Measuring Systems. Page 31 Page 32. PD 5 Laser Range Meter PD 42 Laser Range Meter. PMC 46 Combilaser PM 4-M Multi-line laser PM 2-L Line laser

(1)

(2)

2

PD 5 Laser Range Meter

PD 42 Laser Range Meter

(3)

(4)

2

Technical Data

PD 5 Measuring distance 0.2 m – 70 m Accuracy ± 1.5 mm IP protection class IP 55 Functions Single & continuous

measurement Units m, mm, inch, ft, yd (various)

Laser class 635 nm, Class 2

Operation time with Alkaline battery

8,000 measurements Operating temperature range -10 °C to +50 °C Battery type 2 x AAA, Alkaline Dimension (LxWxH) 164 x 33x 21 mm Weight with batteries 100 g

Order Description Package content Item Number

Laser range meter PD 5 PD 5 laser range meter, PDA 605 toolbag, PDA 615 belt clip, 2 AAA batteries, operating instructions

(5)

Order Description Package content Item Number Laser range meter PD 42 kit In cardboard box, with PDA 65 soft pouch, hand strap, PDA 51 target plate,

PDA 71 Measuring extension, 2AA batteries and operating instructions 401052

Technical Data

PD 42 Max. measuring distance with

target plate 200 m

Accuracy ± 1 mm

Protection class

(dust and water spray) IP 54 Functions Painter area, Area, +, -,

3xPythagoras, Memory, Min./Max., Setting out, Timer

Display Liquid crystal

Spirit level Horizontal and vertical Units m, cm, mm, ft, yd, inch (various) Reference points Front, rear, tripod, spike

Optical sight Built-in

Laser class 635 nm, Class 2 (IEC 825-1) Operation time with Alkaline

battery 10,000 measurements

(6)

2

Technical Data

PMC 46 Measuring distance Line: 10 m, Point: 30 m Accuracy (at 10 m) Line: ± 1.5 mm/Point: ± 3 mm

IP protection class

(except battery compartment) IP 54

Self-leveling range ± 5°

Operating time with alkaline

battery 20 hrs

Auto shut down After 15 minutes Dimensions (L x W x H) 107 x 65 x 96 mm Weight with batteries 413 g

Combilaser PMC 46 Complete with soft pouch, PMA 78 universal adapter, PMA 20 compact tripod, 4 batteries, manufacturer’s certificate, operating instructions. Supplied in a Hilti toolbox.

(7)

Order Description Package content Item Number Multi line laser PM 4-M Equipped with multi line laser PM 4-M, tripod adapter PMW 30, 4 batteries

(Type AA), in Hilti case

2047073

Multi-line laser

PM 4-M

The lines you need. Your fast and accurate squaring and aligning companion from Hilti.

สำ�หรับว�งแนวโครงคร่�วเพื่อติดตั้งผนังเบ�

สำ�หรับง�นย้�ยแนว หรือตรวจสอบอ้�งอิงแนวสูง

ห�แนวระดับสำ�หรับง�นฝ้� ง�นไฟฟ้� ร�งส�ยไฟ และก�รติดตั้ง

ท่อต่�งๆ

ห�แนวระดับ และแนวดิ่งสำ�หรับง�นประตู และหน้�ต่�ง

ห�แนวดิ่งสำ�หรับง�นติดตั้งท่อชนิดต่�งๆ

ไม่ต้องใช้ไม้ระดับ ลูกดิ่ง ไม้ฉ�ก และแนวชอล์ก ด้วยเครื่องเดียวก็

ส�ม�รถทำ�ได้ทุกหน้�ที่

เลเซอร์แนวดิ่งแผ่ออกในรูปแบบ 3D โดยมีเส้นเลเซอร์สองเส้นตัด

กันบนเพด�น

มีปุ่มปรับละเอียด เพื่อปรับห�แนวดิ่ง และแนวระดับที่ต้องก�ร

ปรับเพียงเล็กน้อย

ตัวเครื่องถูกออกแบบให้ทนท�น มีปุ่มล็อคลูกตุ้มเหม�ะมือ และ

สะดวกพกพ�

ส�ม�รถกดปุ่มเลือกใช้เลเซอร์ระดับ หรือดิ่งในแต่ละครั้ง หรือจะใช้

ทั้งสองแนวได้เวล�เดียวกัน

Technical Data

PM 4-M

Measuring distance 10 m/ 50 m (with laser receiver) Accuracy (at 10 m)* ± 2 mm

(except battery compartment)

IP 54

battery 8 hrs

Dimensions (L x W x H) 124 x 124 x 187 mm

Note (*): Factors in particular extreme temperature fluctuations, humidity, shock,

drop, etc., can affect the accuracy. Unless otherwise specified, the tool

was under standard ambient (MIL-STD- 810F) adjusted or calibrated.

(8)

2

Technical Data

PM 2-L

Measuring distance 10 m/ 30 m (with laser receiver) Accuracy (at 10 m)* ± 3 mm

(except battery compartment)

IP 54

battery 20 hrs

Dimensions (L x W x H) 107 x 65 x 95 mm

Line laser PM 2-L Equipped with line laser PM 2-L, pouch PMLW 60, 4 batteries (Type AA), in cardbox

2047045

Laser Range Meter

PM 2-L

Simple and reliable line laser. Your leveling and aligning companion from Hilti.

สำ�หรับง�นย้�ยแนว หรือตรวจสอบอ้�งอิงแนวสูง

ห�แนวระดับสำ�หรับง�นฝ้� ง�นไฟฟ้� ร�งส�ยไฟ และก�รติดตั้ง

ท่อต่�งๆ

ห�แนวระดับ และแนวดิ่งสำ�หรับง�นประตูและหน้�ต่�ง

ห�แนวดิ่งสำ�หรับง�นติดตั้งท่อชนิดต่�งๆ

ไม่ต้องใช้ไม้ระดับ ลูกดิ่ง ไม้ฉ�ก และแนวชอล์ก ด้วยเครื่องเดียวก็

ส�ม�รถทำ�ได้ทุกหน้�ที่

องศ�ของเลเซอร์ทั้งแนวระดับ และแนวดิ่งแผ่ได้กว้�ง และ

ครอบคลุมพื้นที่ก�รทำ�ง�น

มองเห็นได้ถึง 2 แนว ทำ�ให้ง่�ยในก�รอ้�งอิงทั้งแนวดิ่งและแนว

ระดับ

ตัวเครื่องถูกออกแบบให้ทนท�น มีปุ่มล็อคลูกตุ้มเหม�ะมือ และ

สะดวกพกพ�

ส�ม�รถกดปุ่มเลือกใช้เลเซอร์ระดับ หรือดิ่งในแต่ละครั้ง หรือจะใช้

ทั้งสองแนวได้เวล�เดียวกัน

Note (*): Factors in particular extreme temperature fluctuations, humidity, shock,

drop, etc., can affect the accuracy. Unless otherwise specified, the tool

was under standard ambient (MIL-STD- 810F) adjusted or calibrated.

(9)

Technical Data

PR 2-HS Operating range with laser

receiver (diameter) 2 - 600 m Accuracy (at 10 m) ± 0.02 mm Laser class 620-690 nm Class 2 (IEC 60825-1:2007) IP protection class

(except battery compartment) IP 66

Rotating speed 300 rpm

Operating temperature range - 20 °C to 50 °C Operation time Li-ion battery

with CPC technology > 30 hrs Dimensions (L x W x H) 200 x 200 x 230 mm Weight with battery 2.5 kg

Rotating Laser PR 2-HS PR 2-HS Rotating laser, PRA 20 Laser receiver, PRA 83 Laser receiver holder, PRA 84 Battery pack, 2 Batteries AA, PUA 81 Mains adapter, 1 Operating instruction, 2 Producer certificates in Hilti case

(10)

2

Technical Data

PRE 3 Range with laser receiver

(diameter) up to 400 m

Accuracy (at 10 m) ± 0.5 mm Protection class

(dust and water)

IP 56

Laser class 635 nm, Class 2 (IEC 825-1) Self leveling range 10° ( ± 5°) Operating temperature range -20 °C to +50 °C Operation time Li-ion battery

with CPC technology 40 hrs Dimensions (LxWxH) 252 x 252 x 201 mm Weight with batteries 2.4 kg

Rotating laser PRE 3 PRE 3 Rotating laser, PRA 84 battery pack, PRA 31 laser receiver, 2 batteries (type AA, alkaline), PRA 80 laser receiver holder, PRA 85 mains adaptor, 2 manufacturer’s certificates, operating instructions for PRE 3 and PRA 31, packed in a Hilti toolbox.

(11)

Technical Data

PR 3 Operating range with laser

receiver (diameter)

1 m - 300 m Accuracy (at 10 m) ± 0.75 mm

Self leveling range ± 5°

IP protection class IP 56

Laser class 635 nm, Class 2 (IEC 529) Operating distance range of

remote control (radius) 1 m - 30 m Rotating speed 300, 600, 1500 rpm Operating temperature range -20 °C to +50 °C Operation time with

Li-ion battery 30 hrs

Dimension ( L x W x H) 252 X 252 x 201 mm Weight with battery 2.4 kg

Rotating Laser PR 3 PR 3 Rotating laser, PRA 2 remote control, PRA 84 Li-ion battery pack, PRA 85 mains adapter, PRA 50 Target plate, 2x “AA” Alkaline batteries & operating Instructions in Hilti case

(12)

2

Rotating Laser Accessories

PRE 3/PR 2-HS PR 3

Order Description Item Number

Battery charger PUA 83 n n 2044710

Wall mount PRA 72 (in/cm)

The finely adjustable PRA 70 wall mount makes countless jobs much easier n 2088509*

Slope adapter PRA 78

For setting PRE 3 or PR 26 to inclinations of up to 60% n n 360059*

Laser receiver PRA 31

For locating the rotating laser beam easily and accurately within an area of 400m in diameter

n n 426386

Laser receiver holder PRA 80

For easy attachment of the laser receiver to a leveling staff n n 360058

Battery pack PRA 84

Li-ion CPC technology battery pack for PRE 3 & PR 3 rotating laser n n 360055* Height transfer device PRA 81

For transferring meter marks with a fiberglass measuring tape, extendable up to 1 m. To be used in conjunction with PRA 31

n n 368627*

Vertical angle PRA 770 n 435440*

Batter board adapter PRA 750 n 435441*

Batter board receiver holder PRA 751 n 435442*

Facade adapter PRA 760 n 435439*

Crank tripod PA 921

The PA 921 is the type of tripod most frequently encountered in interior finishing & perfect for transferring benchmarks (datum marks). Height adjustable crank tripod (0.73 to 1.63 m) with 5/8” thread, built-in bubble level for quick easy setup

n n 378663

Measuring rod PUA 50

Aluminum, adjustable in height from 0.88 to 4 m; magnetic nail holder at the base of the staff for setting nails into formwork

n n 400935

Tripod PUA 20 kit

Includes PUA 20 tripod with PUA 50 leveling staff attached with clips for easy transportation

(13)

Technical Data

PS 250 Max. detection depth

for rebar (at 36 mm rebar diameter)180 mm Localization accuracy ±3 mm Accuracy of depth

measurement for rebar ±1 mm

Disclaimer Detection performance is depending on depth range and

scan mode used

IP protection class IP 54

Operation time with NiMH

battery 8 hrs

Operating temperature range -10 °C to +50 °C Scanner dimensions 260 x 132 x 132 mm Scanner weight (incl. battery) 2.4 kg

Ferroscan system PS 250 Scanner, hand strap, scanner pouch, monitor, monitor pouch, battery packs(2), mains adapter(2), data cables(2), handset, adapter PSA 55, reference grids PSA 10(5), adhesive tape, markers, brush, cleaning cloth, data module, meter stick, operating instructions(3), producer certificate(2), packed in a Hilti case

2044439

Ferroscan System

PS 250

Get a visible handle on rebar

(14)

2

Technical Data

PS 1000 Max. detection range for

object localization 300 mm Localization accuracy ±10 mm Accuracy of depth indication < 100 mm: ±10 mm

> 100 mm: ±15% Disclaimer Performance depended on

depth, spacing, size and type of object and base material type

and condition IP protection class IP 54, battery IP 56 Operation time with

Li-ion battery pack (scanner) 4 hrs Operating temperature range -10 °C to +50 °C Scanner dimensions 318 x 143 x 190.1 mm Scanner weight (incl. battery) 2.45 kg

X-Scan system PS 1000 Scanner, hand strap, battery pack(3), Mains adapter(2), monitor, monitor pouch, Data cable, connecting cable, headset, reference grids PSA 12(5), reference grids PSA 14(2), adhesive tape, markers, brush, torque wrench, cleaning cloth, data module, operating instructions, producer certificate, Packed in a Hilti trolley

(15)

Detection Accessories

PS 250 PS 1000

Order Description Item Number

Scanner PS 250 S

For extending the PS 250 Ferroscan system n

377652*

Battery pack PSA 80

For the scanner or monitor n 377472*

Battery charger PUA 80 EU

Spare or additional charger for charging the battery n

377458*

Memory card PSA 91 MMC n 305141*

Monitor PSA 100 n 2006082*

Memory card PSA 95 n 2006184*

Battery charger PSA 85

For PSA 82 n 2006181*

For PSA 100 n 2006182*

For PSA 100 n 2006183*

Reference grid PSA 12

600 x 600 mm n n 2006083*

Reference grid PSA 14 1,200 x 1,200 mm

(16)
