QuickTruss® M220

The QuickTruss® M220 system is a lightweight,

versatile, modular aluminium truss range ideal for

exhibition & display applications. The 35mm main

tube is aesthetically combined with continuous

formed spars to create a compact truss with

great free-span characteristics.

M220 features the QuickTruss® connection

tech-nology for an extremely Quick, Simple and Secure

assembly of components using conical connectors

and tapered pins.

In addition to the variety of formats, standard

junctions and accessories available, our

special-ist production service can create virtually any

length, angle or curve profile required to suit your

specific project.

DUO M220

Span in m (ft) 1,00 3.28 2,00 6.56 3,00 9.84 4,00 13.12 5,00 16.41 6,00 19.69 7,00 22.97 8,00 26.25 9,00 29.53 point load in kg (lbs) 250,20 551.7 163,80 361.20 109,00 240.30 80,00 176.40 63,00 138.90 52,20 115.10 43,20 95.30 37,00 81.60 31,50 69.50 deflection in mm (inch) 0,00 0.00 1,00 0.00 3,00 0.10 6,00 0.20 8,00 0.30 11,00 0.40 16,00 0.60 21,00 0.80 28,00 1.10 two point load in kg (lbs) 125,00 275.60 103,00 227.10 81,20 179.00 60,50 133.40 47,30 104.30 38,70 85.30 32,90 72.50 27,20 60.00 24,00 52.90 deflection in mm (inch) 0,00 0.00 2,00 0.10 4,00 0.20 7,00 0.30 10,00 0.40 14,00 0.50 19,00 0.70 25,00 1.00 32,00 1.20 distrib. loading. in kg/m (lbs/ft) 250,20 168.10 124,20 83.50 72,00 48.40 40,50 27.20 25,20 16.90 17,10 11.50 12,60 8.50 9,00 6.00 7,20 4.80 total distrib. loading in kg (lbs) 250,20 551.70 248,40 547.70 216,00 476.30 162,00 357.20 126,00 277.80 102,60 226.20 88,20 194.50 72,00 158.80 64,80 142.90 deflection in mm (inch) 0,00 0.00 2,00 0.10 4,00 0.20 7,00 0.30 11,00 0.40 16,00 0.60 21,00 0.80 28,00 1.10 35,00 1.40

DUO figures are based on use in vertical mode & grid application (i.e. stabilized every 1 m)

triO M220

TRIO figures are based on use in apex down orientation

qUatrO M220

StanDarD LengthS avaiLabLe anD WeightS

m (ft) 0,50 1.64 1,00 3.28 1,50 4.92 2,00 6.56 2,50 8.20 3,00 9.84 3,50 11.48 4,00 13.12 Duo-kg (lbs) 0,63 1.39 1,17 2.57 1,69 3.71 2,20 4.85 2,72 5.98 3,24 7.12 3,756 8.26 4,29 9.44 Trio-kg (lbs) 1,11 2.44 2,07 4.55 2,98 6.55 3,89 8.56 4,80 10.56 5,71 12.57 6,623 14.57 7,58 16.68 Quatro-kg (lbs) 1,48 3.25 2,76 6.06 3,97 8.73 5,18 11.40 6,40 14.08 7,62 16.75 8,83 19.43 10,11 22.24

connection material (pins/clips/cons) and packaging not included in above weights

point load in kg (lbs) two point load in kg (lbs) distrib. load (UDL) in kg/m (lbs/ft) metric data imperial data

(8)

7 DUO btn

triO Stn

tubes 35 x 1,5mm 1 ⅜" x 1_/₁₆_" _braces _{8 mm} 5_/₁₆_" _alloy _{EN - AW 6060 T66}

qUatrO qtn

185 mm

7

5

_/

16

"

_"

19

5 m

m

•

7

/

16

"

Small & Medium

trus

(9)

8 Small size and huge help

QuickTruss® M222

The QuickTruss® M222 system offers great weight

loading capabilities despite its small size and light

physical weight. Considering this, M222 is ideal

for retail, tradeshow and deco rative applications.

Connection is fast and simple, using a Conical

Connector system with Pins and R-Clips.

QuickTruss® M222 is available in custom lengths

and junctions, and can be curved (See Circle

Sec-tion). It comes in Natural Silver or a wide variety of

Powder Coated colors and finishes.

StanDarD LengthS avaiLabLe anD WeightS

m (ft) 0,50 1.64 1,00 3.28 1,50 4.92 2,00 6.56 2,50 8.20 3,00 9.84 4,00 13.12 Duo-kg (lbs) 0,85 1.87 1,70 3.75 2,55 5.62 3,40 7.50 4,25 9.37 5,10 11.24 6,80 14.99 Trio-kg (lbs) 1,15 2.54 2,30 5.07 3,45 7.61 4,60 10.14 5,75 12.68 6,90 15.21 9,20 20.28 Quatro-kg (lbs) 1,75 3.86 3,00 6.61 4,55 10.03 6,00 13.23 7,50 16.53 9,10 20.06 12,28 27.07

DUO M222

triO M222

qUatrO M222

(10)

9 DUO btM

triO StM

tubes 32 x 1,5 mm 1 1_/₄_{" x}1_/₁₆_" _braces _{10 x 1,5 mm} 3_/₈_{" x}1_/₁₆_" _alloy _{EN - AW 6060 T5}

qUatrO qtM

190 mm

7 ½“

222 mm

8 ¾“

190 mm • 7 ½"

222 mm • 8 ¾"

19

6 m

m

•

7

11

10 Small size and huge help

QuickTruss® M290B

The M290 system is the mid-size truss line

of-fered in the QuickTruss® family.

QuickTruss® M290B fits nicely in both large and

small applications. Available in regular ”B” Range

format, it offers great spanning and weight

load-ing capabilities while providload-ing a decorative touch!

The connection method is the same Conical

Con-nection system used in the M222 Series, just

larger in size.

QuickTruss® M290B is available in custom lengths

and junctions, and can be curved (See Circle

Sec-tion). It comes in Natural Silver or a wide variety of

Powder Coated colors and finishes.

StanDarD LengthS avaiLabLe anD WeightS

DUO M290b

Span in m (ft) 4,00 13.12 6,00 19.69 8,00 26.25 10,00 32.81 12,00 39.37 14,00 45.93 16,00 52.50 point load in kg (lbs) 587,00 1294.11 387,00 853.19 286,00 630.52 224,00 493.83 182,00 401.24 152,00 335.10 128,00 282.19 deflection in mm (inch) 12,00 0.47 28,00 1.09 50,00 1.95 79,00 3.08 114,00 4.45 156,00 6.08 206,00 8.03 two point load in kg (lbs) 385,00 848.78 290,00 639.34 214,00 471.79 168,00 370.38 137,00 302.03 114,00 251.33 96,00 211.64 deflection in mm (inch) 14,00 0.55 36,00 1.40 64,00 2.50 100,00 3.90 143,00 5.58 195,00 7.61 254,00 9.91 distrib. loading. in kg/m (lbs/ft) 192,00 129.00 127,00 85.33 71,00 47.70 45,00 30.24 30,00 20.16 22,00 14.78 16,00 10.75 total distrib. loading in kg (lbs) 768,00 1693.15 762,00 1679.92 568,00 1252.22 450,00 992.08 360,00 793.66 308,00 679.02 256,00 564.38 deflection in mm (inch) 10,00 0.39 35,00 1.37 62,00 2.42 97,00 3.78 140,00 5.46 191,00 7.45 249,00 9.71

triO M290b

qUatrO M290b

(12)

11 DUO btb

•

10

1

/

"

Small & Medium

trus

(13)

12 Small size and huge help

QuickTruss® M290V

The M290 system is the mid-size truss line

of-fered in the QuickTruss® family.

QuickTruss® M290V fits nicely in both large and

small applications. Available in heavy-duty ”V”

Range format, it offers great spanning and weight

loading capabilities while providing a decorative

touch! M290V is perfect for larger spans up to 16

meters (52.5").

The connection method is the same Conical

Con-nection system used in the M222 Series, just

larger in size. QuickTruss® M290V is available in

custom lengths and junctions, and can be curved

(See Circle Section). It comes in Natural Silver or a

wide variety of Powder Coated colors and finishes.

StanDarD LengthS avaiLabLe anD WeightS

DUO M290v

triO M290v

qUatrO M290v

(14)

13 DUO btv

triO Stv

tubes 48 x 3 mm 17_/₈_{" x}1_/₈_" _braces _{16 x 2 mm} 5_/₈_{" x}1_/₁₂_" _alloy _{EN - AW 6082 T6}

qUatrO qtv

240 mm • 9

7

_/

16

"

288 mm • 11

7

_/

16

"

2

5

5 m

m

•

1

0

1

/

8

"

2

0 7 m

m

•

8

1

/

8

"

2

"

288 mm

11

7

_/

16

"

Small & Medium

trus

(15)

14 Small size and huge help

QuickTruss® M290E

Electro truss system with integrated track

light-ing. Milos M290 electro system is ideal for retail

and display applications. M290 QuickTruss® fitted

with a Eutrac 3 circuit mains track (3 x 16 A) and

can be produced to any length upon request.

Circles and Curves are also possible.

It is supplied in Natural silver or wide variety of

Powder coated colours and finishes. Track

adapt-ers are available to fit a wide range of

manufac-turers including Erco, IGuzzini, Nokia and

Hoff-meister.

StanDarD LengthS avaiLabLe anD WeightS

m (ft) 0,50 1.64 1,00 3.28 1,50 4.92 2,00 6.56 2,50 8.20 3,00 9.84 4,00 13.12 5,00 16.41 Duo-kg (lbs) 1,77 3.88 3,09 6.80 4,41 9.71 5,73 12.61 7,06 15.52 8,38 18.43 10,72 23.58 13,66 30.05 Trio-kg (lbs) 2,89 6.35 4,90 10.77 6,89 15.15 8,88 19.53 10,87 23.91 12,86 28.29 16,54 36.39 20,82 45.81

16

"

2

4 7 m

m

• 9

¾

"

2

0 7,8

m

•

8

3

/

16

"

(16)

15 eUt 01

Electro straight coupler Eutrac

eUt 03

Earth contact Eutrac

eUt 02

End cap Eutrac

eUt 04

Floating mid feed Eutrac

Small & Medium

trus

(17)

16 Capacity and possibilities

QuickTruss® M390K

The QuickTruss® M390K is a larger format

prod-uct line offered and is available in regular ”K”

Range format.

The M390K Series uses the same Conical

Con-nectors, Pins and R-Clips as the M290 Series and

offers remarkable weight loading capabilities while

fitting the needs of more substantial spans and

booth designs.

QuickTruss® M390K is available in custom lengths

and junctions, and can be curved (See Circle

Sec-tion). It comes in Natural Silver or a wide variety of

Powder Coated colors and finishes.

DUO M390k

Span in m (ft) 4,00 13.12 6,00 19.69 8,00 26.25 10,00 32.81 12,00 39.37 14,00 45.93 16,00 52.5 18,00 59.06 point load in kg (lbs) 831,00 1832.04 549,00 1210.34 407,00 897.28 320,00 705.48 261,00 575.41 218,00 480.61 186,00 410.06 159,00 350.53 deflection in mm (inch) 9,00 0.35 20,00 0.78 36,00 1.40 56,00 2.18 81,00 3.16 111,00 4.33 146,00 5.69 186,00 7.25 two point load in kg (lbs) 612,00 1349.23 412,00 908.30 305,00 672.41 240,00 529.11 196,00 432.11 164,00 361.56 139,00 306.44 120,00 264.55 deflection in mm (inch) 11,00 0.43 26,00 1.01 45,00 1.76 71,00 2.77 102,00 3.98 139,00 5.42 181,00 7.06 229,00 8.93 distrib. loading. in kg/m (lbs/ft) 306,00 205.60 183,00 122.96 102,00 68.53 64,00 43.00 44,00 29.56 31,00 20.83 23,00 15.45 18,00 12.09 total distrib. loading in kg (lbs) 1224,00 2698.45 1098,00 2420.67 814,00 1798.5 640,00 1410.96 528,00 1164.04 434,00 956.81 368,00 811.30 324,00 714.30 deflection in mm (inch) 8,00 0.31 25,00 0.98 44,00 1.72 69,00 2.69 100,00 3.90 136,00 5.30 177,00 6.90 225,00 8.78

triO M390k

qUatrO M390k

StanDarD LengthS avaiLabLe anD WeightS

(18)

17 DUO btk

triO Stk

tubes 50 x 2 mm 2" x 1_/₁₂_" _braces _{20 x 2 mm} 4_/₅_{" x}1_/₁₂_" _alloy _{EN - AW 6082 T6}

qUatrO qtk

340 mm

13

3

_/

8

"

"

3

4

4 m

m

•

1

3

9

/

16

"

2

9

4 m

m

•

1

9

/

16

"

3

9

0 m

m

•

1

5

3

/

8

"

3

4

0 m

m

•

1

3

/

8

"

Small & Medium

trus

(19)

18 Capacity and possibilities

QuickTruss® M390L

The QuickTruss® M390L is a larger format

prod-uct line offered and is available in heavy-duty ”L”

Range format.

The M390L Series uses the same Conical

Con-nectors, Pins and R-Clips as the M290 Series and

offers remarkable weight loading capabilities while

fitting the need of more substantial spans and

booth designs.

QuickTruss® M390L is available in custom lengths

and junctions, and can be curved (See Circle

Sec-tion). It comes in Natural Silver or a wide variety of

Powder Coated colors and finishes.

DUO M390L

triO M390L

qUatrO M390L

Span in m (ft) 4,00 13.12 6,00 19.69 8,00 26.25 10,00 32.81 12,00 39.37 14,00 45.93 16,00 52.50 18,00 59.06 point load in kg (lbs) 2078,00 4581.2 1372,00 3024.74 1014,00 2235.48 797,00 1757.08 649,00 1430.80 541,00 1192.7 458,00 1009.72 391,00 862.01 deflection in mm (inch) 8,00 0.31 18,00 0.70 32,00 1.25 50,00 1.95 72,00 2.81 99,00 3.86 131,00 5.11 167,00 6.51 two point load in kg (lbs) 1219,00 2687.43 1029,00 2268.55 761,00 1677.72 597,00 1316.16 486,00 1071.45 405,00 892.87 343,00 756.18 293,00 645.95 deflection in mm (inch) 8,00 0.31 23,00 0.90 41,00 1.60 63,00 2.46 91,00 3.55 124,00 4.84 162,00 6.32 204,00 7.96 distrib. loading. in kg/m (lbs/ft) 610,00 409.86 404,00 271.45 254,00 170.66 159,00 106.83 108,00 72.57 77,00 51.74 57,00 38.30 43,00 28.89 total distrib. loading in kg (lbs) 2440,00 5379.27 2424,00 5344 2032,00 4479.79 1590,00 3505.35 1296,00 2857.19 1078,00 2376.58 912,00 2010.61 774,00 1706.38 deflection in mm (inch) 6,00 0.23 20,00 0.78 40,00 1.56 62,00 2.42 89,00 3.47 121,00 4.72 158,00 6.16 200,00 7.80

StanDarD LengthS avaiLabLe anD WeightS

(20)

19 DUO btL

triO StL

tubes 48 x 3 mm 1 7_/₈_{" x}1_/₈_" _braces _{20 x 2 mm} 4_/₅_{" x}1_/₁₂_" _alloy _{EN - AW 6082 T6}

qUatrO qtL

340 mm

13

3

_/

8

"

"

3

4

2 m

m

• 1

3

9

/

16

"

2

9

4 m

m

•

1

9

/

16

"

3

8

8 m

m

•

1

5

3

/

8

"

3

4

0 m

m

•

1

3

/

8

"

Small & Medium

trus

(21)

Capacity and possibilities

(22)

b

ig trus

(23)

22 Capacity and possibilities

QuickTruss® M400

QuickTruss® M400 has been designed specifically

for heavy-duty applications and is ideally suited

for large stage and rental markets. In addition to

outstanding strength of construction, the system

features Quick-Connectors for speed and ease of

assembly.

M400 is available in two versions, rectangular and

square formats. It uses larger formats of the

regular Quick-Connectors secured with tapered

pins and retaining clips which enables spans of up

to 20 meters [65,6 ft] to be achieved. The M400

range is also an important component in the

con-struction of our MR3 Roofs.

QuickTruss® M400 is available in custom lengths

and junctions, and can be curved (See Circle

Sec-tion). It comes in Natural Silver or a wide variety of

Powder Coated colours and finishes.

tubes 50 x 4 mm 2" x 1_/₆_" _braces _{25 x 3 mm} _{1" x}1_/₈_" _alloy _{EN - AW 6082 T6}

rect rtO

rect M400

Span in m (ft) 2,00 6.56 3,00 9.84 4,00 13.12 5,00 16.41 6,00 19.69 7,00 22.97 8,00 26.25 9,00 29.53 10,00 32.81 point load in kg (lbs) 4497,00 9914.18 3292,00 7257.61 2460,00 5423.37 1959,00 4318.85 1624,00 3580.30 1383,00 3048.99 1201,00 2647.75 1058,00 2332.49 943,00 2078.96 deflection in mm (inch) 2,00 0.08 6,00 0.23 10,00 0.39 15,00 0.59 22,00 0.86 30,00 1.17 40,00 1.56 50,00 1.95 62,00 2.42 two point load in kg (lbs) 3712,00 8183.55 2469,00 5443.21 1845,00 4067.52 1469,00 3238.59 1218,00 2685.23 1037,00 2286.19 901,00 1986.36 794,00 1750.47 707,00 1558.67 deflection in mm (inch) 3,00 0.12 7,00 0.27 13,00 0.51 20,00 0.78 28,00 1.09 39,00 1.52 50,00 1.95 64,00 2.50 79,00 3.08 distrib. loading. in kg/m (lbs/ft) 2248,00 1510.43 1496,00 1005.16 1119,00 751.86 784,00 526.77 541,00 363.50 395,00 265.40 300,00 201.57 235,00 157.90 189,00 126.99 total distrib. loading in kg (lbs) 4496,00 9911.97 4488,00 9894.33 4476,00 9867.88 3920,00 8642.11 3246,00 7156.20 2765,00 6095.77 2400,00 5291.09 2115,00 4662.77 1890,00 4166.73 deflection in mm (inch) 1,00 0.04 5,00 0.20 11,00 0.43 19,00 0.74 28,00 1.09 38,00 1.48 49,00 1.91 62,00 2.42 77,00 3.00 11,00 36.09 12,00 39.37 13,00 42.65 14,00 45.93 15,00 49.22 16,00 52.5 17,00 55.78 18,00 59.06 19,00 62.34 20,00 65.62 848,00 1869.52 768,00 1693.15 699,00 1541.03 640,00 1410.96 588,00 1296.32 542,00 1194.90 500,00 1102.31 463,00 1020.74 429,00 945.78 398,00 877.44 76,00 2.96 90,00 3.51 106,00 4.13 124,00 4.84 142,00 5.54 163,00 6.36 184,00 7.18 207,00 8.07 232,00 9.05 258,00 10.06 636,00 1402.14 576,00 1269.86 524,00 1155.22 480,00 1058.22 441,00 972.24 406,00 895.08 375,00 826.73 347,00 765 322,00 709.89 298,00 656.98 95,00 3.71 113,00 4.41 133,00 5.19 154,00 6.01 176,00 6.86 201,00 7.84 227,00 8.85 254,00 9.91 283,00 11.04 313,00 12.21 154,00 103.47 128,00 86.00 108,00 72.57 91,00 61.14 78,00 52.41 68,00 45.69 59,00 39.64 51,00 34.27 45,00 30.24 40,00 26.88 1694,00 3734.63 1536,00 3386.30 1404,00 3095.29 1274,00 2808.69 1170,00 2579.41 1088,00 2398.63 1003,00 2211.23 918,00 2023.84 855,00 1884.95 800,00 1763.7 93,00 3.63 111,00 4.33 130,00 5.07 151,00 5.89 173,00 6.75 197,00 7.68 222,00 8.66 249,00 9.71 278,00 10.84 308,00 12.01

3

5

8 m

m

•

1

4

1

/

10

"

207 mm • 8

1

_/

₁₆

_"

2

9

9 m

m

•

1

1 ¾

"

266 mm • 10 ½"

(24)

23 qUatrO qtO

qUatrO M400

Span in m (ft) 2,00 6.56 3,00 9.84 4,00 13.12 5,00 16.41 6,00 19.69 7,00 22.97 8,00 26.25 9,00 29.53 10,00 32.81 point load in kg (lbs) 4495,00 9909.77 3290,00 7253.2 2458,00 5418.96 1957,00 4314.44 1621,00 3573.69 1380,00 3042.38 1197,00 2638.93 1054,00 2323.67 938,00 2067.93 deflection in mm (inch) 2,00 0.08 6,00 0.23 10,00 0.39 15,00 0.59 22,00 0.86 30,00 1.17 40,00 1.56 50,00 1.95 62,00 2.42 two point load in kg (lbs) 3712,00 8183.55 2468,00 5441 1844,00 4065.32 1468,00 3236.38 1216,00 2680.82 1035,00 2281.78 898,00 1979.75 790,00 1741.65 704,00 1552.05 deflection in mm (inch) 3,00 0.12 7,00 0.27 13,00 0.51 20,00 0.78 28,00 1.09 39,00 1.52 50,00 1.95 64,00 2.50 79,00 3.08 distrib. loading. in kg/m (lbs/ft) 2247,00 1509.76 1495,00 1004.49 1118,00 751.18 783,00 526.1 540,00 362.83 394,00 264.73 299,00 200.90 234,00 157.22 188,00 126.32 total distrib. loading in kg (lbs) 4494,00 9907.56 4485,00 9887.72 4472,00 9859.06 3915,00 8631.09 3240,00 7142.97 2758,00 6080.34 2392,00 5273.45 2106,00 4642.93 1880,00 4144.69 deflection in mm (inch) 1,00 0.04 5,00 0.2 11,00 0.43 19,00 0.74 28,00 1.09 38,00 1.48 49,00 1.91 62,00 2.42 77,00 3.00 11,00 36.09 12,00 39.37 13,00 42.65 14,00 45.93 15,00 49.22 16,00 52.5 17,00 55.78 18,00 59.06 19,00 62.34 20,00 65.62 843,00 1858.49 762,00 1679.92 693,00 1527.80 634,00 1397.73 581,00 1280.88 534,00 1177.27 493,00 1086.88 455,00 1003.1 420,00 925.94 389,00 857.60 76,00 2.96 90,00 3.51 106,00 4.13 124,00 4.84 143,00 5.58 163,00 6.36 185,00 7.22 208,00 8.11 233,00 9.09 259,00 10.10 632,00 1393.32 572,00 1261.04 520,00 1146.40 475,00 1047.19 436,00 961.21 401,00 884.05 369,00 813.50 341,00 751.78 315,00 694.46 292,00 643.75 95,00 3.71 113,00 4.41 133,00 5.19 154,00 6.01 176,00 6.86 201,00 7.84 226,00 8.81 254,00 9.91 283,00 11.04 313,00 12.21 153,00 102.80 127 85.33 107,00 71.89 91,00 61.14 77,00 51.74 67,00 45.02 58,00 38.97 51,00 34.27 44,00 29.56 39,00 26.20 1683,00 3710.38 1524 3359.84 1391,00 3066.63 1274,00 2808.69 1155,00 2546.34 1072,00 2363.35 986,00 2173.76 918,00 2023.84 836,00 1843.06 780,00 1719.60 93,00 3.63 111 4.33 130,00 5.07 151,00 5.89 173,00 6.75 197,00 7.68 222,00 8.66 249,00 9.71 278,00 10.84 308,00 12.01

StanDarD LengthS avaiLabLe anD WeightS

m (ft) 0,50 1.64 1,00 3.28 1,50 4.92 2,00 6.56 2,50 8.20 3,00 9.84 4,00 13.12 Rect-kg (lbs) 7,90 17.42 11,90 26.23 15,90 35.05 19,61 43.23 23,61 52.05 27,61 60.87 35,10 77.38 Quatro-kg (lbs) 8,50 18.74 13,10 28.88 17,60 38.80 21,91 48.30 26,40 58.20 31,15 68.67 39,60 87.30

3

5

8 m

m

•

1

4

1

/

10

"

2

9

9 m

m

•

1 1¾

"

b

ig trus

(25)

24 Capacity and possibilities

QuickTruss® M520

QuickTruss® M520 is a high-capacity system

consisting of fixed and folding formats. The

fold-ing version reduces storage and transpor tation

volume by 70% and is quickly assembled to its

load-bearing condition without any tools.

Both formats have impressive free-span

charac-teristics up to 20m [65.6 ft], the Quatro system

also offers incredible loading capacity. All M520

components are joined using the large format

Quick Connectors, tapered pins and clips for an

extremely fast and secure assembly and can be

used with the MR3 roof system.

QuickTruss® M520 is available in custom lengths

and junctions. It comes in Natural Silver or a wide

variety of Powder Coated colours and finishes.

fOLD ftp

fOLD M520

Span in m (ft) 8,00 26.25 9,00 29.53 10,00 32.81 11,00 36.09 12,00 39.37 13,00 42.65 14,00 45.93 15,00 49.22 point load in kg (lbs) 1145,00 2524.29 1065,00 2347.92 1001,00 2206.82 946,00 2085.57 899,00 1981.95 859,00 1893.77 823,00 1814.40 790,00 1741.65 deflection in mm (inch) 14,00 0.55 18,00 0.70 24,00 0.94 31,00 1.21 39,00 1.52 48,00 1.87 58,00 2.26 7,00 0.27 two point load in kg (lbs) 858,00 1891.56 799,00 1761.49 750,00 1653.47 710,00 1565.28 675,00 1488.12 644,00 1419.78 617,00 1360.25 592,00 1305.14 deflection in mm (inch) 18,00 0.70 23,00 0.90 30,00 1.17 38,00 1.48 48,00 1.87 59,00 2.30 77,00 3.00 92,00 3.59 distrib. load (UDL) in kg/m (lbs/ft) 440,00 295.64 346,00 232.48 278,00 186.79 228,00 153.19 190,00 127.66 160,00 107.50 137,00 92.05 118,00 79.28 total distrib. load (UDL) in kg (lbs) 3520,00 7760.26 3114,00 6865.19 2780,00 6128.84 2508,00 5529.19 2280,00 5026.53 2080,00 4585.61 1918,00 4228.46 1770,00 3902.18 deflection in mm (inch) 28,00 1.09 36,00 1.40 44,00 1.72 54,00 2.11 64,00 2.50 76,00 2.96 88,00 3.43 101,00 3.94

Span in m/ft 16,00 52.50 17,00 55.78 18,00 59.06 19,00 62.34 20,00 65.62 21,00 68.90 22,00 72.18 23,00 75.46 24,00 78.74 point load in kg/lbs 760,00 1675.04 732,00 1613.78 707,00 1558.67 659,00 1452.84 616,00 1358.05 577,00 1272.07 540,00 1190.49 506,00 1115.54 475,00 1047.19 deflection in mm (inch) 83,00 3.24 97,00 3.78 114,00 4.45 137,00 5.34 153,00 5.97 169,00 6.59 188,00 7.33 207,00 8.07 227,00 8.85 two point load in kg (lbs) 570,00 1256.63 548,00 1208.13 530,00 1168.45 495,00 1091.29 462,00 1018.53 432,00 952.40 405,00 892.87 380,00 837.76 356,00 784.84 deflection in mm (inch) 110,00 4.29 128,00 4.99 150,00 5.85 167,00 6.51 186,00 7.25 206,00 8.03 227,00 8.85 249,00 9.71 272,00 10.61 distrib. loading. in kg/m (lbs/ft) 102,00 68.53 89,00 59.80 79,00 53.08 69,00 46.36 62,00 41.66 55,00 36.95 49,00 32.92 44,00 29.56 40,00 26.88 total distrib. loading in kg (lbs) 1632,00 3597.94 1513,00 3335.59 1422,00 3134.97 1311,00 2890.26 1240,00 2733.73 1155,00 2546.34 1078,00 2376.58 1012,00 2231.08 960,00 2116.44 deflection in mm (inch) 115,00 4.49 131,00 5.11 147,00 5.73 164,00 6.40 18,30 0.71 202,00 7.88 223,00 8.70 244,00 9.52 267,00 10.41

5

2

9 m

m

•

2

0

8

/

10

"

4

70 m

m

•

1

8

5

/

10

"

520 mm • 20

4

_/

₁₀

_"

579 mm • 22

8

_/

₁₀

_"

(26)

25

tubes 50 x 4 mm 2" x 1_/₆_" _braces _{30 x 3 mm} ₁3_/₁₆_{" x}1_/₈_" _alloy _{EN - AW 6082 T6}

qUatrO qtp

qUatrO M520

Span in m/ft 16,00 52.50 17,00 55.78 18,00 59.06 19,00 62.34 20,00 65.62 21,00 68.90 22,00 72.18 23,00 75.46 24,00 78.74 point load in kg/lbs 842,00 1856.29 779,00 1717.40 723,00 1593.94 672,00 1481.50 626,00 1380.09 583,00 1285.29 543,00 1197.11 507,00 1117.74 473,00 1042.79 deflection in mm (inch) 96,00 3.74 108,00 4.21 122,00 4.76 136,00 5.30 152,00 5.93 168,00 6.55 185,00 7.22 203,00 7.92 223,00 8.70 two point load in kg (lbs) 631,00 1391.12 585,00 1289.70 542,00 1194.90 504,00 1111.13 469,00 1033.97 437,00 963.42 408,00 899.48 380,00 837.76 354,00 780.44 deflection in mm (inch) 119,00 4.64 134,00 5.23 150,00 5.85 167,00 6.51 185,00 7.22 204,00 7.96 224,00 8.74 244,00 9.52 266,00 10.37 distrib. loading. in kg/m (lbs/ft) 105,00 70.55 92,00 61.81 80,00 53.75 71,00 47.70 63,00 42.33 56,00 37.63 49,00 32.92 44,00 29.56 39,00 26.20 total distrib. loading in kg (lbs) 1680,00 3703.76 1564,00 3448.03 1440,00 3174.65 1349,00 2974.03 1260,00 2777.82 1176,00 2592.63 1078,00 2376.58 1012,00 2231.08 936,00 2063.52 deflection in mm (inch) 116,00 4.52 131,00 5.11 147,00 5.73 164,00 6.40 182,00 7.10 20,00 0.78 220,00 8.58 240,00 9.36 262,00 10.22

StanDarD LengthS avaiLabLe anD WeightS

m (ft) 1,00 3.28 1,20 3.94 1,50 4.92 1,60 5.25 2,00 6.56 2,40 7.87 2,50 8.20 3,00 9.84 3,50 11.48 4,00 13.12

Fold-kg (lbs) - - 15,40 33.95 - - 20,90 46.08 - - 29,10 64.15 - - -

-Quatro-kg (lbs) 17,00 37.48 - - 22,90 50.49 - - 27,70 61.07 - - 33,54 73.94 38,30 84.44 44,20 97.44 50,00 110.23 connection material (pins/clips/cons) and packaging not included in above weights

5

2

9 m

m

•

2

0

8

/

10

"

4

70 m

m

•

1

8

5

/

10

"

b

ig trus

(27)

26 Capacity and possibilities

QuickTruss® M950

The latest and largest system in our range

de-signed specifically for maximum loading and

free-span characteristics. M950 redefines the rules

that `big is slow` using proven QuickTruss®

tech-nology for an extremely Quick and Secure

assembly of components. All components are

manufactured by our fully certified welders using

the highest specification materials including

60 x 6 mm (2

3 _/

_{8" x}

1 _/4

_{") main tubes and 32 x 3 mm}

(1

1 _/

_{4" x}

1 _/

_{8") bracing spars. Rectangular and}

compact Folding versions are available to suit any

temporary event or permanent construction(s).

tubes 60 x 6 mm 2 3_/₈_{" x}1_/₄_" _braces _{32 x 3 mm} ₁1_/₄_{" x}1_/₈_" _material _{alloy EN - AW 6082 T6}

fOLD ftt

fOLD M950

10

0

0 m

m

•

3

9

4

/

10

"

9

4

0 m

m

•

3 7"

520 mm • 20

4

_/

₁₀

_"

580 mm • 22

8

_/

₁₀

_"

(28)

27

tubes 60 x 6 mm 2 3_/₈_{" x}1_/₄_" _braces _{32 x 3 mm} ₁1_/₄_{" x}1_/₈_" _material _{alloy EN - AW 6082 T6}

rect rtt

rect M950

StanDarD LengthS avaiLabLe anD WeightS

m (ft) 1,00 3.28 1,20 3.94 2,00 6.56 2,40 7.87 3,00 9.84

Fold-kg (lbs) 24,00 52.91 27,50 60.63 43,90 96.78 48,50 106.92 62,60 138.01

Rect-kg (lbs) 30,00 66.14 33,60 74.08 51,00 112.44 56,00 123.46 71,00 156.53

connection material (pins/clips) and packaging not included in above weights

10

0

0 m

m

•

3

9

4

/

10

"

9

4

0 m

m

•

3 7"

520 mm • 20

4

_/

₁₀

_"

580 mm • 22

8

_/

₁₀

_"

b

ig trus

(29)

28 Capacity and possibilities

4GS-35 / 4GS-50

Our 4GS-35/50 range of modular aluminium

sys-tems is the ideal solution for large truss

structu-res, towers & gantries. The tried, tested & trusted

traditional fork & tongue connection is popular

with rental companies worldwide with great

per-formance and durability.

Custom lengths, junctions and curved sections

can be produced to suit specific size or

configura-tion requirements. Components can be supplied in

either a Natural Mill (Satin) Aluminium or a variety

of Powder Coated colours and finishes.

StanDarD LengthS avaiLabLe anD WeightS

m (ft) 0,39 1.28 0,67 2.18 1,24 4.08 1,82 5.97 2,40 7.87 3,00 9.84 3,56 11.66 4,14 13.58 4GS-35 kg (lbs) 8,00 17.60 9,50 20.90 14,50 31.90 20,00 44.00 25,00 55.00 29,00 63.80 33,00 72.60 38,00 83.60

4gS-35

tubes 48 x 4,5 mm 1 7_/₈_{" x}3_/₁₆_" _braces _{25 x 3 mm} _{1" x}1_/₈_" _alloy _{EN - AW 6082 T6}

299 mm

11

3

_/

₄

_"

347 mm

13

2

_/

₃

_"

(30)

29 StanDarD LengthS avaiLabLe anD WeightS

m (ft) 0,50 1.64 1,00 3.28 2,00 6.56 3,00 9.840 4,00 13.12 4GS-50 kg (lbs) 10,00 22.00 16,00 35.20 32,00 70.40 48,00 105.60 64,00 140.80

4gS-50

tubes 48 x 4,5 mm 1 7_/₈_{" x}3_/₁₆_" _braces _{25 x 3 mm} _{1" x}1_/₈_" _alloy _{EN - AW 6082 T6}

5

0

0 m

m

•

1

9

11

/

16

"

4

5

2 m

m

•

1

7

4

/

5

"

4gS-50

Span in m (ft) 4.00 13.12 6.00 19.69 8.00 26.25 10.00 32.81 12.00 39.37 14.00 45.93 16.00 52.50 18.00 59.06 20.00 65.62 point load in kg (lbs) 3485,00 7684.43 2298,00 5067.09 1696,00 3739.68 1328,00 2928.24 1080,00 2381.40 896,00 1975.68 754,00 1662.57 641,00 1413.41 584,00 1287.72 deflection in mm (inch) 5,00 0.20 12,00 0.47 21,00 0.82 32,00 1.25 46,00 1.79 63,00 2.46 83,00 3.24 104,00 4.06 129,00 5.03 two point load in kg (lbs) 2494,00 5499.27 1723,00 3799.22 1272,00 2804.76 997,00 2198.39 809,00 1783.85 671,00 1479.56 566,00 1248.03 481,00 1060.61 410,00 904.05 deflection in mm (inch) 7,00 0.27 15,00 0.59 26,00 1.01 41,00 1.60 59,00 2.30 81,00 3.16 105,00 4.10 133,00 5.19 165,00 6.44 distrib. loading. in kg/m (lbs/ft) 1271,00 854.18 765,00 514.12 423,00 284.28 265,00 178.09 179,00 120.30 127,00 85.35 93,00 62.50 71,00 47.72 54,00 36.29 total distrib. loading in kg (lbs) 5084,00 11210.22 4590,00 10120.95 3384,00 7461.72 2650,00 5843.25 2148,00 4736.34 1778,00 3920.49 1488,00 3281.04 1278,00 2817.99 1080,00 2381.40 deflection in mm (inch) 6,00 0.23 15,00 0.59 26,00 1.01 40,00 1.56 58,00 2.26 79,00 3.08 103,00 4.02 131,00 5.11 161.00 6.28
