2 Inch LED Recessed LIGHTING

(1)

(2)

2" LED

Recessed LIGHTING

D2LED & A2LED: PrEscoLItE’s rEvoLutIonAry 2" LED LIghtIng. crEAtED to mEEt thE

nEEDs of thE LIghtIng DEsIgn & ArchItEcturAL communIty

With custom optics designed around the precision Xicato brand light engine, D2LED and A2LED offers the opportunity to create clean ceilings with minimal obtrusiveness. The downlight provides general, workable light output – including track and accent lighting – in new construction and retrofit applications, such as:

until recently, small aperture 2" LED products were only suitable for niche or accent lighting. With Prescolite’s revolutionary 2" LED downlights, it’s now possible to experience a new dimension in lighting design for commercial applications.

DoWnLIghtIng WALL WAsh ADJustABLE

LoBBIEs hosPItALIty

LoungE or BAr ArEAs In rEstAurAnts ProfEssIonAL / offIcEs

rEtAIL

hIgh-EnD rEsIDEntIAL

With Prescolite’s 2" LED lighting, lighting designers and architects can have it all – minimal aperture size, efficiency and premium optics – when lighting highly aesthetic environments.

Designers can create clean ceilings with minimal obtrusiveness.

One fixture is designed to work in new construction or retrofit. Multiple optical options available, including wall wash.

Downlight, wall wash, adjustable. All designed to be used together in a space.

(3)

D2LED/A2LED

Product family: Architektur

type: LED Recessed

LED configuration: 2" Open Reflector / Light Engine _{Assembly with Xicato 1300 Lumen module} color temperature: 2700K, 3000K, 3500K, 4000K

crI: 80+ Nominal / 95 CRI

Dimming: 0-10V to 10%

voltage: 120V or 277V

Input Watts: 20W

optics: 25, 35, 45 and wall wash

D2LED

D2LEDWW

2" Led Recessed LIGHTING

d2Led & A2Led

hEAt sInk

fIxturE rEtEntIon sPrIngs

J-tuBE (PAtEnt PEnDIng), no frAmE rEquIrED InsuLAtIon sEnsor

xIcAto LIght EngInE (not vIsIBLE) rEfLEctor LIght PIPE DuAL-sLIDE AImIng 1 2 3 4 5 6 7 8 7 8

(5)

PRescOLITe’s PATeNT PeNdING J-TuBe desIGN:

Provides for separation of line and low voltages Accessible/removable

from below ceiling

Quick connects

Insulation sensor provides thermal protection Features ability to thru branch wire (2 in/2 out). Arlington connector not supplied with fixture

LoW voLtAgE

suPPLy voLtAgE

(6)

cHALLeNGING THe dOwNLIGHTING PARAdIGm

The Lambertian lumen distribution of the Xicato®_{remote phosphor LED module}

provides a unique opportunity to transition from the traditional lighting design model and reduce the aperture diameter.

View the comparison chart below to see how D2LED compares to other downlighting solutions. APErturE DIAmEtEr APErturE ArEA 2.25" 4.0 sq. in. 4.25" 14.2 sq. in. 5.75" 26.0 sq. in. 7.75" 47.2 sq. in. 9.25" 67.2 sq. in.

It’s now possible to create clean ceilings with minimal obtrusiveness using a nominal 2" aperture downlight, while also providing high lumen output (858 delivered lumens) for general applications.

D2LED

hoW smALL Is A

2" APErturE? gEt A

sEnsE of PErsPEctIvE.

When viewing a downlight your eye does not perceive the size of the aperture relative to the diameter, but rather, to the area of the opening! So the D2LED appears to be 1/4 the size of a typical 4" downlight.

(7)

xIcATO mOduLe

D2LED is designed around the premium xicato light engine that: > Uses remote phosphor technology

> Offers color consistency (2-step MacAdam Ellipse) from fixture to fixture

> Is thermally manageable and in a small form factor

> IP66 rated wet location

> Features optical consistency

(8)

xIcATO xsm TecHNOLOGY

The Corrected Cold Phosphor Technology®_{matches blue LEDs to a} phosphor disk to lock in color and provide lighting professionals with the consistency required for architectural applications.

Patented internal optical mixing cavity

Patented thermal design

Patented Corrected Cold Phosphor Technology®

(9)

Prescolite’s heat sink features a state-of-the-art design for optimal thermal management. The design provides consistent unrestricted heat flow from the source to the air. This ensures maximum life and consistent color over the fixture’s lifespan.

> 168 square inches of heat sink surface area > LED module operates substantially under

xicato’s Lm80 maximum test point with free air flow around the heat sink.

thErmAL DEsIgn

D2LED’s unique design doesn’t require a frame to be installed into a ceiling – in most applications. To support the downlight in weak ceilings, such as tiles, Prescolite offers the D2FRM plaster frame option.

A special option is available for applications that require an IC Box – such as high-end residential settings. The D2ICAT IC-rated, and airtight box is an ideal for installing the downlight into an insulated ceiling.*

D2frm: PLAstEr frAmE

D2IcAt: Ic Box

(10)

.46 .44 .42 .40 .38 .36 .34 .32 .35 Xicato Specification MacAdam Ellipses (1, 2, 3, & 4 step) ANSI NEMA Standard Industry Standard Color Bins

.40 .45 .50

Y

X

0.46

0.44

0.42

0.40

0.38

0.36

0.34

0.32

0.35 0.40 0.45 0.50

y

x

4000K 3000K 3500K 2700K .46 .44 .42 .40 .38 .36 .34 .32 .35 Xicato Specification MacAdam Ellipses (1, 2, 3, & 4 step) ANSI NEMA Standard Industry Standard Color Bins

.40 .45 .50

Y

X

The D2LED satisfies the exacting requirements of architectural applications by maintaining color consistency.

cOLOR cONsIsTeNcY

corrEctED coLD PhosPhor tEchnoLogy®

Color point within 2 MacAdam Ellipses Color point centered on Black Body Locus

WhAt DoEs A

2-stEP mAcADAm

ELLIPsE mEAn?

Both of these apples are red, but do they really look the same?

Within a 2-step MacAdam Ellipse, all your apples appear the same.

(11)

The D2LED and A2LED have precise color levels and maintains R9 Values greater than 15, which matches some traditional sources.

rA r1 r2 r3 r4 r5 r6 r7 r8 r9 r10 r11 r12 r13 r14 r15 D2LED 80crI 81 80 85 89 81 78 80 86 66 16 64 79 58 81 93 75 typical compact metal halide 82 90 94 69 82 81 81 87 71 27 59 62 55 93 78 88 typical compact fluorescent 82 91 93 86 91 89 90 88 70 17 76 91 81 93 92 81

IEs std for crI

cOLOR sATuRATION

xIcAto crI r-vALuEs

xIcAto sPEctrAL DIstrIButIon

Wavelength [nm]

(12)

D2LED vs. 50W mr16

In addition to offering superior optics, D2LED provides flexibility with different beam spreads (25º, 35º and 45º), as well as smooth beam edge and uniformity.

In the chart below, see how D2LED compares to typical 50W MR16 lamp:

While a handful of small aperture LED products are on the market, none of them have the high output like D2LED – at 858 delivered lumens and 43 lumens per watt.

D2LED comPArED to

trADItIonAL sourcEs

vArIABLE D2LED mr16

Beam Edge Smooth None Uniformity Perfect Irregular

and striated Glare Low Wide angle,

up to 90 Distribution Defined Erratic

0˚ 15˚ 30˚ 45˚ 60˚ 75˚ 90˚ 700 1400 2100 450 900 1350 0˚ 15˚ 30˚ 45˚ 60˚ 75˚ 90˚ 250 500 750 45˚ 60˚ 75˚ 90˚ 0˚ 15˚ 30˚ DEg cAnDELA 0 1700 5 1853 15 1650 25 308 35 153 45 125 55 36 65 25 75 22 85 20 90 22 cAnDELA DIstrIButIon D2LED25˚ 40˚ 50W MR16 DEg cAnDELA 0 2011 5 1985 15 1705 25 169 35 10 45 3 55 1 65 0 75 0 85 0 90 0 DEg cAnDELA 0 850 5 862 15 891 25 455 35 167 45 105 55 54 65 15 75 4 85 1 90 0 cAnDELA DIstrIButIon D2LED35˚ 55˚ 50W MR16 DEg cAnDELA 0 1118 5 1226 15 1159 25 658 35 71 45 3 55 1 65 0 75 0 85 0 90 0˚0 15˚ 30˚ 45˚ 60˚ 75˚ 90˚ 700 1400 2100 450 900 1350 0˚ 15˚ 30˚ 45˚ 60˚ 75˚ 90˚ 250 500 750 45˚ 60˚ 75˚ 90˚ 0˚ 15˚ 30˚ 0˚ 15˚ 30˚ 45˚ 60˚ 75˚ 90˚ 700 1400 2100 450 900 1350 0˚ 15˚ 30˚ 45˚ 60˚ 75˚ 90˚ 250 500 750 45˚ 60˚ 75˚ 90˚ 0˚ 15˚ 30˚ DEg cAnDELA 0 721 5 735 15 741 25 710 35 392 45 17 55 3 65 1 75 0 85 0 90 0 DEg cAnDELA 0 713 5 792 15 850 25 765 35 493 45 383 55 15 65 1 75 0 85 0 90 0 cAnDELA DIstrIButIon D2LED45˚ 26W QUAD / 6" HORIZONTAL CFL

(13)

D2LED 25º 40º 50W mr16

D2LED 35º 55º 50W mr16

(14)

The D2LED wall wash brings all the superior control of the D2LED and combines it with a revolutionary approach to wall washing.

This unique approach to optical design for wall washing, along with the innovative mounting method, raises the bar on wall wash performance. D2LED wall wash yields distributions that outperform most larger aperture specification grade downlights with traditional sources.

LIght-PIPE tEchnoLogy

Prescolite’s patent-pending light-pipe technology harnesses the light from the Xicato module and transfers it down into the downlight with minimal degradation, maintaining a clean, highly controlled wall wash.

The cut end of the light-pipe has an exclusive lenticular tooled pattern to direct each individual light ray for perfect optical control.

unIformIty

The wall wash configuration of the D2LED maintains the same even light distribution and smooth beam edge that the standard

cLosE to cEILIng

The D2LED wall wash illuminates the wall from ceiling to floor, with a quality of light not seen before in this configuration, including

d2Led wALL wAsH: A POweRFuL cOmBINATION

OF uNIFORmITY ANd cONTROL

smALL APErturE

The D2LED wall wash is configured in the same way as the standard D2LED with its signature 2-inch nominal

(15)

CENTER 3 ft. from wall 3 ft. spacing 3 6 in. DIST

ANCE FROM CEILING

10 ft. 1 ft. 2 ft. 3 ft. 4 ft. 5 ft. 6 ft. 7 ft. 8 ft. 9 ft. 1 5 14 14 12 9 7 5 4 3 1 5 14 14 12 9 7 5 4 3 1 4 14 16 12 9 7 6 4 3 1 4 14 16 12 9 7 6 4 3 1 4 14 16 12 9 7 6 4 3 3 1.5 1.5

FOOTCANDLES

xIcAto sourcE

The D2LED wall wash uses the same Xicato LED module found in D2LED to provide superior color saturation and matching.

room sIDE

contrIButIon

Not only does the D2LED wall wash perform superior wall washing, but it also incorporates the same superior downlighting to the room-side of the fixture, with no room-side glare, utilizing the same VirtualSource appearance as the standard D2LED.

InstALLs from BELoW

Often times, the wall wash version of a downlight will have a different configuration than standard versions. D2LED wall wash has the same easy-to-install configuration as the standard D2LED downlight.

(16)

Ideal for sloped ceilings and accent lighting applications, Prescolite’s new A2LED offers:

> smooth 35-degree optical pattern, which may be adjusted and locked up to 30-degrees from vertical

>unique installation that allows 360-degree rotational aiming

>translating center beam optics to improve optics at high aiming points >2" ceiling opening for a clean look below the ceiling

>xicato module for rich color rendering and saturation

thE smALLEst APErturE In commErcIAL LED LIghtIng

Is noW AvAILABLE As An ADJustABLE LumInAIrE.

xIcAto LIght EngInE

As part of Prescolite’s 2” LED family, A2LED is designed around a high output Xicato light engine. Create clean ceilings with minimal obtrusiveness and superior brightness control.

Additionally, A2LED features:

>uniform, discreet and glare-free illumination >high lumen output

> Long life, low maintenance benefits with a minimum 50,000 hours at 70 percent lumen maintenance

Have a project that calls for superior optics and energy savings – without sacrificing aesthetics? Contact your Prescolite representative about our complete 2-inch downlight, wall wash and adjustable LED offering.

(17)

DuAL-sLIDE AImIng systEm

Most small-aperture adjustable products simply tilt and aim the light into the lower trim.

Prescolite’s unique dual-slide aiming mechanism allows more light out of the fixture!

(18)

In four EAsy stEPs, you cAn InstALL D2LED AnD A2LED In your nExt LIghtIng DEsIgn.

Before the ceiling is finished, run wiring to the approximate location where the D2LED or A2LED will be installed.

Use a 2 7/8" hole saw and pilot drill to cut an opening for the D2LED or A2LED downlight. Because of the small reflector flange of the fixture, the accuracy of this hole is critical. Even a 3" hole saw may leave a ceiling cut out too large to be completely hidden after installation.

Simply slide the J-tube closed until it locks into place with the springs on opposite ends of the assembly to complete the third step. Pull the pre-existing wiring

below the ceiling and connect to the J-tube assembly through the 1/2" knockout. A 3/8" flex conduit duplex connector may be used to easily daisy chain fixtures together or for end-of-run applications a standard 1/2" connector can be used. Because both the D2LED and A2LED feature a 0-10 volt dimming capability, be sure to include any low voltage wire connections in this step. When wiring for dimming, the low voltage wiring installs through the adjoining 1/2" knockout. A second 3/8" flex conduit duplex connector may be used in this knockout where applicable.

stEP 2:

run WIrEs to J-tuBE stEP 1:

mAkE cEILIng cutout

stEP 3:

sLIDE/snAP J-tuBE cLosED

quIck ANd eAsY INsTALLATION

(19)

Feed the J-tube assembly through ceiling cutout. The J-tube assembly has been designed and CSA approved to conveniently lay on top of the ceiling material.

Squeeze the retention springs, insert the light engine assembly into the cut out, and push until the springs pop out above the ceiling, locking the fixture into place.

When installing the A2LED, be sure to adjust the vertical angle at this stage.

Once installed, being careful not to leave finger prints on the reflector, gently twist clockwise slightly to secure firmly against ceiling.

While the D2LED and A2LED are designed with a life expectancy of over 50,000 hours, there may be times when you may need to access the fixture or J-tube assembly. For this reason, the fixtures have been designed to come out of the ceiling as easy as they went in.

Twist the reflector slightly counter-clockwise while applying slight downward pressure. Then, once the springs are accessible, squeeze them together and remove the fixture from ceiling.

stEP 4:

InstALL fIxturE Into cEILIng rEmovAL for sErvIcIng

For emergency egress lighting, D2LED and A2LED are tested and compatible with Dual-Lite 100VA and 250VA LiteGear®_inverters.

(20)

701 Millennium Boulevard Greenville, SC 29607 Phone: (864) 678-1000 www.prescolite.com
