JAAS Java Authentication and Authorization Services

(1)

Java is a trademark and Java 2 is a registered trademark of Sun Microsystems Inc.

JAAS

Java Authentication

and Authorization

Services

Bruce A Rich

Java Security Lead

IBM/Tivoli Systems

(2)

Java, Java 2 are trademarks or

registered trademarks of Sun

Microsystems Inc.

Windows 2000 is a registered

trademark of Microsoft

Trademarks

(3)

JAAS fundamentals

JAAS case study with Kerberos

Backup materials

Java2 security model

JAAS and J2EE relationships

Talk Outline

(4)

JAAS fundamentals

(5)

Add the concept of "user identity" to

the Java 2 security model

Enable existing security services to

plug in

Compatibly extend the current

model

What is JAAS?

(6)

Key elements

Authentication framework

Assertion of identity

Enhanced authorization

Low level of binding between

authentication and authorization

(7)

Authentication framework

Policy-based

Generic and abstract

Sufficient for today's mechanisms,

extensible

Pluggable, stackable

Key abstractions

Subject - any user of computing

Collection of Principals, credentials

Principal (java.security)

(8)

Assertion of identity

Avoids incompatible behavior

Lexically scopes identity

Logically associates Subject with current

Thread

(9)

Enhanced Authorization

Augmentation of current Permission

specification

Principal-based

Any authentication with any Permission

Example in Kerberos section

(10)

Local or remote code (signed or unsigned) Domain A JVM Sandbox Resources Domain C Domain B Security Policy Ability to grant specific permissions

to a particular piece of code

about accessing specific resources on the client, depending on the signer of the code

and/or the location from which the code was loaded.

Java 2 Security Model

(11)

Java 2 Permission Model

Class A's Protection Domain

Class A

SecureClassLoader

POLICY

Certificate 1

Certificate 2 Code Base URL Code Source Permission 1 Permission 1 Permission 2 ... Permission Collection Permission M ... Protection Domain Certificate N

(12)

Java 2 Authorization Model

Cert 1,I

Cert 1,2 Code Base URL Code Source ... Permission Collection ... Cert 1,N Cert 2,1

Cert 2,2 Code Base URL Code Source

...

Cert 2,N

Cert K,1

Cert K,2 Code Base URL Code Source ... Cert K,N Class 1 Class 2

...

Class K

...

Permission to check 1 2 K Perm 1,1 Perm 1,2 Perm 1,M1 ... Perm 2,1 Perm 2,2 Perm 2,M2 ... Perm K,1 Perm K,2 Perm K,M_K Permission Collection Permission Collection

(13)

JAAS Authorization Model

Class A's Protection Domain Class A

SecureClassLoader

POLICY

Certificate 1

Certificate 2 _{Code Base}

URL Code Source Permission 1 Permission 1 Permission 2 ... Permission Collection Permission M ... Protection Domain Certificate N Permission 1 Permission 2 ... Permission Collection Permission M

Subject Y's Protection Domain

POLICY

(14)

JAAS

(15)

Building blocks

LoginModule

5 methods

New java.security.Principal subclass

Allows granting Permissions based on

this new Principal class

Possibly some "credentials" related to

Principal

(16)

Kerberos Authentication

Using JAAS

KerberosUserPrincipal

Allows permissions based on this

authentication technique

KerberosTGTCredential

Allows further service acquisition without

requiring password

(17)

KerberosUserPrincipal

public class KerberosUserPrincipal extends Principal

{

private String name;

// user name

public KerberosUserPrincipal(String userName) {

name = userName

}

public String getName() {

return name;

}

. . .

(18)

KerberosTGTCredential

public class KerberosTGTCredential extends Object

{

private KrbCreds creds;

public KerberosTGTCredential(KrbCreds creds) {

this.creds = creds

};

public KrbCreds getCreds() {

return creds;

}

. . .

}

(19)

KerberosLoginModule

public KerberosLoginModule extends LoginModule { private KerberosUserPrincipal kup;

private KerberosTGTCredential ktc; private Subject subj;

public void initialize (Subject s...) { subj=s; ... } public boolean login() {

if (callbackHandler == null) { // no way to get parameters??? } else {

get username, pw, realm;

authenticate, remember kup and tkc; }

}

public boolean commit() {

subj.getPrincipals.add(kup);

subj.getPublicCredentials.add(ktc);

}

(20)

If in a Windows 2000 domain, already have a Kerberos ticket, but how to use from Java?

New wrinkle for KerberosLoginModule LSACallAuthenticationPackage

KerbRetrieveEncodedTicketMessage + lots of JNI magic

=== KerberosTGTCredential for current Subject

Windows 2000 Interoperability

(21)

Permissions using Kerberos

grant signedBy "mykey", codeBase "file:E:/Solutions/app/*"

principal

com.ibm.security.auth.KerberosUserPrincipal "brich"

{

permission com.ebank.AccountAccess "CloseAccount"; };

(22)

Configuring to use Kerberos

testKerberosAL {

com.ibm.security.auth.KerberosLoginModule required debug=true;

};...login configuration file

...

LoginContext lc = new LoginContext("testKerberosAL"); lc.login();

Subject whoami = lc.getSubject();

Subject.doAs(lc.getSubject(), someActionInstance); ...

(23)

Summary

JAAS extends base security

model to accomodate concept

of "users"

Pluggable, extensible

Kerberos provides an excellent

illustration of the power and

ease of using JAAS to extend

application security

(24)

Resources

Java 2 Network Security

Marco Pistoia, et al, Prentice Hall, 1999, ISBN 0-13-015592-6

Java and Internet Security

Shrader, Rich, Nadalin, IUniverse, 2000, ISBN 0-595-13500-5

http://www.research.ibm.com/compsci/security/javasec/ http://java.sun.com/security

http://java.sun.com/products/jaas

http://www.ietf.org/rfc/rfc1510.txt, Kerberos V5 http://www.ietf.org/rfc/rfc2743.txt, GSS V2

(25)

Java is a trademark and Java 2 is a registered trademark of Sun Microsystems Inc.

Backup Materials

(26)

Java 2 Standard

Edition Security:

Review

(27)

CodeSource

Combination of a set of Signers

(certificates) and a code base

URL

Certificate 1

Certificate 2 Code Base

URL

CodeSource

...

(28)

Policy

A

Permission

is an access right

to a protected resource

In Java 2, Permissions are

stored in the

Policy

object

The reference implementation

is file based

(29)

Sample Java 2 Policy

grant

entries

Describe Permissions

granted to CodeSources

An entry may contain one or

more Permissions

grant signedBy "mykey", codeBase "file:E:/mydir/app/*" {

permission java.lang.RuntimePermission "queuePrintJob";

(30)

ProtectionDomain

A

ProtectionDomain

contains:

A CodeSource

The Permissions granted to the

CodeSource

SecureClassLoader assigns a

ProtectionDomain to each loaded class

Classes with different CodeSources belong

to different ProtectionDomains

Certificate 1

Certificate 2 _{Code Base}

URL Permission 1 Permission 1 Permission 2

...

Permission M

...

Certificate N

(31)

Classes, ProtectionDomains &

Permissions

Each class is assigned to only one

ProtectionDomain

As determined by its CodeSource

Each ProtectionDomain may include

zero or more Permissions

Multiple classes from the same

CodeSource are assigned the same

ProtectionDomain

(32)

. . .

/*

Check to see if the calling

code is authorized.

If not, a SecurityException

(AccessControlException) will be

thrown

*/

AccessController.checkPermission(

new RuntimePermission("queuePrintJob"));

Example of Guard on

Protected Resource

(33)

O'Reilly Conference on Enterprise Java March 26-29, 2001

import java.security.*; class GetProperty {

public static void main(String[] args) { try {

if (args.length > 0) {

String s = System.getProperty(args[0],"name " + args[0] + " not specified");

System.out.println(args[0] + " property

value is: " + s);

} else {

System.out.println("Property name

required");

} }

catch(Exception e){

System.err.println("Caught exception " + e.toString());

} } }

The GetProperty Example

(34)

Each thread in the JVM contains a

number of

stack frames

Each stack frame contains the

method instance variables for a

method called in the current thread

A

thread of execution

may:

Occur completely within a single

protection domain

May involve application

ProtectionDomain(s) and the

system ProtectionDomain

Threads of Execution in Java

(35)

Check of Current Thread

1. AccessController is in the system ProtectionDomain – Permission is implicitly granted

Proceed to the next frame on the thread stack

2. SecurityManager is in the system ProtectionDomain – Permission is implicitly granted

Proceed to the next frame on the thread stack

3. System is in the system ProtectionDomain – Permission is implicitly granted

Proceed to the next frame on the thread stack

4. GetProperty is in the application domain – Is the permission granted?

If yes, then proceed to the next frame on the thread stack If no, throw a SecurityException

java.security.AccessController.checkPermission() java.lang.SecurityManager.checkPropertyAccess()

GetProperty.main() java.lang.System.getProperty()

Calling hierarchy checkPermission()

(36)

Determining the Permission

Set of a Thread

The Permission set of a thread is the intersection of all ProtectionDomains traversed by the execution thread ProtectionDomain 1 ProtectionDomain 2 ProtectionDomain K

I

K K i M j K i j i

Perm

, , 2 , 1 , , 2 , 1 , = =

(37)

P1

ProtectionDomain for Class1 = { P1, P3 }

P3

Authorization - Permissions

Class1.methodA calls Class2.methodB

P2

P3

checkPermission(P1) fails checkPermission(P2) fails checkPermission(P3) succeeds

(38)

Authorization - Permissions

Class1.methodA calls Class2.methodB Calls AccessController.doPrivileged() Class2.methodC

P1

P3

P2

checkPermission(P1) fails

(39)

Class1.methodA calls doPrivileged(AccessControlContext({P3,P4})) calls Class2.methodB

P1

P3

P2

P4

AccessControlContext = {P3, P4} ProtectionDomain for Class1 = { P1, P3 }

checkPermission(P3) succeeds

(40)

Lexical Scoping of

Privilege Modification

How privileged code works

Why it is necessary

Algorithm for run-time access control

(41)

Why Privileged Code?

Application System utility An application is not allowed to access font files The system utility to display a document must obtain those fonts on behalf of the user The application is temporarily enabled to access the font files

(42)

The Privileged Code

Mechanism

doPrivileged() annotates the stack frame

AccessController.checkPermission() stops Permission testing at this stack frame

ProtectionDomain for the class and all the classes that it calls are checked

ProtectionDomain of its callers are not checked

Caller class – Permission testing not performed Class called – Permission testing performed Caller class – Permission testing not performed

Class called – Permission testing performed testing Class called – Permission testing performed

(43)

Example Privileged Code

Must use

java.security.PrivilegedAction

interface

The run() method contains code needing

privilege

AccessController.doPrivileged()

Takes

PrivilegedAction

object argument

Invokes its

run()

method

(44)

Example - Anonymous

Inner Class

someMethod() {

// some normal code here...

AccessController.doPrivileged(new PrivilegedAction() {

public Object run() {

// privileged code goes here, for example:

System.loadLibrary("awt");

return null; // nothing to return

} }

);

(45)

For each class on the thread stack: Get the class's ProtectionDomain If the stack frame is annotated by a doPrivileged(),

Exit the loop

If the last stack frame checked is not annotated with by a doPrivileged(),

Add the ProtectionDomains inherited by the current thread when the current thread was instantiated

AccessController Algorithm -

Stage 1

(46)

If no ProtectionDomains from step1,

Return (only fully trusted code is running)

For each unique ProtectionDomain P obtained in

stage 1,

Call P's implies() method with the Permission

Does P imply the Permission being checked?

If no, Throw an exception Else, Continue

AccessController Algorithm -

Stage 2

Check each ProtectionDomain to see whether

it contains the Permission being checked

(47)

Policy based

Uses a "principal" extension

Lexically scoped

Subject.doAs() & doAsPrivileged take a

PrivilegedAction /

PrivilegedExceptionAction as an

argument

But, no doPrivileged() mark

Authorization algorithm unmodified

JAAS / J2SE Authorization

Relationship

(48)

Sample JAAS Policy

Consists of

grant

entries

Describe Permissions granted to

CodeSources

and

Principals

Each entry may contain one or

more Permissions

grant signedBy "mykey", codeBase "file:E:/Solutions/app/*"

principal com.esite.WebPrincipal "George" {

permission java.lang.RuntimePermission "queuePrintJob"; };

(49)

Sample JAAS Policy -

Roles

"Roles" can be assigned to

Subjects

Authorization performed based

on "Role" assigned to subject

grant signedBy "mykey", codeBase "file:E:/Solutions/app/*"

principal com.eDMV.MethodRole "DMVSupervisor" {

permission com.ebank.AccountAccess "CloseAccount"; };

(50)

Example doAs()

Lexically scoped Subject

. . .

// Authenticate user & build a Subject wUser

. . .

// Switch to the authenticated user

Subject.doAs(wUser, new PrivilegedAction() { public Object Run(){

// Work to be done as wUser requiring

// the addition of the user's privileges return processUserRequest();

}

} // end of PrivilegedAction );

(51)

Subject.doAs() Effect

Extends the effective

ProtectionDomains of methods

called after the Subject.doAs()

call

(52)

Example scenario

Thread / Class

Permissions

Effective Thread

Permission

Class 1

Class 2

Class 3

Class 4

{ P1, P2 }

{ P1, P3 }

{ P2 }

{ P1, P5 }

{ P1, P2 }

{ P1 }

checkPermission(P1)

fails

P

3

P

c2 3

P

c3 3

P

= { }

{ }

(53)

Augmented with doAs()

Thread / Class

Permissions

Effective Thread

Permission

Class 1

Class 2

Class 3

Class 4

{ P1, P2 }

{ P1, P3 }

{ P2,

P1, P4

}

{ P1, P5,

P4

}

{ P1, P2 }

{ P1 }

doAs(X)

{

P1, P4

}

{

P1

}

checkPermission(P1)

succeeds!

{

P1

}

P

c1

3

P

c2

3

(P

c3

U P

X

)

3

(P

c4

U P

X

) = { P1 }

(54)

Another doAs() scenario

Thread / Class

Permissions

Effective Thread

Permission

Class 1

Class 2

{ P1, P2 }

{ P1,

P2, P3

}

{ P1, P2 }

doAs(X)

{

P2, P3

}

{ P1,

P2

}

checkPermission(P2)

succeeds!

P

3

(P

U P

) = { P1, P2 }

(55)

Another doAs() scenario

(con't)

Thread / Class

Permissions

Effective Thread

Permission

Class 1

Class 2

{ P1, P2 }

{ P1,

P2, P3

}

{ P1, P2 }

doAs(X)

{

P2, P3

}

{ P1,

P2

}

Class 2 { P1,

P3

}

doAs(Y)

{

P1, P3

}

{ P1 }

checkPermission(P2)

fails!

P

c13

(P

c2

UP

X

)

3

(P

c2

UP

Y

)={P1}

(56)

Summary

Subject.doAs() extends the

ProtectionDomains of all classes / methods

which the PrivilegedAction object calls

The basic CodeSource authorization

algorithm is unmodified

Subsequent Subject.doAs() calls replace

the Subject in the authorization algorithm

(57)

Java is a trademark and Java 2 is a registered trademark of Sun Microsystems Inc.

JAAS

and

EJBs

(58)

EJB Roles

Enterprise Bean Provider Application Assembler Deployer

System Administrator EJB Server Provider EJB Container Provider

(59)

Development/Deployment

Process

Enterprise Bean

Providers

Application

Assembler

Deployer

System

Administrator

(60)

JAAS->EJB security

Containers implement security

JAAS is a reasonable building block EJB security built around "roles" JAAS built around "Principal"s Mapping required/possible

(61)

Identity (Principal) Mapping

Front-end authenticated principal can be mapped to principal required by back-end systems

Credential Mapping

Used when application server’s and backend support different authentication domains

i.e. PKI to Kerberos

Principal to EJB security role mapping

JAAS->EJB security (cont)

(62)

Exploiting J2SE Security

(1/4)

How can J2SE mechanisms perform

container-based authentication / authorization ? JAAS login modules perform principal

authentication

JAAS principal created

Maps authenticated principal to EJB role(s) EJB method authorization is based on

(63)

Example: Role as principals :

Mapping of principal to "role principals" happens in the JAAS login module

isCallerInRole() looks for the appropriate EJB role principal in the in the current thread

Typically, does the current caller have permission for this method?

Method dispatch authorization tests check, via checkPermission(), the corresponding

MethodPermission JAAS-like Syntax: grant MethodPermission(ejb.account.withdraw) to RolePrincipal(customer) grant MethodPermission(ejb.loan.borrow) to RolePrincipal(customer)

Exploiting J2SE Security

(64)

(3/4)

Example: Role as Permissions:

Given principal-to-roles map, assign permissions for all roles to this principal

Mapping takes place "statically" in the authorization policy definition

Potential problems:

Treats a role both as a principal and a permission

Is dependent on a mapping from method permission from a role permission

JAAS-like Syntax

grant RolePermission(customer) to sam

grant MethodPermission(ejb.account.withdraw) to RolePrincipal(customer)

(65)

Exploiting J2SE Security

(4/4)

Example: Role as collection of permissions and credential

Role is granted a collection of permissions

isCallerInRole() done by checking if caller has access to appropriate RolePermission

collection

Individual method permission test performed by searching the Role permission collections,

granted to the subject, for a method permissions that matches desired operation

JAAS-like Syntax

define RolePermission (customer) as {

MethodPermission(ejb.account.withdraw) MethodPermission(ejb.loan.borrow)

... }
