TECHBOARD COMMUNICATIONS DIVISION

(1)

TECHBOARD COMMUNICATIONS DIVISION

EMC

▪ TB, ALTERNATIVE COMMUNICATION

EMC▪TB, the newborn TECHBOARD COMMUNICATIONS DIVISION, has been working in the professional telecommunications field for more than 30 years. The core business is focused on design, development and production of professional radio equipment, specializing in repeater stations and transceiver equipment for both fixed and mobile use. Thanks to its in-depth knowledge, in-house development and complete control of both software and hardware, EMC▪TB is able to offer flexible, tailor-made solutions that are particularly suitable for Alternative

Communication needs, that is to say applications where

standard telecommunication systems are unreliable or altogether unavailable.

EMC

▪ TB, EMERGENCY SOLUTIONS

The EMC▪TB high quality and reliable solutions are able to satisfy the most demanding

Emergency needs:

Solutions for customized synchronized and isofrequential networks: EMC▪TB develops networks which relay radio signals over covered widespread areas, insuring a homogeneous coverage of the radio signal. Starting from a single repeater station, EMC▪TB is capable of expanding to an entire network system, without wasting resources.

Integrated solutions: the EMC▪TB products can be integrated with other hardware and/or software systems, such as management devices. On the other hand, the EMC▪TB products are currently being integrated with the DIGIEYE range of DVRs, NVRs and centralization systems designed and developed by SYAC▪TB, TECHBOARD SECURITY DIVISION. The EMC▪TB/ SYAC▪TB video security solutions will meet the demands of end-users (transport, traffic monitoring, police surveillance, military applications, etc.) in need of powerful systems capable of complete videosurveillance and emergency functionalities.

(2)

EMC

▪ TB, RADIO COMMUNICATION PARTNER

EMC▪TB highly qualified team supports partners and end-users through the whole pre and post sales process, from R&D to production, testing, installation and follow-up. For those who have to face the difficult world of telecommunications for the first time, EMC▪TB offers a service taking care of all documentation necessary to obtain radio frequency licenses.

Throughout the years, EMC▪TB has consolidated its relationships with high-end clients such as the Italian Ministry of Defense, Ministry of Internal Affairs (Fire Brigade Dept., Public Rescue and Civil Defense), Ministry of Health (118 Ambulance Service), Ministry of Tunisia for Civil Protection, Fire Brigades of Trento, Bolzano and Aosta, Italian Red Cross, Local Administrations and Police departments, Italian National Civil protection, Radiotaxi and Transport companies, etc.

EMC

▪ TB, DMR ASSOCIATION MEMBER

Since 2011, EMC

▪

TB has been a member of the DMR Association with its DMR mobile terminals LANDER and ROMULUS.

DMR Association website: www.dmrassociation.org

The EMC▪TB products are designed and developed by EMC▪TB and produced by TECHBOARD, of which EMC▪TB has been the COMMUNICATIONS DIVISION since the 7th_{of November.}

TECHBOARD and EMC▪TB are located in Modena, city recognized engineering excellence Made in Italy.

For further information, please contact:

EMC▪TB

TECHBOARD COMMUNICATIONS DIVISION Via Della Scienza, 50

41122 Modena Tel. 059 289811 Fax 059 289862

E-mail: [email protected] Website: www.emc-spa.com

(3)

ALTERNATIVE COMMUNICATION & EMERGENCY SOLUTIONS

SUCCESS STORIES

Herein below are described some EMC▪TB applications of wireless networks. The most significant adopted solutions are stellar, tree and ring configurations made of single and/or multi-channels links for national, regional and city coverage, for both voice and data transmission.

Ministry of Interior - Tunisia Civil Defence

Realization of the radio network of the Civil Protection Department of the Republic of Tunisia. Since 1995, date of the project start, the intrinsic modularity of the EMC▪TB PARROT structure has allowed a continuous evolution that still today provides both scalability and constant growing.

The nationwide network supports both voice and data transmission to and from the operation centre in Tunis and from existing terminals throughout the country.

The EMC▪TB PARROT system implemented in Tunisia consists of a nationwide three-channel simulcast network, with single-channel links and backbones.

User Ministry of _Interior Services Civil Protection

Geographic Area Tunisia Republic

Sites number 37

repeaters 48

simulcast channel 3

Configuration Tree + ring

link type Monochannel

Network Access Dedicated channel

Technology EMC

(4)

State Forestry - Puglia

The structure provides independent provincial networks that also can be interconnected with radio remote controls from the operation centre in Bari after validation by a peripheral access code to the system.

Services CFS

Geographic Area Puglia

Sites number 24

repeaters 26

simulcast channel 1

Configuration Tree

Technology EMC

Remote control PTLC

A.I.B. Service - Umbria

The EMC▪TB PARROT network supports the entire voice radio communications for the fire service. All site information converge at the operative control station in Perugia where the remote monitoring system is able to monitor and control the system.

Services A. I. B.

Geographic Area Umbria

Sites number 7

repeaters 7

simulcast channel 1

Configuration Star

link type Radio

Technology EMC

Remote control PTLC

REGIONE DELL’UMBRIA SERVIZIO A. I. B.

(5)

Bari Police Radio Network

The Department of Municipal Police in Bari has adopted a three-channel network EMC▪TB

PARROT stacked in a star configuration that is connected directly with the operation centre for radio links with the involved staff.

Services Police

Geographic Area Bari

Sites number 6

repeaters 15

simulcast channel 3

Network Access Dedicated

Technology EMC

Remote control EMC PTLC

First Health – 118 - Grosseto - Siena – Arezzo – Voice and data Services

The EMC▪TB network supports all voice radio communication of the 118 Service and the digital signalling that follows the process of intervention.

All site and station information converge to the provincial operation centre, where the remote monitoring system is able to monitor and control the system. Each operation centre has got radioserver systems which handle all the traffic. Besides, the system is able to provide TCP-IP relevant information to standard computer systems in use at the 118 Service. Isofrequency stations are connected with single-channel links.

(6)

Services First Health

Geographic Area Grosseto - Siena - _Arezzo Sites number 16

repeaters 16

simulcast channel 3

Network Access Work channel

Technology EMC

Remote control EMC PTLC

Radioserver System for Operation Centre

Sistema 118 Grosseto – Siena

(7)

Civil Defence Marche Region - Backbone WAN to 6.4 GHz 155 Mbit

The Marche Region, in order to improve and optimize the service of communication and data acquisition/processing, has acquired a SDH dorsal extension with 6.4 GHz radio multi-channel links and 155 Mbit capacity. The same multi-channel connections provide a wide area network up to 100 Mbit available in the suburbs and the regional operation centre supporting the physical network.

Services Civil Protection

Geographic Area Marche

Sites number 18

Frequency 6,4 GHz

Link type multichannel - 155 _Mbit Network Access Direct

Technology EMC- Ceragon

Remote Control Ceraview Manager

Autonomous Province of Trento Fire Brigades – RadioServer

The Autonomous Province of Trento Fire Brigades, in order to improve and optimize the service of communication and data acquisition/processing, has acquired a Central Office RadioServer used to manage simultaneously 8 radio channels.

Radio resources are interfaced with the network through dedicated LAN interface (called Voice-to-LAN) and are available for the all operator stations on the network.

The system, through operator stations with a Touch-Screen Dispatcher, allows to monitor radio traffic on multiple channels selected by the operator, record voice calls, listen to audio through Instant Replay function, manage sending, request and reception of GPS coordinates and manage groups and sub-groups of operators.
