accommodate each cable, which improves air flow to reduce cooling costs. High fibre count cables reduce the number of cables to be installed and minimises the required tray space.
The 96 core MPO-MPO Pre-Term features only a diameter of 6.4 mm. 40.000 10.000 1.000 100 1 1995 2000 2005 2010 2015 2020 (Mbps) Working desk Cloud Computing Streamed Video Building Automation Web Conferencing Hosted Virtual Desktop Backbone Collaborative CAD tools
Secure current investment for future applications
With the never ending increase in bandwidth the introduction of 40G or even 100G in a Data Centre is just a couple of years away. Both 40G and 100G connectivity are centralised around the multi array MPO connector. Data Centres can pre-pare for the migration from LC to MPO connectivity by installing now a cable infrastructure based on MPO modules. When the fast changing active equipment is upgraded to 40G/100G the cable infrastructure is already in place. The risk for Data Centre interruption is limited since pulling additional cables is not required.
Practical solutions for real needs
Pre-terminated assemblies optimised for Data Centre
installation
Cables in Data Centres need to be routed through many turns and bends. Pre-Terms have a short bend radius of maximum 75mm. This facilitates installation in such environments without the need to use the more expensive bend insensitive fibre in the backbone.
During installation the connectors of the Pre-Terms are well protected by a reinforced tube. A pulling eye mounted directly on the strength element of the cable facilitates installation in challenging environments.
The Pre-Terms are customised and come in 1m increments to minimise management of overlengths, a key issue in high density cable situations.
Consistent patching without polarity concerns
Nexans MPO expertly designed Pre-Term solution eliminates the aggrevations of traditional polarity methods. No special polarity components, patch cords or installation procedures are required. Nexans’ round Micro-Bundle design and advanced wiring scheme in the Pre-Term construction solves operational patching challenges. Simply pull the Pre-Term cables between the two racks, install identical cassettes on both sides and connect to active devices with the same traditional patch cords on both sides of the channel. With a pair flip in the trunk cable Nexans solves a complex polarity problem giving a simple to install solution to the customer.
Reduce risk for data centre down time
in patching area
Frequent adds and changes put pressure on rules for bend radius and proper installation. This leads to short turns and bends, smaller than the allowed bend radius. Channel loss increases and results unexpectedly in interruption of important applications.
The introduction of the Slimflex patch cord with its very short bend radius, special jacket material and bend insensitive fibre reduces the risk of interruption and provides more security towards a flawless operation.
Increased fire safety
Due to the use of organic materials for insulation and sheathing, cables can severely contribute to increased smoke production during fire that limits visibility and increases toxic gas production. Nexans indoor cables and assemblies feature a low smoke, zero halogen jacket. In addition the cables have passed stringent requirement for flame non-propagation (IEC 60332-1) and fire non-propagation (IEC 60332-3).
The Nexans’ Plug&Play concept is specifically designed for Data Centres where the high density, fast and
enhanced installation benefits of the patch panel meet the key requirements for Data Centre implementation.
It allows quick changes with limited down time, easy migration to other applications and a migration path to
40G/100G.
The central part of the Plug&Play system is an advanced MPO connector. This multi array connector connects 12
fibres at once and is standardised for 40G and 100G Ethernet applications.
Plug&Play modules
•
Plug&Play module with12 LC or 24 LC connections•
Available with LANmark-OF Plug&Play connectivity and low loss connectivity grade•
Available in LANmark-OF OM4 multimode and LANmark-OF OS2 singlemode•
Module can be easily mounted into Nexans’ Plug&Play patch panel•
High density: 4 modules fit into 1U•
100 % factory testedComponents
The Plug&Play system consists of 3 subcomponents: Plug&Play modules, the MPO-MPO Pre-Term and the Plug&Play patch panel. The modules provide the transition between the MPO-MPO Pre-Term and the active devices: the Pre-Term connects to the back of the module and inside the module the fibres are spread out towards the LC connectors at the front.
Patch Panel
•
Up to 4 MPO modules in 1U•
Sliding and tilting patch panel for ease of installation, upgrade and maintenance•
High density connectivity: up to 96 LC depending on module type•
Labelling front for port identification and patch cord management within 1U1GBase-SX 820 440
10GBase-SR 310 190
40GBase-SR4 100
100GBase-SR10 100
1GBit FC-serial(PI-4 100-M5E-SN-I) 1020 460
2GBit FC-serial(PI-4 200-M5E-SN-I) 580 120
4GBit FC (PI-5 400-M5E-SN-I) 330
8Gbit FC(PI-5 800-M5E-SN-I) 130
16GBit FC (PI-5 1600-M5E-SN-I) 85
Extended distance guarantee
with low loss Plug&Play solutions
0 0,2 0,4 0,6 0,8 1 1,2 1,4 MPO Pre-Term
Connection Plug&Play Module 1,6
IEC 11801 standard
LANmark-OF MPO
LANmark-OF Low Loss MPO
0 0,2 0,4 0,6 0,8 1 1,2 1,4 MPO Pre-Term
Connection Plug&Play Module
1,6
IEC 11801 standard
LANmark-OF MPO LANmark-OF Low Loss MPO
Insertion loss for standard loss and low loss (in dB)
Guaranteed distances (in meters)
Guaranteed distances for LANmark-OF OM3 MPO Connectivity
Applications
2 MPO modules
4 MPO modules
Guaranteed distances for LANmark-OF OM4 Low Loss MPO Connectivity
Applications 2 MPO modules 4 MPO modules 6 MPO modules 8 MPO modules
1GBase-SX 900 700 460 140
10GBase-SR 520 400 290 110
40GBase-SR4 150 120 100GBase-SR10 150 120
1GBit FC-serial (PI-4 100-M5E-SN-I) 1200 800 480 120
2GBit FC-serial (PI-4 200-M5E-SN-I) 700 440 140
4GBit FC (PI-5 400-M5E-SN-I) 400 250 20
8Gbit FC (PI-5 800-M5E-SN-I) 210 160
Cable optimised for Data Centres
• Micro-Bundle cable design results in smaller and more pliable cables
• Maximum diameter of 6.4 mm for 96 core cable, less influence on airflow
• Bend radius of 65 mm allows bending in any direction
• Mechanical strong cable with central strength element and aramid yarns
• LSZH jacket, flame non propagation (IEC 60332-1) and fire non-propagation (IEC 60332-3)
Designed for advanced applications
•
Available in SM, OM3 and OM4•
High fibre count up to 96 fibres and 8 MPO connectors•
Maximum insertion loss according to IEC 61300-3-45 for normal loss performance: 0.6 dB•
Maximum insertion loss according to IEC 61300-3-45 for low loss performance: 0.35 dB•
Complex configurations can be supportedEasy to install assembly
•
Flexible fan-out easy to arrange in patch panel due to Micro-Bundle design•
No overlengths: custom made to the required length•
Delivered with protecting tubes around the installed MPO-connectors•
Pulling eye connected to the internal strength element of the cable•
Cable gland for strain relief in patch panelMPO Pre-Term
Patching on core switches and SAN directors
The I/O density of active devices is increasing. Core switches have up to 18 slots, with each up to 48 optical ports (96 LC connections). Patching becomes a real challenge in such a high density environment.
Nexans harness assembly enables superb cabling management using staggered links optimised to grow as your system expands while maintaining flexibility and control.
MPO-LC assembly on switches…. Slimflex patch cord in cross connect
The well defined lay-out of the I/O of the switches allows to design a specific staggered lay-out. Overlengths of the fan-out legs are minimized and visibility is improved.
The always changing patching in the cross connect requires the flexibility of traditional patch cords and Plug&Play modules. Length variation of the cords towards different patch panels and duplex patching is accomadated with the Slimflex patch cord.
The MPO-MPO Pre-Term trunk provides the connection between the 2 racks and provides a migration path to 40G.
LANmark-OF MPO-LC assemblies
• 12 core assembly in SM, OM3 and OM4.
• Male MPO connector and uniboot duplex LC connector
• Low loss performance
• No preferential bending with round cables
• Small bending radius of legs
• Staggered fan-out: first connector 60 cm from bifurcation point and 15 mm distance between uniboot connectors
Preloaded patch panel for high density areas
•
Integrated patch guide•
Sliding and tilting tray•
Preloaded with adaptorsOptimised for Pre-terminated assemblies
•
Fibre managment in 4 different loops for easy installation•
Openings optimised for cable gland Pre-Term•
24, 48 and 96 LC•
SM and MMOptimised for termination with splicing of pigtails
•
4 splice cassettes and 1 cover•
48 fibres with heat shrink protection•
96 fibres with mechanical/aluminium protection•
Cassettes can be lifted and tilted•
Larger splice cassettes for improved fibre management inside cassettesStraight preloaded patch panels
for LC connectivity
Patch cords guided to the side:
•
Rack space saving: no additional patch cord guide•
Labelling facility on patch cord guideAngled preloaded patch panels
for LC connectivity
Patch panel for high density areas
•
Patch cords can be guided to the side•
Same angle as angled copper panels•
Preloaded with adaptors•
Removable tray•
Shallow depthOptimised for Pre-terminated assemblies
•
Fibre management in 4 different loops for easy installation•
Openings optimised for cable gland Pre-Term•
48 LC and 96 LC•
SM and MMOptimised for termination with splicing of pigtails
•
4 splice cassettes and 1 cover•
48 fibres with heat shrink protection•
96 fibres with mechanical/aluminium protection•
Cassettes can be lifted and tilted•
Larger splice cassettes for improved fibre management inside cassettesPatch cords guided to the side:
•
No patch cord guide•
No labelling bar, labelling on patch panel•
Good overview of installed patch cordsHigh quality Pre-Term assembly
•
Tight Buffer Indoor cable•
LANmark-OF OM3, OM4 and SM fibres•
Up to 24 cores•
100 % tested, test report included with Pre-Term•
Overlengths reduced: Pre-Term available with 1m increments900 µm fan-out
•
Optimised for installation inside preloaded patch panels•
Fixation with cable gland for strain relief•
Fan-out optimised for minimising fibre overlength inside patch panel2 mm fan-out
•
Used as patch cord•
Outside of patch patch panel•
Direct connect to active equipment•
No cable glandPre-terminated LC assemblies...
Fast installation without risk
•
Protective tube for connectors during transport and installation•
Pulling eye on one side•
Pulling eye directly connected to cable internal strength elementHigh performance solution
for 10G Ethernet and 16G Fibre Channel
•
Low loss solution connectors allow more connections in the same channel for
advanced applications
0.35 dB/connection versus 0.75 dB/connection in ISO/IEC 11801 standard
•
Performance guarantee for 10G Ethernet
6 LC connections up to 270 m with LANmark-OF OM3
6 LC connections up to 430 m with LANmark-OF OM4
• Performance guarantee: Fibre Channel 8G/16G
6 LC connections up to 125m/75m LANmark-OF OM3
6 LC connections up to 160m/100m LANmark-OF OM4
•
Data Centre configurations with 2 cross connects easily supported
•
Reach extended for backbone cabling
Guaranteed distances for LANmark-OF OM3 LC Pre-Term
Applications 2 connections 4 connections 6 connections
Guaranteed distances for LANmark-OF OM4 LC Pre-Term
Applications 2 connections 4 connections 6 connections
Guaranteed distances (in meters)
1GBase-SX 920 820 720
10GBase-SR 350 300 270
1GBit FC-serial (PI-4 100-M5E-SN-I) 1240 1020 860 2GBit FC-serial (PI-4 200-M5E-SN-I) 720 580 460 4GBit FC (PI-5 400-M5E-SN-I) 400 330 260 8Gbit FC (PI-5 800-M5E-SN-I) 180 160 125 16GBit FC (PI-5 1600-M5E-SN-I) 120 105 75
1GBase-SX 940 840 740
10GBase-SR 550 470 430
1GBit FC-serial (PI-4 100-M5E-SN-I) 1300 1060 880 2GBit FC-serial (PI-4 200-M5E-SN-I) 1780 620 500 4GBit FC (PI-5 400-M5E-SN-I) 440 360 290 8Gbit FC (PI-5 800-M5E-SN-I) 220 200 160 16GBit FC (PI-5 1600-M5E-SN-I) 150 130 100
High density patching favours new patch cords
With the increase in density in Data Centres patching becomes an operational challenge. Initial patching starts orderly, but frequent moves/changes and adds result in less organised patching. Rules for bend radius for patch cords are not always respected resulting in increased risk for application interruption. Patch cords with reduced bend radius reduce the risk of down time. Easy to install patch cords without preferential bending and smaller patch cords are required for the dense cross connects.
Slimflex patch cords
• Bend radius reduced by 75 % to 7,5 mm.
• Less risk for application interruption
• Small round cable with a diameter of 2.6 mm
• Space required reduced by 30 %
• Less influence on cooling
• No preferential bending
• Low loss performance of 0.3 dB to increase headroom in channel and secure applications
Improved patch cord management and access
with Slimflex patch cords
With a uniboot connector and round patch cord instead of a duplex connector on a traditional zipcord the patch cord management is improved. The complexity of patching in high density areas is reduced.
LANmark-OF Slimflex Patch Cords
Reduced attenuation for small bends
With the introduction of an advanced sheating material and fibre the attenuation loss for the Slimflex patchcord has been reduced by 90 % for small bends. This significantly lowers the risk for system failure and improves overall margin.
0.5 0.4 0.3 0.2 0.1 0 Attenuation (dB/turn) 0.6 0.7 Traditional fibre Bend insensitive fibre 0.8
Bend radius (mm)
Frequent adds and changes put pressure on rules for bend radius and proper installation. This leads to short turns and bends, smaller than the allowed bend radius (see examples below). Channel loss increases and results unexpectedly in interruption of important applications. 2.5 2 1.5 1 0.5 0 Limit 10G Ethernet
traditional patch cord
Attenuation (dB)
3 3.5
Slimflex patch cord
Attenuation due to 1 bend
Connector loss
Attenuation due to length
System failure
System protected
Reduced risk for system failure
Special designed more robust patch cords with lower bend radius will reduce risk for downtime significantly.
Slimflex
The small bend radius of Slimflex results in additional system margin and prevents applications from failure.
Reduced risk with Slimflex Patch Cords
Patching... an operational challenge
Nexans Cabling Solutions
Alsembergsesteenweg 2, b3 - B-1501 Buizingen Tel: +32 (0)2 363 38 00 - Fax: +32 (0)2 365 09 99
Nexans Cabling Solutions UK and Intelligent Enterprise Solutions Competence Centre 2 Faraday Office Park - Faraday Road - Basingstoke - Hampshire RG24 8QQ
Tel: +44 (0)1256 486640 - Fax: +44 (0)1256 486650
www.nexans.com/LANsystems - [email protected]
© Nexans Cabling Solutions. All rights reser
ved. LANmark, LANsense and GG45 are registered trademarks of Ne
xans. Release date: April 2012.
About Nexans
With energy as the basis of its development, Nexans, worldwide leading expert in the cable industry, offers an extensive range of cables and cabling systems. The Group is a global player in the infrastructure,
industry, building and Local Area Network markets. Nexans addresses a series of market segments: from energy, transport and telecom networks to shipbuilding, oil and gas, nuclear power, automotives, electronics,
aeronautics, material handling and automation.
Nexans is a responsible industrial company that regards sustainable development as integral to its global and operational strategy. Continuous innovation in products, solutions and services, employee development
and engagement, and the introduction of safe industrial processes with limited environmental impact are among the key initiatives that place Nexans at the core of a sustainable future.
With an industrial presence in 40 countries and commercial activities worldwide, Nexans employs 23,700 people and had sales in 2010 of more than 6 billion euros. Nexans is listed on NYSE Euronext Paris,
compartment A. For more information, please consult www.nexans.com or http://www.nexans.mobi In the field of LAN Cabling Systems, Nexans Cabling Solutions offer a complete range of products and value added services providing improved reliability and reduced cost of ownership for Network Managers,
together with faster installation times for installers.
In addition to LANmark brand cabling systems, Nexans also specialises in LANsense Intelligent Infrastructure Management (IIM) products including Environmental Monitoring and Access Control (EMAC) devices. Nexans offers an unrivalled choice of LAN infrastructure solutions to a global customer based through an
