THE OLDAKER DIFFERENCE.

(1)

(2)

IF YOU HAVE A NEED FOR ANY SPECIAL LEADS OR CABLES THAT ARE NO LONGER AVAILABLE FROM THE MANUFACTURER, OR IF YOU HAVE A NEW DESIGN YOU NEED MADE. LET OLDAKER DISTRIBUTORS HELP. CHECK FROM OUR LIST OF CAPABILITIES.

* CUSTOM DESIGN AND MANUFACTURING OF TEST LEADS OR WIRING DEVICES. * ASSEMBLY OF COMPLEX UNITS, BOTH ELECTRICAL & MECHANICAL.

* PACKAGING.

* RESISTANCE SOLDERING.

* 5 INJECTION MOLDING MACHINES (.5 TO 3 OZ.) BOTH HORIZONTAL & VERTICAL WITH SHUTTLE TABLES. * AUTOMATIC WIRE CUTTING & STRIPPING.

* LIGHT PUNCH PRESSES. * LATHES.

* HANDSCREW MACHINES. * DRILL PRESSES. * BANDSAWS.

* AUTOMATIC SCREW MACHINES, (SINGLE & 5 SPINDLE). * MILLING MACHINES.

* WELDING EQUIPMENT (ELECTRIC & GAS). * SHEET METAL SHEARS.

* BEND BRAKES.

STAINLESS STEELE THREADED NEEDLE TIP WITH POLISHED

POINT TAPERED

STRAIN RELIEF

HEAVY DUTY WIRE 20,000 VOLTS BREAKDOWN

5,000 VOLTS WORKING.

MOLDED FLAME RETARDANT PLASTIC WITH

SAFETY RING

ACCESSORIES ARE RECESSED FOR ADDED SAFETY

NICKLE PLATED THREADED BRASS TIP

9 LEAF SPRING FOR ADDED

CONTACT SURFACE

HEAVY DUTY WIRE 20,000 VOLTS BREAKDOWN

5,000 VOLTS WORKING. MOLDED FLAME

RETARDANT PLASTIC WITH SAFETY RING

ACCESSORIES ARE RECESSED FOR ADDED SAFETY

THE WIRE DIFFERENCE

THE PROBE DIFFERENCE

VALUE ADDED FROM OLDAKER DISTRIBUTORS

MACHINE CAPABILITIES INCLUDE :

OLDAKER MFG. CORP. 301 NORTH MAIN ST. DUNKIRK OHIO 45836 TEL : (419) 759-3551 FAX : (419) 759-3312 E-MAIL : [email protected] SPECIAL CAPABILITIES INCLUDE :

THE REPLACEMENT SAFETY SERIES THE NEEDLE TIP SAFETY SERIES

Notice the wire shown on the left, which is used on our test leads, has many more strands than the wire shown on the right. The difference enables our wire to carry more current and amps safely, and is not easily broke. Also the wire we use has EDPM Rubber insulation which stays more consistent in different temperature ranges, the other wire uses PVC insulation which becomes very stiff in cooler temperatures. Oldaker standard lead length is 4' most others are 2' to 3'.

OLDAKER WIRE THE “OTHER” WIRE

Notice the probes on the right use tips that are all nickel plated brass with small safety rings, all accessories, if any, must slide onto the small .080" diameter pin, which is not safe or secure. Oldaker probes (Shown on the left) use stainless steel needle tips with very sharp polished points for piercing insulation and sure contact, the tips are threaded so all accessories can be securely attached to the tip for better contact and safety. Also the tips are recessed so that the area where the accessory connects to the probe tip is inside the probe to prevent the user from shock. The material used for the probe is ABS, V094 Flame Retardant plastic. The safety rings are 3/4" and well positioned on the probe to keep the user from the exposed tip.

(3)

PAGE 3

INFORMATION

All Oldaker products are guaranteed, claims of defective material must be made within 10 days of shipment. . .

All products are shipped in zip polybags or plastic pouch.

Oldaker will not be liable for damages, loss or expenses arising in connection with the sale, resale, use of,

or the inability to use its products for anything other than its purpose. . .

Any products to be returned must be authorized by Oldaker or Oldaker Distributors.

IF YOU DON'T SEE IT IN THE OLDAKER CATALOG. ASK FOR IT FROM

YOUR OLDAKER DISTRIBUTOR. WE MAY BE ABLE TO HELP.

FOR A COMPLETE UP TO DATE CROSS REFERENCE

CHECK OUR WEBSITE AT www.testleads.net.

PRODUCT INDEX

ACCESSORIES

10 13 15 18 19 20

ADAPTORS & ADAPTOR LEADS

13 20 24

BNC LEADS

7 8 15 16 17

BREAKOUT LEADS

15 16

BULK WIRE & CABLE

26 CLIP LEADS

11 12

CLIPS

15 18 19 20 21

COIL CORD TEST LEADS

5 13 26

CONNECTORS

23 24

DOUBLE PLUG ADAPTORS

16 17 24

FLEXIBLE PROBE TEST LEADS

5 FUSE HOLDER

24 FUSED TEST LEADS

6 HOOK LEADS

8 9 11 13 16

HOOKS

15 21 22

JUMPER LEADS

7 14 15

LEAD BENDER

24 LEAD HOLDER

10 MICRO ADAPTORS

8 13 15

MINIATURE TEST LEADS

4 8 10 13

PART NUMBER INDEX

27 PLUGS & JACKS

22 23 24

PROBES

6 7 8 9 10 18 23 24

PROBE TIPS

24 RETRACTABLE TEST LEADS

6 SCOPE PROBES

25 SHORTING PLUG

24 SILICONE TEST LEADS

5 6 8 9

SOLDERING ACCESSORIES

25 SPECIALTY LEADS

7 10 13 16

STACKABLE TEST LEADS

11 13 14

TELEPHONE STYLE LEADS & ACCESSORIES

11 19 20

TEST LEAD KITS

6 7 8 9 10 22

(4)

NEEDLE TIP SERIES

SAFETY LEAD

The TIP on this lead is made of .080" Dia. X 5/8" long stainless steel with a polished point for insulation piercing. Threaded 8-32 for attachments. (Nickel plated). The PROBE is 5" molded flame retardant ABS plastic with 3/4" safety ring. .

The WIRE is 18 ga. (65x36) tinned copper stranding, rubber insulation .145" Dia. 20KV breakdown 5KV working. Standard length is 4 feet, Sold as Sets 1 Red and 1 Black.

PART NUMBER AND OTHER PLUG STYLES.

PART NUMBER AND OTHER PLUG STYLES. RATED 1,000 VOLTS 10 AMPS

RATED 1,000 VOLTS 10 AMPS

The TIP on this lead is made of .080" Dia. X 1/2" long brass tip threaded 8-32 for attachments. (Nickel plated). . . The PROBE is 4" molded flame retardant ABS plastic with 3/4" safety ring. .

The WIRE is 18 ga. (65x36) tinned copper stranding, rubber insulation .145" Dia. 20KV breakdown 5KV working. Standard length is 4 feet, Sold as Sets 1 Red and 1 Black. Includes clips.

518-10

518-6 518-20 518-21 518-22

518-9 518-1 519-2 518-2 _518-3 519-1 518-11 519

NOTE: MINI LEADS USE 20 ga. WIRE (41 X 36) TINNED COPPER STRANDING .105" DIA. LEAD LENGTH 3.5'

486-16

596 594

582 486-7

581 486-6 486-20 486-21 486-22

486-15 486-5 486-3 513 486-2 _486-17 495-1 486-18 476-4

NOTE: MINI LEADS USE 20 ga. WIRE (41 X 36) TINNED COPPER STRANDING .105" DIA. LEAD LENGTH 3.5'

596-5 596-6

596-7 586-1 586-20 586-21 586-22

596-4

596-1 596-2

597-2 596-8 _596-3

STANDARD REPLACEMENT SERIES

SAFETY LEAD

THIS LEAD INCLUDES THREADED CLIPS THIS LEAD INCLUDES THREADED CLIPS

THIS LEAD USES NEEDLE TIPS THIS LEAD USES

NEEDLE TIPS THIS LEAD USES

NEEDLE TIPS

_{SLIM-LINE SERIES}

TEST LEAD

The TIP on this lead is made of .080" Dia. X 5/8" long stainless steel with a polished point for insulation piercing. Threaded 8-32 for attachments. (Nickel plated). The PROBE is 4.25” slim-line .340 dia. molded flame retardant ABS plastic with non slip ribs and no safety ring. .

The WIRE is 18 ga. (65x36) tinned copper stranding, rubber insulation .145" Dia. 20KV breakdown 5KV working. .Standard length is 4 feet, Sold as Sets 1 Red and 1 Black.

_{SLIM-LINE MINI SERIES}

TEST LEAD

PAGE 4

The TIP on this lead is made of .080" Dia. X 1/2" long brass tip threaded 8-32 for attachments. (Nickel plated). . . The PROBE is 3” slim-line mini .340" dia. molded flame retardant ABS plastic with non slip ribs and no safety ring. . The WIRE is 20 ga. (41x36) tinned copper stranding, rubber insulation .105" Dia. 10KV breakdown 2KV working. Standard length is 3.5 feet, Sold as Sets 1 Red and 1 Black. Includes clips.

518-5 STANDARD PLUG STANDARD PLUG STANDARD PLUG 518 STANDARD PLUG STANDARD PLUG STANDARD PLUG 518-8 STANDARD JACK STANDARD JACK STANDARD JACK MINI RECESSED PLUG MINI RECESSED PLUG MINI PLUG MINI PLUG MINI .105” JACK MINI .105” JACK 476-15 476-16 476-14 MINI RECESSED PLUG MINI PLUG MINI .105” JACK STACKABLE STANDARD PLUG STACKABLE STANDARD PLUG STACKABLE STANDARD PLUG RETRACTABLE STANDARD PLUG RETRACTABLE STANDARD PLUG RETRACTABLE STANDARD PLUG

.080” PIN PLUG

.080” PIN PLUG #10 LUG .080” PIN PLUG

.080” PIN PLUG

.080” PIN PLUG RECESSED STANDARD PLUG RECESSED STANDARD PLUG RECESSED STANDARD PLUG RECESSED STANDARD SHORT PLUG RECESSED STANDARD SHORT PLUG RECESSED STANDARD SHORT PLUG STANDARD JACK STANDARD JACK STANDARD JACK RECESSED STANDARD PLUG .312” RECESSED STANDARD PLUG .312” RECESSED STANDARD PLUG .312” RECESSED STANDARD PLUG .360” RECESSED STANDARD PLUG .360” RECESSED STANDARD PLUG .360” RECESSED STANDARD PLUG .380” RECESSED STANDARD PLUG .380” RECESSED STANDARD PLUG .380” 518-7 SLOTTED JACK FITS SIMPSON 260 METERS SLOTTED JACK FITS SIMPSON 260 METERS SLOTTED JACK FITS SIMPSON 260 METERS

(5)

NEEDLE TIP FLEXIBLE SERIES

SAFETY LEAD

619 619-20 619-21 619-22

663

662 615-11 ₆₁₇

774-7 774-6 774-20 _774-21 774-22

774-9

774-1 774-11 _774-3

776-2 776-8

776-4 776-3 776-20 776-21 776-22

776 776-1 776-6 776-5

NEEDLE TIP FLEXIBLE SILICONE SERIES

SAFETY LEAD

THESE LEADS USE SILICONE WIRE THESE LEADS USE RUBBER WIRE FLEXIBLE PROBE FLEXIBLE PROBE

6” WIRE LENGTH 18 GA. WIRE

12” WIRE LENGTH 18 GA. WIRE

COIL CORD SERIES

TEST LEAD

_{2 CONDUCTOR COIL CORD SERIES}

TEST LEAD

PAGE 5

The TIP on this lead is made of .080" Dia. X 1/2" long brass tip. Threaded 8-32 for attachments. (Nickel plated). . .

The PROBE is 4" molded flame retardant ABS plastic with 3/4" safety ring. .

The WIRE is 2 conductors of 24 ga. (21 x 36) tinned copper stranding with .220" O.D. Coil size 5/8" 1 foot retracted 5 foot extended.

This lead has 2 wires in one coil and is very useful where there is a need for coil cord but not the tangles (1 coil cord, 2 test leads).

The TIP on this lead is made of .080" dia. X 5/8" stainless steel with a polished point for insulation piercing. Threaded 8-32 for attachments (nickel plated).

The PROBE is 5" long molded flame retardant ABS plastic with 3/4" safety ring. .

The WIRE is 18 ga. (65x36) neoprene retractable coil cord 1 foot retracted, 5 foot extended. . . These leads are Sold as Sets 1 Red and 1 Black.

The TIP on this lead is made of .080" Dia. X 5/8" long stainless steel with a polished point for insulation piercing threaded 8-32 for attachments. (Nickel plated). . . The PROBE is 5" molded P.V.C. plastic with 3/4" safety ring. .

The WIRE is 18 ga. (440x002) copper stranding, SILICONE insulation .145" Dia. -100C to +300c, 20KV breakdown 5KV working. Standard length is 4 feet, Sold as Sets 1 Red and 1 Black.

The TIP on this lead is made of .080" Dia. X 5/8" long stainless steel with a polished point for insulation piercing. Threaded 8-32 for attachments. (Nickel plated). . . The PROBE is 5" molded P.V.C plastic with 3/4" safety ring. .

The WIRE is 18 ga. (65x36) tinned copper stranding, RUBBER insulation .145" Dia. 20KV breakdown 5KV working. Standard length is 4 feet, Sold as Sets 1 Red and 1 Black.

STANDARD PLUG 774-5 STANDARD PLUG 618 STANDARD PLUG STANDARD PLUG 774 STANDARD PLUG 615 STANDARD PLUG STANDARD JACK 774-8 STANDARD JACK 664 STANDARD JACK STACKABLE STANDARD PLUG STACKABLE STANDARD PLUG RETRACTABLE STANDARD PLUG RETRACTABLE STANDARD PLUG RETRACTABLE STANDARD PLUG

.080” PIN PLUG .080” PIN PLUG

774-10 .080” PIN PLUG

665 .080” PIN PLUG

RECESSED STANDARD PLUG 774-2 RECESSED STANDARD PLUG 616 RECESSED STANDARD PLUG RECESSED STANDARD SHORT PLUG RECESSED STANDARD SHORT PLUG RECESSED STANDARD SHORT PLUG STANDARD JACK STANDARD JACK STANDARD JACK RECESSED STANDARD PLUG .312” RECESSED STANDARD PLUG .312” RECESSED STANDARD PLUG .312” RECESSED STANDARD PLUG .360” RECESSED STANDARD PLUG .360” RECESSED STANDARD PLUG .360” RECESSED STANDARD PLUG .380” RECESSED STANDARD PLUG .380” RECESSED STANDARD PLUG .380” SLOTTED JACK FITS SIMPSON 260 METERS 773-5 773-4

773-7 773-6 _773-20 773-21 773-22

773 773-2 773-1

STANDARD PLUG STANDARD PLUG STANDARD JACK RECESSED STANDARD PLUG RECESSED STANDARD SHORT PLUG STANDARD JACK RECESSED STANDARD PLUG .312” RECESSED STANDARD PLUG .360” RECESSED STANDARD PLUG .380” SLOTTED JACK FITS SIMPSON 260 METERS SLOTTED JACK FITS SIMPSON 260 METERS 620 SLOTTED JACK FITS SIMPSON 260 METERS

THIS LEAD USES NEEDLE TIPS

THIS LEAD USES NEEDLE TIPS THIS LEAD USES

(6)

ADJUSTABLE NEEDLE TIP SERIES

SAFETY LEAD

_{PART NUMBER AND OTHER PLUG STYLES.}

763-7 763-6 763-20 763-21 763-22

763-3 767-3 763-11 767-10 767-9 767-5 767-8

767-7 767-6 767-20 767-21 767-22

767 767-2 767-1 767-11

REPLACEMENT TIP 623-4

PACKAGED IN REUSABLE POUCH

KIT INCLUDES, SCREW-ON HOOKS - CLIPS - LUGS

TIP PROTECTORS TIP EXTENSIONS

MODULAR PROBE HANDLE HOUSES 600 VOLT FUSE

(INCLUDED) REPLACEMENT FUSE

PART # 2568-1

SILICONE WIRE

OTHER PLUG STYLES RETRACTABLE

TIP COVERS

REPLACEMENT PROBE 763-30 (COLOR)

NOTE : NO ATTACHMENTS CAN BE USED WITH THIS LEAD

_{DELUXE SERIES}

TEST LEAD KIT

PAGE 6

The TIP on this lead is made of .025" Dia. stainless steel with a polished point and is adjustable to 3.5" and is fully insulated to the point. The PROBE is .312" dia. X 5.25" long molded ABS plastic with .385" dia. safety ring. .

The WIRE is 18 ga. (65x36) tinned copper stranding, rubber insulation .145" Dia. 20KV breakdown 5KV working. Standard length is 4 feet, Sold as Sets 1 Red and 1 Black lead.

The TIP on this lead is made of .080" X 5/8" stainless steel with a polished point for insulation piercing, threaded 8-32 for attachments shown above. The PROBE is .312" dia. X 5.25" long molded ABS plastic with .385" dia. safety ring. .

The WIRE is 18 ga. (65x36) tinned copper stranding, rubber insulation .145" Dia. 20KV breakdown 5KV working.

Standard length is 4 feet, Sold as Sets 1 Red and 1 Black lead, includes 2 each of the accessories shown above and is packaged in a reusable plastic pouch. STANDARD PLUG 2568-4 STANDARD PLUG 763-5 STANDARD PLUG STANDARD PLUG 2568-3 STANDARD PLUG 763 STANDARD PLUG STANDARD JACK 763-8 STANDARD JACK STACKABLE STANDARD PLUG STACKABLE STANDARD PLUG RETRACTABLE STANDARD PLUG RETRACTABLE STANDARD PLUG

.080” PIN PLUG

763-10 .080” PIN PLUG

.080” PIN PLUG 763-9 .080” PIN PLUG

RECESSED STANDARD PLUG 2568-2 RECESSED STANDARD PLUG 763-2 RECESSED STANDARD PLUG RECESSED STANDARD SHORT PLUG RECESSED STANDARD SHORT PLUG STANDARD JACK 763-1 STANDARD JACK RECESSED STANDARD PLUG .312” 2568 RECESSED STANDARD PLUG .312” RECESSED STANDARD PLUG .312” RECESSED STANDARD PLUG .360” RECESSED STANDARD PLUG .360” RECESSED STANDARD PLUG .380” RECESSED STANDARD PLUG .380” SLOTTED JACK FITS SIMPSON 260 METERS 2568-5 SLOTTED JACK FITS SIMPSON 260 METERS

2568 FUSED SAFETY TEST LEAD KIT (600 VOLTS)

This fused safety test lead kit has a replaceable 600 volt fuse housed in each of the probe handles which have a pointed 4 MM plug style tip with retractable tip cover.

The PROBE is 4" molded Nylon plastic with safety ring and retractable tip covers. The WIRE is 18 ga. (65x36) tinned copper stranding, SILICONE insulation .145" Dia.. Standard length is 4 feet, sold with 600 volt fuses included. Replacement Fuse Part # 2568-1

SLOTTED JACK FITS SIMPSON 260 METERS

PART NUMBER AND OTHER PLUG STYLES. 250 VOLT ½ AMP SUPPLIED

WITH LEAD

782-16 782-6 782-20 782-21 782-22

782-15

782-3 782-11 _782-17

FUSED SERIES

SAFETY LEAD

FUSE TO PLUG LEAD LENGTH 5”

The TIP on this lead is made of .080" Dia. X 1/2" long brass tip threaded 8-32 for attachments. (Nickel plated). . . The PROBE is 4" molded flame retardant ABS plastic with 3/4" safety ring. .

The WIRE is 18 ga. (65x36) tinned copper stranding, rubber insulation .145" Dia. 20KV breakdown 5KV working. Standard length is 4 feet, Sold as Sets 1 Red and 1 Black lead.

782 STANDARD PLUG 782-5 STANDARD PLUG 782-7 STANDARD JACK STACKABLE STANDARD PLUG RETRACTABLE STANDARD PLUG 782-1 .080” PIN PLUG .080” PIN PLUG

782-2 RECESSED STANDARD PLUG RECESSED STANDARD SHORT PLUG STANDARD JACK RECESSED STANDARD PLUG .312” RECESSED STANDARD PLUG .360” RECESSED STANDARD PLUG .380” SLOTTED JACK FITS SIMPSON 260 METERS

(7)

833 MINI CLIP LEAD KIT

833-1 ALLIGATOR CLIP LEAD KIT

PACKAGED IN REUSABLE POUCH

PAK - 5

TEST LEAD KIT

BNC MODULAR

SAFETY TEST LEAD KIT

PACKAGED IN REUSABLE POUCH 497-3 HOOKS

520 LUGS #10

623 EXTENSION TIPS 458-1 CLIPS

458-1 CLIPS

598 CABLE LEAD 539 PLUGS

USED IN PAK-5

623 EXTENSION TIPS 539B PLUGS

USED IN PAK-5B

537 LEAD 538 PROBES

497-3 HOOKS 520 LUGS

#10

539 PLUGS USED IN BNC 539B PLUGS

USED IN BNC-B

538 PROBES

This lead features the ability to directly thread all accessories to both ends of the lead and eliminates accidental disconnection. All attachments recess into molded connectors to help reduce the possibility of shock. This lead consists of two 4' leads with threaded connectors on both ends, includes 1 Red and 1 Black of all accessories shown above and is packaged in a reusable plastic pouch. The wire used on this lead is a heavy duty 18 ga. 65 x 36 tinned copper stranding .145" O.D. Rubber insulation. NOTE: To order PAK-5 Kit with recessed plugs use part number PAK-5B.

This lead features the ability to directly thread all accessories to the end of the lead and eliminates accidental disconnection. All attachments recess into molded connectors to help reduce the possibility of shock. The lead comes as you see it above with 1 red and 1 black of all the accessories shown above and is enclosed in a reusable plastic pouch. The BNC lead (598) uses 3' of RG/58 CU shielded cable with 19 x .0071 tinned copper stranding center conductor, .195" O.D. PVC insulation. Rated 50 ohms, 1900 volts, color black, the connector wire is 7” of 18 ga. 65 x 36 tinned copper stranding .145" O.D. Rubber insulation. NOTE: to order BNC Kit with recessed plugs (539B) order BNC-B Kit.

PAGE 7

1 EACH OF 5 DIFFERENT COLORS, RED, WHITE, YELLOW, GREEN & BLACK

(5 LEADS) 2 EACH OF 5 DIFFERENT

COLORS, RED, WHITE, YELLOW, GREEN & BLACK

(10 LEADS)

This is a good quality lead for the money and very useful for most handymen, this lead includes 1 each of 5 different colored, 24 ga. Wire, 1 foot long. Has clips and boots on both ends.

This is a good quality lead for the money and very useful for most handymen, this lead includes 2 each of 5 different colored, 24 ga. Wire, 2 foot long. Has mini clips and boots on both ends.

MODULAR SERIES

SAFETY TEST LEAD KIT

REUSABLE POUCH

This lead has a standard banana plug recessed into the probe handle to allow all of the accessories shown above to plug directly into the probe handle. The PROBE is 4" molded flame retardant ABS plastic with 3/4" safety ring. .

The WIRE is 18 ga. (65x36) tinned copper stranding, rubber insulation .145" Dia. 20KV breakdown 5KV working.

Standard length is 4 feet, sold as Sets 1 Red and 1 Black lead, includes 2 each of the accessories shown above and is packaged in a reusable plastic pouch.

660-2 HOOK 491A PLUG

458-3 CLIP 577-5 TIP

660-3 NEEDLE TIP 660-1 LUG << PRESS-ON ACCESSORIES

660-20 660-8

STANDARD PLUG

660-10 STANDARD JACK

660-7 STACKABLE STANDARD PLUG

660-14 RETRACTABLE STANDARD PLUG

660-6 .080” PIN PLUG 660-12 .080” PIN PLUG

660-22 RECESSED STANDARD SHORT PLUG

660-5 STANDARD JACK 660-9 RECESSED STANDARD PLUG .312”

660-21 RECESSED STANDARD PLUG .360” RECESSED

STANDARD PLUG .380”

660 RECESSED STANDARD PLUG

660-11 SLOTTED JACK

FITS SIMPSON 260 METERS

660-4 STANDARD PLUG

(8)

These micro adapter kits allow accessories that were once reserved for scopes and scope probes to be used with standard test meters and is a new method of connecting IC's, test points, wire wrap pins, terminals and other miniature components to standard leads. The lead (4262) for 793 kit, presses onto any test lead with a .080" dia. Probe tip, and allows the user to attach any of the micro hooks or clips to the end of any standard lead set. The lead (4262-1) for 793-1 kit, allows the user to attach micro accessories to either end. The set includes 1 red, 1 black 4262 lead adapter, 1 red 4379 clip, 1 red 4359 pico hook, 1 black 4258 micro hook, 1 black 4256 pincer hook.

BNC / DUAL PLUG MICRO ADAPTER KIT

598 KIT USES RG/58 CABLE

490 KIT USES RG/174 CABLE

506 KIT USES RG/58 CABLE 877 KIT USES RG/174 CABLE

PAGE 8

These adapter kits allow micro accessories to be used with BNC or Dual Plug Cables both RG/58 and RG/174. A new method of connecting IC's, test points, wire wrap pins, terminals and other miniature components to BNC RG/58 or RG/174 cable, using a .025” Square Socket Connection. You have your choice of either BNC or Dual plug on one end and includes 1 red 4379 clip, 1 red 4359 pico hook, 1 black 4258 micro hook, 1 black 4256 pincer hook. To order BNC RG/58 Kit use part # 598 Kit. To order BNC RG/174 Kit use part # 490 KIT, For Dual Plug RG/58 Kit use part # 506 Kit. To order Dual Plug RG/174 Kit use Part # 877 Kit.

954-1 MODULAR TEST LEAD KIT

954-2 MODULAR TEST LEAD KIT

954-3 MODULAR TEST LEAD KIT

954 MODULAR TEST LEAD KIT

PACKAGED IN

REUSABLE POUCH PACKAGED IN

REUSABLE POUCH

PACKAGED IN REUSABLE POUCH

PACKAGED IN REUSABLE POUCH 944-3 CLIP

944-1 CLAMP

944-4 HOOK

944-2 PIN PROBE 769-6S 6’

SILICONE LEAD SET

769-6S 6’ SILICONE LEAD SET

769-6S 6’ SILICONE LEAD SET 769-6S 6’ SILICONE LEAD SET

946 PROBE

946 PROBE 946 PROBE

946 PROBE 793-1 KIT

793-1 KIT TYPICAL APPLICATION THESE KITS USE A .025” SQUARE SOCKET AND PIN CONNECTION

793 KIT TYPICAL APPLICATION 793 KIT

MICRO ADAPTER TEST LEAD KITS

43 CLIP 79

K 43₅₉

H_O O 425_{8 H}

OO_K 4262

LEAD SET

4379 CLIP

.025” SOCKET .025”

SOCKET

24 Ga. 7” LONG

CABLE LENGTH 3 FEET CABLE LENGTH

3 FEET

4258 HOOK 4359 HOOK

4256 HOOK

4262-1 LEAD SET

42 56_H

O O

K

This test lead kit shown above is recommended for electrical, industrial and HVAC applications. The 954 kit comes with 944-3 Clip Probes, 946 Probe Handles and 769-6S 6’ with Silicone Insulation, and Shrouded Right Angle 4mm Plugs on each end. Kit is packaged in a reusable plastic pouch. Rated 1,000 volts / 20 amp.

This test lead kit shown above is recommended for electrical, industrial and HVAC applications. The 954-1 kit comes with 944-1 Clamp Probes, 946 Probe Handles and 769-6S 6’ with Silicone Insulation, and Shrouded Right Angle 4mm Plugs on each end. Kit is packaged in a reusable plastic pouch. Rated 1,000 volts / 20 amp.

This test lead kit shown above is recommended for electrical, industrial and HVAC applications. The 954-2 kit comes with 944-4 Hook Probes, 946 Probe Handles and 769-6S 6’ with Silicone Insulation, and Shrouded Right Angle 4mm Plugs on each end. Kit is packaged in a reusable plastic pouch. Rated 1,000 volts / 20 amp.

This test lead kit shown above is recommended for electrical, industrial and HVAC applications. The 954-3 kit comes with 944-2 Pin Probes, 946 Probe Handles and 769-6S 6’ with Silicone Insulation, and Shrouded Right Angle 4mm Plugs on each end. Kit is packaged in a reusable plastic pouch. Rated 1,000 volts / 20 amp.

(9)

956 TEST LEAD KIT

956-1 TEST LEAD KIT

PAGE 9

1520 SUPER DELUXE TELECOM LEAD KIT

1501 ECONOMY ELECTRONIC LEAD KIT

1500 SUPER ELECTRONIC LEAD KIT

1510 SUPER INDUSTRIAL AUTOMOTIVE KIT

946 PLUG TIP PROBES 769-2S 6’

LEAD SET

949-1 LARGE CLIPS 949-1 CLIPS _{949-2 LOW}

PROFILE CLIPS 769-2S 6’

LEAD SET

LEFT TO RIGHT 944-1 CLAMP PROBES

944-3 CLIP PROBES 944-2 PIN PROBES 944-4 HOOK PROBES 667-2

LEAD SET 667-3

LEAD SET 946 PLUG TIP PROBES 946 PLUG TIP PROBES

958 DELUXE TEST LEAD KIT

968 TEST LEAD KIT

660-1 LUGS

660-1 LUG

513-27 HOOK LEADS

513-27 HOOK LEAD

4262-2 MICRO LEADS 4256 HOOK

4359 HOOK 963 CLIPS

963 CLIPS

949-1 CLIPS 949-1 CLIPS

949-1 CLIPS

944-3 CLIP PROBES

944-3

CLIP PROBES 992-1 HEAVY DUTY HOOKS WITH NEEDLE 946 PROBES

820 TELE. CLIPS 944-1

CLAMP PROBES

521-1 ADAPTERS 963 MINI CLIPS

946 PLUG TIP PROBES

946 PLUG TIP PROBES PLASTIC

POUCH

PLASTIC POUCH

PLASTIC

POUCH _PLASTIC

POUCH PLASTIC

POUCH

769-2S 6’

SILICONE WIRE _{SILICONE WIRE}

SILICONE WIRE

RUBBER WIRE RUBBER WIRE

SILICONE WIRE

SILICONE WIRE SILICONE WIRE

SILICONE WIRE

769-2S 6’

769-2S 6’ PLASTIC

POUCH

PLASTIC POUCH

1521 ECONOMY TELECOM TEST LEAD KIT

660-1 LUGS 820 TELEPHONE

TYPE CLIP (RED)

521-1 PLUG ADAPTOR (RED)

946 BANANA PLUG TIP PROBES 769-2S 6’

LEAD SET

PLASTIC POUCH

949-1 CLIPS

1511 ECONOMY INDUSTRIAL / AUTOMOTIVE LEAD KIT

660-1 LUGS 946 BANANA PLUG TIP PROBES

992-1 HOOK WITH NEEDLE RED ONLY

769-2S 6’ LEAD SET

949-1 CLIPS

(10)

PAGE 10

814 MINI HOOK LEAD

518-26 TEST LEAD KIT

2536 TEST LEAD KIT

518-27 TEST LEAD KIT

997-1 TEST LEAD KIT

876 TEST LEAD HOLDER

997 TEST LEAD KIT

518-28 TEST LEAD KIT

This mini lead uses 24 ga. Miniature test lead wire ( 45 x 40 ) tinned copper stranding with rubber insulation .066" Dia. Colors available red, black, green, white & yellow. Standard lengths are 8", 12", 24", 36". Sold by color & length. Other lengths are available upon request.

814-1 (LENGTH & COLOR) INCLUDES HOOK ON ONE END ONLY.

PLASTIC POUCH

SCREW-ON 40 AMP CLIP SET

SCREW-ON 40 AMP BLACK CLIP 667-3

LEAD SET

20 AMP BATTERY CLIP SET 945

PIN PROBES

518-6 RECESSED PLUGS

WITH NEEDLE TIP PROBES

STRAIGHT RECESSED PLUGS WITH RED NEEDLE TIP PROBE AND 40 AMP BLACK CLIP 518-2

STRAIGHT RECESSED PLUGS WITH NEEDLE

TIP PROBES

PLASTIC POUCH PLASTIC

POUCH

458-4 ALLIGATOR

CLIP SET

458-4 ALLIGATOR

CLIP SET 532-2

LEAD SET 532-2

LEAD SET

944-4 RED HOOK 944-4

RED HOOK

660-1 LUGS 660-1

LUGS

946 PROBES 946

PROBES

PLASTIC POUCH PLASTIC

POUCH

PLASTIC POUCH

This test lead holder measures 5.250" wide by 3" high and has 6 slots 3.250" deep for leads, the holder also has 2 screw holes for wall mounting. Color is blue.

(11)

TELEPHONE STYLE CLIP LEADS

HOOK SERIES LEADS

EXTENDED HOOK STYLE LEADS

STACKABLE SERIES TEST LEADS

PAGE 11

527-5 527-9

527-7 527-6 527-20 527-21 527-22

527-4

527-1 527-2 527-3 527-10 ₅₂₇

STANDARD PLUG STANDARD PLUG STANDARD JACK STACKABLE STANDARD PLUG RETRACTABLE STANDARD PLUG

.080” PIN PLUG RECESSED STANDARD PLUG RECESSED STANDARD SHORT PLUG STANDARD JACK RECESSED STANDARD PLUG .312” RECESSED STANDARD PLUG .360” RECESSED STANDARD PLUG .380” SLOTTED JACK FITS SIMPSON 260 METERS

NOTHING ON END 527-11

This lead has a telephone style clip & boot on one end with a single penetrating pin for insulation piercing and a cluster of hardened needles for a sure connection on groups of wires, also has an angled jaw for hard to reach areas. The other end has various type connections to fit any meter or connection. The wire on standard leads is 18 ga. (65 x 36) tinned copper stranding .145" O.D. RUBBER insulation. Mini leads use 20 ga. (41 x 36) tinned copper stranding .120" O.D. RUBBER insulation. All standard leads are available in SILICONE wire (440 x .002) copper stranding .145" O.D. To order silicone just add "S" to the part number. Stocked length is 4 foot for standard leads, 3.5" for mini leads. These leads are sold as Sets 1 Red and 1 Black.

THIS HEAVY DUTY CLIP HAS A SINGLE PENETRATING PIN FOR INSULATION PIERCING, ALSO HAS A CLUSTER OF

NEEDLES ALONG WITH ANGLED JAW.

This lead has a molded polyethelene stackable standard plug on one end with various other connections on the other end to fit any type of meter or connector. The wire on standard leads is 18 ga. (65 x 36) tinned copper stranding .145" O.D. RUBBER insulation. All standard leads are available in SILICONE wire (440 x .002) copper stranding .145" O.D. To order silicone just add "S" to the part number. Stocked length is 4 foot. These leads are sold as Sets 1 Red and 1 Black, single leads of different lengths can be ordered separately.

This lead has a 4.5" hook on one end which is made of molded nylon and gold plated hook with various other connections on the other end to fit any type of meter or connection. The wire on standard leads is 18 ga. (65 x 36) tinned copper stranding .145" O.D. RUBBER insulation. Mini leads use 20 ga. (41 x 36) tinned copper stranding .120" O.D. RUBBER insulation. All standard leads are available in SILICONE wire (440 x .002) copper stranding .145" O.D. To order silicone just add "S" to the part number. Stocked length is 4 foot for standard leads, 3.5" for mini leads. These leads are sold as Sets 1 Red and 1 Black, single leads of different lengths can be ordered separately.

513-9 513-10

513-11 513-12 513-20 513-21 513-22

513-14

513-16 513-13 548 513-17 513-18

STANDARD PLUG STANDARD PLUG STANDARD JACK 513-25 MINI PLUG STACKABLE STANDARD PLUG RETRACTABLE STANDARD PLUG

.080” PIN PLUG

513-15 .080” PIN PLUG

RECESSED STANDARD PLUG RECESSED STANDARD SHORT PLUG STANDARD JACK RECESSED STANDARD PLUG .312” RECESSED STANDARD PLUG .360” RECESSED STANDARD PLUG .380” SLOTTED JACK FITS SIMPSON 260 METERS

NOTHING ON END 513-26 HOOK 513-19 813-12 527-8 813-8 813-5 813-10

813-7 _813-6 _813-20 _813-21 _813-22

813-4

813-1 813-2 813-3 813-11 _813-15

STANDARD PLUG STANDARD PLUG STANDARD JACK MINI PLUG STACKABLE STANDARD PLUG RETRACTABLE STANDARD PLUG

.080” PIN PLUG

NOTHING ON END 813-9 813

EXTENDED HOOK

This lead has a 2.5" hook on one end which is made of molded nylon and gold plated hook with various other connections on the other end to fit any type of meter or connection. The wire on standard leads is 18 ga. (65 x 36) tinned copper stranding .145" O.D. RUBBER insulation. Mini leads use 20 ga. (41 x 36) tinned copper stranding .120" O.D. RUBBER insulation. All standard leads are available in SILICONE wire (440 x .002) copper stranding .145" O.D. To order silicone just add "S" to the part number. Stocked length is 4 foot for standard leads, 3.5" for mini leads. These leads are sold as Sets 1 Red and 1 Black.

812-12 _812-14 812-8

812-5 812-10

812-7 _812-6 812-20 812-21 812-22

812-4

812-1 812-2 812-3 812-11 812-13

STANDARD PLUG STANDARD PLUG STANDARD JACK 812-16 MINI RECESSED PLUG 513-1 813-14 MINI RECESSED PLUG MINI RECESSED PLUG MINI PLUG MINI .105” JACK STACKABLE STANDARD PLUG RETRACTABLE STANDARD PLUG

.080” PIN PLUG

NOTHING ON END 812-9 812

(12)

ALLIGATOR CLIP LEADS

_{PART NUMBER AND OTHER PLUG STYLES.}

PART NUMBER AND OTHER PLUG STYLES. 510-6

510-3 510-7

510-4 510-2 510-20 510-21 510-22

510-5

550 510-1 ₅₆₅ 510-11 ₅₃₄

511-13

609

511-8 511-9

511-10 511-12 511-20 511-21 511-22

511-4 511-1 511-3 511-5 511-2 543 511-6 511-11 574 604 607-1

607 _604-1 _604-20 _604-21 _604-22

609-1

603 499-1 606-1 603-11 ₆₀₅

MINIGATOR CLIP LEADS

BATTERY STYLE CLIP TEST LEADS

PART NUMBER AND OTHER PLUG STYLES. THIS LEAD IS ALSO AVAILABLE

USING 14 Ga. WIRE. RED OR BLACK

CROCODILE CLIP LEADS

PAGE 12

STANDARD PLUG STANDARD PLUG STANDARD PLUG STANDARD PLUG STANDARD PLUG STANDARD PLUG STANDARD JACK STANDARD JACK STANDARD JACK MINI RECESSED PLUG 476-8 MINI RECESSED PLUG MINI PLUG 608 MINI PLUG MINI .105” JACK STACKABLE STANDARD PLUG STACKABLE STANDARD PLUG STACKABLE STANDARD PLUG RETRACTABLE STANDARD PLUG RETRACTABLE STANDARD PLUG RETRACTABLE STANDARD PLUG

.080” PIN PLUG

.080” PIN PLUG .080” PIN PLUG

.080” PIN PLUG

.080” PIN PLUG RECESSED STANDARD PLUG RECESSED STANDARD PLUG RECESSED STANDARD PLUG RECESSED STANDARD SHORT PLUG RECESSED STANDARD SHORT PLUG RECESSED STANDARD SHORT PLUG STANDARD JACK STANDARD JACK STANDARD JACK RECESSED STANDARD PLUG .312” RECESSED STANDARD PLUG .312” RECESSED STANDARD PLUG .312” RECESSED STANDARD PLUG .360” RECESSED STANDARD PLUG .360” RECESSED STANDARD PLUG .360” RECESSED STANDARD PLUG .380” RECESSED STANDARD PLUG .380” RECESSED STANDARD PLUG .380” SLOTTED JACK FITS SIMPSON 260 METERS SLOTTED JACK FITS SIMPSON 260 METERS SLOTTED JACK FITS SIMPSON 260 METERS

This lead has an alligator clip & boot on one end which is made of nickel plated steel, ( available in copper) with PVC boot and has various other connections on the other end to fit any type of meter or connection. The wire on standard leads is 18 ga. (65 x 36) tinned copper stranding .145" O.D. RUBBER insulation. All standard leads are available in SILICONE wire (440 x .002) copper stranding .145" O.D. To order silicone just add "S" to the part number. Stocked length is 4 foot. These leads are sold as Sets 1 Red and 1 Black. Other lengths available..

This lead has a minigator clip & boot on one end which is made of nickel plated steel, ( available in copper) with PVC boot and has various other connections on the other end to fit any type of meter or connection. The wire on standard leads is 18 ga. (65 x 36) tinned copper stranding .145" O.D. RUBBER insulation. Mini leads use 20 ga. (41 x 36) tinned copper stranding .120" O.D. RUBBER insulation. All standard leads are available in SILICONE wire (440 x .002) copper stranding .145" O.D. To order silicone just add "S" to the part number. Stocked length is 4 foot for standard leads, 3.5" for mini leads. These leads are sold as Sets 1 Red and 1 Black. Other lengths and colors (Green, White, Yellow & Blue).

NOTHING ON END NOTHING ON END NOTHING ON END ALLIGATOR CLIP MINIGATOR CLIP 510 511 764-5 511-14 510-12

This lead has a 20 AMP battery clip & boot on one end which is made of nickel plated steel, ( available in copper) with PVC boot and has various other connections on the other end to fit any type of meter or connection. The wire on standard leads is 18 ga. (65 x 36) tinned copper stranding .145" O.D. RUBBER insulation. Mini leads use 20 ga. (41 x 36) tinned copper stranding .120" O.D. RUBBER insulation. All standard leads are available in SILICONE wire (440 x .002) copper stranding .145" O.D. To order silicone just add "S" to the part number. Stocked length is 4 foot for standard leads, 3.5" for mini leads. These leads are sold as Sets 1 Red and 1 Black.

This lead has a crocodile clip & boot on one end which is made of nickel plated steel, with PVC boot and has various other connections on the other end to fit any type of meter or connection. The wire on standard leads is 18 ga. (65 x 36) tinned copper stranding .145" O.D. RUBBER insulation. Mini leads use 20 ga. (41 x 36) tinned copper stranding .120" O.D. RUBBER insulation. All standard leads are available in SILICONE wire (440 x .002) copper stranding .145" O.D. To order silicone just add "S" to the part number. Stocked length is 4 foot for standard leads, 3.5" for mini leads. These leads are sold as Sets 1 Red and 1 Black..

602

BATTERY CLIP

571

570 570-3

570-2 _570-1 _570-20 _570-21 _570-22

571-1

572 572-1 572-3 572-11 ₆₁₀

STANDARD PLUG STANDARD PLUG STANDARD JACK 764-3 MINI PLUG STACKABLE STANDARD PLUG RETRACTABLE STANDARD PLUG

.080” PIN PLUG

NOTHING ON END

764-6 764

CROCODILE CLIP

592

(13)

.100"

.185"

PAGE 13

2.250" HOOK

6" OF 18 GA. RUBBER INSULATED TEST

LEAD WIRE STANDARD BANANA JACK

PLUGS INTO ANY LEAD WITH STANDARD BANANA

PLUG OF ANY TYPE.

2602 EXTENDED PROBE TEST LEAD SERIES

COIL CORD JUMPER LEADS

992-1 AUTOMOTIVE TYPE HOOK ADAPTER LEAD

982-1 GRIPPER ADAPTER LEAD

513-27 HOOK ADAPTER LEAD

2567 TEST LEAD EXTENSION

5.5" HOOK WITH INSULATION PIERCING NEEDLE.

STANDARD BANANA JACK PLUGS INTO ANY LEAD WITH STANDARD BANANA

PLUG OF ANY TYPE.

This lead is very useful where hard to make connections are required. The narrow size allows close side by side connection for high density IC's. The hook has 2 blades that are connected directly to the wire and are shaped to make a secure connection. The other end has a standard banana jack which fits any standard banana plug, recessed or standard. The wire is 6" of 20 ga. PVC wire .100" O.D. MATERIAL = Molded nylon with stainless steel blades.

SOLD = as 1 lead. Colors available are Red or Black.

This hook lead permits direct hook-up either vertically or horizontally over square wire wrap pins. The other end has a standard banana jack which fits any standard banana plug, recessed or standard. The wire used is 6" of 18 ga. RUBBER wire .140" O.D.

MATERIAL = Molded nylon with gold plated beryllium copper hook. SOLD as 1 each. Colors available, Red or Black.

2.160" GRIPPER HOOK 6" OF 20 GA. PVC

INSULATED TEST LEAD WIRE

STANDARD JACK PLUGS INTO ANY LEAD

WITH STANDARD PLUG OF ANY TYPE. 776-23

776-24

776-25

776-26

776-27

776-28 R/A SHROUDED PLUG TO BANANA JACK

MOLDED “Y” 18 GA. RUBBER WIRE_{6” LONG}

2 CONDUCTOR COIL CORD 1 FOOT RETRACTED, 5 FOOT EXTENDED

STRAIGHT PLUG TO R/A SHROUDED PLUG R/A .380” SHROUDED PLUG TO STRAIGHT SHROUDED PLUG

STRAIGHT PLUG TO R/A PLUG R/A SHROUDED PLUG TO R/A PLUG

R/A PLUG TO ALLIGATOR CLIP

This lead is very useful where a heavy duty hook is needed. This lead accessory has an insulation piercing tip in the hook base. The other end has a standard banana jack which fits any standard banana plug, recessed or standard. The wire used is 6" of heavy duty 18 ga. 65 x 36 tinned copper stranding .140" O.D. MATERIAL = Molded nylon with nickel silver contact.

SOLD = as 1 lead. Colors available are Red or Black.

This lead adapter allows the user to add 4' to any test lead that has a recessed standard banana plug.

The WIRE is 4' of 18ga. (65x36) tinned copper stranding, RUBBER insulation .145" Dia. Wire is rated 20KV breakdown, 5KV working. SOLD as 1 Set. Red and Black.

15” PROBES

2602-5 STANDARD PLUG 2602

STANDARD PLUG

2602-8 STANDARD JACK

2602-2 RECESSED STANDARD PLUG

2602-22 RECESSED STANDARD SHORT PLUG 2602-1

STANDARD JACK

2602-6 RECESSED STANDARD PLUG .312”

2602-7 SLOTTED JACK

FITS SIMPSON 260 METERS

The TIP on this lead is made of .080" Dia. X 5/8" long stainless steel with a polished point. (Nickel plated). The PROBE is LONG For hard to reach areas.

The WIRE is 18 ga. (65x36) tinned copper stranding, rubber insulation .145" Dia. 20KV breakdown 5KV working. Standard length is 5 feet, Sold as Sets 1 Red and 1 Black.

(14)

532

667 547 768

2576 857

2577 858

2578 859

2579 860

2522

-3 -2 -1 -9

-19

JUMPER LEADS

THESE LEADS ARE ALSO AVAILABLE WITH SILICONE WIRE,

JUST ADD " S " TO THE PART NUMBER.

These jumper leads are available in 4 different styles of wire. Style 1 is 20 ga. (41 x 36 ) tinned copper stranding .120" Dia. Rubber insulation. Style 2 is 18 ga. ( 65 x 36 ) tinned copper stranding .145" Dia. Rubber insulation, another option is 14 ga. ( 79 x 45 ) tinned copper stranding .145” O.D. Style 3 is18 ga. ( 440 x .002 ) copper stranding .145" SILICONE insulation. Standard length 4'. Other lengths available upon request. Style 4 is coil cord, 20 ga. ( 65 x 36 ) tinned copper stranding .165" Dia. Neoprene insulation, 1' retracted, 5' extended, coil size .750". Available in Black and Red coils only.

UNLESS SPECIFIED THESE LEADS ARE SOLD AS SINGLE LEADS 4 FEET LONG, WITH STANDARD COLORS RED OR BLACK. PART NUMBERS 532, 667, 547 & 768 ALSO AVAILABLE IN GREEN, BLUE, YELLOW & WHITE.

*

THESE LEADS USE 20 GA. RUBBER INSULATED WIRE 42" LONG. OTHER LENGTHS AVAILABLE UPON REQUEST,

NOT AVAILABLE WITH COIL CORD. . . STANDARD

PLUG

FIRST END LEAD WIRE PART #

18 Ga.

FIRST END LEAD WIRE PART # 14 Ga.

FIRST END LEAD WIRE PART # COIL CORD

SECOND END PART #

RECESSED PLUG RECESSED

PLUG .080" PIN PLUG 3/4" LONG

18 GA. HEAVY DUTY RUBBER WIRE

18 GA. HEAVY DUTY RUBBER WIRE LEAD SHOWN

532-2

LEAD SHOWN 2522-19

PAGE 14

549

769

850

851

852

770

771

772

838

853

854

855

2581 861

2582 862

2583 863

2584 864

2585 865

2586 866

2587 867

2588 868

N/A N/A

2589 N/A

2580 N/A

N/A N/A

-5

-6

-12

-13

-14

-8

-7

-10

-11

-15

-16

-17

*

RETRACTABLE STANDARD PLUG

MINI RECESSED BANANA PLUG

MINI BANANA PLUG

MINI JACK .105" DIA. STANDARD PLUG RECESSED STACKABLE

STANDARD PLUG

RECESSED STANDARD PLUG

.312"

.380"

.360"

RECESSED STANDARD SHORT

PLUG

STANDARD JACK

SLOTTED JACK FITS SIMPSON 260 METERS

.080" PIN PLUG

-0

NOTHING ON END

2594 2595 N/A -20

STACKABLE STANDARD PLUG

(15)

994 ADAPTOR LEAD

PAGE 15

961-2 TWEEZER LEAD

961-1 TWEEZER LEAD

STANDARD BANANA

PLUGS 18 Ga. WIRE

LENGTH 5”

BNC MALE

The tweezers lead is an easy way to test surface mount devices (SMD) and allows the user one hand testing. Tips are gold plated, durable and assure positive electrical connection. Maximum voltage rating is 250 VRMS @ 3 Amps. The cable is RG/174U. Lead length 4 feet.

765 BNC FEMALE BREAKOUT LEAD

NOTHING ON END NOTHING ON END

ALLIGATOR CLIP MINIGATOR CLIP STACKABLE PLUG ALLIGATOR CLIP MINIGATOR CLIP STACKABLE PLUG

MINI HOOK MINI HOOK

The wire on these breakout leads is 20 ga. (41 x 36) tinned copper stranding with PVC insulation. The BNC Male connector has gold plated center contacts with a black polyethelene housing. Red wire connected to center conductor. To order add the dash number of the type of connection you want on the other end. The wire on these breakout leads is 20 ga. (41 x 36) tinned copper stranding with

PVC insulation. The BNC Female connector has gold plated center contacts with a black polyethelene housing. Red wire connected to center conductor. To order add the dash number of the type of connection you want on the other end.

-4 HOOK

-5

-1 -2

-0

-3 -4

HOOK -5

-1 -2

-0

-3

775 BNC MALE BREAKOUT LEAD

4379 MINIGATOR CLIP

WITH .025” PIN CONNECTOR

947 MINIATURE GRIPPER

948 SPRING LOADED PIN PROBE

2.125"

This bendable, clamp style, rotating gripper can also be used with leads 4262 and 4262-1. It is well suited for use with surface mount devices, and has extremely thin wires, can bend 35 degrees and still remain fully operable. It has two .025" square pins to plug into leads and is rated 42V. SOLD as 1 each. Red or Black.

BENDS 35o

This .030" dia. Needle point pin probe is made of stainless steel for durability and is spring loaded for reliability and accuracy. It has a .025" square pin to fit leads 4262 and 4262-1. Rated 50V. SOLD as 1 each. Red or Black.

SPRING LOADED This adaptor lead set is replacement for the B&K Precision # FP-6. Has standard

banana plugs on one end and 2.5" hooks on other.

WIRE is 20 ga. (41 x 36) tinned copper stranding with PVC insulation... Standard length is 4 feet, SOLD as Sets 1 Red, 1 Black and 1 Green

1.625"

This minigator clip has a .025" square pin for direct connection to square socket on wire (Oldaker part # 4262 & 4262-1).

MATERIAL = Nickel plated steel clip with molded PVC boot. SOLD = as 1 each. Red Only.

(16)

506 SERIES BREAKOUT LEAD

3 FEET RG/58, 50 OHM CABLE OTHER LENGTH AVAILABLE

UPON REQUEST.

3/4" DUAL STACKABLE BANANA PLUG.

506-2 ALLIGATOR CLIP

ALLIGATOR CLIP

506-7 506-4 506-11

506-14 506-8 506-3

506-5 506-9 506-10

MINIGATOR CLIP

STANDARD HOOK

MINI HOOK

MINI HOOK EXTENDED HOOK

EXTENDED HOOK

EXTENDED HOOK MINIGATOR CLIP

MINIGATOR CLIP

506-6 NOTHING ON

ONE END.

NOTHING ON ONE END.

NOTHING ON ONE END. 7", 18 GA. HEAVY DUTY

RUBBER INSULATED WIRE OTHER STYLES

LISTED BELOW

3 FEET RG/58, 50 OHM CABLE OTHER LENGTH AVAILABLE

UPON REQUEST. GOLD

CENTER PIN

MOLDED STRAIN RELIEF AVAILABLE IN OTHER COLORS

598-2

598-6 598-10

598-4

598-12 598-7 598-3

598-1 598-9 598-8 598-5

7", 18 GA. HEAVY DUTY RUBBER INSULATED WIRE OTHER STYLES

LISTED BELOW

BNC MALE

3 FEET RG/58, 50 OHM CABLE OTHER LENGTHS AVAILABLE

UPON REQUEST. _GOLD

CENTER PIN MOLDED STRAIN RELIEF

AVAILABLE IN OTHER COLORS

CABLE DESCRIPTION The cable used on the above leads is RG/58, center conductor is (19 x 0071) tinned copper stranding .195" O.D. PVC insulation Cap=29.5 PF/FT,

color black. BNC FEMALE

766-1

766-6 _766-3 766-10

766-11 _766-7 766-2

766-4 766-9 766-8 766-5

7", 18 GA. HEAVY DUTY RUBBER INSULATED WIRE OTHER STYLES

LISTED BELOW

3 FEET RG/174, 50 OHM CABLE OTHER LENGTHS AVAILABLE

UPON REQUEST. BNC MALE

KELVIN CLIP 490-13 KELVIN CLIP

598-13

ALLIGATOR CLIP 490-2

MINI HOOK 490-4 STANDARD HOOK

490-1

MINIGATOR CLIP 490

NOTHING ON ONE END.

490-3 7", 24 GA. RUBBER

INSULATED WIRE

OTHER STYLES LISTED BELOW

AVAILABLE WITH BOOT THAT COMPLETELY COVERS BNC, AVAILABLE IN COLORS

4901 SERIES

AVAILABLE WITH BOOT THAT COMPLETELY COVERS BNC, AVAILABLE IN COLORS

5981 SERIES

CABLE DESCRIPTION The cable used on this lead is RG/174, center conductor is (7 x 34) tinned copper stranding .125" O.D. PVC insulation Cap=30.0 PF/FT, color black.

PAGE 16

STANDARD PLUG

STACKABLE STANDARD PLUG

RETRACTABLE STANDARD PLUG

.080” PIN PLUG

490-12 .080” PIN PLUG .080” PIN PLUG

(17)

BNC / DUAL PLUG LEADS

506-1 = RG/58 506 = ZIP CORD 506-13 = RG/174 3/4" DUAL STACKABLE

BANANA PLUG. GOLD

PLATED PIN 559 = RG/58 599-1 = RG/174

GOLD PLATED SOCKET 766 = RG/58

GOLD PLATED

PIN 541-2 = RG/58 541-3 = RG/59 541-4 = RG/174

OTHER COLOR STRAIN RELIEFS AVAILABLE

BLACK, RED, GREEN, YELLOW, BLUE, WHITE

GOLD PLATED SOCKET 621-1 = RG/58 621-2 = RG/59

GOLD PLATED SOCKET 622-1 = RG/58 622-2 = RG/59

GOLD PLATED

PIN BNC

MALE

BNC MALE 541 = RG/58

OTHER COLOR BOOTS AVAILABLE, BLACK, RED, GREEN, YELLOW, BLUE, WHITE STANDARD LENGTH ON THESE

LEADS IS 3' , OTHER LENGTHS AVAILABLE UPON REQUEST

CABLE DESCRIPTION

RG/58 cable has a center conductor of (19 x 007) tinned copper stranding .195" O.D. Insulation, dielectric is 116P nom, Cap 29.5 PF/Ft. Maximum operating voltage 1900 - 50 ohms, temp. Rating -55c to +90c. Color Black.

RG/174 cable has a center conductor of (7 x 34) tinned copper stranding .105" O.D. PVC Insulation, dielectric is 116P nom, Cap 30.0 PF/Ft. Maximum operating voltage 1500 - 50 ohms. Temp rating -100c to +300c. Color Black.

RG/59 cable has a center conductor of 22 ga. copper stranding .242" O.D. Insulation, dielectric is 146P nom, Cap 21 PF/Ft. Maximum operating voltage 2300 - 75 ohms, temp. Rating -40c to +80c. Color Black.

PAGE 17

BNC MALE & BNC FEMALE LEADS

AVAILABLE WITH DIFFERENT COLOR STRAIN RELIEFS. ORANGE, GREEN, YELLOW, BLUE, BROWN, GREY, PURPLE, BLACK, RED.

(18)

The 949-2is an insulated clip that attaches to standard 4mm shrouded plugs and is low profile, the center of the jaw clamps pins up to 3/8" dia. while the teeth at the front of the jaw are designed to accommodate extremely fine wires. . . Sold as 1 each, RED or BLACK.

PAGE 18

944 SERIES PROBES

945 PROBES

946 PROBES

949-2 LOW PROFILE INSULATED CLIP

963 MINI INSULATED CLIP

949-1 LARGE JAWED INSULATED CLIP

944-4

944-3

944-2

944-1

The Oldaker 944 series test probes are designed to provide utmost user safety. The 1000V products are

based on the Rigid Sleeve principle: Each probe has a socket that accommodates a standard banana plug either standard, shrouded or retractable. The sleeve that surrounds the sides of the 4mm socket is insulated to keep fingers from the test area to insure a shock proof connection to 1000V. Choose from a variety of grip, pierce, clamp and hook types to find the right probe for your test and measurement applications.

The 944-1 features 2 rotating, clamp-style tongs for securely grabbing pins and wires with diameters of up to 5/32". And, thanks to the special shrink - tubing on the flexible shaft, this and all 944 probes are resistant to solder iron heat and high temperatures. Sold as RED or BLACK.

The 944-2 features a clamp-style probe with spring-loaded, stainless-steel pin that allows the user to pierce wires without removing the insulation or causing any damage to the wire. This part pierces wires up to .138" O.D. Sold as RED or BLACK

The 944-3 features a special wide-opening jaw which opens to 7/8" to accommodate a large range of test connectors in R & D labs, workstations and service departments. When the plunger is pressed the jaws simultaneously open and extend from the probe body, then close to make a tight, reliable connection. Sold as RED or BLACK

The 944-4 is the perfect tool for electricians and repair technicians working in hard-to-reach spaces. Its spring-loaded hook extends to a full 7/32" before retracting for a secure grip around the test point.. Sold as RED or BLACK

FLEXABLE

The 945provides precise contact with the area being tested. Its tapered, durable steel tip (9/32" long) is perfect for penetrating insulated and backing layers on PC boards. An anti-shorting clear cap (Oldaker P/N 945-1) can be purchased separately for fine pitch testing... Sold as 1 each, RED or BLACK.

The 946combines testing and measurement functions in one handy tool. Its rugged, dual-function test tip is equally suitable for penetrating insulating and backing layers of printed circuit boards or for inserting directly into 4mm dia. sockets... Sold as 1 each, RED or BLACK.

945-1 TIP PROTECTOR

The 949-1is an insulated clip that attaches to standard 4mm shrouded plugs and has an expanded clamping range of 1", making it especially useful in a wide range of heavy duty electrical, automotive, marine, aviation and industrial test measurement applications ... Sold as 1 each, RED or BLACK.

The 963 clip is an insulated minigator with standard banana jack to fit shrouded or exposed plugs. . . SOLD as 1 each, RED or BLACK.

(19)

This threaded adapter converts any standard banana plug to a threaded connection and allows the user to thread on any of the Oldaker adapters directly to the plug end and changes meter lead to a jumper lead. MATERIAL = nickel plated brass with molded in polyethelene insulator. SOLD as Sets 1 Red and 1 Black.

This 8-32 threaded Hook-It attaches directly onto any test probe tip with matching threads and allows the user to attach lead to any small connector. MATERIAL = .028" silver coated beryllium copper wire with nickel plated brass insert and molded nylon housing. SOLD as Sets 1 Red and 1 Black.

2.2 " 50

THREADED 8-32

.027" .175"

.150"

497-3 HOOK-IT

623 & 623-3 THREADED EXTENSION TIPS

521-1 PLUG ADAPTER

PAGE 19

These extended tips thread onto any standard probe tip with 8-32 threads, and allows the user to reach difficult areas, it also has a stainless steel tip with a polished point for insulation piercing or penetrating coated connections. The tip is

fully insulated to the point to prevent shorting.

MATERIAL = .045" Dia stainless steel needle tip. 623 is 5” long, 623-3 is 3.25” long. The base is nickel plated brass with 8-32 threads and is molded in polyproplene. SOLD as Sets 1 Red and 1 Black.

with cut resistant clear shrink tubing,

5" 623

3.25” 623-3

521 PLUG ADAPTER

This threaded adapter converts any standard banana plug, recessed or exposed, to a threaded connection and allows the user to thread on any of the Oldaker adapters directly to the plug end and changes meter lead to a jumper lead. MATERIAL = nickel plated brass with molded in polyethelene insulator. SOLD as Sets, 1 Red and 1 Black.

520 LUG ADAPTER

TYPICAL APPLICATION

This threaded adapter converts any 8-32 threaded probe tip to a #10 lug. MATERIAL = #10 lug with nickel plated brass insert threaded 8-32 and molded ABS insulator.

SOLD as Sets 1 Red and 1 Black.

498 TIP PROTECTOR

MATERIAL = Polypropelene. SOLD = as Sets 2 Red and 2 Black.

BEFORE

PROTECTS USER FROM SHORTING

OUT TIP. . .

AFTER

458-4 ALLIGATOR CLIPS FIT RECESSED 4 mm PLUG

This alligator clip set fits any standard recessed 4mm plug. MATERIAL = Nickel plated steel.

SOLD = Part # 458-4 is Sold as Sets, 1 Red and 1 Black.

820 THREADED TELEPHONE STYLE CLIP

This clip set threads directly onto any lead with an 8-32 threaded tip, and adds the ability to clip onto larger parts. Clip length is 2 19/32" x 15/16" high and has a PVC boot. Sold as Sets 1 Red and 1 Black, can be ordered separately.

TYPICAL APPLICATION

458-3 ALLIGATOR FITS 4 MM PLUGS

This alligator clip set fits any standard 4mm plug. MATERIAL = Nickel plated steel.

SOLD = Part # 458-3 is Sold as Sets, 1 Red and 1 Black.

458-1 THREADED CLIPS

This 8-32 threaded alligator clip (149-2) attaches directly to threaded probe. MATERIAL = Nickel plated steel with 8-32 threaded end. The Boot (226) is PVC. SOLD = Part # 458-1 is Sold as Sets, 1 Red and 1 Black.

THIS ADAPTER FITS NON RECESSED PLUGS ONLY

(20)

TYPICAL APPLICATION TO METER

4' LEAD _966-1

ADAPTER USER

4' LEAD

USES 226 BOOT This adapter threads onto any lead with an 8-32 threaded tip and allows the user to attach any of the Oldaker 944 series heavy duty lead accessories to any of the Oldaker standard lead sets (See Illustrations Above). This adapter also accepts The Oldaker insulated clip 949 series and if required Oldaker Part Numbers 945 & 946 can also be attached. Sold as Sets, 1 Red and 1 Black.

966-2 PROBE ADAPTER

966-1 TEST LEAD EXTENSION

966 ADAPTER KIT

966 PLUG TO PLUG ADAPTER

PAGE 20

One end of this adapter threads onto any probe with an 8-32 threaded tip and allows the user to attach any lead with a standard banana plug, (shrouded or exposed) to the other end which will extend a standard 4' lead to 8' . (See Diagrams Above). Sold as sets, 1 Red and 1 Black.

This adapter has standard banana jacks on each end and allows the user to attach any lead with a standard banana plug, (shrouded or exposed) to the end of another standard banana plug lead which will extend a standard 4' lead to 8' . (See Diagrams Above). Sold as Sets, 1 Red and 1 Black.

STANDARD PLUG STANDARD PLUG

THREADED PROBE

966-2 ADAPTER

PLUG-IN ACCESSORY

INSERT BOTH PLUGS IN EACH END OF THE ADAPTER.

This complete adapter kit has 1 set of all the adapters shown on this page. The kit includes 1 red and 1 black of each of the following adapters, 521-1, 966, 966-1 and 966-2. The kit comes packaged in a reusable plastic pouch.

PRESS ATTACHMENT ONTO END OF ADAPTER PLUG.

This heavy duty 2.625” telephone type clip has a cluster of hardened needles and also a single pin for extra secure connection and a wide opening jaw (1.312"). 815 is Sold as 1 Clip. 815-1 Boot is Sold as 1 Boot, Red or Black.

815 BED OF NAILS CLIP

8 5-O 1 1 B

OT

149-2 THREADED ALLIGATOR CLIP

This 8-32 threaded alligator clip attaches directly to threaded probe. MATERIAL = Nickel plated steel with 8-32 threaded end.

SOLD = Part # 149-2 is sold as 1 Clip. Part # 226 is Sold as 1 Boot, colors available are red, black, blue, green, yellow & white.

149 ALLIGATOR CLIP

USES 226 BOOT

This alligator clip can be soldered or crimped directly to wire.

MATERIAL = Nickel plated steel. SOLD = Part # 149 is Sold as 1 Clip. Part # 226 is Sold as 1 Boot, colors available are red, black, blue, green, yellow & white..

149-4, 458-5 ALLIGATOR CLIP FITS PIN PLUG

USES 226 BOOT

This Mueller #60PR clip attaches directly to .080” pin plug. MATERIAL = Nickel plated steel. Part # 149-4 is Sold as 1 Clip. Part # 226 is Sold as 1 Boot, colors available are red, black, blue, green, yellow & white.. Also Available, Part # 458-5, Which is Clip & Boot assembled and Sold as Sets 1 Red & 1 Black.

(21)

977 STUB NOSE CLIP

This Mueller #46A clip is plated steel with crimp connection and plastic handles. 977 clip is Sold as 1 clip, please specify Red or Black.

249 MINI CLIP

668 CROCODILE CLIP

PAGE 21

This Mueller #85 crocodile clip has a screw for attaching wire. Clip is made of plated steel. 668 clip is sold as 1 Clip. Part # 680 is Sold as 1 Boot. Colors available are red, black, green, blue, yellow & white.

USES 277A BOOT

USES 680 BOOT

This Mueller #30BL clip is made of nickel plated steel and can be crimped or soldered. 249 clip is Sold as 1 Clip. Part # 277A is Sold as 1 Boot, please specify color, Red or Black.

170-1 20 AMP CLIP

170-1C IS COPPER CLIP

USES 684-1 BOOT

This Mueller #27 clip is plated steel with screw. 170-1 is Sold as 1 Clip. Part # 684-1 is Sold as 1 Boot, please specify Red or Black.

170-3 50 AMP CLIP

USES 684-3 BOOT

This Mueller #21A clip is plated steel with screw. 170-2 clip is Sold as 1 clip. 684-3 boot is Sold as 1 boot of one color, please specify Red or Black.

170 10 AMP CLIP

USES 684 BOOT

170C IS COPPER CLIP

This Mueller #48B clip is plated steel with screw connection. 170 is Sold as 1 Clip. Part # 684 is sold as 1 Boot, please specify Red or Black.

170-2 40 AMP CLIP

USES 684-2 BOOT

170-2C IS COPPER CLIP

This Mueller #25 clip is plated steel with screw. 170-2 is Sold as 1 Clip. Part # 684-2 is sold as 1 Boot, please specify Red or Black.

This hook is field repairable and is designed for difficult IC test connections. Lightweight (less than 1 gram) and finger-eze Hypo Action permits direct hook-up to delicate wires where weight & leverage may damage component. Available in 10 different colors, red, black, brown, orange, yellow, green, blue, violet, grey & white. MATERIAL = Gold plated beryllium copper conductor with molded nylon housing. SOLD as 1 Each, Select Color. . .

817 MINI MICRO HOOK

1.750"

This hook is field repairable and permits direct hook-up either vertically or horizontally over square wire wrap pins. and is available in 10 different colors, red, black, brown, orange, yellow, green, blue, violet, grey & white. MATERIAL = Gold plated beryllium copper conductor with molded nylon housing. SOLD as 1 Each, Select Color.

454 HOOK

2.250"

BODY ATTACH WIRE

PLUNGER

This 5" hook is field repairable and permits direct hook-up either vertically or horizontally over square wire wrap pins.

MATERIAL = Gold plated beryllium copper with molded nylon housing. SOLD as 1 Each Red Or Black.

5.000"

816 EXTENDED HOOK

BODY ATTACH WIRE

(22)

This pico hook has one .025" square pin which plugs into wire socket and is designed for direct connection to a single leg of a DIP or other components with a maximum diameter of .025".

MATERIAL = Molded nylon with gold plated center contact.

SOLD as 1 Each. Available in 10 colors, brown, black, red, orange, yellow, green, blue, violet, gray & white.

.100" .016"

.013"

1.420"

4359 PICO HOOK WITH .025” PIN

PAGE 22

1.75"

This micro hook is designed for difficult IC test connections. Has .025" square pin connector which plugs directly onto wire socket.

MATERIAL = Molded nylon with gold plated center contact.

SOLD as 1 Each, available in 10 colors brown, black, red, orange, yellow, green, blue, violet, gray & white.

4258 MICRO HOOK WITH .025” PIN

2.160"

This hook is designed for hard to make test connections with different shapes and sizes. The narrow size allows close side by side connection for high density IC's. The hook has 2 blades that are connected directly to the wire and are shaped to make a good connection, and is field repairable. Available in red, black, blue, green, yellow & white.

Material = molded nylon with stainless steel blades. Sold = as 1 Each, Select Color. .100"

.185"

982 DOUBLE GRIPPER

This double grip hook assures solid positive connection and with a narrow configuration (.050" wide) makes it ideal for side by side stacking. It also has dual .025" square pins for plug in connection, its spring loaded design is easy to use and assures solid positive contact.

MATERIAL = Molded Nylon.

SOLD as 1 Each. Available in 10 different colors, black, brown, red, orange, yellow, green, blue, violet, gray & white.

.060"

.018" DIA. .090"

4256 DBL-GRIPPER WITH .025” PINS

2.250"

992 AUTOMOTIVE TYPE HOOK

5.5"

This heavy-duty test hook is ideal for automotive testing, solder connection. Has sharp point in hook for sure contact. Available in black, brown, blue, orange, yellow, grey and white.

MATERIAL = Molde nylon with nickel silver contact. SOLD as 1 Each.

491B THREADED 4 mm PLUG

This standard banana plug fits .175" Dia. Jack and is threaded 8-32. NOTE = This is a stand alone plug, no insulator.

Material = knurled nickel plated brass body with nickel silver contacts. Sold = as 1 Plug.

1.062"

.257" DIA. THREADED

8-32 RATED 15 AMP.

284-3 .080” PIN PLUG

This standard pin plug has a .080" Dia. Pin and must be soldered onto wire and pressed into insulator 457C. MATERIAL = Nickel plated brass.

SOLD = as 1 Pin Plug.

1.5" .080"

.187" DIA. USE INSULATOR

457C FOR PIN PLUG.

491A STACKABLE 4 mm PLUG

This standard stackable banana plug fits .175" Dia. And has .166" Dia hole in back. NOTE = This is a stand alone plug, no insulator. Material = knurled nickel plated brass body with nickel silver contacts. Sold = as 1 Plug.

1.5"

.250" O.D. DRILLED .166" DIA. RATED 15 AMP.

RATED 10 AMP.

491 SOLDER & PRESS 4 mm PLUG

This standard banana plug fits .175" Dia. Jack and must be soldered onto wire and pressed into insulator 457B (recessed) or 457C (standard).

Material = knurled nickel plated brass body with nickel silver contacts. Sold = as 1 Plug.

1.062"

.192" RATED 15 AMP

USE INSULATOR 457B FOR RECESSED

BANANA PLUG. USE INSULATOR

457C FOR BANANA PLUG.

.187" DIA.

.540"

450 MINI PLUG

This mini plug fits a .105" jack and must be soldered onto wire and pressed into insulator 457C.

MATERIAL = Nickel plated brass body with nickel silver contacts. SOLD = as 1 Mini Plug.

USE INSULATOR 457C FOR MINI PLUG.
