Group Videoconferencing Systems

(1)

Group Videoconferencing

Systems

MediaConnect 8000 Series

Rollabout and Compact Systems

(2)

Information in this document is subject to change without notice. No part of this document can be reproduced or transmitted in any form or by any means - electronic or mechanical - for any purpose without written permission from VCON Ltd.

MeetingPoint is a registered trademark of VCON, Inc. in the United States. VCON and Media Xchange Manager are trademarks of VCON Ltd.

Microsoft and the Microsoft Internet Explorer logo are registered trademarks or trademarks of Microsoft Corporation in the United States and/or other countries. Windows and NetMeeting are registered trademarks of Microsoft Corporation. All other trademarks are the trademarks of their respective companies.

CAUTION To comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules, the MediaConnect 8000 system must be installed in computer equipment certified to comply with Class A limits. All cables used to connect the computer and peripherals must be shielded and grounded. Operation with non-certified computers or non-shielded cables may result in interference to radio or television reception.

(3)

Limited Warranty

VCON Ltd. warrants the Product identified by the serial number indicated on the HARDWARE either accompanying the SOFTWARE or purchased separately will be free from defects in materials and workmanship under normal use and service for a period of ONE (1) year from the date of receipt. This Limited Warranty shall not apply to any product that in the opinion of VCON Ltd. has not been installed or upgraded according to accompanying documentation from VCON Ltd. or been subject to misuse, misapplication, negligence or accident while in the hands of the purchaser. VCON Ltd. warrants that SOFTWARE will perform according to accompanying user documentation for a period of 90 (ninety) days from the date of receipt; replacement SOFTWARE will be warranted for 90 (ninety) days from the date of receipt.

GRANT OF LICENSE VCON Ltd. grants the Purchaser a exclusive and non-transferable license to use the SOFTWARE product and to make one copy solely for backup or archival purposes, which may include user documentation provided via online or other electronic form. Additional copies may not be made nor may anyone else be allowed to copy or otherwise reproduce any part of the licensed software without prior written consent of VCON Ltd.

COPYRIGHT All trademarks(s), logo(s), name(s), software, documentation and other supporting materials relating to the Product are trademarked, copyrighted or owned by VCON Ltd. as proprietary information protected by United States copyright laws and international and applicable national treaty provisions and laws. Software protection extends beyond its literal code to structure, sequence and organization; any unauthorized use or modification would constitute a misappropriation of VCON’s proprietary rights and a violation of the License agreement.

LIABILITIES VCON’s entire liability and the Purchaser’s exclusive remedy shall be at VCON’s option, either return of the price paid or repair/replacement of the Product not meeting VCON’s declared Limited warranty. VCON or its suppliers shall not be liable in any event to anyone for any indirect, incidental, consequential, special or exemplary damages including without limitation damages for loss of business profits, business interruptions, business information or other pecuniary loss arising out of the use of or inability to use the said Product even if advised of the possibility of such damages. In any case, VCON’s entire liability under any provision of this agreement shall be limited to the amount actually paid by the Purchase for the Product.

(4)

iv VCON MediaConnect 8000 Getting Started Guide

Modifications

The FCC requires the user to be notified that any changes or modifications made to this system that are not expressly approved by VCON Ltd. may void the user’s authority to operate the equipment.

Safety Notice

When you use the MediaConnect 8000 system, observe the following safety guidelines:

Do not remove the cover of the computer or any other accessories. Refer all servicing only to the local VCON distributor or other VCON-certified technicians. To help avoid damaging the computer, make sure that the voltage selection switch on the power supply is set to match the AC power available at your location:

❑

115 V/60 Hz in most of North and South America and some Far Eastern countries such as Japan, South Korea and Taiwan

❑

230 V/50 Hz in most of Europe, the Middle East and the Far East.

Make sure the monitor and attached accessories (PTZ camera, VCR, document camera, and so on) are electrically rated to operate with the AC power available in your location.

To help avoid possible damage to the system boards, wait 5 seconds after turning off the system before disconnecting a device from the computer.

To help prevent electric shock, plug the computer’s and accessories’ power cables into properly grounded power sources. These cables are equipped with three-prong plugs to help ensure proper grounding. Do not use adapter plugs or remove the grounding prong from a cable. If you must use an extension cable, use a three-wire cable with properly grounded plugs.

Make sure that nothing rests on the computer system’s cables and that the cables are not located where they can be stepped on or tripped over.

Keep food and liquids away from the system or accessories.

Keep the computer away from radiators and heat sources. Also, do not block cooling vents. Avoid placing loose papers underneath the computer, and do not place the computer in a closed-in wall unit or on a bed, sofa, or rug.

DANGER Do not operate the computer with any of its covers (including main cover, bezels, filler brackets, front-panel inserts, and so on) removed.

(5)

For Users in Canada

NOTICE:

The Industry Canada Label identifies certified equipment. This certification means that the equipment meets telecommunications network protective, operational and safety requirements as prescribed in the appropriate Terminal equipment Technical Requirements document(s). The Department does not guarantee the equipment will operate to the user’s satisfaction.

Before installing this equipment, users should ensure that it is permissible to be connected to the facilities of the local telecommunications company. The equipment must also be installed using an acceptable method of connection. The customer should be aware that compliance with the above conditions may not prevent degradation of service in some situations.

Repairs to certified equipment should be coordinated by a representative designated by the supplier. Any repairs or alterations made by the user to this equipment, or equipment malfunctions, may give the telecommunications company cause to request the user to disconnect the equipment.

Users should ensure for their own protection that the electrical ground connections of the power utility, telephone lines and internal metallic water pipe system, if present, are connected together. This precaution may be particularly important in rural areas.

NOTICE:

The REN for this device is X.X. The Ringer Equivalence Number (REN) assigned to each terminal device provides an indication of the maximum number of terminals allowed to be connected to a telephone interface. The termination on an interface may consist of any combination of devices subject only to the requirement that the sum of the Ringer Equivalence Number of all the devices does not exceed 5.

CAUTION Users should not attempt to make such connections themselves, but should contact the appropriate electric inspection authority, or electrician, as appropriate.

(6)

vi VCON MediaConnect 8000 Getting Started Guide

Pour les utilisateurs au Canada

AVIS:

L’étiquette d’Industrie Canada identifie le matériel homologué. Cette étiquette certifie que le matériel est conforme aux normes de protection, d’exploitation et de sécurité des réseaux de télécommunications, comme le prescrivent les documents concernant les exigences techniques relatives au matériel terminal. Le Ministère n’assure toutefois pas que le matériel fonctionnera à la satisfaction de l’utilisateur. Avant d’installer ce matériel, l’utilisateur doit s’assurer qu’il est permis de le raccorder aux installations de l’entreprise locale de télécommunication. Le matériel doit également être installé en suivant une méthode acceptée de raccordement. L’abonné ne doit pas oublier qu’il est possible que la conformité aux conditions énoncées ci-dessus n’empêche pas la dégradation du service dans certaines situations.

Les réparations de matériel homologué doivent être coordonnées par un

représentant désigné par le fournisseur. L’entreprise de télécommunications peut demander à l’utilisateur de débrancher un appareil à la suite de réparations ou de modifications effectuées par l’utilisateur ou à cause de mauvais fonctionnnement. Pour sa propre protection, l’utilisateur doit s’assurer que tous les fils de mise à la terre de la source d’énergie électrique, des lignes téléphoniques et des canalisations d’eau métalliques, s’il y en a, sont raccordés ensemble. Cette précaution est particulièrement importante dans les régions rurales.

AVIS:

Le IES assigné à cette équipment est X.X. L’indice d’équivalence de la sonnerie (IES) assigné à chaque dispositif terminal indique le mombre maximal de terminaux qui peuvent être raccordés à une interface. La terminaison d’une interface téléphonique peut consister en une combinaison de quelques dispositifs, à la seule condition que la somme d’indices d’équivalence de la sonnerie de tous les dispositifs n’excède pas 5.

AVERTISSEMENT L’utilisateur ne doit pas tenter de faire ces

raccordements lui-même; il doit avoir recours à un service d’inspection des installations électriques, ou à un électricien, selons le cas.

(7)

About This Getting Started Guide

This guide explains how to set up and to start using the VCON MediaConnect 8000 series videoconferencing system.

For reasons of clarity, this guide refers to both MediaConnect 8000 and 8000Pro as “MediaConnect 8000.” In most cases, the descriptions and functions explained in this guide apply to both products. Otherwise, the particular product is specified. The chapters include detailed instructions for participating in videoconferences and getting the most out of the system’s features.

The following chapter summary briefly describes this guide’s contents: Chapter 1 Welcome to Group Videoconferencing

Introduction to this Getting Started Guide. Chapter 2 Getting Started

Instructions for starting MediaConnect 8000, making a videoconference call, and setting up the system configuration.

Chapter 3 Connecting the MediaConnect 8000

Procedures for connecting the standard equipment and accessories to the MediaConnect 8000 system. Chapter 4 Troubleshooting

Help in solving possible problems that you may encounter with the MediaConnect 8000 system. Appendix A Connecting Optional Accessories

Procedures for connecting optional accessories and peripheral equipment to the MediaConnect 8000 system.

Appendix B Upgrading to a New Version of MeetingPoint® Procedure for uninstalling a previous version of the MeetingPoint® application and installing the new version.

(8)

viii VCON MediaConnect 8000 Getting Started Guide

VCON Technical Support

This Getting Started Guide was designed to help you prepare the MediaConnect 8000 system easily so that you can enjoy its many features.

If a situation occurs that is not covered by the supplied documentation, please request help from our Technical Support channels.

1. Contact your local VCON distributor, and request assistance from its technical support department.

2. Send an e-mail message fully describing the condition plus your system’s configuration to [email protected].

(9)

T

ABLE

OF

C

ONTENTS

Limited Warranty ... iii

Modifications...iv

Safety Notice ...iv

For Users in Canada ...v

Pour les utilisateurs au Canada...vi

About This Getting Started Guide...vii

VCON Technical Support ... viii 1 Welcome to Group Videoconferencing

1.1 MediaConnect 8000 Models...1–1 1.2 Monitor Configurations ...1–2 1.3 MediaConnect 8000 System Components ...1–2 MediaConnect 8000 System Computer ...1–3 Pan/Tilt/Zoom Camera ...1–4 Wireless Keyboard and Receiver...1–5 Tabletop Microphone...1–6 SVGA Monitor (only with MediaConnect 8000Pro) ...1–6 Cart (only with MediaConnect 8000Pro)...1–6 Optional Accessories Supplied by VCON...1–7 2 Getting Started

2.1 Starting MediaConnect 8000 ...2–1 System Managed by MXM...2–1 MediaConnect 8000 and VCB On Same Computer ...2–3 Stand-alone System...2–4 2.2 Starting Videoconferences ...2–4 Starting a Videoconference over IP (Network Connection) ...2–4 Making a Videoconference Call over ISDN Lines...2–6 2.3 Setting Up the MeetingPoint Configuration ...2–7 2.4 Changing Configuration Information ...2–20 3 Connecting the MediaConnect 8000

3.1 Package Contents...3–1 3.2 Connecting Your Equipment ...3–3 Connecting the Wireless Keyboard ...3–5 Connecting the SVGA Monitor ...3–5 Connecting a TV Monitor (Dual Monitor Mode) ...3–6 Connecting Two TV Monitors (Triple Monitor Mode)...3–7

(10)

Table of Contents

x VCON MediaConnect 8000 Getting Started Guide

Connecting the Audio Output... 3–10 Connecting the Tabletop Microphone ... 3–11 Connecting the LAN ... 3–12 Connecting ISDN Lines ... 3–13 Connecting the MediaConnect 8000 to the Power Supply... 3–14 4 Troubleshooting

A Connecting Optional Accessories

A.1 Connecting a VCR for Playback to the Videoconference... A–2 A.2 Connecting a VCR a for Recording the Videoconference ... A–3 A.3 Connecting a Document Camera... A–4 B Upgrading to a New Version of MeetingPoint®

B.1 Uninstalling Previous MeetingPoint Versions ...B–1 B.2 Installing MeetingPoint ...B–2

(11)

1 W

ELCOME

TO

G

ROUP

V

IDEOCONFERENCING

Welcome to VCON’s MediaConnect 8000 series – a fully featured,

videoconference and collaboration rollabout system. The MediaConnect 8000 system is sophisticated, yet friendly. It gives you high video quality and powerful videoconferencing capabilities over an enterprise’s Internet Protocol (IP) local-area (LAN), wide-area networks (WAN) and Integrated Subscriber Digital Networks (ISDN).

1.1 MediaConnect 8000 Models

The MediaConnect 8000 series includes two product configurations:

The products are available in the following models (ask your VCON distributor about availability in your region):

MediaConnect 8000 models meet technical requirements prescribed in the H.323 and H.320 ITU-T standards for networking.

❑

H.323 is the worldwide accepted standard for transmitting video, audio and data across local-area and wide-area networks (LANs and WANs) using the Internet Protocol (IP).

❑

H.320 is the worldwide accepted standard for transmitting video, audio and data over WANs, including narrow-band Integrated Subscriber Digital MediaConnect

8000

LAN/IP (1.5 Mbps) and ISDN (384 Kbps/3 BRI) SVGA-based Workgroup Conferencing System. MediaConnect

8000Pro

LAN/IP (1.5 Mbps) and ISDN (384 Kbps/3 BRI) complete Rollabout Workgroup Videoconferencing system, including a large SVGA monitor and a specially designed cart.

Model 1 Provides one ISDN Basic Rate Interface (BRI) up to 128 Kbps and LAN connection up to 1.5 Mbps. This model is available only with the

MediaConnect-8000 system configuration. Model 3 Provides three ISDN BRI up to 384 Kbps, LAN

connection up to 1.5 Mbps, and support for VCR playback and recording.

(12)

Chapter 1 Welcome to Group Videoconferencing

1-2 VCON MediaConnect 8000 Getting Started Guide

1.2 Monitor Configurations

MediaConnect 8000 systems provide video viewing in the following configurations:

1.3 MediaConnect 8000 System Components

All the components required for connecting and installing the MediaConnect 8000 system are supplied along with comprehensive documentation and fully featured software to make your videoconferences more productive.

The standard MediaConnect 8000 components are:

•

Computer unit with installed videoconferencing board

•

Pan/Tilt/Zoom (PTZ) camera

•

Infrared wireless keyboard and receiver

•

Tabletop microphone

•

SVGA monitor (only with MediaConnect 8000Pro)

•

Cart (only with MediaConnect 8000Pro).

A range of easy-to-use additional accessories can also be provided to enhance the abilities of MediaConnect 8000 (see “Optional Accessories Supplied by VCON” on page 1-7).

Single Monitor This configuration contains one large SVGA monitor, on which local and remote video, the MediaConnect application screen, and shared data applications are displayed.

Dual Monitor This configuration contains one large SVGA monitor and one TV monitor. The SVGA monitor displays the MediaConnect application and shared data applications. The TV monitor displays the local and remote video.

Triple Monitor This configuration contains one large SVGA monitor and two TV monitors. The SVGA monitor displays the MediaConnect application and shared data applications. One TV monitor displays the local video and the other TV monitor displays the remote video.

(13)

MediaConnect 8000 System Computer

The MediaConnect 8000’s standard computer unit contains the videoconferencing board, software for operating the videoconferencing system, and various

connectors located on the rear panel for connecting the other components and accessories. The computer’s operating system may be Microsoft Windows NT or 2000.

The following figure illustrates the system computer.

MediaConnect 8000 System Computer - Front View

In conjunction with technological developments and VCON’s objective to provide a state-of-the-art system, the computer model is subject to change. Your computer may look different than the one shown above.

ON/OFF Button Floppy Drive

CD-ROM Eject CD-ROM Drive

(14)

Pan/Tilt/Zoom Camera

The Pan/Tilt/Zoom (PTZ) camera is controlled by the wireless keyboard through the system software. You can pan, tilt and zoom the camera in a wide range of directions during videoconferences.

The camera can zoom in to its subject up to 16:1.

Up to six pre-set positions can be set for instant recall through the MeetingPoint® application.

Connectors located on the rear of the Camera Unit enable connectivity through the system cables to the main computer.

(15)

Wireless Keyboard and Receiver

The infrared wireless keyboard provides remote control of the MediaConnect 8000 system. It works in conjunction with an infrared receiver, which must be located close to or on the SVGA monitor.

When you use the wireless keyboard, direct at the keyboard receiver from a distance of up to 6 meters.

Wireless Keyboard

(16)

Tabletop Microphone

The supplied tabletop microphone is a high-performance omnidirectional audio source. It is highly sensitive, with a working range covering approximately 6 meters (20 feet) at an area greater than 270° from the front of the unit. The microphone transfers the full range of speaker audio.

The microphone’s cable is 6 meters (app. 20 feet).

SVGA Monitor (only with MediaConnect 8000Pro)

The MediaConnect 8000Pro includes a large SVGA monitor. The monitor provides high quality non-interlaced video at a resolution of up to 1024 x 768 pixels. Using high-quality horizontal and vertical frequencies, the monitor also provides options of automatic or manual degaussing. It is powered by 100-120/180-240 Vac (autoswitchable).

Cart (only with MediaConnect 8000Pro)

The MediaConnect 8000Pro includes an elegant mobile wooden cabinet that is specially designed to house the system components. The SVGA monitor sits on top of the cart, and two shelves are provided for the computer and other accessories.

(17)

Optional Accessories Supplied by VCON

The following optional accessories can be connected to the MediaConnect 8000: VoiceFinder During a group discussion, the VoiceFinder locates

voices, then positions and focuses the camera on the person currently speaking. Its streamlined structure contains four high-quality microphones and advanced technology for intelligent tracking.

VCON VoiceFinder and Camera Unit Document

camera or Second PTZ camera

Increases the video capabilities of the MediaConnect 8000. The second camera may typically be a document camera or another PTZ camera. For example, a document camera can show a placed document on the monitor during a videoconference session to both the local and remote users.

TV monitor(s) For viewing remote and local video in dual (1 TV) and triple (2 TV) monitor configurations.

(18)

(19)

2 G

ETTING

S

TARTED

This chapter provides instructions for starting MediaConnect 8000, making a videoconference call, and setting up the system’s configuration using the Configuration Wizard.

2.1 Starting MediaConnect 8000

➤

To start up the MediaConnect 8000 system

❑

To turn the computer on , press the Power button on its front panel. Microsoft Windows will execute the startup sequence.

Make sure all accessories (camera, SVGA Monitor, and if applicable, TV monitors) connected to the system are also switched on.

MeetingPoint’s Start procedure varies, depending on whether or not your system will be in a videoconferencing network managed by a VCON Media Xchange Manager™ (MXM).

System Managed by MXM

➤

To start MeetingPoint

1. In the Windows Desktop, click the VCON MeetingPoint icon.

The Login dialog box appears.

CAUTION DO NOT attempt to turn the MediaConnect 8000 system ON (Power button) until all of its components and accessories are properly connected. For connection instructions, see Chapter 3, “Connecting the MediaConnect 8000”.

If a MediaConnect 8000 and VCON Conference Bridge (VCB) are installed on the same computer, you must specify the IP address of the MediaConnect 8000 (see the following section).

(20)

Chapter 2 Getting Started

2-2 VCON MediaConnect 8000 Getting Started Guide Initial Login (Registration) to MXM

2. Enter MXM login information as follows (consult with your system administrator):

3. Click Connect to complete the login process.

— If the MXM automatically registers your computer, the MeetingPoint application opens.

— If a message appears stating that the MeetingPoint startup cannot proceed until login is granted, contact your system administrator. After login is granted, click Connect to continue.

MXM Login Name

The name of your computer as listed in the MXM database and the MXM Administrator.

Password/ Verify Password

Password required to log in. The first time you register, you must type it twice for verification. If you do not supply this password, the login request is rejected. Gatekeeper The IP address of the MXM. If you do not know it, ask

your system administrator.

If you are running MeetingPoint for the first time after installation (or logging into a different MXM), the Configuration Wizard setup program appears. This program asks you to enter the information required to run MeetingPoint from your specific location. For the complete standard setup procedure, see “Setting Up the MeetingPoint Configuration” on page 2-7. MeetingPoint’s default properties are suitable for most video meeting requirements. If you must change these settings, please consult with your system administrator or VCON distributor.

(21)

Conference Panel(MXM Support) and Local Video Window

At this point, if the system’s communication lines are connected, you may start a video meeting and receive incoming video meeting calls.

MediaConnect 8000 and VCB On Same Computer

If a MediaConnect 8000 and VCON Conference Bridge (VCB) are installed on the same computer, they each occupy their own IP address. In this case, when you run MeetingPoint, you must specify the IP address of the MediaConnect 8000.

Entering IP Address of the MediaConnect 8000

➤

To select the IP address of the MediaConnect 8000

1. From the Select IP Address list, select the IP address of the MediaConnect 8000.

For normal operation, the MediaConnect 8000 must be assigned the computer’s secondary IP address.

(22)

Stand-alone System

➤

To start MeetingPoint

1. In the Windows Desktop, click the VCON MeetingPoint icon. The Conference Panelappears, followed by the Local Video window.

Conference Panel - No MXM Support

At this point, if the system’s communication lines are connected, you may start a video meeting and receive incoming video meeting calls.

2.2 Starting Videoconferences

Videoconferences may be carried out over your network connection (over IP) or over ISDN phone lines.

Starting a Videoconference over IP (Network Connection)

Use the LAN Dialer to make a call over the network connection, using IP. If you are running MeetingPoint for the first time after installation, the Configuration Wizard setup program appears. This program asks you to enter the information required to run MeetingPoint from your specific location. For the complete standard setup procedure, see “Setting Up the MeetingPoint Configuration” on page 2-7.

MeetingPoint’s default properties are suitable for most video meeting requirements. If you must change these settings, please consult with your system administrator or VCON distributor.

(23)

Dialing Out Over a LAN Connection

➤

To dial through the LAN Dialer

1. In the Address Book Explorer, click the Manual Dialers folder to display the available dialers. Click LAN Dialer.

2. In the box at the top of the right pane, type the IP address (or Alias or E.164 number if a Gatekeeper is connected to your LAN) you want to call. 3. Click Dial to start a videoconference. The Conference Control window

shows the status of your call until the call is accepted and the remote participant appears in the Remote Video window (Single Monitor mode) or in a TV monitor (Dual/Triple Monitor) mode.

If the call does not succeed, a large X appears over the picture of the telephone and the reason for the call failure appears. Click Cancel to close the Conference Control window, or Redial to start the call again.

4. Click the HangUp button to end the call. This button is available during a videoconference.

(24)

Making a Videoconference Call over ISDN Lines

Use the ISDN Dialer to make a call over ISDN lines.

Dialing Out Over an ISDN Line

➤

To dial through the ISDN dialer

1. In the Address Book Explorer, click the Manual Dialers folder to display the available dialers. Click ISDN Dialer.

2. In the box at the top of the right pane, type the ISDN number you want to call.

3. Click Dial to start a videoconference. The Outgoing Call window shows the status of your call until the call is accepted and the remote participant appears in the Video window.

If the call does not succeed, a large X appears over the picture of the telephone and the reason for the call failure appears. Click Cancel to close the Outgoing Call window, or Redial to start the call again.

4. Click the HangUp button to end the call. This button is available during a videoconference.

(25)

2.3 Setting Up the MeetingPoint Configuration

MeetingPoint® is the MediaConnect 8000’s videoconferencing software application. It is pre-installed in the MediaConnect 8000 unit at a VCON facility prior to delivery. However, when you start MeetingPoint for the first time, you have to set up its configuration, according to your particular specifications, in the Configuration Wizard. The Configuration Wizard guides you through the required stages and requests the relevant information for normal operation of MeetingPoint. In addition, you may change any of these configuration details (as long as they are compatible with your equipment) whenever the system is on. The Properties

command is available:

❑

In the Conference Panel’s shortcut menu. Right-click to open it.

❑

In the Conference Panel button menus. Click any arrow to open a specific menu for each MeetingPoint application.

❑

In particular windows and dialog boxes.

(26)

➤

To set up the MeetingPoint configuration

1. In the Configuration Wizard’s opening page, click Next to continue. The User Information dialog box appears.

User Information Configuration

2. In the User information section, type your First Name, Last Name,

Company name, and E-mail address.

In the Dialing Information section, click the Country that you are in, type your area code, and type the appropriate digits for dialing an outside line (External), a Long Distance call, or an International call.

Click Next to continue.

If you need to dial a specific digit to receive an external line, you must type that digit before the digits required for a long distance or international call. For example, if you have to dial 9 to receive an external line, and then 01 to dial long distance, type 901 in the Long Distance box.

(27)

3. In the Communication list, select the type of external communication line your system will use.

Connection Dialog Box

— If you selected None, the LAN dialog box appears. Proceed directly to step 7.

— If you selected On BoardISDN, the Switch Type dialog box appears. Continue to the next step.

None Select for using MeetingPoint with a LAN connection only.

On Board ISDN Select for using MeetingPoint with an ISDN line through the videoconferencing card, in addition to a LAN connection.

(28)

4. In the Switch Type dialog box, the country you are in already appears as

Your Location (set in the User Information dialog box in step 2).

Switch Type Dialog Box

In the Switch Type list, the most common switch type for your country appears automatically. If you are using a different switch type (according to your ISDN carrier), click a different switch type:

In certain areas of the United States, the main ISDN network is Restricted (data rate of 56K). If the computer is connected to a Restricted network, select Check this box if you have restricted 56K access.

Click Next to continue. The Phone Numbers dialog box appears.

•

AT&T 5ESS Custom

•

German 1TR6

•

National ISDN 1

•

French VN3

•

NT DMS100 Custom

•

Australian TS013

•

Japanese NTT

•

Euro-ISDN NET3

If you are not sure whether the computer is connected to a Restricted network, do not select this option. If necessary, consult with your system administrator or ISDN carrier.

(29)

5. In the Phone Numbers dialog box, enter your ISDN phone numbers.

ISDN Phone Numbers Configuration

— If you selected switch type AT&T 5ESS Custom, National ISDN 1

or NT DMS100 Custom, the SPID Numbers dialog box appears. — Otherwise, the LAN dialog box appears. Proceed directly to step 7. Select the

number of ISDN phone lines you will be using

Click the number of ISDN lines the system uses. The number of available lines depends on the number of BRIs (Basic Rate Interface) on the videoconferencing card. Each BRI supports up to two phone lines of 64 kbps each (56 kbps in Restricted networks).

Phone Numbers In the Phone numbers boxes, type the ISDN numbers of each line. Do not include your own country’s

international code or your local area code.

If your ISDN carrier supplied you two identical phone numbers for a BRI, type the number in the consecutive boxes (#1&#2, #3&#4, #5&#6). In all other cases, the phone numbers for each ISDN line may be different.

(30)

6. If your ISDN carrier supplies you with SPID (Service Profile Identifier) numbers, you have to enter them in the SPID Numbers dialog box. A SPID number describes the capabilities of each computer or phone on the ISDN lines. This information may be important to your local telephone company in defining the level of service to provide. If necessary, obtain this information from your ISDN carrier.

SPID Numbers Configuration

Enter SPID Numbers information as follows:

Click Next to continue. The LAN dialog box appears.

Number of SPIDs Click the amount of SPID numbers that you have. SPID 1,2,3,4,5,6 Type the SPID numbers.

If the SPID numbers for each line are identical, or you received only one SPID number from your ISDN carrier, type that number in the SPID 1 box. If you did not receive a SPID number, leave the SPID boxes blank.

(31)

7. In the LAN dialog box, enter configuration information for holding video meetings over the connected network.

LAN Connection Configuration

The LAN configuration includes:

User Name The user’s unique name on the connected network (H.323 alias).

User Number The user’s unique logical number (E.164 string) as defined by your network’s system administrator. The User Number must consist of digits only. Gatekeeper

Address The IP address of the H.323 Gatekeeper to which the computer may register. If your organization has installed a gatekeeper, we recommend that you enter its address. If you do not know its address, ask your system administrator.

If you leave this box blank, the computer cannot register with a gatekeeper.

(32)

Click Next to continue. The Online Directories dialog box appears. — If this version does not support MXM, the Online Directories dialog

box appears.

— Otherwise, the Pan/ Tilt/Zoom Camera appears. Proceed directly to step 9.

Allow Adaptive Bandwidth Adjustment

Select this option to enable reduction of the alloted bandwidth if the network is congested.

Enable Lip Synchronization Mechanization

Select this option to enable adjustment of the video and the audio if they are out of sync with each other (see the MeetingPoint® User Guide, Appendix B, “Monitoring the Conference State”).

Automatic Buffering Control

❑

Select this option to enable the system to automatically control the amount of buffering required to maintain the consistency of the video and audio transmission. For example, if video packets are delayed for 1 or 2 seconds, the system will automatically synchronize the transmission so that the delay does not disturb the visible video.

❑

Deselect this option only if the automatic buffering is not sufficient — for example, if the quality of the video meeting is poor or there is a noticeable delay.

(33)

8. In the Online Directories dialog box, specify if you want to register with an online directory, and if so, which one. Online directories contain lists of registered Internet users who are currently connected to the Internet (online). These directories are usually located on Internet Location Servers (ILS). By default, MeetingPoint enables you to register in the same ILS as other VCON videoconferencing users, ils.vcon.co.il.

Online Directories Dialog Box

Enter Online Directories information as follows:

Click Next to continue. The Pan/ Tilt/Zoom Camera dialog box appears. Online

Directories Select DirectoriesRegister with and Display Online if you want to display an online directory in the MeetingPoint Address Book. Online

Directory Server

In the Server Name list, select the name of the server that you want to register with when you are online.

(34)

9. Set the type of main camera that is connected to the system and the communications port through which it can be controlled. As its standard, MediaConnect 8000 systems are installed with the camera unit connected to COM1.

Pan/Tilt/Zoom Camera Configuration Dialog Box

Enter information as follows: Camera

Selection

In the Select your Pan/Tilt/Zoom camera type

list, select the manufacturer and/or model of the PTZ camera.

In the Select the communication port it is connected to list, select the name of the computer port to which the camera is connected.

Camera

Control Select settingsAllow the remote side to control camera to permit the remote party to control the position and video settings of your PTZ camera. If you do not have a PTZ camera, this option is not relevant.

(35)

— If you chose None in step 3, the Confirmation dialog box appears. Proceed directly to step 12.

— If you chose On BoardISDN in step 3, the MSN dialog box appears. 10. If the connected ISDN network supports Multiple Subscriber Numbering

(MSN), you can specify whether or not you want to use this feature. The MSN service provides more than one phone number per ISDN line. This enables you to connect several phones, faxes, modems, and/or other devices to their own individual phone numbers over a single ISDN line.

MSN Configuration

Enter MSN information as follows:

MSN Support

❑

Select Yes to use MSN capabilities. When MeetingPoint opens after this setup process, you will be able to specify the exact MSN numbers for the computer in the MSN tab of the Conference Panel Configuration Properties dialog box.

❑

Select No if the connected ISDN network does not support this feature, or if you don’t want to use it.

(36)

11. The Sub-Addressing dialog box is applicable if the MediaConnect 8000 shares an ISDN BRI line with other equipment (such as other computers, fax machines, standard telephones, and so on). In such a case, an

additional series of numbers and/or letters is added to the end of its phone number.

Sub-Addressing Dialog Box

If the computer has a sub-address, enter information as follows:

Click Next to continue. The Confirmation dialog box appears. Sub-Addressing Type the phone number followed by an “¦” character,

and the series of numbers and/or letters making up the sub-address.

If the connected ISDN network does not support this feature, or if you do not want to use it, leave this box blank.

(37)

12. In the Confirmation dialog box, review the information that you entered during the MeetingPoint setup process. If necessary, drag the scroll bar down to see more information.

Confirmation of Setup Information

To change any information before exiting the Configuration Wizard, click

Back to return to a specific dialog box and make the appropriate changes. When you are finished, click Next as many times as necessary to return to the Confirmation dialog box and check your settings again.

13. To save the setup and exit the Configuration Wizard, click Finish. The MeetingPoint application now starts. The local video appears on the SVGA monitor (in Single Monitor mode) or on a TV monitor (in Dual or Triple Monitor mode).

To cancel the setup, click Cancel. In this case, all setup information will be discarded and you will not be able to run MeetingPoint until you perform the setup at another time.

(38)

2.4 Changing Configuration Information

After completing the Configuration Wizard the first time that you run

MeetingPoint, you can change the configuration information through the System Properties dialog boxes. The System Properties are accessible from several locations.

The table below describes the quickest way to access the configuration information that you entered in the Configuration Wizard.

User Information In the Conference Panel, right-click and then click

Properties. In the Properties dialog box, click the User Data icon.

LAN or

❑

Double-click the Gatekeeper icon in the Conference Panel tray.

-or-MXM-compatible applications only

In the Conference Panel, click the Services arrow and then click H.323 Properties.

If the system is not registered with a GateKeeper:

❑

In the Conference Panel, right-click and then click

Properties. In the Properties dialog box, click the

Communication icon. Online

Directories

Non-MXM-compatible applications only

1. In the Conference Panel, click the Dialer arrow and then click Properties. The Address Book

Properties dialog box appears with the General tab open.

(39)

Chapter 2 Getting Started Pan/Tilt/Zoom 1. In the Conference Panel, right-click and then click

Hardware icon. 2. Click the Camera tab. Switch Type,

Phone Numbers, SPID, MSN, Subaddressing

1. In the Conference Panel, right-click and then click

Telephony icon. 2. Click the appropriate tab.

(40)

(41)

3 C

ONNECTING

THE

M

EDIA

C

ONNECT

8000

The MediaConnect 8000 system installation process includes the following stages:

❑

Unpacking the items from the shipping package

❑

Connecting the supplied standard and optional equipment

3.1 Package Contents

When you open the MediaConnect 8000 system shipping package(s) for the first time, check that the following items are included in accordance with the supplied product. If any of the items (according to your Customer Order) are missing or damaged, contact your VCON distributor immediately.

MediaConnect 8000 Components

Component Basic Pro

Model 1 Model 3 Model 3

IBM Pentium III computer with VCON

videoconferencing card installed

✔

Pan/Tilt/Zoom (PTZ) camera unit with its

power supply, camera control and composite video cables, and remote control (with 2 AA batteries)

✔

Infrared wireless keyboard & receiver

(with 4 AA batteries)

✔

Tabletop microphone & cable

✔

Power cable

_✔

ISDN cable

✔

(3)

✔

(3)

S-Video 4x4 cable —

✔

S-Video 8x4 cable

_✔

(42)

Chapter 3 Connecting the MediaConnect 8000

2 Audio cables (stereo,

stereo-dual RCA)

✔

Audio cable (dual RCA-dual RCA) —

✔

MeetingPoint® software CD-ROM (software pre-loaded in system)

✔

Rescue CD-ROM, including operating

system

✔

29" SVGA Monitor — —

✔

SVGA cable — —

✔

Rollabout cabinet & keys — —

✔

MediaConnect 8000 Getting Started

Guide

✔

MeetingPoint® User’s Guide

✔

Limited Warranty/registration card

_✔

Component Basic Pro

(43)

3.2 Connecting Your Equipment

This section describes the connection of the standard equipment supplied with the MediaConnect 8000 system.

The following figure illustrates the rear side of the MediaConnect 8000 Model 3 computer unit.

MediaConnect 8000 Computer Unit (Model 3)

CAUTION For all components and accessories, make sure that the power is turned off and the item is disconnected from its power supply before making all connections.

To PTZ camera’s VISCA IN connector To SVGA monitor To LAN To electrical

power supply VCON videoconferencing card

Keyboard Receiver to mouse port

and KYBD connector

To AUDIO IN of SVGA monitor From SPKR connector of videoconferencing card To VoiceFinder (if installed -

purchased separately from VCON)

(44)

The following figure describes which items are connected to specific connectors on the Monitor 3000 videoconferencing card.

Connections to Videoconferencing Card ISDN 1 ISDN 2 ISDN 3 Microphone Audio OUT Speakers S-Video OUT TV (Dual Monitor) S-Video IN PTZ Camera Second or Document Camera VCR Audio In VCR Audio Out/ Dual Monitor VCR Video In VCR Video Out/ Dual/Triple Monitor

(45)

Connecting the Wireless Keyboard

1. Locate the box containing the Wireless Keyboard and take out the following two items:

— Infrared (IR) Receiver — Wireless Keyboard

2. Feed the cables from the IR receiver through the small hole at the rear of the IR receiver cut-out on the rollabout cabinet. Push the receiver gently into position.

If you do not have the rollabout cabinet, place the IR receiver on top of your SVGA monitor.

3. Connect the two cables to the mouse port and the KYBD mini-DIN PS/2 connector on the computer’s rear panel. Place the Wireless Keyboard on your conference table, preferably at an operating distance of no more than 6 meters away from the keyboard receiver.

Connecting the SVGA Monitor

➤

To connect the SVGA monitor to the MediaConnect 8000 system

❑

Connect the supplied SVGA cable between the VGA output on the rear of the MediaConnect 8000 computer and the VGA input on the rear of the supplied 29" SVGA Monitor (supplied only with

MediaConnect 8000Pro).

CAUTION Make sure that the computer is turned off.

If a Wireless Keyboard, which use a serial mouse control instead of PS/2 control, is supplied, the mouse control connection will be a 9-way D-type connector connected to the COM2 port on the rear of the

MediaConnect 8000 computer unit.

CAUTION Make sure that the computer and the SVGA monitor are turned off.

(46)

Connecting a TV Monitor (Dual Monitor Mode)

Dual Monitor mode comprises one SVGA monitor (for connection instructions, see “Connecting the SVGA Monitor” earlier in this section) and one TV monitor.

➤

To connect a TV monitor to the MediaConnect 8000 system in Dual Monitor mode

❑

Depending on whether the TV monitor supports S-Video (mini-DIN connector) or Composite (RCA), connect the supplied TV cable between the applicable ports.

If the TV monitor uses:

CAUTION Make sure that the computer and the TV monitor are turned off.

If the TV monitor supports both of these types, we recommend that you use the S-Video connection because it provides higher quality video.

S-Video Signalling Composite Video Signalling

Connect the TV cable between the TV’s Video In connector and the videoconferencing card’s MONITOR

connector.

Connect the TV cable between the TV’s Video In connector and the videoconferencing card’s VCR VID OUT connector.

(47)

Connecting a TV Monitor in Dual Monitor Mode

Connecting Two TV Monitors (Triple Monitor Mode)

Triple Monitor mode comprises one SVGA monitor (for connection instructions, see “Connecting the SVGA Monitor” on page 3-5) and two TV monitors.

Because of the videoconferencing card panel’s configuration, one TV monitor must be connected to the S-Video connector (mini-DIN) and the other TV monitor must be connected to the Composite (RCA) connector.

➤

To connect two TV monitors to the MediaConnect 8000 system in Triple Monitor mode

1. Connect the supplied S-Video TV cable between the S-Video-type TV’s Video In connector and the videoconferencing card’s MONITOR

connector.

2. Connect the supplied RCA TV cable between the RCA-type TV’s Video In connector and the videoconferencing card’s VCR VID OUT

connector.

CAUTION Make sure that the computer and both TV monitors are turned off.

(48)

3-8 VCON MediaConnect 8000 Getting Started Guide Connecting Two TV Monitors in Triple Monitor Mode

Connecting the Main PTZ Camera

➤

To connect the main Pan/Tilt/Zoom camera to the MediaConnect 8000 computer unit

1. Connect the supplied S-Video + Camera Control harness as follows: the

VIDTOP connector on the videoconferencing card and the S VIDEO OUT connector on the camera.

2. Connect the camera control cable between the camera’s RS232C IN

connector on the camera and the COM1 serial port on the rear panel of the MediaConnect 8000computer unit (see the figure on page 3-3).

3. Place the camera at the vantage point you want.

4. Connect the power cable between the power supply and the camera’s DC IN connector.

5. Connect the camera control cable between the camera’s RS232C IN

connector on the camera and the COM1 serial port on the rear panel of the MediaConnect 8000computer unit (see the figure on page 3-3).

6. Place the camera at the vantage point you want.

In Triple Monitor mode, one TV monitor displays the local view and the other TV monitor displays the remote view. You may switch this function between the monitors by using the Video Window’s Select Camera function (see “Selecting an Active Camera” in the MeetingPoint® User’s Guide).

(49)

7. Connect the power cable between the power supply and the camera’s DC IN connector.

(50)

Connecting the Audio Output

➤

To connect the MediaConnect 8000 system’s audio output to the SVGA monitor

1. Connect one of the supplied audio cables between the IN connector of the sound card and the videoconferencing card’s SPKRS connector.

2. Connect the second audio cable between the OUT connector of the sound card and the AUDIO IN connectors left and right of the SVGA monitor.

(51)

Connecting the Tabletop Microphone

➤

To connect the tabletop microphone

1. Connect the microphone’s 3.5mm jack to the MIC connector on the videoconferencing card.

2. Place the microphone on your conference table with the cable stretching toward the MediaConnect 8000 system.

(52)

Connecting the LAN

LAN support on the MediaConnect 8000 system is built on-board directly onto the motherboard of the computer. The computer provides a standard RJ-45 interface for 10-Base-T and 100-Base-T networks.

➤

To connect the MediaConnect 8000 system to your LAN

❑

Connect the LAN cable between the RJ-45 connector on the rear of the computer (see the figure on page 3-3) and the outlet to your LAN.

(53)

Connecting ISDN Lines

➤

To connect the MediaConnect 8000 system to one ISDN lines (2 B-channels providing 128 Kbps connectivity)

❑

Connect an ISDN cable to the ISDN 1 connector on the videoconferencing card and the outlet to your ISDN line.

➤

To connect the MediaConnect 8000 system to two ISDN lines (4 B-channels providing 256 Kbps connectivity)

❑

Connect one ISDN cable to the ISDN 1 connector and the second ISDN cable to the ISDN 2 connector on the videoconferencing card and the outlet to your ISDN line.

➤

To connect the MediaConnect 8000 system to three ISDN lines (6 B-channels providing 384 Kbps connectivity)

❑

Connect one ISDN cable to the ISDN 1 connector, the second ISDN cable to the ISDN 2 connector, and the third ISDN cable to the ISDN 3

connector on the videoconferencing card and the outlet to your ISDN line.

(54)

Connecting the MediaConnect 8000 to the Power Supply

After you completed all the MediaConnect 8000’s components connections, you can connect the MediaConnect 8000 to a 115 Vac or 230 Vac power supply, depending on the local power line.

➤

To connect the MediaConnect 8000 to a power supply

1. Below the power socket on the rear panel of the unit, change the voltage setting to 115 Vac or 230 Vac if necessary.

115/230 Volt Power Setting

2. Insert the power cable into the power socket on the rear panel. 3. Insert the plug into the power supply.

CAUTION The factory default setting corresponds to the voltage of the electricity supply of your region. As a precaution, check that the setting is correct before starting MediaConnect 8000.

(55)

4 T

ROUBLESHOOTING

This chapter may help you resolve certain conditions that may occur while operating the MediaConnect 8000 system.

If you are unable to find a solution to your problem, please request help from our Technical Support channels.

➤

To request technical support

❑

Contact your local VCON distributor, and request assistance from its technical support department.

-or-Send an e-mail message fully describing the condition plus your system’s configuration to [email protected]. . Connection Problems Solution When switched ON, the system does not have any power

1. Verify that the power cable is correctly inserted in the power connector on the computer’s rear panel and that it is firmly plugged into the power outlet.

2. Verify that the power outlet is working correctly. 3. If the problem still remains, contact your local VCON

(56)

Chapter 4 Troubleshooting

Keyboard Problems

Solution

When you work with the keyboard, the system does not respond.

1. Make sure that you are directing the keyboard directly at the receiver unit with no obstructions between them. 2. Check that the receiver is connected correctly and that

the receiver LEDs are ON.

3. Optimal distance for using the keyboard is 6 meters (19.5 feet). Use of the keyboard over a long period of time without replacing its batteries will reduce this optimal distance.

4. Check that the batteries are inserted correctly in the keyboard. If necessary, replace the batteries.

5. If the problem still remains, contact your local VCON distributor for further instructions.

(57)

Chapter 4 Troubleshooting Camera Problems Solution The camera does not respond to movement requests.

1. Make sure that you are directing the keyboard directly at the receiver unit with no obstructions between them. 2. Verify that the Camera unit is connected correctly to the

computer.

3. Verify that the camera unit is set as unit number 1 (CAMERA NO. switch on rear of camera unit). 4. Verify that the camera control cable is connected

between the VISCA IN connector on the camera and the

COM1 serial port on the rear panel of the computer.

The Far End (remote) camera does not respond.

1. Verify that a controllable PTZ camera is connected to the remote user’s computer.

2. Verify that the remote user allows you to establish control the remote camera.

3. Verify that remote camera control was enabled in your system (in the System Properties>Hardware>Camera dialog box, Auto Connect Remote PTZ Camera Control must be selected).

(58)

Video Problems

Solution

The system is switched ON but the local Video Image is blank.

1. Verify that the Camera is switched ON.

2. Verify that all connections from the computer to the Camera unit are correct.

3. In the Local Video window, select each camera in turn to verify selection of the correct video source

The local Video Image is the VCON logo.

1. If you have only the SVGA monitor, verify that you have chosen the Single Monitor Mode from the Video Window.

2. If you have a TV and an SVGA monitor, verify that you have chosen the Dual Monitor Mode, and that the TV is tuned into the correct channel.

The video image is unstable and coming through in blocks.

❑

Verify that you dialed two (B-channel) numbers for each ISDN line. If you only dial one number for each line, only 64 kbps will be used instead of 128 kbps. Disconnect the call and dial again, or ask the caller to redial.

(59)

Chapter 4 Troubleshooting Audio Problems Solution When connected in a video-conferencing session, you cannot hear any sounds from the remote user.

1. Verify that the system’s volume is not turned down or muted.

2. Verify that the monitor volume is not muted.

3. Verify that all audio connections from the computer to the SVGA monitor are correct.

4. Verify that the remote participant has not muted audio transmission from the remote side.

5. If you started the videoconference, then disconnect and redial to verify whether the problem remains. If the remote user started the videoconference, advise the remote user to disconnect and redial to verify whether the problem remains.

6. Connect MediaConnect 8000 in a loopback (dial the second ISDN channel of the first BRI pair) and verify that your audio is working.

(60)

4-6 VCON MediaConnect 8000 Getting Started Guide Audio from

your system is not being received by the remote user.

1. Verify that you have not turned the audio transmitted from your microphone off – muting audio being transmitted from your system to the remote user. 2. Verify that in the system Properties>Hardware>Audio

dialog box, the correct Audio Device and Microphone Origin are selected.

3. Verify that the connection from the microphone to the computer is correct.

4. Instruct the remote participant to examine the remote system as indicated in the previous section for received audio.

5. Connect your system in a loopback (dial the second ISDN channel of the first BRI pair) and verify your audio.

Audio reception is not clear.

❑

Verify that you dialed two (B-channel) numbers for each ISDN line. If you only dial one number for each line, only 64 kbps will be used instead of 128 kbps. Disconnect the call and dial again, or ask the caller to redial.

Audio Problems

(61)

Chapter 4 Troubleshooting Connectivity Problems Solution When trying to start or receive an ISDN call, the connection fails.

1. Verify that the ISDN line(s) are connected and not loose. 2. In the system Properties>Telephony>Phone Numbers

dialog box, check that the ISDN numbers entered match the connected line(s).

When trying to start or receive a LAN call, the connection fails.

1. Verify that the LAN cable is connected and not loose. 2. Verify that the TCP/IP settings (Windows Control

Panel>Network>Configuration tab) are correct.

When trying to start or receive a call through the Gatekeeper, the connection fails.

1. Verify that the Gatekeeper IP Address is entered correctly in the Gatekeeper Address box of the system Properties >Communication>LAN dialog box.

2. Verify that your system’s E.164 code or alias name is entered correctly in the User Alias box of the system Properties >Communication>LAN dialog box.

(62)

(63)

A

C

ONNECTING

O

PTIONAL

A

CCESSORIES

In addition to its standard components, the MediaConnect 8000 system is compatible with various optional accessories and peripheral devices that add features and convenience to your conferencing. This appendix explains how to connect these devices:

•

Connecting a VCR for Playback to the Videoconference

•

Connecting a VCR a for Recording the Videoconference

(64)

Appendix A Connecting Optional Accessories

A-2 VCON MediaConnect 8000 Getting Started Guide

A.1 Connecting a VCR for Playback to the

Videoconference

The MediaConnect 8000 system supports the playback of a videocassette to a videoconference.

➤

To connect a VCR to the videoconferencing card’s panel for playback

1. Connect the VCR cable with the (usually yellow) jacks between the VIDEO OUT connector of the VCR and the VCR VID IN (yellow) connector of the videoconferencing card.

2. Connect the VCR cable with the (usually white) jacks between the AUDIO OUT connector of the VCR and the VCR AUD IN (white) connector of the videoconferencing card.

3. Verify that the VCR is connected to a power supply.

For specific instructions on installing and operating the VCR, see its accompanying user’s guide.

Connecting to VCR for Playback to the Videoconference CAUTION Make sure that the computer and the VCR are turned off.

(65)

Appendix A Connecting Optional Accessories

A.2 Connecting a VCR a for Recording the

Videoconference

The MediaConnect 8000 system supports the recording of a videoconference. The system must be operating in Dual or Triple Monitor mode in order to record.

➤

To connect a VCR to the videoconferencing board’s panel for recording

1. Connect the yellow-jack cable between the VIDEO IN connector of the VCR and the VCR VID OUT (yellow) connector of the

videoconferencing card.

2. Connect the VCR cable with the white jacks between the AUDIO IN connector of the VCR and the VCR AUD OUT (black) connector of the videoconferencing card.

For specific instructions on installing and operating the VCR, see its accompanying user’s guide.

Connecting to VCR for Recording Videoconferences
