Evaluation of CFD to predict smoke
movement in complex enclosed spaces
Application to three real scenarios: an underground station,
an offshore accommodation module and
a building under construction
Prepared by
Health and Safety Laboratory
HSE
Health & SafetyExecutive
Evaluation of CFD to predict smoke
movement in complex enclosed spaces
Application to three real scenarios: an underground station,
an offshore accommodation module and
a building under construction
Dr N. Gobeau and Dr X.X. Zhou
Fire and Explosion Group
Health and Safety Laboratory
Harpur Hill
Buxton
SK17 9JN
RI, TD and OD HSE divisions have jointly commissioned HSL to investigate the capabilities and limitations of Computational Fluid Dynamics (CFD) to predict the transport of smoke in complex enclosed spaces. Despite a lack of validation for this application, CFD is increasingly used in safety cases as a predictive tool to demonstrate the effectiveness of modern building designs and/or emergency ventilation to control the movement of smoke in the event of a fire. To meet the objective, HSL has undertaken a research project combining CFD modelling and experiments. The work consisted of three distinct phases:
Phase 1 comprised CFD calculations relating to three real “complex spaces”. These were an underground station, an accommodation module on an offshore platform and a high rise building under construction. Different CFD modelling approaches were used to investigate their effect on the prediction of smoke movement. The particular modelling approaches tested were representative of those being employed in fire safety engineering. Phase 2 produced a “benchmark” dataset of experimental measurements of the movement of hot smoke in simple small scale structures. A range of basic geometries were constructed, instrumented and tested, each addressing a particular aspect of the physical behaviour of smoke layers. While the experiments were deliberately simplified to concentrate on the fundamental of smoke movement, the geometries were similar to those found in the three real cases - corridors/tunnels, both horizontal and sloping, larger open spaces and tall atria.
Phase 3 was a detailed examination of CFD performance in modelling the phase 2 benchmark experiments. The specific aspects of the modelling process were varied, such as the computational grid, and the discretisation scheme. The results of each calculation were compared with measurements, allowing the level of agreement to be quantified. The results of the different modelling approaches were also compared to quantify their relative effects.
The present report contains the description and conclusions of the work related to Phase 1, the modelling of three real scenarios by different approaches.
This report and the work it describes were funded by the Health and Safety Executive (HSE). Its contents, including any opinions and/or conclusions expressed, are those of the authors alone and do not necessarily
© Crown copyright 2004 First published 2004 ISBN 0 7176 2881 7
All rights reserved. No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any form or by any means (electronic, mechanical, photocopying, recording or otherwise) without the prior written permission of the copyright owner.
Applications for reproduction should be made in writing to: Licensing Division, Her Majesty's Stationery Office, St Clements House, 2-16 Colegate, Norwich NR3 1BQ or by e-mail to hmsolicensing@cabinet-office.x.gsi.gov.uk
Summary
Objectives
RI, TD and OD HSE divisions have jointly commissioned HSL to investigate the capabilities and limitations of Computational Fluid Dynamics (CFD) to predict the transport of smoke in complex enclosed spaces. Despite a lack of validation for this application, CFD is increasingly used in safety cases as a predictive tool to demonstrate the effectiveness of modern building designs and/or emergency ventilation to control the movement of smoke in the event of a fire. To meet the objective, HSL has undertaken a research project combining CFD modelling and experiments. The work consisted of three distinct phases:
Phase 1 comprised CFD calculations relating to three real “complex spaces”. These were an underground station, an accommodation module on an offshore platform and a high rise building under construction. Different CFD modelling approaches were used to investigate their effect on the prediction of smoke movement. The particular modelling approaches tested were representative of those being employed in fire safety engineering.
Phase 2 produced a “benchmark” dataset of experimental measurements of the movement of hot smoke in simple small scale structures. A range of basic geometries were constructed, instrumented and tested, each addressing a particular aspect of the physical behaviour of smoke layers. While the experiments were deliberately simplified to concentrate on the fundamental of smoke movement, the geometries were similar to those found in the three real cases - corridors/tunnels, both horizontal and sloping, larger open spaces and tall atria.
Phase 3 was a detailed examination of CFD performance in modelling the phase 2 benchmark experiments. The specific aspects of the modelling process were varied, such as the
computational grid, and the discretisation scheme. The results of each calculation were
compared with measurements, allowing the level of agreement to be quantified. The results of the different modelling approaches were also compared to quantify their relative effects. The present report contains the description and conclusions of the work related to Phase 1, the modelling of three real scenarios by different approaches.
Main Findings
All the CFD modelling approaches employed provided results that looked realistic. In each case they could in principle be used as a basis of an engineered approach to fire safety. In particular, the effects of complex geometry and forced ventilation on smoke movement are readily addressed using CFD.
However, a comparison of quantitative data; such as the temperature of the hot layer, the depth of the smoke layer along the ceilings, and the rate of propagation of smoke, showed that these key parameters can vary significantly - depending on the modelling approach used. The
particular conclusions we can draw from the modelling approaches applied in these three real scenarios are:
Surprisingly, differing grid resolution did not lead to significant differences in smoke movement. This was because both grids employed here, including the coarser one, were appropriate for the scenario modelled. In general, however, the grid resolution needs to be fine enough to adequately capture the key flow phenomena.
The use of a high order convection discretisation scheme resulted in the prediction of more flow detail and a more rapid rate of smoke spread. Ideally, second- or
higher-order accurate schemes should be used. First-order scheme may be acceptable providing the grid is not too coarse and that the resulting error is shown to be
conservative.
A Boussinesq approximation to account for thermal effects on flow compressibility under-predicted the temperatures and the rate of smoke propagation when compared to a more valid approach of calculating the air density from an equation of state. A
Boussinesq approximation should therefore not be used unless there is clear evidence that the error is conservative.
A standard k-e turbulence model failed to predict the correct behaviour of the flow. An additional buoyancy-related production term was found necessary to reproduce
successfully the features of the flow. It is highly recommended that it is implemented in any model of transport of smoke.
A volumetric heat source model and an eddy-break-up combustion model both provided acceptable and ultimately similar results for smoke propagation.
However, the realistic prescription of the fire source was found to be crucial for both a volumetric heat source model and an eddy-break-up combustion model. Since a volumetric heat source model requires more assumptions input to the source (heat and volume output) than an eddy-break-up model, the latter is likely to provide more realistic results for situations where the fire shape is a-priori not well defined and/or may vary with time.
The boundary conditions for heat transfer at the walls were found to have an impact on the transport of smoke, but this was highly dependent on the scenario - they were more crucial for a confined fire and in the absence of forced ventilation.
Main Recommendations
A significant, although limited, number of CFD simulations have been undertaken for three real scenarios. These obviously do not cover all the situations that Fire Safety Engineers are likely to encounter. Hence the present findings and conclusions must be interpreted with caution, especially for scenarios in which the flow characteristics could be very different near the fire source.
All of the existing CFD modelling approaches could not be reviewed in this work. It was decided to concentrate on those most commonly employed and therefore the most likely to be presented in safety cases submitted to HSE. Amongst the models not included in this study are those for simulation of radiation and advanced turbulence models.
Nevertheless, the simulations have examined some of the main modelling approaches being employed in fire safety engineering. They therefore do allow general conclusions to be drawn. In particular, the scenario-dependent sensitivity of the results to the detailed modelling
approach employed means that it is vital that the user of CFD for smoke movement applications is knowledgeable and well trained both in CFD and fire science.
Since, however, the sensitivities to the modelling approaches are not always evident a-priori, it is also strongly recommended that a set of CFD simulations be undertaken, rather than a one-off case; which could be misleading. This set of CFD simulations should focus on the potential key sensitivities.
CFD is under constant development. Any new models made available to the Fire Safety community should be carefully assessed before trust in their predictions can be gained.
Contents
1. INTRODUCTION . . . 1
2. SCENARIOS . . . 4
2.1. Description of premises . . . 4
2.1.1. Underground station . . . 4
2.1.2. Offshore accommodation module . . . 4
2.1.3. Building under construction . . . 5
2.1.4. Summary . . . 5
2.2. Possible fires . . . 5
2.2.1. In the underground station . . . 5
2.2.2. In the offshore accommodation module . . . 5
2.2.3. In the building under construction . . . 6
3. ILLUSTRATION OF CFD CAPABILITY: INITIAL MODELLING . . . 7
3.1. CFD code . . . 7
3.2. Computational domain and grid . . . 8
3.2.1. Underground station . . . 8
3.2.2. Offshore accommodation module . . . 8
3.2.3. Building under construction . . . 8
3.3. Physical sub-models . . . 9
3.4. Fire source . . . 10
3.4.1. In the underground station . . . 10
3.4.2. In the offshore accommodation module and the building under construction . . . 10
3.5. Boundary conditions . . . 11
3.6. Initial conditions . . . 11
3.7. Numerical methods . . . 12
3.8. Convergence criteria . . . 12
3.9. Results and discussion . . . 13
3.9.1. Underground station . . . 13
3.9.2. Offshore accommodation module . . . 15
3.9.3. Building under construction . . . 15
4. COMPARISON OF DIFFERENT MODELLING APPROACHES . . . 18
4.1. Underground station . . . 19
4.1.1. Flow compressibility . . . 19
4.1.2. Buoyancy effects in the k-e turbulence model . . . 20
4.1.3. Heat transfer at the walls . . . 22
4.2. Offshore accommodation module . . . 23
4.2.1. Grid size . . . 23
4.2.2. Discretisation scheme . . . 25
4.2.3. Heat transfer at the walls . . . 25
4.3. Building under construction . . . 27
4.3.1. Shape of the prescribed heat source . . . 28
4.3.2. Fire growth curve . . . 29
4.3.3. Fire modelling approaches . . . 30
5. CONCLUSIONS AND RECOMMENDATIONS . . . 33
5.1. Conclusions . . . 33
5.2. Recommendations . . . 35
6. REFERENCES . . . 37
7. ACKNOWLEDGEMENTS . . . 40
APPENDIX A - Summary of scenarios and initial CFD models
APPENDIX B - Figures related to the initial simulation of the underground station
Figure B.1 - Layout of the underground station Figure B.2 - Computational domain and grid
Figure B.3 - Background ventilation inside the underground station
Figure B.4 - Airflow field and iso-surfaces of smoke concentration 3 minutes after ignition (forced ventilation off)
Figure B.5 - Airflow field and iso-surfaces of smoke concentration 5 minutes after ignition, just before forced ventilation is switched on.
Figure B.6 - Airflow field and iso-surfaces of smoke concentration 46 seconds after forced ventilation started.
Figure B.7- Airflow field and iso-surfaces of smoke concentration 65 seconds after forced ventilation started.
APPENDIX C - Figures related to the initial simulation of the offshore accom-modation module
Figure C.1 - Layout of the offshore accommodation module : ground and first floors.
Figure C.2 -Layout of the offshore accommodation module : first and second floors.
Figure C.3 - Computational domain and grid. Figure C.4 - Fire source in the laundry.
Figure C.5 - Iso-surfaces of smoke concentration 60 seconds after ignition. Figure C.6 - Iso-surfaces of smoke concentration 90 seconds after ignition. Figure C.7 - Iso-surfaces of smoke concentration 120 seconds after ignition. Figure C.8 - Iso-surfaces of smoke concentration 150 seconds after ignition. Figure C.9 - Iso-surfaces of smoke concentration 180 seconds after ignition. Figure C.10 - Iso-surfaces of smoke concentration 210 seconds after ignition. Figure C.11 - Iso-surfaces of smoke concentration 450 seconds after ignition.
APPENDIX D - Figures related to the initial simulation of the building under construction
Figure D.1 - Schematic diagram of the building under construction, side elevation.
Figure D.2 - Computational domain and grid.
Figure D.3 - Fire source and computational grid on third floor. Figure D.4 - Smoke iso-surface 30 seconds after ignition. Figure D.5 - Smoke iso-surface 80 seconds after ignition.
Figure D.6 - Airflow field and smoke iso-surface 120 seconds after ignition. Figure D.7 - Airflow field and smoke iso-surface 150 seconds after ignition. Figure D.8 - Airflow field and smoke iso-surface 250 seconds after ignition.
APPENDIX E - Comparison between different CFD modelling approaches for the underground station
Figure E.1 -Temperature distribution near the fire 115 seconds after ignition.
Figure E.2 - Smoke concentration at the walls 60 seconds after ignition
Figure E.3 - Smoke concentration at the walls 90 seconds after ignition
Figure E.4 -Smoke concentration at the walls 115 seconds after ignition
Figure E.5 - Time-dependent smoke fluxes across vertical planes at entrance, mid-length and exit of the bridge.
Figure E.6 - Time-dependent smoke fluxes across vertical planes at the entrance of the corridor leading to exit 2 and at exit 2.
APPENDIX F - Comparison between different CFD modelling approaches for the offshore accommodation module
Figure F.1 - Comparison of the two different grids employed.
Figure F.2 - Temperature distribution and velocities in the laundry, 120 seconds after ignition.
Figure F.3 - Profiles of excess temperature and vertical velocity in the fire source, 120 seconds after ignition.
Figure F.4 - Profiles of excess temperature, smoke mass fraction and lateral velocities near the fire, 120 seconds after ignition.
Figure F.5 Temperature distribution and velocity vectors on the first floor -location of the fire - 45 centimetres above the ground, 120 seconds after ignition.
Figure F.6 Temperature distribution and velocity vectors on the first floor -location of the fire - 2 metres above the ground, 120 seconds after ignition.
Figure F.7 - Profiles of excess temperature, smoke mass fraction and velocity in the doorway of the laundry opening to a corridor, 120 seconds after ignition.
Figure F.8 - Profiles of excess temperature, smoke mass fraction and velocity in the doorway of the laundry near a stairwell, 120 seconds after ignition.
APPENDIX G - Comparison between different CFD modelling approaches for the building under construction
Figure G.1 - Excess temperature and mesh near the fire 150 seconds after ignition
Figure G.2 - Vertical profiles of excess temperature and smoke concentration in the centreline of the fire 150 seconds after ignition
Figure G.3 - Vertical profiles of excess temperature and smoke concentration ten metres away from the fire, 150 seconds after ignition
Figure G.4 - Horizontal profiles of excess temperature and smoke concentration 4.55 metres above the fire, 0.45 metres from the ceiling 150 seconds after ignition.
Figure G.5 - Excess temperature distribution on the third floor - location of the fire,150 seconds after ignition.
Figure G.6 - Smoke concentration distribution on the third floor -location of the fire,150 seconds after ignition.
Figure G.7 - Smoke concentration distribution in the atrium, 150 seconds after ignition.
APPENDIX H - Details of the buoyancy modification of the k-e turbulence model in CFX5.
1. INTRODUCTION
Computational Fluid Dynamics (CFD) is a powerful technique which provides an approxi mate solution to the coupled governing fluid flow equations for mass, momentum and energy transport. The flexibility of the technique makes it possible to solve these equations for fluid flow in very complex spaces.
Originally widely used by the aerospace and other manufacturing industries, CFD is now being increasingly employed in fire safety engineering to predict the movement of smoke from possible fires in complex enclosed spaces, such as atria, shopping malls, warehouses, etc... For instance, London Underground Ltd. applied CFD to examine the effectiveness of smoke control systems in tunnels and stations on the Jubilee Line Extension, particularly in relation to novel design features such as platform edge doors and smoke canopies. Eurotunnel commissioned CFD work during the construction of the Channel Tunnel and the incident investigation following the 1996 fire. CFD has also been employed to predict smoke movement in the Millenium Dome (Sinai et al., 2000).
In each of the above examples, reliance could not be placed on simpler modelling techniques to predict smoke movement. This is primarily because these simpler methods assume that the space of interest is geometrically simple, i.e. a box-shaped room. Also, they often require empirical input. When the space is geometrically complex and experimental data is absent, CFD approaches are becoming more commonly used. The growth in the use of CFD for the prediction of smoke movement is also a result of the shift from prescriptive codes to predic tive methods - as allowed in fire safety engineered solutions to the problems of fire.
As the use of CFD in fire safety engineering is growing, it is likely that HSE will be increas ingly faced with assessing fire safety cases which are either entirely or partly based on CFD simulations. Although CFD is a powerful technique, it does however have its limitations. It is very important to be aware of these when assessing the conclusions drawn from CFD predic tions.
Unfortunately, CFD modelling has not been carefully evaluated against reliable data for complex smoke movement applications. RI, OSD and TD divisions of HSE are therefore funding a project to address this issue. The main aim of the project is to quantify the advan tages and limitations of CFD for predicting smoke movement in complex enclosed spaces. The work comprises:
1. Initial application of CFD to real scenarios of interest to HSE funding divisions to illustrate the capabilities of CFD modelling;
2. Sensitivity of the CFD results to a range of modelling approaches widely employed by the Fire Engineering Community;
3. Experimental measurements at small-scale, focusing on areas identified by the initial CFD simulations as potentially challenging for CFD;
4. CFD modelling of the small-scale experiments and quantification of the accuracy of the CFD solution by comparing against experimental data; the influence of CFD sub-models and parameters on the accuracy of the solution will be investigated;
This report presents the CFD modelling of real scenarios in tasks 1 and 2 above. The bench mark experiments and their CFD modelling in tasks 3 and 4 are described in the report HSL CM/01/18 (Ledin et al., 2004). The findings of the whole project are the basis of a guidance note aimed at HSE Inspectors to help them assess CFD results used to support safety cases (Gobeau et al., 2003). The project is summarised in the report HSL CM/03/15 (Gobeau et al., 2004).
A total of three real scenarios were simulated: an underground station, an offshore accommo dation module and a building under construction. They were selected for their complex geometry and for their relevance to each HSE division funding the project. Possible fires, and their induced smoke movement, were modelled. It should be stressed that the specific cases were chosen as being representative of the type of application for which CFD could be
employed. They were not selected because of any outstanding concern over fire safety in these premises, merely as illustrative examples. They are described in Section 2.
Section 3 presents an initial CFD modelling of these scenarios. Qualitatively, smoke propaga tion was predicted quite realistically in all three scenarios. The direction and rate of smoke propagation, together with effects of any ventilation systems, are predicted clearly highlight ing the potential of CFD. However, in the absence of measurements, the accuracy of these results cannot be readily assessed. This is due to potential errors from a number of sources; the adequacy of the modelled governing equations, simplifications in the modelled geometry, grid and discretisation errors, assumed boundary conditions, etc... It is therefore important to highlight that these initial simulations informed the design of the small-scale experiments; ultimately providing a quantitative assessment of CFD for the modelling of the smoke movement.
Whilst it is not readily possible to draw absolute conclusions on the accuracy with which smoke movement is predicted for these real scenarios, it is however possible to illustrate the sensitivity of the results to a range of modelling approaches. When setting up a model, CFD practitioners have to make numerous numerical and physical assumptions. These will depend on a number of factors, such as the scenario modelled, the resources available - in computer, time and fundings, as well as on the user expertise. For example, the physical processes of the fire itself can be described by a variety of different sub-models of varying complexity. The simplest approach is a prescribed heat source model; in which the fire is represented by imposing a heat release rate in a pre-determined volume. Although this is a simple approach, it is very widely used (Hadjisophocleous et al., 1999; Sinclair, 2001; Tonkelaar, 2001). In more advanced approaches a combustion model is used - which means that the volume in which heat is released - the flaming region, is predicted, rather than prescribed. The modelling of combustion is a whole branch of science in itself. When a combustion model is used in Fire Safety engineering, often a crude approach is taken - as exemplified by ‘Eddy Break-Up’ models (Sinai, 2001; Yau et al., 2001; Drake and Meeks, 2001). Whilst this approach can often lead to a more realistic representation of a fire than a prescribed heat source, it should be noted that it is still a gross approximation. Indeed, there are on-going discussions amongst CFD Fire Safety practitioners on the actual benefits of this approach compared to the simpler heat source representation (Xue et al., 2001; Kumar and Cox, 2001).
Section 4 therefore compares different CFD modelling approaches, representative of those commonly employed by the Fire Safety Engineering community and covering those likely to
be encountered in fire safety cases submitted to HSE and other regulations. It is important to stress that the CFD modelling in this report is very representative of approaches actually employed. It is not claimed to be ‘state-of-the-art’ from an academic perspective. Indeed, that is not its aim. Readers who would like to gain a comprehensive knowledge of the modelling approaches available to predict smoke movement are invited to refer to Cox (1995) or Grant and Lea (2001).
The sensitivities which have been explored are as follows: Different computational grids;
First and second order convection discretisation schemes; Heat transfer boundary conditions at the walls;
Representation of the fire source: prescribed heat source and simple eddy break-up combustion model; different prescribed fire growth curves.
This has made it possible to quantify the effects of these differing approaches on the predic tion of temperature distribution, air flow field and smoke propagation between the different models as applied to real complex scenarios. This is important: it illustrates where key sensi tivities may lie in the practical application of CFD to the modelling of smoke movement information which is significant for both the CFD practitioner and regulator.
It must be noted that for practical reasons it has not been possible to employ each modelling approach for each scenario. However, lessons can be learnt and extrapolated from one case to another. Therefore the reader is strongly encouraged to look at all the scenarios, even though if interested in only one application, for instance railway or construction safety.
Finally, conclusions are drawn on CFD’s capabilities and limitations for the prediction of smoke movement in complex enclosed spaces in Section 5.
2. SCENARIOS
To illustrate CFD modelling of smoke movement in complex enclosed spaces of interest to HSE, each sponsoring division provided a representative real scenario. Hence, an under ground station was investigated for RI; an offshore accommodation module for OSD and a building under construction for TD. For each of these spaces, a possible fire - its power and location - was defined.
2.1. Description of premises 2.1.1. Underground station
An underground station on the Jubilee Line Extension was chosen as representative of a complex space for which RI may have to assess a fire safety case. The station was visited by HSL staff, accompanied by a representative of London Underground Ltd.
The station is on four levels, which are from top to bottom: street level with three exits; a ticket hall; platforms for the East London line; platforms for the Jubilee line. The ticket hall is a large space, the floor dimensions of which are roughly 30 m x 30 m. Its height is 3.75m except where it is roofed by a glass dome housing the main exit. Escalators and stairs lead from the paid area to the Southbound platform of the East London line on one side and to the Southbound East London line on the other side. From the ticket hall, three exits lead outside: one passes directly to surface level via a short flight of stairs; the other two are accessed via a bridge overlooking the stairs and escalators of the Southbound platform of the East London line. This bridge is enclosed by glass windows. A layout of the station is presented in Figure B.1 (in Appendix B).
The station is equipped with smoke detectors and for the purpose of fire safety is divided into a number of zones. The emergency response upon detection of fire depends upon the zone in which it is located, but is typically forced ventilation from lower levels exhausting to atmos phere via the three exits.
2.1.2. Offshore accommodation module
OSD have a regulatory duty to assess offshore safety cases. These can include the conse quences of fire in living quarters. An accommodation module on an existing platform was thus considered suitable for the present study. Diagrams of the layout of the module were supplied and are presented in Figures C.1 and C.2 (in Appendix C) showing the module has four main floors. From ground floor to the second floor are the utility and public areas: operat ing rooms, laundries, kitchen, dining room, recreational rooms, etc...The third floor houses bedrooms. Two staircases at the opposite ends of the module link all the floors. These stair cases do not have a central ‘well’.
2.1.3. Building under construction
FOD, advised by TD, is responsible for regulating safety on construction sites. This includes fire safety during the construction and fitting-out stage of a building. Although the building will eventually be equipped with a detection system, and mitigation via sprinklers and possi bly ventilation, these systems are unlikely to be fully operational until construction is finished. During the building and fitting-out phase, there are also fire hazards present which will not be seen during normal occupation, i.e. electrical power tools, waste packing material, etc... An eighteen-storey office building under construction in London was chosen as representative of a typical large development and visited by HSL staff. A 76m high atrium links all the floors. With the exception of the first floor, two open bridges cross the atrium at each storey. In addition, there are two staircases which give access to all floors and offer a possible additional route for smoke transport. The main part of each floor is an open-plan area. Figure D.1 presents a schematic diagram of the building.
2.1.4. Summary
Altogether, the three scenarios provide the opportunity to test CFD in a wide range of real complex enclosed spaces. The geometrical features of these spaces include: large floor areas with restricted elevation, i.e. the ticket hall in the underground station and open-plan offices in the building under construction; large vertical spaces, i.e. building atrium; a complex network of interconnecting rooms and corridors, i.e. offshore accommodation module; levels intercon nected by staircases, escalators or atria.
2.2. Possible fires
Fires were chosen in each case to be as realistic as possible, rather than those leading to worst case conditions.
2.2.1. In the underground station
In the underground station, none of the fittings or equipment is highly flammable. It was therefore assumed that the main fire source in the public areas could be the suitcase of a passenger, containing clothes of different fabrics. The fire was assumed to occur in the ticket hall, in front of the shops on the unpaid side of the ticket barrier. This location was suggested by fire services. This location also allows the consequences of fire in a shop to be inferred, although it should be noted that no shops were fitted out when the station was visited. Further details of the fire source are given in Section 3.4.
2.2.2. In the offshore accommodation module
It is reported that 20% of fires in offshore accommodation modules occur in kitchens or laundries (Connolly, 2000). In this work, a mix of 50% cotton-50% polyester linen was
assumed to burn in the laundry on the first floor. The main interest is in the transport of smoke out of the laundry into corridors and upper levels via the stairwells.
Further details of the fire source are given in Section 3.4. 2.2.3. In the building under construction
Most fires on construction sites happen close to the end of completion, when part of the furni ture has already been brought in (Buckland, 2000). An armchair, made of PU foam 23 was therefore assumed to catch fire on the first floor. The main interest here is the transport of smoke to remote upper storeys of the building, via the stairwell and atrium.
3. ILLUSTRATION OF CFD CAPABILITY: INITIAL MODELLING
This section explains the initial selection of physical and numerical models, and boundary conditions, used to set up the CFD models, a summary of which can be found in Table 1 in Appendix A.
3.1. CFD code
A commercial CFD code, rather than an in-house or academic code, is most likely to be used by a fire safety consultant or industry sector to carry out a fire safety assessment. This is because it is more cost-effective than developing and maintaining an in-house code and academic codes tend not to offer the full range of geometric flexibility required.
The codes known as CFX (formerly FLOW3D), developed and marketed by AEA
Technology, were used in all cases. This was for several reasons. AEA technology is possibly the market leader for fire safety applications, having been contracted by HSL to model the Kings Cross Fire as part of the subsequent investigation (Fennel, 1988) and having had well publicised success and technical development opportunities as a consequence. The codes embody most, if not all, of the physical and numerical sub-models included in other commer cial codes. In addition, AEA Technology is the main code supplier for HSL: we have thus established a strong relationship over several years with AEA Technology and we have gained a significant experience of using their codes for our CFD calculations.
Two codes were used: CFX4 and CFX5. Their main difference is the structure of the mesh, i.e. how the geometry is subdivided into smaller volumes called grid cells. In CFX4, a mesh must be structured: being based on distorted ‘brick-like’ cells grouped in ‘blocks’. With CFX5 an unstructured approach is used, based on tetrahedra. The latter allows the modelling of very complex geometries much more easily and more efficiently.
CFX5 is still under major development. As a consequence, the current version of CFX5 -CFX5.4 - includes fewer physical and numerical models than CFX4, for instance until very recently no combustion model has been available in CFX5. However this does not preclude its use for fire safety applications. Indeed, CFX5 was used to investigate the consequences of a fire in the Millenium Dome (Hiorns and Sinai, 1999). AEA Technology’s long-term objective is to stop developing CFX4. Therefore in the future, state-of-the art models will be imple mented in CFX5 solely.
The use of these two codes ensures that many of the different meshing, physical sub-models and numerical techniques embodied in the CFD codes presently available on the market can be represented in this study.
3.2. Computational domain and grid
The geometry of the problem, i.e. computational domain, needs to be defined for the CFD code and then subdivided into grid cells. One transport equation for each flow variable is solved at each cell. Hence, even though modern workstations are powerful, CFD calculations still require large computer resources. The computational domain is therefore often a compro mise between the complete interior space and a more limited region in which smoke
movement is of concern. Where necessary, boundary conditions must be applied to take into account the effect of the flow external to the reduced geometry.
The computational domains for the three real scenarios, and their grids, are described below. 3.2.1. Underground station
The underground station is on four levels. In this study, however, only two levels were consid ered: the ticket hall where the fire occurs and the dome at the upper level. This was for
reasons of computational economy. The two platform levels below the ticket hall were excluded from the computational domain. Half of the escalators and stairs leading to the platforms were represented though, in order to be able to reproduce reasonably well the natural or forced-ventilation flow that enters the ticket hall from the platforms below. The model was created in CFX5.4 and thus an unstructured mesh approach was used. The mesh was refined at strategic locations, such as in the vicinity of the fire, where key features may need to be captured. However, to allow small geometrical features to be resolved by the mesh, refinement was also necessary in other areas. As a result, the grid consisted of 93,052 nodes. Figure B.2 in Appendix B illustrates the computational domain and grid for the under ground station.
3.2.2. Offshore accommodation module
The fire was assumed to occur in the first floor laundry, making it most unlikely that the smoke would be transported to the ground floor. Therefore only floors one to three were represented in the CFD model. Rooms, whose doors were likely to be closed, were also
ignored in the computational domain. However, doors leading from the laundry to the corridor on the first floor and those opening onto the stairwells were assumed to be open.
In contrast with the underground station, CFX4.3, based on a structured mesh, was used for this scenario. This was possible because of the reduced complexity of the interior space. The grid density was refined in the fire region. Elsewhere the grid density was near-uniform. A grid of 28,214 cells distributed in 54 blocks was created.
3.2.3. Building under construction
In this scenario the main interest is the transport of smoke from a lower level to a remote upper level via either the atrium or stairwells. The fire was assumed to break out on the third floor. The next three floors are represented in the computational domain, as well as the upper most floor on the 18th storey and of course the atrium and stairwells. Doors giving access to open-plan offices on one side of the atrium from floors seven to seventeen and on the ground
and first floors were assumed to be closed. Hence these areas were not represented in the CFD model.
Figure D.1 in Appendix D shows the whole geometry of the building and the highlighted areas are the parts included in the computational domain. Figures D.2 and D.3, show the computa tional domain and its subdivision into grid cells. The geometry was simplified somewhat and so the two staircases are assumed to be vertical empty spaces; the stairs are not represented. Again this is a less complex geometry than the underground station and so the structured mesh approach of CFX4.3 was used. The grid was also refined at the fire location. A total of
155,734 cells and 109 blocks were employed.
3.3. Physical sub-models
Transport of smoke was, in all cases, initially simulated by modelling the fire as a prescribed source of heat and smoke, with an additional passive scalar transport equation solved for movement of the smoke. Compared to using a combustion model - which could be expected to better reproduce the characteristics of the fire source, the use of a prescribed heat source is known to lead to poorer results near the fire but may nevertheless produce reasonable results in the far-field (Ivings, 1999). The use of a prescribed volumetric heat source was the
preferred approach here, since smoke movement is being predicted in large spaces and the far-field behaviour is of most interest. In addition, this is the approach most commonly used by fire consultants. Furthermore, it involves solving fewer transport equations than acquired by a combustion model, thus easing computational run-times.
The sensitivity of the results to the modelled fire source for smoke movement in the building under construction are explored in Section 4.3. Initially, the model used to represent the changes in air density was a ‘weakly’ compressible (i.e. Low Mach number) approach, in which air density is assumed independent of pressure fluctuations and air kinetic energy is negligible compared to its internal energy. An equation of state is used to couple temperature, pressure and determine density. However, internal numerical problems in CFX5 alone (see Section 4.1) required the use of a simpler model based on the Boussinesq approximation; the density here being assumed constant except in the gravity term in the momentum equation. This approximation is strictly only valid for temperature variations over a range of a few tens of centigrade. This is in fact likely to be the case in most parts of the computational domain away from the fire. That said, this approach could result in errors in calculated air velocities induced by the fire, which could be propagated elsewhere. However, the adoption of the Boussinesq approximation is again one which is sometimes used by others in this field. This is often as a means of increasing the rate of convergence of a problem and therefore reducing the run-time. The effect of this approximation is explored in Section 4.1.1.
A standard k-e turbulence model, modified to account for buoyancy effects, was employed. The k-e model is certainly the most widely used turbulence model for fire safety applications, although it does have its limitations. Its main advantages are that it is computationally
unexpensive and is relatively stable numerically. Its main limitations in the context of smoke movement is that it assumes an isotropic eddy viscosity, which does not account for the
non-isotropic effects of buoyancy on turbulent mixing. The buoyancy modification, referred to above, aims, for example, to account for the reduced mixing due to stable stratification, i.e. as exhibited by a hot smoke layer, but it does not by any means represent all of the important effects of buoyancy on turbulent mixing. This issue, and its consequences, is discussed in more details in Section 4.1.2.
The overall approach used here is a compromise of a relatively simple set of physical
sub-models, which will allow solutions to be obtained in practical timescales. The approach is in fact widely used by fire safety consultants and industry for predicting smoke movement in complex enclosed spaces.
3.4. Fire source
3.4.1. In the underground station
In the underground station, a fire with a peak heat output of 0.2 MW was estimated from previous HSL work involving tests on a suitcase containing a range of clothes; the peak heat output was determined from the mass loss rate measured by Thyer (1999). The plan area of the fire was set the same as the dimensions of the container (1 m x 1m) in which the suitcase was tested. The height of the flaming region was fixed at 2.5 m, from observations during this experiment. The heat output was increased linearly over one minute in a volume of grid cells corresponding to the above dimensions, i.e. 1 m x 1 m x 2.5 m. After one minute, a constant heat release rate of 0.2 MW was imposed. The production of smoke was deduced from values of smoke yield assuming the products burning consisted of 50% cotton - 50% polyester (The SFPE Handbook of Fire Protection Engineering, 1995). Note however, that the volume over which heat was reduced in the subsequent simulations, since predicted temperatures with the above source prescription were found to be unrealistically low. Section 4.1 provides more details.
3.4.2. In the offshore accommodation module and the building under construction
For both the offshore accommodation module and building under construction, a fire of 1 MW was considered to be a realistic fire size, following discussion with fire safety specialists (Atkinson, 2000). Radiation can be modelled but was not included here since, other than very simple approaches can lead to greatly increased run-times. A fixed percentage of the fire power, based on the combustible materials, was hence assumed to be lost by radiation. This is a common practice, although it is strictly only valid for materials producing small quantities of smoke. Therefore, the fire sources in the models were set at 0.7 MW in the offshore accom modation module and at 0.55 MW in the building under construction; these quantities repre senting the convective heat output - primarily responsible for the transport of smoke (Table 3-4.11 of the SFPE Handbook of Fire Protection Engineering, 1995).
For the offshore accommodation module, linen made of 50% cotton and 50% polyester were assumed to burn. For the building under construction the combustible was assumed to be an armchair made of PU foam 23. A realistic plan area for each fire was decided. The height was deduced from the fire power and plan area using an empirical relation (Hekestad, 1983). The fixed volume in which heat was distributed was assumed to be a simple parallelepiped. The
fire was assumed to grow to its steady heat output following a time-squared growth rate (Rho and Ryou, 1999). As previously, smoke production was deduced from empirical data on the burning materials (Table 3-4.11 of the SFPE Handbook of Fire Protection Engineering, 1995).
3.5. Boundary conditions
The offshore accommodation module and the building under construction were considered completely sealed and therefore no inlet nor outlet boundary conditions were defined.
For the underground station, the ventilation strategy in the event of a fire in the unpaid side of ticket hall is to generate a ventilation flow aiming to clear smoke from the ticket hall and exhaust it via the passenger exits. This ventilation is created by large fans in the Jubilee line tunnels. To model this situation, imposed flow boundary conditions were applied on the surfaces of the computational domain which correspond to connections between the ticket hall and East London line level. These surfaces appear in red in Figure B.2 - Appendix B. Normal velocities were imposed, however their values and area distribution were not easy to deter mine: the operational conditions of the ventilation fans are known but as the platform levels are not modelled, the distribution of air velocities is unknown. This velocity distribution will depend on the complex geometrical shape of the unmodelled platform levels and on interven ing obstacles. The values eventually imposed at these boundaries were deduced from
measurements of mass fluxes carried out by LUL. The values were gradually increased from a low velocity of 0.1 m/s representative of normal operating conditions, to a forced ventilation of 0.21 m/s from the Southbound platform and of 0.36 m/s from the Northbound platform. The forced-ventilation was assumed to begin five minutes after ignition - which includes a delay for detection. The full power was assumed to occur after a further minute. At the three exits, fully-developed flow was assumed by imposing pressure boundaries.
At the walls, a no-slip condition was applied. Standard turbulent logarithmic wall functions are used. Adiabatic walls were imposed at the underground station, i.e. no heat flux was allowed, whilst constant ambient temperatures were set for all walls in the offshore accommo dation and building under construction. The effect of these assumed conditions is explored in Section 4.1.3.
3.6. Initial conditions
As the offshore accommodation module and the building under construction are assumed to be well sealed, quiescent conditions at ambient temperature were imposed at the start of the calculations.
For the underground station, a small background ventilation flux of 119 kg/s was imposed and used as the initial conditions for the transient fire simulation. The initial temperature was ambient. This small background ventilation flow is assumed to correspond to air movement induced by train movements. Note that setting an initial low ventilation flow also helps the code to converge.
3.7. Numerical methods
Default first-order numerical schemes are used for the discretisation of convection, apart from the simulation of the offshore accommodation module; where second-order schemes were used for all equations except the pressure equation. Results obtained by first-order schemes will suffer to a greater or lesser degree from the spurious effects of numerical diffusion - a tendency for over-rapid mixing. First-order schemes are, however, often more stable and less costly in computational time than more accurate higher order schemes, hence this approach is commonly encountered in fire safety applications of CFD. It is explored in Section 4.2.2. The Algebraic Multigrid solver in CFX4 was required for solution of the pressure equation for both the offshore accommodation module and the building under construction. This was made necessary by the complexity of the geometry. Unfortunately it ruled out the possibility of running these simulations in parallel over multiple processors, which would have reduced run-times.
The time steps for the simulations of the offshore accommodation module and building under construction were gradually increased to a maximum of 0.5 second - see details in Appendix A. Smaller time steps of 0.2 second were used for the underground station. Larger time steps of 1 second were employed after two minutes, once the fire was fully developed, to simulate the movement of smoke up to the start of the forced ventilation. The time steps were then reduced to 0.2 second to ensure convergence of the computed time-dependent forced velocity field. A sensitivity test of the predictions to the value of the time step was undertaken for the offshore accommodation module and the value of 0.5 second was found acceptable. Although ideally a sensitivity test should have been undertaken for the two other scenarios, the values chosen were expected to be adequate on the following grounds: the heat output of the fire in the building under construction was identical to that in the offshore accommodation module and so a similar time step should successfully reproduce the flow induced by the fire; the fire in the underground station was less powerful but influenced by a small background ventilation flow, hence a smaller time step was fixed to capture the interaction between the flow induced by the fire and the ventilation flow. The time step was later increased for reducing the
computing time, once the flow was fully developed.
3.8. Convergence criteria
For the underground station, simulated with CFX5, the normalised residuals were decreasing and their values at the end of a time-step were below the criteria advised by the code supplier by a factor of ten. It was difficult to establish if the results were fully converged but this was the best convergence that could be achieved.
CFX4, used for the simulations of the building under construction and the offshore accommo dation module, provides non-dimensionalised residuals (actually the sum of the absolute values for all cells). The residuals of the enthalpy equation were normalised by the time dependent heat output. These were found to be typically below 0.002 for the simulations of the building under construction and about 0.1 for the simulations of the offshore accommoda tion module. The residuals for the mass conservation were compared with the total mass in
the computational domains. Once the fire was fully developed the residuals of the mass equation in the building were around 1 kg/s, i.e. 0.5 kg per time step - as the time step was 0.5 s. This was very small compared to the overall mass of air of 110,000 kg. In the offshore accommodation module, the mass residuals corresponded to 4.3 kg for a total mass of air of 2,000 kg. The low values of the ratio of the mass residuals to the total mass of air - respec tively 10-5 and 2.10-3 for the building under construction and the offshore accommodation
module -suggest that mass is being conserved to a good degree of accuracy. Ideally, however, the mass residuals should be compared with a reference flux indicative of the air flow inside the domain - which will be far lower than the total mass of air. Unfortunately, for both scenar ios, such a reference flux is not easy to determine a priori.
The residuals of the smoke transport equation were compared with the smoke source term. The ratios of the residuals to the source terms were of the order of 0.005 for both the building under construction and the offshore accommodation module.
In addition, the values of all solved variables were monitored at a point near the fire. The values were found to reach a steady-state level at each time step.
Ideally, the mass and heat balances should be checked globally and in a region including the fire. However, this is in practice difficult for a complex geometry divided into a large number of blocks.
In order to gain more confidence that the results were converged, a sensitivity test to the number of iterations per time step was performed for the building under construction. No significant difference was found in the results by doubling the number of iterations per time step over the first minute.
Although the above checks indicate that the solutions were adequately converged, there might still be some uncertainty: a) there was only limited information on the residuals and overall balances in the version CFX5.3 of the CFD code employed to carry out the simulations of the underground station; b) it was difficult to determine the values characteristic of the flow to compare the residuals against for the scenarios where the fire occurred in a closed building and was driving the flow - scenarios of the building under construction and offshore accom modation module. These situations are, however, typical of the challenges faced by CFD practitioners. The sensitivity tests to numerical parameters such as the number of iterations per time step have been undertaken to increase the confidence that the convergence achieved was good enough not to affect the overall conclusions of this work.
3.9. Results and discussion 3.9.1. Underground station
The work reported here must certainly be viewed as initial results only, due to a number of shortcomings in the modelling approach - outlined below. Nevertheless, despite these limita tions, the approach taken in these simulations is not untypical of the wider CFD fire commu nity. It is therefore instructive to examine these results, both to highlight the capabilities of
CFD as a tool for modelling smoke movement and to speculate on the possible consequences of these shortcomings.
Figures B.3 to B.7, Appendix B, illustrate the predicted flow and movement of smoke in the station at various times - before ignition, prior and subsequent to forced emergency ventilation being initiated.
In the five minute period before forced ventilation is initiated, Figures B.4 and B.5 show that smoke is transported throughout most parts of the ticket hall and appears to extend to the main exit routes. In particular, the ‘bridge’ to two of the exits is smoke-logged. It is worth noting that other emergency routes do exist on the platforms that enable the passengers and staff to escape without going through the ticket hall.
Following the start-up of forced ventilation, smoke is cleared from large parts of the paid side of the ticket hall, by being convected towards the exits and into the dome. After one minute, Figure B.7 shows that the bridge is still not quite clear of smoke. However, by one and half minutes after start-up of forced ventilation, the bridge is clear of smoke.
The benefits of CFD simulations of smoke movement around such a complex space are well illustrated by this application: for example, the consequences of delays in starting emergency ventilation, and its effectiveness once operational, can readily be assessed. In principle this can even be done at the design stage, allowing alternative strategies to be examined.
These CFD results are in broad agreement with cold smoke tests conducted at the station. It is encouraging that this is the case. Indeed, the CFD results show the behaviour that would intui tively be expected . However the shortcomings referred to above need to be examined. Firstly, the initial fire source described in Section 3.4 was abandoned because predicted temperatures were unrealistically low. A much reduced fire volume, made of a plan area of 0.5m x 0.5m, and a height of 0.6 m, was instead specified. Predicted temperatures were now far higher, with a peak of just 450o
C. Note that unconfined flame temperatures are more typically 600o
C 700o
C. This under-prediction in temperature may in part be a problem due to lack of grid resolution in the fire source region. However the use of a prescribed volumetric heat source to represent a fire is likely to be the prime reason, since to produce a realistic fire source, it involves ad-hoc specification and adjustment of the heat release rate and volume over which heat is liberated. The sensitivity of results to the fire source are addressed in Section 4.
Secondly, the use of the Boussinesq approximation - necessitated due to restrictions within the code, is strictly only valid when temperature differences are small, i.e. of the order of a few tens of Centigrade. That is clearly not the case here. It is difficult to state with certainty the effects of this approximation, but it will affect the calculation of buoyancy-induced flow. The impact of errors is thus most likely to be felt when forced ventilation flows are small, i.e. before start-up of emergency ventilation. Again sensitivity tests are required and these are provided in section 4.
In summary, simulation of this real scenario shows that whilst plausible results can be obtained for certain flow parameters - such as smoke transport, there is still considerable uncertainty in the predicted flows. This uncertainty can however be reduced by sensitivity studies.
3.9.2. Offshore accommodation module
All the figures related to the accommodation module can be found in Appendix C.
A prescribed volumetric heat source is again used to represent the fire. This is illustrated in Figure C.4. The predicted peak temperatures inside the laundry are high, at just over 1000o
C immediately above the fire. In this case, this could conceivably be a broadly realistic tempera ture, since the laundry is relatively small, at 10 m x 10 m, and ventilated through only two doors.
Analysis of the results shows that initially smoke is confined to the laundry. At approximately 60 seconds after ignition, it makes its way into the adjoining corridor (Figure C.6). By 90 seconds, it has spread to the bottom of the nearest staircase (Figure C.7). It rises nearly half way up this staircase some 30 seconds after entering the stairwell, whilst at the same time it just reaches the other staircase, at the opposite end of the first floor corridor (Figure C.8). It reaches the third floor 180 seconds after ignition (Figure C.9) and it then propagates along it (Figure C.10). Although the third floor has become fully smoke-logged, little smoke has travelled onto the middle second floor dining room (Figure C.11).
Whilst fire doors should prevent such rapid transport of smoke around an accommodation module, they can be left, or wedged, open. CFD clearly illustrates the risks which are then posed by rapid smoke movement.
3.9.3. Building under construction
An isometric view of the floor on which the fire is located is shown in Figure D.3, Appendix D.
The movement of smoke is illustrated by a series of figures, D.4 to D.8, which show the flowfield on a plane through the fire and an iso-surface of smoke concentration, at differing times.
Initially the smoke spreads as a ceiling layer within the third floor open plan office. Figure D.4 shows its progress 30 seconds after ignition. Shortly after one minute, smoke has entered the atrium; Figure D.5 shows the position at 80 seconds. By 40 seconds later, smoke has risen a further five storeys, Figure D.6. By 150 seconds after ignition, smoke reaches the upper storeys of the atrium, Figure D.7, however it has only just begun to rise in the open stairwell. At just four minutes after ignition, smoke has found its way from the atrium into the upper most floor, Figure D.8. By this time, it is also rising in the stairwell.
This simulation illustrates the potential rapid progress of smoke around a building in which fire and smoke protection measures are not yet operational. This could obviously be of signifi cant benefit when assessing and controlling risks during construction. Clearly CFD would be a useful tool in this context.
However, although the simulated movement of smoke appears physically plausible, there are uncertainties in its rate of progress. These arise because the maximum predicted temperature in the fire plume is around 300oC. For a 1MW fire, application of the Mc Caffrey’s plume
relationship (McCaffrey, 1979) indicate that a peak temperature of about 900o
C. could be expected. Since the simulated flow is entirely driven by the effects of buoyancy, errors in temperature at the source are likely to be reflected in the rate at which smoke is transported. In this case, since temperatures are under-predicted, rates of transport may also be under
predicted. This could mean that smoke would propagate even faster in practice i.e. the simula tions may well be non- conservative.
Again the use of a prescribed volumetric heat source is likely to be the prime reason for the unrealistically low temperatures. It is probable that the volume in which heat is introduced is too large; this volume is currently set as a parallelepiped, whilst in reality it more closely approximates a cone.
The need for sensitivity tests, here to the representation of the fire source, is well illustrated by this scenario.
It should be noted that the simulation could not be continued after 260 seconds, since the solution diverged. This is believed to be due to the somewhat unrealistic assumption that the building is completely sealed. A simulation using a fully compressible flow model, rather than a weakly compressible model in which the pressure is assumed constant in the solution of the equation of state, should allow the calculations to be continued, with no significant differ ences in the predictions. This is a useful point to make: practical difficulties in applying CFD codes may well result in truncated simulations.
3.9.4. Summary
Three fire scenarios, in an underground station, an offshore accommodation module and a building under construction, each of interest to sponsoring HSE divisions, have been
modelled using a state-of-the-art CFD code. Each has a complex geometry. All three scenar ios provide the opportunity to demonstrate CFD’s capabilities and limitations for the model ling of smoke movement
Initial simulations have here been undertaken to primarily give an indication of CFD’s capabilities. The gross features of the flow certainly appear to be plausibly predicted: a less well ventilated area on the bridge between the ticket hall and the exits in the underground station is identified; smoke transport can be tracked along corridors and staircases in an
accommodation module; the rapid rise of smoke in the atrium of a building under construction is illustrated. These simulations also appear to provide key information on the effectiveness of forced ventilation on smoke clearance, as well as the generally rapid rate of transport of smoke in complex enclosed spaces.
However, whilst these calculations appear plausible, they are nevertheless subject to consider able uncertainty due to shortcomings in the representation of the fire source, use of simplified physical sub-models, assumed boundary conditions and unquantified numerical errors. The approach taken in modelling these scenarios is, however, typical of that employed by others active in this field, and the predictions are similar to those that would be likely to be presented should CFD have been used in support of a safety assessment for these situations.
In the absence of experimental data, it is thus imperative that sensitivity tests be undertaken to attempt to reduce some of the uncertainty in these, and similar, CFD simulations.
Ultimately, however, comparison with experimental data is essential to quantify the capabili ties of CFD. The physics involved in the development of a fire and production of smoke is complex. Key areas of concern, i.e. those of importance for smoke transport and for which CFD’s capabilities are still uncertain are:
Readers are invited to consult the HSL report on benchmark experiments and CFD modelling (Ledin et al., 2002) which aims to elucidate the capability of CFD to reproduce the key physics of the flow; the complexity of which is increased, in part, by the geometrical features of the spaces in which a fire occurs. The benchmark experiments were designed to retain those aspects of the geometry that led to complex physics. They comprised:
influence of a ventilation flow;
transport along corridors and in areas with large floor plan ;
transport in vertical spaces, such as escalator shafts, stairwells or atria; transport between interconnected large open spaces, or large open spaces and
corridors: either large horizontal spaces, as per the ticket hall of an underground station, or large vertical spaces such as building atria.
The next section investigates the effect that different CFD modelling approaches have on the prediction of smoke movement for the three scenarios.
4. COMPARISON OF DIFFERENT MODELLING APPROACHES
When using a CFD package to create a CFD model, the user has to select physical and numerical sub-models, ways of defining the source, mesh sizes, locations of the boundaries, etc... In some cases, the user is forced to make compromises: for instance because of the contradictory requirements of the different sub-models implemented or because of practical limitations on resources available. The latter situation is very likely to be the case for simula tions of smoke transport in large and complex spaces, which are demanding of computer resources. Simple mathematical models, or relatively coarse grids, for example, might have to be employed in order to achieve reasonable run-times. The objective of this part of the work is to report the extent to which the CFD results are influenced by the parameters chosen by the CFD practitioners i.e. the sensitivity of simulations.
A range of CFD modelling approaches, representative of those commonly used by many consultants, have therefore been employed to simulate the three real scenarios. These include different physical models, numerical schemes and fire source representations, as summarised in Table 1. More advanced models, which embody more details of the physics of the flow, do exist. However, they are more demanding in computer resources and therefore are less likely to be applied to smoke movement scenarios in large and complex spaces, certainly as
presented to HSE in safety cases.
Table 1 - The different modelling approaches employed
Scenarios
CFD Underground station Offshore module Building under construction
parameters
Initial grid
Grid dependence
Vs
Grid cells doubled on floor where fire is
located First-order accurate Spatial discreti-sation schemes Numerical parameters (upwind) Vs
Higher order accurate (CCCT) Flow compressibility Boussinesq approximation Vs Compressible
k-e model:
Turbulence Phy sica l mo delling C3=0
modelling Vs
C3=1
Volume heat source model (no combustion)
Fire modelling Vs
Eddy-break-up combustion model Wall heat transfer Bo unda ry co nditio
ns Adiabatic wall
Vs
Wall at ambient temperature
Adiabatic wall
Vs
Wall at ambient temperature
The temperatures, velocities and transported smoke concentrations predicted by the different modelling approaches. This provides an insight into the sensitivity of the results and conse quently indicated where there is uncertainty.
4.1. Underground station
Four simulations have been carried out using CFX5.4.1 for the scenario of the underground station. One modelling parameter has been changed from one simulation to another, as outlined in Table 2 below.
Table 2 - The different simulations for the underground station scenario
Initial Run 2 Run 3 Run 4
Compressibility Boussinesq Compressible Compressible Compressible
approximation model model model
Buoyancy effect
in the k-e model
C3=0 C3=0 C3=1 C3=1
Heat transfer Adiabatic wall Adiabatic wall Adiabatic wall Wall at ambient
wall boundary temperature
conditions
This allowed us to investigate the influence of the following parameters: Boussinesq approximation compared to a compressible flow model
(by comparing simulations ‘Initial’ and ‘Run 2’);
buoyancy modification term in the k-e turbulence model (by comparing simulations ‘Run 2’ and ‘Run 3’)
heat transfer at the walls
(by comparing simulations ‘Run 3’ and ‘Run 4’).
4.1.1. Flow compressibility
The Boussinesq approximation assumes a constant density and takes into account the air movement due to thermal effects by an additional term in the momentum equations. Details of its implementation in CFX5 are given in Appendix H. This approach is valid for small
temperature gradients and is typically recommended in CFX-5 when temperature variations do not exceed 30o
C. Despite this limitation, we are aware that this model is sometimes used to predict the transport of smoke from a fire in large volume spaces. The argument presented to us is that the model assumption will be valid in most parts of the domain with the exception
