Solid Control Catalog_v5

(1)

Pressure Control &

Waste Management

(2)

“

Our Company is committed to continuous

improvement of its global health, safety and

environmental processes while supplying

high-quality, environmentally responsible

(3)

Overview

2

Rig-Equipment Engineering

6

Integrated Package Delivery 6

Solids Control and Products

10

Drilling Waste Management Systems 10

Mud Mixing System 12

Shakers 18

BEM-650 Shale Shaker 18

MD-3 Shale Shaker 22

Meerkat PT Shale Shaker 24

Mongoose Pro Shale Shaker 30 Mongoose PT Linear- And Dual-Motion Shaker 37

Vibratory systeMs analysis testing (Vsat) 45

Mud Cleaners 46

High-Volume Mud Cleaners 46

Centrifuges 50

414 Centrifuge 50

518 Centrifuge 52

CD-250 Centrifuge 54

CD-500 Centrifuge Electric-Drive High-Volume 58

CD-500 Centrifuge Fully Hydraulic High-Volume 60

CD-500 Centrifuge Slim-Line High-Volume 62

Drilling FluiDs TemperaTure ConTrol sysTem 66

FluiDs proCessing sysTem (Fps) 67

Screens 70

Composite OEM and Replacement Screens 70

Duraflo AXIOM Screens 74

Duraflo Composite OEM Screens 76

Duraflo Composite Replacement Screens 78

Hiflo Composite Replacement Screens 82

Drilling Waste Management

84

Cuttings Handling & Transportation 84

CleanCut Cuttings Collection & Transportation System 84 VaCuuM ColleCtion systeM 91

Verti-G Cuttings Dryer 95

Verti-G Low-Profile Cuttings Dryer 98

Cuttings Treatment 99

Bioremediation Technology 99

fox systeM enHanCeMent 100 Hammermill 101

Rotary Kiln 103

Thermal Desorption Technologies 104

tHerMal PHase seParation 106

Waste Injection 107

WI Training Centers 109

Liquid Waste Treatment 110

Dewatering 110

reClaiM Technology 112

Pressure Control, Frac Flowback

and Well Testing

114

CarbontraCker 114

D-gassers 116

3 PHase sePerator 116

CD-1400 Centrifugal D-gasser 117

Compact Vacuum D-gasser 119

Horizontal D-gasser 121

Vertical D-gasser 122

muD/gas separaTors 123

MuD/gas seParator 123

MuD/gas seParator re-CertifiCation serViCe 125 suPer MuD/gas seParator (SMGS) 126

toga System 128

Drilling Chokes 132

autoCHoke 132

low Pressure autoCHoke (lPaC) 134

suPerCHoke 135

esuPerCHoke 136

Pressure & Fluid Management System 137

oPtiM-izer 137

Pressure & fluiD ManageMent systeM (PFMS) 138

Pipeline Services 142

Choke maniFolDs 143

Waste Management

144

Tank Cleaning 144

Automatic Tank Cleaning 144

Production Tank Cleaning 146

Oilfield Water Management 147

aqualibriuM Oilfield Water Management 147 Multi-PHase Clarifier (MPC) 148

Slop Treatment 150

The enViroCenter Process 150

enVirounit 152

Production Waste Management 154

Process Control & Rig Instrumentation

156

SG-smarT Data-Acquisition System 156

(4)

Solutions for you and your well

Drilling Fluid Systems

& Products

■

■ Wellsite and project engineering

Simulation software ■

■ Drilling-fluid systems and additives ■

■ alPine sPeCialty CHeMiCals* feDeral* Wholesale

■

■ HDD Mining & Waterwell ■

■ Technical support

Solids Controls, Pressure

Control & Waste Management

■ ■ Rig-equipment engineering – Solids control – Solids-control systems – Mud mixing – Shakers – Mud cleaners – Centrifuges

– fluiDs ProCessing systeM (fPs) ■ ■ Cuttings handling and transportation ■ ■ Oilfield screens ■ ■ Waste injection ■ ■ Cuttings treatment ■ ■ Pressure control – D-gassers – Disc-type chokes – Shuttle chokes – Choke consoles – Pressure & fluiD

ManageMent systeM (PfMs) ■

■ Rig instrumentation

■

■ Enhanced fluids treatment

■

■ Vessel cleaning

■

■ Produced water treatment

■

(5)

Production Technologies

■

■ Specialty production chemicals

■ ■ Chemical management ■ ■ Drag reduction ■ ■ H₂S treatment ■ ■ Descaling, decontamination and decommissioning ■

■ Commodity and utility chemicals

■

■ Produced water treatment

■

■ Production Waste Management

Completion Fluid Systems

& Products, Reservoir Drill-In

Fluids, Breakers, Filtration &

Specialized Tools

■

■ Engineering/simulation software

■

■ Reservoir drill-in fluids ■

■ Intervention fluids ■

■ Breakers

■

■ Spacers and Displacement Chemicals

■ ■ Specialized Tools ■ ■ Completion Fluids ■ ■ Filtration ■

■ Fluid-loss control systems

■

(6)

We work with operators to: ■

■ Address specific waste

management challenges while keeping pace with drilling ■

■ Meet or exceed local regulations,

as well as corporate responsibility and sustainability objectives ■

■ Improve well site economics and

the viability of operations ■

■ Minimize produced waste volumes

and treatment requirements ■

■ Introduce onsite treatment

capabilities that minimize or remove the need for costly waste transportation ■

■ Increase the reuse of valuable

drilling fluids and natural resources to minimize consumption and waste volumes

■

■ Preserve fluid quality to protect downhole equipment, prevent NPT, improve drilling performance and protect the production potential of the reservoir

Broad capabilities for

diverse challenges

Wherever you operate, M-I SWACO provides access to global capabilities and leading technologies, supported by a network of unmatched resources and specialist expertise.

Through a longstanding program of research and development, M-I SWACO strives to constantly improve the performance of our technologies. This commitment also results in innovations designed to meet the changing requirements of a new generation of wells.

Dealing with the high volumes of solids and fluids produced while drilling is only part of today’s Drilling Waste Management story. M-I SWACO offers a proactive approach that provides new opportunities to reduce the consumption of resources, and increase their reuse. Alongside compliance with environmental regulations, our solutions are also helping customers improve performance; both operationally and economically.

Performance

beyond compliance

Drilling Waste Management

(7)

Protecting people,

safeguarding places

Wherever they are, M-I SWACO people are dedicated to operating safely; protecting their colleagues, customers and the communities in which they work. Whether operating at pristine frontiers or in established, mature fields, they respect these environments at all times. From the lab to the office to the wellsite, each member of the M-I SWACO team is dedicated to meeting client expectations.

Supporting a full range

of operations

M-I SWACO can help customers improve performance and protect valuable assets across the full E&P lifecycle. Drilling Waste Management is one of a wide range of technical disciplines that also include:

■

■ Drilling Fluids and Systems

■

■ Completion Fluids and Systems

■

■ Production Technology and Chemicals

(8)

Integrated Package Delivery

Rig-Equipment Engineering

Reduce risk. Lower costs.

Get meas urable, improved

results on your next project

Those are the exact results that the M-I SWACO Integrated Package Delivery (IPD) capabilities deliver through integrated mud mixing, fluids processing, drilling and Drilling Waste Management (DWM). We can apply this inte gration to our drilling and DWM product lines across the globe, helping you succeed in harsh environments, where extended life requirements of assets and facilities matter most, where QHSE issues demand continual close attention, and where it makes good business sense to reduce spares.

As the world’s largest supplier of drilling and completion fluids and drilling waste management equipment, M-I SWACO can take you from flowline to ultimate reuse or disposal as a logical extension of our vast knowledge of fluid technology and management. Our Aberdeen-based IPD organization manages the design, procurement, manufacture, installation and commissioning of custom-built, integrated equipment packages for M-I SWACO operations worldwide. The team also has offices in Houston, Stavanger, Volgograd and Singapore.

What M-I SWACO IPD can do for you While it is an accepted fact that the use of modern technology can signif icantly reduce E&P costs, oper ators and service companies are still faced with the burden of identifying and then applying the optimum technologies for project needs. The decision to evaluate a project in detail from start to finish, followed by strategic management, can help the operator reduce costs and increase operational efficiency.

Our experienced multidisciplinary team delivers integrated packages of equipment for the management of drilling and completion fluids, oil and synthetic-coated drilled cuttings as well as production and well flowback waste streams.

(9)

Capabilities with strong advantages for you

Much has changed in our industry, and M-I SWACO has actively embraced the integrated-project concept that has emerged in recent years. To provide customized, value-added solutions with a guarantee of tech nical integrity and quality of work, our IPD division performs in-depth examination of your project, merging management skills with appropri ate technologies. Our scope of equipment and process-control services is configured to serve you first and foremost.

Making technology and engineering work for you

We have learned what is important to you. We’ve been involved since the 1980s when modifications to equipment were necessary to meet the stringent regulations for North Sea operation. Because we’ve experienced firsthand the growing sensitivity to QHSE issues associated with rig construction, M-I SWACO has rapidly expanded IPD services to meet ever-increasing demands such as CE/ATEX and NORSOK compliance in the North Sea and international standards and country regulations in the Caspian Sea and eastern Russia.

As the economic stakes of drilling and production rise, more operators are taking a second look at project-specific bulk-handling and drilling waste management packages.

It’s a way of controlling costs in the face of challenging demands such as:

■ ■ Harsh environments ■ ■ Extended-life requirements ■ ■ Spares reduction ■ ■ Environmental regulations ■

■ Health and safety issues

While we design, engineer and manufacture equipment to suit your needs, the team also works to reduce costs through commonality of materials and spares in addition to providing consistent documentation. Clients around the world have discovered that the benefits from IPD services, such as improved safety, regulatory compliance, reduced costs and improved overall efficiency offset all upfront requirements.

■

■ Meet goals faster and more efficiently through informed, up-to-the-minute

engineering decisions ■

■ Achieve higher-quality results from improved project insight

■

■ Maximize the drilling fluids program through detailed engineering equipment

design and process ■

■ Reduce non-productive time through remote control and monitoring

■

■ Mitigate QHSE incidents through preliminary planning, removal of personnel from

hazardous environments and consistent documentation ■

■ Realize gains from strategically located M-I SWACO IPD networks

Features and advantages

(10)

Integrated controls deliver improved safety, efficiency and economics Human-Machine Interface (HMI) systems are becoming increasingly common features in modern drilling installations. They can be designed to operate in standalone mode, or can be integrated into the drilling-rig manufacturers’ other control systems. The outputs from these systems, including alarms, are available to the operator, driller, and loggers and M-I SWACO personnel.

HMI systems allow operators to set performance parameters, or preset timed operations, for equipment that previously had to be manually operated and monitored. Benefits include a significantly improved working environment, keeping workers out of potentially hazardous environments, reducing personnel requirements, and improving equipment performance. We use systems-control hardware and software that enables remote control

and monitoring of all our main equipment packages. Reliable remote monitoring from either shore-based or corporate facilities is a growing reality. Benefits now being witnessed by various global operators include:

■

■ Improved operating safety from

remote control ■

■ Efficient equipment adjustment

and control ■

■ Efficient mixing and blending of

chemicals into mud systems ■

■ Minimal exposure of personnel

to potentially hazardous areas through remote detection of equipment failure or inoperability ■

■ Reduced onsite personnel

requirement as a result of remote diagnostics

Smoother operations begin with project-specific documentation Documentation becomes particularly important toward helping equipment operators get the most from the systems

we design, build and manufacture. To address this issue, another core activity of the IPD team is to produce project- specific documentation that accompanies each of the packages. We provide:

■

■ A Supplier Master Documentation

Schedule (SMDS) that can include up to 600 documents for complex projects

■

■ A data-collection tool that captures information of every tag detail within the scope of supply

■

■ Project-specific user manuals

■

■ Project-assurance manuals

The M-I SWACO Integrated Package Delivery group is dedicated to producing project- specific, fit-for-purpose equipment packages, including drilling waste management and mud-mixing systems, for new and refurbished drilling installations.

Integrated Package Delivery

(11)

Technical Expertise ■

■ Multi-disciplined team approach

■

■ Project management

■

■ Detailed engineering and design

■

■ 3-D solid modeling and Computational

Fluid Dynamics (CFD) ■

■ Development of manufacturers’

equipment and systems ■

■ Fabrication and package integration

■

■ System testing and mechanical

completion ■

■ Integration with rig/platform drilling-control and -monitoring system

■

■ Installation and commissioning

■

■ Training and technical support

■

■ ISO9001 and 14001 approved

Integrated Systems ■

■ Solids control

■

■ Drilling waste management

■

■ Cuttings re-injection ■

■ Cuttings transport and storage

■

■ Cuttings dryers

■

■ Mud mixing and bulk handling

■

■ Programmable Logic Controller

(PLC) control systems ■

■ EnViroCenter* facilities ■ ■ Cuttings treatment ■ ■ Water treatment ■ ■ Thermal treatment ■ ■ H

2S well test cleanup

■

■ Modular DWM design capabilities

PLC Control Systems ■

■ Control system design and

development ■ ■ Application programming – Siemens^ S7 300^ series – Profibus communications ■

■ HMI SCADA systems

– Cimplicity Plant Edition^ ■

■ Control-philosophy development

■

■ Design and manufacture of

control equipment ■

■ HMI screen presentation

System Design Capabilities ■

■ Design and supply of customized

control systems ■

■ Hazardous-area equipment design

■ ■ PLC applications ■ ■ Instrumentation ■ ■ Embedded microcontrollers ■ ■ Remote diagnostics Services ■ ■ Process automation ■ ■ Project management ■ ■ Design consultancy ■ ■ Product development ■ ■ Equipment evaluation ■ ■ Feasibility studies ■ ■ Training simulators

A wide range of integrated services that deliver measurable,

on-time results to your bottom line

Maximum value on location

Take advantage of our global reach. We have operations in the U.S., Europe, the Middle East, Africa and the Asia Pacific region. Each regional base offers our full range of services to meet your local project requirements.

We recognize that our clients are searching for solutions to meet the needs of projects with a multicountry profile. Take the next step in fluids assurance and solids control. Seamless operations from technical integrity and quality are the result of these high-performance engineering packages.

(12)

Drilling Waste Management Systems

Solids Control Systems & Products

Improve drilling efficiency

and environmental compliance

with an integrated

solids-control system

The goal of all modern solids- control systems is to reduce overall well costs through the efficient removal of drilled solids while reducing and minimizing the loss of drill fluids. Additional goals include worker health and safety and environmental compliance.

The key to designing the best systems in the market comes down to working with the rig designers, contractors, operators and ship yards to provide the best in class.

To operate each type of equipment so that the maximum separation efficiency is achieved requires a lot of thought, and many factors must be considered. The quantity and sizing of equipment must be specific so that the efficiency of the solids-control system can be maximized through data such as final volume of mud accumulated while drilling, total volume of solids removed and fluid dilution rates. The greater percentage of drill solids removed and drilling fluid preserved, the higher the operating efficiency.

Redefining solids control through the systems approach

To meet the demands of new advancements within the drilling market, M-I SWACO has looked at the wider drilling process to design a fit-for-purpose solids-control system. Incorporating modern drilling methods, new equipment enhancements and understanding issues such a limited-discharge legislation and drilling-fluid properties, we have designed the best-in-class system for the market. We work with the customer at the project and local operational levels so we can transfer process knowledge and practical operational experience to the system’s design. This helps ensure that the system meets the requirements for today’s drilling practices and allow expansion for tomorrow’s.

As the heart of the fluids process, solids control is the key to cost reduction. Ensuring its effectiveness lies in understanding that different drilling operations will optimize, and must be able to configure, the installed equipment in different ways. This is how the volume of liquid contents in the waste stream is minimized, reducing waste- processing costs. Tight control greatly reduces the need for dilution, and this further minimizes fluid and waste-processing costs. The key to accurate process design is applying comprehensive analysis techniques and competently executing their application.

(13)

Solids Control Systems & Products: Drilling W

aste Management Systems

Accommodating the process-design variables

The first consideration in designing the solids-control system is that there are enough shale shakers to process the drilling fluid, accounting for circulation rates, mud types, water depths, drilling-fluid properties and separation parameters to a given specification. The goal is to remove as much of the drilled cuttings as possible. Given the importance of the shale shaker, it is also very important to understand the effects of separation efficiency on screen life with different motions and G-forces. M-I SWACO helps clients determine the most efficient shakers and screens to achieve optimum economic performance of the solids-control system.

The separation performance of a shale shaker screen is normally represented by the percentage of drill solids removed and the screen life. Grading the screens will vary from manufacturer to manufacturer, but the best way to compare is to look at fluid volume capacity versus solids- removal efficiency.

The mud cleaner is a bank of hydrocyclones mounted over the shaker. In some installations, there are desander and desilter cones mounted in such a way that the unit can be used as a mud cleaner or as a shaker and hydrocyclone unit separately. With today’s finer-screening shakers that have higher overall efficiency rates than the traditional linear-motion shakers, the applications for mud cleaners are limited.

Decanting centrifuges are a very important component of the solids-control system and understanding how to optimize them can be challenging, but when used properly, they are a very valuable asset to complete the system. Centrifuges are capable of removing very fine solids - down to 5µ - that cannot be removed by any other equipment. The centrifuge can greatly improve the separation efficiency of the solids-removal system while drilling with water-base muds to assist in the reduction of liquid-discharge volumes. In weighted muds, the centri fuge is used to reclaim barite while removing colloidal solids that can cause high mud viscosity, poor filter-cake properties and decreased penetration rates.

The centrifuge is the primary separa tion device used in a chemically enhanced dewatering system to reduce liquid discharge volumes.

Delivering solutions

Header boxes designed with controlled flow distribution and purpose-built controls Mud returns

with drill solids Latest shaker andscreening technology

Clean mud Drill solids Waste disposal

(14)

Mud-Mixing System

Solids Control Systems & Products

Regardless of rig size or project complexity, M-I SWACO will use our operational and engineering experience to design a system that meets the customers and market expectations. We will then engineer, fabricate and commission the mud-mixing system required to perform efficiently and safely. Whether it’s a single HiriDe_{* eductor, or a}

fully automated, touch-screen-controlled, multifunction system, it will deliver the best performance available.

If one quality best describes the system, it is “versatility.” Originally conceived for mixing drilling fluids, an M-I SWACO system can be designed for completion fluids as well. Rugged construction, using low-temperature carbon steel and stainless steel, ensures long life in hostile environments. All components feature a minimized footprint and the flexibility to be positioned as rig space dictates.

System components

Each of the components supplied by M-I SWACO can be put in one of three categories: Solids induction, liquid injection and control.

(15)

Solids Control Systems & Products: Mud Mixing

Solids induction

Bulk-bag-additive unit

The big bag unit coupled with the HiriDe eductor ensures optimum feeding performance, product management and safety.

■

■ Adjustable for bulk bag heights 48 to 72 in. (1,219 to 1,829 mm)

■

■ Super sacks up to 4,000 lb (1,814 kg) ■

■ Integrated sack cutter

■

■ Improved materials handling

■

■ Improved mixing rates - bentonite

33,000 lb/hr (14,969 kg/hr) ■

■ Reduces hazardous dust, material

storage requirements, waste generation and product loss ■

■ Feeds directly into the HiriDe eductor which reduces dust and entrains the solid additives

Surge tank

The pressure vessel integrates the storage and feed of bulk materials. An integral load cell and indicator accurately presents the amount of material added by weight.

■

■ Maintains a continuous flow of solids; accurate level and flow control ■

■ Optimal mixing efficiency and

effectiveness ■

■ With HiriDe eductor creates a dust-free environment for improved health and safety conditions

■

■ Standard capacity is 70.6 ft3 (2 m3). Manufactured in other sizes. ■

■ Conforms to ASME Section VIII Div 1

and hazardous-area oper ation ATEX and the European Pressure Equipment Directive PED 97/23/EC

■

■ Automated management

of storage volume ■

■ Fitted with load cells and high- and low-level indicators, pressure gauge, and pressure-relief valve

■

■ Can operate in low temperatures

–4°F (–20°C)

Maximum process temperature

Arrangement drawing: Bulk-bag-additive unit

Arrangement drawing: Surge tank

All dimensions are expressed in inches (millimeters).

62.9 (1,597.7) 60 (1,524) 31.5 (800.1) CG 67 (1,701.8) 119.5 (3,053.3) 66.6 (1,691.6) 66.6 (1,691.6) 29.4 (746.8) 29.5 (749.3) 29.2 (741.7) 29.4 (746.8) 58.9 (1,496.1) 58.8 (1,493.5) 11.7 (297.2) 0.2 (5.1) CG EMPTY LIFT ON LY 0.5 (12.7) CG 13.2 (335.3) CG 76.9 (1,953.3) 72.7 (1,846.6) 172.8 (4,389.1) 153.9 (3,909.1) 114 (2,895.6) 32.3 (820.4) 118.5 (3,009.9) 18.6 (472.4) CG 94.3 (2,395.2) CG 94.3 (2,395.2) CG

(16)

Automatic sack slitter and pallet lifter An operator feeds sacked chemicals into the automatic sack slitter where the chemical is separated from the sack in a dust-controlled environment. The chemicals are then passed through the HiriDe eductor, or dosing screw/ valve to the HiriDe eductor, to facilitate mixing. The sack is discarded into a disposal bag to minimize operator handling and dusting. A pallet lifter is used in conjunction with the sack slitter to ergonom ically enhance the operator’s activities by eliminating the need for bending and picking up heavy sacks.

■

■ Ergonomic design

■

■ Automatic sack compactor

■

■ Self-cleaning, dust-extraction system ■

■ Can process up to 120 sacks/hr

■

■ Rated for hazardous environment

Zone 1 gas ■

■ Minimized lifting with pallet lifter ■

■ Dust-free attachments create a

healthier environment ■

■ Minimized product loss

■

■ Lower maintenance

Arrangement drawing: Automatic sack slitter

Mud-Mixing System

Solids Control Systems & Products

121.2 (3,078.5) 65.4 (1,661.2) CG 76.5 (1,943.1) CG 149.1 (3,787.1) 65.4 (1,661.2) CG 76.5 (1,943.1) CG 154 (3,911.6) 65.4 (1,661.2) 62.1 (1,577.3) 73.5 (1,866.9) 96 (2,438.4) 28.2 (716.3)

(17)

h

i

r

iDe

Eductor

The HiriDe eductor integrates a proprietary MiniMuM Pressure DroP

(MPD) 175 nozzle and unique triMix Diffuser (TMD) into an easily installed, rugged, stainless steel frame which has been designed to an optimal height for improved ergonomics. The unit is available in three configurations: FE, SE and EA.

■

■ Rapid, complete mixing of dry or liquid additives into the fluid system ■

■ Lowest comparable pressure loss

■

■ Creates high shear rates in a circulating loop

■

■ Compact design with small footprint

■

■ Dust-free, dry-product mixing

■

■ Minimizes “fish eyes” in hard-to-mix products ■

■ Requires less energy

■

■ Flexible design eliminates extra equipment

■

■ Ideal for rigs where space is at a premium

■

■ A greater degree of worker safety

h

i

s

iDe

Blender

(rental equipment)

The HisiDe* blender is an example

of scientific theory and prac tical engineering meeting to create the next evolution of mix-on-the-fly technology. In offshore drilling, precise fluid density and rheological control are much too important to be left to a mix-on-the-fly unit that may not be doing its job. M-I SWACO personnel, using advanced Computational Fluid Dynamics (CFD) modeling, have proven that this is often the case. With the aid of CFD, M-I SWACO has designed and engineered the HisiDe blender as the answer to the question of accuracy and speed in mix-on-the-fly operations. Capitalizing on a unique combination of baffle geometry, exhaustive design and patented1_{, Westfall^ static mixers;}

the HisiDe blender delivers efficient

cut-back of WBM and effective shearing of OBM, ensuring downhole stability, emulsion quality and rapid supply-boat turnaround.

■

■ Accurate, high-volume and thorough

mixing on the fly ■

■ All-steel construction and no moving parts

■

■ Minimal pressure drop across the unit

■

■ In-line baffle premixing and in-line static mixers

■

■ Same unit for OBM and SBM

■

■ Fewer downhole problems

■

■ Faster turnaround for supply vessels ■

■ Easy-to-use, trouble-free operation ■

■ Energy-efficient design

Arrangement drawing: h

i

r

iDe

Eductor

Arrangement drawing: h

i

s

iDe

Blender

All dimensions are expressed in inches (millimeters) 8 (203.2) 29.6 (751.8) 49 (1,244.6) 42.2 (1,071.9) 39.3 (998.2) 37.3 (947.4) 49 (1,244.6) 63.6 (1,615.4) 19.2 (487.7) CONFIG — 02 W/CL CAP 17 (431.8)

(18)

Liquids injection

Caustic soda mix tank

This unit provides an enclosed area for adding sacks of caustic soda to the fluid system.

■

■ Compact footprint similar to HiriDe eductor ■ ■ Ergonomic height ■ ■ Dust-free enclosure ■

■ Wetted parts are stainless steel ■

■ Minimal lifting required ■

■ Reduced product loss and

healthier environment ■

■ Minimized corrosion

Chemical-additive unit

The chemical-additive unit is the new standard for introducing liquid chemicals into the fluids-mixing process.

■

■ Precise control of injection rates ■

■ Quick installation; easy to operate ■

■ Compact footprint: 5 x 8 x 4 ft high (1.5 x 2.4 x 1.2 m high)

■

■ ATEX Zone 1 gas motors and meters

■

■ Wetted parts are stainless steel ■

■ Gear pumps for high-viscosity fluids and greater control over the chemical-injection process. Each revolution of the gears delivers a finite volume of chemical

■

■ Optimal liquid dosing ■

■ Low-maintenance operation

■

■ Pumps a wide variety of chemical

additives

Mud-Mixing System

Solids Control Systems & Products

49 (1,244.6) 18.6 (472.4) CG 27.6 (701) CG 57.5 (1,460.5) 80.7 (2,049.8) 38.5 (977.9) CG 38.5 (977.9) CG 35.8 (909.3) 17.8 (452.1) 10.8 (274.3) 6.9 (175.3) 35.6 (904.2) 18.6 (472.4) CG 26.7 (678.2) 43.4 (1,102.4) 27.6 (701) CG 64.1 (1,628.1) 51.8 (1,315.7) 53.9 (1,369.1) CG 24.6 (624.8) CG 24.6 (624.8) CG 53 (1,346.2) 31.3 (795) CG 41.6 (1,056.6) CG 41.6 (1,056.6) CG 31.3 (795)_CG 90 (2,286) 64.1 (1,628.1)

Arrangement drawing: caustic soda mix tank

Arrangement drawing: chemical-additive unit

(19)

System control

Human-Machine Interface (HMI) systems are becoming increasingly common features in modern drilling installations. They are designed to operate in standalone mode, or can be integrated into other control systems. Outputs from these systems, including alarms, can be available to a multitude of control displays including the driller, operator, logger and M-I SWACO personnel. HMI systems allow operators to set upper and lower performance parameters and preset some timed operations for equipment that once required manual operation and monitoring.

advantages include: ■

■ Improved working environment

■

■ Reduced dust and potential hazards

■

■ Reduced personnel requirements

■

■ Improved equipment performance

The overall control system for

the fluids-mixing package consists of a Programmable Logic Controller (PLC) control cabinet networked via Ethernet to a server panel holding two redundant server PCs, a logger PC and viewer monitors.

In addition to the main acquisition network, a maintenance and diagnostic Profibus MPI network is provided for diagnostic and maintenance tasks.

The Mud-Mixing system runs on Cimplicity Plant Edition^_{which is run on}

the Windows XP^_{operating system as}

the main SCADA package. A Microsoft SQL server is configured as the logging PC to afford reliable historic data logging and retrieval.

User interface and system control is achieved via a trackball/mouse and keyboard. All communications between the application PLCs and the workstations are controlled via the M-I SWACO dual redundant servers.

Workstation displays show various information pages which are selectable via the trackball/mouse. The operator can control and monitor the performance of equipment using the operator-interface unit. To allow the operator to configure and control the package, a layered paged system is available for ease of use.

(20)

BEM-650 Shale Shaker

Solids Control Systems & Products: Shakers

Easy-access inspection ports, with pop-in covers, prevent fluid loss during surges. True, cold installation via feeder to pipe flange.

Better solids and fluids

processing, less screen wear

The BEM-650 Shale shaker is the third- generation balanced-elliptical-motion shale shaker from M-I SWACO. Its performance is centered on our field-proven and patented, balanced-elliptical -motion technology. Independent testing has confirmed that, compared with other shaker types, this gentle rolling motion consistently provides better solids removal and fluid recovery with less screen wear. The BEM-650 Shale shaker has been designed with a number of sig nificant refinements that include:

■

■ Smaller footprint ■

■ Fully stainless steel design

■

■ Dual decks (for scalping

and fine solids separation) ■

■ Automated deck-angle adjustment2

■

■ Detachable feeder

■

■ Pneumatic screen clamping3

As a result, the BEM-650 Shale shaker routinely provides: ■

■ A compact unit built for long life ■

■ Improved solids removal and fluid

recovery at higher feed rates ■

(21)

Solids Control Systems & Products: Shakers: BEM-650 Shale Shaker

■

■ Patented1, balanced elliptical motion produces a drier cuttings discharge and results in improved separation efficiency

■

■ Stainless steel construction reduces

maintenance costs as a result of low corrosion

■

■ State-of-the-art motion generators

are oilfield proven and require minimal maintenance

■

■ Flowback pan between top

and bottom decks maximizes effective screening area ■

■ Integral scalping deck improves

process capacity, reduces installation costs and improves primary deck screen life ■

■ Gumbo slide design minimizes

gumbo buildup ■

■ Dual-angle bottom deck improves separation of water-base-mud cuttings ■

■ Shallow header tank delivers

better fluids distribution to screens with no solids settling ■

■ Sloping sump design with left and/or right discharge minimizes settling of ultra-fines

■

■ Meets certification requirements at

highest level - ATEX, NORSOK, CE and UL-rated versions available ■

■ Low operational noise levels

ensure safety ■

■ Extra-long drip lips ■

■ Easy-to-install optional

vapor-extraction hood reduces operator exposure to vapors associated with drilling fluids

■

■ M-I SWACO design and service

organization provides assistance with rig installation surveys, flow-distribution design to shakers, as well as shaker house and solids- control system design

Flow-distribution box ■

■ Detachable flow-distribution box

with built-in lift points allows for flexible installation

■

■ Allows true, “cold” installation to 10 in. (254 mm) pipe flange ■

■ No welding, torch cutting or grinding is necessary ■

■ Two large slide gates, with reliable tab/slot locators, reduce tendency to clog with gumbo

Controls ■

■ Control panel, with simple start/stop

button is suitable for remote operation, reducing operator exposure to vapors associated with drilling fluids

■

■ Easy-to-use pneumohydraulic

deck-angle adjustment2_{reduces mud}

losses from screens ■

■ Bed-angle indicator aids accurate

adjustment of basket angle Screen technology

■

■ Composite screen technology

increases effective open area, improves process capacity and maximizes screen life

■

■ Special, lightweight screen design

allows for easier screen handling ■

■ Pre-tensioned screens (top and

bottom decks) allow for quicker screen changes

■

■ All screens front load to improve

operator safety

Screen-clamping system ■

■ Operated by single three-way,

three-position SST ball valve ■

■ Pressure regulator permanently

set to proper operating pressure ■

■ Pneumatic quick clamping

of screens for quick screen-changing operations ■

■ Screen clamping and angle

adjustment operated by rig air supply, lowering maintenance and utilities ■

■ All components bolt on

■

■ Clamp blade axles cast into part

with larger shaft size ■

■ Clamp blade receivers have

tighter tolerance and increased materials depth

Two inspection/cleanout ports ■

■ Removable cover allows easy

access for rear-screen inspection and maintenance

■

■ Contains splashing and prevents

fluid loss during surges ■

■ Improves access to rear

clamp blades

Features and advantages

Gumbo slide design minimizes gumbo buildup.

(22)

BEM-650 Shale Shaker

Solids Control Systems & Products: Shakers

BEM-650 Shale Shaker

Specifications

■

■ Length: 96.6 in. (2,454 mm) ■

■ Width: 81 in. (2,057 mm) ■

■ Weir height: 41.2 in. (1,046 mm) ■

■ Height: 66.1 in. (1,679 mm) ■

■ Weight: 3,900 lb (1,769 kg) Screen Deck and Screens

■

■ Gross screen area

Scalping deck: 13.8 ft2_{(1.3 m}2₎

Primary deck: 27.6 ft2_{(2.6 m}2₎

■

■ Net (API) screen area

Scalping deck: 10.8 ft2_{(1 m}2₎

Primary deck: 21.6 ft2_{(2 m}2₎

■

■ Deck angle adjustable: +5°, –3°

■

■ Screen type: Pre-tensioned composite

■

■ Screen clamping: Pneumatic

■

■ Two scalping and four primary screens

Basket Isolation ■

■ Coated carbon steel springs

Motor Specifications ■

■ Two (2) vibrator motors

■

■ 460V/60 Hz/1,800 rpm/2 hp or 400V/50 Hz/1,500 rpm/1.75 hp Other voltages are also available ■

■ Explosion proof

■

■ Class I, Groups C and D

■

■ Class II, Groups E, F and G

■

■ UL, CE, CSA, ATEX, NORSOK

■

■ Motor weight: 200 lb/60 Hz (91 kg,

60 Hz) 216 lb/50 Hz (98 kg, 50 Hz) ■

■ Nominal flow capacity >600 gpm (2,271 L/min), dependent upon fluid properties, solids loading, screen configuration, deck angle and maximum 5.0 G-force

Section A

Multiple fine screening wire mesh choices:

■

■ High-capacity mesh (HC) designed

to produce excellent flow rates ■

■ Long-life mesh (XR*) designed to extend time between screen changes

■

■ Other mesh types available,

including TBC*_{and XL}

Two, large slide gates reduce tendency to clog with gumbo Section B

Two, large slide gates reduce tendency to clog with gumbo Section C

Detachable flow-distribution box allows for flexible installation Section D

Control panel, with simple start/ stop button, is suitable for remote operation

Section E

Rear-screen inspection port, equipped with removable cover, simplifies inspection and maintenance

Section F

State-of-the-art motion generators are oilfield-proven for low maintenance Section G

Bed-angle indicator aids accurate adjustment of basket angle Section H

Screen-clamping system, with single-point, pneumatic control, speeds screen-changing operations Section I

Flowback pan between top and bottom decks

Section J

Lower deck contains four pre-tensioned, flat-panel primary screens with a gross screen area of 27.6 ft2_{(2.6 m}2₎

Section K

Upper deck contains two

pre-tensioned, flat-panel scalping screens with a gross screen area of 13.8 ft2_{(1.3 m}2₎

Section L

Patent-pending, deck-adjustment

system _{Fully stainless steel design. CE, ATEX, NORSOK}

A C D E F G H I J K L B

(23)

BEM-650 Shale Shaker

45.6 (1,158) 41 (1,041) 87.8 (2,230) 31.5 (800) 22.4 (569) 41.2 (1,046) Weir height 15.2 (386) 2 (51) 9.2 (234) 33.3 (846) 22.9 (582) Approx. C of G Deck-angle adjustment indicator Discharge gate, 2 required Lifting lug, 2 (51) diameter hole for lifting equipment Starter assembly Feeder assembly Removable inspection cover, 10 (254) opening Splash guard Motion generator, 2 hp

(voltage per customer contract), explosion-proof, 2 places Grounding lug 66.1 (1,679) 21.5 (546) 32.9 (836) 120 (3,048) Recommended motor removal (both sides)

28 (711) Screen area top deck

81 (2,057)

56.2 (1,427) Screen area bottom deck

73 (1,854) Max. vertical adjustment of slide gates Pneumatic clamping system controls Adjustable slide gates

for flow control

Hydraulic lift controls 76.5 (1,943)(1,428)56.2 96.6 (2,454) 37.5 (953) Approx. C of G 6.8 (173) 5.4 (137) 32 (813) 36.3 (922) Recommended screen removal Lifting lugs (4 places) Recommended motor removal (both sides) Approximate location of electrical connection, .75 (19) FNPT 97.2 (2,469) REF 19.6 (498) Air inlet 8.9 (226) 47.6 (1,209) Approx. C of G Removable inspection covers, 10 (254) opening ISO view, 1:20 85.6 (2,174) View A-A View A-A 1 (25) 4 (102) 67 (1,702) 4X Ø 11 (28) mounting holes 26 (660) 11 (279) 45.3 (1,151) 38.2 (970) 42.4 (1,077) 4.8 (122) 16 (406) OD of cover Air inlet, 0.25 (6) FNPT Hydraulic reservoir 14.2 (361) B.C. 25.3 (643) 36.7 (932) Elec. connection

(24)

MD-3 Triple-Deck Shale Shaker

Solids Control Systems & Products: Shakers

M-I SWACO new-generation MD-3* triple-decker shaker offers an ideal combination of high efficiency, adaptability and space optimization. The compact MD-3 shale shaker is unique in that it can adapt quickly as drilling conditions and cuttings volumes change.

Changing drilling conditions require immediate and flexible solids control solutions. At the same time, ever-tightening environmental restrictions demand up-to-the-minute compliance. There is also the matter of high drilling costs and the need to recover expensive base fluids. In addition, offshore and some onshore locations have limited space available demanding technologies be as compact as possible.

The MD-3 shale shaker meets all those requirements and more. The advanced MD-3 shaker delivers in a small footprint, a high-efficiency solids-control option adaptable to changing drilling conditions. The highly efficient solids removal capacity of the MD-3 shaker translates to lower waste volumes, costs and downtime. What’s more, by generating drier cuttings at reduced volumes, the MD-3 shaker cuts your environmental footprint and associated coats.

(25)

Solids Control Systems & Products: Shakers: MD-3 T

riple-Deck Shale Shaker

■

■ Progressive and balanced modes of

elliptical motion ■

■ Unique feeder assembly that presents

fluid to the scalping screens as a uniform, low impact curtain. Feeder easily can be configured into a variety of connection points for installations with limited space ■

■ High-capacity operating mode

for increased capacity and conveyance rate

■

■ Efficiency operating mode for

increased fluid recovery, discard dryness and screen life

■

■ Vibratory Motion DriVe* in two modes (6.3 and 7.2 Gs) produces a drier cuttings discharge and results in improved separation efficiency ■

■ Vibratory Motion DriVe allows operating modes to be switched while shaker is in motion ■

■ Heavy-gauge carbon-steel

construction and 316 L stainless steel on high-wear areas reduce maintenance costs and helps to ensure long service life

■

■ Fluid distribution designed to utilize all available screen area, regardless of drilling conditions

■

■ Modular platform to accommodate a

variety of features ■

■ Available in common power supply

configurations to meet all applicable global electrical standards

■

■ Deck-adjustment system capable of

adjustment while processing fluid ■

■ Fume-extraction hood reduces

operator exposure to vapors associated with drilling fluids and prevents fluid splashing outside the shaker boundaries

■

■ State-of-the art motion generators

are oilfield proven and require minimal maintenance

■

■ Standard spray bar assists

conveyance of heavy and/or sticky solids on scalping deck during various formations

Advantages

■

■ Produces drier cuttings

■

■ Extends screen life

■

■ Minimizes HSE footprint

■

■ Lowers waste volume

■

■ Reduces costs

■

■ Requires less rig space

(26)

M

eerkat

PT Shale Shaker

Solids Control Systems & Products: Shakers

The flexibility of dual motion

The dual-motion shale shaker that adapts as solids change

M-I SWACO has combined linear and balanced elliptical motion technology to create the revo lu tion ary Meerkat PT* dual-motion shaker. The design incor porates a 0.6 hp vibrator motor that allows it to perform on an unparalleled level.

But as drilling conditions change,

the Meerkat PT dual-motion shaker

can be adjusted “on the fly.” Simply flipping a switch on the control box reconfigures the shaker from linear to balanced ellip tical motion. There is no need to suspend or shut down operations. With the Meerkat PT shaker oper ating in the gentler balanced ellip tical mode, solids encounter reduced G-forces and longer screen residence time. This results in drier solids, improved drilling-fluid recovery, longer screen life and reduced operating costs.

The economy of linear motion

The dual-motor Meerkat PT

linear-motion shaker is especially effective while drilling top-hole sections where heavy, high-volume solids are usually encountered. In these intervals, shakers need to generate high G-forces to effectively move dense solids across the screens.

The M-I SWACO Meerkat PT shaker

represents the latest developments in compact, modular design and the flex ibility for multiple configurations to meet a wide range of customer requirements and rig environments. This brochure is a reference to the two standard configurations of the Meerkat PT shaker:

■

■ Standard Meerkat PT shaker with

header box ■

■ Standard Meerkat PT low-profile shaker with possum belly

All motor specifications (hp, voltage, speed) are nominal values and may vary with configurations. Additional nonstandard config urations of the Meerkat PT shaker will be made

(27)

■

■ Units can be customized to meet

both tight-space requirements and high-performance criteria

■

■ All configurations are compact

and modular ■

■ Linear motion for fast conveyance

and heavy loading; balanced elliptical motion for maximum retention time and drier cuttings

■

■ Elliptical motion at the flip of a switch without stopping the shaker

■

■ Balanced basket functions flawlessly

in either linear or balanced elliptical mode, with dry, light loads or wet, heavy loads

■

■ Most reliable mechanical

jack ing system in the industry - simple and easy to use; requires no pinning ■

■ Unique distribution box option can

replace flowline possum belly, providing increased handling capacity and dampening the velocity of fluid from the flowline ■

■ Pre-tensioned composite screens for

fast screen changes and overall ease of use

■

■ Ultra-tight seal between screen and

screen bed eliminates solids buildup and costly bypass of solids

■

■ Largest net-usable screen

area among shakers of similar footprint: 15.9 ft2_{(1.5 m}2₎

Features and advantages

Comparison of balanced elliptical motion to linear motion

Linear Motion Balanced Elliptical Motion

■

■ G-force linear motion up to 6.9 G’s ■

■ Speeds conveyance

■

■ Increases shaker-fluid capacity

■

■ Enables shaker to process heavier solids loads

■

■ Enhances cuttings-processing volume

■

■ Uniform elliptical motion at all points on basket ■

■ Reduces G-forces (5.7 G’s maximum)

■

■ Optimizes solids removal

■

■ Maximizes drilling-fluid recovery

■

■ Drier cuttings ■

■ Extends screen life

Solids Control Systems & Products: Shakers:

m

ee

rk

aT

(28)

M

eerkat

PT low-profile shaker

with possum belly

Solids Control Systems & Products: Shakers

m

eerkaT

pT low-profile shaker

with possum belly

DECK ANGLE INDICATOR MANUAL DECK ANGLE ADJUSTMENT (2 PLCS)

MOTION GENERATOR 0.60 HP (VOLTAGE PER CUSTOMER SPECIFICATIONS) EXPLOSION PROOF (NON-EXPLOSION PROOF OPTIONAL) 1 REQUIRED PER SHAKER MOTION GENERATOR 2 HP

(VOLTAGE PER CUSTOMER SPECIFICATIONS) EXPLOSION PROOF (NON-EXPLOSION PROOF OPTIONAL) 2 REQUIRED 3 MOTOR STARTER BOX ISO VIEW 1:15 LIFTING LUG 4 PLCS B B SECTION B-B 1:10 POSSUM BELLY GATE 56.9 (1,445)

10-IN. INLET CONNECTION WELD COVER PLATE POSSUM BELLY

FEEDER 8-IN. BYPASS (2 SIDES)

75.2 (1,910) 90 (2,286) 72.6 (1,844) 17.9 (455) 31.5 (800) 64.3 (1,633) 63 (1,600) LIFTING LUG 13.9 (353) 33.3 (846) 40.9 (1,039) 6 (52) SKID HEIGHT 46 (1,168) @ +3° 44 (1,118) @ 0° 41.5 (1,054) @ –3° 19.5 (495) APPROX C.G. 34.2 (869) APPROX C.G. 48.7 (1,237) SPRING CENTER TO CENTER

44 (1,118) APPROX C.G. 90 (2,286) 94 (2,388) 44.1 (1,120) APPROX C.G. 40.2 (1,021) 72.5 (1,842) 1.8 (46) 4Xø 22.3 (566) WEIR HEIGHT APPROXIMATE LOCATION OF ELECTRICAL CONNECTION (0.75-IN. [19.1 mm] FNPT) 21.8 (554) 4.5 (114) SPARE SCREEN WEDGES

(2) PER SHAKER 57 (1,448) SPRING CENTER TO CENTER DECK ANGLE INDICATOR MANUAL DECK ANGLE ADJUSTMENT (2 PLCS)

44 (1,118) APPROX C.G. 90 (2,286) 44.1 (1,120) APPROX C.G. 40.2 (1,021) 72.5 (1,842) 1.8 (46) 4Xø 22.3 (566) WEIR HEIGHT APPROXIMATE LOCATION OF ELECTRICAL CONNECTION (0.75-IN. [19.1 mm] FNPT) 21.8 (554) 4.5 (114) SPARE SCREEN WEDGES

44 (1,118) APPROX C.G. 90 (2,286) 94 (2,388) 44.1 (1,120) APPROX C.G. 40.2 (1,021) 72.5 (1,842) 1.8 (46) 4Xø 22.3 (566) WEIR HEIGHT APPROXIMATE LOCATION OF ELECTRICAL CONNECTION (0.75-IN. [19.1 mm] FNPT) 21.8 (554) 4.5 (114) SPARE SCREEN WEDGES

44 (1,118) APPROX C.G. 90 (2,286) 44.1 (1,120) APPROX C.G. 40.2 (1,021) 72.5 (1,842) 1.8 (46) 4Xø 22.3 (566) WEIR HEIGHT APPROXIMATE LOCATION OF ELECTRICAL CONNECTION (0.75-IN. [19.1 mm] FNPT) 21.8 (554) 4.5 (114) SPARE SCREEN WEDGES

(2) PER SHAKER 57 (1,448) SPRING CENTER TO CENTER Specifications ■ ■ Length: 94 in. (2,388 mm) ■ ■ Width: 72.5 in. (1,842 mm) ■

■ Weir height: 22.3 in. (566 mm) ■

■ Height: 44 in. (1,118 mm) ■

■

■ Screen area: Gross: 22 ft2 (2 m2) Net (API): 15.9 ft2_{(1.5 m}2₎

■

■ Deck-angle adjustment: –3° to +3°

■

■ Screen type: Pre-tensioned

4 x 2 ft (1.2 x 0.61 m) ■

■ Three screen panels per shaker

■ Powder-coated steel springs

■ Two (2) primary vibrator motors

■

■ One (1) secondary vibrator motor

on dual-motion model ■ ■ 440-480V/60 Hz/1,800 rpm or 380-415V/50 HZ/1,500 rpm ■ ■ Explosion proof ■

■ Class I, Groups C and D ■

■ UL/cUL, CE, ATEX, NORSOK

Nominal Fluid Capacity ■

■ 500 gpm (1,893 L/min)

m

ee

rk

aT

(29)

27

Standard M

eerkat

PT shaker

with header box

Solids Control Systems & Products: Shakers

s

TanDarD

m

eerkaT

pT shaker

with header box

Specifications ■

■ Length

Linear motion: 96.6 in. (2,454 mm) Dual motion: 120 in. (3,048 mm) ■

■ Width: 68.9 in. (1,750 mm) ■

■ Weir height: 29 in. (737 mm)

■

■ Height: 51 in. (1,295 mm) ■

■

■ Screen area: Gross: 22 ft2 (2 m2) Net (API): 15.9 ft2_{(1.5 m}2₎

■

■ Deck-angle adjustment: –3° to +3°

■

■ Screen type: Pre-tensioned

4 x 2 ft (1.2 x 0.61 m) ■

■ Three screen panels per shaker

■ Powder-coated steel springs

■ Two (2) primary vibrator motors

■

■ One (1) secondary vibrator motor on

dual-motion model ■ ■ 440-480V/60 Hz/1,800 rpm or 380-415V/50 Hz/1,500 rpm ■ ■ Explosion proof ■

■ Class 1, Groups C and D

■

■ UL/cUL, CE, ATEX, NORSOK

Nominal Fluid Capacity ■ ■ 500 gpm (1,893 L/min) REAR VIEW ISO VIEW 63 (1,600) 68.9 (1,750) 1.5 (38) 4Xø 63 (1,600) 10.3 (262) APPROXIMATE LOCATION OF ELECTRICAL CONNECTION (0.75-IN. PT) 31.6 (803) ø10 (254) ø 8 (203) ø6 (152) MOTION GENERATOR 2 HP

(VOLTAGE PER CUSTOMER CONTRACT) EXPLOSION PROOF 2 PLACES

MOTION GENERATOR .6 HP (VOLTAGE PER CUSTOMER CONTRACT) EXPLOSION PROOF

101.4 (2,576)

47.2 (1,199) SPARE SCREEN WEDGES (2) PER SHAKER 24 (610) 6-IN. INLET CONNECTION 25 (636) 8-IN. INLET CONNECTION 26 (660) 10-IN. INLET CONNECTION 34.2 (869) THREE MOTOR CONTROL PANEL 41.6 (1,057) 29 (737) WEIR HEIGHT 23.1 (587) APPROXIMATE C.G. 52.8 (1,341) APPROXIMATE C.G. APPROVED LIFTING POINT APPROVED LIFTING POINT 53 (1,345) @+3° 51 (1,295) 48.5 (1,232)@ –3° MANUAL DECK ANGLE ADJUSTMENT ONE EACH SIDE

REAR VIEW ISO VIEW 63 (1,600) 68.9 (1,750) 29.5 (749) APPROXIMATE C.G. 1.5 (38) 4Xø

APPROVED LIFT POINT

63 (1,600) 10.3 (262) APPROXIMATE LOCATION OF ELECTRICAL CONNECTION (0.75-IN. PT) MUD OUTLET ONE EACH SIDE 63 (1,600) 31.6 (803) ø10 (254) ø 8 (203) ø6 (152) MOTION GENERATOR 2 HP

MOTION GENERATOR .6 HP (VOLTAGE PER CUSTOMER CONTRACT) EXPLOSION PROOF 101.4 (2,576) 64.5 (1,638) 47.2 (1,199) SPARE SCREEN WEDGES (2) PER SHAKER 24 (610) 6-IN. INLET CONNECTION 25 (636) 8-IN. INLET CONNECTION 26 (660) 10-IN. INLET CONNECTION 34.2 (869) DECK ANGLE INDICATOR ONE EACH SIDE

EARTH GROUNDING POINT (BOTH SIDES) THREE MOTOR CONTROL PANEL 41.6 (1,057) 29 (737) WEIR HEIGHT UNIT TAG 101.4 (2,576) 44.6 (1,133) 33.5 (851) 73.1 (1,857) 23.1 (587) APPROXIMATE C.G. 52.8 (1,341) APPROXIMATE C.G. APPROVED LIFTING POINT APPROVED LIFTING POINT 53 (1,345) @+3° 51 (1,295) 48.5 (1,232)@ –3° MANUAL DECK ANGLE ADJUSTMENT ONE EACH SIDE

REAR VIEW 68.9 (1,750) 29.5 (749) APPROXIMATE C.G. 1.5 (38) 4Xø

APPROVED LIFT POINT

63 (1,600) 10.3 (262) APPROXIMATE LOCATION OF ELECTRICAL CONNECTION (0.75-IN. PT) MUD OUTLET ONE EACH SIDE 63 (1,600) 31.6 (803) ø10 (254) ø8 (203) ø6 (152) MOTION GENERATOR 2 HP

REAR VIEW ISO VIEW 63 (1,600) 68.9 (1,750) 29.5 (749) APPROXIMATE C.G. 1.5 (38) 4Xø

APPROVED LIFT POINT

63 (1,600) 10.3 (262) APPROXIMATE LOCATION OF ELECTRICAL CONNECTION (0.75-IN. PT) MUD OUTLET ONE EACH SIDE 63 (1,600) 31.6 (803) ø10 (254) ø 8 (203) ø6 (152) MOTION GENERATOR 2 HP

m

ee

rk

aT

(30)

In any configuration, the M

eerkat

PT shaker

takes performance to a new level

Solids Control Systems & Products: Shakers

The Meerkat PT shaker’s modular construction is as basic and important to its

success as the unit’s dual-motion capability.

By incorporating the concept of modules, M-I SWACO has built big advantages

into the Meerkat PT shaker. Customers have the option of bolting single

Meerkat PT units into a dual or triple configuration, with different feed systems and

mud cleaner options. In the field, rig personnel can reconfigure the unit quickly, via bolted connections, to meet changing requirements.

Another big advantage of the M-I SWACO bolted, modular design becomes apparent when it’s time to ship the unit internationally. With the M-I SWACO mobilization option, our crews will partially disassemble the Meerkat PT shaker and pack it in a

safe, compatible container. The unit’s modularity reduces disassembly and packing time at the shipping end and unpacking and reassembly time at the receiving end. Once onsite, crews can configure the modules and install the shakers, using bolted, not welded, connections.

m

eerkaT

PT dual shaker

m

eerkaT

PT Low-Profile dual shaker

Features and advantages

■

■ Combines two or three Meerkat PT

shakers into one integral assembly by bolting together skids with field-installable kit

■

■ Standard assembly includes

common possum belly ■

■ Available options:

– Multiple header tanks – Mud cleaner – Lifting frame – Distribution box ■

■ Can be lifted/rigged as single unit ■

■ Single flowline connection

to shakers ■

■ Feeder slide gates integral to possum belly

■

■ Flow distribution controlled by slide gates

■

■ Flow can be opened/closed

to any shaker ■

■ Flow can be regulated by

(31)

These configurations are just the beginning

M-I SWACO is currently developing additional configurations of the Meerkat PT

shaker. To see for yourself what we have planned, visit an M-I SWACO representative to review the latest specifications for our soon-to-be-launched models.

These configurations are just the beginning

M-I SWACO high-capacity com posite shaker screens are the most rugged, long-lasting and efficient screens available. The new com posite screens, unique in the industry, provide resistance to corrosive drilling fluids. The screens also offer significant fluid capacity, excellent resistance to blinding, drier solids discharge and a large net-usable screen area.

Composite construction creates an ultra-tight seal between the screen and screen bed and eliminates solids buildup and costly solids bypass. The unique screen-locking mechanism wedges the screen firmly in place and allows the screen to be removed for repair or replacement.

m

eerkaT

PT Mud Cleaner*

Mud cleaners can be installed on the single, dual and triple configurations:

■

■ The D-sanDer* unit is available in two- or three-cone

■

■ The D-silter* unit is available in six, eight or ten twin-cone

■

■ Low profile (approx. 64 in. [1,626 mm] to top of trough) ■

■ Integral bypass between shaker

and D-silter/D-sanDer units ■ ■ Compact footprint ■ ■ Allows inspection/ maintenance without ladders or scaffolds ■

■ Operates as D-silter and D-sanDer units and flowline

shaker independently

m

ee

rk

aT

(32)

Features

■

■ Dual motion: Balanced Elliptical/

Progressive Elliptical ■

■ Motion change during operation at

the “flip of a switch” ■

■ Two 2.5 hp motion generators

■

■ Increased screen access

■

■ Heavy duty, reliable, mechanical

deck adjustment system. Jacks with corrosion resistant coating

■

■ Large capacity distribution box

■

■ Utilizes high-tension composite

screens ■

■ Ultra-tight seal between screen and

screen bed ■

■ Largest non-blanked screen area

among shakers of similar footprint: 21.2 ft² (1.97 m²)

Benefits

■

■ Balanced Elliptical motion in Capacity

mode provides increased fluid capacity and solids conveyance rate ■

■ Progressive Elliptical motion in

Efficiency mode for increased fluid recovery, discard dryness, and screen life

■

■ Rugged design and simple operation

reduces maintenance costs ■

■ Lightweight composite screens allow

quick screen change out ■

■ Screen to shaker seal eliminates

solids buildup and costly solids bypass

■

■ Easier access for quicker and safer

screen changes and screen inspections

■

■ Continuous shaker operations when

switching between motions

The flexibility of dual motion

With the new generation Mongoose

Pro dual-motion shale shaker, M-I SWACO has combined balanced and progressive elliptical motion technology for a shaker that adapts as drilling conditions change.

As drilling conditions change, the evolutionary Mongoose Pro dual-motion shaker can be adjusted “on the fly.” Simply flipping a switch on the control box reconfigures the shaker from balanced to progressive elliptical motion. There is no need to suspend or shut

down operations. With the Mongoose

Pro shaker operating in the gentler progressive elliptical mode, solids encounter reduced G-forces and longer screen residence time.

This results in drier solids, improved drilling-fluid recovery, longer screen life and reduced operating costs.

The economy of elliptical motion

The Mongoose Pro shaker in balanced

elliptical mode is especially effective while drilling top-hole sections where heavy, high-volume solids usually are encountered. In these intervals, shakers need to generate high G-forces to effectively move dense solids across the screens. During drilling breaks and increased viscosity the balanced elliptical motion eliminates the need for screen changes as well as losses.
