INTELLIGENT & BASIC POWER DISTRIBUTION UNITS

BASIC POWER

The Conteg Intelligent & Basic Power product range comprises three different

technologies to address the needs of the high-density computing user. The range

comprises power strips which feature either no intelligence (Basic), the ability to

remotely monitor current draw per strip using Ethernet and IP (Monitored range)

or the ability to fully manage power strips and groups of power strips across the

network (Managed range). Conteg Intelligent & Basic Power offers a combination

of outlets, including national outlet styles combined with industrial outlets,

high-amperage inputs and both 1-phase and 3-phase powered models. Standard

1-phase input plug styles include the EN60 309 16 A and 32 A type or the IEC-C20 or

Schuko/UTE, which are also rated for 16 A operation. The standard 3-phase input

plug is EN60 309 3×16 A.

Managed PDU

Monitored PDU Basic PDU with DP‑RP‑VM‑02

Monitored PDU

These Basic Power Distribution Units are designed for standard applications without the above standard safety or operational requirements. These

models provide reliable power to the cabinet for a standard environment.

*_{panels contain HF filter}

1_{for vertical installation use DP‑RP‑VM‑01} 2_{for vertical installation use DP‑RP‑VM‑02, see above}

picture “Basic PDU with DP‑RP‑VM‑02”

DESCRIPTION:

• Types:

a) 19" mounting

b) 10" mounting

c) free-standing

d) vertical

• Outlet types: UTE, SCHUKO, UK, IEC320 C13,

IEC320 C19

• Other outlet types in combination with surge

protection and ammeter also available

• Power output:

- SCHUKO, UTE, IEC320 C19: 16 A, 250 V

- UK: 13 A, 250 V

- IEC320 C13: 10 A, 250 V

• Power input:

- all types with 3 m power cord

- UK plug for PDU with UK outlets

- Schuko/UTE plug for all other PDUs

BASIC POWER DISTRIBUTION UNITS – FOR STANDARD ENVIRONMENT

Code Mounting H in U Outlettype Qty Over voltage protection Switch

DP-RP-02-UK 10" 1 UK 2 No No

DP-RP-03-UTE 10" 1 UTE 3 No No

DP-RP-03-SCHU 10" 1 SCHUKO 3 No No

DP-RP-06-UTESP 1 * _19" ₂ _UTE ₆ _Yes _Yes

DP-RP-06-SCHUSP 1 * _19" ₂ _SCHUKO ₆ _Yes _Yes

DP-RP-06-UTESP-F free - UTE 6 Yes Yes

DP-RP-06-SCHUSP-F free - SCHUKO 6 Yes Yes

DP-RP-06-UKS 1 _19" ₁ _UK ₆ _No _Yes

DP-RP-07-UK 1 _19" ₁ _UK ₇ _No _No

DP-RP-08-UTES 1 _19" ₁ _UTE ₈ _No _Yes

DP-RP-08-SCHUS 1 _19" ₁ _SCHUKO ₈ _No _Yes

DP-RP-09-UTE 1 _19" ₁ _UTE ₉ _No _No

DP-RP-09-SCHU 1 _19" ₁ _SCHUKO ₉ _No _No

DP-RP-09-IECC19 1 _19" ₁ _{IEC320 C19} ₉ _No _No

DP-RP-12-IECC13 1 _19" ₁ _{IEC320 C13} ₁₂ _No _No

DP-RP-20-IECC19 2 _vertical _- _{IEC320 C19} ₂₀ _No _No

DP-RP-20-IECC13 2 _vertical _- _{IEC320 C13} ₂₀ _No _No

DP-RP-20-SCHUV 2 _vertical _- _SCHUKO ₂₀ _No _No

(3)

Strips feature a local easy-to-read ammeter on the outlet strip along with the ability to monitor the current draw of outlets remotely over an Ethernet

connection. The user can aggregate the information from thousands of Intelligent Power Strips in one location. Designed for high-density, mission-critical

server applications, the Conteg Monitored power strips provide reliable power to the cabinet for both standard and blade server environments.

The enhanced version of the monitored strip also offers voltage and frequency metering. Hence the PDU is able to report the power factor, active and

apparent power and main energy consumed in kWh. A calculation of carbon emission data (CO

₂

footprint) and the price estimation of consumed energy

is also made.

monitored PDU

INTELLIGENT POWER MONITORED

INTELLIGENT POWER DISTRIBUTION UNITS – MONITORED

Code Input plug Length Type 1 outlet Qty Type 2 outlet Qty Rating Mounting Dimensions in mm

H W D IP-DMI-008C3 00 016 C20 x 1 _C13 ₈ _x _x _16 A _1U ₄₃₂ ₄₄ ₉₀ IP-DMI-021C33C916 C20 x 1 _C13 ₂₁ _C19 ₃ _16 A _0U _{1 645} ₄₄ ₅₆ IP-DMI-314C32C932 EN 60 309 3 m C13 14 C19 2 32 A 0U 1 245 44 56 IP-DMI-321C33C932 EN 60 309 3 m C13 21 C19 3 32 A 0U 1 645 44 56 IP-DMI-321C33C911 EN 60 309 3 m C13 21 C19 3 3× 16 A 0U 1 778 44 56 IP-DMI-318C36C922 EN 60 309 3 m C13 18 C19 6 3× 32 A 0U 1 778 44 56

INTELLIGENT POWER DISTRIBUTION UNITS - ENHANCED MONITORED (kWh)

IP-DEI-008C3 00 016 C20 x 1 _C13 ₈ _x _x _16 A _1U ₄₃₂ ₄₄ ₉₀

IP-DEI-321C33C932 EN 60 309 3 m C13 21 C19 3 32 A 0U 1 645 44 56

1_{INPUT power cords for these models must be ordered separately (see table page 127)}

Basic PDU

BASIC POWER DISTRIBUTION UNITS – FOR STANDARD AND BLADE SERVER ENVIRONMENTS

Code Input plug Length Type 1 outlet Qty Type 2 outlet Qty Rating Mounting Dimensions in mm

H W D

IP-BA-308UK8C916 EN 60 309 3 m UK 8 C19 8 16 A 0U 860 44 44

IP-BA-312UK8C316 EN 60 309 3 m UK 12 C13 8 16 A 0U 985 44 44

IP-BA-308SH8C916 EN 60 309 3 m SCHUKO 8 C19 8 16 A 0U 722 44 44

IP-BA-312SH8C316 EN 60 309 3 m SCHUKO 12 C13 8 16 A 0U 777 44 44

IP-BA-308UT8C916 EN 60 309 3 m UTE 8 C19 8 16 A 0U 780 44 44

IP-BA-312UT8C316 EN 60 309 3 m UTE 12 C13 8 16 A 0U 865 44 44

IP-BA-320C34C916 EN 60 309 3 m C13 20 C19 4 16 A 0U 908 44 44

IP-BA-C20C34C916 C20 3 m C13 20 C19 4 16 A 0U 908 44 44

IP-BA-C08C3 00 016 C20 3 m C13 8 None 0 16 A 1U 439 44 44

IP-BA-320C34C932 EN 60 309 3 m C13 20 C19 4 32 A 0U 1 038 44 44

IP-BA-306C9 00 011 EN 60 309 3 m C19* 6 None 0 3× 16 A 1U 439 44 44

IP-BA-306SH00 011 EN 60 309 3 m SCHUKO 6 None 0 3× 16 A 1U 439 44 44

IP-BA-306UT00 011 EN 60 309 3 m UTE 6 None 0 3× 16 A 1U 439 44 44

IP-BA-306C9 00 022 EN 60 309 3 m C19* 6 None 0 3× 32 A 1U 439 44 145

These Basic Power Distribution Units are designed for high-density, mission-critical server applications. These models provide reliable power to the

cabinet for both standard and blade server environments.

DP‑RP‑09‑UTE DP‑RP‑09‑SCHU DP‑RP‑12‑IECC13

(4)

INTELLIGENT POWER MANAGED

managed PDU

Strips represent the leading edge in functionality available in a power

strip. Employing a server-grade microprocessor, this product has

unprecedented management and monitoring capabilities available

through the built in web-server and firewall.

• Switch individual outlets on or off to enable remote reboot of servers

• Virtual grouping of outlets for single-click reboot of multi-corded

servers

• Single-click control of entire racks or non-critical loads

• Current monitoring per outlet (POM)

• User-definable sequencing of outlets for reboot

Designed for high-density, mission-critical server applications, the

Conteg Managed power strips provide reliable power to the cabinet in

both standard and blade-server environments.

The enhanced version of the managed strip also offers voltage and

frequency metering. Hence the PDU is able to report the power factor, active

and apparent power and main energy consumed in kWh. A calculation of

carbon emission data (CO

₂

footprint) and the price estimation of consumed

energy is also made.

INTELLIGENT POWER DISTRIBUTION UNITS – MANAGED (MONITORED PER OUTLET)

Code Input plug Length Type 1 outlet Qty Type 2 outlet Qty Rating Mounting Dimensions in mm

H W D

IP-DMA-008C3POM16 2 _C20 _x1 _C13 ₈ _x _x _16 A _1U ₄₃₂ ₄₄ ₉₀

IP-DMA-308C9POM32 EN 60 309 3 m C19 8 x x 32 A 1U 432 44 90

INTELLIGENT POWER DISTRIBUTION UNITS - ENHANCED MONITORED (kWh)

IP-DEA-308C9POM32 EN 60 309 3 m C19 8 x x 32 A 1U 432 44 90

1_{INPUT power cords for these models must be ordered separately (see below)} 2_{“POM” stands for “per‑outlet‑monitored” i.e. each outlet is metered separately}

INTELLIGENT POWER DISTRIBUTION UNITS – MANAGED (MONITORED PER STRIP)

Code Input plug Length Type 1 outlet Qty Type 2 outlet Qty Rating Mounting Dimensions in mm

H W D IP-DMA-008C3 00 016 C20 x 1 _C13 ₈ _x _x _16 A _1U ₄₃₂ ₄₄ ₉₀ IP-DMA-021C33C916 C20 x 1 _C13 ₂₁ _C19 ₃ _16 A _0U _{1 778} ₄₄ ₅₆ IP-DMA-314C32C932 EN 60 309 3 m C13 14 C19 2 32 A 0U 1 245 44 56 IP-DMA-321C33C932 EN 60 309 3 m C13 21 C19 3 32 A 0U 1 778 44 56 IP-DMA-318C36C911 EN 60 309 3 m C13 18 C19 3 3x 16 A 0U 1 778 44 56 IP-DMA-318C36C922 EN 60 309 3 m C13 18 C19 3 3x 32 A 0U 1 778 44 56

INTELLIGENT POWER DISTRIBUTION UNITS - ENHANCED MANAGED (kWh)

IP-DEA-008C3 00 016 C20 x 1 _C13 ₈ _x _x _16 A _1U ₄₃₂ ₄₄ ₉₀

IP-DEA-314C32C932 EN 60 309 3 m C13 14 C19 2 32 A 0U 1 245 44 56

1_{INPUT power cords for these models must be ordered separately}

INTELLIGENT POWER MANAGED

Brackets for PDU

Code Options

DP-RP-VM-01 Brackets for mounting vertical 19" power distribution unit into PREMIUM/OPTIMAL frame DP-RP-VM-02 Brackets for mounting vertical power distribution unit DP-RP-20-xx into PREMIUM/OPTIMAL frame DP-RP-VM-06 Swivel brackets for mounting vertical PDU DP-RP-xx and IP-xxx into PREMIUM/OPTIMAL frame, set for 1 PDU

(5)

INPUT POWER CORDS FOR INTELLIGENT PDUs

Code In-out type Length

IP-C-C9SH25 IEC 320 C19 to Schuko (plug) 2.5 m

IP-C-C93 025 IEC 320 C19 to EN 60 309 (1×16 A) 2.5 m

IP-C-C9C225 IEC 320 C19 to IEC 320 C20 2.5 m

OUTPUT POWER CORDS FOR INTELLIGENT PDUs

Code In-out type Length

EN60 309 16A 1PH IEC320 C13 Also known as C13 IEC320 C19 Also known as C19 UK FRENCH GERMAN

Output Socket Types

IEC320 C13 Also known as C13 IEC320 C19 Also known as C19 UK FRENCH GERMAN

Output Socket Types

IEC320 C19 IEC320 C13 Also known as C13 IEC320 C19 Also known as C19 UK FRENCH GERMAN

Output Socket Types

UK IEC320 C13 Also known as C13 IEC320 C19 Also known as C19 UK FRENCH GERMAN

Output Socket Types

UTE IEC320 C13 Also known as C13 IEC320 C19 Also known as C19 UK FRENCH GERMAN

Output Socket Types

SCHUKO

Input plug types

EN60309 16A

also known as EN309 16A a 16 amp socket

EN60309 32A

EN60309 63A

also known as EN309 63A a 63 amp socket IEC320 C14 Also known as C14 IEC320 C20 Also known as C20 SCHUKO -GERMAN UTE - FRENCH UK

Input plug types

EN60309 16A

EN60309 32A

EN60309 63A

Input plug types

EN60309 16A

EN60309 32A

EN60309 63A

Input plug types

EN60309 16A

EN60309 32A

EN60309 63A

Input plug types

EN60309 16A

EN60309 32A

EN60309 63A

Input plug types

EN60309 16A

EN60309 32A

EN60309 63A

also known as EN309 63A a 63 amp socket IEC320 C14 Also known as C14 IEC320 C20 Also known as C20 SCHUKO -GERMAN SCHUKO - FRENCH UK IEC320 C13 UK (BS 1 363) IEC320 C14 IEC320 C20 SCHUKO – GERMAN UTE – FRENCH

Input plug types

EN60309 16A

EN60309 32A

EN60309 63A

OUTLET AND PLUG TYPES:

Note: Compatible with IP‑DMI and IP‑DMA

EN60 309 32A 1PH

EN60 309 16A 3PH EN60 309 32A 3PH

Dashboard screenshot of enhanced managed PDU:

Traditional basic PDUs, which are still produced and delivered, have part numbers starting with code DP-RP-xx. Conteg´s PDU part numbers for

Intel-ligent and Basic power strips are set up in accordance with the following matrix.

IP-DMI-321C33C911

*

An example of a correct product code

3

NUMBER OF OUTLET TyPE 1

2

INPUT PLUG TyPE (on the input power cord)

Code Options

0 no cable, Inlet C20 only

C IEC C20

3 EN 60 309

1

POWER STRIP TECHNOLOGy

Code Options

BA Basic

DMI Monitored (over IP)

DMA Managed

DEI Enhanced Monitored

DEA Enhanced Managed

HOW TO READ PRODUCT CODE FOR INTELLIGENT POWER UNITS

IP

-

1.

-

2.

4.

5.

6. 7.

4

TyPE OF OUTLET TyPE 1

Code Options UK UK SH Schuko UT UTE (French) C3 C13 C9 C19

6

TyPE OF OUTLET TyPE 2

Code Options C3 C13 C9 C19

7

RATING OF STRIP Code Options 16 16 Amps 32 32 Amps 11 11 kW (3×16 A) 22 22 kW (3×32 A)

3.

5

NUMBER OF OUTLET TyPE 2

* IP‑DMI‑321C33C911 indicates a Monitored Power Strip with plug EN 60 309, 21×C13 and 3×C19 outlets with 3×16 Ampere rating (11kW).
