An Energy-efficient Hardware Implementation of HOG-based

Object Detection at 1080HD 60 fps with Multi-scale Support

Received: date / Accepted: date

Abstract A real-time and energy-efficient multi-scale object detector hardware implementation is presented in this paper. Detection is done using Histogram of Ori-ented Gradients (HOG) features and Support Vector Machine (SVM) classification. Multi-scale detection is essential for robust and practical applications to de-tect objects of different sizes. Parallel dede-tectors with balanced workload are used to increase the through-put, enabling voltage scaling and energy consumption reduction. Image pre-processing is also introduced to further reduce power and area costs of the image scales generation. This design can operate on high definition 1080HD video at 60 fps in real-time with a clock rate of 270 MHz, and consumes 45.3 mW (0.36 nJ/pixel) based on post-layout simulations. The ASIC has an area of 490 kgates and 0.538 Mbit on-chip memory in a 45nm SOI CMOS process.

Keywords Object Detection · Histogram of Oriented Gradients · Multi-scale · Low power architectures · Embedded vision

1 Introduction

Object detection is needed for many embedded vision applications including surveillance, advanced driver as-sistance systems (ADAS) [1], portable electronics and robotics. For these applications and others, it is desir-able for object detection to be real-time at high frame

A. Suleiman, V. Sze

Department of Electrical Engineering and Computer Science, Massachusetts Institute of Technology,

77 Massachusetts Ave, room 38-260 Cambridge MA, 02139

E-mail: suleiman, [email protected]

Fig. 1 Examples of pedestrians with different sizes based on their distances from the camera and/or their different heights. Images are taken from INRIA person dataset [5].

rates, robust and energy-efficient. Real-time processing is necessary for applications such as ADAS, and au-tonomous control in unmanned aerial vehicles (UAV), where the vehicle needs to react quickly to fast changing environments. High frame rate enables faster detection to allow more time for course correction. For detection robustness, it is essential that detectors support mul-tiple image scales to detect objects with variable sizes. As shown in Fig. 1, the size difference can be due to dif-ferent distances from the camera (i.e. an object’s height is inversely proportional to its distance from the cam-era [2]), or due to the actual size of the object (e.g. pedestrians with different heights). In addition, high resolution images, such as high definition (HD), enable early detection by having enough pixels to identify far objects, which is particularly important for fast moving objects. Finally, for energy consumption, in both UAV and portable electronics, the available energy is limited by the battery whose weight and size must be kept to a minimum [3]. Additionally, heat dissipation is a crucial factor for ADAS application [4].

A conventional method of object detection involves translating the image from pixel space into a higher di-mensional feature space. Classification is then used at different regions in the image to decide whether a spe-cific object exists or not. Histogram of Oriented Gradi-ents (HOG), which looks at the distribution of edges, is

Fig. 2 Object detection algorithm using HOG features.

a widely accepted feature for object detection [6]. HOG features provide a reasonable trade-off between detec-tion accuracy and complexity compared to alternative richer features [7]. A combination of other types of fea-tures can be added to HOG for more accurate detec-tion with the cost of more computadetec-tion power. How-ever, no single feature has been shown to outperform HOG, which makes HOG-based detection the baseline for object detection systems [2].

In this paper, we describe a hardware-friendly real-time energy-efficient HOG algorithm for object detec-tion, with multi-scale support. The resulting implemen-tation delivers high-throughput processing to achieve real-time, robust and accurate object detection at high frame rates with low hardware and energy costs. The main contributions of this work are:

1. Efficient scale selection and generation for multi-scale detection.

2. Parallel detectors with voltage scaling.

3. Image pre-processing to reduce multi-scale memory and processing overhead.

The rest of the paper is organized as follows. Sec-tion 2 provides a survey of existing HOG-based object detector implementations. Section 3 describes the HOG detection algorithm and the importance of multi-scale detection for robustness. Section 4 describes the hard-ware architecture of the HOG-based object detector. Section 5 introduces the parallel detectors architecture and voltage scaling. Then, image pre-processing is in-troduced in Section 6. We present the performance met-rics including detection accuracy and hardware com-plexity in Section 7 and conclude in Section 8.

2 Previous Work

The majority of the published implementations of HOG-based object detection are on CPU and GPU platforms. In addition to consuming power in hundreds of Watts (e.g., Nvidia 8800 GTX GPU consumes 185W [8]),

which is not suitable for embedded applications, they often cannot reach high definition (HD) resolutions. Au-thors in [9] demonstrate a real-time object detection system with multi-scale support on a CPU processing 320×240 pixels at 25 frames per second (fps). The im-plementation in [10] achieves higher throughput on a GPU at 100 fps using the approach presented in [7] to speed up feature extraction, but with a resolution of 640×480 pixels.

For higher throughput, FPGA-based implementa-tions have recently been reported. Different parts of the detector are implemented in [11] on different plat-forms: HOG feature extraction is divided between an FPGA and a CPU, and SVM classification is done on a GPU. It can process 800×600 pixels at 10 fps for single scale detection. The entire HOG-based detector is implemented in [12] on an FPGA, and can process 1080HD video (1920×1080 pixels) at 30fps. However, the implementation only supports a single image scale. An ASIC version of this design is presented in [13], with dual cores to enable voltage scaling for power consump-tion of 40.3mW for 1080HD video at 30fps, but still only supports a single image scale. A multi-scale ob-ject detector is demonstrated on an FPGA in [14] that can process 1080HD at 64 fps. The 18 scales are time-multiplexed across 3 successive frames. As a result, ef-fectively only 6 scales are processed per frame. It should be noted that these hardware implementations have rel-atively large on-chip memory sizes (e.g., [13] uses 1.22 Mbit on ASIC, [14] uses 7 Mbit on FPGA), which con-tributes to increased hardware cost.

Thus, from the previous discussion, none of the ex-isting implementations satisfies all the desired require-ments for accurate and robust object detection in em-bedded systems, which include real-time, high resolu-tion (1080HD), high frame rate (>30 fps), multiple im-age scale, low power and low hardware costs.

3 Overview of the HOG algorithm

Fig. 2 shows a block diagram of the steps involved in object detection using HOG features as presented in [6]. The image is divided into non-overlapping 8×8 pixels patches called cells, where gradients are calculated at each pixel. A histogram of the gradient orientations with 9 bins is generated for each cell. The histogram is then normalized by its neighboring cells to increase robustness to texture and illumination variation. For each cell, the normalization is performed across blocks of 2×2 cells resulting in a final 36-D HOG feature vec-tor.

The HOG feature vector is extracted for cells in a predefined detection window. In this work, the detec-tion window is chosen to be 128×64 pixels which is suit-able for pedestrian detection [6]. This window sweeps the entire image with non-overlapping cells. A conven-tional way to perform detection is by training a sup-port vector machine (SVM) [15] classifier for the prede-fined detection window size. The classifier has the same dimension as the detection window. The classification output is referred to as a score, and is compared to a threshold to make a detection decision. This operation is repeated as the detection window sweeps the image. As mentioned in Section 1, scaling is an important factor in object detection algorithms since there is no prior knowledge about object size/distance from cam-era. Generally, and since most of the features are not scale invariant, there are two methods to perform multi-scale detection. The first naive approach is to have mul-tiple SVM classifiers, each trained for the same object at a different size. In this case, the weights of the differ-ent SVM classifiers must be determined and a unique detector is used for each size. This approach is rarely used because it increases the complexity of the training process where multiple classifiers have to be trained. In addition to that, and from the hardware point of view, these classifiers coefficients have to be stored on-chip and it is shown later in this work that the SVM weights memory consumes a significant amount of power.

The second approach, which is conventionally used in object detectors [2] and is carried out in this work, is to have only one SVM classifier for one detection window size, and to generate an image pyramid com-posed of multiple scaled versions of the same frame, which is then processed by the same detector as shown in Fig. 3. In this approach, small objects can be de-tected in the high resolution scales while large objects can be detected in the low resolution scales, all with the same classifier. The ratio between the dimensions of successive scales in the image pyramid is called the scale factor.

Fig. 3 Image pyramid with multiple scales. Processing all scales with the same SVM template can detect objects of different sizes.

Fig. 4 Precision-Recall curves for INRIA person dataset [5] using different scaling factors: single scale (AP=0.166), scale factor of 2 (AP=0.275), scale factor of 1.2 (AP=0.391), and scale factor of 1.05 (AP=0.401, used in the original HOG algorithm [6]).

The precision-recall curve shown in Fig. 4 is one method to measure the detection accuracy. Increasing the number of processed scales, by reducing the scale factor, increases the Average Precision (AP)1_{from 0.166}

with single scale to 0.401 with scale factor of 1.05 (44 scales per 1080HD frame). However, this comes at the cost of increased computation in terms of generating the image pyramid and processing the newly generated pixels for each scale.

4 Hardware Architecture

In this work, a cell-based approach is used where one cell is processed at each stage of the architecture. There

1 _{Average precision measures the area under precision}

re-call curve. Higher average precision means better detection accuracy.

Fig. 5 Scanning order in reading the pixels from a frame (1080HD for this example). (a) Row raster scan. (b) Column raster scan.

are various orders in which the cells of a 2-D image can be processed by the object detection hardware. The fol-lowing two orders were examined as shown in Fig. 5: raster scan in row order and raster scan in column order. While the processing order does not affect the detection accuracy, it does impact the size of the on-chip memory in the hardware. Note that the compu-tation pipeline of the object detection core, consisting of the detector and the scale generator, is the same for both vertical and horizontal scans; only the memory controller and memory sizes change. In the following sections, an architecture based on column raster scan will be discussed. In Section 7.3, a detailed hardware comparison between the two approaches is presented.

4.1 Detector

The detector can be divided into HOG feature extrac-tion and SVM classificaextrac-tion. The feature extracextrac-tion shown in Fig. 6 includes cell histogram generation, the his-togram buffer, and hishis-togram normalization. The SVM classification shown in Fig. 9 includes multiply-and-accumulate (MAC) units, the accumulation buffer, and the SVM weights buffer.

4.1.1 HOG feature extraction

Fig. 6 shows the block diagram of the HOG feature extraction unit. It is composed of two key blocks: cell histogram generation and histogram normalization. In the cell histogram generation, a gradient filter [-1 0 1] is used to generate a pair of horizontal and vertical gradients at each pixel in the 8×8 input cell2_{. The}

ori-entation and the magnitude of the gradient are then calculated from this pair, and a histogram of 9 bins is generated for the cell. To reduce the implementation cost, the following approximations were performed:

– Orientation: We carried out the orientation binning scheme similar to [11, 16]. As the orientation is only used to choose the histogram bin, the actual angle of the gradient does not need to be calculated. The limit angles for each bin are known constants (θi), as

shown in Fig. 7. Each gradient bin can be calculated using constant multiplications rather than complex computation to calculate the actual gradient angle. – Magnitude: Computing the L2-norm gradient mag-nitude similar to what is used in [6] requires a square root operation which is complex to implement in hardware. An L1-norm magnitude, which doesn’t require a square root, is used in this work instead. L1-norm and L2-norm are not linearly dependent but they are strongly correlated. The overall detec-tion accuracy does not degrade with the L1-norm magnitude, which suggests that HOG feature is less sensitive to the gradient magnitude and more sensi-tive to the gradient orientation.

As shown in Fig. 2, each cell requires its neighbor-ing 8 cells to create four overlapped blocks for normal-ization. Accordingly, the 9-bin cell histogram must be stored in a line buffer so that it can be used to compute the normalized histogram with respect to the different blocks. The buffer stores 3 columns of cell histograms. Each histogram bin requires 14-bit, resulting in a total of 126-bit per a cell histogram.

The normalization is then done by dividing the 9-bin histogram by the energy (L2-norm) of each of the four overlapped blocks. Unlike the gradient magnitude, us-ing L1-norm here to compute the block energy results in about 5% degradation in performance [6]. The L2-norm is computed from sum of square of the histogram bins across the four corresponding cells for each block. The square root is then taken using a simple non-restoring square root module; which is time shared across the four blocks. Finally, 9 sequential fixed point dividers

2 _{Different gradient filters are tested in [6] like 1-D, cubic,}

3×3 Sobel as well as 2×2 diagonal filters. Simple 1-D [-1 0 1] filter works the best.

Fig. 6 Block diagram of HOG feature extraction with average input and output bandwidths.

Fig. 7 Histogram bins can be calculated without the actual value of the gradient angle. In the shown example, the pixel is assigned to bin 2 if the shown inequality has been satisfied. Note that (θi) is constant for all i’s.

are used (one per bin) to generate the normalized HOG feature. These fixed-point dividers are customized to exploit the fact that the normalized values are always fractions (i.e., there is no integer part in the division output). Based on simulations, the bit-width for each normalized bin is chosen to be 9-bit to maintain the detection accuracy. After normalization, the output is a 36-D vector representing the HOG feature.

4.1.2 SVM Classification

In this work, a linear SVM classifier is trained off-line and its weights are loaded to an on-chip buffer, so that the detector can be configured for different objects. The bit-width of the SVM weights is reduced to minimize both size and bandwidth of the on-chip buffer. The 4,608 SVM weights (representing 128×64 pixels per de-tection window) are quantized to a 4-bit signed fixed-point, with a total memory size of 0.018 Mbit.

Fig. 8 Example of a shared cell across overlapped windows. 8×4 cells per window are shown for simplicity.

An on-the-fly approach similar to [13] is carried out for classification. The HOG feature of each cell is imme-diately used for classification once it is extracted so that it is never buffered or recomputed. This reduces on-chip memory requirements and external memory bandwidth as each pixel is only read once from the off-chip frame buffer. All calculations that require the HOG feature must be completed before it is thrown away. Fig. 8 shows a simple example, with a small detection win-dow size of 8×4 cells, of how several detection winwin-dows share a cell. Each cell effectively appears, and must be accumulated, at all positions in overlapped detection windows. For a 128×64 pixels detection window, each cell is shared with (16×8 = 128) windows, but at dif-ferent positions within each window.

The on-the-fly classification block is shown in Fig. 9. The processing is done using a collection of MACs. Each MAC contains two multipliers and one adder to com-pute a partial dot product of 2 values of the detection window features and the SVM weights, and another

Fig. 9 Block diagram of the on-the-fly SVM classification unit.

adder to accumulate the partial dot products. Thus, it takes 18 cycles to accumulate all 36 dimensions for a given cell position. Two columns of cells, out of the eight columns in the detection window, are processed in parallel, requiring 16×2 MACs. Accordingly, 18×4 cy-cles are required to complete the 4,608 multiplications for the whole detection window. Using this approach, the 17-bit accumulation values are stored instead of the HOG features (36×9-bit), resulting in a 19× reduction in the required buffer size.

4.2 Scale Generator

A scale generator is used to generate the image pyra-mid, as shown in Fig. 3. The key blocks required to gen-erate the pyramid include low pass filters, down sam-plers, pixel line buffers and interpolators as shown in Fig. 10.

4.2.1 Scale Factor Selection

There is a trade-off in selecting the scale factor between the detection accuracy and the number of cells to pro-cess. Table 1 shows an exponential increase in the num-ber of cells per frame as more scales are used (i.e., re-ducing the scale factor). Using a scale factor of 1.05 in the baseline implementation [6] increases the workload by more than 10× compared to a single scale. In this work, a scale factor of 1.2 is chosen as it introduces only 0.01 reduction in AP, with an increase of only 3.2× in the workload. For a 1080HD frame and a scale factor of 1.2, 12 scales per frame are required in the image pyra-mid. This careful selection of the scale factor results in a 3.3× reduction in the number of cells generated per frame compared to the baseline implementation.

Table. 1 Scale factor effect on detection accuracy, with num-ber of cells per 1080HD frame in the image pyramid. AP numbers are calculated on the INRIA person dataset [5].

Scale Factor AP Scales Cells Increase Single-scale 0.166 1 32,400 1.0× 2 0.275 4 43,030 1.3× 1.4 0.337 7 65,530 2.0× 1.3 0.372 9 78,660 2.4× 1.2 0.391 12 104,740 3.2× 1.1 0.398 23 184,450 5.7× 1.05 0.401 44 344,220 10.6×

4.2.2 Scale Generation Architecture

Fig. 10 shows a block diagram of the scale generator module. Pixels are streamed-in once from the off-chip frame buffer. Low pass filters are used to process the pixels to prevent aliasing before downsampling by two and by four, generating two octaves. The original and the two octaves images are partially stored in on-chip line buffers. The buffers store 25 columns of pixels of each image, which is sufficient to generate the different scales. The buffers are shared across scales within the same octave.

As shown in Fig. 10, the 12 required scales are gener-ated as follows: the fifth and ninth scales, which ideally would have a scaling factor of 2.07 and 4.3 respectively, are approximated to be the octaves (i.e. scale factors of 2 and 4 respectively) to reduce number of calcula-tions. Using bilinear interpolation, three scales are gen-erated from each octave with scale factors of 1.2, 1.44 and 1.73. The bilinear interpolation for the scaled im-age generation begins as soon as the supporting pixels are available in the shared pixel line buffers. An on-the-fly interpolation is used so that a minimum number of pixels is buffered before interpolation. The generated scales are passed directly to feature extraction module and no scaled images are stored on-chip after interpo-lation.

5 Parallelism and Voltage Scaling

Multi-scale detection increases the power consumption relative to single-scale due to the scale generation over-head and the processing of the additional scales. If a sin-gle detector is used, clock frequency and voltage must be increased to process these additional scales while maintaining the same throughput. Thus in this work, multiple parallel detectors are used in order to reduce the clock frequency and voltage while maintaining the same throughput.

Three different configurations are tested for the par-allel detectors architecture: one, three and five

detec-Fig. 10 Scale generation architecture with average input and output bandwidths.

tors. Fig. 11 shows the trade-off between area, power and throughput in each architecture using column raster scan mode. On the left of Fig. 11, the supply voltage is held constant at 0.72V, and a throughput of 30, 60, and 80 fps is achieved by the one, three and five detec-tors respectively. On the right of Fig. 11, the through-put is held constant at 60 fps, and the supply voltage is varied for each configuration to evaluate the energy consumption. To achieve a constant 60 fps throughput, the supply voltage must be increased to 1.1 V for the one-detector configuration, and can be decreased to 0.6 V for the five-detector configuration. As expected, large energy reduction is achieved by using three parallel de-tectors compared to a single detector due to voltage scaling. Although the five-detector architecture gives a slightly lower energy point, the three-detector architec-ture is selected because it offers a better energy versus area trade-off. The same behavior is expected regardless of cell processing order.

A simple replication of the hardware to implement the parallel detectors results in extra area and power consumption, which can be avoided. The parallel de-tectors are using the same SVM template to detect one object. As a result, a separate buffer for SVM weights in each detector means replicating information and wast-ing memory area and bandwidth. In this architecture, the detectors are carefully synchronized such that they share the same SVM weights at any moment. This en-ables using only one buffer for SVM weights for all de-tectors, which results in 3× reduction in memory size and bandwidth, and 20% reduction in the overall sys-tem power.

Fig. 12 shows the overall detection system. The pix-els from the 12 scales are distributed to three

paral-Fig. 11 Throughput with constant supply voltage of 0.72 V (left) and energy with constant throughput of 1080HD at 60 fps (right) for the three different detectors configurations.3

lel detectors. The distribution is done such that the three detectors have balanced workloads. The original HD scale is passed to Detector (1), the next 2 scales to Detector (2), and the remaining 9 scales to Detec-tor (3). All three detecDetec-tors are identical except that the size of the histogram and the accumulator buffers are different based on the number and the size of the scales processed by each detector. The exact memory sizes in each detector are shown in Table 5. With three paral-lel detectors and voltage scaling, a 3.4× energy saving is achieved compared to a single detector as shown in Fig. 11.

3 _{The energy numbers for 0.6 V and 1.1 V supplies are}

estimated from a ring oscillator voltage versus power and fre-quency curves. SRAM minimum voltage is 0.72 V.

Fig. 12 Object detection system architecture.

Fig. 13 Pedestrian image with the corresponding trained SVM template in (a) original and (b) gradient magnitude rep-resentations. Image is taken from INRIA person dataset [5].

6 Image Pre-processing

Image pre-processing can reduce the overhead cost of generating the scales, with minor impact on the detec-tion accuracy.

6.1 Coarse Resolution of Pixel Intensity

The size of the pixel line buffers used in the scale gen-erator block is about half of the overall system mem-ory size. One way to reduce the size of these buffers is to quantize the pixel intensity below the conventional 8-bit. This also reduces the logic of the multipliers in the interpolation block. Fig. 15 shows the AP versus the pixel intensity bit-width (dashed line). Because the HOG feature is fairly robust to quantization noise, the intensity can be quantized down to 4-bit with an AP loss of only 0.015. Going from 8-bit to 4-bit pixel inten-sity results in a 50% reduction in the pixel line buffers size. However, this can be further reduced as discussed in the next section.

Fig. 14 Histogram of pixel intensities. Left column shows 8-bit bit-width. Right column shows coarse quantization.

6.2 Detection on Gradient Image

The detection accuracy mainly depends on the features being able to capture the main characteristics of the ob-ject. Since the HOG feature is a function of edge orien-tations, it should have consistent detection performance on other image representations that preserve edge ori-entations. Fig. 13 shows two representations of the same pedestrian: the left is the original intensity image, and the right is the gradient magnitude image. The gradi-ents are calculated using a simple [-1 0 1] filter. Edges that compose the pedestrian contour are visible in both images. To further demonstrate that detection on gradi-ent magnitude images is reasonable, Fig. 13 shows also the trained SVM templates on both original and gradi-ent magnitude training images. Both templates capture similar pedestrian characteristics (e.g. head, shoulders, legs).

The motivation behind processing gradient magni-tude images is to further reduce the pixel intensity bit-width, and to reduce the switching activity in the hard-ware because the gradient magnitude image is usually more sparse. Fig. 14 shows the intensity histograms for the original and the gradient magnitude represen-tations of an example image. The original image pix-els intensities are well distributed across the whole dy-namic range of 8-bit. However in the gradient magni-tude image, most of the pixels intensities are concen-trated around low values and do not cover the whole dynamic range. Thus, the gradient magnitude image can use fewer bits per pixel because of the dynamic range reduction.

Fig. 15 shows that the original images give a 0.02 better AP at high pixel intensity bit-width compared

Fig. 15 Average precision (AP) values versus pixel resolu-tion for both original and gradient magnitude images.

to the gradient magnitude images (solid line). At 4-bit, both original and gradient magnitude images have the same AP. Reducing the bit-width to 3-bit in gradient magnitude images approximately maintains the same AP and has a 25% smaller pixel line buffer size.

The image pre-processing results in a 24% reduc-tion in the overall system power. The area and power breakdown for both 8-bit original image and 3-bit gra-dient magnitude image detectors are shown in Table 2. The pre-processing required for the gradient magnitude image detection architecture introduces very small area and power overhead. However, it results in a 45% power reduction in the scale generator block. The pixel line buffers size is reduced from 0.363 Mbit to 0.136 Mbit. Smaller multipliers are used in the interpolation unit, resulting in 30% area saving. The detector power is also reduced by 20% due to smaller subtractors and accu-mulators in the histogram generation unit, and due to the reduction in switching activity in the data-path.

7 Results

As mentioned in section 4, this architecture is cell-based where one cell is processed at each stage in the pipeline. Fig. 16 shows a timing diagram of the detection pipeline with different top level modules. These modules are running in parallel as shown and each one is processing a different cell at a time in unit time intervals of 78 cycles. Number of cycles is balanced between modules to reduce idle times and maximize throughput. Each module is pipelined internally as well to maximize the operating clock frequency.

Table. 2 Area and power breakdown for object detector ar-chitecture for both original and gradient magnitude images. Numbers are based on post-layout simulations with 45nm SOI CMOS process. Original Gradient Area (kgates) Pre-proc. n/a 7 Scale Gen. 240 167 Detector 1 90 86 Detector 2 102 100 Detector 3 133 130 Total 565 490 Power (mW) Pre-proc. n/a 0.5 Scale Gen. 17.10 9.30 Detector 1 13.10 10.10 Detector 2 11.60 9.50 Detector 3 10.15 8.05 SVM mem. 7.85 7.85 Total 59.80 45.30

Fig. 17 AP, power and memory sizes for different object detection architectures. (A) Single-scale with one detector at 0.6 V. (B) scale with one detector at 1.1 V. (C) Multi-scale with three parallel detectors at 0.72 V. (D) Multi-Multi-scale with three parallel detectors and pre-processing at 0.72 V.4

Fig. 16 Detection architecture pipeline with number of cycles required by each module.

Table. 3 Optimized fixed point bit-width.

Parameter Sign Integer Fraction Gradient magnitude 0 8 0 Cell histogram bin 0 14 0 Block energy 0 26 0 HOG feature bin 0 0 9 SVM weights 1 0 3 SVM accumulator 1 3 13

7.1 Detection Accuracy

The INRIA person dataset [5] was used to evaluate the impact of the modified parameters on the detec-tion accuracy. These modificadetec-tions include: using L1-norm for the gradient magnitude, fixed-point numbers representation (shown in Table 3), approximating the image pyramid with a scale factor of 1.2, and image pre-processing. Our implementation, which supports multi-scale detection, without pre-processing is close to the original HOG algorithm [6] with 0.389 AP compared to 0.4. With pre-processing, our implementation gives 0.369 AP.

7.2 Architectural and algorithmic optimization results Fig. 17 shows the design space of the detection accu-racy, the memory size and the power numbers for dif-ferent architectures at the same throughput (1080HD video at 60 fps). Our three main contributions can be shown as follows:

1. Introducing multi-scale detection boosts the detec-tion accuracy by 2.4×. The overhead of the image pyramid generation and the processing of the new scales results in 14× increase in power and 8.8× in-crease in memory size compared to a single detector (A to B in Fig. 17).

4 _{Energy numbers for 0.6 V and 1.1 V supplies are}

esti-mated from a ring oscillator voltage versus power and fre-quency curves. SRAM minimum voltage is 0.72 V.

2. Parallelism reduces the power by 3.4× due to volt-age and frequency reduction without affecting the detection accuracy. No change in the memory size is achieved (B to C Fig. 17).

3. Image pre-processing reduces multi-scale memory and processing overhead, resulting in a 24% over-all power reduction and a 25% overover-all memory size reduction (C to D in Fig. 17).

7.3 Image Scanning Order

As discussed in Section 4, two scan modes can be imple-mented; column and row raster scans. Both modes use similar architecture and layout floorplan. The only dif-ference is the on-chip buffers size and their correspond-ing address decoder logic. Row line buffers are used in row raster scan architecture and column line buffers are used in column raster scan architecture. Row raster scan results in higher memory size because usually the frame width is larger than its height. For example, the ratio between 1080HD frame width to its height is 16:9; thus a column raster scan would reduce the memory size by approximately 16₉×. However, if we account for the fact that cameras typically output pixels in row raster scan order, processing the cells in the same order will reduce latency and additional memory controller com-plexity to reorder pixels from row to column order. The decision of processing order will depend on the overall system design parameters, such as camera specification. Table 4 shows a comparison between the two archi-tectures with memory size numbers. Comparing row to column raster scans, the scale generator and the his-togram buffers have an increase of 1.8× in their sizes, which is approximately the ratio between the width and the height of a 1080HD frame. The SVM buffer size doesn’t change because it stores the same SVM tem-plate in both cases. The accumulator buffers on the other hand have double the increase with 3.6×. The difference is that the accumulator buffers change from storing 8 columns of the partial dot product values in the column raster scan architecture to storing 16 rows

Table. 4 Comparison between the memory size in column raster scan and row raster scan architectures. Memory size in (Mbit).

Column scan Row scan Scale Generator 0.136 0.243 Detectors Histogram 0.289 0.520 Accumulator 0.095 0.340 SVM Memory 0.018 0.018 Total 0.538 1.121

Fig. 18 Layout of the object detector core (column scan architecture).

in the row raster scan architecture. The numbers 8 and 16 are the detection window width and height respec-tively. The overall on-chip memory size increase from column to row raster scan architectures is about 2×.

7.4 Post-layout Results

The core layout of the column scan mode architecture is shown in Fig. 18. Area and power breakdown for the main computation blocks of the overall system is shown in Fig. 19. The classification and the SVM buffer con-sume about 50% of the system power. The remaining 50% of the power is divided between the feature extrac-tion and the scale generaextrac-tion. Although the SVM buffer has a relatively smaller size compared to the memo-ries in the scale generation and the feature extraction blocks, it consumes large power due to its high band-width. Table 5 shows a breakdown of various memory blocks size and bandwidth. Note that the SVM weights buffer has a zero write bandwidth, assuming that the template weights are loaded only at the beginning of the detection process and never changed.

Table 6 shows a comparison between this work with both scan modes and the ASIC implementation in [13]. Both designs can process 1080HD videos. To be able to process 30 fps, the design in [13] has dual cores process-ing only one scale, resultprocess-ing in poor detection accuracy. In this work, a 6.4× increase in throughput is required relative to [13]: 3.2× to support multi-scale and 2× to support 60 fps rather than 30 fps in [13]. Although this work supports multi-scale detection, the size of the on-chip memory is only 0.538 Mbit in the column raster scan architecture. Doubling the memory size in the row

Fig. 19 Area and power breakdowns for the overall column scan object detection system.

raster scan architecture still gives a comparable mem-ory size. Comparing column and row raster scan ar-chitectures, 30% increase in power is reported for row raster scan, mainly because of the increase in on-chip memory size.

8 Conclusion

Multi-scale support is essential for robust and accu-rate detection. However, without any architectural op-timization, the scale generation and processing would result in a 14× power consumption increase, which is a concern for energy-constrained applications. An effi-cient architecture is presented in this work to generate the image pyramid. Parallelism and voltage scaling re-sult in a 3.4× power reduction. Image pre-processing reduces the scales generation overhead, and results in 24% reduction in the overall system power. Two types of image scan modes are presented, column and row raster scans. Using 45nm SOI CMOS ASIC technology at a supply voltage of 0.72 V, this design can process 1080HD video at 60 fps, with a total power consump-tion of 45.3 mW and 58.5 mW for column and row raster scan architectures respectively.

Acknowledgements Funding for this research was provided by Texas Instruments and the DARPA YFA grant N66001-14-1-4039. The authors would like to thank Xilinx University Program (XUP) for equipment donation.

References

1. Haltakov, V., Belzner, H., Ilic, S. (2012). Scene under-standing from a moving camera for object detection and free space estimation. In Proceedings IEEE Intelligent Ve-hicles Symposium (pp. 105–110).

5 _{AP number is not reported in [13]. This number is from}

Table. 5 The size and the bandwidth of different memories in the design.

Block Size Dimension Bandwidth (MB/s) (Mbit) address × word Read Write Scale generator Pixel buffer 1 0.078 1088×75 980 255 Pixel buffer 2 0.039 544×75 Pixel buffer 3 0.019 272×75 Histogram buffer Detector 1 0.055 2048×28 1,009 112 Detector 2 0.080 3040×28 Detector 3 0.154 5760×28 Accumulator Detector 1 0.018 544×17 (×2) 1,743 1,743 Detector 2 0.027 832×17 (×2) Detector 3 0.050 1536×17 (×2) SVM weights 0.018 144×128 7,776 0

Table. 6 Comparison between this work (three time-shared parallel detectors, with image pre-processing) and the imple-mentation in [13].

[13] This work Column Row CMOS Technology 65nm 45nm SOI Area (mm2_{) 3.3×1.2 2.8×0.96 3.2×1.08}

Gate count (kgates) 502 490 498 Memory size (Mbit) 1.220 0.538 1.121 Image resolution 1920x1080 1920x1080 Frequency 42.9 MHz 270 MHz Frame rate 30 fps 60 fps Scales 1 12 Supply 0.7 V 0.72 V Power (mW) 40.3 45.3 58.5 Energy (nJ/pixel) 0.648 0.364 0.470 AP 0.1665 _0.369

2. Dollar, P., Wojek, C., Schiele, B., Perona, P. (2012). Pedes-trian Detection: An Evaluation of the State of the Art. IEEE Transactions on Pattern Analysis and Machine In-telligence, 34(4), 743–761.

3. Meingast, M., Geyer, C., Sastry, S. (2004). Vision based terrain recovery for landing unmanned aerial vehicles. In Proceedings IEEE Conference on Decision and Control (Vol. 2, pp. 1670–1675).

4. Myers, B., Burns, J., Ratell, J. (2001). Embedded Elec-tronics in Electro-Mechanical Systems for Automotive Ap-plications. SAE Technical Paper (2001-01-0691).

5. INRIA Person Dataset for Pedestrian Detection. http://pascal.inrialpes.fr/data/human/.

6. Dalal, N. & Triggs, B. (2005). Histograms of oriented gra-dients for human detection. In Proceedings IEEE Com-puter Society Conference on ComCom-puter Vision and Pattern Recognition (Vol. 1, pp. 886–893).

7. Dollar, P., Belongie, S., Perona, P. (2010). The Fastest Pedestrian Detector in the West. In Proceedings of the British Machine Vision Conference (pp. 68.1–68.11). 8. Jinwook, O., Gyeonghoon, K., Injoon, H., Junyoung, P.,

Seungjin, L., Joo-Young, K., Jeong-Ho, W., Hoi-Jun, Y. (2012). Low-Power, Real-Time Object-Recognition Proces-sors for Mobile Vision Systems. IEEE Micro, 32(6), pp. 38–50.

9. Wei, Z., Zelinsky, G., Samaras, D. (2007). Real-time Accu-rate Object Detection using Multiple Resolutions. In Pro-ceedings IEEE International Conference on Computer Vi-sion (pp. 1–8).

10. Benenson, R., Mathias, M., Timofte, R., Van Gool, L. (2012). Pedestrian detection at 100 frames per second. In Proceedings IEEE Conference on Computer Vision and Pattern Recognition (pp. 2903–2910).

11. Bauer, S., Kohler, S., Doll, K., Brunsmann, U. (2010). FPGA-GPU architecture for kernel SVM pedestrian detec-tion. In Proceedings IEEE Computer Society Conference on Computer Vision and Pattern Recognition Workshops (pp. 61–68).

12. Mizuno, K., Terachi, Y., Takagi, K., Izumi, S., Kawaguchi, H., Yoshimoto, M. (2012). Architectural Study of HOG Feature Extraction Processor for Real-Time Ob-ject Detection. In Proceedings IEEE Workshop on Signal Processing Systems (pp. 197–202).

13. Takagi, K., Mizuno, K., Izumi, S., Kawaguchi, H., Yoshi-moto, M. (2013). A sub-100-milliwatt dual-core HOG ac-celerator VLSI for real-time multiple object detection. In Proceedings IEEE International Conference on Acoustics, Speech and Signal Processing (pp. 2533–2537).

14. Hahnle, M., Saxen, F., Hisung, M., Brunsmann, U., Doll, K. (2013). FPGA-Based Real-Time Pedestrian Detection on High-Resolution Images. In Proceedings IEEE Confer-ence on Computer Vision and Pattern Recognition Work-shops (pp. 629–635).

15. Cortes, C. & Vapnik, V. (1995). Support-Vector Net-works. Journal of Machine Learning, 20(3), 273–297. 16. Cao, T. & Deng, G. (2008). Real-Time Vision-Based Stop

Sign Detection System on FPGA. In Proceedings Digital Image Computing: Techniques and Applications (pp. 465– 471).
