PGS
In
trod
u
ct
io
n
"Value Series" : Best VALUE gaming cases with the highest C/P Ratio (Cost to Performance ratio).
"Professional Series – Red label" : Super tower or Super mid-tower cases with elegant, clean line designs.
"Aluminum – Silver label" : Unique “Full aluminum” cases targeting at power users, professionals and gamers.
"Ultimate Gaming Series – Black label" : Ultimate gaming cases targeting at the extreme gamers. This Series offers gamers with most functions, expandability and Extreme cooling.
"Compact – Blue Label" : Small form factor case series including cube cases, mini-ITX and Mini-Tower
(Micro-ATX). Red
Des
ig
n
Co
n
ce
p
t
Syclone II
After the success of Syclone case, Aerocool is proud to announce the NEW Syclone II case !! The Syclone II case is a "Stylish" design chassis with strong personality. Its "Aggressiveness" is what every gamer looks for in a gaming case !!
This case is solidly constructed in 0.6mm SECC Japanese steel and beautifully finished both inside and out. Not only the chassis is beautifully finished in All Black (both interior and exterior) color, the "PCI covers", "MB Plate",
"Removable HDD cage" and "screw-less kits" are high-lighted in Blue (Syclone II Black) or Red (Syclone II Red) colors to make the case UNIQUE and stands out from the others.The combination of this unique chassis finishing and glossy front panel w/ LEDs give this case a stunning look !!
The Syclone II case is designed with "User-Friendly" concept in mind and it gives gamers great expandability and versatility. Its "Screw-less" features and pre-drilled holes on the Motherboard plate for cable routing make this chassis an easy install. The Pre-drill cable routing holes are also protected by high quality rubber to prevent cable damages from sharp edges. A CPU hole is also pre-drilled on the MB plate for ease of cooler assembly and removable.
This chassis offers great expansion capabilities. It can support 4 x 5 1/4" devices, 1 x 3 1/2" device (external) with converter bracket (included)and 6 x Hard Drives. The chassis is also deep enough to support Long High End VGA cards up to 400mm in length (when the middle HDD cage is removed). With the Middle HDD cage installed, the chassis can support long VGA cards up to
280mm in length.
It maximized airflow with 3 fans including front in-take 14cm fan (included), Back Exhaust 12cm LED fan (included), and a 12cm or 14cm side panel fan (optional). A removable PSU dust filter is included to prevent dust entering your computer.
The Syclone II case is available in BLACK color (Syclone II Black) or BLACK/RED color (Syclone II Red) combination.
Galle
ry
Front Open Back
F
eat
u
res
- High Performance "Mid-Tower" for gamers and enthusiasts.
- Solidly constructed chassis - The chassis is solidly constructed by 0.6mm SECC Japanese
steel
- Unique and Attractive Internal Color Combination - Not only the chassis is beautifully finished in
All Black (both interior and exterior), the PCI covers, MB Plate, Removable HDD cage and
screw-less kits are high-lighted in Blue (Syclone II Black) or Red (Syclone II Red) colors to make the case UNIQUE and stands out from the others.
- High-End Graphic Card Support (up to 400mm) - Supports Longer high-end VGA cards
up to 280mm. The Middle HDD Cage is removable. Once the middle HDD cage is removed , the chassis can support VGA cards up to 400mm.
- High Expandability - Supports 4 x 5.25" external devices, 6 x 3.5" HDDs (internal) and 1 x 3.5"
external device (with the converter) such as a Floppy drive or a Card Reader.
- Ease of Installation - New "Easy-Install" screw-less kits are included for the 5.25" devices and
HDDs. The HDD cage is also rotated 90 degrees for easy installation of HDDs.
- Easy Access Top I/O Ports - 2 x USBs, Audio/Mic (AC 97 + HD audio) and E-SATA ports are
located on the top panel for easy access.
- Smart Cable Management - "Cable routing is pre-drilled on the MB so users can hide cables
behind the MB tray. The pre-drilled holes are also protected by top quality rubber to prevent cuts or damages to the cable from sharp edges".
- Dust Protection - Includes removable bottom PSU dust filters to prevent dust entering your
computer.
- Mesh PCI cover - Includes Blue (Syclone II Black) or Red Metal Mesh PCI covers (Syclone II Red)
for better ventilation.
- Bottom PSU position - the bottom PSU location enables PSUs to suck in cold air and provide
better air flow for your system.
- Water-cooling Support - water-cooling holes are pre-drilled to support water-cooling systems.
- Easy Cooler Assembly - CPU hole is pre-drilled on the MB plate for simple cooler assembly and
removable.
Speci
fi
cat
io
n
s
Spec Cooling System Case Type Material Motherboards Chassis Dimensions Drive Bays Expansion SlotsMax length space available for PCI slots I / O Ports
Rated Voltage
Starting Voltage
Power Consumption
Rated Current
Speed
Air Flow
Air Pressure
Noise
MTBF
: : : : : : : : : : : : : : : : : : Middle Tower SECC 0.6mm ATX & Micro ATX480(H) x 270(W) x 525(D)
4 x 5.25" (External) 、6 x 3.5" (internal) 7 Slots
280/400 mm
2 x USB2.0 / e-SATA / Mic & headphone (AC97 & HD audio)
12V
<=6.0V
4.32W
0.36A
1500 RPM+-10%
96.5 CMF
1.069 mm-H2O
29.6dBA
100000 hours
Front12V
<=9.0V
3.6W
0.30A
1500 RPM+-10%
82.6 CMF
1.273 mm-H2O
26.5dBA
100000 hours
RearA
ir
F
lo
w
Superb airflow - install up to 3 fans !!
1. Front - 1 x 14cm fan (included)
2. Back - 1 x 12cm BLUE LED fan (included) 3. Side - 1 x 12 or 14 cm fan (optional)
In
sid
e
Tool-free for 5.25” bay
HDD Cage is removable
HDD cage fits three HDDs (screwless)
Pre-drilled holes for cable management
"with Rubber protection". Pre-drill pipe holes
for water cooling w/meshed PCI slot "High Quality Mesh PCI Cover"
Filter included to prevent dust from entering PSU
Sufficient depth of chassis for installing long cards (HDD cage removed)
