ARTECHE IRH series are dry type indoor service current transformers. The core is encapsulated with Type B epoxy resin which provides excellent internal dielectric properties and mechanical strength, ensuring a long mechanical and electrical life. The transformer is maintenance free.
The core is built with high permeability grain oriented silicon steel laminations for low losses.
The windings are copper wire with copper plate double isolation. The concentric distribution of the coils prevents magnetic flux leakage, achieving greater accuracy and higher capacity to withstand mechanical stresses in adverse operating conditions.
CURRENT TRANSFORMERS: IRH SERIES
Characteristics:
› Indoor or Outdoor service
› Metering and/or relaying application
› 60 Hertz
› 600 Vac, 10 kV BIL
› Transparent and sealable secondary terminal cover
› Rotating secondary shorting device
› UL Recognized Component
UL Recognized Component
3.15”
ø1.40”
5”
3.40”
3.66”
ø1.40”
5”
3.40”
3.66”
IRH-1
IRH-3
3.14”
3.22”
ø3.26” 7.08”
Window Type:
Primary Bar Type:
IRH-1 model can be supplied without the base upon request
3.15”
12.13”
Electrical characteristics
Window Type
Low Base
Current Ratio (Primary:
Secondary) (A)
Continuous Thermal
Current Rating Factor
@ 30°C
Continuous Thermal Current Rating Factor
@ 55°C
IEEE Metering Accuracy
Relay Accuracy
735261060 300:5 1.2 1.0 0.6B0.1/1.2B0.2 -
735261080 400:5 1.2 1.0 0.6B0.2/1.2B0.5 -
735261100 500:5 1.2 1.0 0.6B0.5 -
735261120 600:5 1.2 1.0 0.3B0.1/0.6B1.0 -
735261160 800:5 1.2 1.0 0.3B0.2/0.6B1.0 C-10
735261200 1000:5 1.2 1.0 0.3B0.5/0.6B2.0 C-10
735261240 1200:5 1.2 1.0 0.3B0.5/0.6B2.0 C-10
Additional ratings available upon request.
Electrical characteristics Window
Type Low Base
Bar Type Low Base
Window Size
Current Ratio (Primary:
Secondary) (A)
Continuous Thermal Current Rating Factor @
30°C
Continuous Thermal Current Rating Factor @
55°C
IEEE Metering Accuracy
735221040 - 1.5" 200:5 3.0 2.0 0.3 B0.2
735221060 - 1.5" 300:5 2.0 1.5 0.3 B0.2
735221080 - 2.0" 400:5 2.0 1.5 0.3 B0.2
735221120 - 2.0" 600:5 1.5 1.2 0.3 B0.2
- 735225020 1.22" 100:5 4.0 3.0 0.3 B0.2
- 735225040 1.22" 200:5 3.0 2.0 0.3 B0.2
- 735225045 1.22" 200:5 2.0 1.5 0.3 B0.5
- 735225060 1.22" 300:5 2.0 1.5 0.3 B0.5
- 735225080 1.4" 400:5 2.0 1.5 0.3 B0.5
- 735225100 1.4" 500:5 2.0 1.5 0.3 B0.5
- 735225120 1.4" 600:5 2.0 1.5 0.3 B0.5
- 735225160 1.4" 800:5 1.5 1.2 0.3 B0.5
High Accuracy Extended Range 5% nominal current to Rating Factor
735227120 735228120 1.4" 600:5 2.0 1.5 0.15SB0.2
Additional ratings available upon request.
IRH-5
Window Type:
NEMA-4 primary bar available upon request
IRH-5 model can be supplied without the base upon request Primary Bar Type:
IRH-7
Tapered Type:
Wide Type:
4.59”
3.21”
See table
9.01”
4.59”
See table
8.66”
3.21”
3.03”
4.5”
6.2”
9.08”
3.03”
6.2”
9.06” 4.5”
Electrical characteristics
Window Type Low Base
Bar Type Low Base
Window Size
Current Ratio (Primary:
Secondary) (A)
Continuous Thermal Current Rating Factor @
30°C
Continuous Thermal
Current Rating Factor @
55°C
IEEE Metering Accuracy
Relay Accuracy
735301010 735305010 2.56" 50:5 4.0 3.0 1.2 B0.1 - 735301020 735305020 2.56" 100:5 4.0 3.0 0.3 B0.1 C-10 735301040 735305040 2.56" 200:5 4.0 3.0 0.3 B0.5 C-30 735301060 735305060 3.15" 300:5 4.0 3.0 0.3 B0.5 C-30 735301080 735305080 3.15" 400:5 4.0 3.0 0.3 B0.5 C-30 735301100 735305100 3.15" 500:5 3.0 2.2 0.3 B0.5 C-30 735301120 735305120 3.15" 600:5 2.0 1.5 0.3 B0.5 C-30 735301160 735305160 3.15" 800:5 2.0 1.5 0.3 B0.5 C-20 735301200 735305200 3.15" 1000:5 2.0 1.5 0.3 B0.5 C-30 735301240 735305240 3.15" 1200:5 1.5 1.2 0.3 B1.8 C-30 735302040 735306040 3.15" 200/400:5 4.0 / 2.0 3.0 / 1.5 0.3 B0.2 /
0.3 B0.5
C-30 / C-50 735302060 735306060 3.15" 300/600:5 3.0 / 2.0 2.2 / 1.5 0.3 B0.2 /
0.3 B0.5
C-20 / C-40 735302080 735306080 3.15" 400/800:5 2.0 / 2.0 1.5 / 1.5 0.3 B0.2 /
0.3 B0.5 C-10 /
C-30 High Accuracy Extended Range 5% nominal current to Rating Factor
735307120 735308120 3.15" 600:5 2.0 1.5 0.15S B0.5 - 735300120 735309120 3.15" 600:5 3.0 2.0 0.15S B0.2 - 735307200 735308200 3.15" 1000:5 2 1.5 0.15S B0.5 - Additional ratings available upon request.
Electrical characteristics
Tapered type
Wide type
Current Ratio (Primary:
Secondary) (A)
Continuous Thermal
Current Rating Factor
@ 30°C
Continuous Thermal
Current Rating Factor
@ 55°C
IEEE Metering Accuracy
Relay Accuracy
735323020 735324020 100:5 4.0 3.0 1.2 B0.1 -
735323040 735324040 200:5 4.0 3.0 0.3 B0.1 C-10
735323060 735324060 300:5 4.0 3.0 0.3 B0.2 C-20
735323080 735324080 400:5 4.0 3.0 0.3 B0.2 C-20
735323100 735324100 500:5 3.0 2.2 0.3 B0.5 C-20
735323120 735324120 600:5 3.0 2.2 0.3 B0.5 C-20
735323160 735324160 800:5 3.0 2.2 0.3 B0.5 C-20
735323200 735324200 1000:5 2.0 1.5 0.3 B0.5 C-30
735323240 735324240 1200:5 2.0 1.5 0.3 B0.9 C-30
735323300 735324300 1500:5 2.0 1.5 0.3 B0.9 C-50
735323400 735324400 2000:5 1.5 1.2 0.3 B1.8 C-20
735323600 735324600 3000:5 1.3 1.0 0.3 B1.8 C-20
735323800 735324800 4000:5 1.0 0.75 0.3 B1.8 C-10
High Accuracy Extended Range 5% nominal current to Rating Factor
735327100 735328100 500:5 2.0 1.5 0.15S B0.2 -
4
IRH-10
IRH-12
CURRENT TRANSFORMERS: IRH SERIES
IRH-10 can be supplied with the following accessories upon request:
- Low base - Window plate - NEMA-4 primary bar
IRH-12 can be supplied with the following accessories upon request:
- Low base
Electrical characteristics
Window Type No Base
Current Ratio (Primary:
Secondary) (A)
Continuous Thermal Current Rating Factor @
30°C
Continuous Thermal Current Rating Factor @
55°C
IEEE Metering Accuracy
Relay Accuracy
735340000 400:5 3.0 2.2 0.3 B0.2 C-20
735340001 500:5 4.0 3.0 0.3 B0.5 -
735340002 600:5 3.0 2.2 0.3 B0.5 C-30
735340003 800:5 2.0 1.5 0.3 B0.5 C-30
735340004 1000:5 2.0 1.5 0.3 B0.5 C-30
735340005 1200:5 2.0 1.5 0.3 B0.9 C-30
735340006 1500:5 3.0 2.2 0.3 B0.9 C-30
735340007 2000:5 2.0 1.5 0.3 B1.8 C-50
735340008 3000:5 1.5 1.2 0.3 B1.8 C-10
735340009 4000:5 1.33 1.0 0.3 B1.8 -
735340160 600/1200:5 3.0/2.0 2.2/1.5 0.3 B0.2/B0.9 C-10/C-30 735340161 800/1600:5 3.0/2.0 2.2/1.5 0.3 B0.2/B1.8 C-30/C-50 735340162 1000/2000:5 3.0/2.0 2.2/1.5 0.3 B0.5/B1.8 C-30/C-50 735340163 1500/3000:5 2.0/1.5 1.5/1.2 0.3 B0.9/B1.8 -/C-10 735340164 2000/4000:5 2.0/1.33 1.5/1.0 0.3 B1.8/B1.8 - High Accuracy Extended Range 5% nominal current to Rating Factor
735340320 2000:5 2.5 1.8 0.15S B0.9 -
Additional ratings available upon request.
Electrical characteristics
Window Type No Base
Current Ratio (Primary:
Secondary) (A)
Continuous Thermal Current Rating Factor @
30°C
Continuous Thermal Current Rating Factor @ 55°C
IEEE Metering Accuracy
Relay Accuracy
735360000 2000:5 2.0 1.5 0.3 B0.9 C-50
735360001 3000:5 2.0 1.5 0.3 B1.8 C-100
735360002 4000:5 1.5 1.2 0.3 B1.8 C-100
735360003 5000:5 1.33 1.0 0.3 B1.8 C-100
735360004 6000:5 1.0 0.75 0.3 B1.8 -
735360030 1000/2000:5 3.0/2.0 2.2/1.5 0.3 B0.5/B1.8 C-30/C-50 735360031 1500/3000:5 3.0/2.0 2.2/1.5 0.3 B0.5/B1.8 C-50/C-100 735360032 2000/4000:5 2.0/1.5 1.5/1.2 0.3 B0.9/B1.8 C-50/C-100 735360033 2500/5000:5 2.0/1.33 1.5/1.0 0.3 B1.8/B1.8 C-50/C-100 735360034 3000/6000:5 1.33/1.0 1.0/0.75 0.3 B1.8/B1.8 - High Accuracy Extended Range 5% nominal current to Rating Factor
735360060 2000:5 2.5 1.8 0.15S B0.9 -
Additional ratings available upon request.
2.62”
7.5”
9”
ø8.25”
ø5.5”
2.62”
9.76”
12.07”
ø11.38”
ø8.25”
ARTECHE URC series are dry type indoor/
outdoor service voltage transformers.
The core is encapsulated with polyurethane which provides excellent internal dielectric properties and mechanical strength, ensuring a long mechanical and electrical life. The transformer is maintenance free.
The core is built with high permeability grain oriented silicon steel laminations for low losses.
The windings are copper wire with copper plate double isolation. The concentric distribution of the coils prevents magnetic flux leakage, achieving greater accuracy and higher capacity to withstand mechanical stresses in adverse operating conditions.
Characteristics:
› Indoor or Outdoor service
› Metering and/or relaying application
› 60 Hertz
› 600 Vac, 10 kV BIL
› Transparent and sealable primary and secondary terminal cover
› UL Recognized Component
UL Recognized Component
URC-3
URC-5
4.9” 5.2”
5.6” 5.1”
0.2”
Electrical characteristics
Code Ratio Primary
(V)
Secondary (V)
IEEE Metering Accuracy
Continuous Rated Voltage
Factor (Un)
Thermal Burden
(VA)
755500106 1.061:1 115/200Y 108.3 0.3 W, 0.6 X - 300 VA
755500001 1:1 120/208Y 120 0.6 W - 300 VA
755500002 2:1 240/416Y 120 0.3 W, 0.6 X - 300 VA
755500023 2.3:1 276/478Y 120 0.3 W, 0.6 X - 300 VA
755500024 2.4:1 288/500Y 120 0.3 W, 0.6 X - 300 VA
755500025 2.5:1 300/520Y 120 0.3 W, 0.6 X - 300 VA
755500003 3:1 360/480Y 120 0.3 W, 0.6 X - 300 VA
755500333 3.33:1 400/400Y 120 0.3 W, 0.6 X - 300 VA
755500004 4:1 480/480Y 120 0.3 W, 0.6 X - 300 VA
755500020 2:1 480/480Y 240 [email protected] - 300 VA
755500416 4.167:1 500/500Y 120 0.3 W, 0.6 X - 300 VA
755500005 5:1 600/600Y 120 0.3 W, 0.6 X - 300 VA
755500250 2.5:1 600/600Y 240 0.3 W, 0.6 X - 300 VA
Electrical characteristics
Code Ratio Primary
(V)
Secondary (V)
IEEE Metering Accuracy
Continuous Rated Voltage
Factor (Un)
Thermal Burden
(VA)
755510002 2:1 240/416Y 120 0.3 Y - 500 VA
755510024 2.4:1 288/500Y 120 0.3 Y - 500 VA
755510025 2.5:1 300/520Y 120 0.3 Y - 500 VA
755510003 3:1 360/480Y 120 0.3 Y - 500 VA
755510004 4:1 480/480Y 120 0.3 Y - 500 VA
755510005 5:1 600/600Y 120 0.3 Y - 500 VA
755510001 1:1 120/208Y 120 0.3 Y - 500 VA
6.7”
6.9”
5.9” 6.1”
5.8”
4.7”
6
ARTECHE ICP series are dry type indoor service current transformers. The core is encapsulated with an impact-resistant polycarbonate which provides excellent internal dielectric properties and mechanical strength, ensuring a long mechanical and electrical life. The transformer is maintenance free.
The core is built with high permeability grain oriented silicon steel laminations for low losses.
The windings are copper wire with copper plate double isolation. The concentric distribution of the coils prevents magnetic flux leakage, achieving greater accuracy and higher capacity to withstand mechanical stresses in adverse operating conditions.
CURRENT TRANSFORMERS: ICP SERIES
Characteristics:
› Indoor service
› Metering and/or relaying application
› 60 Hertz
› 600 Vac, 10 kV BIL
› Transparent and sealable secondary terminal cover
› Rotating secondary shorting device
› UL Recognized Component
UL Recognized Component
Electrical characteristics
Code
Current Ratio (Primary:
Secondary) (A)
Continuous Thermal Current
Rating Factor @ IEEE Metering Accuracy Relay Accuracy
30°C 55°C
735131120 600:5 2.0 1.5 0.3B0.5/0.6B1.8 C50
735131200 1000:5 2.0 1.5 0.3B1.8 C100
735131240 1200:5 2.0 1.5 0.3B1.8 C100
735131300 1500:5 2.0 1.5 0.3B1.8 C200
735131400 2000:5 2.0 1.5 0.3B1.8 C200
735131800 4000:5 2.0 1.5 0.3B1.8 C200
735132120 600:5 MR 2.0 1.5 0.3B0.5/0.6B1.8 C100
735132240 1200:5 MR 2.0 1.5 0.3B1.8 C200
735132400 2000:5 MR 2.0 1.5 0.3B1.8 C200
735132800 4000:5 MR 2.0 1.5 0.3B1.8 C200
Additional ratings available upon request.
Electrical characteristics
Code
Current Ratio (Primary:
Secondary) (A)
Continuous Thermal Current
Rating Factor @ IEEE Metering Accuracy Relay Accuracy 30°C 55°C
735151120 600:5 2.0 1.5 0.3B0.9/0.6B1.8 C200
735151200 1000:5 2.0 1.5 0.3B1.8 C200
735151240 1200:5 2.0 1.5 0.3B1.8 C200
735151300 1500:5 2.0 1.5 0.3B1.8 C400
735151400 2000:5 2.0 1.5 0.3B1.8 C400
735151800 4000:5 1.33 1.0 0.3B1.8 C400
735159992 6000:5 1.0 0.75 0.3B1.8 C400
735152120 600:5 MR 2 1.5 0.3B0.9/0.6B1.8 C200
735152240 1200:5 MR 2 1.5 0.3B1.8 C400
735152400 2000:5 MR 2 1.5 0.3B1.8 C400
735152800 4000:5 MR 1.33 1.0 0.3B1.8 C400
735159994 6000:5 MR 1 0.75 0.3B1.8 C400
Additional ratings available upon request.
ICP-3
0.38”
3.54”
10”
10”
ø6.50”
ø9.9”
ICP-5
0.38”
6.93”
2 X 10”
2 X 10”
