Hardware for the Internet of Things
Certified, carrier-approved modems, routers,
and gateways for use on GSM, CDMA, HSPA+, and LTE networks
NETWORKING DEVICES
QuickCarrier® USB-D
Cellular USB Dongles
• Easily enables global deployment of M2M communications • 7+ year lifecycle versus consumer-grade dongles
• Connection Manager automatically installs drivers
MultiConnect® Cell 100 Series
Cellular Modems
• Rugged chassis supports industrial M2M applications • Serial or USB connections offer application flexibility
• External antenna connector for improved range and performance
MultiConnect® rCell 100 Series
Cellular Routers
• Complimentary device management offers lowest total operating cost • HSPA+ models support global deployment with one device
• Optional GPS, Wi-Fi® & Bluetooth® for enhanced applications • Class I, Division 2 certification for use in hazardous locations
MultiConnect® rCell 500 Series -
NEW for Europe Only
LTE Cellular Router
• 4G LTE performance up to: 100 Mbps downlink and 50 Mbps uplink (CAT3) • Wi-Fi (802.11 b/g/n) supports up to 128 concurrent connections
• Dual power supply input, 12-48VDC • Dual SIM/USIM cards
• Automatic WAN failover and failback
New Gateway for the Internet of Things
The MultiConnect® Conduit™ platform is a configurable hardware platform customized using plug-and-play MultiConnect® mCard™ interfaces to collect data from MultiConnect® mDot™, sensors, and other assets for cellular delivery to a preferred data center.
Conduit is supported by DeviceHQ™, a pre-populated online application store, allowing both developers and IT personnel to easily provision, deploy, and manage their gateway and associated devices. Users are also able to create custom applications using an intuitive drag-and-drop interface. Complex application development is supported with a custom Linux development
environment, making Conduit the premier platform to enable M2M connectivity for the Internet of Things.
Ethernet
GPIO
LoRa™ Serial
EMBEDDED MODEMS AND SOMS
MultiConnect® Dragonfly
™-
NEW
Cellular SoM with 4 pin USB Connection
• Cortex® M3 processor to host your application
• Full suite of interfaces connects sensors and other assets • Compatible with ARM® mbed development platform
SocketModem® Cell & SocketModem® iCell
Intelligent/Cellular Modems with Universal Socket Connection
• Technology roadmap allows connectivity upgrades without a redesign • Universal IP® stack features common AT commands across technologies • Universal Socket Bluetooth, Ethernet, and PSTN models also available
MultiConnect® OCG-E
Cellular SoM with 80 pin Board-to-Board Connection
• ARM9™ processor to host your application
• Custom Linux environment supports open source application development • Multiple interfaces provide maximum application flexibility
MultiConnect® PCIe
Cellular Modem with PCI Express Mini Card Connection
• Enables cellular connectivity without a redesign
• HSPA+ models support global deployment with one device
• Optional digital voice, GPS, Wi-Fi & Bluetooth for enhanced applications
DEVELOPER KITS
SocketModem® Shield -
NEW
Cellular Adaptor for Arduino Shield Compatible Developer Boards
• Rapidly prototype with SocketModem® and Dragonfly capabilities • www.mbed.org software library simplifies development
Claudia Schweigert Line Manager Mündelheimer Weg 9 D-40472 Düsseldorf, Germany Tel: +49 211 9511 - 123 Email: [email protected] Web: www.unitronic.de FM31060 ISO 9001 Quality Management FM 586973 ISO 13485 Medical Devices Quality Management
About MultiTech
Multi-Tech Systems, Inc. has been expanding the connected world by delivering industry-leading
communications technology platforms for over 40 years. Offering an extensive line of fully certified and carrier-approved external and embedded modems, routers and gateways, MultiTech works with thousands of customers worldwide to easily enable cellular, analog, Wi-Fi®, Bluetooth®, LoRa™, GPS and other M2M communication capabilities for their IoT applications. For more information, please visit www.multitech.com.
World Headquarters - U.S.A.
Multi-Tech Systems, Inc. 2205 Woodale Drive
Mounds View, MN 55112 U.S.A. Tel: 763-785-3500
Toll-Free: 800-328-9717 Email: [email protected] www.multitech.com
EMEA Headquarters
Multi-Tech Systems (EMEA) Strata House 264-270 Bath Road Harlington UB3 5JJ United Kingdom Tel: +(44) 118 959 7774 Email: [email protected] www.multitech.co.uk
Features are subject to change without notice.
Trademarks & Registered Trademarks: MultiTech and the MultiTech logo, Conduit, DeviceHQ, Dragonfly, mCard, mDot, MultiConnect, QuickCarrier, SocketModem, Universal IP: Multi-Tech Systems, Inc. All other products and technologies are the trademarks or registered trademarks of their respective holders.
UNITRONIC AG Mündelheimer Weg 9 40472 Düsseldorf Telefon 0211 / 95 110 Telefax 0211 / 95 11 111 [email protected] PART OF LAGERCRANTZ GROUP
Future-Proof Your
Connected Devices
AirPrime® SL Series offers smart connectivity for consumer and industrial applications. Its standard 25 x 30 mm LGA (Land Grid Array) package allows fully automated manufacturing for high-volume production.
Available in multiple air interfaces versions (EDGE, HSDPA, HSPA+, CDMA 1xRTT and EV-DO), the AirPrime SL Series presents an easy upgrade path to next-generation network technologies.
With its application framework and cloud-based device management services, the smart AirPrime SL Series accelerates your M2M deployment. AirPrime SL Series modules have a solid track record in several M2M sectors such as transportation, energy, industrial, security, sales & payment, networking, fi eld service and healthcare.
AIRPRIME SL6087 - ELECTED “BEST 2G MODULE”
Elected “Best 2G Module” by the GSMA, the AirPrime SL6087 is a quad-band EDGE module which natively supports the Open AT application framework and a comprehensive set of device management capabilities. It is available with Embedded SIM as an option.
AIRPRIME SL808X
The AirPrime SL808x offers HSDPA connectivity and quad-band
GSM/GPRS/EDGE network access for global coverage. It natively supports the Open AT application framework and a comprehensive set of device management capabilities. Is it available with Embedded SIM as an option. AIRPRIME SL809X
The AirPrime SL809x is one of the smallest high-speed HSPA+ modules in the industry, featuring voice, antenna diversity, and GPS support. It includes quad-band GSM/GPRS/EDGE connectivity as well.
AIRPRIME SL301X/SL501X
The AirPrime SL301x and SL501x offer dual-band CDMA 1xRTT and EV-DO connectivity with GPS and antenna diversity.
AIRPRIME SL9090
The AirPrime SL9090 is a multimode HSPA+/EV-DO module designed to operate on the main mobile networks in North America with a single product reference. It features GPS and supports quad-band GSM/GPRS/EDGE.
KEY BENEFITS
• High scalability for new network technologies
• A single small form factor to adress multiple air interfaces for global deployment
• Resists industrial environments and extended temperatures
• Available with an application framework to simplify software development • Remote upgrade and monitoring via a
cloud platform
Smart
Sierra Wireless AirPrime®
Embedded Wireless Modules
SL Series
UNITRONIC AG Mündelheimer Weg 9 40472 Düsseldorf Telefon 0211 / 95 110 Telefax 0211 / 95 11 111 [email protected]
Contact:
Sierra Wireless, the Sierra Wireless logo, AirPrime, and the red wave design are trademarks of Sierra Wireless. Other registered trademarks that appear on this brochure are the property of the respective owners. © 2014 Sierra Wireless, Inc. www.sierrawireless.com
SL6087 SL808X SL809X SL301X/SL501X SL9090
AIR INTERFACE
GSM/GPRS/EDGE GSM/GPRS/EDGE/HSDPA GSM/GPRS/EDGE/HSPA+ CDMA 1xRTT EV-DO Rev A (SL501x) GSM/GPRS/EDGE/HSPA+/ EV-DO Rev A/ CDMA 1xRTT FREQUENCY BANDS GSM/GPRS/EDGE 850/900/1800/1900 MHz 850/900/1800/1900 MHz 850/900/1800/1900 MHz 850/900/1800/1900 MHz WCDMA SL8080/81: 850/1900 MHz SL8082/83: 900/2100 MHz SL8084/85: 800/850/2100 MHz SL8090: 800/850/1900/2100 MHz SL8092: 900/2100 MHz 800/850/1900/2100 MHz CDMA 800/1900 MHz 800/1900 MHz APPROVALS
Regulatory R&TTE, CE, GCF-CC, FCC, PT-CRB, China RTE, ICASA, Anatel
SL8080/81: FCC, IC, GCF-CC, PTCRB SL8082/83: R&TTE, CE, GCF-CC SL8084/85: CE, GCF-CC, PTCRB, A-Tick compliant FCC, IC, CE, GCF-CC, PTCRB, A-Tick compliant FCC FCC, IC, PTCRB, A-Tick compliant
Carrier AT&T, Vodafone SL8080/81: AT&T, Rogers SL8084/85: Telstra
AT&T, NCC, NTT DoCoMo Verizon, Sprint AT&T, Verizon, Sprint, NTT DoCoMo
CURRENT CONSUMPTION
Alarm (leakage only) 10.4 μA* 35 μA* <50 μA* <50 μA*
Standby and Idle (Sleep) 1.9 mA <2 mA <2 mA 3.5mA <2 mA
GSM/GPRS max 1.5mA peak @3.6V
418mA average 2.2A peak @3.6V (+32dBm) 500mA average 2.3A peak @3.6V (+32dBm) 730mA average 2.3A peak @3.6V (+32dBm) 730 mA average
EVDO REV A max 1000mA 1000mA
HSxPA max 570mA @ 3.6V (+23dBm) 682mA @ 3.6V (+23dBm) 1A @ 3.6V (+23dBm) CPU PERFORMANCE
Processor ARM946 / DSP ARM926EJS / QDSP4 ARM1136JS ARM926EJS ARM1136JS
Core frequency 26-104 MHz 184 MHz / 92 MHz 300MHz 192MHz 300MHz
User MIPS Available 3 3 3 3 3
AUDIO
Analog Audio 1x micro in/1x speaker out 1x micro in/1x speaker out
Digital Audio PCM PCM PCM (SL8090/92) /I2S (SL8092) PCM (SL3010/SL5010) PCM / I2S
Codec FR, EFR, HR, AMR FR, EFR, HR, AMR, QCELP-13K FR, EFR, HR, AMR FR, EFR, HR (SL3010/SL5010) FR, EFR, HR, AMR
Quality VDA2A
Echo cancellation & Noise reduction 3 3 3 3 3
DTMF 3 3 3 3 3
INTERFACES
UART 1 x 4 Wire and 1 x 8 Wire 1x 4 Wire or 8 wire 1x 4 Wire or 8 Wire 1 x 4 Wire 1 x 4 Wire or 8 Wire
USB 1 x USB 2.0 Full Speed 1 x USB 2.0 High Speed 1 x USB 2.0 High Speed 1 x USB 2.0 High Speed 1 x USB 2.0 High Speed
SPI 1 x 4-Wire 1 x 4-Wire 1 x 4-Wire 1 x 4-Wire
I2C 1 1 ADC 2 2 GPIO Up to 26 Up to 5 Up to 3 Up to 5 Up to 4 RTC 1 Timers (HW, SW, Capture) 1 Interrupts Pins 2
Flash LED Output 1 1 1 1 1
PWM (Buzzer) 1 1 1 1 1 Tx Burst indicator 1 1 1 SIM interface 1.8/3V 1.8/3V 1.8/3V 1.8V/3V 1.8V/3V ANTENNA DIVERSITY 3 3 3 LOCATION SOLUTION AirPrime XM0110 GPS module and Location Library
gpsOne gpsOneXTRA gpsOne gpsOneXTRA
EMBEDDED SIM
Optional Optional MANAGEMENT SERVICES
3 3
CONTROL OPTIONS
AT commands, C/C++ language AT commands, C/C++ language AT commands AT commands, CnS AT commands, QMI APPLICATION FRAMEWORK Open AT Open AT INTERNET SERVICES TCP/UDP/FTP/HTTP/SMTP/ POP3/SNMP/SSL TCP/UDP/FTP/HTTP/SMTP/ POP3/SNMP/SSL
TCP/UDP TCP/UDP TCP/ UDP
DRIVERS
Android, Linux, Windows CE 6.0, Windows Mobile 6.5
Android, Linux, Windows CE 6.0, Windows Mobile 6.5
Windows CE 6.0, Windows Mobile 6.5
Android, Windows CE 6.0, Win-dows Mobile 6.5, Linux SDK DEVICE DIMENSIONS
25 x 30 x 2.65 mm 25 x 30 x 2.35 mm 25 x 30 x 2.35 mm 25 x 30 x 2.35 mm 25 x 30 x 2.35 mm TEMPERATURE RANGE
-40°C to +85°C -40°C to +85°C** -40°C to +85°C -40°C to +85°C -40°C to +85°C * Power mode in Alarm Mode can be reduced to less than 1μA with external design.
** Except AirPrime SL8081/83/85. Contact Sierra Wireless for more information.
Sierra Wireless AirPrime®
Embedded Wireless Modules
SL Series
UNITRONIC AG Mündelheimer Weg 9 40472 Düsseldorf Telefon 0211 / 95 110 Telefax 0211 / 95 11 111 [email protected] PART OF LAGERCRANTZ GROUP
Compact, Flexible, and Future
Proof 2G, 3G, and 4G Essential
Modules
Sierra Wireless AirPrime® HL embedded modules offer everything device manufacturers need to meet essential connectivity requirements for machine-to-machine (M2M) applications such as healthcare, point of sale terminals, fl eet management, tracking, and consumer electronics. Key differentiators include a common form factor, small size, low-power consumption, enhanced RF performance, optional GNSS (GPS and GLONASS), and worldwide coverage.
COMPACT: THE SMALLEST 2G TO 4G FORM FACTOR ON THE MARKET The HL Series is the smallest module on the market sharing a common form factor across 2G, 3G, and 4G technologies. Now, with just one PCB design, device manufacturers can easily integrate voice and data connectivity and deploy in any region, on any wireless mobile network. FLEXIBLE: SOLDER DOWN OR CHOOSE THE SNAP-IN SOCKET TO SWITCH MODULES ANY TIME
The compact form factor offers the choice of soldering down the module for effi cient high-volume production or, using a snap-in socket on the same solder pads for total fl exibility in prototyping or smaller volume runs. The innovative snap-in socket allows device manufacturers to deploy or change modules at any point in the production and product life cycles.
FUTURE PROOF: INTELLIGENT PIN-TO-PIN COMPATIBILITY TO SUPPORT EVOLVING TECHNOLOGIES
The core and extension pins on the common form factor enables forward and backward compatibility between the different 2G, 3G, and 4G module variants. This means that the mechanical pin location delivers the same function across the series. The optional custom pins allow for new features as technology evolves making it the most future proof module on the market.
Sierra Wireless AirPrime
®
Embedded Modules
HL Series
Essential
EASY TO INTEGRATE AND MANAGE
Th e HL Series can be managed remotely with AirVantage® Management Service, enabling device manufacturers to securely upgrade device fi rmware over-the-air. Th is can extend the life of your products and solutions by future-proofi ng remote assets, expanding service quality, and saving customers time and operating costs.
Th e more we talked with Sierra Wireless, the more confi dent we became that they really understood what we needed to not only build and launch a new generation of outdoor lighting fi xtures, but to also grow and evolve them over time. – Vasanth Philomin,
General Manager Philips CityTouch
UNITRONIC AG Mündelheimer Weg 9 40472 Düsseldorf Telefon 0211 / 95 110 Telefax 0211 / 95 11 111 [email protected]
Contact:
Masthead in white centred
vertically in the text box -
3 line max if possible
Sierra Wireless, the Sierra Wireless logo, AirPrime, and the red wave design are trademarks of Sierra Wireless. Other registered trademarks that appear on this brochure are the property of the respective owners. © 2014 Sierra Wireless, Inc. www.sierrawireless.com
Sierra Wireless AirPrime
®
Embedded Modules
HL Series
HL75xx Series HL8548 HL6528
FORM FACTOR
LGA LGA LGA
AIR INTERFACE
LTE & LTE/HSPA GSM/GPRS/EDGE/HSD/PA/HSUPA GSM/GPRS FREQUENCY BANDS LTE HL7519: B2/B4/B13 HL7528: B1/B3/B5/B7 HL7548: B2/B4/B5/B13/B17 HL7549: B3/B7/B28 HL7588: B2/B4/B5/B13/B17 HSPA HL7588: B2/B5 B1/B2/B5/B6/B8 EDGE 850/900/1800/1900 GSM/GPRS 850/900/1800/1900 850/900/1800/1900 APPROVALS
Regulatory PTCRB, FCC, GCF, IC, KC Mark CE, FCC, PTCRB, GCF, IC, Anatel, CCC CE, FCC, PTCRB, GCF, IC, Anatel, CCC Carrier Depends on Models: AT&T, Verizon, Rogers, KT, SKT, LGU+... AT&T, Vodafone, NTT... Approved in many carriers over the world CURRENT CONSUMPTION
Power Supply for Extended Battery LIfe 2.8V supports 2.8V supports 2.8V supports Alarm (leakage only) 110μA 40μA 35μA Standby and Idle (Sleep) LTE: 1.5 mA 1.2 mA 1 mA
GSM/GPRS max 360 mA 360 mA
HSxPA max HL7588: 560 mA 560 mA LTE max CAT 4: 750 mA
AUDIO
Analog Audio 3
Digital Audio 3depends on the variants 3 3
Codec depends on the variants HR, FR, EFR, AMR HR, FR, EFR, AMR Echo Cancellation & Noise Reduction depends on the variants 3 3
DTMF depends on the variants 3 3
INTERFACES
UART 3 8 lines 3 8 lines 3 8 lines
USB 3 3
SPI 3
ADC 2 2 2
GPIO 8 8 8
Flash LED Output 3 3
PWM (Buzzer) 1 1 2
Tx Burst Indicator 3 3 3
SIM interface 1.8V/3V 3 1 SIM DSDS support 2 SIM DSDS support LOCATION SOLUTION
GPS & Glonass Sirf V GPS & Glonass Sirf V CLOUD SERVICES
FOTA through AVMS FOTA through AVMS FOTA through AVMS INTERNET SERVICES
TCP+UDP+FTP+HTTP+HTTPS TCP+UDP+FTP+HTTP+HTTPS TCP+UDP+FTP+HTTP+HTTPS DRIVERS
USB drivers for Linux, Android, Win CE, Win8
USB drivers for Linux, Android, Win CE,
Win7, Win XP RIL driver for Win CE & Linux DEVICE DIMENSIONS
22x23x2.5 mm 22x23x2.5 mm 22x23x2.5 mm TEMPERATURE RANGE
- 40°C / + 85°C - 40°C / + 85°C - 40°C / + 85°C
About Sierra Wireless
Sierra Wireless is the global leader in machine-to-machine (M2M) devices and cloud services, delivering intelligent wireless solutions that simplify the connected world. Our solutions are simple, scalable, and secure, and enable customers to get their connected products and services to market faster.
