HD/H-20 TON

Manuel

HD/M/H/Mov 30 TON

Motorlu - Kollu - Gezer Silindirli

Motor and Hand Operated with Movable Cylinder

HD. 20 Ton

HD. 30 Ton

HD.30 Ton

Kapasite

Capacity

Manuel

Kollu

Manuel

Kollu

Motor Opedated

Motorlu

A (mm)

1600

1700

2100

B (mm)

750

800 C (mm)

750

750 1200

D (mm)

490

550

740 E (mm)

200

300 H (mm)

700

800

900 Stroke (mm)

170

400 Motor (hp.)

-

3.0 Pompa/Pump (Lt.)

-

6.5 Ağırlık/Weight (kg.)

175

200

600 TEKNİK ÖZELLİKLER / TECHNICAL

SPECIFICATION

HİDROLİK ATÖLYE PRESİ

HYDRAULIC WORKSHOP PRESS

HD/H-30 TON

(5)

Motorlu - Kollu - Gezer Silindirli

Motor - Hand Operated - Movable Cylinder

HD./80 TON

M/H/Mov

HD. 60 Ton

HD. 80 Ton

HD.100 Ton

Kapasite

Capacity

Motor Opedated

Motorlu

Motor Opedated

Motorlu

Motor Opedated

Motorlu

A (mm)

2100

245

245 B (mm)

850

900

900 C (mm)

1200

1320

D (mm)

820

920 1010

E (mm)

300

300 H (mm)

800

900

900 Stroke (mm)

400

400 Motor (hp.)

3.0

5.5 Pompa/Pump (Lt.)

6.5

11.0 Ağırlık/Weight (kg.)

675

725

900 TEKNİK ÖZELLİKLER / TECHNICAL

SPECIFICATION

HİDROLİK ATÖLYE PRESİ

HYDRAULIC WORKSHOP PRESS

HD./60 TON

M/H/Mov

HD./100 TON

M/H/Mov

(6)

HD-120 TON

M/H/Mov

HD-180 TON

M/H/Mov

HD. 120 Ton HD. 160 Ton HD.180 Ton Kapasite

Capacity Motor OpedatedMotorlu Motor OpedatedMotorlu Motor OpedatedMotorlu

A (mm) 2500 2500 2550 B (mm) 1000 1000 110 C (mm) 1620 1400 2100 D (mm) 1200 1100 1550 E (mm) 400 350 550 H (mm) 900 900 900 Stroke (mm) 400 400 400 Motor (hp.) 5.5 7.5 10.0 Pompa/Pump (Lt.) 11 15 22

Ağırlık/Weight (kg.)

1300 1300 1600

TEKNİK ÖZELLİKLER / TECHNICAL SPECIFICATION

HİDROLİK ATÖLYE PRESİ

HYDRAULIC WORKSHOP PRESS

Motorlu - Kollu - Gezer Silindirli

Motor - Hand Operated - Movable Cylinder

HD-160 TON

M/H/Mov

(7)

Motorlu - Gezer Silindirli

Motor - Operated, Movable Cylinder

KAPASİTE / CAPACITY (TON) 30 60 80 100-S 100-W 120-S 120-W 160 180 200 250 300 400

A Yükseklik / Height (mm) 2130 2240 2260 2260 2260 2370 2370 2400 2420 2470 2510 3000 3000 B Ayak Boyu / Base Lenght (mm) 850 900 900 1050 1050 1050 1050 1000 1250 1200 1200 1300 1300 C Pres Genişliği / Press Wideness (mm) 1600 1600 1720 1860 2000 2080 2060 1800 2500 2300 2300 2450 2500 D İki Sütun Arası / Between Two Columns (mm) 740 820 920 1010 1200 1010 1200 1100 1550 1300 1300 1400 1400 E İki Sütun Arası (En) / Between Two Columns (Width) (mm) 300 300 300 30 400 300 400 350 550 450 450 550 550 F Sütun En / Column Width (mm) 100 110 110 120 140 120 140 140 140 160 180 300 300 G Sütun Kalınlığı / Column Thickness (mm) 20 25 25 30 30 30 30 30 30 35 35 45 50 H İş Alma Kapasitesi / Working Capacity (mm) 900 900 900 900 900 900 900 900 900 900 900 900 900 Piston Stroku / Piston Stroke (mm) 400 400 400 400 400 400 400 400 400 400 400 400 400 Hidrolik Pompa / Hydraulic Pump (lt) 6,5 3,5 3,5 11 11 11 11 15 22 22 34,5 45 60 Motor Gücü / Motor Power (hp) 3 3 3 5,5 5,5 5,5 5,5 7,5 10 10 15 20 25 Toplam Ağırlığı / Total Weight (kg) 630 705 755 100 1100 1050 1200 1300 1550 2350 2600 3500 4000

HİDROLİK ATÖLYE PRESİ

HYDRAULIC WORKSHOP PRESS

HD-200 TON

M/Mov

HD-100 TON

M/H/Mov

HD-250 TON

M/Mov

(8)

Platine Şase

Plate Chassis

Hidrolik Gezer Silindir

Moving Cylinder by Hydraulic

HD/P-400 TON

M/Hyd. Mov. Cyl.

HD-500 TON

M/Hyd. Mov. Cyl.

HİDROLİK ATÖLYE PRESİ

HYDRAULIC WORKSHOP PRESS

HD-300 TON

KAPASİTE / CAPACITY (TON) 300 400 500 A Yükseklik / Height (mm) 3000 3000 3000 B Ayak Boyu / Base Lenght (mm) 1300 1300 1300 C Pres Genişliği / Press Wideness (mm) 2450 2500 2500 D İki Sütun Arası / Between Two Columns (mm) 1400 1400 1400 E İki Sütun Arası (En) / Between Two Columns (Width) (mm) 550 550 550 F Sütun En / Column Width (mm) 300 300 300 G Sütun Kalınlığı / Column Thickness (mm) 45 50 50 H İş Alma Kapasitesi / Working Capacity (mm) 900 900 900 Piston Stroku / Piston Stroke (mm) 400 400 400 Hidrolik Pompa / Hydraulic Pump (lt) 45 60 80 Motor Gücü / Motor Power (hp) 20 25 30 Toplam Ağırlığı / Total Weight (kg) 3500 4000 5000

(9)

HD-600 TON

M/Hyd. Mov. Cyl.

Hyd. Adjustable Mangle

Hidrolik Gezer Silindir

Moving Cylinder by Hydraulic

ÖZEL TİP ATÖLYE PRESLERİ

SPECIAL TYPE WORKSHOP PRESSES

HD-300 TON

Çift Silindirli ve Tablalı Pres

Double Cylinder Press with Table

HD-200 TON

Atölye Tipi Sıvama Presi

Workshop Type Deep Drawing Press

(10)

HİDROLİK SIVAMA ve ÜTÜLEME PRESİ

HYDRAULIC DEEP DRAWING and SINGLE ACTION PRESS

TİPİ

TYPE

H

300 TON

OTOMATİK ÜTÜLEME PRESİ

AUTOMATIC SINGLE ACTION PRESS

(11)

PLC Control System

Touch Screen

HİDROLİK SIVAMA PRESİ

HYDRAULIC DEEP DRAWİNG PRESS

Table Size

2400 x 1200 mm

Main Stroke

1000 Ton = 800 mm

Cushion Stroke

500 Ton = 250 mm

OTOMATİK / AUTOMATIC

1000 TON

(12)

OTOMATİK PLC KONTROLLÜ ÜTÜLEME PRESİ

AUTOMATIC PLC CONTROL WITH TOUCH SCREEN - SINGLE ACTION PRESS

HİDROLİK KOLONLU PRESS

HYDRAULIC COLUMN PRESS

250 TON

OTOMATİK ÜTÜLEME PRESİ

AUTOMATIC SINGLE ACTION PRESS

200 TON

OTOMATİK SIVAMA PRESİ

(13)

30-150 TON HİDROLİK C - TİPİ PRESS

30-150 TONS HYDRAULIC C - TYPE PRESS

30-150 TON

OTOMATİK BÜKÜM PRESİ

AUTOMATIC BENDING PRESS

30-150 TON

TABLALI OTOMATİK ÜTÜLEME PRESİ

AUTOMATIC with TABLE SINGLE ACTION PRESS

TEKNİK ÖZELLİKLER / TECHNICAL DETAILS

Kapasite / Capacity 30 TON 60 TON 100 TON 150 TON Tabla Ebatı / Table Dimension 500 x 500_{500 x 500} 500 x 500_{500 x 500} 600 x 500_{500 x 500} 800 x 600_{600 x 600}

Motor (hp) 4 4 4 4

Pompa / Pump (Lt.) 12 + 6 15 + 6 22 + 6 33 + 6

Stroke 400 400 400 400

İş alma Yüksekliği / Workings Height 400 400 400 400 Silindir / Cylinder (Ø) 135 175 225 270

(14)

160 TON HİDROLİK BÜKÜM PRESİ

160 TON HYDRAULIC BENDING PRESS

TEKNİK ÖZELLİKLER / TECHNICAL DETAILS Silindir / Cylinder Ø 220 Motor / Motor 4 kw. – 5.5 Hp. Pompa / Pump 11 Litre – Liter Büküm Boyu / Bending Lenght 1200 mm

(15)

200 TON HİDROLİK BÜKÜM PRESİ

200 TON HYDRAULIC BENDING PRESS

OTOMATİK

AUTOMATIC

TEKNİK ÖZELLİKLER / TECHNICAL DETAILS Silindir / Cylinder Ø 200x2 Motor / Motor 11 kw. – 15 Hp. Pompa / Pump 33 Litre – Liter Tandhem Büküm Boyu / Bending Lenght 2000 mm Büküm Kalınlığı / Bending Thickess 7mm

(16)

İŞ MAKİNALARI İÇİN TAMİR & BAKIM EKİPMANLARI

(17)

ÖZEL AMAÇLI SICAK KAUCUK PRESİ

(18)

HİDROLİK HORTUM SIKMA PRESİ

HYDRAULIC HOSE CRIMPING PRESS

Teknik Özellikler / Technical Details

Hortum Sıkma Presi /Hose Crimping Press

HS1

Maksimum Hortum Kalınlığı / Max Hydraulic Hose

2”

Maksimum Sıkma / Max Crimping

105 mm

Sıkma / Saat / Swaging / Hour

650 Kalıp Açıklığı /Dies Opening

+ 22

Standart Voltaj / Standart Voltage

375 – 420 V 3 phrase

Ölçü / Dimension

450 x 650 x 950 mm

Ağırlık / Weight

265 kgs

Teknik Özellikler / Technical Details

Hortum Sıkma Presi

Hose Crimping Press

HS2

Maksimum Hortum Kalınlığı

Max Hydraulic Hose

3”

Maksimum Sıkma

Max Crimping

135 mm

Sıkma / Saat

Swaging / Hour

720 Standart Voltaj

Standart Voltage

375 – 420 V 3 phrase

Ölçü

Dimension

1200x600x1200 mm

Ağırlık

(19)

BRONŞ BASMA VE ÇEKME PRESLERİ

(20)

HİDROLİK SAC DESEN PRESİ

HYDRAULIC SHEET FORMING PRESS

200 TON

OTOMATİK

/ AUTOMATIC

300 TON

MANUEL

/ MOTOR OPERATED

500 TON

OTOMATİK

/ AUTOMATIC

Kapasite / Capacity 200 TON 300 TON 500 TON Tabla Ebatı / Table Dimension 1400 x 500 1400 x 600 1600 x 700

Motor ( hp. ) 10 15 20

Pompa 15 + 55 22 + 65 35 + 75

Stroke 400 400 400

İş alma boyu 400 400 400

Silindir / Cylinder mm. ( Ø ) 2 x 225 2 x 270 2 x 290 OTOMATİK : Çift el veya ayak butonu, Işık Bariyeri, Siviç

(21)

TAM TOTOMATİK ŞERİT TESTERE

FULL AUTOMATIC BAND SAWING MACHINE

SMA-280

OTOMATİK

AUTOMATIC

Ana Motor /Main Motor 4 KW 5.5 HP Sürücü Motor / Driver Motor 0.25 KW Soğutma Suyu Motor / Cooling Water Motor 0.09 KW Hidrolik Pompa / Hydraulic Pump 2.2 LT Lama Kesim Kapasitesi / Flat Cutting Capacity 280 x 300 mm Yuvarlak Kesme Kapasitesi / Round Cutting Capacity 280 mm Kare Kesme Kapasitesi / Square Cutting Capacity 280 x 280 mm Şerit Ölçüsü / Blade Size 3660 x 27 x 0.9 mm Ölçüler / Overall Dimensions 1150x1800x 320 mm (LxWxH)

(22)

Motor /

Motor

5.5 kw.- 7.5 hp

Pompa /

Pump

2.2 Litre

Kesim Kapasitesi /

Cutting Capacity

Ø 500mm

Kesme Açısı /

Angle of Relief

45º - 90º

Şerit Ölçüsü /

Blade Size

5310 mm x 27mm x 0.9mm x

3/4

Ölçüler /

Dimensions

2500mm x 1600mm - 1500mm

En / W Boy / L Yükseklik / H

Ağırlık /

Weight

800 kg

TEKNİK ÖZELLİKLER / TECHNICAL SPESICICATION

YARI

OTOMATİK

SEMİ AUTOMATIC

ŞERİT TESTERE

BAND SAWING MACHINE

(23)

TUZ BASMA PRESİ

SALT PRESS

TUZ

SALT

YAĞ ÇIKARMA PRESİ

OIL EXTRUDING PRESS

ÖZEL AMAÇLI PRESLER

(24)

HİDROLİK PROFİL BÜKÜM PRESİ

HYDRAULIC CAMBERING PRESS

CNC KONTROL SYSTEM

Tonaj - Capacity 250 Ton ( 220 Barda) Pompa - Pump Kt6c-14 Paletli Pompa - Palettice Pump

Motor 22 Kw

İleri Hızı - Forward Speed 9 Mm/sn Geri Dönüş Hızı - Return Speed 23 Mm/sn

Strok - Stroke 900 Mm

İş Alma Kapasitesi - Working Capacity 900 Mm Arka Dayama Boyu - Back Support Lenght 5000mm Dayamalar Elektro Mıknatıs Sistemlidir.

Supports Are With Elctromagnets System .

Dayama Hareketleri Servo Motor İle Sağlanmaktadır.

Moving Of Support Is Provided With Servo Motor

(25)

HURDA BALYA PRESİ

SCRAP BALLING PRESS

(26)

HİDROLİK KOMBİNE MAKAS

HYDRAULIC IRONWORKER

HİDROLİK DELME MAKİNASI

HYDRAULIC PUNCING MACHINE

Otomatik Tutucu

Automatic Holder

HDK-60

(27)

HİDROLİK TUTUCU

HYDRAULIC HOLDER

TEKNİK PARAMETRE/TECHNICAL PARAMETER

Tip/Type HDK-60 HDK-90 HDK-115 HDK-140 HDK-180 HDK-250

Kapasite/Capacity(Ton) 60T 90T 110T 140T 180T 250T

Max. Saç kesim kalınlığı

Max. Shearing Thickness of Steel Plates (mm) 16 20 25 30 40 50

Kesme açısı/Angle of Shearing 7 0 ₈0 ₈0 ₈0 ₈0 ₈0

Lama Kesme Boyu / Flat Bar Catting (H*W) (mm) 16x250 20x330 25x330 30x355 35x400 40x400 Lama Kesme Boyu / Flat Bar Catting (H*W) (mm) 8x400 10x480 16x600 20x600 25x700 30x750

Strok Boyu/Ram Stroke (mm) 80 80 80 80 100 100

Strok Sayısı (dak.)/Number of Stroke (times/min) 6 8 6 8 8 8

Boğaz Derinliği/Throat (mm) 300 355 400 600 600 600

Delme Kalınlığı/Punching Thickness (mm) 16 20 25 28 35 40

Max. - Delme çapı/Max. Diameter of Punching (mm) 25 30 35 38 40 40

Ana Motor gücü/Main Motor Power (kw) 4 5.5 7.5 11 15 18

Dış Ölçüler/Overall Dimension (LxWxH) mm 1650x800x1780 1950x900x1930 2355x980x2100 2680x1060x2380 2770x1240x2350 3000x1440x2450

Ağırlık/Weight (kg) 1900 2600 4800 6800 7500 10800

Profil

Profile Round BarYuvarlak Square BarKöşebent

Eşit Açı/Equal Angle _Profil

Jojst ChannelKanal 900 Lama / 900 Shearing 450 Lama / 450 Shearing

MODEL HDK-60 45 40x40 120x120x12 70x70x8 126x74x5 126x53x5.5 HDK-90 50 45x45 140x140x12 70x70x10 160x86x6 160x60x6.5 HDK-115 60 50x50 160x160x14 80x80x7 200x102x9 200x75x9 HDK-140 65 55x55 180x180x16 80x80x10 280x124x10.5 280x86x11.5 HDK-180 70 60x60 200x200x18 100x100x10 300x126x11 300x89x11.5 HDK-250 80 65x65 200x200x20 120x120x10 320x130x10 320x92x12
