EUROTHERM MASTER COMMUNICATIONS 5000 Series with Master Communications for unsurpassed access to process data everywhere

(1)

EUROTHERM

MASTER

COMMUNICATIONS

5000 Series with Master Communications for

unsurpassed access to process data everywhere

(2)

The 5000 will recognise other Eurotherm products on the network and auto-configure parameters for the operator to use. Additional parameters in any instrument can be manually configured. The 5000 Master Communications will support any Modbus device – if the instrument is not a recognised profile, the user may manually configure the device – offering ultimate flexibility via easy-to-use configuration pages.

Whether the 5000 is being viewed via its local, TFT colour, touch screen display or remotely on a PC or PDA, it offers a range of standard views and the ability for the user to configure a customised view to best suit their application. Some options included are trends, bar graphs, numeric values, mimics, control faceplates and alarm/event views. The 5000 also has powerful Maths and Events functions allowing the user to configure pre-defined actions or buttons. Whether it’s driving a relay, popping up a message window or changing the display colour on an alarm – the 5000 is designed to give the best information for your process.

The 5000 Series supports both serial and Ethernet connectivity. Information from a serial slave device can be read over the Ethernet. The 5000 also support ‘Talk through’ communications enabling configuration of a slave device over the network ‘through’ the 5000 – e.g. iTools running on a PC on the Ethernet network may be used to configure Eurotherm controllers acting as slaves to the 5000.

Using the Bridge 5000 software, all data accessed by the 5000 can be viewed remotely on any PC anywhere on the network. With Full Bridge the user also has full, remote operation and configuration while still maintaining high security and data integrity. Master Communications in the 5000

Series is designed for simple connectivity and ease of operator use. The 5000 Master Unit will scan a user-defined selection of addresses and auto-detect devices on the network.

CONNECTIONS MADE EASY

The 5180V, 5100V and 5000B now all support Modbus Master Communications over Ethernet and Serial connections. Powerful features from within the 5000 Series – such as user-defined screens, remote access and Auditor Features – can now be applied to other areas of the plant. Whether you need to securely record data from other instruments or a centralised HMI for operator use – 5000 Series offers you a simple and powerful solution.

Product Support

HMI

Serial to Ethernet

Autoscan

networked devices

(3)

Control, Record and Visualise

The 5000 with Master

Communications can be used with Eurotherm control products to give an integrated recording and control solution. The 5180V has a colour, touch screen and provides an excellent HMI for visualisation of the plant. Controller faceplates can be viewed on the recorder enabling the operator to monitor the controllers as well as to change setpoints and other parameters from a single user interface. Bridge software offers complete remote access to the recorder and hence the controllers. Vacuum Furnace Carburising Annealing Freeze Dryers Integrated control and recording

Customised plant visualisation Superior security and audit trail functionality

Long term, secure data storage

Easy set-up and communications Batch functionality

Complete configuration of the controllers can be carried out across the network using the PC based iTools package. There

is no need to change the network or connect directly to the controllers as the 5000s support “Talk-through”

communications – enabling the user to access the controllers seamlessly through the 5000.

HEAT TREATMENT MADE EASY

iTOOLS

Configuration, monitoring and data logging software Cloning Commissioning OPC Modbus Server

5180V

Customised screens, tailored to meet application needs 12.1” SVGA, touch screen display

2704

Advanced 3 loop controller Setpoint programming Maths and logic functions Open communications User Interface customisation

3504

2408

2704

(4)

5180V

EUROTHERM

SUITE

Scalable software solutions Intuitive operation Single tag entry Embedded OPC Online monitoring of continuous and sequential strategies Complete Plant view

2500

Plug-in modules DIN rail mounting High accuracy Alarm monitoring Advanced PID and logic control

SIGNAL CONDITIONERS

A full range of Signal Conditioning units is also available from Eurotherm providing distributed, low density I/O.

2408i

Universal indicator

Temperature, pressure, flow, level Accurate

Stable

Linearisation functions Alarms

THIRD PARTY I/O

Any third party I/O supporting Modbus communications can be used for connection to the 5000 Series

Modbus Master Communications on the 5000 Series provides a method of reading and recording up to 96 input channels on a single recorder. Adding control and indication to the same network provides a total solution and flexible centralised HMI.

Eurotherm’s 2500 DIN Rail I/O offers a distributed, scalable I/O system. It provides high accuracy and plant monitoring using an extensive range of analogue and digital modules. The 5000 Series can auto-scan for the 2500 and has a pre-configured set-up for the unit, making configuration of the system quick and simple.

Third party I/O can be manually configured within the 5000 – offering the ultimate in flexibility for your system.

Local and remote I/O Bulk I/O Centralised visualisation Remote monitoring Nuclear Power distribution CHP Hydro-electric Gas powered

(5)

5100V

Secure, embedded Audit Trail Electronic Signatures Unlimited, unique user names

Mean Kinetic Temperature (MKT) function Time Synchronisation

T640

Micro DCS configurable controller Continuous and sequential functionality Standard control PID – cascade/ratio control Advanced control e.g. Boiler blowdown, drum level

PLC

Any third party product supporting Modbus communications can be connected to the 5000 Series and make use of its Audit Trail and security functionality.

3216

Temp/process controller Alpha-numeric messaging Ethernet enabled Universal inputs

2404/8

High stability controllers PID, on/off and motorised valve control Advanced adaptive tuning algorithms 20 setpoint programs Load current monitoring Multi-zone programming

The 5000 takes data security to new levels. The 5000’s Auditor Features are designed in accordance with 21 CFR Part 11. It has unlimited, unique user names with password security. Each user can have individual access permissions and all changes and events are recorded into the embedded audit trail. Electronic Signatures are supported and all data – process and Audit Trail – are stored in a binary, encrypted format to prevent tampering. The 5000 Series has security systems designed in accordance with 21 CFR Part 11. Using Master Communications, this security can be applied to third party devices providing a secure, centralised Audit Trail.

21 CFR Part 11 Environment Monitoring Steam Measurement Reaction vessels Autoclaves pH control

(6)

Modbus Master Communications on the 5000 Series is easy to use and flexible. Any device using serial or Ethernet Modbus communications can be connected. All 5000 instruments are available with Bridge software. Bridge provides the user with remote monitoring and configuration capability – including Modbus functionality. Using the 5000 as a Master on your network, data from connected slaves can be viewed and controlled from any PC, anywhere. The 5000 instruments support both serial and Ethernet communications – so data from a serial device can be transferred to an Ethernet network. They also offer ‘Talk-through’ communications – so PC tools for slave devices on the network can be used through the 5000 without the need to change connections.

JOIN THE NETWORK

Remote monitoring and control Remote configuration

Serial to Ethernet conversion ‘Talk through’ functionality

SECURE GATEWAY FOR LEGACY EQUIPMENT MADE EASY

5000B

Remote viewing and configuration Advanced security and Audit Trail DIN rail or wall mounting 13.25Mbyte FLASH memory for process history Up to 12 universal inputs and 84 maths inputs Ethernet and serial communications

Bridge Software

Bridge Software Seamless interface from Plant floor to PC Remote live monitoring Remote configuration

4103C

1-4 pen continuous chart recorder Universal, isolated inputs 16 event inputs 16 relay outputs Annotation

4250M

Six colour, high speed, multipoint chart recorder Up to 96 inputs

High speed scanning (all inputs at 1s) Maths functions Data storage to PC memory card

394

Circular chart recorders Up to 6 input channels Annotation Maths functions Totalisers

THIRD PARTY

EQUIPMENT

Any third party equipment supporting Modbus – Ethernet or Serial – can be connected to 5000 Series and viewed remotely. Process data can be recorded on the 5000 and values monitored or changed either from the 5000 display or remotely using the Bridge software.

(7)

Master communications on the 5000 Series can be used to simply bring information back to a centralised point for ease of operator use. The 5000 provides a Screen Builder facility to enable the user to customise screens to best suit their application – from representations of control faceplates to plant mimics. Using the Bridge software these views can be replicated on any PC on the network or, for the ultimate in remote, mobile monitoring, on a PDA device.

CENTRALISED HMI MADE EASY

2408i

PDA

Remote, live monitoring Remote, full operation and configuration Wireless communication

5000B

3504/3508

Advanced process control Setpoint programming Maths & logic functions Open communications User interface customisation Modular expandable I/O

5000B

5180V

Customised screens, tailored to meet application needs 12.1” SVGA, touch screen display

BRIDGE

Full, remote viewing, operation and configuration.

(8)

EUROTHERM LIMITED http://www.eurotherm.co.uk

UK SALES OFFICE US OFFICE Eurotherm Ltd Eurotherm

Faraday Close Durrington Worthing 741-F Miller Drive

BN13 3PL United Kingdom Leesburg VA 20175-8993

Tel. +44 (0)1903 695888 Fax +44 (0)1903 203767 Tel. 1-703-443-0000 Fax 1-703-669-1300

All rights are strictly reserved. No part of this document may be reproduced, modiﬁed, or transmitted in any form by any means, nor may it be stored in a retrieval system other than for the purpose to act as an aid in operating the equipment to which the document relates, without the prior written permission of Eurotherm limited.

Eurotherm Limited pursues a policy of continuous development and product improvement. The speciﬁcations in this document may therefore be changed without notice. The information in this document is given in good faith, but is intended for guidance only. Eurotherm Limited will accept no responsibility for any losses arising from errors in this document.

Part No. HA028136 Issue 1 Printed in England 04.03

CONNECTIONS MADE EASY

PRODUCT ETHERNET SERIAL MODBUS MASTER MODBUS SLAVE

5180V ● ● ● ● 5100V ● ● ● ● 5000B ● ● ● ● 5100e ● ● 2500 ● ● ● 2216e ● ● 2208e ● ● 2204e ● ● 3216 ● ● 2416 ● ● 2408 ● ● 2404 ● ● 3504 ● ● ● 3508 ● ● ● 2604 ● ● ● 2704 ● ● ● ● 2408i ● ● T630 ● ● T640 ● ● ● 4181G ● ● 4250G ● ● 4103C ● ● 4103M ● ● 4181M ● ● 4250M ● ● 4250C ● ● 394 ● ●

Master Product Slave devices Max. input Cyclic write On demand Serial Comms Ethernet Display comms channels outputs write outputs

5180V 16 96 48 48 RS232 / RS485 10BaseT 12.1" SVGA

5100V 16 48 48 48 RS232 / RS485 10BaseT 5.5" _ VGA

5000B 16 96 48 48 RS232 / RS485 10BaseT No

Master Product Read / write points Serial Comms Display

2704 100 RS232 / RS422 / RS485 Dot matrix 120-160 pixels
