Thomas Built Buses. Original

(1)

(2)

2 ZONAR • zonarsystems.com • 877.843.3847

T

aBle

of

C

onTenTs

s

oluTions

3

V3™ TelemaTics conTrol UniT 4

Z Pass™ 5

ZTa™ 6

Z Pass+™ 7

inPUT/oUTPUT (i/o) 8

Panic BUTTon 9

GroUnd Traffic conTrol™ 10

R

epoRTing

C

apaBiliTies

12

Zonar’s GPs rePorTinG 13

diaGnosTics rePorTinG 19

i/o rePorTinG 23

sTUdenT TrackinG rePorTs 24

ZalerTs 26

Geo-fencinG caPaBiliTies 28

(3)

s

oluTions

The products included in the recommended package represent

the latest technology aimed at creating safe and efficient fleets

(4)

V3

™

T

elemaTiCs

C

onTRol

u

niT

f

lexiBle

T

rackinG

+ d

iaGnosTics for

m

ixed

f

leeTs

The Next Best Thing to Being in the Driver’s Seat

Real-time fleet management This easy-to-install device is available in a variety of packages to meet the needs of all mixed fleets. Depending on the connections available in each vehicle, the V3™ will collect data either from GPS data or straight from the vehicle’s engine control unit (ECU). The V3™ also provides an integration platform as the hub that connects all Zonar in-vehicle devices, such as our inspection module, EVIR®_{, and optional inputs (I/Os)}

to capture events. With a 5-year warranty, the V3™ is the best value for your customers’ fleets.

Tells your customers what they need to know

Our V3™ provides the first GPS system to capture data in five dimensions: latitude, longitude, time, odometer, and, with the Ground Traffic Control™ package, fuel consumption. The V3™ provides a new level of precision and gives your customers a real-time window into their fleet’s activities, so they can make important decisions about operations based on the latest data.

Available in these packages: • Track & Trace Service is a simple

plug-in, available for light-duty cars and trucks. It provides GPS tracking, location and path for vehicle location and tracking. • Track, Trace & Idle Service

will provide alerts if the Check engine or Stop engine light comes on for light-duty vehicles (Class 1-3) with an OBD-II or JBus connection. True idle time is collected for preventing fuel loss and waste from excessive idling.

• Track, Trace, Idle & Diagnostics Service offers tracking plus diagnostics and fuel reporting. If there’s an engine issue, the V3™ will receive an alert via the vehicle’s computer. These fault codes are transmitted instantly, so troubleshooting begins while the vehicle is on the road, saving your customers time and keeping their vehicles on the road.

What will the V3™ do for your customers?

• Integrate tracking, diagnostics and other add-ons, including our inspection module and auxiliary inputs.

• Monitor geo-fencing tracking perimeters.

• Capture every turn of the key, every stop and start, as well as speed, idle time and odometer. • Protect assets by alerting

management when a potentially dangerous situation occurs. • Record data in five dimensions:

latitude, longitude, time,

odometer and fuel consumption.

gps Base paCkagesand daTa ColleCTedand RepoRTed

Track & Trace Service Track, Trace & Idle Service _{Diagnostics Service}Track, Trace, Idle &

Speed, odometer, idle time and location tracking   

Usage report   

Check engine or Stop engine light on notification  

Vehicle and engine diagnostic codes 

Fuel reporting 

Idle fuel consumption 

(5)

How Z Pass™ works:

1. Students entering or exiting the bus swipe their ID cards while passing the Z Pass™ reader.

2. Student and driver hear an audible

beep, confirming that the card was

read.

3. The recorded time and location data are automatically and securely sent to

Zonar’s web-based Ground Traffic

Control™ application for reporting.

Z p

ass

™

s

TUdenT

r

idershiP

T

rackinG

Peace of Mind for Student Safety

Smarter student transportation Z Pass™ improves the safety and efficiency of pupil transportation, enabling school officials to quickly track where and when students enter and exit their buses, and then analyze that information to make data-driven decisions about transportation needs. It provides a new level of peace of mind for both staff and parents.

Powerful data for operations All ridership data collected from student card swipes is immediately accessible via Zonar’s web-based Ground Traffic Control™ application and organized with data from all other Zonar devices. This data can then be accessed, perhaps to see where a lost student got off the bus, or analyzed, perhaps to increase bus optimization throughout the year.

Designed with schools in mind Day to day, Z Pass™ will provide accurate and immediate answers for parents wondering if and when their student got on or off the bus. Long-term, it will automate the process for generating reports for Medicaid reimbursements, McKinney-Vento Act, and other cost recovery efforts, stretching budgets with minimal administrative burden.

Loading process stays the same Customers say it works because Z Pass™ doesn’t slow the loading or unloading process. No other action is required other than tapping the card to the reader as the student gets on or off the bus. This simple act will provide your customers with a wealth of information that will benefit employees at every level and streamline student transportation.

What will Z Pass™ do for your customers?

• Provide data to make informed decisions based on facts. • Record the time, date and

location of each entrance and exit.

• Answer parents’ and school

officials’ questions instantly and

accurately.

• Export information in CSV for data analysis and XML for mapping.

• Provide authorities a list of students on a bus in case of an emergency situation.

• Automate student and mileage

tracking for efficient billing of field trips, off-site vocational

training and other billable activities.

(6)

What will ZTA™ do for your customers?

• Answer parent and guardian

questions about bus location quickly and easily.

• Save time waiting at bus stops for students.

• Display bus locations.

• Reduce calls to schools about bus locations.

• Map the recent path of buses.

• Support for multiple platforms, including popular mobile devices.

ZTa

™

B

Us

l

ocaTion

a

PP for

P

arenTs and

G

Uardians

An Answer to “Where’s My Child’s Bus?”

Empowers parents, saves time ZTA™ will help school district parents, guardians and students get the most out of transportation services by providing customized bus location reporting. In the morning, guardians can watch the bus approach on the ZTA™ app and send students to the bus stop at an appropriate time, with minimal waiting in inclement weather. In the afternoons, parents and guardians who pick children up from the bus stop will save time by seeing when the bus is approaching in order to meet their child promptly. Saves schools time and money By giving parents real-time bus location, schools can significantly reduce calls from parents asking, “Where’s my child’s bus?” This will save administrative staff hours of work over the school year.

Easy and secure

Parents and guardians can log-in easily using their own social media credentials. They can then name each route for easy reference and save information for multiple routes in a single account. For security, schools can restrict permissions to parents through the use of custom school or district names, access codes, and individual routes.

Available from anywhere, any time ZTA™ provides parents information from iOS and Android devices, as well as the web browser of any Internet-connected computer. The map displays the child’s home location, the location of the bus, and several minutes of recent route history. With ZTA™, school districts, parents, and students will all benefit from up-to-date information.

(7)

Z p

ass

+

™

B

Us

r

ide

r

ePorTinG for

P

arenTs

Answers Directly to Parents

A whole new level of comfort Using the information gathered from the Z Pass™, the Z Pass+™ program sends notifications of where and when children get on and off the school bus directly to parents’ cellphones. This new, simple solution gives parents the peace of mind that comes with knowing their children arrived safely at the bus stop.

Reduces calls to schools

Parents will no longer have to call the school to know if, when, and where their student got on or off the bus. They now have access to the same information the school uses to answer questions about bus riders. With this capability, they can act right away if they discover their child is not where he or she is supposed to be.

Provides real-time answers

After creating a Z Pass+™_account

online, parents can log into a password-protected website to view their child’s bus riding activity. For added convenience, parents can always change their instant alerts and add new phone numbers. Numbers can be added for grandparents, baby sitters and anyone else who might be concerned with a student’s safe arrival home.

Simple and secure

All it takes is one easy setup on the secure Z Pass+™ website to notify parents of card scans via text message. Since students already use Z Pass™ cards when they board or exit the bus, so no additional action is required from students or bus drivers.

What will Z Pass+™ do for your customers?

• Alert parents and guardians via text message to ridership activity.

• Reduce calls to schools

regarding transportation, saving administrative staff time.

• Save valuable resources, with no demands on existing IT infrastructure or personnel. • Provide address and time of

card swipe as well as a map of location.

• Track ridership of multiple children and provide alerts to multiple numbers from a single account.

• Speed the search for missing children.

Dallas Rackow, Director of Transportation Freeport School District

“Student ridership tracking with Z Pass+

provides parents with a level of security and confidence

we didn’t know was possible. Calls to the transportation

department are no longer necessary.”

(8)

Quantifying Driver Activities

Count, sum, and map activities With I/Os, dispatch can see where and when a driver used a seat belt, turned on lights and more. Within our I/O reports, your customers will see how many times a school bus open its door. They can sum how many miles a continuous I/O was used. They can even track these activities within a certain geo-fence of interest. These multi-purpose connections will help your customers manage their fleets by exception.

How it works

The I/O module collects data from inputs, detecting from off-on-off with an active range of 8-30 volts. Speed, heading, idle, stop and start are monitored by the V3™, so gathering those metrics will not take up an I/O connection.

Amazing alerting

Zonar software offers your customers the ability to configure alerts based on I/O connections. For example, fleet managers can receive an alert if the a safety arm is out while the vehicle is traveling more than 30 mph. Or they could get an alert if a driver is not wearing a seat belt two minutes after the engine is turned on.

Many options to meet needs Some uses school districts have found for I/Os include seat belt on/ off, door open/closed, wheelchair lift, stop arm, alarm, engine pre-heater, checkmate power, and parking brake. I/Os have even been used around geo-fenced railroad crossings to ensure the driver follows proper procedure in these instances.

What will I/Os do for your customers?

• Map each instance of an I/O, pinpointing activities such as door opening and closing. • Track the path of a continuous

I/O.

• Alert about the use or the lack of use of an auxiliary device, such as a seat belt.

• Count instances of activities.

• Sum miles of continuous activities.

• Filter activities by geo-fence.

The I/O module shows the path an asset traveled while auxiliary inputs were engaged. The associated report also counts the number of instances and sums the miles traveled.

i

npuT

/o

uTpuT

(i/o)

e

VenT

T

rackinG

(9)

The Fastest Help to Drivers in Need

Just in case

Drivers on the road can quickly find themselves in dangerous situations. For the highest level of safety and protection, Zonar offers a Panic Button to facilitate a quick response in case of an emergency situation. If a driver is in danger or needs help immediately, he or she can push this button to send an alert to managers or dispatch. This signal prompts the GPS to up its data reporting rate to once every 10 seconds.

Send help quickly

In order to find help, dispatch users can enter into the Location Report to find the vehicle. There they can right-click on the asset and select “Closest 5 Assets.” This will give dispatchers a list of the closest vehicles, to send the fastest help possible.

Alerts for emergencies

The Panic Button can be linked to alerts for emergency situations. These alerts can be sent to one person, a group of people, or everyone in the organization. Hopefully drivers will never need the emergency button, but if they ever do, your customers will be glad to have it. Drivers will appreciate the benefit, adding to driver retention and staff morale. Small investment, big payoff The Panic Button comes with a one-time hardware cost and is installed at the same time as the V3™ GPS device. There is no monthly fee. For this small one-time investment, your customers can rest assured that their drivers have a quick response in case of the worst case scenario.

What will the Panic Button do for your customers?

• Protect buses by alerting management immediately of when a potentially dangerous situation arises.

• Alert management via email or text message of an emergency

situation occurring in the field. • Increase GPS reporting to once

every 10 seconds to provide pinpoint tracking of a vehicle or driver in danger.

• Communicate a help signal to dispatch in a discreet manner, when radio contact may not be possible.

• Provide peace of mind for

drivers in the field.

p

aniC

B

uTTon

(10)

What will Ground Traffic

Control™ do for your customers?

• Map every turn of the key, every stop and start, and all activity. • Supervise each driver’s speed,

path, safety and idling.

• Customize reports, alerts and dashboards for each user’s preferences.

• Alert management to speeding drivers, excessive idling and prohibited geo-fence crossings. • Ensure maximum safety,

transparency, and accountability. • Automate tasks that used to be

a burden on drivers, dispatch and administrative staff.

• Integrate with third-party systems, using our open API for maximum ROI.

g

Round

T

RaffiC

C

onTRol

™

W

eB

-B

ased

f

leeT

m

anaGemenT

Like Air Traffic Control for a Ground-Based Fleet

Fleet at your customers’ fingertips

Ground Traffic Control™ will provide organizations with the most accessible real-time picture of fleet operations. With an unlimited number of users and 24/7 access from computers, tablets, and smartphone web browsers, Ground Traffic Control™ is the most robust package on the market. The service now includes dashboards. All this power for tracking, reporting, and easy exporting of fleet data is included with your customers’ Zonar service.

Monitors the field from anywhere

Our web-based software allows fleet management to see vehicle speeds, idle times and geo-fence entry at any time, from anywhere. Now it’s easy to coordinate a workforce out in the field, by having actionable data organized in one accessible location.

Alerts protect assets

If a driver is speeding dangerously, idling excessively, or entering a prohibited area, your customers will know right away. Ground Traffic Control™ alerts the right people with a text message, email or pop-up window within the application whenever a user-created threshold is violated.

Geo-fencing for smart mapping With unlimited freeform geo-fencing capabilities, Ground Traffic Control™ will make sure assets are where they should be, and will alert your customers if they’re out of place. This prevents both theft and waste. Entire fleet or a single asset

Ground Traffic Control™ comes pre-built with macro-to-micro reporting capabilities to calculate overall fleet mileage or details of each asset’s path, including each stop and start.

(11)

Zonar Systems

p

RoduCTs

f

eaTuResBy

C

onsumeR

V3™ ZPass I/Os Thomas

Built Buses Thomas Built Buses Dealers Thomas Built Buses End Users Cables JBus-capable (varies by vehicle model, including 6- and 9-pin) Cable included

with kit Connects from input to V3

GPS tracking Yes Yes Yes Yes

Odometer From ECM Yes Yes Yes

Speed From ECM Yes

Location Yes Yes Yes Yes

JBus alerts (hard braking,

roll stability, ABS) Yes Yes Yes Yes Idle Time True Idle Yes

Idle Fuel From ECM Yes

Usage report Yes Yes Yes Yes

Fuel reporting From ECM Yes Yes Yes

Check and stop engine

light on notification Yes Yes Yes Yes Vehicle and engine

diagnostic codes Yes Yes Yes Yes Driver identification Yes Yes Yes

Student and rider

tracking Via student RFID cards Yes

Door open, light usage

and other event tracking Yes Up to five event inputs Yes Yes

Appropriate for white

fleet Yes

(12)

12 ZONAR • zonarsystems.com • 877.843.3847 12 ZONAR • zonarsystems.com • 877.843.3847

R

epoRTing

C

apaBiliTies

From pre-made reports to dozens of options, from the whole

fleet to one vehicle, from the last year to this morning, these

reports will answer all your customers’ questions about how

they can run more efficient fleets.

(13)

The V3™ will track vehicles, but it’s the reports below that will provide the metrics to make real-time decisions.

The Location Report

• Use to: See the current location of assets in relation to landmarks, geo-fences and roads. • Benefits: Easy visual check of asset locations.

• Options and features: Auto-refresh every 30 seconds. Show paths up to two hours for up to five vehicles. • Customizable by: One asset, subgroup or all assets; user-specified time range; geo-fence.

• Data collected: Asset number, time of GPS collection, speed, power on or off, geo-fence, address.

Z

onaR

’

s

gps R

epoRTing

(14)

The Path Report

• Use to: See a “bread-crumb” trail of asset paths or track up to five vehicles’ activity in real time. • Benefits: Visual check of where assets have been and real-time tracking of vehicle paths.

• Options and features: Click the symbol to view the point of maximum speed on the map. • Customizable by: Events shown, such as each turn of the key and each stop and start in traffic. • Data collected: Asset number, date range, distance, maximum speed, idle and stop of each path.

(15)

Activity Report

• Use to: Sum up all vehicle activity in one easy-to-export report.

• Benefits: Prevents unauthorized use of company vehicles during off hours, averting waste of costly fuel. • Options and features: Coordinates with an alert to notify management in real time about off-hours activity. • Customizable by: Asset number, date range, attribute filters.

• Data collected: Date, asset number, time range, distance traveled, maximum speed, maximum idle.

Schedule Report

• Use to: Make sure vehicles are coming and going to the right places on time. • Benefits: Uses easy-to-recognize geo-fence labels to show where vehicles are.

• Options and features: Can show all assets in selected geo-fences or all geo-fences with selected vehicles. • Customizable by: Attribute filters, date range, asset, geo-fence.

• Data collected: Date, time entering or exiting geo-fence, and total time, duration and distance within geo-fence.

(16)

Idle Time Report

• Use to: Show where and when vehicles are idling excessively.

• Benefits: Provides quantifiable savings in fuel cost as well as greenhouse gases saved by lowering idling. • Options and features: Associated ZAlert™ notifies management in real time of wasteful idling.

• Customizable by: Asset, attributes, idles within or outside of zone, date range, and acceptable maximum idle time. • Data collected: Asset, dates, idle count, maximum idle time, idle time zone, total idle, total cost and emissions.

Z

onar

’

s

GPs r

ePorTinG

c

onTinUed

(17)

Speed Report

• Use to: Prevent drivers from putting others in danger and the company at risk by speeding.

• Benefits: Resolves speeding complaints and provides evidence in accident cases using a year of historical data. • Options and features: Associated ZAlert™ notifies management in real time of speeding out in the field. • Customizable by: Asset number, date range, zone filter, attribute filters, maximum acceptable speed.

• Data collected: Asset number, maximum speed and time of occurrence, number of speeding events, and zone.

The Speed Graph illustrates whether speeding is a one-time occurrence or chronic

violation. Hovering over a point shows the information and clicking it shows the point on the map.

(18)

Audit Report

• Use to: Provide a magnifying-glass report on one asset’s activity.

• Benefits: Gives quick answers during detailed incident investigations, and totals miles and trip times. • Options and features: Paints the most vivid picture of one asset’s activity.

• Customizable by: Asset number, date range, idle times to be included.

• Data collected: Date, time, in or out geo-fences, miles traveled, idle and stop times, average and max mph and trip time.

(19)

The powerful diagnostic capabilities of the V3™ are the next best thing to looking under the hood yourself.

The Diagnostics Report

• Use to: Display vehicle’s Engine Control Module (ECM) fault code information. • Benefits: Serves as an early warning and remote monitoring system.

• Options and features: Associated alerts warn dispatch at the same time the driver sees the Check Engine light. • Customizable by: Asset, check engine and stop engine, date range.

• Data collected: Asset, date and time, check or stop engine alert, fault codes and description.

The Diagnostics Report includes links to fault code events to map exactly where the warning occurred.

d

iagnosTiCs

R

epoRTing

V3™ hd-GPs r

ePorTs

(20)

Trip Report

• Use to: Deliver the trip details and cumulative data from the Engine Control Module (ECM) of assets.

• Benefits: Totals the cost of each trip, so your customers can make smart decisions about where they send their vehicles. • Options and features: Sums data for the trip and for the total amount recorded off the ECM.

• Customizable by: All assets or one asset, date and time range.

• Data collected: Fuel use, idle fuel use, miles driven, miles per gallon and engine hours for the trip.

(21)

JBus Fuel Path Report

• Use to: Provide the asset’s fuel consumption for the selected date range. • Benefits: Geo-coded ECM fuel information is sent in real time.

• Options and features: Maps path and fuel use.

• Customizable by: All assets or one asset, zone in which fuel was used, date and time range. • Data collected: Fuel use, idle fuel use, miles driven, miles per gallon and engine hours for the trip.

(22)

GPS Engine Hours Report

• Use to: Calculate elapsed and total engine hours by asset and set the hours value from the Hobb’s meter. • Benefits: Geo-coded ECM fuel information is sent in real time.

• Options and features: Summarize engine hours by zone. • Customizable by: All or one asset, date range, zone, attribute.

• Data collected: Asset, first power on and last power off time, power off zone, ending hour meter, elapsed hours.

(23)

Information collected from I/Os can be counted, mapped and summed in Ground Traffic Control™.

The Input Module Report

• Use to: View all input activity.

• Benefits: Counts the number of incidences and sums the miles of continuous activity, such as snow plowing. • Options and features: Report activity within a geo-fence. Links to path report to map activity.

• Customizable by: One asset, subgroup or all assets; user-specified time range; zone; and one of five inputs. • Data collected: Asset number, total number of incidences, duration of input use, distance of input use.

i/o R

epoRTing

(24)

Our Z Pass™ Student Tracking reports will provide information about where students got on and off the bus.

Z Pass™ Report by Student

• Use to: Review each student’s activity and number of card swipes.

• Benefits: Provides a searchable record of all student busing activity, organized in one location. • Options and features: Click on an event to bring up a map of its location.

• Customizable by: Show all students or only students with card events.

• Data collected: Card RFID number, student name, student ID number, event count, date and time, zone and address.

Clicking on an event brings up a map showing where the student swiped his or her card.

s

TudenT

T

RaCking

R

epoRTs

Z P

ass

™ s

TUdenT

T

rackinG

r

ePorTs

(25)

Z Pass™ Report by Asset

• Use to: See number of riders per bus and analyze bus utilization. • Benefits: Provides a list of riders in case of emergency.

• Options and features: Shows addresses and geo-fences of all pickups, as well as a map with a click on an event. • Customizable by: Show all assets or only assets with events.

• Data collected: Asset ID, fleet, asset tag, VIN, event count, student names, odometer, date, time, zone and address.

Our associated Z Pass+™ service, billed directly to parents and free to schools, will deliver card-swipe information directly to parents’ and guardians’ smartphones.

(26)

The Most Important Information, Now

Knows what your customers need to

Zonar’s real-time ZAlerts provide customizable and configurable alerts to make sure the right people get the most important information as quickly as possible. This feature offers the benefit of peace of mind. Your customers will know if any driver is putting others in danger by speeding, or wasting fuel and money by idling excessively. Your customers won’t just know later; they can put a stop to it right away.

Prevent waste and halt dangerous practice

ZAlerts were designed to make sure drivers are operating within the boundaries of safety, efficiency and compliance. With these alerts, management can be guaranteed that their assets are being operated with minimal risk and cost. Alerts are communicated via pop-up window within the Ground Traffic Control™ application, email and/or SMS text message.

Your customers choose the level of alert

For each fully customizable alert, your customers will be able to choose a low, medium or high priority level. Users will be able to choose which alerts go to which managers and in which form: email, text message or pop-up alert. Immediate results

With ZAlerts, your customers will see improvement in operational efficiencies and safety across the entire organization from the first day they use the system.

ZAlerts warn management about: Activity

Engine turned on during non-working hours, which may signal theft or non-authorized use.

Battery

Low battery, based on configurable voltage.

GPS Speed

Speeding in a geo-fence, such as a school zone or work site.

GPS Zone

Vehicles entering prohibited areas or leaving a work site, another possible sign of theft.

Idle

Idling for longer than user-set parameters, which wastes fuel.

I/O

Auxiliary device engaged longer than recommended or at higher speeds than recommended.

JBus

Stop or check engine, ABS, RSC and hard braking, which may be signs of an accident or emergency situation. Panic

Activation of panic button by driver. (With additional purchase of panic button.)

Hard braking alert as a pop-up window within

Ground Traffic Control™.

Za

leRTs

(27)

What will ZAlerts do for your customers?

• Save fuel by preventing idling. Sitting in the vehicle while the engine is on may seem harmless, but it wastes tens of thousands of dollars per year. Set an acceptable time frame and be alerted when drivers idle for longer to save on fuel loss and stop greenhouse gas emissions.

• Prevent unauthorized use. The Activity Alert works like the GPS Zone alert, restricting vehicles to their appropriate time of use instead of place. Both prevent theft and unauthorized use. • Keep vehicles where they

should be. ZAlerts will let your customers know if a vehicle enters a prohibited area or exits its work zone. Either incident can be a sign of theft or unauthorized use, which puts organizations at risk of fuel loss at least, and a total vehicle loss at worst. This alert uses the names your customers give to their geo-fences, making it user-friendly.

• Prevent dangerous speeding. Until now, it was impossible to know if drivers were speeding until they got a ticket or an accident occurred. Now your customers can prevent costly and dangerous situations, minimizing risk, by setting alerts

to be notified when a vehicle is

traveling above the speed they deem safe.

(28)

The Power to Protect the Fleet

Geo-fences let our system know where your customers’ vehicles should and should not be, what their drivers should and should not be doing, and what kind of activities they want to know about. Geo-fences make it easy to locate assets by using the names your customers give them, instead of addresses.

Simple to draw

A geo-fence is a virtual area your customers draw on the map to define a place of interest. They can outline as many geo-fences as they need and change them at any time within our system. We provide three options to address a variety of situations:

• Polygons: Fit areas of any shape, defining perimeters. • Lines: Define a point of crossing or speeding.

• Circles: Outline an area within a certain distance. Know who is where

Within each geo-fence, our system knows when an asset exits or enters and how many miles it has been driven within that area. With geo-fencing, managers keep track of drivers without having to watch the map, resolving many personnel issues without confrontation.

Summarize data by geo-fence

Geo-fencing will help make sure drivers arrive on time, provide data for billing if needed, and help your customers know how much time has been spent at each location. Reports and maps can be filtered by geo-fence, so your customers can analyze the activity happening in each area. Keep drivers on the path

Geo-fencing is great for keeping assets out of prohibited areas. Your customers can opt to receive an alert via text message or email if a driver enters a location off-limits. If they find that drivers are going to an inappropriate location while on the clock, fleet management can draw a geo-fence around the area and run a report to find out who has been there and how much time was spent at that location up to the last year.

Provides location-based intelligence

Geo-fencing provides managers the kind of control we could have never imagined a decade ago. This amazing capability offers assurance that vehicles are in safe hands, that money is not being wasted on time card padding, and that fuel is not being used for personal errands. This will be a great value to Thomas Built customers.

g

eo

-f

enCing

C

apaBiliTies

P

oWerfUl

V

irTUal

P

erimeTers

(29)

What will Geo-fences do for your customers?

• Prevent unauthorized vehicle use.Geo-fences can create an alert to let your customers know if drivers exit an area that their vehicles are supposed to stay in, • Track vehicles on fleet terms.

Geo-fences turn coordinates and addresses into labels that are easy to recognize. Using the same terms your customers

use in the yard, Ground Traffic

Control™ provides a vehicle’s activities as they enter geo-fences, including duration and miles driven.

• Alerts as vehicles approach. Circular geo-fences around a location give warning when an asset is about to reach its destination. Your customers will get advance notice that vehicles are arriving, so staff can be ready and eliminate delays. Save even more time by importing multiple stops and automatically applying a circular geo-fence to each one. • Address complaints using

data. If a citizen says a drivers was speeding, your customers can now simply draw a linear geo-fence across the road

in question, set the speed parameters, and query whether

any of their drivers were speeding while passing that strip of road, any time over the

last year. The conflict is resolved

using data.

(30)

Map Views for Every Need

Zonar offers several mapping views that change with one click, and all are customizable with layers such as geo-fences, traffic, weather and labels, so your customers can see exactly what’s happening with their fleets.

Layers Add Value to Any View

Traffic, weather, geo-fences, user maps and labels can be shown or hidden on any map view.

Customizable Icons

Zonar maps default to color-coded arrows that point in the direction in which the asset is headed. We also provide a variety of industry-specific icons, so your customers can see at a glance which types of assets are where.

Road View shows assets on an atlas-like map. Easy to read and quick to load, this view shows simple representations of water, parks and buildings.

Bird’s Eye View and other satellite views display buildings, roads and landmarks in amazing detail, providing the most vivid picture of assets’ locations.

Traffic affects your customers’ fleets’ schedule and ability to get work done. Now your customers can keep a close eye on it with this map layer and route their vehicles around problem areas to save time.

Weather can be overlaid on all maps within Ground Traffic Control. Knowing what precipitation may be affecting the work day of your customers’ fleets will help their drivers avoid delays.

Default Icons
