Simulating Composite

Materials and Structures

2nd_{– 3}rd_{February 2010}

Esbjerg, Denmark

Invitation

Composite structures or components are increasingly used as primary load carrying structures in nearly all fields of our society, taking advan-tage of the increased structural strength and stiffness to weight ratios, corrosion resistance, or more innovative design capability that compo-sites bring. The nature of the composite used can range from cheap and freely available glass fiber reinforced systems to exotic and specifi-cally tailored carbon, aramid or even metal/matrix systems, with many forms of manufacturing process available.

The design may include thick composite sections with large numbers of plies, there may be regions of significant ply drop off, sandwich con-struction and also bonded joints. In this case the strength prediction may become very difficult and can often only be solved with the incor-poration of advanced experimental tests.

The successful application of FE methods for the design of components and structures which are made of modern materials strongly depends on the ability of the designer to choose the correct lay up, fiber orienta-tion etc. The development of numerical methods and faster computers, better design criteria etc. makes it much more economically efficient

In Cooperation with

(2)

than experimental testing although that experimental test in some ex-tent is still needed.

It is anticipated that the increased use of such advanced materials combined with the necessity to calculate the structural integrity more precisely, will result in an increasing amount of advanced FE analysis to simulate failure phenomena using nonlinear analysis, progressive cracking, debonding, delamination, brittle and ductile fracture, etc.

The seminar is intended as a forum for experts in the area of prediction and modelling of complicated composite structures by using FEA. The event is accompanied by an exhibition of engineering software, com-puter systems, and related consultancy services. A comprehensive review of the current state-of-the-art and trends as well as of future challenges will thus be accessible to participants.

The foundation of a NAFEMS Composite Working Group will be dis-cussed. All interested should not miss this opportunity to get information about this first hand.

To register for this seminar or to learn more about exhibition and spon-sorship opportunities, please go to http://www.nafems.org

Organization

This seminar is organized by NAFEMS NORDIC in cooperation with Aalborg University, Risø DTU and IDA, Danish Society of Engineers.

Technical Coordinators

Dr. Find M. Jensen (Risø DTU) – Chairman * Prof. Lars Damkilde (AAU-Esbjerg) – Co-chairman Dr. Anders Kristiansen (AAU-Esbjerg) – Co-chairman Dr. Lars P. Mikkelsen (Risø DTU) – Co-chairman

(3)

Agenda

2nd_February

13:30 Welcome and Introduction to NAFEMS

13:45 Digimat Material eXpert – From the Material Lab to the Efficient and Optimal Design of Reinforced Plastic Parts

S. Lepage, L.Adam, R. Assaker (e-Xstream engineering)

14:10 New Approaches for Efficient Pre and Post Processing of Composite Structures R. Roos, M. Wintermantel (EVEN – Evolutionary Engineering AG);

M. Hörmann (CADFEM GmbH); M. Palanterä (Componeering Inc.)

14:35 Innovative Numerical Methods for Analysis and Optimisation of Composites M. Bruyneel, J. P. Delsemme, Ph. Jetteur, A. Remouchamps (Samtech)

15:00 Benefits of Structural Optimization in the Aerospace Design Process: Recent Indus-trial Applications on Composites Structures

P.-O. Jansell (Altair Engineering) 15:25 Coffee break

16:00 Keynote presentation:

Benchmarking of Damage and Triaxial Design Methodologies for Fibre Reinforced Composites: The Second and Third World-Wide Failure Exercises (WWFE-2 and WWFE-3)

A.S. Kaddour (QinetiQ)

16:45 Use of the Model Correction Factor Method with FEM-based Reliability Analysis of Composites

N. Dimitrov (Siemens), C. Berggreen (DTU Mek); P. Friis-Hansen (Det Norske Veritas) 17:10 Sponsor presentation:

Altair Engineering 17:20 Sponsor presentation:

Simulia Scandinavia 17:30 Discussion

18:30 Come together in the exhibition area

(4)

Agenda

3rd_February

Design of Composite Structures C. Burchardt (Bach Composite Industry)

9:15 State of the Art FE-Simulations of Wind Turbines

P. Berring, R. Bitsche, F. M. Jensen (Risø DTU); C. Jensen (ECC) 9:40 On Innovative Concepts of Future Wind Turbine Blade Design

F. M. Jensen, R. Bitsche, K. Branner, T. Sieradzan, A. Roczek, P. Berring (Risø DTU) 10:05 Structural Behaviour Due to Bend-Twist Couplings in Wind Turbine Blades V. Fedorov, N. Dimitrov, C. Berggreen, S. Krenk (DTU Mek);

K. Branner, P. Berring (Risø DTU) 10:30 Coffee break

11:00 A Smeared-out Material Model Predicting Compressive Failure of Composites L. P. Mikkelsen (Risø DTU); K. D. Sørensen (Aalborg University);

H. M. Jensen (Aarhus University)

11:25 Elastic Microscale Simulation of Fiber-reinforced Polymers F. Wenzlau (Fraunhofer ITWM)

11:50 Application of a Cycle Jump Technique for Acceleration of Fatigue Crack Growth Simulation

R. Moslemian, C. Berggreen (DTU Mek); A. M. Karlsson (University of Delaware, USA) 12:15 Debonding Failure in Composites

B. N. Legarth, C. Didriksen, A. B. Richelsen (DTU Mek) 12:40 Lunch break

Simulation of Fiber Composites – An Assessment K. Rohwer (German Aerospace Center)

14:25 Joining of Composites Research B. F. Sørensen (Risø DTU)

14:40 NAFEMS Composites Working Group

R. Oswald (NAFEMS)
