Page 2
ARBOGA BG 6 – 8 – 10
...Page 3
ARBOGA INDUSTRIAL DOUBLE ENDED GRINDING
AND POLISHING MACHINES
...P
ARBOGA DRILL SHARPENER
...Page 12
ARBOGA DEBURRING MACHINES
...Page 15
ARBOGA BELT GRINDER 75 – 100 – 150
...Page 16
ARBOGA COMBINED PIPE AND BELT GRINDER
...Page 19
ARBOGA CENTRELESS GRINDING
...Page 21
ARBOGA CENTRELESS GRINDER WITH
WET COOLING SYSTEM...Page 23
ARBOGA PIPE NOTCHING MACHINES...Page 25
A
...Page 3
A
...Page 6
A
...Page 12
A
...Page 15
A
...Page 16
A
...Page 19
A
...Page 21
A
...Page 23
A
...Page 25
A
TABLE OF CONTENTS
A
Page 4
The ARBOGA BG double ended grinders and polishers are high quality machines ideal for the workshop. They are available as bench and height adjustable pedestal models both fitted with heavy duty bearings and balanced grinding wheels. This allows for calm and steady grinding and polishing.
Standard features are: Available accessories: Emergency stop Pedestal ( ART: 1065275 )
Working light EX-16 exhaust system( ART: 1022353 ) Heavy adjustable tool rest Belt arm 50x800mm ( ART: 1538600 ) Grinding wheel dresser Tapered spindles ( ART: 1100726/1100734) Coolant tray Polishing guards ( ART: 0921443 ) Spigots for extraction Wire brush
Dressing tool
Model BGE 6
Motor power – Watt 500
Voltage – V 230 Phase 1 Speed – 50Hz/60HZ 2800/3300 Grinding wheels – mm 150x25x32 Polishing wheels – mm 150x25x32 Belt arm – mm 50x800 Weight – kg 12 ART: 360101001 – BGE 6 ART: 360101002 – BGE 6
Page 6
Model BGE/T 8
Motor power – Watt 650 /750
Voltage – V 230 / 400 Phase 1 / 3 Speed – 50Hz/60HZ 2800/3300 Grinding wheels – mm 200x32x32 Polishing wheels – mm 200x32x32 Belt arm – mm 50x800 Weight – kg 20 ART: 380101001 – BGE 8 ART: 380103001 – BGT 8 ART: 380101002 – BGE 8 ART: 380103002 – BGT 8 ART: 380101020 – BGE 8 ART: 380103020 – BGT 8 ART: 380101020 – BGE 8 ART: 380103020 – BGT 8
A
Model BGE/T 10
Motor power – Watt 950 / 1100
Voltage – V 230 / 400 Phase 1 / 3 Speed – 50Hz/60HZ 2800/3300 Grinding wheels – mm 250x32x32 Polishing wheels – mm 200x32x32 Belt arm – mm 50x800 Weight – kg 31 ART: 390101001 – BGE 10 ART: 390103001 – BGT 10 ART: 390101001 – BGE 10 ART: 390103001 – BGT 10
Page 8
A
AR
RB
BO
OG
GA
A IIN
ND
DU
US
ST
TR
RIIA
ALL D
DO
OU
UB
BLLE
E E
EN
ND
DE
ED
D
G
The ARBOGA grinding and polishing machines are manufactured for heavy duty use in industry. A totally enclosed quality motor with wide distance between grinding wheels gives ample space for grinding on either wheel, and the accurately balanced shaft assembly with dustproof sealed quality bearings ensures a quiet and vibration free operation for many years. Durable wheel guards, flanges and tool rests comply with general factory safety regulations.
ART: 304653001 - E-308
ART: 301653200 EPU-312 w/KU12 exhaust
ART: 305653002 - PO-308
Page 10
First class grinding wheels, adjustable spark arrestors, eye shields and tool rests are standard equipment.
A wide range of accessories is available ensuring maximum flexibility and utilisation for workshop use.
The ARBOGA 308 and 312 can be fitted with a belt arm either on one side or on both sides. The belt arm is built for heavy duty and made of steel plates. The belt arm is quick and easy to adjust. The belt is changed by a simple and swift operation.
ART: 307653001 - EB-308
The ARBOGA industrial grinders and polishers can be fitted with powerful exhaust systems. There are two options: the KU extraction and the EX-16 extraction. Both are very powerful extraction units and can meet the demand of the modern day industry.
The EX-16 extraction unit is built into the pedestal of the machine. Consequently this extraction unit will not take up extra space in the workshop.
All ARBOGA double ended grinders are fitted with an emergency switch as standard. The emergency switch is mounted either in the pedestal for foot operation or for the bench models fitted with a cord so it can be placed in the best
position for the user.
The main switch on the ARBOGA machines is a DISA switch. This ensures a steady power supply and quality.
The KU extraction unit is fitted on the back of the machine.
Page 12
Standard equipment:
x First class grinding wheels x Adjustable spark arrestors x Heavy eye shields x Sturdy tool rests
Available accessories: x Extraction fan KU
x EX-16 Extraction unit w/pedestal x Taper threaded spindles x Belt arm
x Adjustable tool rest x Deburring attachment
x Mist cooling device ( ART: 0240501 ) x AXOIM eye shield ( ART: 0700101 ) x Pedestal ( ART: 1065015 – 1065016 )
A
AXIOM eye shield
ARBOGA 308
ART: 304653001 – E 308
ART: 304653012 – POE 308
Page 14
A
AR
RB
BO
OG
GA
A 331100
ART: 315653000– E 310 ART:318303001 – PO 310 ART: 318303030 – POD 310 ART: 315653004 – POE 310 ART: 315653002 – EB 310A
A
AR
RB
BO
OG
GA
A 331122
ART: 303653002 – PO 312
ART: 3301653001 – E 312
Page 16
T
TE
EC
CH
HN
NIIC
CA
ALL S
SP
PE
EC
CIIFFIIC
CA
AT
TIIO
ON
NS
S FFO
OR
R
A
AR
RB
BO
OG
GA
A 330088 –– 331100 -- 331122
Model 308 310 312 Motor power – Hp 1,36 2,03 / 2,31 2,72 / 3,0 Voltage – V 400 400 400 Phase 3 3 3 Speed – 50Hz/60HZ - 1400/1700 1400/1700 Speed – 50Hz/60HZ 2800/3300 2800/3300 2800/3300 Grinding wheels – mm 200x38x20 250x38x20 300x50x32 Polishing wheels – mm 200x20x6 200x20x20 300x30x32 Belt arm – mm 50x2000 50x2000 75x2000 Weight – kg 17/52 45/60 58 / 120 OPTIONALS 308 310 312 Pedestal 1065015 1065015/16 1065016 KU extraction unit 1040108 1040108 1040109EX-16 extraction pedestal 1022342 1022342 1022344
Adjustable tool rest L0744410 / R1065091 L0744410 / R1065091 L0773671 / R0773663 Taper threaded spindles L1532367 / R1532383 L1532367 / R1532383 L1532383 / R1532391 Belt arm L1533772 / R1533771 L1533772 / R1533771 L1533778 / R1533777 Cyclone 100S dust coll. Filter 700681300 700681300 700681300
A
AR
RB
BO
OG
GA
A D
DE
EB
BU
UR
RR
RIIN
NG
G M
MA
AC
CH
HIIN
NE
ES
S
x ARBOGA Deburring Machines are built for heavy duty applications.
x Built for quality and reliability.
x All machines comply with current safety requirements.
x An adjustable tool rest, swivel arrestors and eye shields are supplied as standard.
x Can be supplied with complete dust extraction.
x Powerful motors 1,5HP/3,0HP
Main motor Exhaust motor Weight
Deburrin Emergency
ART: 388701000 – 250AGM
Page 18
A
BEP 308 with AXIOM eyeshield
The simple drill grinding solution
The ARBOGA BEPAB 308 with drill grinding attachments A & B mounted on a pedestal with working table and water cup. This machine grinds twist drills from 4 - 60 mm with a point angle of 116-118º. The BEP machines are also available with just attachment A (BEPA 308) with drill grinding capacity 4-30mm or just attachment B (BEPB 308) with drill grinding capacity 30-60mm. If only one drill grinding attachment is fitted to the machine, it leaves several options available on the other side of the machine, e.g. grinding wheel, polishing wheel, belt arm, deburring attachment, etc. - all depending on each customer’s individual needs.
The ARBOGA BEPAB 308 consists of a motor with cup wheels, mounting base, and two drill holders for drills 4-30 mm (A) and 30-60 mm (B), respectively. The standard equipment includes a diamond dresser and holder, eye shields, pedestal, working table and water cup. Tool rests are not standard on the BEPAB machine.
The twist drill is placed in the drill grinding attachment. Firmly put your thumb on the drill to hold it in the attachment and with a firm movement swing the attachment/arm from left to
Page 20
perfect condition – therefore the cup wheel must be dressed regularly. A dressing diamond and a holder are supplied with the machine.
Dressing diamond ART: 1532590
Table for pedestal models ART: 1065106
Water cup ART: 0771333 Drill grinding attachment A ART: 1532498
Pedestal ART: 1065015 Drill grinding attachment B
ART: 1532503
ART: 306653051 – BEPA 308 ART: 306653150 – BEPAX 308 ART: 306653002 – BEPA 308
Page 22
A
ARBOGA industrial belt grinders are designed for continuous heavy duty grinding, and the quality underlined is by more than a decade of manufacturing experience. The machines are characterised by a compact and strong design. The machines are fitted with an adjustable tool rest, eye shield and motor protection switch with built in no-volt release and an emergency stop button. Even though the machines are made for heavy duty the noise level is always below 80 dBA.
The ARBOGA belt grinders are fitted with easy to use belt travel regulation. This is a very important detail for the life span of the contact wheel. The belt travel is adjusted near to the axle of the contact wheel. Easy to adjust before starting
to grind.
Obtaining the perfect grinding result is with either hard or soft rubber coating on the contact wheel. All contact wheels from ARBOGA are delivered as standard in hardness 70 duro. Harder or softer rubber coatings are available on request.
On the top of all ARBOGA belt grinders there is a large grinding surface, making it unnecessary to dismount the grinder. The large protection cover ensures the safety of the user while operating the machine.
Page 24
All standard models are prepared for a central exhaust system. All models are available with/without a powerful built-in double exhaust system – with dust bags as standard on exhaust models.
As an accessory ARBOGA can supply a Cyclone with dust collection, micro filter and cyclone rack to all ARBOGA belt grinders with built in exhaust. The cyclone’s operating principle obtains the best possible utilisation of the unique ARBOGA powerfully built in exhaust systems - as there is no resistance to stop the airflow. Inside the cyclone the air and the grinding dust is kept separated. The air flows out of the top of the cyclone, while the grinding dust is led to the bottom of the cyclone dust collector.
The cyclone with dust collection is the perfect solution for simple and efficient collection of dust without reduction in the exhaust quality.
Standard equipment:
x Adjustable eye shield
x Angle-adjustable tool rest
x Switch with emergency stop
x No-volt release
x Prepared for central exhaust
x Large grinding surface
Available accessories:
x Brake motor
x 2-speed motor
x Motor with extra HP
x Spark arrester for exhaust
x Switch with delay on exhaust
x Cyclone for dust collection
x Cyclone complete with exhaust system
x Contact wheel with extra hard or extra soft rubber coating.
Belt
length Standard voltage Standard motor RPM 50/60 Hz
Speed of
belt Contactwheel Exhaust (S) Weight
75x2000 2800/ 200x75
ART: 470232130 – ARBOGA 75 470232230 – ARBOGA 75X
ART: 470233140 – ARBOGA 100
Page 26
A
AR
RB
BO
OG
GA
A C
CO
OM
MB
BIIN
NE
ED
D P
PIIP
PE
E A
AN
ND
D B
BE
ELLT
T
G
The ARBOGA combined pipe and belt grinder is a high quality and very versatile machine. The machine can be used both as a normal standard belt grinder and a pipe notching machine. The machine is fitted with a sturdy cross table at the front of the machine which easily can be removed if the belt grinder has to be used as a standard belt grinder. All need is just to fit a normal contact wheel on the machine and it is operational. (conversation kit)
The cross table can be adjusted in every way – can tilt, height adjust and side adjust. This makes the machine perfect for precision grinding.
As an accessory a conversation kit can be supplied. This makes it possible to convert from pipe notcher to belt grinder
in a few minutes. The conversation kit consists of a normal standard contact wheel, a standard tool rest and a spark box.
ART Model length Belt Standard motor 50/60Hz RPM Capacity Grinding angles Standard voltage Exhaust (S) 470232139 ARBOGA 75 BR 75x2000 mm 3 / 4,1 HP 1400/2800 17-70mm degrees 0-60 3x400v -
Page 28
A
The ARBOGA 75CG Centreless grinding and polishing machines are supplied with a newly developed centreless attachment. This attachment can be mounted on all belt grinders with a belt of 75x2000 mm and with a large grinding surface on top. The Centreless grinding attachment is easy to operate and grinds/polishes all pipes and tubes from ø20-100 mm.
ARBOGA CG Centreless grinding and polishing machines are unique compared to other centreless grinders on the market, because the machine remains fully functional as a belt grinder, even when the centreless grinding attachment is fitted. It is not necessary to dismount the centreless attachment, when using the belt grinder for normal grinding operations. Both the contact wheel and the flat grinding surface on top are available for normal grinding and polishing, even when the attachment is on the machine.
The accessory consists of the following parts: 1. Attachment with separate drive motor and gearbox.
2. Extraction hose with all necessary fittings for belt grinders with exhaust system. 3. Cover for the top grinding surface – with and without an exhaust spigot. 4. Support table over the motor with nylon surface.
5. Drive wheel for belt grinder with hard rubber surface. 6. Support feeding table.
Main motor Centreless motor Contact Grinding
Page 30
A
AR
RB
BO
OG
GA
A C
CE
EN
NT
TR
RE
ELLE
ES
SS
S G
GR
RIIN
ND
DE
ER
R
W
The ARBOGA 75CGW is suitable to sand, grind, clean, or polish tubes with a diameter ranging from 5 to 150 mm. and a maximum weight of approximately 20 Kg. The centreless units can operate at variable speeds to adjust the rolling speed to the diameter of the piece, and are equipped with three different supports as standard. The counter wheels are adjusted electronically and in continuous progression from 15 to 75 rpm.
The contact wheels can be replaced with other wheels with different hardness to obtain the best results. The prismatic guide that supports the piece is easy to adjust and covered with plastic anti-friction material, which can be replaced with fibre brushes.
The electrical system is in compliance with normal standards and installed in a sealed metallic box.
Page 32
A
ARBOGA pipe grinder type RS/RSX has the following features:
x The only pipe grinder on the market that offers adjustment of the grinding section instead of the work piece.
x Due to the adjustment of the grinding section instead of the work piece, the required work space is kept to an absolute minimum, i.e. when grinding long pipes.
x Quick and easy adjusting of all angles between 0-60º.
x Precision grinding of pipes and profiles in all angles between 0-60º.
x Quick and easy changing of rollers for all sizes.
x High quality and heavy construction.
x The perfect and accurate result makes welding very easy afterwards.
ARBOGA 100/150 RS and RSX pipe grinders are perfect for grinding all kinds of pipes and profiles before welding, and suitable for batch production where precision and perfect finish and fitting is demanded: Production of frames – handrails – go-carts – wheel chairs – ship rails – gates – furniture frames – stainless from 21 to 70 mm diameter in all materials. ARBOGA 100/150 RSX is supplied with a powerful built-in exhaust system which efficiently removes grinding dust from the grinding belt. When mounting the Scantool Cyclone 100 directly to the built-in exhaust system – you obtain the best possible solution of collecting the grinding dust.
Page 34
Main motor Exhaust motor Capacity Grinding belt speedBelt Grinding angels Drive wheel
HP 50/60Hz RPM HP ARBOGA 100RS 21-70 mm 100x1600 18 m./sec 0 - 45 200x100x28 mm 4,1 1400/1700 0,5 ARBOGA 150RS 21-100 mm 150x1600 18 m/sec. 0 - 65 200x150x28 mm 4,1 1400/1700 0,5 ART: 740683120 – 100RS 740681220 – 100RSX ART: 740682120 – 150RS 740682220 – 150RSX
A
