G.E Device Summary for Frame 9E

(1)

A4

29/08/2011

31/08/2011

HELFER THOMAS

PAQUES DIDIER

PANAROTTO ELVIO

PAQUES DIDIER

HELFER THOMAS

VALIDE

NOMENCLATURE.APP.CONTROLE

DEVICE SUMMARY

GE Official

(2)

Ce document, propriété exclusive de

GE Energy Products France SNC est strictement confidentiel. Il ne peut être communiqué, copié ou

reproduit sans notre autorisation écrite préalable. This document, exclusive property of GE Energy Products France SNC is strictly confidential.

It must not be communicated, copied or

reproduced without our prior written consent.

_{First made for}

_{: 9171E}

ITEM :

0414

UNLESS OTHERWISE SPECIFIED NAMES DATE

DIMENSIONS ARE IN MM [INCHES] TOLERANCES ON: 1 [2] PL DECIMALS + DRAWN

T. Helfer

13/10/09 CHECKED

D. Pâques

13/10/09

Attention : Don’t modify this document without any update of the database P414.

Attention : Ne pas modifier ce document sans mise à jour de la base P414.

EACH SECTION SHALL BE REVISED IN

ITS ENTIRETY.

ALL SHEETS OF EACH SECTION ARE

THE SAME REVISION LEVEL AS

INDICATED IN THE REVISION

BLOCK

SECTION

NO. OF

SHEETS

REV

INDEX

1 C

01EN

28 C

01FR

28 C

REV

DESCRIPTION

NAMES

DATE

SIGNATURES

A

First issue

T. Helfer

13/10/2009

D. Pâques

P. Janin

B

IM-2010005556

T. Helfer

16/09/2010

D. Pâques

P. Kleinprintz

C

IM-2011005753

(DCI 11019816)

T. Helfer

26/08/2011

D. Pâques

E. Panarotto

(3)

REVISIONS

Rev

Description

A

First issue

B

- P&ID 0471 : Number change : 227D1412 instead of 219D2887

- P&ID 0462 : characteristics modification of devices 33WN-8, 90WN-1 and VPR62-1

(4)

Abbreviations

Descriptions

AA

Atomizing Air

ACF

Control Filter Downstream Pressure

AD

Compressor Discharge Air

AE

Extraction Air

AMF

Lube Oil Filter Downstream Pressure

DEC.

Decreasing

DPDT

Double pole, double throw

DPG

Differential Pressure Gauge

FC

Fail safe to close

FO

Fail open

GF

Gas Fuel

GFV

Gas Fuel Vent

GPL

Gas Valve Stem Packaging Leakoff

INC.

Increasing

LVDT

Linear variable differential transformer

MLI

Model List Item : four digit code used by General Electric to identify

components, assembly, drawings or specifications, example : MLI 0414 for

Device Summary

NC

Normally closed

NO

Normally open

Normal

Means absolute zero energy level, such as no power, no oil, no speed, no

temperature

OD

Oil Drain

OD

Oil drain above oil tank level

OD

Oil drain below oil tank level

OH

Control Oil High Pressure

OHT

Trip Oil High Pressure

OL

Lube Oil

OLV

Lube Oil Event

OR

Regulated Lube Oil

PC

Piping connecting point

Safety

Safety Integrity Level (a cross means the device belong to a safety loop

_{to personnel safety). Do not modify devices or settings of any safety loop.}

Slope

The arrow direction indicates the liquid gravitational drainage due to the slope

SPDT

Single pole, double throw

SPST

Single pole, single throw

WD

Water Drain

WF

Water Feed

WR

Water Return

(5)

Wiring diagram

Description

ACCY

The device is in the accessories wiring diagram (MLI 401A)

AIR

The device is in the cooling fan module wiring diagram (MLI A132)

AIR DRY

The device is in the air dryer module wiring diagram (MLI 1049)

CHROM

The device is in the chromatograph module wiring diagram (MLI G023)

CLEAN

The device is in the cleaning module wiring diagram (MLI E026)

CO2

The device is in the CO2 fire protection module wiring diagram (MLI A068)

ENCL-G

The device is in the gas enclosure interface drawing (MLI 1195)

ENCL-LF

The device is in the liquid fuel / atomizing air / water injection module enclosure interface drawing (MLI

1152)

ENCL-LO

The device is in the lube oil / fuel gas module enclosure interface drawing (MLI 1137)

ENCL-T

The device is in the turbine enclosure interface drawing (MLI 1113)

ENCL-V

The device is in the ventilation enclosure interface drawing (MLI 1643)

ENCL-WI

The device is in the water injection enclosure interface drawing (MLI 1196)

FILT

The device is in the air filter wiring diagram (MLI A040)

FG-SSOV

The device is in the fuel gas, SSOV & vent module wiring diagram (MLI G064)

GAS

The device is in the gas module wiring diagram (MLI 0991 or 401G)

GAS HEAT

The device is in the gas heating and treatment system wiring diagram (MLI G025)

GENE

The device is in the generator wiring diagram

IBH

The device is in the bleed heating wiring diagram (MLI A037)

LF-AA

The device is in the liquid fuel / atomizing air module wiring diagram (MLI A162)

LF-AA-WI

The device is in the liquid fuel / atomizing air / water injection module wiring diagram (MLI A162)

LF-SR

The device is in the liquid fuel recirculation skid wiring diagram (MLI 969S)

LF-TR

The device is in the liquid fuel treatment skid wiring diagram (MLI E020)

LF-FD

The device is in the liquid fuel flow devider wiring diagram (MLI 0613)

LF-H

The device is in the liquid fuel heater wiring diagram (MLI E041)

LF-TPH

The device is in the liquid fuel transfert pump&heating skid wiring diagram (MLI E047)

LF-PH

The device is in the liquid fuel pump&heating skid wiring diagram (MLI A245)

LF-FT-PR

The device is in the liquid fuel flow totalizer & pression regulation skid wiring diagram (MLI A246)

LO FG

The device is in the lube oil / fuel gas module wiring diagram (MLI A160)

LOAD

The device is in the load gear wiring diagram (MLI A012)

MIST

The device is in the mist eliminator outline drawing (MLI A098)

OIL

The device is in the lube oil wiring diagram (MLI 0990 or 401H)

STEAM

The device is in the steam injection module wiring diagram (MLI A135)

(6)

WASH

The device is in the water washing module wiring diagram (MLI E025)

WI

The device is in the water injection module wiring diagram (MLI A035)

(7)

System Name

MLI

P&ID

System

Reference

Rev

Control Devices Turbine System

0415

CD

227D1199

A

Lube Oil System

0416

LO

227D1331

F

Cooling and Sealing Air System

0417

CSA

219D2331

C

Instrument Air System

0419

APU

N/A

Cooling Water System

0420

CW

219D2889

D

Starting Means System

0421

SM

205D4866

C

Gas Fuel System

0422

GF

227D1390

C

Liquid Fuel System

0424

LF

227D1347

E

Atomizing Air System

0425

AA

227D1078

D

Fire Protection System

0426

FP

219D2715

B

PP Station Air System

0428

AE

N/A

Steam Injection System

0431

SI

N/A

Inlet Air heating System

0432

IAR

N/A

Hydraulic Supply System

0434

HS

209D7043

C

Heating and Ventilation System

0436

HV

219D2734

C

Turbine and Compressor Cleaning System

0441

TCC

227D1308

A

Turbine and Compressor Washing System

0442

TCW

219D1293

C

Water Injection System

0462

WI

227D1360

A

Compressor Inlet Guide Vanes System

0469

IGV

219D1732

A

Flow Inlet and Exhaust System

0471

IE

227D1412

A

Gas Detection System

0474

GD

209D7635

A

Fuel Purge System

0477

FPU

219D1141

B

Gas Fuel Process System

0482

GFPS

N/A

Nitrogen Injection System

0491

NI

N/A

Performance Monitor System

0492

PM

214D1258

C

Additive Injection Skid System

0494

LFAD

219D1937

B

Interconnections lines System

0969

IL

N/A

(8)

MLI

PID Devices MLI

Wiring

Diagram Safety Designation

0425 20AA-18 918T TURB Solenoid valve for VA18-1 control

Characteristics : Normal : 1 to 3 open ; 2 closed | 0.035 kW | 125 VDC 0425 20AB-1 0922 ACCY Solenoid valve for VA22-1 control

Characteristics : Normal : 1 to 3 open ; 2 closed | 0.035 kW | 125 VDC 0417 20CB-1 1071 TURB Compressor bleed solenoid valve

Characteristics : Normal : B to C Open, A closed | 0.04 kW | 125 VDC 0424 20CF-1 0510 ACCY Fuel pump clutch solenoid

Characteristics : Normal : NO | 125 VDC | 0.16 kW (max) 0422 20FGC-1 0509 GAS Trip solenoid valve for gas control valve (VGC-1)

Characteristics : Normal : NO | 0.0156 kW | 125 VDC 0422 20FGS-1 0507 GAS Fuel gas stop valve solenoid valve

Characteristics : Normal : NO | 0.0156 kW | 125 VDC 0424 20FL-1 0511 ACCY Liquid fuel stop valve solenoid

Characteristics : Normal : NC | 0.02 kW | 125 VDC 0494 20IA-31 E021/E0

48 VAN

Solenoid valve command the VA99-32 valve

Characteristics : Normal : 1 to 2 closed | 12 W | 125 VDC 0441 20KF E026 CLEAN Motor valve cleaning skid

Characteristics : 230 VAC | Normal : NC | 50 hz | 0.045 kW 0441 20KF/PB E026 CLEAN Cleaning skid push button

0424 20PF-100 0961 TURB Purge fuel liquid solenoid valve

Characteristics : Normal : A to P open. B closed | 40 W | 125 VDC

0477 20PG-1 0991 GAS

Solenoid valve for VA13-1 control

Characteristics : Normal : 1 to 3 open ; 2 closed | 0.035 kW | 125 VDC

Settings : A needle-valve is installed upstream of 20PG-1 in order to adjust VA13-1 time opening at 30 seconds

0477 20PG-2 0991 GAS Solenoid valve for VA13-2 control

Characteristics : Normal : 1 to 3 open ; 2 closed | 0.035 kW | 125 VDC 0477 20PL-1 918T TURB Solenoid valve for VA19-1 control

Characteristics : Normal : 1 to 3 open ; 2 closed | 0.035 kW | 125 VDC 0421 20TU-1 0605 ACCY Torque converter fill / drain solenoid valve

Characteristics : Normal : NC

0469 20TV-1 0548 TURB Solenoid valve for compressor IGV trip system Characteristics : Normal : NO | 0.1 kW | 125 VDC 0442 20TW-1 0953 TURB Motor valve off-line compressor water wash

Characteristics : 230 VAC | Normal : NC | 50 hz | 0.072 kW 0442 20TW-2 0983 TURB Motor valve turbine water wash

Characteristics : 230 VAC | Normal : NC | 50 hz | 0.23 kW 0442 20TW-3 0953 TURB Motor valve on-line compressor water wash

Characteristics : 230 VAC | Normal : NC | 50 hz | 0.072 kW 0422 20VG-1 0991 GAS Fuel gas vent solenoid valve

Characteristics : Normal : NO | 0.009 kW | 125 VDC 0477 20VG-2 0991 GAS Gas fuel purge vent solenoid valve

Characteristics : Normal : NO | 0.125 kW | 125 VDC 0462 20WN-1 A035 WI Water injection stop valve solenoid valve

Characteristics : Normal : NO | 0.0112 kW | 125 VDC 0462 20WN-2 A035 WI Water injection stop valve solenoid valve (part of VS2-2)

Characteristics : Normal : NO | 0.0112 kW | 125 VDC 0420 20WN-30 0963 TURB Solenoid valve for fuel check valves cooling water

(9)

PID Diagram

0425 23AB-1 1047 ACCY Anti-condensation heater for motor 88AB-1 Characteristics : 50 hz | 230 VAC | 0.05 kW 0436 23BT-1 1605 ENCL-T Anti-condensation heater for motor 88BT-1

Characteristics : 50 hz | 230 VAC | 0.05 kW 0436 23BT-2 1605 ENCL-T Anti-condensation heater for motor 88BT-2

Characteristics : 50 hz | 230 VAC | 0.05 kW 0421 23CR-1 0603 ACCY Anti-condensation heater for motor 88CR-1

Characteristics : 50 hz | 230 VAC | 0.18 kW 0436 23HA-11 1658 ENCL-G Gas compartment heater

Characteristics : 50 hz | 400 VAC | 3.9 kW 0436 23HA-12 1658 ENCL-G Gas compartment air inlet heater

Characteristics : 50 hz | 400 VAC | 15 kW 0436 23HA-13 1658 ENCL-G Gas compartment air inlet heater

Characteristics : 50 hz | 400 VAC | 15 kW 0436 23HA-30 1113 ENCL-T Auxiliaries compartment heater

Characteristics : 50 hz | 400 VAC | 15 kW 0434 23HQ-1 0628 ACCY Anti-condensation heater for motor 88HQ-1

Characteristics : 50 hz | 230 VAC | 0.05 kW 0436 23HT-30 1113 ENCL-T Turbine compartment heater

Characteristics : 50 hz | 400 VAC | 20 kW 0416 23QA-1 1006 ACCY Anti-condensation heater for motor 88QA-1

Characteristics : 50 hz | 230 VAC | 0.1 kW 0416 23QT-1 0938 ACCY Immersion heater lube oil tank

Characteristics : 50 hz | 400 VAC | 13.0 kW 0416 23QT-2 0938 ACCY Immersion heater lube oil tank

Characteristics : 50 hz | 400 VAC | 13.0 kW 0416 23QV-1A A098 MIST Anti-condensation heater for motor 88QV-1A

Characteristics : 50 hz | 230 VAC | 0.05 kW 0421 23TG-1 0603 ACCY Anti-condensation heater for motor 88TG-1

Characteristics : 50 hz | 230 VAC | 0.05 kW 0417 23TK-1 1233 ACCY Anti-condensation heater for motor 88TK-1

Characteristics : 50 hz | 230 VAC | 0.05 kW 0417 23TK-2 1233/A

132 ACCY

Anti-condensation heater for motor 88TK-2 Characteristics : 50 hz | 230 VAC | 0.05 kW 0436 23VG-1 1605 ENCL-T Anti-condensation heater for motor 88VG-1

Characteristics : 50 hz | 230 VAC | 0.05 kW 0436 23VG-2 1605 ENCL-T Anti-condensation heater for motor 88VG-2

Characteristics : 50 hz | 230 VAC | 0.05 kW Anti-condensation heater for motor 88WN-1

(10)

PID Diagram

0436 23WR-30 1196 ENCL-WI Water injection skid enclosure heater Characteristics : 50 hz | 400 VAC | 9 kW 0471 27TF-1 A040 FILT GT air filter general alarm dispatching 0415 28FD-10 1121 TURB Flame detector combustion chamber n°10 0415 28FD-11 1121 TURB Flame detector combustion chamber n°11 0415 28FD-4 1121 TURB Flame detector combustion chamber n°4 0415 28FD-5 1121 TURB Flame detector combustion chamber n°5 0415 30SG-1 1213 TURB Ignition transformer alarm relay

Characteristics : Normal : NO 0436 33BT-1 1605 ENCL-T

GT compartment ventilation damper limit switch Characteristics : Normal : NO

Settings : Flap closed : limit switch activated, contact closed 0436 33BT-2 1605 ENCL-T

GT compartment ventilation damper limit switch Characteristics : Normal : NO

Settings : Flap closed : limit switch activated, contact closed 0417 33CB-1 1022 TURB

Bleed valve limit switch (11th stage) Characteristics : Normal : NO

Settings : Valve opened : limit switch activated, contact closed 0417 33CB-2 1022 TURB

Settings : Valve opened : limit switch activated, contact closed 0436 33DT-1 1605 ENCL-T

Auxiliaries compartment door limit switch Characteristics : Normal : NO

Settings : Door closed : limit switch activated, contact closed 0436 33DT-11 1658 ENCL-G

Load compartment door limit switch gas compartment Characteristics : Normal : NO

Gas compartment door limit switch Characteristics : Normal : NO

Settings : Door closed : limit switch activated, contact closed 0436 33DT-2 1605 ENCL-T

Auxiliaries compartment door limit switch Characteristics : Normal : NO

Turbine compartment door limit switch Characteristics : Normal : NO

(11)

PID Diagram 0424 33FL-1 0511 ACCY

Liquid fuel stop valve limit switch Characteristics : Normal : NO

Settings : Valve closed : limit switch activated, contact closed 0436 33JS-1 1659 ENCL-WI

Water injection skid enclosure : ventilation damper limit switch Characteristics : Normal : NO

Settings : Flap closed : limit switch activated, contact closed 0436 33JS-2 1659 ENCL-WI

Water injection skid enclosure : ventilation damper limit switch Characteristics : Normal : NO

Settings : Flap closed : limit switch activated, contact closed 0441 33KF-1 E026 CLEAN

Cleaning skid valve limit switch Characteristics : Normal : NO

Settings : Valve closed : limit switch activated, contact closed 0441 33KF-2 E026 CLEAN

Cleaning skid valve limit switch Characteristics : Normal : NO

Settings : Valve opened : limit switch activated, contact closed 0424 33PF-1 0961 TURB

Purge fuel liquid valve limit switch VP-1 Characteristics : Normal : NO

Settings : Valve closed : limit switch activated, contact closed 0477 33PG-1 0991 GAS

VA13-1 close position limit switch Characteristics : Normal : NO

VA13-1 open position limit switch Characteristics : Normal : NO

Settings : Valve opened : limit switch activated, contact closed 0477 33PG-3 0991 GAS

VA13-2 close position limit switch Characteristics : Normal : NO

VA13-2 open position limit switch Characteristics : Normal : NO

Settings : Valve opened : limit switch activated, contact closed 0421 33TC-1 0605 ACCY

Torque converter solenoid valve limit switch Characteristics : Normal : NO

Settings : 20TU-1 de-energized : switch activated, contact closed 0442 33TFD-1 1026 TURB

False start drain valve limit switch Characteristics : Normal : NO

Settings : Valve opened : limit switch activated, contact closed 0421 33TM-5 0605 ACCY

Torque converter low torque limit switch

Characteristics : Normal : NO, switch closed for IGV closed or max torque Settings : Setup at 3 tr of handwheel (full scale 0-242 tr)

0421 33TM-6 0605 ACCY

Torque converter high torque limit switch

Characteristics : Normal : NO, switch closed for IGV closed or max torque Settings : Setup at 242 tr of handwheel (full scale 0-242 tr)

0436 33VG-1 1605 ENCL-T

Load compartment ventilation damper limit switch Characteristics : Normal : NO

Settings : Flap closed : limit switch activated, contact closed 0422 33VG-11 0991 GAS

Gas system vent valve limit switch Characteristics : Normal : NO

Settings : Valve closed : limit switch activated, contact closed 0436 33VG-2 1605 ENCL-T

Load compartment ventilation damper limit switch Characteristics : Normal : NO

Settings : Flap closed : limit switch activated, contact closed 0436 33VL-1 1658 ENCL-G

Gas compartment ventilation damper limit switch Characteristics : Normal : NO

(12)

PID Diagram 0436 33VL-2 1658 ENCL-G

Gas compartment ventilation damper limit switch Characteristics : Normal : NO

Settings : Flap closed : limit switch activated, contact closed 0462 33WN-1 A035 WI

Water injection control valve limit switch (part of VC4-1) Characteristics : Normal : NO

Settings : Valve full opened : limit switch activated, contact closed 0462 33WN-2 A035 WI

Water injection control valve limit switch (part of VC4-1) Characteristics : Normal : NO

Settings : Valve full closed : limit switch activated, contact closed 0462 33WN-3 A035 WI

Water injection stop valve limit switch (part of VS2-1) Characteristics : Normal : NO

Settings : Valve full closed : limit switch activated, contact closed 0462 33WN-7 A035 WI

Settings : Valve full closed : limit switch activated, contact closed 0415 39V-1A 1218 TURB Vibration sensor

Characteristics : For 25.4 mm/s (1 in/s), 150 ± 7.5 mV peak 0415 39V-1B 1218 TURB Vibration sensor

Characteristics : For 25.4 mm/s (1 in/s), 150 ± 7.5 mV peak 0415 39V-2A 1218 TURB Vibration sensor

Characteristics : For 25.4 mm/s (1 in/s), 150 ± 7.5 mV peak 0415 39V-3A 1218 TURB Vibration sensor

Characteristics : For 25.4 mm/s (1 in/s), 150 ± 7.5 mV peak 0415 39V-3B 1218 TURB Vibration sensor

Characteristics : For 25.4 mm/s (1 in/s), 150 ± 7.5 mV peak 0415 39V-CC 1218 TURB

Compressor casing accelerometer

Characteristics : 1.02 mV/m/s2 (10 mV/g) ± 5% 3.94 mV/mm/s ± 5%

0415 39VS-11 235A TURB

Vibration sensor

Characteristics : Output proximitor : 7.87 V/mm (0.2 V/mil) Settings : Gap : 1.4 ± 0.05 mm (0.055 ± 0.002 in)

0415 39VS-12 235A TURB

Vibration sensor

Characteristics : Output proximitor : 7.87 V/mm (0.2 V/mil) Settings : Gap : 1.4 ± 0.05 mm (0.055 ± 0.002 in) 0415 39VS-21 235B TURB

Vibration sensor

0415 39VS-22 235B TURB

Vibration sensor

0415 39VS-23 235B TURB

Vibration sensor

0415 39VS-24 235B TURB

Vibration sensor

(13)

PID Diagram 0415 39VS-31 235C TURB

Vibration sensor

Characteristics : Output proximitor : 7.87 V/mm (0.2 V/mil) Settings : Gap : 1.4 ± 0.05 mm (0.055 ± 0.002 in) 0415 39VS-32 235C TURB

Vibration sensor

Characteristics : Output proximitor : 7.87 V/mm (0.2 V/mil) Settings : Gap : 1.4 ± 0.05 mm (0.055 ± 0.002 in) 0426 43CP-1 1113 ENCL-T Break glass unit auxiliaries compartment access door

Characteristics : Normal : NO

0426 43CP-2 1113 ENCL-T Break glass unit GT compartment access door Characteristics : Normal : NO

0426 43CP-3 1153 ENCL-T Break glass unit auxiliaries compartment access door Characteristics : Normal : NO

0426 43CP-4 1113 ENCL-T Break glass unit GT compartment access door Characteristics : Normal : NO

0426 43CP-5 1113 ENCL-T Break glass unit load compartment access door Characteristics : Normal : NO

0426 43CP-6 1195 ENCL-G Break glass unit gas compartment access door Characteristics : Normal : NO

0426 43CP-7 1195 ENCL-G Break glass unit gas compartment access door Characteristics : Normal : NO

0442 43TW-1/PB 1105 TURB Off-line water wash push button Characteristics : Normal : NO 0442 43TW-2/PB 1105 TURB Turbine water wash push button

Characteristics : Normal : NO 0426 45FA-10A 1113 ENCL-T

Thermostatic fire detector auxiliaries compartment Characteristics : Normal : NO

Settings : Closed : 163 ± 14°C (325 ± 25°F) 0426 45FA-10B 1113 ENCL-T

Settings : Closed : 163 ± 14°C (325 ± 25°F) 0426 45FA-11A 1113 ENCL-T

Settings : Closed : 163 ± 14°C (325 ± 25°F) 0426 45FA-1A 1104 ACCY

(14)

PID Diagram 0426 45FA-1B 1104 ACCY

Settings : Closed : 163 ± 14°C (325 ± 25°F) 0426 45FA-2A 1104 ACCY

Settings : Closed : 163 ± 14°C (325 ± 25°F) 0426 45FA-2B 1104 ACCY

Settings : Closed : 163 ± 14°C (325 ± 25°F) 0426 45FA-6A 0991 GAS

Thermostatic fire detector gas compartment Characteristics : Normal : NO

Settings : Closed : 163 ± 14°C (325 ± 25°F) 0426 45FA-6B 0991 GAS

Settings : Closed : 163 ± 14°C (325 ± 25°F) 0426 45FA-7A 0991 GAS

Settings : Closed : 163 ± 14°C (325 ± 25°F) 0426 45FA-7B 0991 GAS

Settings : Closed : 163 ± 14°C (325 ± 25°F) 0426 45FT-1A 1103 TURB

Thermostatic fire detector GT compartment Characteristics : Normal : NO

Settings : Closed : 316 ± 14°C (600 ± 25°F) 0426 45FT-1B 1103 TURB

Thermostatic fire detector load compartment Characteristics : Normal : NO

Settings : Closed : 316 ± 14°C (600 ± 25°F)

0474 45HA-4 1658 ENCL-G Gas detector gas module compartment ventilation duct Characteristics : Range : 0 - 20% LEL

(15)

PID Diagram

0474 45HT-1 1113 TURB Gas detector turbine compartment Characteristics : Range : 0 - 20% LEL 0474 45HT-2 1113 TURB Gas detector turbine compartment

Characteristics : Range : 0 - 20% LEL 0474 45HT-3 1113 TURB Gas detector turbine compartment

Characteristics : Range : 0 - 20% LEL

0474 45HT-4 1605 ENCL-T Gas detector turbine compartment turbine compartment ventilation duct Characteristics : Range : 0 - 20% LEL

0474 45HT-5 1605 ENCL-T Gas detector turbine compartment ventilation duct Characteristics : Range : 0 - 20% LEL

0474 45HT-6 1605 ENCL-T Gas detector turbine compartment ventilation duct Characteristics : Range : 0 - 20% LEL

0436 49HA-12 1658 ENCL-G

Security thermostat gas compartment heater Characteristics : Normal : NO

Settings : Closed at 100 +0/-16°C (212 +0/-61°F)

0426 5E-10 1113 ENCL-T Emergency stop button located at auxiliary compartment outside GT compartment Characteristics : Normal : NC

0426 5E-11 1113 ENCL-T Emergency stop button located at auxiliary compartment outside GT compartment Characteristics : Normal : NC

0494 63AF-31 E021/E0 48 VAN

Pressure switch of the air circuit Characteristics : Normal : NC Settings :

Increase open at : 3 ± 0.25 bar (43.5 ± 4 psi)

0471 63CA-1 A040 FILT

GT compressed air inlet filter low pressure switch Characteristics : Normal : NO

Settings :

Not adjustable : increase close at : 6 ± 0.5 bar (87 ± 7.25 psi) | Decrease open at : 5.5 ± 0.5 bar (79.77 ± 7.25 psi)

0422 63FG-1 0991 GAS

Gas fuel pressure switch Characteristics : Normal : NC Settings :

Decrease close at : 1.03 ± 0.05 bar (15.0 ± 0.75 psi) |

Not adjustable : increase open at : 2.41 ± 0.05 bar (35.0 ± 0.75 psi)

0422 63FG-2 0991 GAS

Gas fuel pressure switch Characteristics : Normal : NC Settings :

Decrease close at : 1.03 ± 0.05 bar (15.0 ± 0.75 psi) |

Not adjustable : increase open at : 2.41 ± 0.05 bar (35.0 ± 0.75 psi)

0424 63FL-2 0992 ACCY

Liquid fuel pressure switch Characteristics : Normal : NO Settings :

Not adjustable : increase closed at : 2.75 ± 0.14 bar (40 ± 2 psi) | Decrease open at : 2.41 ± 0.07 bar (35 ± 1 psi)

0434 63HF-1 0926 ACCY

Hydraulic filter differential pressure alarm Characteristics : Normal : NC

Settings :

Not adjustable : decrease close at : 2.75 ± 1.03 bar (40 ± 15 psi) | Increase open at : 4.13 ± 0.2 bar (60 ± 3 psi)

(16)

PID Diagram

0434 63HQ-1 0926 ACCY

Low hydraulic supply pressure auxiliary hydraulic pump start Characteristics : Normal : NO

Settings :

Not adjustable : increase close at : 100 ± 3.1 bar (1450 ± 45 psi) | Decrease open at : 93 ± 1.7 bar (1350 ± 25 psi)

0441 63KJ E026 CLEAN

Cleaning skid pressure switch Characteristics : Normal : NC

Settings : Increase open at : 1 ± 0.1 bar (14.5 ± 1.5 psi)

0424 63LF-7 0992 ACCY

Fuel filter differential pressure alarm Characteristics : Normal : NC Settings :

0477 63PG-1 0991 GAS

Pressure switch on VA13-1 & VA13-2 intervalves space Characteristics : Normal : NC

Settings :

0477 63PL-21 918T TURB

Pressure switch on liquid fuel purge air Characteristics : Normal : NO

Settings :

Not adjustable : increase close at : 6 ± 0.3 bar (87 ± 4 psi) | Decrease open at : 4.6 ± 0.3 bar (67 ± 4 psi)

0416 63QA-2 0926 ACCY

Low lube oil pressure alarm Characteristics : Normal : NO Settings :

Not adjustable : increase close at : 3.1 ± 0.14 bar (45 ± 2 psi) | Decrease open at : 2.8 ± 0.07 bar (40.6 ± 1 psi)

0416 63QQ-21 0940 ACCY

Main lube oil filter differential pressure switch Characteristics : Normal : NC

Settings :

0416 63QQ-22 0940 ACCY

Main lube oil filter differential pressure switch Characteristics : Normal : NC

Settings :

0416 63QQ-8 0916 ACCY

Torque converter filter differential pressure Characteristics : Normal : NC

Settings :

Increase open at : 1.5 ± 0.2 bar (21.75 ± 3 psi)

0416 63QT-2A ALT. GENE

Generator bearing low lube oil pressure Characteristics : Normal : NO

Settings :

Not adjustable : increase close at : 0.62 ± 0.035 bar (9 ± 0.5 psi) | Decrease open at : 0.55 ± 0.021 bar (8 ± 0.3 psi)

0471 63TF-10A A040 FILT

Differential pressure switch between air inlet and hoods Characteristics : Normal : NC

Settings : Increase open at : 3 ± 0.2 mbar (0.04 ± 0.003 psi) 0471 63TF-10B A040 FILT

Differential pressure switch between air inlet and hoods Characteristics : Normal : NC

Settings : Increase open at : 3 ± 0.2 mbar (0.04 ± 0.003 psi)

0471 63TF-2A A040 FILT

GT inlet air system differential pressure switch Characteristics : Normal : NC

Settings :

(17)

PID Diagram

0471 63TF-2B A040 FILT

GT inlet air system differential pressure switch Characteristics : Normal : NC

Settings :

Increase open at : 21 ± 0.5 mbar (0.3 ± 0.007 psi)

0417 63TK-1 A053/A

132 ACCY

Turbine exhaust frame cooling pressure switch Characteristics : Normal : NO

Settings :

Closed above 381 ± 19 mm H2O (15 ± 0.75 in H2O)

0417 63TK-2 A053/A

132 ACCY

Turbine exhaust frame cooling pressure switch Characteristics : Normal : NO

Settings :

Closed above 381 ± 19 mm H2O (15 ± 0.75 in H2O) 0462 63WN-1 A035 WI

Water injection pressure switch Characteristics : Normal : NC

Settings : Open on decreasing pressure / atm : -0.270 ± 0.01 bar (-3.9 ± 0.14 psi) 0462 63WN-2 A035 WI

Water injection pressure switch Characteristics : Normal : NO

Settings : Open on decreasing pressure : 25 bar (363 psi) 0462 63WN-3 A035 WI

Water injection differential pressure switch on water injection pump filter Characteristics : Normal : NC

Settings : Open on increasing differential pressure : 1.03 bar ± 0.1 bar (15 ± 1 psi) 0424 65FP 0533 ACCY Liquid fuel pump (by pass valve) servo valve

0422 65GC-1 0509 GAS Gas control valve servo valve (VGC-1) 0494 71FA-31 E021/E0

48 VAN

Level switch in the tank 501BA Characteristics : Normal : NO Settings : Opening on low level 0494 71FA-32 E021/E0

48 VAN

Level switch in the auxiliary tank Characteristics : Normal : NO Settings : Opening on low level 0424 71FF-4 969L TURB

Fuel leakage detection pot level switch Characteristics : Normal : NC

Settings : Opening on high level 0424 71FF-5 969L TURB

Settings : Opening on high-high level 0424 71FF-6 969L TURB

Settings : Opening on high-high level 0416 71QH-1 1038 ACCY

High level lube oil tank Characteristics : Normal : NC

Settings : Increase open on high level. See lube oil schematic MLI 416 for setting 0416 71QL-1 1038 ACCY

Low level lube oil tank Characteristics : Normal : NO

Settings : Decrease open on low level. See lube oil schematic MLI 416 for setting 0424 77FD-1 0910 ACCY Flow divider magnetic pickup-speed

Settings : Gap : 0.23 ± 0.025 mm (0.009 ± 0.001 in) 0424 77FD-2 0910 ACCY Flow divider magnetic pickup-speed

Settings : Gap : 0.23 ± 0.025 mm (0.009 ± 0.001 in) 0424 77FD-3 0910 ACCY Flow divider magnetic pickup-speed

Settings : Gap : 0.23 ± 0.025 mm (0.009 ± 0.001 in) 0415 77HT-1 0546 TURB Speed sensor

(18)

PID Diagram

0415 77HT-2 0546 TURB Speed sensor

Settings : Gap : 1.27 ± 0.127 mm (0.05 ± 0.005 in) 0415 77HT-3 0546 TURB Speed sensor

Settings : Gap : 1.27 ± 0.127 mm (0.05 ± 0.005 in) 0415 77NH-1 0546 TURB Speed sensor

Settings : Gap : 1.27 ± 0.127 mm (0.05 ± 0.005 in) 0415 77RP-11 235A TURB

Keyphasor, shaft end drive turbine side

Characteristics : Output proximitor : 7.87 V/mm (0.2 V/mil) Settings : Gap : 1.4 ± 0.05 mm (0.055 ± 0.002 in) 0425 88AB-1 1047 ACCY Atomizing air booster motor

Characteristics : 15 kW | 3000 rpm | 27.5A | 50 hz | 400 VAC 0436 88BT-1 1605 ENCL-T Cooling air fan motor - acoustical enclosure GT compartment

Characteristics : 37 kW | - rpm | 50 hz | 400 VAC

0436 88BT-2 1605 ENCL-T Cooling air fan motor - acoustic enclosure GT compartment Characteristics : 37 kW | - rpm | 50 hz | 400 VAC

0421 88CR-1 0603 ACCY Electrical cranking motor

Characteristics : 1000 kW | 3000 rpm | 50 hz | 6.6 kV 0494 88FA-30 E021/E0

48 VAN

Electric motor of PFA-30 pump

Characteristics : 0.46 kW | 1500 rpm | 50 hz | 230 VAC 0494 88FA-31 E021/E0

48 VAN

Characteristics : 0.37 kW | 1380 rpm | 50 hz | 400 VAC 0494 88FA-32 E021/E0

48 VAN

Characteristics : 0.37 kW | 1380 rpm | 50 hz | 400 VAC 0424 88FM 0613 ACCY Flow divider starting motor

Characteristics : 0.37 kW | 1400 rpm | 50 hz | 400 VAC 0434 88HQ-1 0628 ACCY Auxiliary hydraulic supply pump motor

Characteristics : 15 kW | 1500 rpm | 28.2A | 50 hz | 400 VAC 0436 88JS-1 1659 ENCL-WI Water injection skid enclosure cooling air fan motor

Characteristics : 0.37 kW | 1500 rpm | 50 hz | 400 VAC 0436 88JS-2 1659 ENCL-WI Cooling air fan motor water injection skid enclosure

Characteristics : 0.37 kW | 1500 rpm | 50 hz | 400 VAC 0416 88QA-1 1006 ACCY Auxiliary lube oil pump motor

Characteristics : 90 kW | 3000 rpm | 149,5A | 50 hz | 400 VAC 0416 88QE-1 1007 ACCY Emergency lube oil pump motor

Characteristics : 9 kW | 1750 rpm | 89A | 125 VDC 0416 88QV-1A A098 MIST Lube oil mist eliminator motor

Characteristics : 18.5 kW | 3000 rpm | 32.8A | 50 hz | 400 VAC 0421 88TG-1 0538 ACCY Turning gear electrical motor

Characteristics : 30 kW | 750 rpm | 50 hz | 400 VAC 0417 88TK-1 1233/A

132 ACCY

Turbine exhaust frame cooling blower & motor Characteristics : 45 kW | 3000 rpm | 79A | 50 hz | 400 VAC 0417 88TK-2 1233/A

132 ACCY

Turbine exhaust frame cooling blower & motor Characteristics : 45 kW | 3000 rpm | 79A | 50 hz | 400 VAC 0421 88TM-1 0605 ACCY Torque adjuster drive motor

(19)

PID Diagram

0436 88VG-1 1605 ENCL-T Cooling air fan motor acoustic enclosure load compartment Characteristics : 18.5 kW | 1500 rpm | 50 hz | 400 VAC 0436 88VG-2 1605 ENCL-T Cooling air fan motor acoustic enclosure load compartment

Characteristics : 18.5 kW | 1500 rpm | 50 hz | 400 VAC 0436 88VL-1 1658 ENCL-G Cooling air fan motor gas module acoustic enclosure

Characteristics : 4 kW | 1500 rpm | 50 hz | 400 VAC 0436 88VL-2 1658 ENCL-G Cooling air fan motor gas module acoustic enclosure

Characteristics : 4 kW | 1500 rpm | 50 hz | 400 VAC 0462 88WN-1 A035 WI Water injection pump motor

Characteristics : 55 kW | 3000 rpm | 92.5 A | 50 hz | 400 VAC 0422 90SR-1 0507 GAS Gas speed ratio/stop valve servo valve

0469 90TV-1 0548 TURB Servovalve, compressor IGV actuator

0462 90WN-1 A035 WI

Electro-pneumatic converter Settings :

04 ± 0.20 mA for 0 bar (0 psi) 20 ± 0.20 mA for 2.6 bar (37.7 psi)

0436 95BT-1 1605 ENCL-T

Air flow control (anemometer) for turbine enclosure Characteristics : 04 - 20 mA for 0.5 - 30 m/s Settings : fan not running, 0% air flow : 4 -0/+1 mA

fan running and doors closed : x1 mA, adjust the speedtronic constant software at a value equivalent to { [60% * (x1 - 4) ] + 4 mA }

0436 95BT-2 1605 ENCL-T

0436 95BT-3 1605 ENCL-T

0415 95SG-13 1213 TURB Ignition transformer for 95SP-13

Characteristics : 0.15 kVA | 50 hz | 15 kV | 230 VAC 0415 95SG-14 1213 TURB Ignition transformer for 95SP-14

Characteristics : 0.15 kVA | 50 hz | 15 kV | 230 VAC 0415 95SP-13 1214 TURB Spark plug for combustion chamber n°13 0415 95SP-14 1214 TURB Spark plug for combustion chamber n°14

0436 95VL-1 1658 ENCL-G

Air flow control (anemometer) for gas skid enclosure Characteristics : 04 - 20 mA for 0.5 - 30 m/s Settings : fan not running, 0% air flow : 4 -0/+1 mA

0436 95VL-2 1658 ENCL-G

0436 95VL-3 1658 ENCL-G

(20)

PID Diagram

0425 96AA-4A 557T TURB

Atomizing air manifold pressure transmitter Settings :

04 ± 0,05 mA for -1 bar (-14.5 psi) 20 ± 0,1 mA for 35 bar (507.6 psi)

0425 96AA-4B 557T TURB

0425 96AA-4C 557T TURB

0425 96AD-1 0926 ACCY

Atomizing air main compressor differential pressure transmitter Settings :

04 ± 0.02 mA for 0 bar (0 psi) 20 ± 0.1 mA for 6 bar (87 psi)

0492 96AP-1A 0559 ACCY

Pressure transmitter Settings :

04 ± 0.02 mA for 0.745 bar abs (22 in of Hg) 20 ± 0.10 mA for 1.250 bar abs (36.9 in of Hg)

0492 96AP-1B 0559 ACCY

0492 96AP-1C 0559 ACCY

0492 96BD-1 0559 ACCY

Differential pressure transmitter between the air inlet of GT and the bell of GT intake Settings :

04 ± 0.02 mA for 0.000 bar (0.000 in of H2O) 20 ± 0.10 mA for 0.345 bar (138.5 in of H2O)

0417 96CD-1A 0557 ACCY

Compressor discharge pressure transmitter Settings :

04 ± 0.05 mA for 0 bar (0 psi) 20 ± 0.05 mA for 21 bar (304.5 psi)

0417 96CD-1B 0557 ACCY

0417 96CD-1C 0557 ACCY

0492 96CS-1 0559 ACCY

Differential pressure transmitter between the air inlet of GT and the bell of GT intake Settings :

04 ± 0.02 mA for 0 mbar

20 ± 0.10 mA for 27.4 mbar (11 in of H2O)

0422 96FG-1 0991 GAS

Inlet gas fuel module pressure transmitter Settings :

04 ± 0.05 mA for 0 bar (0 psi) 20 ± 0.1 mA for 34.5 bar (500 psi)

0422 96FG-2A 0991 GAS

Fuel gas inter-valve pressure transmitter Settings :

(21)

PID Diagram

0422 96FG-2B 0991 GAS

0422 96FG-2C 0991 GAS

0422 96GC-1,2 0509 GAS

Fuel gas control valve (VGC-1) LVDT Settings :

0.7 ± 0.1 V = 0% open 3.5 ± 0.5 V = 100% open

0416 96QA-2 0926 ACCY

Lube oil system VPR-2 inlet pressure transmitter Settings :

0416 96QE-2 0926 ACCY

Emergency pump discharge pressure transmitter Settings :

04 ± 0.05 mA for 0 bar (0 psi) 20 ± 0.1 mA for 2 bar (29 psi)

0416 96QT-2B ALT. GENE

Low lube oil pressure transmitter generator Settings :

0416 96QV-1 0557 ACCY

Tank s air vacuum differential pressure transmitter Settings :

04 ± 0.05 mA for 0 bar (0 psi) 20 ± 0.1 mA for -15 mbarg (vacuum)

0471 96RH A040 FILT

Dew point and temperature transmitter Settings : Outlet 1 : 04 ± 0.05 mA for -50°C (-58 °F) 20 ± 0.05 mA for +50°C (122 °F) Outlet 2 : 04 ± 0.05 mA for 0% RH 20 ± 0.05 mA for 100 % RH 0422 96SR-1,2 0507 GAS Stop ratio fuel gas (VSR-1) LVDT

Settings : 0.7 ± 0.01 VAC for 0 mm

0471 96TF-1 A040 FILT

Differential pressure transmitter of total filtration stages Settings :

04 ± 0.05 mA for 0 mmH2O (0 inH2O) 20 ± 0.1 mA for 254 mmH2O (10 inH2O)

0471 96TF-10 A040 FILT

Differential pressure transmitter between air inlet and hoods Settings :

04 ± 0.05 mA for 0 mmH2O (0 inH2O) 20 ± 0.1 mA for 254 mmH2O (10 inH2O)

0421 96TM-1 0605 ACCY

Torque converter IGV position transmitter Settings :

04 ± 0.05 mA for 0 tr of handwheel (full scale 0-242 tr) 20 ± 0.05 mA for 242 of handwheel (full scale 0-242 tr)

0469 96TV-1 0548 TURB LVDT (Linear variable displacement transmitter), compressor IGV actuator Settings : 0.7 ± 0.01 VAC for 34° IGV angle

0469 96TV-2 0548 TURB LVDT (Linear variable displacement transmitter), compressor IGV actuator Settings : 0.7 ± 0.01 VAC for 34° IGV angle

0415 96VC-11 235A TURB

Vibration sensor

(22)

PID Diagram 0415 96VC-12 235A TURB

Vibration sensor

0422 96VM-1 0639 OTHER

Gas mass flow transmitter Settings : 04 ± 0.05 mA for 0 kg/s (0 lbm/s) 20 ± 0.1 mA for 10 kg/s (22 lbm/s) 0462 96WF-1 A035 WI Flow transmitter Settings : 04 ± 0.2 mA for 0 m3/h (0 gpm) 20 ± 0.2 mA for 20.4 ± 0.1 m3/h (90 ± 0.44 gpm) 0462 96WF-2 A035 WI Flow transmitter Settings : 04 ± 0.2 mA for 0 m3/h (0 gpm) 20 ± 0.2 mA for 20.4 ± 0.1 m3/h (90 ± 0.44 gpm) 0462 96WF-3 A035 WI Flow transmitter Settings : 04 ± 0.2 mA for 0 m3/h (0 gpm) 20 ± 0.2 mA for 20.4 ± 0.1 m3/h (90 ± 0.44 gpm) 0425 AAT-1A 637T TURB Atomizing air precooler air discharge thermocouple

Characteristics : Type K

0425 AAT-2A 637T TURB Atomizing air precooler air discharge thermocouple Characteristics : Type K

0434 AH1-1 0908 N/A

Control oil hydraulic accumulator Characteristics : 17.8 l (4.7 gal) | Nitrogen Settings : 51.7 ± 1 bar (750 ± 15 psi) 0422 AH1-3 0991 N/A

Control oil hydraulic accumulator Characteristics : 17.8 l (4.70 gal) | Nitrogen Settings : 51.7 ± 1 bar (750 ± 15 psi) 0436 AT-AC-1 1113 ENCL-T Thermocouple accessory compartment

0436 AT-AC-11 1195 ENCL-G Thermocouple gas compartment Characteristics : Type K

0436 AT-LC-1 637T TURB

Air temperature load compartment

Characteristics : Platinum PT100 | 100 Ohm at 0°C (32°F) | -50 to 260 °C (-58 to 500 °F) | 0.385 Ohm/°C (0.214 Ohm/°F)

0436 AT-TC-1 637T TURB

Air temperature turbine compartment

Characteristics : Platinum PT100 | 100 Ohm at 0°C (32 °F) | -50 to 260 °C (-58 to 500 °F) | 0.385 Ohm/°C (0.214 Ohm/°F)

0436 AT-TC-2 1113 ENCL-T Thermocouple : turbine compartment enclosure Characteristics : Type K

0436 AT-TC-3 1113 ENCL-T Thermocouple : turbine compartment enclosure Characteristics : Type K

0436 AT-WI-1 1659 ENCL-WI Water injection compartment temperature water injection compartment Characteristics : Type K

0415 BT-J1-1A,1B 235A TURB Dual thermocouple temperature journal bearing n°1 Characteristics : Type K

0415 BT-J1-2A,2B 235A TURB Dual thermocouple temperature journal bearing n°1 Characteristics : Type K

0415 BT-J2-1A,1B 235B TURB Dual thermocouple temperature journal bearing n°2 Characteristics : Type K

0415 BT-J2-2A,2B 235B TURB Dual thermocouple temperature journal bearing n°2 Characteristics : Type K

(23)

PID Diagram

0415 BT-J3-1A,1B 235C TURB Dual thermocouple temperature journal bearing n°3 Characteristics : Type K

0415 BT-J3-2A,2B 235C TURB Dual thermocouple temperature journal bearing n°3 Characteristics : Type K

0415 BT-TA1-4A,4B 235A TURB Dual thermocouple temperature pad n°4 of thrust bearing n°1 Characteristics : Type K

0415 BT-TA1-8A,8B 235A TURB Dual thermocouple temperature pad n°8 of thrust bearing n°1 Characteristics : Type K

0415 BT-TI1-1A,1B 235A TURB Dual thermocouple temperature pad n°1 of counter thrust bearing n°1 Characteristics : Type K

0415 BT-TI1-6A,6B 235A TURB Dual thermocouple temperature pad n°6 of counter thrust bearing n°1 Characteristics : Type K

0425 CA1 0607 N/A Main atomizing air compressor

Characteristics : Centrifugal | 2.7 kg/s | Gear box shaft speed: 6600 rpm 0425 CA2 1047 N/A Booster atomizing air compressor

Characteristics : Volumetric | 510 m3/h (2245.46 gal/min) | 4000 rpm 0415 CT-DA-1 637T TURB Thermocouple compressor air discharge temperature

0415 CT-DA-2 637T TURB Thermocouple compressor air discharge temperature Characteristics : Type K

0415 CT-IF-1 637T TURB Thermocouple temperature compressor air inlet Characteristics : Type K

0415 CT-IF-2 637T TURB Thermocouple temperature compressor air inlet Characteristics : Type K

0492 CT-IF-3/R 637T TURB

Resistance temperature detector

0421 ET-CRS-11/R 0603 ACCY

Cranking motor stator Ph1 temperature sensor 1

0421 ET-CRS-12/R 0603 ACCY

Cranking motor stator Ph1temperature sensor 2

0421 ET-CRS-21/R 0603 ACCY

0421 ET-CRS-22/R 0603 ACCY

0421 ET-CRS-31/R 0603 ACCY

0421 ET-CRS-32/R 0603 ACCY

0477 FA3-1 918T N/A Liquid fuel purge air filter Characteristics : 5 µm

0425 FA4-1 0983 N/A Filter on actuation air of atomizing air and purge systems Characteristics : 5 µm

(24)

PID Diagram

0462 FA8-2 A035 N/A Water injection air filter Characteristics : 5 µm

0441 FAKJ-1 E026 N/A Pressure switch filter cleaning skid 0441 FAKJ-2 E026 N/A Screen type filter

0424 FD1-1 0613 N/A

Flow divider

Characteristics : type lineare, 7 elements with double pumps | 883 l/min (233 gpm) at 1650 rpm | 50 hz

0424 FF2-1 1014 N/A HP fuel filter

Characteristics : Beta 40 = 75 0424 FF2-2 1014 N/A HP fuel filter

Characteristics : Beta 40 = 75 0494 FF31-1 E021/E0

48 N/A

Filter before the pumps Characteristics : Mesh = 0.91 mm 0434 FH2-1 1051 N/A Hydraulic oil supply filter

Characteristics : Beta 3 > 200 0434 FH2-2 1051 N/A Hydraulic oil supply filter

Characteristics : Beta 3 > 200

0424 FH3 0992 N/A Hydraulic filter liquid fuel servo valve (control) Characteristics : 40 µm

0469 FH6-1 0548 N/A Filter, hydraulic fluid supply , IGV controller assembly Characteristics : Beta 15 = 75

0422 FH7-1 0507 N/A Servo hydraulic supply filter of stop ratio valve (VSR) Characteristics : 15 µm abs

0422 FH8-1 0509 N/A Gas fuel control valve (VGC) servo hydraulic fluid supply filter Characteristics : 15 µm abs

0462 FM1-1 A035 N/A

Water injection flowmeter

Characteristics : 1,4 m3/h (6 gpm) | Nominal K factor : 343.5 pulse/l (1300 pulse/US gallon) | 20.4 m3/h (90 gpm)

0462 FW1-1 A035 N/A High pressure filter Characteristics : Beta 13 = 75

0462 FW1-2 A035 N/A Water injection upstream pump Y strainer Characteristics : Filtering media 800µm 0462 FW1-3 A035 N/A Conical filter downstream flowmeter

Characteristics : Filtering media 150µm 0421 HM-1 0605 N/A Torque converter and reversing gear 0469 HM3-1 0548 N/A Actuator assembly, inlet guide valve system

Characteristics : Actuator operation limits : 31.5° ± 0.5° to 87.75° ± 0.25° 0425 HX1-1 1003 N/A Atomizing air precooler

0416 LOF1-1 1010 N/A Lube oil filter

Characteristics : Beta 40 = 75 0416 LOF1-2 1010 N/A Lube oil filter

Characteristics : Beta 40 = 75 0416 LOHX-1 1001 N/A Lube oil cooler

0416 LOHX-2 1001 N/A Lube oil cooler

0416 LT-B1D-1 637T TURB Lube oil thermocouple #1 bearing drain Characteristics : Type K

(25)

PID Diagram

0416 LT-BT1D-1 637T TURB Lube oil thermocouple #1 bearing thrusts drain Characteristics : Type K

0416 LT-G1D-1 ALT. GENE Lube oil thermocouple generator and load gear #1 bearing drain Characteristics : Type K

0416 LT-G2D-1 ALT. GENE Lube oil thermocouple generator and load gear #2 bearing drain Characteristics : Type K

0416 LT-OT-1 1218 TURB

Resistance temperature in oil tank detector

0416 LT-OT-2 1218 TURB

Resistance temperature in oil tank detector

0416 LT-TH-1 637A ACCY Lube oil temperature turbine header thermocouple Characteristics : Type K

0422 MG1 0512 N/A Gas fuel nozzle 0424 PF1 0611 ACCY

Main fuel pump

Characteristics : Positive displacement screw pump | 2924 rpm | 68.9 bar (1000 psi) | 870.5 l/min (230 gpm)

0494 PFA-30 E021/E0 48 N/A

Unloading pump

Characteristics : Volumetric pump | 25 l/min (6.6 gpm) 0494 PFA-31 E021/E0

48 N/A

Dosing pump

Characteristics : Volumetric pump | 1500 rpm | 10 bar (145 psi) | Flow to define 0494 PFA-32 E021/E0

48 N/A

Dosing pump

Characteristics : Volumetric pump | 1500 rpm | 10 bar (145 psi) | Flow to define 0434 PH1 0627 N/A Main hydraulic supply pump

Characteristics : Volumetric pump | 1422 rpm | 105 bar (1500 psi) | 65 l/min (17.1 gpm) 0434 PH2 0628 N/A Auxiliary hydraulic supply pump

Characteristics : Volumetric pump | 1450 rpm | 105 bar (1500 psi) | 45.4 l/min (12 gpm) 0416 PQ1-1 0601 N/A Lube oil main pump

Characteristics : Volumetric | 6.89 bar (100 psi) | 3000 l/min (792 gpm) 0416 PQ2-1 1007 N/A Lube oil emergency pump

Characteristics : Centrifugal | 1.37 bar (19.87 psi) | 1596 l/min (422 gpm) 0494 PSV-31 E021/E0

48 N/A

Breather valve of 501BA tank Characteristics : Normal : NC

Settings : Overpressure : 0.15 bar (2.17 psi); Vaccum : 0.01 bar (0.15 psi) 0462 PW1-1 A035 N/A Water injection pump unit

Characteristics : Centrifugal pump | 12263 rpm | 33 bar (480 psi) | 26.6 m3/h (117 gpm) 0426 SLI-1 1104 ACCY Light warning auxiliaries compartment

Characteristics : 0.015 | 50 hz | 230 UPS 0426 SLI-1A 1113 ENCL-T Fire alarm auxiliaries compartment

Characteristics : Visual alarm | 24 VDC 0426 SLI-1B 1113 ENCL-T Fire alarm GT compartment

Characteristics : Visual alarm | 24 VDC Fire alarm GT compartment

(26)

PID Diagram

0426 SLI-1D 1195 ENCL-G Fire alarm gas compartment Characteristics : Visual alarm | 24 VDC 0426 SLI-1E 1195 ENCL-G Fire alarm gas compartment

Characteristics : Visual and audible alarm | 24 VDC 0426 SLI-2 1104 ACCY Light warning auxiliaries compartment

Characteristics : 0.015 | 50 hz | 230 UPS 0426 SLI-2B 1113 ENCL-T Fire alarm GT compartment

Characteristics : Visual alarm | 24 VDC 0426 SLI-2C 1113 ENCL-T Fire alarm GT compartment

Characteristics : Visual and audible alarm | 24 VDC 0426 SLI-2E 1195 ENCL-G Fire alarm gas compartment

Characteristics : Visual and audible alarm | 24 VDC 0426 SLI-3C 1113 ENCL-T Fire alarm load compartment

Characteristics : Visual and audible alarm | 24 VDC 0415 TT-IB-1 637T TURB Thermocouple temperature exhaust tunnel

0415 TT-IB-2 637T TURB Thermocouple temperature exhaust tunnel Characteristics : Type K

0415 TT-IB-3 637T TURB Thermocouple temperature exhaust tunnel Characteristics : Type K

0415 TT-WS1AO-1 637T TURB Thermocouple wheelspace temperature outer position after first wheel Characteristics : Type K

0415 TT-WS1AO-2 637T TURB Thermocouple wheelspace temperature outer position after first wheel Characteristics : Type K

0415 TT-WS1FI-1 637T TURB Thermocouple wheelspace temperature inner position forward first wheel Characteristics : Type K

0415 TT-WS1FI-2 637T TURB Thermocouple wheelspace temperature inner position forward first wheel Characteristics : Type K

0415 TT-WS2AO-1 637T TURB Thermocouple wheelspace temperature outer position after second wheel Characteristics : Type K

0415 TT-WS2AO-2 637T TURB Thermocouple wheelspace temperature outer position after second wheel Characteristics : Type K

0415 TT-WS2FO-1 637T TURB Thermocouple wheelspace temperature outer position forward second wheel Characteristics : Type K

0415 TT-WS2FO-2 637T TURB Thermocouple wheelspace temperature outer position forward second wheel Characteristics : Type K

0415 TT-WS3AO-1 637T TURB Thermocouple wheelspace temperature outer position after third wheel Characteristics : Type K

0415 TT-WS3AO-2 637T TURB Thermocouple wheelspace temperature outer position after third wheel Characteristics : Type K

0415 TT-WS3FO-1 637T TURB Thermocouple wheelspace temperature outer position forward third wheel Characteristics : Type K

0415 TT-WS3FO-2 637T TURB Thermocouple wheelspace temperature outer position forward third wheel Characteristics : Type K

0415 TT-XD-1 0623 TURB Thermocouple temperature of GT exhaust Characteristics : Type K

(27)

PID Diagram

0477 VA13-1 0991 N/A

Gas fuel purge circuit valve Characteristics : Normal : NC

Settings : Opening time shall be 30 ± 5 seconds. Closing time shall be 10 seconds at maximum. 0477 VA13-2 0991 N/A

Gas fuel purge circuit valve Characteristics : Normal : NC

Settings : Opening time of VA13-2 should be less than VA13-1 False start drain valve

(28)

PID Diagram

0442 VA17-2 1026 N/A False start drain valve Characteristics : Normal : FO 0442 VA17-5 1026 N/A False start drain valve

Characteristics : Normal : FO

0425 VA18-1 1070 N/A Atomizing air compressor pressure adjustment valve Characteristics : Normal : NC

0477 VA19-1 918T N/A Liquid fuel purge air valve

Characteristics : Normal : C to L opened ; U closed 0417 VA2-1 1022 N/A Compressor bleed valve

Characteristics : Normal : NO 0417 VA2-2 1022 N/A Compressor bleed valve

0425 VA22-1 0922 N/A CA2 booster atomizing air compressor inlet air isolation butterfly valve Characteristics : Normal : NO

0417 VA2-3 1022 N/A Compressor bleed valve Characteristics : Normal : NO 0417 VA2-4 1022 N/A Compressor bleed valve

0477 VA36-1 0991 N/A

Quick exhaust pneumatic valve for gas fuel purge valve VA13-1 Characteristics :

Under pressure : 1 to 2 open and vent 3 closed Out of pressure : 2 open to vent 3

0477 VA36-2 0991 N/A

Quick exhaust pneumatic valve for gas fuel purge valve VA13-2 Characteristics :

Under pressure : 1 to 2 open and vent 3 closed Out of pressure : 2 open to vent 3

0494 VA99-31 E021/E0 48 N/A Pneumatic valve Characteristics : Normal : NO 0494 VA99-32 E021/E0 48 N/A Pneumatic valve Characteristics : Normal : NC 0494 VA99-33 E021/E0 48 N/A Pneumatic valve Characteristics : Normal : NO

0434 VAB1 0947 N/A Hydraulic system air bleed valve (main) 0434 VAB2 0947 N/A Hydraulic system air bleed valve (auxiliary) 0424 VC3 0516 N/A By pass control valve

Characteristics : Stroke = 28.57 mm (1.125 in) | Normal : NO 0462 VC4-1 A035 N/A Water injection flow control valve

Characteristics : Normal : NC 0462 VCK100 A035 N/A Check valve

Characteristics : Normal : NC 0424 VCK1-1T14 0961 N/A

Liquid fuel nozzle check valve Characteristics : Normal : NC

Settings : Cracking pressure : 8.27 ± 0.34 bar (120 ± 5 psi)

0416 VCK20-13 A098 N/A

Lube oil mist eliminator check valve Characteristics : Normal : NC

Settings : beginning to open at -100 ± 10 mm H2O (-3.94 ± 0.4 in H20) at full speed no load
