"IGtra Pro" was designed to make the monitoring and analysis of temperatures easier to read.
Easy and accurate settings:Within seconds, you can set recorders and set:
• the frequency of temperature measurement
• clock synchronizing the recorder on the pc
• countdown timer to start recording later
• alarms of the level of temperatures
You can also enter an internal identification to your iButton (refrigerator, freezer, cold room, product, transport, etc.). Fast and rich in information records:
In reading your iButton, viewing the listing directly temperature readings and a list of high alarms and alarms bases, and a graph showing the curve recorded throughout the mission falls temperatures.
Solutions informatiques
M a i n f u n c t i o n s : • Traceability and
temperature monitoring • Set your iButtons • Raise your iButtons • Archive your data on a
secure external server
• Print a list and a graph of the data collected
A d v a n t a g e s :
• No limit on number of iButtons
• Automatic, secure data archiving
• Simplified management of Use
• Reduced operating costs (MO and travel expenses)
• Inviolability of temperature data recorded
This software allows programming and playback buttons with
archiving data on a secure Internet external server.
You can also:
• Zoom the graph
• Print the graph and the listing temperatures
• Search records by date, user...
Sending data to the server:
After making all your operations locally you click transfer data from iButton to your secure external server. You will then be able to read your data at any time using login and password that you have been given with the purchase of the package iGtra Pro.
The iGtra Pro software provides complete inviolability of temperature data recorded by iButtons. In conclusion:
The iGtra Pro software is the ideal solution for controlling simple but reliable, all your temperature controls, track your products, your transport and your processes.
With the ability to read data archiving on an external server via Internet, operating costs related to the management of temperature readings will be greatly reduced.
• Total immunity temperature readings
• Secure archiving of data on the server
Solutions informatiques
Specifications for use iGtra Pro program:
• a computer or tablet running Windows 7 or 8 with a free USB port
• Internet connection
IGtra Pro package consists of:
• A " USB :1 -Wire / iButton Adapter" interface for license key to use the program.
iButtons reader: just snap the iButton on the reader to make reading or programming. It connects to the back of the USB: 1 -Wire / iButton interface.
• The iButton is the smallest temperature logger in the world but also the least expensive to use!
The range of possible to record iButtons temperatures ranging from - 40 ° C to 125 ° C Ideal for all your temperature controls, track your products, your transport and your processes. Small, rugged, this temperature recorder fits everywhere and supports shocks, water, and dust. All records are archived and time in the protected memory. Battery life: up to 8 years.
• A login and password allowing access to data stored on temperature readings on your secure external server.
There are several models of iBoutons:
Model DS1921G DS1922L DS1922T
Measuring range -40°c à +85°c -40°c à +85°c 0°c à +125°c
Storage capacity 2048 measures 4096 measures 4096 measures
Estimated life expectancy 8 years 8 years 8 years
Tested and approved European standard EN 12830
DS1921G Form Factor Drawing (units = mm)
P a c k a g g e : • S o f t w a r e i G t r a P r o • I n t e r f a c e r e a d e r • i B o u t o n s • L o g i n + p a s s w o r d Concerned sectors
For more information, please contact 00324/365.64.19 and ask
for your test pack for duration 2 weeks.
Solutions informatiques
iGtra Pro « single user »:
In the "Single User" version, the user can do anything; it is both "Master and Costumer"
• Set the iButtons
• Identify iButtons
• Archive data of temperature reading to the secure server via Internet
• Connect to the server to view the archived data
• Print a list and a graph of the data collected i G t r a P r o
iGtra Pro « multi user »:
In the "Multi User" version, we define a “Master” and / or “Customer”. - Master :
• Set the iButtons
• Connect to the server to view the data stored by customers
• Print listings and graphs of temperature readings clients - Costumer :
• Identify iButtons
• Print a list and a graph of its temperature readings
• Archive data of temperature shifts to the secure server via Internet
With the ability to read the archives of temperature readings over a secure Internet via external server manager controls may at any time and without moving analyze data from all its customers.
→ Less than travel to pick up shifts
→ Less waste of time to recover the temperature readings → Less risk of losing the archived data
• i G t r a P r o M a s t e r :
