1 1 E0NN537BA COVER Assy., Hydraulic Lift, Includes: Cover & Ref. 2 & 3 (Prod Date) after 01-JAN-1975;
1 1 E0NN537CB COVER Assy., Hydraulic Lift, 3900, 4100, 4600, 515, 532,
420, 535, Includes: Cover & Ref. 2 & 3 (Prod Date) after 01-JAN-1975;
1 1 D6NN537B COVER Assy., Hydraulic Lift, W/Breather Hole, 2600N,
2600V, 3600N, 3600V, Includes: Cover & Ref. 2 & 3 (Prod Date) after 01-JAN-1975;
2 1 D3NN997A VALVE SEAT Seat, Check Valve
(Prod Date) after 01-JAN-1975;
2 1 D3NN997B SEAT Check Valve Oversize Used to Service Covers
Stamped O/S
(Prod Date) 01-JAN-1975-31-MAR-1976;
2 1 D6NN997A SEAT/SLOT Seat, Check Valve .020 O/S
(Prod Date) after 01-APR-1976; 3 1 9992069 O-RING,0.07" Thk x 0.614" ID, -16, Cl 6, 90 Duro -016, 90 Duro, .614" ID x .070" Thk
(Prod Date) after 01-JAN-1975; 4 4 86050212 BOLT,Hex, 7/16" - 14 x 1 1/2", Gr 8 Screw, Cap, HH, G8, 7/16"-14 x 1-1/2"
(Prod Date) after 01-JAN-1975;
(Prod Date) after 01-JAN-1975;
6 3 379414S2 BOLT Hex, 7/16"-20 x 1-3/4"
(Prod Date) after 01-JAN-1975; 7 1 280541 BOLT,Hex, 7/16" - 14 x 2", Gr 8 Screw, Cap, HH, G8, 7/16"-14 x 2"
(Prod Date) after 01-JAN-1975; 8 3 81834248 BOLT,Hex, 7/16" - 14 x 3 1/4" Screw, Cap, HH, G8, 7/16"-14 x 3-1/4"
(Prod Date) after 01-JAN-1975;
9 4 70929014 SCREW Cap, HH, G8, 7/16"-14 x 3-1/2"
(Prod Date) after 01-JAN-1975;
10 1 380313S36 STUD G8, 7/16"-14-20 x 1-3/4"
(Prod Date) after 01-JAN-1975;
11 1 D3NN669A PIN Plunger Guide
(Prod Date) after 01-JAN-1975;
12 1 E7NN502AA GASKET Cover
(Prod Date) after 01-JAN-1975;
13 1 C5NN475B COVER Assy., Accessory, Includes: Cover & Ref. 14 & 15
(Prod Date) after 01-JAN-1975;
15 1 C5NNN991B SEAL
(Prod Date) after 01-JAN-1975; 16 5 229317 O-RING,0.103" Thk x 0.549" ID, -113, Cl 6, 90 Duro -113, 90 Duro, .549" ID x .103" Thk
(Prod Date) after 01-JAN-1975; 17 1 272217 O-RING,0.07" Thk x 0.426" ID, -13, Cl 6, 90 Duro 90 Duro, .426" ID x .070" Thk
(Prod Date) after 01-JAN-1975; 18 1 9992298 O-RING,0.07" Thk x 0.489" ID, -14, Cl 6, 90 Duro 90 Duro, .489" ID x .070" Thk
(Prod Date) after 01-JAN-1975; 19 1 218774 O-RING,0.103" Thk x 1.174" ID, -123, Cl 6, 90 Duro 90 Duro, 1.174" ID x .103" Thk (Prod Date) after 01-JAN-1975; 20 2 81834248 BOLT,Hex, 7/16" - 14 x 3 1/4" Screw, Cap, HH, G8, 7/16"-14 x 3-1/4"
(Prod Date) after 01-JAN-1975;
21 1 304777S36 SCREW Cap, HH, G5, 5/16"-18 x 1-5/8"
(Prod Date) after 01-JAN-1975;
22 2 379409S36 BOLT Hex, 7/16"-14 x 1.37
(Prod Date) after 01-JAN-1975;
23 1 E1NNM897AA SHAFT Hydraulic Lift
(Prod Date) after 01-JAN-1975;
(Prod Date) after 01-JAN-1975;
1 C7NN517C SHAFT Lift Control Lever, 2600N, 3600N
(Prod Date) after 01-JAN-1975;
1 E0NN517AA SHAFT 4100, 4600NO
(Prod Date) after 01-JAN-1981;
24 1 87011S94 O-RING .469" ID x .070" Thk, Except 2600N, 2600V, 3600N,
3600V
(Prod Date) after 01-JAN-1975;
25 1 74175S WOODRUFF KEY,#6, 5/32" x 5/8", HT Key, Woodruff , 2600N, 2600V, 3600N, 3600V #6, 5/32" x 5/8", HT
(Prod Date) after 01-JAN-1975;
26 1 D3NNF982A SUPPORT Quadrant
(Prod Date) after 01-JAN-1975;
26 1 E0NNF982AA SUPPORT Quadrant, 2600N, 2600V,3600N, 3600V
(Prod Date) after 01-JAN-1981;
27 1 957E532 GASKET Support or
(S/N Range) Quadrant-Cover; (Prod Date) after 01-JAN-1975;
29 2 9706729 BOLT,Hex, 7/16" - 14 x 1", Gr 5, Full Thd
(Prod Date) after 01-JAN-1975;
30 1 C7NNA611A WASHER Lift Shaft Cup, Except 2600N, 2600V, 3600N, 3600V
(Prod Date) after 01-JAN-1975; 30 1 81541 WASHER,0.5" ID x 1.25" OD x 0.08" Thk 2600N, 2600V, 3600N, 3600V 7/16"
(Prod Date) after 01-JAN-1975;
31 1 E1ADDN522B COMPRESSION SPRING,Compression, 16.77mm
OD x 7.87mm L Spring
(Prod Date) after 01-JAN-1975;
32 1 34422S7 NUT Lock, 7/16"-20
(Prod Date) after 01-JAN-1975;
33 2 83977032 DISC,15.75mm ID x 76.2mm OD x 5.33mm Thk Friction, Except 2600N, 2600V, 3600N, 3600V (Prod Date) after 01-JAN-1975;
33 2 E9N518 DISC Friction, Except 2600N, 2600V, 3600, 3600V, FTO-E
(Prod Date) after 01-JAN-1975; 33 1 86574207 WASHER,16mm ID x 50mm OD x 5.23mm Thk Friction, 2600V, 3600V
(Prod Date) after 01-JAN-1975;
33 1 E9N518 DISC Friction, 2600N, 3600N
34 1 D3NN516A PLATE Friction, Except 2600N, 2600V, 3600N, 3600V (Prod Date) after 01-JAN-1975;
34 1 83930487 PLATE Friction, 4100N, 4100NO, 4600N, 4600NO
(Prod Date) after 01-JAN-1981;
35 AR 81837134 SPACER Except 2600N, 2600V, 3600N, 3600V (Replaces
D3NNJ977A)
(Prod Date) after 01-JAN-1975;
36 2 80680 LOCK WASHER,3/8 0.381 CST ZND WASHER, LOCK, , Except 2600N, 2600V, 3600N, 3600V 3/8"
(Prod Date) after 01-JAN-1975;
37 2 88011 BOLT,Hex, 3/8" - 16 x 1 1/4", Gr 5 Except 2600N, 2600V, 3600N, 3600V Hex, 3/8"-16 x 1 1/4", G5, Full Thd
(Prod Date) after 01-JAN-1975;
38 1 D3NNN625A SECTOR Quadrant Assy., Lift Control, Except 2600N, 2600V,
3600N, 3600V
(Prod Date) after 01-JAN-1975;
39 2 56701S2 SCREW Cap, Flg Hd, Pilot Pt, G5, 1/4"-20 x 1/2", Except
2600N, 2600V, 3600N, 3600V (Prod Date) after 01-JAN-1975;
40 1 D3NNB505B HANDLE Assy., Lift Draft Control Except 2600N, 2600V,
40 1 E0NNB505AB11L HANDLE Assy., 4100N, 4100NO, 4600N, 4600NO (Prod Date) after 01-JAN-1981;
40A 1 E0NNL892AA KNOB
(Prod Date) after 01-JAN-1975;
41 1 D3NND943B HANDLE Assy., Lift Position Control, Except 2600N, 2600V,
3600N, 3600V
(Prod Date) after 01-JAN-1975;
41 1 E0NND943AB11L HANDLE Assy., 4100N, 4100NO, 4600N, 4600NO
(Prod Date) after 01-JAN-1981;
42 1 81846067 STOP Lift Control Lever, Except 2600N, 2600V, 3600N,
3600V
(Prod Date) after 01-JAN-1975;
43 1 81844747 KNOB Lever Stop, Except 2600N, 2600V, 3600N, 3600V
(Prod Date) after 01-JAN-1975;
44 1 34464S36 NUT Tee, 1/4"-20, Except 2600N, 2600V, 3600N, 3600V
(Prod Date) after 01-JAN-1975;
45 1 C5NN515E CONTROL Quadrant Assy., Lift Control, 2600N, 3600N
(Prod Date) after 01-JAN-1975;
46 1 86533178 LEVER & Friction Plate Assy, Control, 2600N, 3600N
47 1 C7NNA953C STOP Assy., Control Lever, 2600N, 3600N (Prod Date) after 01-JAN-1975;
1 957E499C RETAINER Lever to Quadrant, 2600N, 3600N
(Prod Date) after 01-JAN-1975; 48 1 80701 WASHER,0.31" ID x 0.73" OD x 0.07" Thk 2600N, 3600N 1/4"
(Prod Date) after 01-JAN-1975;
49 1 350890S36 WING NUT,1/4"-28 NUT, WING, , 2600N, 3600N 1/4"-28
(Prod Date) after 01-JAN-1975;
50 1 C7NN515A SECTOR Qaudrant Assy., Control, 2600V, 3600V
(Prod Date) after 01-JAN-1975;
51 2 80680 LOCK WASHER,3/8 0.381 CST ZND WASHER, LOCK, , 2600V, 3600V 3/8"
(Prod Date) after 01-JAN-1975;
52 2 9628503 NUT,3/8" - 16, Gr 5 G5, 3/8"-16, 2600V, 3600V
(Prod Date) after 01-JAN-1975;
53 2 88011 BOLT,Hex, 3/8" - 16 x 1 1/4", Gr 5 2600V, 3600V Hex, 3/8"-16 x 1 1/4", G5, Full Thd (Prod Date) after 01-JAN-1975;
54 1 E440GB9 BALL Lever, 2600V, 3600V
(Prod Date) after 01-JAN-1975;
56 1 C7NNG960A PIN Lever, 2600V, 3600V
(Prod Date) after 01-JAN-1975;
57 1 80680 LOCK WASHER,3/8 0.381 CST ZND WASHER, LOCK, , 2600V, 3600V 3/8"
(Prod Date) after 01-JAN-1975;
58 1 9628503 NUT,3/8" - 16, Gr 5 G5, 3/8"-16, 2600V, 3600V
(Prod Date) after 01-JAN-1975;
59 1 C7NNA953A STOP Lever, Stop, 2600V, 3600V
(Prod Date) after 01-JAN-1975;
60 1 350890S36 WING NUT,1/4"-28 NUT, WING, , 2600V, 3600V 1/4"-28
(Prod Date) after 01-JAN-1975;
61 1 C7NNG959A ROD Assy., Lift Control, 2600V, 3600V
(Prod Date) after 01-JAN-1975;
62 1 97411S36 CIRCLIP,3/8" 2600V, 3600V 3/8"
(Prod Date) after 01-JAN-1975;
63 1 97012S36 CLEVIS 5/16"-24 x 2-1/4", 2600V, 3600V
(Prod Date) after 01-JAN-1975;
64 1 C7NN514A ARM & Friction Plate Assy., Lift, 2600V, 3600V
65 1 354493S8 PIN Clevis, 5/16" x 1-3/16", 2600V, 3600V (Prod Date) after 01-JAN-1975;
66 1 87394 COTTER PIN,1/8" x 1/2" PIN, SPLIT (COTTER), , 2600V, 3600V 1/8" x 1/2" (Prod Date) after 01-JAN-1975;
67 1 C7NNN878A FLANGE Quadrant, 2600V, 3600V
(Prod Date) after 01-JAN-1975;
68 1 D4NN686B LEVER Pisition Control Selector, 2600N, 2600V, 3600N,
3600V
(Prod Date) after 01-JAN-1975;
69 1 87336 LOCK PIN,5.05mm OD x 22.22mm L, Slotted Pin, , 2600N, 2600V, 3600N, 3600V 3/16" x 7/8", Slotted
(Prod Date) after 01-JAN-1975;
70 1 957E832 PLUG Check Valve
(Prod Date) after 01-JAN-1975;
71 1 D3NNN860A HOUSING Spring
(Prod Date) after 01-JAN-1975; 72 1 87035S95 O-RING,0.103" Thk x 0.612" ID, -114, Cl 6, 90 Duro 90 Duro, .625" ID x .103" Thk
(Prod Date) after 01-JAN-1975;
74 1 351666S BALL 15/32 Dia.
(Prod Date) after 01-JAN-1975;
75 1 C5NN546A YOKE 2600, 233, 231, 531
(Prod Date) 01-JAN-1975-30-SEP-1979;
76 1 C5NNN547A SPRING Draft Control, 2600, 233, 231, 531
(Prod Date) 01-JAN-1975-30-SEP-1979;
77 1 957E525 DRIVER SEAT Seat, Spring, 2600, 233, 231, 531
(Prod Date) 01-JAN-1975-30-SEP-1979;
78 1 C5NNN528A SEAL Rubber Spring, 2600, 233, 231, 531
(Prod Date) 01-JAN-1975-30-SEP-1979;
79 1 E9N529 FELT SEAL Felt, Seat Spring, 2600, 233, 231, 531
(Prod Date) 01-JAN-1975-30-SEP-1979;
80 1 C5NN670A PLATE Cover, 2600,233, 231, 531
(Prod Date) 01-JAN-1975-30-SEP-1979;
81 3 81547 LOCK WASHER,7/16" WASHER, LOCK, , 2600, 233, 231, 531 7/16"
(Prod Date) 01-JAN-1975-30-SEP-1979;
82 3 83909101 FLANGE BOLT,Hex, 7/16" - 14 x 1 1/4" Cap, Flg Hd., G5, 7/16"-14 x 1-1/4", Plate to Cover, 2600, 233, 231, 531
83 1 81815672 YOKE,5/8" - 24 Except 2600, 233, 231 531 (Prod Date) after 01-JAN-1975;
83 1 81815672 YOKE,5/8" - 24 2600, 233, 231, 531
(Prod Date) after 01-OCT-1979;
84 1 81815737 HOUSING Spring, Except 2600, 233, 231, 531
(Prod Date) after 01-JAN-1975;
84 1 81815737 HOUSING Spring, 2600,233,231,531
(Prod Date) after 01-OCT-1979;
85 3 81547 LOCK WASHER,7/16" WASHER, LOCK, , Except 2600, 233, 231, 531 7/16"
(Prod Date) after 01-JAN-1975;
85 3 81547 LOCK WASHER,7/16" WASHER, LOCK, , 2600, 233, 231, 531 7/16"
(Prod Date) after 01-OCT-1979; 86 2 280747 BOLT,Hex, 7/16" - 14 x 1 3/4", Gr 5
(Prod Date) after 01-JAN-1975;
86 1 D5NN4N033A BOLT Hex, Breather, 7/16"-14 x 1-1/8", 2600, 231, 233,
531
(Prod Date) after 01-JAN-1975;
86 1 D5NN4N033A BOLT Hex W/Hole, Breather, 7/16"-14 x 1-3/4", 4600,
87 1 81816029 SEAT Seal, Draft Control, Except 2600, 233, 231, 531 (Prod Date) after 01-JAN-1975;
87 1 81816029 SEAT Seal, Draft Control, 2600, 233, 231, 531
(Prod Date) after 01-OCT-1979;
88 1 C5NN547B SPRING 3600, 333, 335
(Prod Date) after 01-JAN-1975;
88 1 C5NN547B SPRING 2600, 233, 231, 531
(Prod Date) after 01-OCT-1979;
88 1 81801610 SPRING 3900, 4100, 4600, 535, 420, 515, 532
(Prod Date) after 01-JAN-1975;
89 AR 81802007 SHIM,26.16mm ID x 50.8mm OD x 0.39mm Thk .0145/.0155, Except 2600, 233, 231, 531 (Prod Date) after 01-JAN-1975;
89 1 81802007 SHIM,26.16mm ID x 50.8mm OD x 0.39mm Thk .0145/.0155, 2600, 233, 231, 531 (Prod Date) after 01-OCT-1979;
89 AR C5NNK834C SHIM .0195/.0205, Except 2600, 233, 231, 531
(Prod Date) after 01-JAN-1975;
89 1 C5NNK834C SHIM .0195/.0205, 2600, 233, 231, 531
(Prod Date) after 01-OCT-1979;
(Prod Date) after 01-JAN-1975; 89 1 C5NNK834D SHIM,26.16mm ID x 50.8mm OD x 0.65mm Thk .0245/.0255, 2600, 233, 231, 531
(Prod Date) after 01-OCT-1979;
89A AR C5NND975A SPACER Tension Lockout, Service Only, 3600, 4100, 4600,
3900
(Prod Date) after 01-JAN-1975;
89A 1 C5NND975A SPACER Tension Lockout, Service Only, 2600, 233, 231, 531
(Prod Date) after 01-OCT-1979;
90 1 C5NN525B DRIVER SEAT Seat, Spring, Except 2600, 233, 231, 531
(Prod Date) after 01-JAN-1975;
91 1 E9NN541AA ROD Plunger, Draft Control
(Prod Date) after 01-JAN-1975;
90 1 C5NN525B DRIVER SEAT Seat, Spring, 2600, 233, 231, 531
