Towing – Recovery

Actros

Guidelines for Breakdown Services 2009 Edition

(4)

(5)

If you have any questions or problems in connection with the towing or recovery of Actros vehicles, please contact:

Daimler AG

Technical Field Service Tel. +49 711 / 17 - 59 762

(6)

are subject to change without notice.

Reprinting, reproduction or translation, in whole or in part, is not permissible without the written consent of Daimler AG.

If you have any questions or suggestions concerning this product, please write to us at: E-mail: [email protected] Fax: +49-(0) 18 05/0 12-79 78 or Address: Daimler AG GSP/OI HPC R822, W002 D-70546 Stuttgart Technical status: 11/2009 © 2009 Copyright Daimler AG

This Manual, including all its parts, is protected under the laws of copyright. Any further processing or use requires the previous written consent of Daimler AG. This applies in particular to reproduction, distri-bution, alteration, translation, microfilming and storage and/or

processing in electronic systems, including databases and online services.

(7)

Safety and liability information

9

Conventions

9

Vehicle identification

10

Quick guide

12

Instrument panel

Actros 1 (up to 12/1999)

15 Overview 15 Vehicle Diagnostic System/Vehicle Service System 16

Note on display messages 17

STOP lamp 18 System abbreviations 19 Display messages 22 Indicator lamps 27

Instrument panel

Actros 1 (as of 01/2000)

28 Overview 28

Driver Information System (FIS) 31

STOP lamp 39 System abbreviations 40 Display messages 43 Indicator lamps 49

Instrument panel

Actros 2/3 (as of 01/2003)

50 Overview: Actros 2 50 Overview: Actros 3 51 Onboard computer 56

STOP lamp 64

System abbreviations 65

Display messages 66

General

(8)

Actros 1 89

Actros 2/3 91

Fuel system

92

Overview of fuel system 92

Hand pump (location) 95

Bleeding the fuel system 96

Electrical system

98

EMERGENCY OFF switch 99

Jump starting 102

Batteries 105

Gearshift

109

Manual gearshift system 110

Telligent® gearshift system 111

Telligent® automatic gearshift system and

Mercedes PowerShift 113

Teach-in process (Telligent® gearshift/automatic

gearshift system) 116

Teach-in errors 119

Emergency shift of manual gearshift system 120 Actros 1: Emergency shift of Telligent® gearshift

system and Telligent® automatic gearshift system 123 Actros 2/3: Emergency shift of Telligent® gearshift

system, Telligent® automatic gearshift system or

Mercedes PowerShift 128

Compressed air production

134 Versions 134

Pressure regulating system 135

Constant pressure system with separate

four-circuit protection valve 135

Constant pressure system with Electronic

Air-Processing Unit (EAPU) 136

Pressure table 137

Brake system

138 General 138

Telligent® brake system 138

(9)

Telligent

level control

152

Diagram of Telligent® level control 152

Raising/lowering the chassis frame 154

Filling the air suspension system from an external source 156

Tilting the cab

157

Engine

163

Starting/stopping the engine with the cab tilted 163

Tow-starting

165 General 165

Preparations for tow-starting 165

Tow-starting vehicles with manual gearshift system 166 Tow-starting vehicles with Telligent® gearshift system 166 Tow-starting vehicles with Telligent® automatic

gearshift system and Mercedes PowerShift 167

Quick guide

168

Towing

169

General 169

Electrical circuits 172

Air brake system 174

Stopped engine, transmission and/or axle damage 176

Drive and propeller shafts 177

Towing with a tow bar 180

Towing in raised position 181

Raising by the wheels 183

Raising by the front axle 184

Raising by the front of the frame (Actros 1 only) 184 Raising by the leaf springs (construction site vehicles only) 186

Raising at the rear 186

Gearshift 189

Tow-starting

(10)

Recovery

190 General 190

Super-wide tires 191

Recovering the vehicle from the rear 193

Safety components 195

Special tools

196

Recovery

(11)

General

The aim of these guidelines is to provide roadside assistance and towing personnel with the instructions and

information necessary in order to remove the vehicle from the scene of the breakdown or accident within 30 minutes whenever possible.

These guidelines assume that the reader understands and complies with the pertinent accident prevention regulations, any relevant professional guidelines for vehicle ownership or recovery and towing company association regulations, and the road traffic regulations of the country in question.

The instructions in these guidelines, in particular those pertaining to vehicle recovery, are intended exclusively for experienced recovery specialists and are left to the discretion of the user.

Compensation and/or warranty claims arising from towing or recovery measures will not be accepted by Daimler AG.

Conventions

Risk of accident

$

All vehicles that have been towed or recovered from a breakdown must be examined for technical condition and checked for damage at a qualified workshop which possesses all the expertise and tools required to properly perform the necessary work.

Mercedes-Benz recommends a Mercedes-Benz service center for this work. It is absolutely essential that all safety-relevant work and all work on safety-relevant systems is performed by a qualified specialist workshop. Pay attention to the notes in the chapter "Recovery", see page 190.

Risk of accident

$

Tampering with electronic components and their software can cause them to stop functioning. The electronic systems are networked together by interfaces. In some cases, interfering with these electronic systems can also cause malfunctions in systems that were not directly affected. Such malfunctions can put the operational safety of your vehicle, and thus your own personal safety, at considerable risk.

Other improperly performed work or modifications to the vehicle can also jeopardize operational safety. Some safety systems operate only when the engine is running. For this reason, do not switch the engine off while driving.

$

Warning

%

Environmental warning

!

Potential damage + Tip M Instruction

(12)

Location of vehicle model plate/vehicle identification number

Data on the vehicle model plate

• Vehicle model

• Headlamp basic setting • Smoke index

• Rear axle ratio

• Vehicle identification number (VIN) • Permissible gross vehicle weight • Permissible axle loads

18 44

18 Permissible gross vehicle weight in tonnes

44 Engine output in hp (x 10)

: Model plate (example)

; Vehicle identification number on right longitudinal frame member

(13)

General

Key to vehicle identification number

Vehicle identification number (VIN)

WDB 934.042 1 L 115548

WDB Vehicle manufacturer

934.042 Vehicle model designation (see below)

1 Steering

1 = left-hand drive vehicles, 2 = right-hand drive vehicles L Code letter or code number of manufacturing plant

"K" up to 12.03/"L" as of 01.04 115548 Vehicle identification end number

934.04

934 Vehicle version (model designation code) 930/950 = Platform vehicle 932/952 = Dumper 933/953 = Concrete mixer 934/954 = Semitrailer tractor .04 Axle configuration 00 ... 06 4 x 2 07, 08 4 x 4

11 6 x 2 DNA (dual-tired trailing axle, Nummek)

20, 21 6 x 2

23 6 x 2/2 (Hendrickson leading axle, Great Britain only)

22 6 x 2/4 14, 16, 24 6 x 4 18, 41 6 x 6 30, 31, 42 8 x 4/4 32 8 x 6/4 33 8 x 8/4 8 x 8/4

8 Number of wheels or wheel pairs

x 8 Number of driven wheels or wheel pairs /4 Number of steered wheels

(14)

Description and roadside assistance

Instrument panel, Actros 1 (up to 12/1999)

Overview... Page 15 Vehicle Diagnostic System (FDS)/Vehicle Service System (FSS) ... Page 16 Note on display messages ... Page 17 STOP lamp ... Page 18 System abbreviations ... Page 19 Display messages ... Page 22 Electronic system malfunction displays ... Page 26 Indicator lamps ... Page 27

Instrument panel Actros 1 (as of 01/2000)

Overview... Page 28 Reservoir pressure gauge for brake circuits 1 and 2 ... Page 29 Gear indicator ... Page 30 Fuel level indicator... Page 30 Driver Information System ... Page 31 Note on display messages ... Page 35 STOP lamp ... Page 39 System abbreviations ... Page 40 Display messages ... Page 43 Indicator lamps ... Page 49

Instrument panel, Actros 2/3 (as of 01/2003)

Overview: Actros 2 ... Page 50 Overview: Actros 3 ... Page 51 Reservoir pressure gauge for brake circuit 1 or 2... Page 52 Gear indicator ... Page 53 Fuel/AdBlue® level gauge ... Page 55 Onboard computer... Page 56 Note on display messages ... Page 62 STOP lamp ... Page 64

(15)

Description and roadside assistance

Oil level in engine

Calling up the engine oil level on the display: Actros 1 (up to 12/1999)... Page 89 Calling up the engine oil level on the display: Actros 1 (as of 01/2000) ... Page 90 Calling up the engine oil level on the display: Actros 2/3 (as of 01/2003) ... Page 91

Fuel system

Overview of fuel system... Page 92 Fuel tank... Page 93 Hand pump location ... Page 95 Bleeding the fuel system... Page 96

Electrical system

Overview of electrical system ... Page 98 EMERGENCY OFF switch ... Page 99 Jump starting ... Page 102 Batteries ... Page 105

Gearshift

Overview of gearshift ... Page 109 Manual gearshift system... Page 110 Telligent® gearshift system ... Page 111 Telligent® automatic gearshift system and Mercedes PowerShift ... Page 113 Teach-in process... Page 116 Teach-in errors... Page 119 Emergency shift of manual transmission (HPS) ... Page 120 Emergency shift of Telligent® gearshift system and Telligent®

automatic gearshift system (Actros 1) ... Page 123 Emergency shift of Telligent® gearshift system, Telligent®

automatic gearshift system and Mercedes PowerShift (Actros 2/3) ... Page 128

Compressed air production

Versions... Page 134 Pressure regulating system ... Page 135 Constant pressure system with separate four-circuit protection valve ... Page 135 Constant pressure system with Electronic Air-Processing Unit (EAPU)... Page 136 Pressure table... Page 137

(16)

Description and roadside assistance

Brake system

General ... Page 138 Frequent-stop brake ... Page 139 Safety valve ... Page 140 Active Brake Assist ... Page 140 Location of components ... Page 143 Filling the brake system from an external source ... Page 144 Releasing the spring-loaded parking brake ... Page 148

Telligent®_{level control system}

Diagram of Telligent® level control system... Page 152 General ... Page 153 Operating unit... Page 153 Raising/lowering the chassis... Page 154 Filling the air suspension system from an external source ... Page 156

Tilting the cab

Before tilting ... Page 157 Mechanical/hydraulic... Page 158 Electrohydraulic ... Page 159

Engine

(17)

Description and roadside assistance

Overview

Instrument panel, Actros 1 (as of 01/2000), see page 28.

1 2 3 15 14 13 5 6 8 10 7 9 11 12 4

: STOP lamp, see page 27 G Control buttons for Vehicle Diagnostic System

(FDS)/Vehicle Service System (FSS), see page 16

; The left-hand field of the display see page 16 shows warning indicators see page 17 and malfunction displays concerning the electronic systems see page 26.

H Chassis display • Starting-off aid • Differential lock(s) • Trailing axle • Power take-off(s). = The right-hand field of the display see page 16

shows operating information.

? Indicator lamps, see page 27 I Gear indicator display

Vehicles with Telligent® gearshift system, see page 111, or Telligent® automatic gearshift system, see page 113.

A Level control display B Coolant temperature gauge C Fuel level gauge

D Engine oil pressure gauge

E Reservoir pressure, brake circuit 1 J Auxiliary heater timer

(18)

Description and roadside assistance

Vehicle Diagnostic System (FDS)/Vehicle Service System (FSS)

Do not press the control buttons : until the function test is complete.

The control buttons : are used e.g. to call up stored data and malfunctions from the diagnostic system.

"SYSTEM" button

The "SYSTEM" button can be used to call up operational, service and diagnostic information. This is displayed in the right-hand field of the display.

With the outside temperature displayed: M Press "SYSTEM" button once.

Operating information is displayed. M Press "SYSTEM" button twice.

Service information is displayed. M Press "SYSTEM" button three times.

Diagnostic information is displayed (1st electronic system). If you continue to press the "SYSTEM" button, diagnostic information on further electronic systems is displayed.

"INFO" button

Additional information in the selected electronic system is displayed.

"QUIT" button

The diagnostic information disappears and the outside temperature is displayed.

Selecting language

The vehicle is delivered with Service mode set to the language of the recipient country. M Press "SYSTEM" button twice (Service mode).

M Press the "INFO" button repeatedly until the language setting is shown in the display. FDS Vehicle Diagnostic System

FSS Flexible Service System (Telligent®

(19)

Description and roadside assistance

Note on display messages

Left display field

:

yellow/red

Automatic displays

The left-hand display field automatically shows warning indicators and malfunction displays concerning the electronic systems.

Each malfunction in an electronic system is indicated by a fault code, stored and assigned to a malfunction class, see page 26.

Right display field

;

green/yellow

Automatic displays

• Outside temperature • Operating information

(e.g. fluid level in windshield washer system) • Service information

Calling up displays (see page 16)

• Check information (e.g. engine oil pressure) • Service points/service dates

• Stored service data • Diagnostic information

Display examples

Display messages, see page 22.

Display messages with code, see page 26. 0 4147: Fault code

Electronic system failure, see page 19. MR: Engine control

(20)

Description and roadside assistance

STOP lamp

M Turn vehicle key in ignition lock to drive position. The STOP lamp : goes out after max.

10 seconds or when the engine is started.

The STOP lamp : lights up:

The STOP lamp : lights up and the warning "Brake system reservoir pressure" is displayed:

1 Risk of accident

$

If the STOP lamp does not go out or if it lights up while driving, the operational safety of the vehicle is at risk. • Stop the vehicle as soon as possible taking into account the traffic situation

• Switch off the engine and apply the parking brake

• Have the system checked and repaired as quickly as possible at a qualified specialist workshop possessing the required expertise and tools in order to perform the necessary work.

Mercedes-Benz recommends a Mercedes-Benz service center for this work. It is absolutely essential that all safety-relevant work and all work on safety-relevant systems is performed by a qualified specialist workshop.

Cause Action Page

Engine oil level too low. Check engine oil level. 89

Engine oil pressure too low. Check engine oil level. Check engine oil pressure.

Oil level OK: Tow the vehicle away.

89 89 169

Cause Action Page

Reservoir pressure of brake circuit 1 or 2 below 6.8 bar.

(21)

Description and roadside assistance

System abbreviations

If an electronic system fails, only the abbreviation : of the defective electronic system is displayed.

1 Risk of accident

$

Drive with special care!

If an electronic system fails, this is displayed by the abbreviations below. The handling and braking behavior of the vehicle may change!

Have the affected system checked and repaired as quickly as possible at a qualified specialist workshop possessing the required expertise and tools in order to perform the necessary work.

Abbreviation Description Action

ABS Antilock brake system:

The wheels may lock up when braking. The lateral stability of the vehicle may change.

M Drive with special care or tow the vehicle away,

see page 153. AG (AGE) Automatic gear selection

(Vehicles with Telligent® automatic gearshift system)

M Fold out the clutch pedal and shift gears manually, see page 123. M Drive with special care.

AHE Trailer recognition module:

The braking behavior of the vehicle may change.

M Drive with special care. BS (EPB) Brake control:

The braking behavior of the vehicle has changed significantly. The ABS is deactivated. The wheels may lock up when braking. The lateral stability of the vehicle may change. The brake pedal travel is longer and the brake pedal forces are higher.

M Drive with special care.

EAB Electronic trailer/semitrailer brake:

The braking behavior of the vehicle may change. The wheels may lock up when braking. The lateral stability of the vehicle may change. The brake pedal travel is longer.

EDW Anti-theft alarm system M Have the system repaired.

(22)

ve-Description and roadside assistance

FLA Flame starting system (cold-starting aid):

At temperatures below –4 °C the starting charac-teristics change.

M Have the system repaired.

FR (FMR) Drive control Activate engine limp-home mode:

M Apply parking brake and switch off engine.

M After 10 seconds, start engine. In limp-home mode the engine speed is limited to 1250 rpm.

If the engine speed is not sufficient to start off or drive, tow the vehicle away, see page 169.

GS (EPS) Transmission control M If a gearchange is no longer

possi-ble, perform an emergency shift, see page 126.

HZR Heater control M Have the system repaired.

INS Instrument cluster:

Important information (warnings, malfunctions) can no longer be displayed.

M Tow the vehicle away if necessary, see page 169.

KB Clutch operating system

M Fold out the clutch pedal and shift gears manually, see page 123.

KOM Communications interface M Have the system repaired.

KS Clutch control

KSA Comfort locking system M Have the system repaired.

MR (PLD) Engine control:

The accelerator pedal is inoperative and the engine speed is constantly below 1300 rpm.

Activate engine limp-home mode: M Apply parking brake and switch off

engine.

(23)

Description and roadside assistance

NR Level control:

The handling of the vehicle may change (e.g. chassis leans to one side, center of gravity changed).

PSM Parameterizable special module:

The power take-off is inoperative.

M Have the system repaired.

RS (RET) Retarder control M Drive with special care.

SIL Seat electronics, left M Have the system repaired.

SIR Seat electronics, right M Have the system repaired.

SRS Supplemental restraint system M Have the system repaired.

WS Maintenance system M Have the system repaired.

WSK Torque converter clutch:

The handling of the vehicle may change.

M Tow the vehicle away, see page 169.

ZHE Auxiliary heater M Have the system repaired.

(24)

Description and roadside assistance

Display messages

Display messages on a yellow background

Display message Possible cause/

consequence

Possible remedy

Risk of accident

$

The poly-V belt has snapped or the three-phase alternator is defective.

The voltage in the on-board electrical system has dropped below 22 V. The handling and braking behavior of the vehicle may change.

M Stop the vehicle as soon as possible taking into account the traffic situation.

M Switch off engine and apply parking brake. M Check poly-V belt.

M If the poly-V belt is OK, have the electrical sys-tem checked at a qualified workshop.

M If the poly-V belt has snapped, notify a quali-fied workshop and have the poly-V belt re-placed.

Risk of accident

$

The alternator is defective. The handling and braking behavior of the vehicle may change.

M Switch off engine and apply parking brake. M Have the electrical system checked at a

quali-fied workshop. A bulb or fuse in vehicle light

system or brake lamp has failed.

M Check and replace the appropriate bulb. M Check and replace the appropriate fuse.

Risk of accident

$

The reservoir pressure in the ancillary consumer circuit has dropped below 5.5 bar. The gears can no longer be shifted correctly.

M Top up the compressed air system, fill from an external source, see page 144, or tow the ve-hicle away, see page 169.

Risk of accident

$

Fault in the brake system of the tractor vehicle or trailer/ semitrailer.

The handling and braking behavior of the vehicle may change.

M Drive with special care or tow the vehicle away, see page 169.

(25)

Description and roadside assistance

Display messages on a red background

consequence

Possible remedy

Risk of accident

$

M Switch off engine and apply parking brake. M Check poly-V belt.

M If the poly-V belt is OK, have the electrical sys-tem checked at a qualified workshop.

M If the poly-V belt has snapped, notify a quali-fied workshop and have the poly-V belt re-placed.

The engine oil level has dropped about 2 l below the minimum fill level.

The warning buzzer sounds. The STOP lamp lights up.

M Switch off engine and apply parking brake. M Check engine oil level, see page 89, and top up

if necessary.

The engine oil level has dropped below the minimum fill level.

The warning buzzer sounds. The STOP lamp lights up.

M Switch off engine and apply parking brake. M Check engine for leaks.

M Contact a qualified specialist workshop if there is visible oil leakage.

M Make sure that escaping oil does not contam-inate the environment.

M Immediately add the oil quantity shown in the right-hand display field.

Risk of accident

$

The oil level in the reservoir of the power steering system has dropped to the minimum fill level.

If more oil is lost, there is a risk of accident because the vehicle will be difficult to steer.

M Top up steering oil and drive with special care. M Adjust your driving style. Reduce speed before

corners in particular.

M Have the steering system checked at a quali-fied workshop.

(26)

Description and roadside assistance

Four-axle vehicles: Steering circuit 2 has failed. The vehicle can only be steered with increased effort.

M Adjust your driving style. Reduce speed before corners in particular.

M Have the steering system checked at a quali-fied workshop.

The coolant level has dropped about 4 l below the normal fill level.

The warning buzzer sounds.

M Switch off engine and apply parking brake. M Top up coolant.

M Have the cooling system checked for leaks at a qualified workshop.

Risk of accident

$

The reservoir pressure • in brake circuit 1 or 2 has

dropped below 6.8 bar • in the spring-loaded brake

and trailer brake circuit is too low

or

• Compressed air consumption too high while maneuvering • Compressed air system

leaking.

The operational safety of the vehicle is at risk.

M Top up the compressed air system, fill from an external source, see page 144, or tow the ve-hicle away, see page 169.

Risk of accident

$

The service limit of the brake linings has been reached. The braking behavior of the vehicle may change signifi-cantly.

M Have the brake linings replaced at a qualified workshop as quickly as possible.

Risk of accident

$

Brake pressure limiting.

M Have the brake system checked at a qualified Display messages on a red background

consequence

(27)

Description and roadside assistance

The retarder cannot be

deactivated during ABS control.

Risk of accident

$

Malfunction in brake system of trailer/semitrailer.

The handling or braking properties of the vehicle may change.

M Have the brake system checked at a qualified workshop.

Clutch overloaded: The permissible operating temperature of the clutch system has been exceeded. If the moving-off or

maneuvering process is not ended within 5 seconds when the warning buzzer sounds, the clutch is closed. This can stall the engine. Observe the traffic situation.

M Leave the clutch to cool and select a lower moving-off gear if necessary.

Display failure (vehicles with Telligent® automatic gearshift system). Important operating information and warnings can no longer be displayed. The handling and braking behavior of the vehicle may change.

M Fold out the clutch pedal and shift gears man-ually, see page 123.

M Drive with special care. or

Risk of accident

$

Display failure. Important operating information and warnings can no longer be displayed.

M Tow the vehicle away, see page 169. Display messages on a red background

consequence

(28)

Description and roadside assistance

Electronic system malfunction display

Explanation of malfunction display:

ABS = Abbreviation of the defective electronic system, see page 19.

The coding of fault paths and fault types is accessible to workshop staff. : Abbreviation ; Fault code 0 Malfunction class 41 Fault path 47 Fault type

Risk of accident

$

If the malfunction display is accompanied by a warning buzzer, this indicates that the problem poses a potential danger that can directly compromise the vehicle's operational safety.

Malfunction class

Action

0 Have the fault rectified at the next workshop service.

1

_{Risk of accident}

_$

In the case of class 1 malfunctions, it may be that the handling and braking properties of the vehicle have changed.

Have the malfunctions repaired as quickly as possible at a qualified specialist workshop possessing the required expertise and tools in order to perform the necessary work. Mercedes-Benz recommends a Mercedes-Benz service center for this work. It is absolutely essential that all safety-relevant work and all work on safety-relevant systems is performed by a qualified specialist workshop.

2

_{Risk of accident}

_$

In the case of class 2 malfunctions, the operational safety of the vehicle is at risk. The handling and braking properties of the vehicle have changed.

(29)

Description and roadside assistance

Indicator lamps

Indicator lamp Description

High beam

Cab lock

Cargo liftgate

Frequent-stop brake

Stationary air conditioner

Parking brake

Permanent brake (retarder)

Dumper body

Acceleration skid control "ASR"

Applicable for vehicle with Telligent® automatic gearshift system: Speed too high for automatic downshift – brake!

(30)

Description and roadside assistance

Overview

Instrument panel, Actros 1 (up to 12/1999), see page 15.

: Status indicator (yellow or red) B Reservoir pressure, brake circuit 2, see page 29

; Driver Information System (FIS) display • Operating information

• Warnings

• Display of malfunctions and failures of electronic systems

Driver Information System (FIS), see page 31.

C STOP lamp, see page 39 D Multifunction display (MFD)

• Gear indicator, see page 30 • Trip odometer

• Time.

= Indicator lamps, see page 49 E Fuel level gauge, see page 30

? Reservoir pressure, brake circuit 1, see page 29

F Coolant temperature gauge A Function buttons for Driver Information System

(FIS), see page 31

G Clock control buttons H Auxiliary heater timer

(31)

Description and roadside assistance

Reservoir pressure gauge for brake circuits 1 and 2

To ensure the operational safety of your vehicle a reservoir pressure of about 10 bar is required in the pressure circuits of the brake system.

The ancillary consumer circuit is filled only after brake circuits 1 and 2 have been filled.

: Reservoir pressure, brake circuit 1 ; Reservoir pressure, brake circuit 2

Risk of accident

$

Leaks in the compressed air brake system put the operational safety of the vehicle at risk. If the reservoir pressure in the compressed air brake system is too low, it is not possible to brake the vehicle or change gear. You could cause an accident with possible injury to yourself and others.

Do not set the vehicle in motion until the required reservoir pressures have been reached and the STOP lamp has gone out.

If the display shows J, do not start to move the vehicle or, if moving, stop it as quickly as possible taking into account the traffic situation. In addition, the status indicator lights up red and the STOP lamp does not go out.

Have the brake system checked and repaired as quickly as possible at a qualified specialist workshop possessing the required expertise and tools in order to perform the necessary work.

(32)

Description and roadside assistance

Gear indicator

Fuel level gauge

M Turn vehicle key in ignition lock to drive position. M Check level on fuel level gauge :

and top up if necessary.

M Switch off the engine and the auxiliary heater be-fore filling the reservoir.

Fuel reserve indicator

When the content of the fuel tank has dropped to about 14%, the display shows 7. At the same time the status indicator lights up yellow.

: Engaged gear 1–8 1st to 8th gear N Transmission neutral R Reverse gear ; Preselected gear 1–8 1st to 8th gear = Engaged splitter group

/ High-speed splitter group 0 Low-speed splitter group ? Preselected splitter group

/ High-speed splitter group 0 Low-speed splitter group

(33)

Description and roadside assistance

Driver Information System (FIS)

The Driver Information System (FIS) informs the driver e.g. about operating information, warnings and malfunctions, while driving.

Buttons

The Driver Information System (FIS) is operated using the buttons on the instrument panel. Do not press the buttons until the automatic function test is complete.

Automatic function test

M Turn vehicle key in ignition lock to drive position.

The warning buzzer sounds for about 2 seconds. At the same time all the indicator lamps light up briefly and the display shows the last menu item set.

Risk of accident

$

Operating the Driver Information System (FIS) while driving can distract your attention away from what is happening on the road. You could lose control of the vehicle and cause an accident.

For this reason, only operate the Driver Information System (FIS) when the vehicle is stationary with the parking brake applied.

: RESET button ; Function buttons

T Cancel the display and return to the next menu level up.

9 Scroll up in the active menu or select function/setting.

: Scroll down in the active menu or select function/setting.

S Select highlighted menu item or information.

(34)

Description and roadside assistance

Driver Information System (FIS) display

Operating information, warnings and malfunctions can be shown in the display :. At the same time the relevant segments of the status indicator ; light up yellow or red.

When a malfunction/warning display is confirmed with button T, the malfunction/warning display moves to the memory field =.

Malfunctions within various electronic systems can be displayed sequentially (with each display lasting about 5 seconds). If there are multiple malfunctions in an electronic system, only the event with the highest priority is displayed by the malfunction indicator.

The fields ? of the display : are assigned individual segments A in the status indicator = which light up red or yellow according to the information priority rating.

A warning buzzer may also sound in addition to the display message, see page 86.

: Display

; Memory field

= Status indicator (yellow or red)

? Display field (example) A Status indicator segment

Display Status indicator Confirm display with function

button T, see page 31 Malfunction class, see page 36

Operating information yellow Display disappears 0

Operating

information/warnings

yellow Display changes to the memory field 1

(35)

Description and roadside assistance

Menus

The menus each comprise a number of functions pertaining to the same subject. Certain menus can only be selected when the vehicle is stationary.

Menu overview

+

The number and sequence of the menus depend on the vehicle version and the vehicle equipment.

Diagnosis see page 40

Display of all diagnosable control units installed in the vehicle as well as current and stored events.

If there are no events, the display shows "Unavailable". Overview of system abbreviations

Fault Info Malfunctions in memory field.

Settings Language

ART signal transmitter (Telligent® distance control) Display differential locks

Display NR (level control)

Display separation (activate and deactivate display with dashes)

Service Info Display maintenance system for general maintenance jobs according to the vehicle load.

Check Info Axle load indicator

Engine oil pressure Power take-off

Other check information • Engine operating hours • Engine oil level

• Engine oil top-up quantity

Equipment Operating states of the differential locks and Telligent® level control.

(36)

Description and roadside assistance

Selecting language

When the vehicle is delivered, the language of the recipient country is set in the "Service Info" menu. Service information can be displayed in 20 languages.

Operating information and further details

(instructions) can only be displayed in German and English.

Displaying and changing the language setting

Displaying the language setting

With the vehicle stationary:

M Turn vehicle key in ignition lock to drive position. M Press one of the function buttons ;.

M Use 9 or : button to select the "Service Info" menu.

M Press S button.

M Press : button repeatedly until the language setting is shown in the display.

Changing the language setting

M With the language displayed, press and hold down the RESET button :.

M Press S button repeatedly until the desired language is shown in the display. M Release RESET button :.

The most recently displayed language is saved. Return to main display:

: RESET button

(37)

Description and roadside assistance

Note on display messages

Each malfunction in an electronic system (e.g. tachograph) is indicated by a display message, and is stored and assigned to a malfunction class.

Malfunctions within various electronic systems can be displayed sequentially (with each display message lasting about 5 seconds). If there are multiple malfunctions in an electronic system, only the display message with the highest priority is shown.

In the event of failure or malfunction of an electronic system, the display shows either the system abbreviation with a display message or the event code.

Display message with system abbreviation

: System abbreviation of electronic system, see page 40

TCO: Tachograph

; Function restrictions (cause of malfunction) Text message:

"Stop Vehicle – Load Tachograph Disk" = Location of malfunction:

6 Tractor vehicle 1 Trailer/semitrailer ? Further information is available.

M Press S button on instrument panel. A Status indicator (yellow or red)

(38)

Description and roadside assistance

Display with event code (example)

Malfunctions within various electronic systems can be displayed sequentially (with each display message lasting about 5 seconds). If there are multiple malfunctions in an electronic system, only the display message with the highest priority is shown.

: System abbreviation of electronic system, see page 40

"BS": Brake control ; Status indicator (red)

= 2 80 00 Event code

2 Malfunction class

The malfunction class is either "0", "1" or "2", see page 36.

80 Fault path

00 Fault type

? Further information is available.

M Press S button on instrument panel.

Risk of accident

$

If a display message appears and the warning buzzer sounds at the same time, the operational safety of the vehicle is at risk.

Have the malfunctions repaired immediately at a qualified specialist workshop possessing the required expertise and tools in order to perform the necessary work.

(39)

Description and roadside assistance

Malfunction class 0

Have class "0" malfunctions repaired at a qualified specialist workshop during the next service.

The malfunction display reappears after the engine is restarted. In the memory field, see page 32, display messages for various electronic systems can be shown sequentially (with each display lasting about 5 seconds).

If there are multiple malfunctions in an electronic system, only the display message with the highest priority is shown.

: Status indicator yellow ; Malfunction class "0"

: Status indicator yellow ; Malfunction class "1"

Risk of accident

$

In the case of class "1" malfunctions, it may be that the handling and braking properties of the vehicle have changed.

Adjust your driving style accordingly and drive with special care.

Follow the instructions and observe the additional information in the Driver Information System (FIS). Have the cause checked and repaired as quickly as possible at a qualified specialist workshop possessing the required expertise and tools in order to perform the necessary work.

(40)

Description and roadside assistance

The malfunction display reappears after the engine is restarted. In the memory field, see page 32, display messages for various electronic systems can be shown sequentially (with each display lasting about 5 seconds).

If there are multiple malfunctions in an electronic system, only the display message with the highest priority is shown.

: Status indicator red ; Malfunction class "2"

Risk of accident

$

In the case of class "2" malfunctions, the operational safety of the vehicle is at risk. The handling and braking properties of the vehicle may change.

If it is possible to drive on:

Adjust your driving style accordingly and drive with special care.

Continuing to drive may result in damage to the vehicle and is against the law. If it is not possible to drive on:

• Stop the vehicle immediately in a safe place taking into account the traffic situation

• Follow the instructions and observe the additional information in the Driver Information System (FIS) • Have the affected system checked and repaired immediately at a qualified specialist workshop possessing

the required expertise and tools in order to perform the necessary work.

(41)

Description and roadside assistance

STOP lamp

1 Risk of accident

$

If the STOP lamp does not go out or if it lights up while driving, the operational safety of the vehicle is at risk.

• Stop the vehicle as soon as possible taking into account the traffic situation.

• Apply the parking brake and switch off the engine.

• Have the affected system checked and repaired as quickly as possible at a qualified specialist workshop possessing the required expertise and tools in order to perform the necessary work

(42)

Description and roadside assistance

System abbreviations

Risk of accident

$

If an electronic system fails, this is displayed by the abbreviations below. The handling and braking behavior of the vehicle may change!

Have the affected system checked and repaired as quickly as possible at a qualified specialist workshop possessing the required expertise and tools in order to perform the necessary work.

Abbreviation Description Action

ABS Antilock brake system:

The wheels may lock up when braking. The lateral stability of the vehicle may change.

AG Automatic gear selection M Fold out the clutch pedal and shift

gears manually, see page 123. M Drive with special care. ART Autonomous intelligent cruise control:

Inoperative

BS Brake control:

The braking behavior of the vehicle has changed significantly. ABS is deactivated.

The wheels may lock up when braking. The lateral stability of the vehicle may change. Brake pedal travel longer, brake pedal forces increased.

EAB Electronic trailer/semitrailer brake:

The braking behavior of the vehicle may change. The wheels may lock up when braking. The lateral stability of the vehicle may change. Brake pedal travel longer.

EDW Anti-theft alarm system M Have the system repaired.

FFB Radio remote control M Lock/unlock the doors with the

(43)

Description and roadside assistance

FR Drive control Activate engine limp-home mode:

M Apply parking brake and switch off engine.

M If the engine speed is not sufficient to start off or drive, tow the vehicle away, see page 169.

GS Transmission control M If a gearchange is no longer

possi-ble, perform an emergency shift, see page 126.

HPS Manual gearshift system (HPS) M Perform emergency shift,

see page 120.

HZR Heater control M Have the system repaired.

INS Instrument cluster:

Important information (warnings, malfunctions) can no longer be displayed.

KOM Communications interface M Have the system repaired.

KS Clutch control

Vehicles with Telligent® automatic gearshift system

KSA Comfort locking system M Have the system repaired.

MR Engine control:

Accelerator pedal inoperative and constant engine speed below 1300 rpm.

Activate engine limp-home mode: M Apply parking brake and switch off

engine.

M If the engine speed is not sufficient to start off or drive, tow the vehicle away, see page 169.

NR Level control:

The handling of the vehicle may change (e.g. chassis leans to one side, center of gravity changed).

PSM Parameterizable special module: M Have the system repaired.

(44)

Description and roadside assistance

SIL Seat electronics, left M Have the system repaired.

SIR Seat electronics, right M Have the system repaired.

SPA Lane Assistant M Have the system repaired.

SRS Supplemental restraint system M Have the system repaired.

TCO Tachograph M Have the system repaired.

WS Maintenance system M Have the system repaired.

WSK Torque converter clutch:

The handling of the vehicle may change.

ZHE Auxiliary heater M Have the system repaired.

ZV Central locking M Lock/unlock the doors with the

vehicle key.

(45)

Description and roadside assistance

Display messages

Display message with yellow status indicator

Display message Possible cause/consequence Possible remedy

Risk of accident

$

M Switch off engine and apply parking brake.

M Check poly-V belt.

M If the poly-V belt is OK, have the electrical system checked at a qualified workshop. M If the poly-V belt has snapped,

notify a qualified workshop and have the poly-V belt re-placed.

Risk of accident

$

The alternator is defective.

M Have the electrical system checked at a qualified work-shop.

• No monitoring of the trailer/ semitrailer.

• When switching on the lights: Bulb or fuse for standing lamps, low beam lamps, taillamps, license plate illumi-nation or rear fog lamp is defective. • When braking: Brake lamp is

defective.

• When signaling: Turn signal lamp is defective.

• After the instrument panel function check: Fuse for brake lamps is defective.

M Check and replace the appro-priate fuse.

M Check and replace the appro-priate bulb.

The oil level of the automatic engine oil refill system has dropped to about 3.5 l.

(46)

Description and roadside assistance

Engine oil level has dropped to minimum fill level.

M Top up.

Coolant level has dropped about 2 l below the normal fill level.

M Top up.

Coolant temperature is too high. The engine output is automatically reduced.

M Demand less power from the engine.

M Make sure that the air supply to the radiator is not obstruct-ed.

Fuel level has dropped to about 14% of maximum fill level.

M Refuel.

The fluid level in the reservoir of the windshield washer/headlamp cleaning system has dropped to about 1 l.

M Top up.

Risk of accident

$

The reservoir pressure for ancillary consumers has dropped below 5.5 bar. The clutch can no longer be fully

disengaged and reliable gearchanges are no longer possible.

M Top up the compressed air sys-tem, fill from an external source, see page 144, or tow the vehicle away,

see page 169.

Risk of accident

$

Fault in brake system of tractor unit or trailer/semitrailer.

M Drive with special care or tow the vehicle away,

see page 169. Display message with yellow status indicator

(47)

Description and roadside assistance

Risk of accident

$

Fault in Telligent® automatic gearshift system. The warning buzzer sounds.

M Fold out the clutch pedal and shift gears manually,

see page 123.

M Drive with special care. You cannot start the engine.

Immobilizer is activated.

M Wait until the warning buzzer stops.

M Turn the vehicle key in the igni-tion lock all the way back. M Repeat the start attempt after

about 2 seconds. Display message with yellow status indicator

Display message with red status indicator

Risk of accident

$

M Check poly-V belt.

M If the poly-V belt is OK, have the electrical system checked at a qualified workshop. M If the poly-V belt has snapped,

notify a qualified workshop and have the poly-V belt re-placed.

The engine oil pressure is too low. The warning buzzer sounds. The STOP lamp lights up.

The operational safety of the engine is at risk.

M Check engine oil level, see page 90, and top up.

(48)

Description and roadside assistance

Engine oil level has dropped about 2 l below minimum fill level. The warning buzzer sounds.

The STOP lamp lights up.

M Check engine oil level, see page 90, and top up.

Risk of accident

$

The oil level in the reservoir of the power steering system has dropped to the minimum fill level.

If more oil is lost, there is a risk of accident because the vehicle will be difficult to steer.

The STOP lamp lights up.

M Top up steering oil and drive with special care.

Four-axle vehicles: Steering circuit 2 has failed.

The vehicle can only be steered with increased effort.

M Adjust your driving style. Re-duce speed before corners in particular.

M Have the steering system checked at a qualified work-shop.

Coolant level has dropped about 4 l below the normal fill level. The warning buzzer sounds.

M Top up coolant.

M Have the cooling system checked for leaks at a qualified workshop.

Risk of accident

$

Reservoir pressure

• in brake circuit 1 or 2 has dropped below 6.8 bar

• in the spring-loaded brake and trailer brake circuit is too low

or

M Top up the compressed air sys-tem or fill from an external source, see page 144. or

(49)

Description and roadside assistance

Risk of accident

$

The service limit of the brake linings has been reached.

The braking behavior of the vehicle may change significantly.

M Drive with special care. M Have the brake linings

re-placed at a qualified workshop as quickly as possible.

Risk of accident

$

Malfunction in brake system of trailer/ semitrailer.

The handling or braking properties of the vehicle may change.

M Drive with special care. M Have the brake system

checked at a qualified work-shop.

Risk of accident

$

Brake pressure limiting.

The applied brake pressures no longer correspond to the load state.

The braking behavior of the vehicle is changed.

M Drive with special care. M Have the brake system

checked at a qualified work-shop.

The retarder cannot be deactivated during ABS control or when depressing the accelerator pedal.

Vehicles with Telligent® automatic gearshift system:

Clutch overloaded: The permissible operating temperature of the clutch system has been exceeded. If the moving-off or maneuvering process is not ended within 5 seconds when the warning buzzer sounds, the clutch may overheat.

M Leave the clutch to cool and select a lower moving-off gear if necessary.

(50)

Description and roadside assistance

Risk of accident

$

Display failure. Important operating information and warnings can no longer be displayed.

M Drive with special care. M Tow the vehicle away, see

page 169.

The service date has been significantly exceeded.

M Perform service.

M Have the service work per-formed at a qualified work-shop.

(51)

Description and roadside assistance

Indicator lamps

Indicator lamp Description

Dumper body

Acceleration skid control "ASR" and Telligent® stability control "SR"

Applicable for vehicle with Telligent® automatic gearshift system: Speed too high for automatic downshift – brake!

Torque converter clutch

Flame starting system (cold-starting aid)

Cargo liftgate

Frequent-stop brake

Stationary air conditioner

Parking brake applied.

Permanent brake

Steering lock of hydraulically steered trailing axle.

Cab lock

(52)

Description and roadside assistance

Overview: Actros 2

Instrument panel, Actros 1 (up to 12/1999), see page 15. Instrument panel, Actros 1 (as of 01/2000), see page 28. Instrument panel, Actros 3 (as of 06/2008), see page 51.

: Speedometer with display for trip mileage and total mileage

B Reservoir pressure gauge for brake circuit 1 or 2, see page 52

C Brake circuit 2 indicator lamp, see page 52 ; Indicator lamps, see page 84 D Brake circuit 1 indicator lamp, see page 52

= STOP lamp, see page 64 E Button for instrument illumination brighter

? Display, see page 57 F Button for instrument illumination darker

A Tachometer with • Ecometer • Clock

• Outside temperature indicator.

G RESET button

H Button for confirming display messages I Button for resetting trip mileage to "0" J Fuel level gauge, see page 55

(53)

Description and roadside assistance

Overview: Actros 3

Instrument panel, Actros 1 (up to 12/1999), see page 15. Instrument panel, Actros 1 (as of 01/2000), see page 28. Instrument panel, Actros 2 (as of 06/2008), see page 50.

: Speedometer with display for trip mileage and total mileage

B Reservoir pressure gauge for brake circuit 1 or 2, see page 52

C Brake circuit 2 indicator lamp, see page 52 ; Indicator lamps, see page 84 D Brake circuit 1 indicator lamp, see page 52

= STOP lamp, see page 64 E Button for instrument illumination brighter

? Display, see page 57 F Button for instrument illumination darker

A Tachometer with • Ecometer • Clock

• Outside temperature indicator.

G RESET button

H Button for confirming display messages I Button for resetting trip mileage to "0" J Fuel level gauge, see page 55

(54)

Description and roadside assistance

Reservoir pressure gauge for brake circuits 1 and 2

To ensure the operational safety of your vehicle a reservoir pressure of about 10 bar is required in the pressure circuits of the brake system, or 11 bar in vehicles with Electronic Air-Processing Unit (EAPU), see page 136.

The ancillary consumer circuit is filled only after brake circuits 1 and 2 have been filled.

M Turn vehicle key in ignition lock to drive position.

The brake circuit with the lowest reservoir pressure is displayed automatically by the appropriate indicator lamp : or ;. The gauge = shows the reservoir pressure in this brake circuit.

Reservoir pressure (example on Actros 2) : Brake circuit 1 indicator lamp

; Brake circuit 2 indicator lamp

= Reservoir pressure gauge for brake circuit 1 or 2

+

You can check the reservoir pressure of both brake circuits in the Check Info menu under Reservoir pressure.

Risk of accident

$

Leaks in the compressed air brake system put the operational safety of the vehicle at risk. If the reservoir pressure in the compressed air brake system is too low, it is not possible to brake the vehicle or change gear. You could cause an accident with possible injury to yourself and others.

Do not set the vehicle in motion until the required reservoir pressures have been reached and the STOP lamp has gone out.

If the display shows J, do not start to move the vehicle or, if moving, stop it as quickly as possible taking into account the traffic situation. In addition, the status indicator lights up red and the STOP lamp does not go out.

Have the brake system checked and repaired as quickly as possible at a qualified specialist workshop possessing the required expertise and tools in order to perform the necessary work.

(55)

Description and roadside assistance

Gear indicator

Telligent® automatic gearshift system and Mercedes PowerShift (16-speed transmission)

The display shows the following information:

• The engaged gear and the engaged splitter group : • The transmission mode ;

• The active operating mode =.

Mercedes PowerShift (12-speed transmission)

Depending on the transmission version, the display shows the following information: • The engaged gear :

• The transmission mode ; • The active operating mode =.

Gear indicator in display

: / High-speed splitter group

0 Low-speed splitter group

1–8 1st to 8th gear

N Transmission neutral

R1, R2 Reverse gears 1 and 2 (Mercedes PowerShift)

R Reverse gear (Telligent® automatic gearshift system)

; E EcoRoll mode

P Power mode

= A Automatic mode

M Manual mode

Gear indicator in display : 1–12 1st to 12th gear

N/E

/

Transmission neutral, high-speed splitter group

N/E

0

Transmission neutral, low-speed splitter group

R1–R4 1st to 4th reverse gear

; E EcoRoll mode

P Power mode

= A Automatic mode

(56)

Description and roadside assistance

Telligent® gearshift system (16-speed transmission)

The display shows information on the engaged gear and the engaged splitter group : as well as on the recommended or preselected gear with the

corresponding splitter group ;.

Gear indicator in display / High-speed splitter group

0 Low-speed splitter group

1–8 1st to 8th gear

N Transmission neutral

(57)

Description and roadside assistance

Fuel/AdBlue

®

_{level gauge}

M Turn vehicle key in ignition lock to drive position. M Check level on fuel/AdBlue®_{level gauge and top}

up if necessary.

M Switch off the engine and the auxiliary heater be-fore filling the reservoir.

Fuel reserve indicator

When the content of the fuel tank has dropped to about 14%, the display shows 7. At the same time the status indicator lights up yellow.

AdBlue® level gauge

The AdBlue® level gauge : only shows the approximate AdBlue®_{level. The AdBlue}®_{level is}

indicated by 4 blue segments.

Fuel/AdBlue®_{level gauge}

(example on Actros 2) : AdBlue® level gauge

; Fuel level gauge

+

The fuel supply and range can be called up in the Trip computer menu.

1 segment AdBlue® level between reserve and tank 1/4 full

2 segments AdBlue® level between tank 1/4 and 1/2 full 3 segments AdBlue® level between

tank 1/2 and 3/4 full 4 segments AdBlue® level between

tank 3/4 full and tank full + The current AdBlue®_{level, in liters, is only}

displayed in the onboard computer menu under

Actros Info/Check Info, see page 60.

+

The current AdBlue® level, in liters, is only displayed in the Check Info menu.

!

If the AdBlue® reservoir is empty or there is a malfunction in the BlueTec® exhaust

aftertreatment system, the indicator lamp ; lights up. In this case the vehicle must be refueled with AdBlue® or the fault must be rectified immediately.

(58)

Description and roadside assistance

Onboard computer

The onboard computer informs the driver e.g. about fuel consumption, journey time, events, operating states, service dates, malfunctions, fault causes and remedial action, while driving.

The onboard computer is operated using the buttons on the multifunction steering wheel and the buttons on the instrument panel.

Operation

Onboard computer (example on Actros 3)

Risk of accident

$

Operating the onboard computer while driving can distract your attention away from what is happening on the road. You could lose control of the vehicle and cause an accident.

For this reason, only operate the onboard computer when the vehicle is stationary with the parking brake applied.

: Display B Telephone:

: Accept call/redial

9 End call or direct access to telephone menu

; Á Reset button:

Reset trip data Reset trip counter

= T Confirm display messages C VU

Scroll up/down in main menu Confirm display message Return to main menu

The most recently selected settings are saved automatically.

? ? RESET button:

Confirm service work performed.

Change operating fluid data in menu Settings/ submenu Operating fluids.

A WX

Adjust volume on audio device (radio and telephone).

D Scroll in submenu (select function): & Forward

(59)

Description and roadside assistance

Display fields

The fields of the display change automatically depending on the display type and priority rating (e.g. operation indicators, display messages, menus).

Display fields may also be linked together.

If certain settings can be made in a menu, this is indicated in the display by the symbol º. Settings are made using the buttons W and X on the multifunction steering wheel.

Status indicator

Individual segments of the status indicator light up white, yellow or red to distinguish display messages according to their priority rating. Display messages with yellow or red status indicator, (see page 66).

: Basic display with speedometer and text information (display messages, instructions etc.)

; Symbols or system abbreviations, e.g. for the ABS function check, display messages, service indicators, malfunctions and status indicator (white, yellow and red)

= Menu display or status indicator (white, yellow or red)

? Operation indicator for level control (vehicles with air suspension) A Gear indicator (transmissions with

Telligent® gearshift system, Telligent® automatic gearshift system or Mercedes PowerShift)

B Reminder field (stored malfunctions or received SMS messages)

C Operation indicator for differential locks D Operation indicator for cruise control, speed

limiter, Telligent® distance control, Active Brake Assist
