Microfluidic large scale integration and its application to systems biology

(1)

Application to Systems Biology

Thesis by

Sebastian Josef Maerkl

In Partial Fulfillment of the Requirements for the Degree of

Doctor of Philosophy

California Institute of Technology Pasadena, California

2007

(2)

c

2007
