The original piston-engine Defender has seen service since the 1970s in Central Africa. In the 1980s and 90s a turbine version was introduced, which has seen service with, amongst many others, customers such as the UK Ministry of Defence and the Royal Oman Police.
The latest version of the Defender comes from a similar pedigree, with its short field landing capability, durability, low purchase and operating costs and low maintenance. However, it also incorporates numerous improvements such as the extended cabin, enhanced range and endurance, increased payload, electronic flight instruments and the scope to
integrate a wide range of specialist mission equipment.
GETTING THE JOB DONE
The Defender's transit speed is 160 knots, but it also has exceptional low-speed handling and manoeuvring capabilities at around 70-90 knots allowing for continuous tight turns during low level observation, inspection and photography. At this low speed it has an endurance of around 8 hours assisted by an extended fuselage and larger wings which has been developed for improved fuel capacity. Fitted with durable and fuel efficient Rolls Royce Allison engines, 250-B17F flat-rated at 400hp with 200amp generators, the Defender has a proven track record as the world's most versatile, reliable and economic task-oriented aircraft.
“The Defender. The ultimate solution in combining cost
effectiveness and performance with rugged durability.”
Heritage
+
VERSATILE
+
DURABLE
+
COST-EFFECTIVE
+
Defender pedigree includes: BN2 Piston Defender, BN2T Turbine Defender, BN2T-4R Defender and the latest BN2T-4S Defender.
Defenders have served with distinction in armed forces and military fleets across the world, including the UK Army Corps. It is an invaluable tool in training military personnel – ten parachutists and a jump master can easily be accommodated, and a sliding door fitted. The Defender can act as a targeting system for long range weapons and land
based vehicles. For speed of reaction, flexibility, command control and communications, the Defender
is particularly efficient at maximising surveillance co-ordination when other resources are limited.
“The Defender has a proven track record, not only in
solving transportation problems simply and economically
but in providing reliable support for other military vehicles.”
Military
+
BATTLEFIELD INTELLIGENCE
+
FRONTLINE SUPPORT
+
CASEVAC
+
Suggested equipment options:
Radar, FLIR, ESM
THE DEFENDER OFFERS:
+
Four underwing hardpoints for external stores and ordnance+
Secure communications for battlefield command and control+
Overland and maritime search radar+
State of the art IR/TV cameras with laser rangefinders+
Fully integrated defensive aid suites such as MAWS, DIRCM, chaff and flares+
Additional fuel capacity for long range/endurance missions+
Operates readily from 350m unprepared strips including beaches, jungle clearings and grassUnbeatable value for money
The Defender’s low unit cost price allows customers to focus their budget on mission equipment. The Defender’s low through-life cost ensures that the financial viability of the mission is never compromised.
MILITARY
Designed to perform a wide range of demanding roles, the Defender is in service with government and law enforcement authorities all over the world. Specialist detection equipment, radars, scanning systems and cameras can be installed internally or externally from four underwing hardpoints. High resolution cameras can also be installed through
apertures in the aircraft floor or doors. Advanced communications systems on board enable ground action to be co-ordinated during crime detection, interception and arrest.
Suggested equipment options:
Video or still cameras, hand held or pod mounted detection systems, FLIR, secure communication, Tracker.
“The Defender 4000 is a most valuable tactical asset in a
broad range of challenging operations.”
Kieran O’Toole, Greater Manchester Police
Law Enforcement
+
HOMELAND SECURITY
+
URBAN SURVEILLANCE
+
+
COUNTER-TERRORISM
+
THE DEFENDER OFFERS:
+
Twin engine safety and low noise for urban surveillance+
High wing configuration, combined with a wide field of view from cockpit, low panel and blister windows, provides unobstructed view through almost 360 degrees+
Low operating and maintenance costs+
All weather day and night search capabilities+
Support and liaison in tandem with short range police helicopters and land vehicles+
Real time transfer of images and information through digital air to air or air to ground data links+
Freedom to release resources more productively used elsewhereLAW ENFORCEMENT
Extended endurance
The Defender’s range and endurance surpasses that of all UK Police helicopters employed on similar missions. The endurance of the Defender allows for complete mission coverage for the majority of police crime detection and interception operations.
TYPICAL MISSION ENDURANCE PROFILES
The Defender’s proven track record in operations related to Coast Guard, Exclusive Economic Zones and Maritime Patrol is unmatched by other aircraft in its class. Long range endurance, aided by the aircraft’s refined and enhanced fuel storage options, gives maximum surveillance/protection control with competitively low running and
maintenance costs. A variety of long range radar and search equipment can be fitted, putting the Defender a long way in front of its competition.
“We live in times of heightened awareness when it comes to the
control of Exclusive Economic Zones, border patrol, environmental
observation and homeland security. The Defender facilitates the
cost-effective execution of these tasks.”
Maritime
+
COASTAL SURVEILLANCE
+
EEZ MANAGEMENT
+
+
MARITIME COUNTER-TERRORISM
+
THE DEFENDER OFFERS:
+
A state of the art surveillance platform for coastal/border patrol+
Long range, low speed handling for aerial reconnaissance, search and rescue+
High wing configuration for maximum visibility for both pilots and crew+
Long range and endurance capabilities for extended patrol for EEZ protection, control of fisheries resources and other offshore assets+
Ship traffic and sea state observation, port and coastal observation, environmental/coastal erosion surveillanceSuggested equipment options:
MARITIME
Exceptional mission coverage
Extended range fuel options allow for both littoral and deep water surveillance capabilities, operating autonomously or in conjunction with surface vessels. In one mission the Defender could potentially cover a sea area of approximately 500,000 square km.
The Defender is operated on special missions worldwide, ranging from geological surveys and aerial mapping to environmental monitoring, pest control, and air ambulance operations. Its low loiter speed, long endurance and extremely economical performance make it the ideal solution for a variety of agencies and initiatives.
An excellent short field landing capability and extended mission range make the Defender ideal for operations in even the most inhospitable areas.
“The introduction of the BN2 has improved our programme due
to it being a very stable platform, with excellent added features,
and we are very pleased with the aircraft’s performance.”
Jerome Gueringer, Aerial Supervisor Mosquito Control Dept, Calcasieu Parish Police, USA
Special Mission
+
ENVIRONMENT
+
AERIAL SURVEY
+
AIR AMBULANCE
+
THE DEFENDER OFFERS:
+
Extremely stable platform suitable for photographic and survey work+
Underwing hardpoints for external spray systems to enhance operators’ safety+
Reconfigurable cabin for maximum operational flexibility+
Extended cabin to transport 2 stretchers, paramedic and life support equipmentTypical roles:
Unparalleled versatility
The Defender is a versatile platform built for a wide range of equipment, and its stability and endurance have made it a popular choice for operators around the world.
Height 171.5 in (4.4m)
Wing span 636.in (16.2m) Length 480.5 in (12.2m)
“The Defender has unbeatable long
range capabilities compared with
any twin turboprop in its class. It is
built for endurance and reliability,
whilst at the same time achieving
maximum cost effectiveness.”
William Hynett, Chief Executive, Britten-Norman
Technical data
Operating weights
MAXIMUM TAKE OFF 8500lb (3855kg)
MAXIMUM LANDING 8500lb (3855kg)
MAXIMUM ZERO FUEL 8300lb (3764kg)
PAYLOAD WITH MAXIMUM FUEL 1598lb (724kg)
DISPOSABLE LOAD 3600lb (1632kg) USABLE FUEL 2002lb (908kg)
Performance
TAKE-OFF DISTANCE Ground roll 1167ft/365m To clear 50ft (15m) 1855ft/565m RATE OF CLIMBTwin engine 1250ft per min/6.35m per sec
One engine 200ft per min/1.02m per sec
ABSOLUTE CEILING
Two engine 25,000ft/7620m
One engine 12,000ft/3660m
MAXIMUM CRUISE SPEED 176 knots/326 kph
ECONOMICAL CRUISE SPEED 150 knots/278kph
STALL SPEEDS (IAS)
Flaps up, power off 53 knots/98kph
Flaps down, power off 47 knots/87kph
LANDING DISTANCE
Ground roll 1012ft/308m
To clear 50ft (15m) 1934ft/589m
RANGE
TECHNICAL DATA / MISSION EQUIPMENT
“We can offer customers a bespoke
design service for their aircraft.
Our systems engineers can integrate role
equipment which is tailored to your
specific operational requirements.”
Jim Roberts, Head of Systems, BNA
“
There are a number
of different options
available, some of which
are represented here –
whatever your needs,
our design team is on
hand to help
you meet them.
”
As sole manufacturer-approved providers of Britten-Norman’s worldwide customer support, Fly BN’s maintenance and customer service personnel are unrivalled in their ability to offer operators first class product support – delivered direct to your door.
Through our Field Engineering programme, we can offer full in-country support for your aircraft ranging from inspections and surveys through to major modifications. Our UK logistics headquarters offers a 24/7 AOG spare parts service with shipments being made by our international network of distributors.
Fly BN is a wholly owned subsidiary of Britten-Norman and is backed by independent approvals from EASA. The company is also ISO 9001 accredited under the aerospace industry AS9100 standards.
Product Support
From our base at Bembridge, Isle of Wight, BN Resources offers training worldwide for pilots, mission operators, avionics technicians and maintenance engineers. In support of these Defender, Islander and Trislander courses, we can also provide courses in English for Aviation (ESP) for those who need to refresh their English prior to embarking on our aero courses. In addition to our excellent, state of the art training facilities and newly refurbished aero-club, we also have available a dedicated runway and access to the aircraft manufacturing line at Britten-Norman. We offer expert, dedicated instruction and our company is ISO 9001 accredited under the stringent rules of the AS9100. The company is further accredited as sole manufacturer-approved provider of aviation training by Britten-Norman.
Training
