MAY 2016 | Volume 95 Number 5

HydrocarbonProcessing.com

SPECIAL REPORT: MAINTENANCE AND RELIABILITY

39 Take steps to achieve lubrication maintainability

M. Barnes

43 Apply a short-term, high-temperature carbon steel solution to piping systems

M. Chowdry and V. Tiwari

47 Failure prevention—The ultimate asset management strategy

B. Snider

PROCESS ENGINEERING AND OPTIMIZATION

53 Small-scale coal-to-chemicals can revitalize India’s petrochemicals industry, economy—Part 2

M. Marve, S. Sakthivel and P. V. Paluskar

59 Catalytic coprocessing of used cooking oil with straight-run gasoil in a hydrotreating pilot plant

H. de Paz Carmona, A. Brito Alayón, M. Romero Vázquez, J. Frontela Delgado and J. J. Macías Hernández

HEAT TRANSFER

67 Use computational fluid dynamic analysis to revamp fired heaters

A. Chilka and A. Garg

ENVIRONMENT AND SAFETY

75 Lifting of US crude export ban will impact process safety management

K. Molly

TERMINALS AND STORAGE—SUPPLEMENT

T-80 Optimize tank farm operations, safety and profitability

D. Rueda-Rojas

Cover Image: The Epsilon 3XLE benchtop energy-dispersive X-ray fluorescence spectrometer enables ultra-light element analysis for the petrochemical industry.

DEPARTMENTS

4 Industry Perspectives

12 Business Trends

23 Industry Metrics

25 Global Project Data

87 Innovations 90 Marketplace 92 Advertiser Index 93 Events 94 People COLUMNS 9 President’s Letter

A new day for you, a new day for us

11 Editorial Comment Maintenance spending to jump in 2016 as refiners catch up with turnarounds

27 Reliability

Principles are more important than strategies

31 Automation Strategies The “big picture” on ExxonMobil’s open system initiative

33 Petrochemicals

Fluctuations in GCC ethylene production encourage refinery-petrochemicals integration

37 Engineering Case Histories Case 90: Precautions when working near equipment
