Experiences with 2-D and 3-D Mathematical Plots on the Java™ Platform
What you will learn
> Techniques for writing software that plots
mathematical and scientific data
> How to apply Java tools to these tasks:
Java2D for 2D graphs JOGL for 3D graphs
> How to make best use of these toolkits, especially
> Maple is a symbolic math application:
Performs math on symbols as well as numbers A huge number of mathematical operations
> User interface is all Java (~1M lines)
Outputs math as mathematicians, scientists or
engineers expect it
> Previous toolkit lacked speed, quality,
controllability and economy.
Demo
Requirements
> New Features
Interactive annotation
Mathematical labels part of the plot Speed and memory improvements Try to use few Java components
> Notable Existing Features
Plots embeddable in a worksheet Export to bitmap and vector
Design
Overview> Maple GUI uses Model-View-Controller
> Each symbol, plot, component, axis etc. has a model > Each model has a view
> Model update → view layout → view draw
View Model
Design
Plot Atoms> Atoms are small objects that store elements in a
form that is quick to draw
> They may store pixel positions, or a Shape object,
or a symbol image and location…
> Created at layout time and stored in the MVC view > To draw itself a component just draws all its atoms
Design
Plot Atoms
interface Atom {
void draw(Graphics g); }
class PolygonAtom implements Atom { GeneralPath poly;
PolygonAtom(float x[],float y[]) { // create the path…
}
void draw(Graphics g) {
Design
Math in Labels
> Mathematical expressions are drawn directly by
positioning the view within the plot
> Annotations use an existing package which draws
Optimizations:
float v int coordinates
> drawPolyline(int[],int[],int) v draw(Shape)
> In theory ints are faster but floats more accurate > You need float coordinates for printing or vector
graphics (e.g. Postscript)
> Considered using int-based calls on screen and
float-based for print
> Ended using floats throughout: the differences in
both accuracy and performance were small (except for printing).
Optimizations:
Sprites
> Rendering performance was acceptable,
except when drawing many symbols
> Sprites are small images which can be drawn to
the screen instead of lines and shapes
> Faster to draw an image than even a simple shape > Create a Sprite object which holds an image for
the symbol
Optimizations:
Sprites
Backgrounds of Sprites must be transparent
2D Plots
The results> The 2D plots were released in 2007. > Speeded up by a factor of 7
> Memory used less than 1/10th
> The new features were appreciated by customers > Spurred demand for the same features in 3D
Requirements
3D Project> New Features
Interactive annotation, drawn in Java2D over 3D Mathematical labels part of the plot, embedded at
3D positions
Other improvements as before
> Notable Existing Features
Toolkits
Candidate toolkits for 3D
> The choices:
Java3D: a complete scenegraph tool written in Java JOGL: a thin Java layer over OpenGL
LWJGL: a Java layer over OpenGL designed for
games
A game engine, such as JMonkeyEngine
> LWJGL eliminated as it uses a single window. > Many game engines have LWJGL underneath
Toolkits
JOGL v Java3D
> Java3D advantages:
A complete OO toolkit
Simpler to learn than OpenGL
> JOGL advantages:
If you know OpenGL you know JOGL Virtually full OpenGL functionality
Known portability Wide use
Toolkits
JOGL
> GLCanvas (heavyweight AWT) or GLJPanel
(lightweight Swing) accelerated components
> GLEventListener is attached to the component
render the scene
> GL object passed to the listener provides Java
equivalents for OpenGL calls.
> You can (and must) use OpenGL documentation. > Each view object has a method to draw itself with
Design
Mixing 2D labels into 3D
> Labels are positioned in 3D space
> Math is drawn into an image with a transparent
background
> Set a raster position in 3D, then shift it in 2D to get
the alignment right
> Image drawn into the scene with JOGL
> gl.glRasterPos3fv(arrayXYZ, 0);
gl.glBitmap(0, 0, 0, 0,xOff, yOff, null); gl.glDrawPixels(w,h,…, image);
Design
Mixing 2D labels into 3D
Design
Mixing 2D labels into 3D (cont.)
> When OpenGL writes shape it sets the ‘depth’ at
which it is written (depth buffer)
> Subsequent shapes at a greater depth are not
written i.e. surfaces behind a surface aren’t seen.
> But the depth buffer is written even for
transparent pixels
> We have to use two passes:
Write solid pixels and set the depth buffer
Design
Mixing 2D labels into 3D (cont.)
gl.glDepthMask(true);
gl.glAlphaFunc(GL.GL_GEQUAL,alpha);
drawAllComponents();
gl.glAlphaFunc(GL.GL_LESS, alpha);
gl.glDepthMask(false);
Rendering Mechanism
Limitations of GLJPanel
> Started with one GLJPanel per plot
> A Maple document may have many plots. > But GLJPanels take resources (video RAM) > After creating so many they stop rendering > JOGL Issue 370
Rendering Mechanism
Reusing a GLJPanel
> Reuse GLJPanel, stealing them from plots that are
offscreen.
> But you can’t reposition and draw a GLJPanel in
the same event
> There are other problems with writing plots for
export.
Rendering Mechanism
GLPBuffers> GLPBuffers allow for drawing hardware
accelerated graphics offscreen
> Render 3D to the GLPBuffer, then the image to
the screen
> Now easy to draw 2D annotations over the PBuffer
> We have fewer components
> We still need to reuse GLPBuffers since they use
Rendering Mechanism
Creating a GLPBuffer GLDrawableFactory factory = GLDrawableFactory.getFactory(); … GLPbuffer buf = factory.createGLPbuffer(…, width,height,…); … GLContext glContext =Rendering Mechanism
Drawing to a GLPBuffer void draw(Graphics g) { try { glContext.makeCurrent(); GL gl = glContext.getGL(); // make GL calls… BufferedImage img = Screenshot.readToBufferedImage(w,h); g.drawImage(img, x, y null); … } finally {if (GLContext.getCurrent()==glContext) {glContext.release();}
Rendering Mechanism
GLPBuffers (cont)
> Not all displays support GLPBuffers:
GLDrawableFactory.
canCreateGLPbuffer();
> Creation can still fail, because they need video
resources
> Catch GLException when creating; and
RuntimeException because of JOGL bugs
Rendering Mechanism
Offscreen drawable
> There is also a unaccelerated offscreen drawable > This is outside the published interface: it is used
by GLJPanel.
> See GLJPanel source
GLDrawableImpl offscreenDrawable =
GLDrawableFactoryImpl.getFactoryImpl(). createOffscreenDrawable(glCap,…);
Platform issues:
> Not all machine configurations will work with JOGL
‘out of the box’.
> Working OpenGL doesn’t mean working JOGL > Need to call glGetError() (or use DebugGL)
> Catch GLException and process it > Check your display capabilities with
GLDrawable.getChosenGLCapabilities();
Platform issues:
Mac
Platform issues:
Windows
> Few
> ATI drivers: need at least v8.231 (Catalyst 8) > Remote Desktop Connection and some laptop
external monitors:
May not be able to use the 2-pass transparency
algorithm
Check the supported alpha bits
Platform issues:
Linux
> Some
> Many default Linux installs don’t work with JOGL > Proprietary video drivers needed
ATI Catalyst 8.12 nVidia version 177
Demo
Summary:
2D
> Favour precision over speed
> Store presentation data close to the Java drawing
format
> Use sprites for symbols
Summary:
3D
> JOGL:
Provides all your 3D needs
Is good if you already have structure
May not be best if you need to create structure
> Programming JOGL is programming OpenGL > Write math as images directly to the 3D scene
Requires transparency handling
Summary:
3D (cont)
> PBuffers:
Simplify 2D/3D mixing
Allow many plots in an app Have little performance cost Reduce component count
Need to go outside the spec for unaccelerated
Resources:
> Jumping into JOGL:
http://today.java.net/pub/a/today/2003/09/11/jogl2d.html/ > JOGL documentatation: http://download.java.net/media/jogl/builds/nightly/javadoc_public/overview-summary.html http://www.opengl.org/sdk/docs/man/ > JOGL forum: http://www.javagaming.org/index.php/board,25.0.html > PBuffers: http://today.java.net/pub/a/today/2008/10/30/integrating-glpbuffer-and-graphics2d.html
David Clayworth
Senior GUI Developer Maplesoft
