201403 Tampa Performance3

(1)

RED HAT CONFIDENTIAL | JEREMY EDER

1

Performance Tuning and

Analysis of Red Hat

Enterprise Linux 6 and 7

Jeremy Eder

Principal Software Engineer

March 13, 2014

(2)

2

Agenda: Performance Analysis of RHEL6/7

●

Performance Engineering Overview

●

Performance Analysis Utilities

●

Tuned

●

NUMA Tuning

(3)

RED HAT CONFIDENTIAL | JEREMY EDER 3

Performance Engineering

Overview

Micro-Benchmarks

Applications/Benchmarks

(4)

4 _{Red Hat Confidential}

Red Hat Performance Engineering

● Benchmarks – code path coverage

● CPU – linpack, lmbench

● Memory – lmbench, McCalpin Streams

● Disk IO – Iozone, aiostress – scsi, FC, iSCSI

● Filesystem – IOzone, postmark– ext3/4, xfs. gfs2,gluster ● Network – Netperf – 10 Gbit, 40 Gbit IB, PCI3

● Bare Metal, RHEL6/7 KVM

(5)

5

Performance Projects / Tooling

● RHEL6.5 “numad” “tuna”, and “tuned”

● Tuna used to bind IRQ's / real-time like isolation ● Profiling challenges

−Data address profiling (cache-2-cache detection),

providing:

• the hottest contended cachelines

• the process names, addresses, pids, tids causing that contention

• the cpus they ran on,

(6)

6

Performance Optimization

Out-of-the-box

(7)

8

Performance Tuning Automation

Automatic Tuning Tuned Transparent Hugepages numad irqbalance Manual Tuning N/A Static Hugepages

NUMA Pinning (numactl) IRQ Pinning (tuna)

RHEL7 numa_balancing

(8)

9

But...what if we have a problem ?

(9)

10

But...what if we have a problem ?

● Automatic not enough...

(10)

11

But...what if we have a problem ?

● Need to eek out the last X percent ● Need Determinism

(11)

12

But...what if we have a problem ?

● Need to eek out the last X percent ● Need Determinism

(12)

13

Overview of Performance

Analysis Utilities

(13)

14

perf

Userspace tool to read CPU

counters and kernel tracepoints

(14)

15

perf list

List counters/tracepoints available

on your system

(15)

16

perf list

grep for something interesting,

maybe to see what numabalance is

doing ?

(16)

17

perf top

System-wide 'top' view of busy

functions

(17)

18

perf record

(18)

19

perf record

●

Record system-wide (-a)

(19)

20

perf record

●

Record system-wide (-a)

●

A single command

(20)

21

perf record

●

Record system-wide (-a)

●

A single command

●

An existing process (-p)

(21)

22

perf record

●

Record system-wide (-a)

●

A single command

●

An existing process (-p)

●

Add call-chain recording (-g)

(22)

23

perf record

●

Record system-wide (-a)

●

A single command

●

An existing process (-p)

●

Add call-chain recording (-g)

(23)

24

perf report

(24)

25

perf report

/dev/zero

(25)

26

perf diff

(26)

27

perf probe (dynamic tracepoints)

Insert a tracepoint on any function...

Try 'perf probe -F' to list possibilities

(27)

28

(28)

29

Overview of Performance

Analysis Utilities

(29)

30

Performance Co-Pilot (PCP)

(Multi) system-level performance

monitoring and management

(30)

31

pmchart – graphical metric plotting tool

(31)

32

pmchart – graphical metric plotting tool

● Can plot myriad performance statistics ● Recording mode allows for replay

● i.e. on a different system ● Record in GUI, then

(32)

33

pmchart – graphical metric plotting tool

● Can plot myriad performance statistics ● Recording mode allows for replay

● i.e. on a different system ● Record in GUI, then

# pmafm $recording.folio

● Ships with many pre-cooked “views”...for example:

● ApacheServers: CPU%/Net/Busy/Idle Apache Servers ● Overview: CPU%/Load/IOPS/Net/Memory

(33)

34

(34)

35

Performance Co-Pilot Demo Script

# CPU

/root/pig -s 5 # DISK

dd if=/dev/zero of=/root/2GB count=2048 bs=1M oflag=direct # NETWORK

netperf -H lab7 -l 5 # MEMORY

/root/pig -m 16384 -l sleep -s 5

(35)

RED HAT CONFIDENTIAL | JEREMY EDER 36 CPU % Load Avg IOPS Network Memory Allocated

(36)

37

collectl mode

(37)

38

collectl mode

IOPS CPU

(38)

collectl mode

IOPS NET CPU

(39)

collectl mode

IOPS MEM NET CPU

(40)

41

(41)

42

(42)

43

NUMA Tuning

Discovery

(43)

44

Visualize NUMA Topology: lstopo

How can I visualize my system's NUMA topology in Red Hat Enterprise Linux?

https://access.redhat.com/site/solutions/62879

(44)

45

Visualize NUMA Topology: lstopo

(45)

46

Visualize NUMA Topology: lstopo

PCI Devices

(46)

47

Visualize NUMA Topology: lscpu

# lscpu

Architecture: x86_64 ...

CPU(s): 16 On-line CPU(s) list: 0-15 Thread(s) per core: 1

Core(s) per socket: 8 Socket(s): 2 NUMA node(s): 2 ...

NUMA node0 CPU(s): 0-7 NUMA node1 CPU(s): 8-15

(47)

48

Visualize NUMA Topology: lscpu

# lscpu

Architecture: x86_64 ...

CPU(s): 16 On-line CPU(s) list: 0-15 Thread(s) per core: 1

Core(s) per socket: 8 Socket(s): 2 NUMA node(s): 2 ...

NUMA node0 CPU(s): 0-7 NUMA node1 CPU(s): 8-15

Logical Cores/HT

(48)

49

NUMA Topology and PCI Bus

● Install adapters “close” to the CPU that will run the

performance critical application.

● When BIOS reports locality, irqbalance handles

NUMA/IRQ affinity automatically.

# lstopo-no-graphics |egrep 'NUMA|eth4' NUMANode L#0 (P#0 144GB)

NUMANode L#1 (P#1 144GB) Net L#10 "eth4"

(49)

50

RHEL NUMA Scheduler

● RHEL6

● numactl, numastat enhancements

● numad – usermode tool, dynamically monitor, auto-tune

● RHEL7 – numabalance

● Enable / Disable

(50)

51

How to manage NUMA manually - Checklist

Checklist

 Research Topology  Make a resource plan  Consider I/O  Virtualization Tool  lstopo/lscpu  cgroups, numactl  irqbalance/PCI Bus  numatune/numad

(51)

52

How to manage NUMA manually - Checklist

Checklist

 Research Topology  Make a resource plan  Consider I/O  Virtualization Tool  lstopo/lscpu  cgroups, numactl  irqbalance/PCI Bus  numatune/numad

(52)

53

How to manage NUMA manually - Checklist

Checklist

 Research Topology  Make a resource plan  Consider I/O  Virtualization Tool  lstopo/lscpu  cgroups, numactl  irqbalance/PCI Bus  numatune/numad

(53)

54

How to manage NUMA manually - Checklist

Checklist

 Research Topology  Make a resource plan  Consider I/O  Virtualization Tool  lstopo/lscpu  cgroups, numactl  irqbalance/PCI Bus  numatune/numad

(54)

55

How to manage NUMA manually - Checklist

Checklist

 Research Topology  Make a resource plan  Consider I/O  Virtualization Tool  lstopo/lscpu  cgroups, numactl  irqbalance/PCI Bus  numatune/numad

(55)

56

NUMA Tools: numastat

Completely rewritten for RHEL6.4

Per-node /proc/meminfo

Backwards compatible

(56)

57

NUMA Tools: numastat

Completely rewritten for RHEL6.4

Per-node /proc/meminfo

Backwards compatible

(57)

58

numastat: compatibility mode (old)

# numastat node0 node1 numa_hit 77587739 131990042 numa_miss 0 0 numa_foreign 0 0 interleave_hit 30254 30099 local_node 69302710 129511360 other_node 8285029 2478682

(58)

59

numastat: per-node meminfo (new)

# numastat -mczs Node 0 --- MemTotal 65491 MemFree 60366 MemUsed 5124 Active 2650 FilePages 2021 Active(file) 1686 Active(anon) 964 AnonPages 964 Inactive 341 Inactive(file) 340 Slab 380 SReclaimable 208 SUnreclaim 173 AnonHugePages 134

(59)

60

numastat: per-node meminfo (new)

# numastat -mczs

Node 0 Node 1 Total ---MemTotal 65491 65536 131027 MemFree 60366 59733 120099 MemUsed 5124 5803 10927 Active 2650 2827 5477 FilePages 2021 3216 5238 Active(file) 1686 2277 3963 Active(anon) 964 551 1515 AnonPages 964 550 1514 Inactive 341 946 1287 Inactive(file) 340 946 1286 Slab 380 438 818 SReclaimable 208 207 415 SUnreclaim 173 230 403 AnonHugePages 134 236 370

(60)

61

NUMA Tuning

numad

(61)

62

NUMA: Process Scheduler Behavior

● Scheduler distributes load evenly across all cores ● Maintains responsiveness

● Optimizing for CPU utilization

● Tries to use idle CPUs, regardless of where process

memory is located

BUT!

Using remote memory degrades

performance!

(62)

63

How to manage NUMA manually - Checklist

Short Term (RHEL6.4)  U

serspace solution

numad

Long Term (RHEL7)

(63)

64

How to manage NUMA manually - Checklist

Short Term (RHEL6.4)  U

serspace solution

numad

Long Term (RHEL7)  In-Kernel Solution

numabalance

(64)

65

(65)

66

Effect of Automatic NUMA Balancing Software

# numastat -c pig (default scheduler – non-optimal)

PID Node 0 Node 1 2578 (pig) 2123 11878 2579 (pig) 1988 12013 2580 (pig) 14000 1 2581 (pig) 1981 12020

(66)

67

Effect of Automatic NUMA Balancing Software

# numastat -c pig (default scheduler – non-optimal)

PID Node 0 Node 1 2578 (pig) 2123 11878 2579 (pig) 1988 12013 2580 (pig) 14000 1 2581 (pig) 1981 12020

PID Node 0 Node 1 2578 (pig) 14000 0 2579 (pig) 0 14000 2580 (pig) 14000 0 2581 (pig) 0 14000 Before numad After numad

(67)

Effect of numad/numabalance

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 0 2000 4000 6000 8000 10000 12000 14000

Automatic NUMA Balancing - NUMAD

NODE-0-MB NODE-1-MB

Time (sec onds)

M e g a b yt e s P e r N U M A N o d e numad begins numad done

(68)

69

(69)

70

(70)

71

What is “tuned” ?

Tuning profile delivery mechanism

Red Hat ships tuned profiles that

improve performance for many

workloads...hopefully yours!

(71)

72

(72)

73

Tuned: Storage Performance Boost

(73)

RED HAT CONFIDENTIAL | JEREMY EDER 74 0 50 100 150 200 250 Max

Tuned: Network Latency Performance Boost

C6 C3 C1 C0 La te nc y (M ic ro se co nd s)

C-state lock improves determinism, reduces jitter

(74)

75

(75)

76

tuned Profile Summary: RHEL6

Tunable default

enterprise-storage virtual-host virtual-guest performancelatency- performance

throughput-sched_min_ granularity_ns 4ms 10ms 10ms 10ms 10ms sched_wakeup_granula rity_ns 4ms 15ms 15ms 15ms 15ms dirty_ratio _{20% RAM} _40% _10% _40% _40% dirty_background_ratio _{10% RAM} _5% swappiness ₆₀ ₁₀ ₃₀

I/O Scheduler (Elevator) _CFQ _deadline _deadline deadline deadline deadline Filesystem Barriers On Off Off Off

CPU Governor ondemand performance performance performance Disk Read-ahead 4x

Disable THP Yes

(76)

77

(77)

78

Tuned: Updates for RHEL7

(78)

79

Tuned: Updates for RHEL7

●

Installed by default!

●

Profiles automatically set based on install type:

●

Desktop/Workstation: balanced

(79)

80

Tuned: Updates for RHEL7

(80)

81

Tuned: Updates for RHEL7

●

Re-written for maintainability and extensibility.

●

Configuration consolidated to single

(81)

82

Tuned: Updates for RHEL7

●

Re-written for maintainability and extensibility.

●

Configuration is now consolidated a single

tuned.conf file

(82)

83

Tuned: Updates for RHEL7

●

Re-written for maintainability and extensibility.

●

Configuration is now consolidated a single

tuned.conf file

●

Optional hook/callout capability

●

Adds concept of Inheritance (just like

(83)

84

Tuned: Updates for RHEL7

●

Re-written for maintainability and extensibility.

●

Configuration is now consolidated a single

tuned.conf file

●

Optional hook/callout capability

●

Adds concept of Inheritance (just like

httpd.conf)

●

Profiles updated for RHEL7 features and

(84)

85

Children Parents

Tuned: Profile Inheritance

latency-performance throughput-performance network-latency network-throughput virtual-host virtual-guest balanced desktop

(85)

86

Children Parents

Tuned: Profile Inheritance

latency-performance throughput-performance network-latency network-throughput virtual-host virtual-guest balanced desktop Your-DB Your-Web Your-Middleware

(86)

87

(87)

88

Tunable Units Balanced throughput-performance network-throughput

Inherits From/Notes throughput-performance

sched_min_ granularity_ns nanoseconds auto-scaling 10000000 sched_wakeup_granularity_ns nanoseconds 3000000 15000000

dirty_ratio Percent 20 40

dirty_background_ratio Percent 10 10

swappiness Weight 1-100 60 10

I/O Scheduler (Elevator) deadline

Filesystem Barriers Boolean Enabled

CPU Governor ondemand performance

Disk Read-ahead KB 128 4096

Disable THP Boolean Enabled

Energy Perf Bias normal performance

kernel.sched_migration_cost_ns nanoseconds 500000

min_perf_pct (intel_pstate only) Percent auto-scaling 100

tcp_rmem Bytes auto-scaling Max=16777216

tcp_wmem Bytes auto-scaling Max=16777216

udp_mem Pages auto-scaling Max=16777216

(88)

89

Tunable Units Balanced latency-performance network-latency

Inherits From/Notes latency-performance

sched_min_ granularity_ns nanoseconds auto-scaling 10000000

sched_wakeup_granularity_ns nanoseconds 3000000 10000000

dirty_ratio percent 20 10

dirty_background_ratio percent 10 3

swappiness Weight 1-100 60 10

I/O Scheduler (Elevator) deadline

Filesystem Barriers Boolean Enabled

CPU Governor ondemand performance

Disable THP Boolean N/A No Yes

CPU C-States N/A Locked @ 1

Energy Perf Bias normal performance

kernel.sched_migration_cost_ns nanoseconds N/A 5000000

min_perf_pct (intel_pstate only) percent 100

net.core.busy_read microseconds 50

net.core.busy_poll microseconds 50

net.ipv4.tcp_fastopen Boolean Enabled

kernel.numa_balancing Boolean Disabled

(89)

90

Tunable Units throughput-performance virtual-host virtual-guest

Inherits From/Notes

throughput-performance

throughput-performance sched_min_ granularity_ns nanoseconds 10000000

sched_wakeup_granularity_ns nanoseconds 15000000

dirty_ratio percent 40 30

dirty_background_ratio percent 10 5 30

swappiness Weight 1-100 10

I/O Scheduler (Elevator)

Filesystem Barriers Boolean

CPU Governor performance

Disk Read-ahead Bytes 4096

Energy Perf Bias performance

kernel.sched_migration_cost_ns nanoseconds 5000000

min_perf_pct (intel_pstate only) percent 100

(90)

91

RHEL “tuned” package

Available profiles: - balanced - desktop - latency-performance - myprofile - network-latency - network-throughput - throughput-performance - virtual-guest - virtual-host

(91)

92

(92)

RED HAT CONFIDENTIAL | JEREMY EDER 93 0 50 100 150 200 250 Max

CPU Tuning: C-states (idle states)

C6 C3 C1 C0

C-state Impact on Jitter

La te nc y (M ic ro se co nd s)

Time (1-sec intervals)

(93)

94

Power Consumption RHEL6 vs RHEL6@C0

● C-state lock increases power draw over “out of the box”

● Use cron to set latency-performance tuned profile when necessary. ● Or use BUSY_POLL

● Set tuned profile in application init script

Test Efficiency [Wh] % Diff Kernel Build +12.5%

Disk Read +32.2% Disk Write +25.6% Unpack tar.gz +23.3% Active Idle +41%

(94)

RED HAT CONFIDENTIAL | JEREMY EDER 95 Default pk cor CPU %c0 GHz TSC %c1 %c3 %c6 %c7 0 0 0 0.24 2.93 2.88 5.72 1.32 0.00 92.72 0 1 1 2.54 3.03 2.88 3.13 0.15 0.00 94.18 0 2 2 2.29 3.08 2.88 1.47 0.00 0.00 96.25 0 3 3 1.75 1.75 2.88 1.21 0.47 0.12 96.44 latency-performance pk cor CPU %c0 GHz TSC %c1 %c3 %c6 %c7 0 0 0 0.00 3.30 2.90 100.00 0.00 0.00 0.00 0 1 1 0.00 3.30 2.90 100.00 0.00 0.00 0.00 0 2 2 0.00 3.30 2.90 100.00 0.00 0.00 0.00 0 3 3 0.00 3.30 2.90 100.00 0.00 0.00 0.00

Turbostat shows P/C-states on Intel CPUs

(95)

96

Profiling cpuidle and cpufreq

● Fixed upstream cpuidle regression in June

● Future CPUs such as Haswell add more C-states,

C8,C9,C10

● Turbostat display a bit awkward for 40+ cores

● Direction in future is to shrink the exit-latency between

C-states

● http://www.breakage.org/2012/11/processor-max_cstat

(96)

97

(97)

Helpful Utilities

Supportability ● redhat-support-tool ● sos ● kdump ● perf ● psmisc ● strace ● sysstat ● systemtap ● trace-cmd ● util-linux-ng NUMA ● hwloc ● Intel PCM ● numactl ● numad ● numatop (01.org) Power/Tuning ● cpupowerutils (R6) ● kernel-tools (R7) ● powertop ● tuna ● tuned Networking ● dropwatch ● ethtool ● netsniff-ng (EPEL6) ● tcpdump ● wireshark/tshark Storage ● blktrace ● iotop ● iostat

(98)

99

Helpful Links

● Red Hat Low Latency Performance Tuning Guide

● Optimizing RHEL Performance by Tuning IRQ Affinity

● Red Hat Performance Tuning Guide

● Red Hat Virtualization Tuning Guide

● STAC Network I/O SIG

● Finteligent Low Latency Tuning w/KVM

● Perf

(99)

100
