In late July 2004, a shocking report hit the healthcare news wires that 195,000 deaths in the U.S. could be attributed to hospital errors. This number nearly doubles the Institute of Medicine's (IOM) 1999 study that claimed 98,000 people a year die from what it characterized as preventable medical errors.

HealtGrades, Inc. a Lakewood, CO based company took into account the Medicare records of 50 states and Washington DC over a three year period from 2000 through 2002. Out of 37 million hospitalizations tracked, there were 1.14 million "patient-safety incidents" reported, and "of the total 323,993 deaths among Medicare patients in those years that developed one or more patient-safety incidents, 293,864, or 81% of these deaths were directly attributable to the incidents." Thus, between 2000 and the end of 2002, 1 out of 4 Medicare patients died of a patient-safety related incident. See: http://www.msnbc.msn.com/id/5536730/

In an effort to reduce costly medical errors and increase patient safety, more and more hospitals and health systems have begun to initiate positive patient identification (PPI) strategies which include Bar Code-Enabled Point-of-Care technology (BPOC). BPOC systems, when augmented with sophisticated computer logic, can protect patients from prescription, transcription and dispensing errors. This technology allows for real time confirmation of patient identification, medication, dose, time and route of administration.

HIMSS (Healthcare Information & Management Systems Society) in its 15th Annual Leadership Survey sponsored by Superior Consultant Company and released in June, 2004, reported cost pressures and patient safety issues were the top two business challenges that will have the greatest impact on healthcare over the next two years. It was also reported that the top IT priorities in terms of automated clinical applications were: #1: Electronic Medical Records (EMR); #2: Computer-based Practitioner/Physician Order Entry (CPOE) and # 3: Clinical Information Systems.

As for which healthcare technologies will have the greatest focus over the next two years: high-speed networks, data security, and bar coding garnered the most survey votes from information technology (IT) executives at healthcare provider institutions and vendor organizations across the U.S. The rise of bar coding in importance, as compared to 2003 HIMSS survey results, can probably be attributed to increased industry awareness of the role that bar code technology can play in helping to reduce misidentification errors that ultimately will lower the number of patient-safety-related or Sentinel Events.

Introduction

Regulatory Influences: HIPAA, FDA & JCAHO

The Healthcare Insurance Portability and Accountability Act of 1996 (HIPAA) was the kick start for healthcare institutions to seriously consider bar coding as a means of safeguarding the way they transmit, store, and access protected health information. HIPAA regulations state that a common set of codes must be adopted by healthcare facilities that encompass all medical procedures as part of an electronic exchange of information to increase efficiency and reduce medical errors.

More recently, however, the U.S. Food and Drug Administration (FDA) released its final ruling in February 2004 requiring a linear bar code (that conforms to Unified Code Council "UCC"

specifications) be on many over-the counter and prescription drugs, vaccines, and blood products administered in healthcare settings to help improve patient safety at point-of-care. The Joint Commission on Accreditation of Healthcare Organizations (JCAHO) also views correct specimen labeling and accurate patient ID as cornerstones of their Patient Safety Standards & Guidelines:

■ Use at least two patient identifiers (not including the room #) whenever taking blood

samples or administering medication or blood products.

■ Prior to surgical or invasive procedures, conduct a final verification process.

Positive Patient ID at Point-of-Care & PDC’s Role

The reduction of medication errors at point-of-care is the primary goal of many healthcare institutions that have opted to automate their medication administration processes: e-MAR (electronic medication administration). Nearly one third of the medication administration errors that have been cited as the cause of ADE (Adverse Drug Events) occur at bedside and only 2% are caught. Clinical research released in September of 2002 concluded that "healthcare facilities are experiencing as many as 1 error per every 5 administered," leaving a huge gap in acceptable patient safety standards. See: www.bridgemedical.com/pdf/whitepaper_barcode.pdf

To ensure positive patient identification, successful bar code implementation integrates the responsibilities of healthcare professionals in Admissions, Pharmacy, Laboratory, Blood Bank, Emergency and other patient care departments. Healthcare personnel in Patient Safety, Quality Control, Risk Management, and Information Technology are also involved in the development and implementation of Bar Code Point-of-Care (BPOC) systems. To that end, Precision Dynamics

Through the entire patient point-of-care process, the ultimate goal is to provide quality healthcare to each patient and to ensure the accurate administration of the five rights: Right Patient, Right Drug, Right Dose, Right Time and Right Route of Administration.

This reference guide is for all healthcare managers and practioners who are evaluating bar code wristband or bar code label systems to ensure positive patient identification in their facility. We hope this information will assist you in selecting the best solution to meet your needs. Inside you will find a summary of Precision Dynamics' portfolio of bar code solution options including the advantages and disadvantages of each. The three areas of focus will be:

■ Thermal Printing Wristband Solutions

■ Adhesive Label Wristband Solutions

■ Laser Printing Wristband & Label Solutions

Regardless of which option you select, we at Precision Dynamics want to go on record to urge you to choose a solution which offers you optimal security with a positive tamper-evident closure in a wristband, along with optimal scanability and freedom from smearing, moisture or other vulnerabilities in a label. The American Hospital Association (AHA) calls for a

"tamperproof, non-transferable identification band…that minimizes the possibility that identifying data can be lost or transferred from one patient to another." (See: the American Hospital

Association Management Advisory: Identification of Newborns & Other Patients, 1992.) All of Precision Dynamics media products meet these important criteria for patient safety and have a long history of successful use in the healthcare field.

A

A GGlliimmppssee aatt RRFFIIDD

RFID represents the next advanced step in positive patient identification after bar coding. PDC

pioneered the development of the Smart Band®_{RFID Wristband System in 2000 and continues to}

lead the way in Auto ID. PDC RFID solutions ensure the integrity of information between patient, host device, and/or hospital information center. Unlike bar code, RFID’s non-line-of-site data transmission can be read through and around the human body, clothing, bed coverings, and non-metallic materials. Furthermore, RFID wristband solutions help to ensure that the "Five Rights of Medications Safety" are achieved, facilitating real-time confirmation of the Right Patient, Drug, Dose, Route, and Time. To learn more, visit wwwwww..ppddcc--rrffiidd..ccoomm or call 880000--884477--00667700 xx11332200 to request a PDC RFID Healthcare Solutions brochure.

Print bar code information directly on the wristband G

GEENNEERRAALL AADDVVAANNTTAAGGEESS::

■ Most popular method of bar coding in ID bands in U.S. hospitals

■ Efficient process saves time

■ Durability of bands prevents folding or wrinkling of bar code (which can interfere

with scanning)

■ Secure snap closure prevents tampering or removal of band

■ Suitable for decentralized admissions via low-cost printers in remote locations

■ Full range of wristband sizes and colors available

G

GEENNEERRAALL DDIISSAADDVVAANNTTAAGGEESS

■ Requires dedicated direct thermal printer

■ Material may not be perceived as soft enough for infant patient identification

Thermal Printing Wristband Solutions

W

Direct Thermal Printing Wristbands

A

ADDVVAANNTTAAGGEESS

■ Provides high quality bar code

■ Lower cost because there is no printer ribbon to buy or replace

■ Printing cannot smear because information is "burned" onto a protected thermal layer D

DIISSAADDVVAANNTTAAGGEESS

■ Thermal surface can disintegrate when exposed to very hot temperatures (e.g.

whirlpool bath therapy)

■ Thermal surface will turn dark over long period of time. Not suitable for long term

medical records, but suitable for short term applications (e.g. patient wristband worn up to 10 to 14 days)

Thermal Transfer Printing Wristbands

A

ADDVVAANNTTAAGGEESS

■ Provides high quality bar code

■ Will not turn dark over time

■ Suitable for both long term medical records and short term applications

D

DIISSAADDVVAANNTTAAGGEESS

■ More expensive---requires thermal ribbon that must be replaced

■ Printed information is more susceptible to abrasion or smearing than direct thermal

printing (premium resin ribbons will provide best results)

■ Disposal of used ribbons present some HIPAA security or patient privacy-related

issues if not properly destroyed

P

PDDCC PPrroodduuccttss AAvvaaiillaabbllee CompuBand®

ScanBand®

(2005 PDC Healthcare Catalog, pages 4-7)

Thermal Printing Wristband Solutions

W

Wrriissttbbaannddss ffoorr DDiirreecctt TThheerrmmaall && TThheerrmmaall TTrraannssffeerr PPrriinnttiinngg

P

PDDCC PPrroodduuccttss AAvvaaiillaabbllee Precision®_CompuBand®

(2005 PDC Healthcare Catalog, page 7)

Adhesive Labels are applied:

(1) to All-in-One Wristband System with Clear Adhesive Shield (Option 1, opposite page) (2) Directly on Wristband (without Covering) (Option 2, opposite page)

(3) Inside Clear Protective Pocket (Option 3, opposite page)

G

GEENNEERRAALL AADDVVAANNTTAAGGEESS S

Seeccuurriittyy && SSaaffeettyy

■ Non-transferable, secure plastic snap provides maximum security, as opposed to

adhesive closures

■ Complies with HIPAA, JCAHO, and American Hospital Association industry standards

S

Sccaannaabbiilliittyy && FFuunnccttiioonnaalliittyy

■ Clear adhesive shield provides easy and accurate bar code scanning and optimal

protection from water, solvents, and other abrasives

■ Provides carrier for capturing data for medication administration, point-of-care-testing

(POCT), transfusion verification, specimen collection/tracking, and patient charging

■ Large label area accommodates both laser and thermal labels

C

Coommffoorrtt && QQuuaalliittyy

■ Soft, smooth, and non-abrasive to sensitive skin

■ Water-resistant, durable, and strong, yet lightweight and comfortable

G

GEENNEERRAALL DDIISSAADDVVAANNTTAAGGEESS

■ Three step application may be considered too labor intensive, requiring more handling

than other options listed in this booklet

O

OPPTTIIOONNSS AADDVVAANNTTAAGGEESS DDIISSAADDVVAANNTTAAGGEESS PPDDCC PPRROODDUUCCTTSS AAVVAAIILLAABBLLEE

Adhesive Label

Wristband

Option 1

System with Clear Adhesive Shield

■ Allows you to use laser or thermal labels ■ Secure snap closure prevents tampering or

removal of band

■ Supports text, linear and 2D bar codes, photo ID and graphics

■ Plastic band prevents folding or wrinkling of bar code (which can interfere with scanning)

■ Full range of wristband colors available

■ Not a one-step process

■ Must center the label beneath the clear adhesive shield to ensure proper alignment

S Seennttrryy®®_{BBaarr CCooddee} LLaabbeellBBaanndd™™ (2005 PDC Healthcare Catalog, page 9)

Adhesive Label

Wristband

Option 2

(no covering)

■ Special ClearImage surface on wristband allows for superior label adhesion ■ Durable & strong; yet lightweight

and comfortable

■ Available in 3 sizes and up to 7 colors ■ This option supports text, linear and 2D bar

codes, photo ID and graphics

■ Secure snap closure prevents tampering or removal of band

■ Full range of wristband sizes and colors available for color coding options

■ Exposed label may be affected by moisture and abrasion over time

■ Quality of the bar code produced by laser printers is very dependent on the printer capabilities and the label stock used

S

Seennttrryy®®_{DDaattaaMMaattee}®®_SSyysstteemm

(2005 PDC Healthcare Catalog, page 10)

Adhesive Label

Wristband

Option 3

Pocket

■ Allows you to continue using current insert style wristbands

■ Allows you to continue using current bar code labels

■ Bar code can be scanned through the clear insert pocket

■ Insert pocket protects the bar code from moisture and tearing

■ Plastic band prevents folding or wrinkling of bar code (which can interfere with scanning) ■ Secure snap closure prevents tampering or

removal of band

■ Full range of wristband sizes and colors available for color coding options

■ Requires more handling than other options listed in this booklet

■ Clear protective pocket may not allow for consistent scan rates

S

Saaffeegguuaarrdd®®_{SSeeaalliiddeenntt}®®_,,

S

Seeccuurrlliinnee®®_{,, aanndd PPrriimmeeBBaanndd}®®

(2005 PDC Healthcare Catalog, page 11)

Print bar code wristbands and labels as part of a laser printed form. A

ADDVVAANNTTAAGGEESS

■ Single piece construction allows you to print wristbands, forms, and labels from the

same laser printer

■ Capable of full color or other images using color laser printers as well as producing a

clear, crisp bar code

■ Available with pre-printed color, if desired

■ Available in multiple styles & sizes

■ No extra equipment (e.g. thermal printers) needed

■ Integral laminate protects image

D

DIISSAADDVVAANNTTAAGGEESS

■ Decentralized admission via remote printers may be cost prohibitive due to the added

expense of toner cartridges

■ Exposed label may be soiled by moisture and body fluids

■ Entire sheet of labels must be printed. Some labels may not be used, thus increasing cost.

■ The quality of laser printed bar codes is greatly dependent on the capabilities of the

printer and the label stock used

Laser Printing Wristband & Label Solutions:

P

PDDCC PPrroodduuccttss AAvvaaiillaabbllee DataMate®_Laser

Label/Wristband System (2005 PDC Healthcare Catalog, page 13)

Glossary of Bar Code Symbologies & Terms

Chhaarraacctteerr sseett What characters can be represented by the symbology.

C

Chheecckk DDiiggiitt This is the last character before the stop character and is calculated by a formula based on the rest of the data. It is part of some

symbologies and is added to others to increase the security rate. C

Coonnttiinnuuoouuss b

baarr ccooddee

If barcode characters contain a space at the end of each character as part of it.

D

Deennssiittyy Number of Data Characters per unit of length, usually inches.

D

Diissccrreettee bbaarr ccooddee If the spaces between characters are not part of each character.

E

Elleemmeenntt wwiiddtthhss Number of different width elements in the bar code, two width or multiple width.

FFiixxeedd lleennggtthh Bar code must have this many characters.

O

Onnee ddiimmeennssiioonnaall b

baarr ccooddee

Symbology that can be read by drawing a straight line through any part of the bar code is one dimensional.

M

Moodduullee wwiiddtthh Width of the narrowest element.

N

Noommiinnaall wwiiddtthh Width of the narrowest element.

Q

Quuiieett ZZoonnee This is the area to left and right of the bar code. It is required on all bar codes, otherwise any graphics, type or the edges of the item will be interpreted as a bar. For two dimensional bar codes it is all four sides.

A

A

ABBCC SSyymmbbooll - The American Blood Commission (ABC) developed this symbol as a bar code standard for automated systems in the blood service community. The particular symbology used for the ABC symbol is Codabar.

A

ABBMMAA - Auto ID Bar Code-Enabled Medication Administration System. A

Accccuurraaccyy - The determination of whether any element width or inter-character gap width (if applicable) differs from its nominal width by more than the printing tolerance.

A

ADDCC - Automated Data Collection or Automated Data Capture - refers to all technologies that automate the process of data collection without the use of a keyboard, including bar code, magnetic stripe, (OCR) optical card reader, voice recognition, smart card or (RFID) radio frequency identification. ADC provides a quick, accurate and cost effective way to collect and enter data.

A

Addhheessiivvee - 1) A substance (cement, glue, gum) capable of holding materials together by surface contact. 2) The portion of a pressure sensitive label which allows the label to cling to its intended surface.

A

AIIAAGG - Automotive Industry Action Group - a trade association responsible for creating automotive industry standards pertaining to bar code symbology and common label formats. A

AIIMM - Automatic Identification Manufacturers, Inc. - a U.S. trade association headquartered in Pittsburgh, PA who represent the manufacturers of automatic identification systems. AIM International (AIMI) is a global affiliation of trade associations whose member companies are involved with application of automatic identification technology. For more information access http://www.aimi.org.

A

Alliiggnnmmeenntt - In an automatic identification system (Auto ID), the relative position and orientation of a scanner to the symbol.

the development of voluntary bar code, quality standards. Bar code printing standards and the readability of bar code symbols are determined and classified into grades from A to F, in order to provide an overall symbol quality test. http://www.ansi.org/.

A

Appeerrttuurree - The opening on an optical system (scanner) that establishes the field of view. A

Apppplliiccaattiioonn -The particular use the label, tag or ticket will serve once the barcode, text, or graphic image is applied.

A

ApppplliiccaattiioonnTTeemmppeerraattuurree - The temperature at the time the label is applied. A

Assppeecctt RRaattiioo - The numeric ratio of the bar's height to the symbol's length

B

B

Baacckkccooaattiinngg - Used on a thermal transfer ribbon to prevent the ribbon from sticking to the print head and to the substrate (media/label material). It also protects the printhead from excessive heat, static, and abrasion.

B

Baacckkggrroouunndd - The spaces, quiet zones, and areas surrounding a printed symbol. B

Baarr - The darker element of a printed bar code symbol. B

Baarr CCooddee - A bar code is a piece of Automatic Identification Technology (Auto ID) that stores real time data. It is a series of vertical bars or a graphical bar pattern which can, (depending on the width and pattern) encode numbers and letters in a format which can easily be retrieved and interpreted by a bar code reader.

B

Baarr ccooddee CChhaarraacctteerr - A single group of bars and stripes that represents a specific quantity (often one) of numbers, letters, punctuation marks, or other symbols. This is the smallest subset of a bar code symbol that contains data.

B

Baarr CCooddee DDeennssiittyy - The number of characters that can be represented in a linear unit of measure. This number is often expressed in characters per inch or cpi.

Technology Print Quality Scanner Readability Initial Installation Cost Long Term Maintenance Material Waste Dot Matrix Fair Low Low/Moderate Moderate/High High Ink Jet Moderate Low/Moderate High Moderate/High High Laser Moderate Moderate Moderate/High Moderate/High High Direct Thermal Moderate/ Excellent Moderate/ Excellent

B

Baarr HHeeiigghhtt //LLeennggtthh - The bar dimension perpendicular to the bar width is also called bar height. Scanning is performed in an axis perpendicular to the bar length.

B

Baarr WWiiddtthh - The thickness of a bar measured from the edge closest to the symbol start character to the trailing edge of the same bar.

B

Beeaarreerr BBaarrss - A minimum of two parallel bars running the length of the top and bottom edge of a bar code. Bearer bars, if used, reduce the probability of a misread when a skewed scanning beam enters and/or leaves the symbol through the top or bottom.

B

Bii--DDiirreeccttiioonnaall - Bar code symbology capable of being read successfully independent of scanning direction.

B

Biinnaarryy - A numbering system that uses only 1's and 0's. B

Biitt - An abbreviation for binary digit. A single element (0 or 1) in a binary number. B

Biittmmaappppeedd FFoonntt - Refers to the inherent character and font sets found within a thermal printer and their respective ability to be adjusted and "shrunk to fit". Bitmapped fonts are commonly available in limited point sizes - ex - 6, 8, 10, 12, 14 and 18 point - whose edges can become distorted or rough with manipulation outside the prescribed point size ranges

B

BPPOOCCTT-Bar Code Enabled Point-of-Care Testing

C

C

Chhaarraacctteerr - (1) A single group of bars and spaces that represents a specific number (usually one) of numbers, letters, punctuation marks, or other symbols. (2) A graphic shape representing a letter, numeral, or symbol. (3) A letter, digit, or other symbol that is used as part of the

organization, control, or representation of data. C

Chhaarraacctteerr AAlliiggnnmmeenntt - The vertical or horizontal position of characters with respect to a given set of reference lines.

C

Chhaarraacctteerr DDeennssiittyy - Within a linear bar code symbol, the number of data characters per unit length (typically per inch). For a discrete symbology, the character width must include the intercharacter gap.

C

Cooddee 112288 - is a continuous, multilevel, full ASCII code. There are three types of code 128 encoding. Type A provides the character set of all upper case alphanumeric characters plus all of the ASCII control characters. Type B provides the character set of all upper and lower case alphanumeric characters. Type C provides increased density for numeric encoding with double density numeric characters for all number pairs from 00 to 99.

C

Cooddee 1166KK - This symbol is a stack of from 2 to 16 rows. C

Cooddee 3399 - is the most commonly used bar code. It can encode both numbers and letters which is ideal for most industrial and non-retail applications. The Automotive industry uses Code 39 as its standard for shipping container labels. If you are just starting out a bar code application of your own, we recommend using Code 39.

C

Cooddee 4499 - was introduced in 1987 by the Intermec Corporation as a multi-row, continuous, variable length symbology and was the first stacked (two dimensional) barcode to receive widespread interest.

C

Cooddee 9933 - Code 93 is the complimentary version of Code 39 and allows labels to be approximately 30 percent shorter than Code 39.

C

Cooddaabbaarr -- AA0011223344BB.. -- Codabar is a discrete, numeric code with special characters and four different start/stop characters. Allowable data characters are (0 - 9), special characters (- $ : / . + ), and start-stop characters ( A, B, C, D ).

C

Coolloorr SScchheemmee - Scanners read bar codes by using red light to recognize the contrast between the bars and spaces of the symbol. Colors that will scan effectively need to be chosen. Black bars against a white background are the safest choice, but other combinations will also work. Quiet Zone: The margins around the bar codes are vital; they enable the scanner to identify the beginning and the end of the bar code.

C

Coonnccaatteennaattiioonn - The ability of a reading system to join together that data from multiple symbologies and interpret the information in a single message.

C

CPPOOEE - Computerized Physician Order Entry

D

D

Daattaa IIddeennttiiffiieerr - A character (or set of characters) that uniquely defines the specific use of the data encoded in the bar code symbol following the data identifier. Also known as a Flag Character. D

Deeccooddeerr - An electronic device which translates the electrical signals from a scanner into computer compatible data. The decoder performs checks on the electronic signal to validate it, and processes the signal through a decode algorithm designed to detect errors in the signal. The

output of the decoder may drive a keyboard input to a terminal (see Keyboard Wedge Decoder) or may interface with a communications port on a computer (see Serial Decoder).

D

Deemmaanndd PPrriinntteerr - A printer capable of creating individual documents one at a time, as needed D

Doott MMaattrriixx PPrriinnttiinngg - A print technology that employs several needles which are evenly spaced across a moveable horizontal shuttle which oscillates back and forth as the paper advances. Dot matrix printers print a bar code by creating overlapping adjacent dots to produce

approximations of a straight edge line. Prints low to medium density bar codes that may not meet certain end-user guidelines. The dot size on the matrix printer limits the narrow element size and density of the bar code. Continuous ribbon re-use on dot matrix printers requires continuous monitoring of ribbon condition to ensure adequate bar code contrast - Ribbon ink that has become exhausted can produce an image that is inadequate for scanning. Ink saturated ribbon can result in paper "bleed" which can cause image distortion. Dot matrix printers are modified line printers that are most frequently used for printing batches of large labels with low density bar codes. Printing of single, individualized labels results in significant waste. The design of the matrix printer's print carriage, sitting far below the media, also does not enable one to adequately maximize one's label space.

D

Doott SSiizzee ((PPrriinntteerr)) - The size of the printed dot on a substrate in a matrix or line to form

characters. Minimum dot size is determined by the size of the thermal element of the print head being used by the thermal printer. Dot size determines the X dimension. The X dimension is always a simple multiple of the dot size.

D

Doott SSiizzee ((SSccaannnneerr)) - The diameter of the beam of light projected by the scanner used to read a bar code symbol. The scanner dot size should be no larger than the X dimension of the bar code symbol. D

DPPII - Dots Per Inch (refer to Resolution) D

Diirreecctt TThheerrmmaall PPrriinntt - (DT) Direct thermal printing is an old technology originally designed for low cost copiers and fax machines. It has since been transformed into a highly successful technology for bar coding. The thermal print head is typically a long linear array of tiny resistive heating elements (100-300/inch) arranged perpendicular to the paper flow. Each thermal print head element locally heats an area on the chemically coated paper directly under the print element. This induces a chemical reaction which causes a dot to form in that area. The image is formed by building it from dot rows as the media passes underneath the active edge of the print head. Direct thermal printing is an excellent choice for many bar code labeling applications. DT printers provide

E

E

Eddggee RRoouugghhnneessss - Irregularities in the printing of bar code elements, resulting in a non-uniform edge and edge errors.

E

EDDPP -Electronic Data Processing - the act of processing information electronically. E

EDDII -Electronic Data Interchange - A method by which data is/are electronically transmitted from one point to another.

E

EHHRR - Electronic Health Record e

eMMAARR - Electronic Medication Administration Record

F

FFaacceessttoocckk - The part of the substrate (media) where printing occurs.

FFiirrsstt RReeaadd RRaattee ((FFRRRR)) - The ratio of the number of successful reads on the first scanning attempt to the number of attempts. Commonly expressed as a percentage.

FFiixxeedd RRaattiioo - The ratio between the width of the bars in the code is a fixed standard and cannot be changed.

H

H

Haanndd--HHeelldd SSccaannnneerr - A hand-held scanning device used as a contact bar code reader or OCR (optical code) reader.

H

Heeaatt RReessiissttaannccee - The property of a material which inhibits the occurrence of physical or chemical changes caused by exposure to high temperatures.

H

HIIBBCCCC - Abbreviation for the Health Industry Business Communications Council - a trade association responsible for the symbology and label format used by the healthcare industry. H

HIIMMSSSS- HIMSS (Healthcare Information and Management Systems Society) is the healthcare industry's membership organization exclusively focused on providing leadership for the optimal use of healthcare information technology and management systems for the betterment of human health. Founded in 1961 with offices in Chicago, Washington D.C., and other locations across the country, HIMSS represents more than 14,000 individual members and some 220 member

corporations that employ more than 1 million people. HIMSS frames and leads healthcare public policy and industry practices through its advocacy, educational and professional development

initiatives designed to promote information and management systems' contributions to ensuring quality patient care.

H

Hiigghh DDeennssiittyy - This bar code type has narrow spaces and bars with an "X" dimension that is less than 7.5 mils.

H

Hoorriizzoonnttaall BBaarr CCooddee - A bar code or symbol presented in such a manner that its overall length dimension is parallel to the horizon. The bars are presented in an array that looks like a picket fence.

H

Huummaann--RReeaaddaabbllee -The interpretation of bar code data, often printed immediately below the bar code in a readable format to humans.

I

IInnkk JJeett PPrriinnttiinngg - Common direct marking process and a favorite on high speed production lines. Ink droplets are selectively deflected between a moving product and an ink return channel . Ink jet printing is frequently used for coding products and cartons with human readable data and lot codes at very high speed and for case coding of cartons with bar codes. Bar codes on

corrugated boxes are intentionally made large so that dot placement accuracy becomes less critical. Thus, using more ink and creating questionable print quality and usefulness for bar coding.

IInnkk LLaayyeerr - The bottom layer of a thermal transfer ribbon of a thermal ribbon which is composed of waxes, resins or a combination of both.

IIPPSS - Inches Per Second (refer to Print Speed)

ISO (International Organization for Standardization) - is a worldwide federation of national standards bodies from some 100 countries, one from each country. ISO is a non-governmental organization established in 1947. The mission of ISO is to promote the development of

standardization and related activities in the world with a view to facilitating the international exchange of goods and services, and to developing cooperation in the spheres of intellectual, scientific, technological and economic activity. For more information access http://www.iso.ch/.

L

rungs on a ladder. Contrast with Picket Fence.

LLaaddddeerr OOrriieennttaattiioonn - A bar code symbol positioned vertically with horizontal bars and spaces. LLaammiinnaattee - Apply one layer of material over another.

LLaasseerr SSccaannnneerr - An optical bar code reading device using a low-energy laser light beam as its source of illumination.

LLaasseerr PPrriinnttiinngg - The laser printer works much like a photocopier projecting controlled streams of ions onto the surface of a print drum resulting in a charged image. The charged image then selectively attracts toner particles - transferring the image onto the paper substrate (media) by means of pressure. The pressure from the print head and drum then fuse the image to the paper - creating the image. A laser printed label is only as durable as a photocopy of paper. They commonly cannot produce chemical or water resistant labels. Laser printer labeling adhesives must be carefully selected to ensure stability under the heat and pressure of the fuser. Laser printers are not well suited for industrial labeling applications or individual product labeling applications. Compatible toners for thermal printing applications are, often times, lacking. Cost of toner is significant for barcode printing - 15-30% black for bar code print versus 5% black for word processing print - 6 x the cost for barcoding using laser when compared to direct thermal or thermal transfer!

M

M

Maacchhiinnee--RReeaaddaabbllee - A general term used for printed material that can be directly transferred to a data processing system.

M

Maannuuffaaccttuurreerr''ss IIDD - In the UPC code, the 6-digit number applied by the UCC to uniquely identify a manufacturer or company selling products under its own name. Also, the first 6 digits of the 12-digit UPC.

M

Maattrriixx SSyymmbboollss - Appear as a checker board. They are most likely square in shape, and contain some form of "finder pattern" which distinguishes them from other symbols. The finder pattern provides a decoding reference for scanners.

M

Miissrreeaadd - A condition that occurs when the data output of a reader does not agree with the data encoded in the bar code symbol.

N

N

Noonn--RReeaadd - The absence of data at the scanner output after an attempted scan due to no code, defective code, scanner failure or operator error.

N

Nuullll MMooddeemm CCoonnnneeccttoorr - A device which connects to the serial output of a print cable and switches pins 2 and 3, transmitted data signal and received data signal.

N

Nuummeerriicc - A character set that includes only numbers.

O

O

Oppeerraattiinngg TTeemmppeerraattuurree - denotes the prescribed temperature range for the safe operation of a thermal printer.

O

Orriieennttaattiioonn - The alignment of a bar code symbol with respect to horizontal. Two possible orientations are horizontal and vertical bars and spaces (picket fence formation) and vertical with horizontal bars and stripes (ladder formation).

O

Ovveerrhheeaadd - The fixed number of characters required for start, stop, and checking in a given bar code symbol, e.g. a symbol requiring a start and stop character and two check characters contains four characters of overhead. To encode three characters with the overhead listed, seven characters are required to print.

P

P

Paarraalllleell IInntteerrffaaccee - a link between data processing devices on which the data moves over multiple wires and more quickly than serial interface. Imagine transmitting all 8 letters in a word at the same time over each wire. In parallel interface, the 8 bits (a byte) are received and then processed simultaneously.

P

PDDFF--441177 - A popular two-dimensional bar code that allows thousands of characters to be stored in its data format of multi-stacks. Some states use this type of bar code for driver's license information. Healthcare facilities may also use the PDF417 for patient records because of the amount of data it can store.

P

P

Poollyyeetthhyylleennee -A tough, sturdy plastic film having very good, low temperature Characteristics. P

Poollyypprrooppyylleennee - Similar to polyethylene but stronger and having a higher temperature Resistance. P

Prreessssuurree SSeennssiittiivvee LLaabbeell - A pressure sensitive label product is a die-cut part that has been converted through the production equipment using the type of pressure sensitive material that has

a protective backing. The end product is produced in the form of rolls, sheets, fanfold or by other techniques that produce like products which have been slit or cut from the converted roll.

P

Prriinntt MMeetthhoodd - denotes the print technology used to print a label - commonly direct thermal or thermal transfer variety.

P

Prriinntt QQuuaalliittyy - The measure of compliance of a bar code symbol to the requirements of dimensional tolerance, edge roughness, spots, voids, reflectance, PCS, quiet zone, and encodation.

P

Prriinntt SSppeeeedd - the speed at which the label moves through the print head measured in inches per second (ips)

Q

Q

Quuaalliittyy CCoonnttrrooll - Applications that use automatic identification to make sure the right material is in stock so it can be delivered for the right cost to the right user at the right time.

R

R

RAAMM --RRaannddoomm AAcccceessss MMeemmoorry - A machine's main working memory. Program instructions and data are stored here. Each location in memory has a unique address, so the computer can access the information in any location at any time it's required (i.e. "randomly"). RAM can be erased, written to, read from, and rewritten. It is erased when a computing device is turned off. R

Reessoolluuttiioonn - The narrowest element dimension that can be distinguished by a particular reading device or printed with a particular device or method. Generally the higher the resolution the better the resultant print quality.

R

Reelleeaassee LLiinneerr ((BBaacckkiinngg)) - The portion of the pressure sensitive label which supports and holds the facestock and adhesive until application to the intended surface is needed.

R

Reessoolluuttiioonn - The narrowest element dimension that can be distinguished by a particular reading device or printed with a particular device or method. Measured in Dots Per Inch (dpi).

R

Riibbbboonn - A cloth or plastic tape coated with several layers of material, one of which is ink-like, that produces the visible marks on the substrate. Used on formed font impact, dot matrix, thermal transfer and hot stamp printers. Also called foil.

S

S

Sccaalleeaabbllee FFoonnttss - refers to the inherent character and font sets found within a thermal printer and their respective ability to be adjusted and "shrunk to fit". Scaleable fonts are also commonly referred to as smooth fonts as their point sizes can be adjusted to any desired custom size evenly and proportionally, without the advent of visible roughedges.

S

Sccaannnneerr - A device used to read a bar code symbol. It optically converts optical information into electrical signals.

S

Seerriiaall IInntteerrffaaccee - a link between data processing devices on which all the data moves over one wire, one bit at a time. Think of it as transmitting words one letter at a time until a total of 8 letters or bytes (8 bits) are received. The byte is then processed, but in a slower fashion than parallel. Common serial interface communications are RS232 C, RS422 and RS485 (9 or 25 Pin). S

Shheellff LLiiffee -The period of time during which a product can be stored under specified conditions and still remain suitable for use.

S

Skkeeww - Rotation of a bar code symbol about an axis parallel to the symbol's length. S

Sppeeeedd // TThhrroouugghhppuutt - used interchangeably to refer to a rate of motion or printer performance calculated in ips or inches per second. The higher the ips the greater the printers performance rating. S

Sttaarrtt CChhaarraacctteerr - A unique character to the left of the bar code which allows for bi-directionality. (In a vertical bar code, the start character is at the top).

S

Sttoopp CChhaarraacctteerr - A unique character to the right of the bar code which allows for bi-directionality. (In a vertical label, the stop character is at the bottom).

S

Suubbssttrraattee - The surface on which a bar code symbol is printed. Also, interchangeably referred to as media.

S

Syymmbboollooggyy - The language used in bar code technology (e.g. UPC, Code 39, etc). STAC (Symbol Technical Advisory Committee) to the Uniform Code Council Inc., (see UCC).

T

T

Taammppeerrpprrooooff LLaabbeell - A pressure-sensitive material that cannot be removed intact, thus making reuse of the label impossible.

T

Thheerrmmaall TTrraannssffeerr

Print - Thermal transfer printers use the same basic technology as direct thermal printers, but with the elimination of chemically-coated media in favor of a non-sensitized face stock and a special inked ribbon. A durable polyester ribbon film coated with a dry thermal transfer ink is placed between the thermal printhead and label. The thermal print head is used to melt the ink onto the label surface, where it cools and anchors to the media surface. The polyester ribbon is then peeled away, leaving behind a stable, passive image. Consistent / sharp edge bar code print capability - with durable long-life and archival image stability. Clean, quiet, compact operation Batch or individual label print capability. Low cost / low maintenance compared to comparable technologies. Maximum readability and IR scanability. High contrast text, graphic and barcode print capability. Durable for operation joint office / industrial applications.

Throughput - refers to the average length of label stock that a printer can process and print in a given amount of time. Throughput differs from print speed in that throughput includes the label transmission, formatting and printing times. Due to these factors, a 12 ips machine may have lower throughput than a 10 ips printer.

T

Tiilltt -Rotation of a bar code symbol about an axis perpendicular to the substrate. T

Twwoo--DDiimmeennssiioonnaall BBaarr CCooddee - Two Dimensional Bar codes are special rectangular codes which 'stack' information in a manner allowing for more information storage in a smaller amount of space. These are also referred to as 'Stacked' Bar Codes or 'Matrix' Bar Codes. A standard bar code is limited to 20 to 25 characters.

T

Twwoo--DDiimmeennssiioonnaall SSyymmbboollooggyy - A machine readable symbol composed of rows of encrypted data arranged in a rectangular or square pattern. The rows of data may be composed of bar code strips, "stacked" to form the two-dimensional block pattern or arranged as a checkerboard "matrix" of typically square elements.

U

U

UCCCC -- UUnniiffoorrmm CCooddee CCoouunncciill - formerly the Uniform Product Code Council. The organization that administers the UPC and other retail standards.

U

USSSS ((UUnniiffoorrmm SSyymmbbooll SSppeecciiffiiccaattiioonn)) - The current series of symbology specifications published by AIM; currently includes USS-I 2/5, USS-39, USS-93, USS-Codabar and USS-128.

V

V

Veerriiffiiccaattiioonn - The technical process by which a Bar Code symbol is evaluated to determine whether it meets the specification for the specified symbol.

V

Veerriiffiieerr - A device that makes measurements of the bars, spaces, quiet zones and optical characteristics of a symbol to determine if the symbol meets the requirements of a specification or standard. Vertical Bar Code - A code pattern presented in such an orientation that the axis of the symbol from start to stop is perpendicular to the horizon. The individual bars are in an array that appears as rungs of a ladder.

V

Vooiidd - The undesirable absence of ink in a printed bar.

XYZ

""XX"" DDiimmeennssiioonn - The "X"-dimension is the narrowest bar or space in the bar code. This bar or space is measured in millimeters. (mil=1/1000 of an inch). The "X"- dimension defines the density of a linear symbology. Depending on what the "X"- dimension of a bar code is, the bar code will be called either high density or low density.

""ZZ"" DDiimmeennssiioonn -The achieved width of the narrow elements, calculated as the average of the narrow bar width and the average narrow space width.

Z

ZPPLL // ZZPPLL IIII - Zebra Programming Language - is the universal language / code of all Zebra bar code printers. ZPL is an ASCII based format that enables label generation to occur by way of an instructional blueprint g label length, field origin, field data and other related information. ZPL enables labels with any combination of text, barcode or graphics to be created.

w

ww

ww

w..p

pd

dc

c--h

he

ea

alltth

hc

ca

arre

e..c

co

om

m

FFoorr iinnffoorrmmaattiioonn ccaallll CCuussttoommeerr CCaarree aatt 880000..777722..11112222 oorr 881188..889977..11111111 66::3300 aamm--44::3300 ppmm PPSSTT 13880 Del Sur Street | San Fernando, CA 91340-3490
