IMPLEMENTATION OF A RAPTORQ-BASED PROTOCOL FOR PEER TO PEER NETWORK
A Thesis
presented in partial fulfillment of requirements for the degree of Master
in the Electrical Engineering The University of Mississippi
by Yuzhu Bai
Copyright Yuzhu Bai 2015 ALL RIGHTS RESERVED
ABSTRACT
The object of this thesis is to develop and test a Ruby based implementation of the RaptorQP2P protocol. The RaptorQP2P protocol is a novel peer-to-peer protocol based on RaptorQ forward error correction. This protocol facilitates delivery of a single file to a large number of peers. It applies two levels of RaptorQ encoding to the source file before packet transmission. Download completion time using RaptorQP2P was found to be significantly improved comparing to BitTorrent.
We developed a Ruby interface to the Qualcomm proprietary RaptorQ software de-velopment kit library. Then we achieved the two levels of RaptorQ encoding and decoding with the Ruby interface. Our implementation uses 5 threads to implement RaptorQP2P fea-tures. Thread 1 runs as a server to accept the connection requests from new peers. Thread 2 works as a client to connect to other peers. Thread 3 is used for sending data (pieces) and thread 4 is to receive data from neighboring peers. Thread 5 manages the piece map status, the peer list, and choking of a peer.
We first tested communication modules of the implementation. Then we set up scheduled transmission tests to validate the intelligent symbol transmission scheduling de-sign. Finally, we set up a multi-peer network for close to practical tests. We use 5 Raspberry Pi single-board computers to act as 1 seeder and 4 leechers. The seeder has the whole file and delivers the file to the 4 leechers simultaneously. The 4 leechers will also exchange part of the file with each other based on what they have received.
Test results show that our implementation attains all the features of RaptorQP2P: the implementation uses two levels RaptorQ encoding; a peer is able to download a piece from multiple neighbors simultaneously; and a peer can send the received encoded symbols of a piece to other peers even if the peer does not have the full piece yet.
DEDICATION To my family.
ACKNOWLEDGEMENTS
I would like to sincerely thank my advisor, Prof. John N. Daigle, for his profes-sional guidance and enormous patience throughout my graduate study at the University of Mississippi. My grateful appreciations also go to Prof. Feng Wang, Prof. Ramanarayanan Viswanathan, Dr. Xiao Di and Prof. Lei Cao for the many helpful comments and suggestions on my research.
I would like to thank Dr. Xiao Di, Prof. Lei Cao, Prof. Ramanarayanan Viswanathan and my family for supporting me to pursue a degree in Master of Science.
Finally, I am most grateful to my family and all my friends in Oxford, Mississippi for all their help in every way possible. A special gratitude must go to Dr. Xiao Di for his selfless support and invaluable suggestions.
TABLE OF CONTENTS
ABSTRACT . . . ii
DEDICATION . . . iii
ACKNOWLEDGEMENTS . . . iv
LIST OF FIGURES . . . vi
LIST OF TABLES . . . viii
INTRODUCTION . . . 1
RUBY INTERFACE TO RAPTORQ LIBRARIES . . . 5
RAPTORQP2P . . . 23
IMPLEMENTATION OF RAPTORQP2P . . . 27
TEST RESULTS OF RAPTORQP2P . . . 42
CONCLUSION AND FUTURE WORK . . . 48
BIBLIOGRAPHY . . . 49
APPENDICES . . . 52
SOURCE CODES . . . 53
LIST OF FIGURES
2.1 Communication Architecture with RQ Encoder and RQ Decoder . . . 6
2.2 Processing Flow for RQ Encoder and Decoder . . . 6
2.3 Workflow of RQ Encoder Interface Function StringSimpleSend() . . . 10
2.4 Workflow of RQ Decoder Interface Function FileSimpleDecode() . . . 12
2.5 Wrapping the RaptorQ library with SWIG . . . 15
2.6 RQ Encoder Interface Test . . . 16
2.7 RQ Decoder Interface Test . . . 17
2.8 Run Time of RQ Encoder on Raspberry Pi . . . 18
2.9 Run Time of RQ Encoder at Different Symbol Sizes on Raspberry Pi . . . 19
2.10 Run Time of RQ Decoder on Raspberry Pi . . . 20
2.11 Encoded Symbols for Decoding Overhead-Failure Probability Test . . . 21
3.1 Two Level RaptorQ Encoding . . . 25
4.1 Simplified Flowchart of RaptorQP2P . . . 29
4.2 Multi-threading in The Implementation . . . 31
4.3 System Module Structure of RaptorQP2P . . . 32
4.4 Internal Communication. . . 34
4.5 Packet Format . . . 35
4.6 Piecemap Format . . . 36
4.8 Message process. . . 40
5.1 Raspberry Pi . . . 43
5.2 Communication Test. . . 43
5.3 Scheduled Transmission Test. . . 45
LIST OF TABLES
2.1 Essential Functions in RQ Encoder library . . . 7
2.2 Essential Functions in RQ Decoder library . . . 8
CHAPTER 1
INTRODUCTION
The objective of this thesis is to develop and test a Ruby based implementation of RaptorQP2P protocol. The RaptorQP2P protocol is a novel peer-to-peer protocol based on the RaptorQ Forward Error Correction (FEC) for reliable sharing of large files over the Internet [1]. The RaptorQ is a type of fountain code and belongs to the family of Raptor codes [2]. The primary application of RaptorQ is application layer forward error correction (FEC).
In this work, we utilize the Qualcomm proprietary RaptorQ software development kit library (RaptorQ SDK) to achieve RaptorQ encoding and decoding. We developed a collection of C functions that provide access to functions in the RaptorQ library. Then a Ruby interface to the collection of C functions was developed. This combination forms a rapid prototyping kit for implementing RaptorQ based content delivery. Run time for major subcomponents was quantified through a series of tests performed on Mac OS and Raspberry Pi platforms. Test results of RaptorQ library run times and peer to peer file distribution are presented.
The implementation in this thesis facilitates delivery of a single file to a large number of peers. We built a Raspberry Pi based research platform that enables us to
• download and upload data from any peer;
• trace and record data transmitted from any of the peers in the network; and
The remainder of this chapter gives an introduction to RaptorQ FEC and then briefly describes the RaptorQP2P protocol. An outline for the remainder of the thesis is also provided.
1.1 RaptorQ FEC
RaptorQ Forward Error Correction (FEC) belongs to the family of Raptor codes. It is a type of fountain code [3]. Fountain codes are also called rateless erasure codes, and the first practical fountain code is LT codes, which were invented by Luby in 1998 [4].
In a general LT coding scheme, the original file is divided into blocks and each block is then divided into source symbols. Each encoded symbol is generated as a linear combination of source symbols. The number of encoded symbols is theoretically limitless. In the decoding part, the decoder is able to recover the original block when a sufficient number of distinct symbols is received. These symbols can be any set of the generated encoding symbols as long as they are slightly longer in length than the original block [4]. LT codes are proved to be very efficient as the source data grows. That is, the average overhead required to recover source data decreases with increasing block size [5].
Following Luby’s work, Shokrollahi [3] developed Raptor codes as an extension of LT codes. Raptor codes can be viewed as a combination of LT-code and LDPC code [6]. In the Raptor coding scheme, some intermediate symbols are generated from the source symbols by a high-rate LDPC code in the pre-coding stage. These intermediate symbols are then encoded by LT-code. The fountain property of Raptor codes is provided in the LT-coding stage. Raptor codes are proved to outperform LT codes on a wide variety of noisy channels [7].
RaptorQ code is a new variant of Raptor codes. Comparing to standardized Rap-tor codes, RapRap-torQ code has several improvements to the encoding and decoding processes. First, before the intermediate symbols are generated, RaptorQ augments FEC source blocks with additional padding symbols to ensure faster encoding and decoding [6]. Second,
Rap-torQ adopts a two stage pre-coding algorithm (LDPC and HDPC) to generate the inter-mediate symbols. Third, the RaptorQ uses a modified more efficient encoding process in the second encoding step. Finally, the RaptorQ code operates over the finite field GF(256) instead of the standardized Raptor code operating over Galois field GF(2) [3]. All the above features not only offer RaptorQ a better coding performance, but also allow RaptorQ to support larger source symbol block sizes. Specifically, RaptorQ supports up to 56,403 source symbols in a source block, and can generate as many as 16,777,216 encoded symbols for one source block [3].
The RaptorQ code also has a smaller decoding overhead requirement comparing to standardized Raptor codes. For example, the first widely adopted Raptor code, the Raptor 10 code, requires an overhead of 24 to achieve a failure probability of 10−6 while the RaptorQ code ensures a failure probability of less than 10−6 with an overhead of 2 symbols.
1.2 RaptorQP2P
The RaptorQP2P protocol facilitates reliable peer-to-peer sharing of large files over networks [1]. It utilizes two levels of RaptorQ encoding and an intelligent symbol scheduling algorithm to remedy some limitations of the BitTorrent protocol. The RaptorQP2P protocol can be viewed as an extension of the BitTorrent protocol, which was designed by Bram Cohen in 2001. In order to clarify the motivation for RaptorQP2P, we will review BitTorrent first. BitTorrent is a peer-to-peer file sharing protocol that efficiently distributes large files over the Internet. In a traditional client-server protocol, the central server is responsible for delivering all the content to clients (peers). On the contrary, a peer-to-peer protocol enables the transfer of data from one peer to another. Some limitations of the servers and the network can be highly reduced in this way. Besides the peer-to-peer feature, BitTorrent protocol introduced a piece selection strategy to decide what data to request and a peer selection strategy to decide which peers to transfer pieces [8]. The piece selection strategy in BitTorrent begins by selecting pieces at random and then switches to rarest-first. The
peer selection strategy, which is known as tit-for-tat, always unchokes peers with highest data rate every ten seconds. These two strategies guarantee good performance when the network is in steady state. However, in the real world, the peers and the network are always changing. The overall system performance may be significantly less than optimal [1].
With above findings, Su, Wang, Daigle and Shan proposed a novel protocol named RaptorQP2P, which is based on RaptorQ coding, to overcome the limitations of BitTorrent. The RaptorQP2P protocol encodes the source file with two levels of RaptorQ before trans-mission: the file is firstly RaptorQ encoded to generate a group of source blocks and repair blocks, and then each block is RaptorQ encoded to generate source symbols and repair sym-bols. These symbols are then distributed over the Internet. A peer is able to reconstruct a block after collecting enough distinct symbols for the block. When the peer possesses enough distinct blocks, the file can be recovered. By utilizing RaptorQ codes, the RaptorQ protocol allows multiple peers to send symbols (slices) of the same block (piece) to a peer simultaneously. This is a significant advantage over BitTorrent. Moreover, to maximize the utilization of peers’ upload capacities, this protocol also allows opportunistic transmissions, where a peer can send the received encoded symbols of a piece to other peers even if the peer does not have all the slices of that piece. A more detailed description of RaptorQP2P is given in Chapter 3.
1.3 Organization of Thesis
The remainder of this thesis is structured as follows. Chapter 2 introduces the inter-face design and some tests for the RaptorQ libraries from Qualcomm. Chapter 3 gives a brief review of the RaptorQP2P. Chapter 4 describes the practical implementation of this proto-col. Chapter 5 shows test results of the RaptorQP2P implementation. Chapter 6 concludes the thesis with a discussion on the future work.
CHAPTER 2
RUBY INTERFACE TO RAPTORQ LIBRARIES
This chapter provides a thorough discussion of our Ruby interface to the functions of the RaptorQ libraries which were provided by the Qualcomm Technologies, Inc. We begin by describing the Qualcomm RaptorQ software development kit in Section 2.1. In Section 2.2, we explain how the interface was designed for the library. In Section 2.3, we present a series of tests of our interface and the library.
2.1 The RaptorQ Library
The Qualcomm proprietary RaptorQ SDK is a specification-compliant implementa-tion of the RaptorQ code specified in [3]. It consists of a RQ Encoder library and a RQ Decoder library, where each provides functions that enables us to build RaptorQ encod-ing/decoding applications.
Figure 2.1 illustrates a system-level view of communication between the RQ Encoder and RQ Decoder. This architecture is also adopted in our implementation of RaptorQP2P. In this architecture, the sender application retrieves and presents blocks of source data to an RQ Encoder to generate repair data (encoded data). Both the source data and repair data are passed to the sender transport layer for packetizing and transmission. At the receiver end, the receiver transport layer collects the packets and deliver them to the receiver application. When the RQ Decoder receives enough data (whether source or repair), it is able to recover the original source file. The benefit of using RaptorQ FEC in this architecture is that the RaptorQ FEC technology provides packet-level erasure protection against the loss of packets. In the above RaptorQ scheme, the original source file is first divided into a number of source blocks. Each source block is further partitioned into equal-sized source symbols.
Sender Application Sender Transport RaptorQ RQ-Encoder Source Data Receiver Application Receiver Transport RaptorQ RQ-Decoder Recovered Data
Sender Network Receiver
Figure 2.1. Communication Architecture with RQ Encoder and RQ Decoder.
Figure 2.2 shows a typical processing flow of the RQ Encoder and Decoder, which is also adopted in our implementation. The sender application passes source blocks to the RQ En-coder to generate intermediate blocks. The intermediate blocks are to be used to generate repair symbols. When the RQ Decoder have received enough symbols, whether source sym-bols or repair symsym-bols, the original source blocks can be recovered. The Qualcomm RaptorQ SDK provides a series of functions to accomplish the above process. Our interface design is to wrap these functions in such a way that a single call in Ruby script operates the encoding or decoding process. Before discussing the interface design, we will introduce the RQ library first. RQ Decoder RQ Encoder Sender Application Source Block Repair Symbols Generate Intermediate Block RaptorQ RQ-Encoder Generate Repair Symbols Sender Transport Receiver Transport
Source and Repair Symbols with ID Source Block Recover Source Block RaptorQ RQ-Decoder Receiver Application
The RQ Encoder Library consists of 11 functions, but only 7 of them are crucial to fulfill a RaptorQ encoding process. Our interface for the encoder part integrates the 7 functions into one single function StringSimpleSend(). This function takes in the source data as a string and returns encoded symbols. Table 2.1 gives a brief introduction to the 7 functions.
Table 2.1. Essential Functions in RQ Encoder library
Function Purpose
DFRQEnclnit( ) Initialize the working block memory. DFRQEncReset( ) Reset the working block memory.
DFRQEncPrepare( ) Prepare for the generation of an intermediate block.
DFRQEncInitSrcBlock( ) Initialize a source block for the generation of intermediate block.
DFRQEncGenIntermediateBlock( ) Generate an intermediate block. DFRQEncGenRepairSymbols( ) Generate repair symbols.
DFRQEncGetSourceSymbols( ) Produce source symbols.
The RQ Decoder Library consists of 11 functions, whereas 7 of them are crucial to fulfill a RaptorQ decoding process. We also integrated the 7 functions into one single function, named FileSimpleDecode(). This function takes in the received symbols and tries to reconstruct the source data. Table 2.2 briefly introduces these functions.
2.2 Interface Design for the RaptorQ Library
In our implementation of the RaptorQP2P protocol, we achieve the two level Rap-torQ encoding (which is an essential to the RapRap-torQP2P) via the RapRap-torQ libraries. These libraries provide a set of C functions (described in Section 2.1) that enables us to build our own RaptorQ encoding and decoding applications. While Ruby is well known for rapid prototyping, we choose to implement the RaptorQP2P in Ruby.
Table 2.2. Essential Functions in RQ Decoder library
Function Purpose
DFRQDecMemRequest( ) Request the memory needed for decoder op-eration.
DFRQDecInit( ) Initialize the decoder block. DFRQDecReset( ) Reset the decoder block.
DFRQDecAddRcvSymbolIDs( ) Inform the RQ Decoder of the ESIs (Encod-ing Symbol ID) of received symbols.
DFRQDecPrepare( ) Prepare for the reconstruction of a source block.
DFRQDecInitRcvBlock( ) Initialize a receive block for the recovery of a source block.
DFRQDecRecoverSource( ) Recover a source block.
To simplify the prototyping, we developed a collection of C functions that provide access to functions in the RQ library. In the encoding part, function StringSimpleSend() was developed as a full RaptorQ encoding function utilizing the APIs. In the decoding part, function FileSimpleDecode() was developed to achieve the RaptorQ decoding function. We call these two functions Interface Functions. The interface functions are then wrapped by SWIG along with the APIs for Ruby access.
2.2.1 Interface Function Design
The API functions introduced in sections 2.1 contain a number of memory-level op-erations. This makes it complicate if we try to fulfill the RaptorQ encoding and decoding by calling these functions directly from Ruby. Therefore we developed interface functions in C to achieve the full RaptorQ encoding and decoding functions.
The first interface function developed by us is StringSimpleSend(). The formal vari-ables for this function are as follows:
in bytes. The idea is to give the user the freedom to partition the file according to his own objectives.
• Source data pointer. This is a pointer to the input data, namely the source data to be encoded. The source data is a binary string that is passed from another function.
• Data size. This integer-valued variable tells the length of the input string (source data) in bytes. It is essential for function StringSimpleSend() to obtain both the pointer and length of source data because the source data is treated as a binary string, and it can be complicate to find out the length of a binary string in C. Directly passing in the string length helps to simplify the development process.
• Encode ratio. This is an integer-valued variable no less than 100, typically set to be 200, 300, 400, etc. The literal meaning of encode ratio is the percentage protection to be applied to the source data. For example, Encode ratio = 100 stands for a 100% protection where all the output symbols will be source symbols and there is no repair symbols. Encode ratio = 200 means as many repair symbols as source symbols will be generated.
• Output file name. This is a character-valued variable indicating the output file name. The source symbols partitioned from source data will be written into file Output file name.src, and the generated repair symbol will be written into file Output file name.rep.
The work flow of StringSimpleSend() is shown in Figure 2.3. This figure also shows the corresponding API functions that are called in each step. At the very beginning, the pro-gram allocates the working memory and calls DFRQEncInit() to initialize the RQ Encoder. Then the RQ Encoder is reset by DFRQEncReset(). After that, the interface function calls DFRQEncPrepare() and DFRQEncIntSrcBlock() to prepare for and initialize intermediate block generation. When all the preparation jobs are finished, intermediate blocks are gen-erated by DFRQEncGenIntBlock(). Source symbols and repair symbols can be gengen-erated
by DFRQEncRepairSymbols() and DFRQGetSourceSymbols(). When the operation on one block of data is finished, the program moves on to next block if there are any.
RQ ENCODER LIBRARY START Allocate Memory END Initialize RQ Encoder Reset RQ Encoder
Prepare for Intermediate Block Generation
Initialize Source Block Parameters
Generate Intermediate Block
Generate Symbols More Source Blocks? No Same SymbolsPerBlock and SymbolSize? Yes Yes Same Library Mode and
Enough Memory? Yes No No DFRQEncInit DFRQEncReset DFRQEncPrepare DFRQEncInitSrcBlock DFRQEncGenIntBlock DFRQEncRepairSymbols DFRQGetSourceSymbols OR
Figure 2.3. Workflow of RQ Encoder Interface Function StringSimpleSend() (Adopted from Qualcomm RaptorQ RQ Encoder Developer’s Guide).
The decoding interface function developed by us is FileSimpleDecode(). This function tries to recover the original data from a bunch of symbols. The recovered data will be returned in a file after a successful decoding, or the function will return a failure status. The formal variables for this function are as follows:
the encoding process.
• Input file name. This is a character-valued variable. All the incoming symbols will be stored in a binary file in the name of Input file name.
• Output file name. This is also a character-valued variable indicating the output file name of the decoder. The recovered data will be written into file Output file name if the decoding process succeeds.
• File size. This integer-valued variable indicates the size of the original source data. It helps to determine the memory space and number of symbols needed for decoding operation.
• Number of extra symbols. This is an integer-valued variable no less than 0. The number of extra symbols stands for the difference of number of received symbols and the number of original source symbols. If the number of source symbols is k and we received k + 1 symbols, then the number of extra symbols equals 1.
The work flow of FileSimpleDecode() is shown in Figure 2.4. At the beginning, the API function DFRQDecMemRequest() gets memory block sizes so that the program is able to allocate memory. After that DFRQDecInit() initiates and DFRQDecReset() resets the decoder. Then some preparation work is done by DFRQDecPrepare(). The received block parameters is initialized by DFRQDecInitRcvBlock(). When the preparation is finished, the program tries to recover the source block. If the recovery succeeded, the recovered block will be written into an output file. The program moves on to next block if there is any.
2.2.2 Wrapping C Functions with Ruby Using SWIG
We use the software development tool Simplified Wrapper and Interface Generator (SWIG) to generate the interface between Ruby and the C functions. SWIG is a software development tool for building scripting language interfaces to C and C++ programs [9].
RQ DECODER LIBRARY START
Get memory block sizes
END
Allocate Decode, Receive and Temporary Block
Initialize Decoder
Reset Decoder
Add ESIs
Prepare for source block recovery
Initialize receive block parameters
More Source Blocks? No Same erasure pattern? Yes Yes Same Library
Mode and Enough Memory?
Yes
No No
DFRQDecMemRequest()
Recover Source Block Free all blocks
Get new block sizes & Reallocate Temp and Receive Blocks
Yes No
Same Symbol Size?
DFRQDecInit() DFRQDecReset() DFRQDecAddRcvSymbolIDs() DFRQDecPrepare() DFRQDecInitRcvBlock() DFRQDecRecoverSource()
Figure 2.4. Workflow of RQ Decoder Interface Function FileSimpleDecode() (Adopted from Qualcomm RaptorQ RQ Encoder Developer’s Guide).
It can be used to connect programs written in C and C++ with a variety of high-level programming languages, such as Perl, Python, Ruby, and Tcl. In this section, we’ll show the process of wrapping function StringSimpleSend() along with RQ encoder library into dynamic libraries that can be used by Ruby. First we will create our own C library that includes the RQ encoder library, then we make an interface file for SWIG. Finally we will produce desired dynamic library (*.so) with SWIG. The process to wrap the other interface function FileSimpleDecode() is similar. With the help of SWIG, we are able to call the C functions directly from a Ruby script as long as the generated dynamic library is required. The detailed steps are as follows:
Step 1 Create the C library.
