CHAPTER 1
Internal Combustion Systems
1.1 Car Engines
Modern car industry uses mainly internal combustion engines. The reason for calling them this is fuel combustion taking place in the engine cylinder. The car industry meets the 21st century with a wide variety of design solutions for the internal combustion engines. This diversification could be classified on the basis of some basic principles listed underneath: Based on the type of fuel used engines could be [1]:
• petrol type
• diesel fuel type (Fig.1) • liquid gas type engines;
• There are some internal combustion engines using other types of fuel but they are not found so often. These are some special purpose cars (like sports cars, for example) that are uniquely manufactured.
Based on operation principle [2]:
• Four-stroke engines. The characteristic feature for them is that their operation cycle involves four strokes (Fig.2). First stroke (admission) – the air-fuel mixture enters the cylinder. Second stroke (compression) – the piston compresses the air-fuel mixture through its motion. Third stroke (combustion) – the air-fuel mixture ignites and combusts thus moving the piston and this is the only stroke in the cycle performing work. Fourth stroke (release) - the exhaust gas is released [2].
• Two-stroke engines (Fig.3) [3]. First
stroke – admission of fresh gas into the cylinder from carburetor and simultaneous compression of the gas mixture in the area above the piston. Second stroke - pre-compression of fresh gas in the crankcase and combustion of gas mixture in the cylinder. Exhaust gases are released and fresh gas enters the combustion section from the crankcase through overflow ducts [3].
The two-stroke type of engine with its gas-distribution mechanism is cheaper to produce and easier to maintain compared to the four-stroke type. Engine lubrication is very simplified and still reliable as oil is mixed with the fuel. This saves power and additional fuel consumption needed to drive supplementary systems – lubrication and gas-distribution mechanisms. Besides, the two-stroke type features more uniform torque as a combustion stroke is performed for each turn of the crankshaft [3]. The disadvantages of the two-stroke type of engine are the inevitable losses of scavenging leading to power reduction and higher fuel consumption. Incomplete combustion results in higher harmful emissions in exhaust gases. This type of
engines have higher average temperature in the cylinder due to the higher number of combustion strokes. The two-stroke type of engine is incapable of providing efficiencies similar to those of the four-stroke one as the latter has time available for one complete piston stroke during cylinder charging and discharging, which helps achieve better completeness of the two processes [3].
Based on the number of cylinders used the engines are 1, 2, 3, 4, 6, 8 and 12-cylinder type.
Based on the location of the cylinders:
• In-line engines – cylinders are vertically positioned in a line (Fig. 4,I);
• Box engines – cylinders are horizontally positioned one against the other (Fig. 4,II);
• V-type engines – cylinders are positioned at an angle and
Fig. 2
Fig. 3
mounted on a common crankshaft (Fig. 4, III).
Based on the piston movement in the cylinder engines are [4]: • Reciprocating piston engines (Fig. 5);
• Rotary piston engines – Vankel engines (Fig. 6);
The following classification could be made from thermodynamics point of view:
• Constant volume internal combustion engine v = const. This is known in practice as a carburetor type of engine (or Otto’s engine) [5]. Combustion is instantaneous and has explosive nature when v = const.;
• Constant pressure p = const. internal combustion engine. This is the engine of R.Diesel. Combustion is performed under relatively constant pressure and a portion of fuel is constantly admitted until the end of this stroke under high pressure [6];
• Constant volume and constant pressure internal combustion engine (v = const. and p = const.).
Efficiency is the parameter featuring the effectiveness of engine energy transformation. When considering internal combustion engines as heat machines, the thermal efficiency best characterizes the differences between various engine types from thermodynamics point of view. The thermal efficiency (ηt) of an internal combustion engine at v = const. (carburetor type engine) is as follows [6]:
η
εκ
t = −1 1−1, where
ε - is the extent of compression, κ = c
c
p v
is adiabatic parameter,
cp = volume specific heat capacity at p = const, cv = volume specific heat capacity at v = const.
It could be seen from the above formula that efficiency increases with the increase of the extent of combustion.
η ρ κε ρ κ κ t = − − − − 1 1 1 1( ), where:
ρ - is the degree of pre-expansion.
When we analyse this formula we could see that efficiency increases when the extent of compression increases or when the degree of pre-expansion decreases.
So far, we have only considered thermal efficiency but we should point out that the overall efficiency of an internal combustion engine is the product of its thermal efficiency and mechanical efficiency (considering friction losses) [6]:
η = ηt . ηmech .
The following advantages of the diesel type of engines could be pointed out when comparing them to the carburetor type [7]:
- Lower fuel consumption determined by the higher degree of compression; - Diesel engines have higher efficiency;
- Diesel fuel is cheaper than petrol;
- The risk of fire is lower due to the higher ignition temperature of the diesel fuel; - Exhaust gases of diesel engines are less toxic compared to those of carburetor
engines;
and the following disadvantages:
- Diesel engines are heavier than carburetor ones. Their components are larger due to the high forces involved;
- The cost of production and repair of diesel engines is higher due to the complicated and precise combustion mechanism;
- Diesel engines are noisier.
To give a better idea of the advantages and disadvantages of both types of engines I would like to consider the types of fuel they use.
1.2. Carburetor type engine fuel
In order for a certain fuel to be suitable for carburetor engines it is necessary that it has such steam pressure (good evaporation characteristics, low boiling temperature) that it completely evaporates in the volume of air provided for combustion even at the lowest operation environment temperature.
The basic part of fuels suitable for carburetor type of engines is produced from petroleum by means of direct distillation of respective light fractions or by cracking heavier and less deficient fractions. The formation of double bonds in the cracking process follows a certain regularity, which depends on the depth of hydrocarbon braking. Along with this, some reactions take place, which transform unsaturated hydrocarbons into other more stable cyclic compounds [7]. CH3 CH2 -3H 2 CH2 CH2 CH2 CH CH CH2 CH = CH2 CH2 CH
Thus, some valuable for petrol composition compounds are produced – naphthenic and aromatic hydrocarbons.
The liquid products from the cracking process are subjected to fraction distillation to extract petrol. The residue containing heavier hydrocarbons, resins, etc, compounds is usually burned out or added to heavy diesel fuel. The petrol fractions practically contain no resins and the acid and sulphur content in them is relatively low. Catalytic cracking and reforming processes could produce even purer petrol fractions [8].
1.3. Diesel engines fuels
The diesel fuel is ignited in the chamber by the air heated in the compression so of major importance here is its lowest ignition temperature (self-ignition temperature). Low-boiling point fuels like petrol and kerosene are not suitable for this purpose. Gas oil fractions proved to be the most suitable fuel for diesel engines [8]. Actually, diesel engines have been developed working on heavier petroleum fractions – even with tail fractions. From all fuel properties surface resistance and especially viscosity are the most important for the degree of dispersion. The speed of combustion in diesel engines and from this, the degree of combustion could be increased by means of additives. Known as positive catalysts are naphthenates of some metals – barium, copper (Cu). It should be noted here that the presence of water and hard impurities in diesel fuel results in more intensive wear in the combustion system [8].
Considering all said above we should mention some ecological aspects of petrol and diesel fuel usage. The share of contamination caused by car engines where fuel combustion is incomplete in the global ecological problem is fairly large. Various toxic substances are concentrated in the exhaust gases of internal combustion engines and these could be classified into the following sequence depending on the degree of their harmful effect on human health [9]:
Carbon oxide (CO), hydrocarbons, nitrogen oxides, cancerous substances, soot, lead compounds and sulphur dioxide (SO2).
While petrol engines produce highly poisonous carbon oxide, diesel engines are significantly better as they operate on excessive air and burn our fuel in a more perfect way. Carbon oxide could cause lasting damages even when in insignificant quantities (0.5% by volume) and in larger concentrations could even cause death. Soot is mainly produced from diesel engines with malfunctioning spraying systems [9]. Sulphur compounds are also produced as a result of diesel fuel combustion. Lead compounds are released in environment with the exhaust gases of some carburetor type fuels the octane number of which has been increased using ethylization with lead tetraethyl [9].
The operational performance of the engine significantly affects the toxic content of the exhaust gases. Design imperfections result in incomplete combustion and hence, increased harmful emissions. It is impossible to counteract to all harmful substances in exhaust gases to an adequate degree but still, a number of efficient methods have been developed to significantly reduce mainly carbon oxide and hydrocarbon additions content in air [9].
In pursuit of eliminating harmful emissions in exhaust gases resulted in the wide usage of unleaded petrol and catalysts. The four-stroke engines taking over the two-stroke ones also resulted in improved environmental parameters.
selected materials are making better use of the principles of modern design considering ecological requirements, recycling possibilities, etc.
The basic parameters of internal combustion engines are engine stroke (displacement) capacity, degree of compression, engine power and the type of fuel used [10].
An important feature of an engine is its so-called stroke (displacement) capacity [11]. This is equal to the product of the piston area, its stroke and the number of cylinders.
The degree of compression is another parameter that characterizes the engine. This is determined by dividing the overall cylinder volume by the volume of combustion chamber [12].
Engine power is the work the engine performs per unit time.
Car design engineers have always tried to get the highest possible efficiency from an engine [12]. This determines the variety of technical and technological solutions being searched for in the following basic areas [13]:
• Increasing the degree of compression – this is the most often used parameter to influence engine efficiency;
• Reducing the degree of pre-expansion – used to influence efficiency of diesel engines;
• Improvement of intake during the admission stroke – this is influenced using the following factors:
- low cylinder temperature; - good cooling;
- low mixture temperature ensuring intake of larger quantities (mass) of it; - low rarification (vacuum) in the intake stroke (absence of throttling); - low residual exhaust gases pressure [14].
• Special design of the combustion chamber – a wide variety of shape exists;
• M-process by MAN - in diesel engines engineers are considering not the classical uniform fuel distribution (which along with heat and pressure is a reason for transforming part of the fuel into soot), but spraying that forms a thin layer along the spherical combustion chamber in the piston [14].
References
1. C.D. Rakopoulos, E.G. Giakoumis, Second-law analyses applied to internal combustion engines operation. Progress in Energy and Combustion Science, Volume 32, Issue 1, 2006, Pages 2-47.
2. Sebastian Verhelst, Thomas Wallner, Hydrogen-fueled internal combustion engines. Progress in Energy and Combustion Science, Volume 35, Issue 6, December 2009, Pages 490-527.
Pages 153-159.
4. G. De Nicolao, C. Rossi, R. Scattolini, M. Suffritti, Identification and idle speed control of internal combustion engines. Control Engineering Practice, Volume 7, Issue 9, September 1999, Pages 1061-1069.
5. F. Payri, J.M. Luján, J. Martín, A. Abbad, Digital signal processing of in-cylinder pressure for combustion diagnosis of internal combustion engines. Mechanical Systems and Signal Processing, Volume 24, Issue 6, August 2010, Pages 1767-1784.
6. A.K. Sen, G. Litak, C.E.A. Finney, C.S. Daw, R.M. Wagner, Analysis of heat release dynamics in an internal combustion engine using multifractals and wavelets. Applied Energy, Volume 87, Issue 5, May 2010, Pages 1736-1743.
7. Zhichao Tan, Rolf D. Reitz, An ignition and combustion model based on the level-set method for spark ignition engine multidimensional modelling. Combustion and Flame, Volume 145, Issues 1-2, April 2006, Pages 1-15.
8. J. I. Ramos, Comparisons between thermodynamic and one-dimensional combustion models of spark-ignition engines. Applied Mathematical Modelling, Volume 10, Issue 6, December 1986, Pages 409-422.
9. Alex M.K.P. Taylor, Science review of internal combustion engines. Energy Policy, Volume 36, Issue 12, December 2008, Pages 4657-4667.
10. V. S. S. Chan, J. T. Turner, Velocity measurement inside a motored internal combustion engine using three-component laser Doppler anemometry. Optics & Laser Technology, Volume 32, Issues 7-8, October 2000, Pages 557-566.
11. F. Payri, J. Benajes, F. V. Tinaut, A phenomenological combustion model for direct-injection, compression-ignition engines. Applied Mathematical Modelling, Volume 12, Issue 3, June 1988, Pages 293-304.
12. Zissimos P. Mourelatos, A crankshaft system model for structural dynamic analysis of internal combustion engines. Computers & Structures, Volume 79, Issues 20-21, August 2001, Pages 2009-2027.
13. S. Richard, O. Colin, O. Vermorel, A. Benkenida, C. Angelberger, D. Veynante, Towards large eddy simulation of combustion in spark ignition engines. Proceedings of the Combustion Institute, Volume 31, Issue 2, January 2007, Pages 3059-3066.
14. Ugur Kesgin, Study on the design of inlet and exhaust system of a stationary internal combustion engine. Energy Conversion and Management, Volume 46, Issues 13-14, August 2005, Pages 2258-2287.
CHAPTER 2
Spark Plug Material Selection & Manufacturing
2.1 Electric spark ignition of combustion mixture
2.1.1 Spark plug breakdown voltage
An electrical spark past the spark plug electrodes ignites the combustion mixture in the cylinders of carburettor and gas engines and petrol-injection engines. When voltage is applied to the plug electrodes a negative ion and electron flow directed towards the negative electrode is being created in the gas and combustion vapours area between the electrodes. The so-called “glow discharge” occurs between the electrodes of the spark plug [1].
When the applied voltage is increased this increases the speed of moving ions and electrons. Under certain voltage the speed of ions and electrons and their kinetic energy reaches such high values that when they hit neutral molecules they break them [1]. The result is collision ionization. Collision ionization builds up as an avalanche and a breakdown of the gas gap occurs – the spark plug electrodes are connected by a continuous ion and electron flow. The result is the occurrence of so-called spark discharge between plug electrodes.
Heat is emitted when ions and electrons hit neutral molecules. The gaseous shell of the ion and electron flow heats up and expands abruptly thus causing light and sound effects [1]. The voltage causing a sparkle to pass between the plug electrodes is called breakdown voltage.
The breakdown voltage depends on the spark gap, the temperature and pressure of the combustion mixture in the cylinder, on the shape, polarity, material and temperature of electrodes and also on engine characteristics and operation conditions [2].
There is an almost linear relation between breakdown voltage and spark gap.
The influence of electrode polarity over breakdown voltage is as high as is the difference in shape between electrodes and their temperature. The breakdown voltage could be 10 to 15% higher for a positive polarity of the central electrode than for a negative polarity [2].
To reduce breakdown voltage the spark plug electrodes should be made sharp but they easily burn at such shape. So the most suitable shape for electrodes is the cylindrical shape with flat ends, as these would burn significantly less [2].
- When the temperature of the central electrode of a spark plug is increased the breakdown voltage decreases.
- When the temperature of the gas between plugs electrodes is increased the ionisation increases and the breakdown voltage decreases.
- The pressure in the cylinder has the opposite effect. When pressure is increased the gas density is also increased and breakdown voltage increases.
When the engine is initially started the walls of the cylinder and spark plugs are cold. The combustion mixture has low temperature, too. So the breakdown voltage would be higher when the engine is initially started.
As engine speed increases the breakdown voltage is reduced as the mixture temperature and the temperature of the central plug electrode increase with the increase of rotation frequency. The wider the throttle valve is opened the larger the quantity of fresh combustion mixture is and the higher the pressure at compression end would be. The breakdown voltage is higher [3]. But as the quantity of fresh combustion mixture increases the pressure increases, too as is the temperature of the mixture and of spark plug electrodes. The influence of temperature in some engines is so significant that breakdown voltage for some speed conditions is higher for a fully open throttle valve than it is for a partially open throttle valve [3].
The breakdown voltage increases when the mixture is being concatenated or enriched. Engines work efficiently with lean mixtures. Lean mixtures are harder to ignite. To ensure their ignition the spark gap of the spark plug should be increased from 0.6 - 0.7 mm to 0.8 – 0.9 mm. This additionally increases the breakdown voltage [4].
The lowest necessary voltage that should be applied by the ignition system to spark plug electrodes is equal to the highest breakdown voltage. Table 1 shows the voltage for which the strikes of the ignition system should be calculated for a spark gap of 1mm [4].
Engine parameters Breakdown voltage
Degree of compression
Max. rotation
frequency In operation mode n = 1000 – 1500 n = 150 – 200 In start mode
7 - 7,5 8 – 8,5 4000- 4500 5000 12000 – 14000 13000 – 15000 16000 – 18000 18000 – 20000
With a spark gap of the spark plug of 0.6 – 0.7mm and a moderate degree of compression the minimum voltage necessary would be 11000 - 12000 V.
With normally operating warmed up engines the mixture temperature at the moment of applying the spark would be close to the self-ignition temperature. This is why only a negligible amount of electrical spark energy (1 – 5 MJ) would be sufficient to ignite the mixture. The ignition system of modern engines provides sparks of significantly higher energy (15- 50) mJ [4].
2.1.2 Moment of applying the spark
The combustion mixture in engine cylinders does not burn immediately but takes some time (several milliseconds). An engine would have the highest power and saving when the mixture burns out at the smallest possible volume, i.e. when the piston is close to the top dead centre This is achieved by igniting the combustion mixture earlier, before the piston moves to the top dead centre the burning out of the mixture starts before the top dead centre and ends after the top dead centre, i.e. this is performed at the smallest possible volume and lowest possible heat loss, respectively [4].
The moment of ignition is determined by the angle between the position of the engine crankshaft at the moment of applying the spark between the spark plug electrodes and the position of the same crankshaft when the piston is in the top dead centre. This angle is called angle of advance ignition.
When the ignition is too short the mixture burns out mainly during the expansion and could sometimes continue even during the release cycle. Due to the fact that the mixture burns in a larger volume, i.e. with a larger available cooling surface, heat losses are significant. The engine is less powerful and overheats [5].
When the ignition is too early the mixture burns out mainly before the top dead centre the pressure in the cylinder reaches its maximum before the piston is in its top dead centre– thus the piston is subjected to strong counter impacts and large negative work is performed. The engine overheats and is less powerful. External signs for too early ignition are the characteristic metal knocking due to the counter impacts and engine overheating.
The optimum advance angle of ignition depends on a number of factors [5]:
A. Rotation frequency of the engine. As rotation frequency of the engine increases the turbulence of the combustion mixture becomes more intensive and burning is speeded up but the increased burning speed could not compensate for the reduced time during which the piston moves close to the top dead centre. The higher the rotation frequency is the earlier should the spark be applied so burning is performed close to the top dead centre in the smallest possible volume, i.e. with minimum loss.
It is necessary to maintain the angle of advance of ignition with respect to the engine rotation frequency. A special regulator, usually a centrifugal type, ensures this.
B. Engine load. As the load on the engine increases the throttle valve opens wider, the quantity of combustion mixture increases and the mixture temperature and pressure increase in the end of compression. When the quantity of combustion mixture is higher its contamination with burnt gases is lower. The higher the temperature and pressure at the moment of ignition and the purer the mixture is, the higher would the burning speed be and the smaller the optimum angle of advance of ignition. It is necessary to have the angle of advance ignition to correspond to the load of the engine. A vacuum regulator accomplishes this.
C. Detonation. Detonation is burning the mixture at abnormally high speed. The occurrence of detonation is determined by fuel and combustion mixture quality, temperature, pressure and the duration of temperature and pressure applied to the combustion mixture. A measure of the anti-detonation resistance of fuel is its octane number.
At larger angle of advance of ignition the mixture burns out at increasing temperature and pressure in the cylinder and this creates favourable conditions for detonation. A limit angle of advance of ignition exists for each individual engine operation condition and certain time (octane number) and when this limit is exceeded detonation results [6].
The signs for detonation during engine operation are the metallic hammering, overheating, black smoke, reduction in power and saving. It is not recommended to run an engine with detonation for a long time [6]. Detonation could be avoided by reducing the angle of advance of ignition. A special device called octane corrector accomplishes this.
2.1.3 Spark plug arrangement
Modern spark plugs are non-dismountable. They comprise a steel shell, washers, insulator, stem, central electrode and side electrode [7].
The steel shell 1 is threaded in its bottom end to allow screwing to a cylinder head. A bended side electrode 6 is attached to the shell. The insulator 3 is positioned within the shell. Two
steel stem 4 is positioned in the insulator and the stem is threaded in its upper end to match the terminal nut and ends in the central electrode in its bottom end. The high voltage wire from the rectifier is connected by means of the terminal nut to the stem [7]. The high voltage is transmitted via the stem to the central electrode and if it is sufficient to break down the spark gap a spark is passed between the electrodes, which ignites the combustion mixture in the cylinder.
The dismountable spark plug is only different in that the insulator is fastened to the shell by means of a nut. When the nut is unscrewed the insulator could be removed from the shell to be cleaned or exchanged when damaged [7].
The spark plug is subjected to extremely heavy conditions during engine operation. It is subjected to mechanical, heat and electrical load and chemically active substances.
The bottom end of the spark plug contacts gases of various temperatures depending on the process taking place in the cylinder. During filling the temperature of the combustion mixture is 323-353 K and at the end of combustion gas temperature reaches 2500 K and more.
The spark plug possesses certain heat inertia and its bottom end temperature could not be varied with the variation in gases temperature in the cylinder for one cycle. As the average temperature of the gases in the cylinder for one operation cycle is significant the spark plug heats up considerably and a certain average temperature is maintained in each point. The larger portion of heat transmitted by the gasses in the cylinder to the insulator is discharged via the copper washers to the shell and from there, to the cylinder head and cooling medium and the remaining heat – via the insulator and shell into the environment. Fig. 1 shows heat flows through the spark plug (temperatures are in °C) [7]. The bottom end temperature of the insulator depends on a number of factors: temperature of gases in the cylinder; frequency of operation cycles; design of cylinder head and the position of the spark plug; the
surface area of the bottom shell of the insulator, the design and number of side electrodes; the heat conductivity of individual components; cooling conditions of the spark plug, etc.
Insulator bottom end temperature and central electrode temperature reach 773-1073 K. The side electrode heats less than that as the heat from it is directly transferred to the shell. The shell of the plug heats only slightly to 393 - 423 K for liquid cooling and 498 – 523 K for air-cooling of the engine.
Some rather active gases and substances are contained in the combustion products like ozone, oxygen, carbon oxide, sulphur and lead oxides that may cause corrosion on plug electrodes. During spark plug operation electrodes are subjected to the so-called electrical erosion – wear caused by the electrical spark [7].
The heavy duty operating conditions of the spark plug place high requirements for the construction and material of individual components and manufacturing techniques.
2.1.4 Electrodes
The material selected for electrodes should be resistant to gas corrosion and electrical erosion under high temperature conditions. The heat expansion coefficient of the central electrode should be close to that of the insulator to avoid any local mechanical overstress. The side electrodes material should not be brittle so they do not break during adjustments of sparkling gap.
Electrodes are usually manufactured of nickel-manganese alloys (97%-95% Ni, 3-5% Mn). This alloy has high melting temperature (1723 K), it is corrosion resistant when working with un-ethylized fuel and does not require specifically high breakdown voltage. Under high temperature nickel ionizes the spark gap and thus reduces necessary breakdown voltage [8]. Chrome-titanium steel could also be used to manufacture spark plug electrodes. Such electrodes have better corrosion resistance than nickel ones but they require higher breakdown voltage.
The number of side electrodes could be one to four. When a higher number of side electrodes are adopted the spark passes through the smallest spark gap. When the given side electrode burns and the spark gap is thus increased, the spark shifts to another electrode. This way the spark moves around all electrodes in sequence and one does not need to adjust spark gap so often. The larger number of side electrodes facilitates spark plug scale deposition.
Electrode polarity influences spark plug durability. The anode arch temperature is higher than cathode temperature. The side electrode cools better. When this is anode the operating conditions of the two electrodes are almost similar and their enrichment is reduced.
The spark gap of spark plugs in ordinary engines is 0.6 – 0.7mm. For engines with very high degree of compression to reduce breakdown voltage this value is 0.4 – 0.6 [8].
In small spark gaps the ignition capabilities of the spark are reduced and also there is a risk of clogging it with deposited scale.
When the spark gap is large the breakdown voltage is high and this creates harder operation conditions for the induction coil, high-voltage cables and spark plug insulator.
2.1.5 Insulator
The insulator is the most heavily loaded component in the spark plug mechanically, thermally and electrically. The material chosen for the insulator should have high mechanical and electrical strength under both low and high temperatures; high heat conductibility; it should not react with the products of combustion and should preserve its crystal structure under high temperatures.
The insulator should be capable of withstanding a voltage of 15000 – 20000 V with no surface discharge rupture. Moreover, it should have high electrical resistance to allow only minimum current flow [8].
Spark plug insulators are usually manufactured of ceramic materials. These have very good heat conductance, high electrical and mechanical strength.
For widely used engines operating under moderate temperature conditions spark plugs with ceramic material insulators are usually used containing 76% Al2O3, called uralite.
For high-duty engines (with high degree of compression and heavy temperature conditions) spark plugs with ceramic insulators containing 90-98% Al2O3 are used (sinter corundum, crystal corundum, sintox, corundite, etc.)
2.1.6 Shell
The shell is threaded and has a hex head provided for wrench, which allows the spark plug to be screwed to the cylinder head. The car engine spark plugs have M18x1.5 and M14x1.25 threads [9]. The smaller diameter spark plugs are smaller in size and it is easier to find a place for them when designing the engine it takes less time for the to heat up to operation temperature thus reducing the chance of engaging them at engine start up. But when the spark plug is smaller the walls of the insulator are thinner and higher requirements are placed for the material.
2.1.7 Shield
Shielded ignition systems involve shielded spark plugs. The external part of the insulator of such plugs is positioned within a shield. Shielded cables should be used to connect to shielded spark plugs [9].
2.2 Spark Plug Thermal Characteristics
It has been established through trials that carburettor engine could operate normally without interruption provided that the temperature of the bottom end of the insulator and the central electrode in the spark plug is within 850 – 1300K [9]. At temperatures lower than 850 K the oil getting into the insulator does not burn but only the light fractions evaporate leaving a thick resinous mass – scale, which is deposited on the spark plug. The scale thus shunts the spark gap in the plug, creates energy loss and reduces the voltage applied to the electrodes. At temperatures higher than 850K the oil getting into the spark plug burns out completely. The combustion products are dry and they sputter and are blown outside during release – the spark plug is self-cleaned.
But at temperatures higher than 1130K the spark plug causes advance ignition of the mixture – the mixture is ignited by its contact with the strongly heated bottom insulator end and central electrode before the spark is applied. The engine overheats and is reduced in power due to advance ignition of the mixture [9]. A sign of advance ignition is the white colour of the bottom part of the insulator and the presence of melted material spots from the insulator and electrode. The temperature of the bottom end of the insulator depends on the heat flow of heated gases to the insulator and its release into the cooling medium and ambient air.
pressure or frequency of rotation) the higher the heat released in the cylinder per unit time and the better should heat release in the spark plug be.
The quantity of heat transferred to the insulator depends on the insulator –burnt gases contact surface and the distance between the insulator and the shell. Varying these values and using materials of various heat conductances to make the insulator, the central electrode, stem and washers, as well as varying the cross section of the latter could produce spark plugs of various heat characteristics. As the length of the bottom end of the insulator determines to a large extend the insulator and burnt gases contact surface area, it is also used to determine the heat characteristics of spark plugs. The longer the bottom parts of the insulator, the higher the heating of the spark plug would be at identical other conditions and the “warmer” it is going to be.
The so-called heat number determines the thermal characteristics of spark plugs. The heat number is the time in hundreds of a minute after which the spark plug screwed to a special engine operating under certain conditions starts to apply advance ignition of the mixture. Spark plugs with heat numbers from 100 to 500 are available. The higher the heat number of a spark plug, the “colder” it is going to be [10].
The high heat number (225 – 500) spark plugs are intended for highly accelerated engines with high degree of compression. The mass used spark plugs in engines have 100 – 225 heat number.
The correct choice of heat number is rather significant for the normal operation of spark plugs and engines. For new types for engines the spark plugs are selected after trials by installing various thermal characteristics spark plugs and measuring the temperature of the central electrode. If a given plug refuses to operate due to the scale deposited over it this means it is too “cold” and if it causes advance ignition – it is too “hot” for the selected engine. When the correct heat number has been selected the engine would operate under all conditions without interruptions and without any advance ignitions [10].
The correct spark plugs for a certain engines should be selected considering their thermal characteristics and thread length. When the spark plug is screwed in the face of its shell should be aligned with the combustion chamber surface – only the electrodes should show in the combustion chamber.
The spark plugs should have the thermal characteristics given in the engine manufacturer’s leaflet. The spark plugs recommended by the manufacturer could be exchanged for “colder” or “warmer” plugs if needed for the operation conditions.
2.3 Manufacture
2.3.1 Body shell manufacture
Manufacturing of certain products is determined by the selected materials, design requirements (precision, surface roughness, shape deviations, surface deviation, heat treatment, etc.) and last but not least by the scale of production.
Considering performance requirements for the body shell of
N F =
τ
spark plugs, the scale of production and allowed expenses for production and materials we could make the following conclusions [10]:
- With respect to operating temperature conditions the body shell is subjected to 350°C. - No special precision requirements are claimed;
- A production scale of 10000000 pieces per year is a fairly large volume, which determines the nature of our particular production as mass production;
- The mass nature of production implies minimum waste technologies and maximum cut time of action. This immediately makes turning operation inefficient;
- We determine production cycle for mass type of production by the following formula:
, where
F - is the actual annual working time fund
N = 10 000 000 pieces – the annual production scale
F = 359424 min for 260 working days, three-shift production and 4% time for scheduled
maintenance.
r = 0,0359 min = 2.16 sec
Above cycle value shows that a ready spark plug should be produced every 2.16 seconds. When selecting materials for each spark plug component one should observe the linear expansion coefficient and the character of this expansion (how it would affect the distance between electrodes). The difference in heat accumulation of each component in various areas should also be considered.
Considering the mass nature of production we could suggest to use the cold die forming (pressing) method for manufacturing the spark plug body shell. Thread cutting should better be made by cold rolling [10].
The advantages of forming methods described above are the following [11]: - Lack of waste – complete usage of material
- Provide higher production efficiency - Improve the structure of material - Surface quality is fairly good - Good dimension precision
- Internal stress distribution in the material is more uniform and without any high concentration areas
Considering described methods of plastic deformation most suitable material is low-carbon steel with up to 0.08% carbon content (Ferritic steel). It is suitable for cold die forming and deep drawing. The material is also attractive in cost. This type of steel also satisfies all functional requirements for spark plug body shell.
- Withstand discharge voltages of up to 15000 – 20000V with no surface rupture; - Have high electrical resistance so the current flow through it is the minimum; - Withstand high mechanical loads;
- Have high heat conductivity; - Not react with combustion products
- Not change its crystal structure under high temperature.
Several ceramic materials comply with these requirements. The material, which could be used to manufacture the spark plug insulator is the ceramic material uralite containing 76% Al2O3. Ceramic materials containing 90-98% Al2O3 (sinter-corundum, crystal corundum, sintox, corundite, borrum -corundum, etc.). Suitable machines to be used for forming the insulator are isostatic presses [11]. The manufacture of spark plug insulator with its central electrode and terminal post could be performed in two ways [12]:
- manufacturing the insulator separate from the central electrode and terminal post; - manufacturing the insulator complete with the central electrode and terminal post. The exact method to be applied would depend on the developed spark plug design and available know-how. The present matter does not make any commitment to the exactly point out the material trademark for producing the spark plug body shell and insulator. To be able to provide this information we will need to know design details, design [12].
References
1. C.D. Rakopoulos, E.G. Giakoumis, Second-law analyses applied to internal combustion engines operation. Progress in Energy and Combustion Science, Volume 32, Issue 1, 2006, Pages 2-47.
2. D. Steiner, H. Burtscher, H. Gross, Structure and disposition of particles from a spark-ignition engine. Atmospheric Environment. Part A. General Topics, Volume 26, Issue 6, April 1992, Pages 997-1003.
3. Epaminondas Mastorakos, Ignition of turbulent non-premixed flames. Progress in Energy and Combustion Science, Volume 35, Issue 1, February 2009, Pages 57-97. 4. Seiichiro Kumagai, Tadami Sakai, Ignition of gases by high-energy sparks. Symposium
(International) on Combustion, Volume 11, Issue 1, 1967, Pages 995-1001.
5. J. D. Dale, M. D. Checkel, P. R. Smy, Application of high energy ignition systems to engines. Progress in Energy and Combustion Science, Volume 23, Issues 5-6, 1997, Pages 379-398.
6. Michikata Kono, Seiichi Shiga, Seiichiro Kumagai, Kazuo Iinuma, Thermodynamic and experimental determinations of knock intensity by using a spark-ignited rapid compression machine. Combustion and Flame, Volume 54, Issues 1-3, December 1983, Pages 33-47.
7. H.T. Lin, M.P. Brady, R.K. Richards, D.M. Layton, Characterization of erosion and failure processes of spark plugs after field service in natural gas engines. Wear, Volume 259, Issues 7-12, July-August 2005, Pages 1063-1067.
8. Ignitability of spark plug — The consideration on leanburn condition: Hiroshi Ono, Masahiro Ishikawa, Yoshihiro Matsubara (NGK Spark Plug Co., Ltd.). JSAE Review, Volume 17, Issue 4, October 1996, Page 444.
9. Henry S. Rawdon, A.J. Krynitzky, A study of the deterioration of nickel spark plug electrodes in service. Journal of the Franklin Institute, Volume 188, Issue 6, December 1919, Pages 812-813.
10. Spark plug gasket sealing. Sealing Technology, Volume 2001, Issue 92, August 2001, Pages 12-13.
11. L.A. Killick, The sparking plug Some design of considerations. Materials & Design, Volume 3, Issue 4, August 1982, Pages 511-514.
12. N. Kawahara, E. Tomita, S. Takemoto, Y. Ikeda, Fuel concentration measurement of premixed mixture using spark-induced breakdown spectroscopy. Spectrochimica Acta Part B: Atomic Spectroscopy, Volume 64, Issue 10, October 2009, Pages 1085-1092.
CHAPTER 3
High Energy Rate (Her) Forming
Modern technological progress in the metal processing area is characterized by new progressive technological methods implemented in production and high mechanization and automation of existing ones.
An important position in the raw of new technological processes in the plastic deformation metal processing area is occupied by the high-speed (impulse) methods of forming [1].
Stamping of large-size components made of high-strength alloys; creation of new composite materials and reinforcement of large products of complicated shape became possible thanks to the utilisation of high-pressure shock wave energy [1].
The most economically suitable and practically feasible means to create shock waves proved to be the use of various types of explosives. Considered for application in this area is the electro-magnetic field (Fig. 1), and the electric sparkling discharge in water medium (Fig. 2), (Fig. 3) [2].
The issue about the contribution of high-speed forming to the solution of manufacturing problems is rather important. This technique should be applied where conventional technological solutions prove to be complicated and expensive and sometimes – even impossible [2].
Fig. 1
Fig. 2
Explosive forming (fig. 4) is performed in air or water medium. In some cases sand, oil or other liquid medium is applied. The most widely spread technique is explosive deformation in water medium (hydro-explosive deformation) [3].
3.1 Explosives and physical nature of explosions
Explosives are materials featuring high speed of chemical interaction as a result of which a certain quantity of heat and gaseous products are released. When the blast wave is spread in a certain volume at a speed of several kilometres per second leaving heated gases under high pressure behind, the explosion process is called detonation [3]. The constant speed of detonation is a characteristic feature of explosives, which provides their efficient application. The maximum speed of spreading for the detonation wave of explosives used for engineering purposes is from 2000 to 9000 m/s. The maximum pressure of expanding gaseous products goes up to hundreds of thousands atmospheres. Explosives used for metal processing operations could be classified into four groups [4]:
A. Slow-burning powders; B. Fragmentation – TNT, etc. C. Burning gaseous mixtures;
D. Compressed gases, which under certain conditions undergo almost immediate transition from liquid into gaseous state.
Fragmentation explosives find the widest application in forming operations. The time needed for the transition of a fragmentation explosive into a gaseous product is millions of a second
The energy of the explosion is transferred into the formed product via an intermediate conducting medium and the denser this medium is the higher the efficiency of the overall process. Air is the poorest conducting medium as it has very low density. Water provides for significantly higher efficiency with its density of 830 times the density of air. High-speed deformation is a result of the exceptionally fast spreading of the shock wave front (high-pressure front). The shock wave amplitude is a decreasing function of time. The following relation expresses the pressure change [5]:
θ t
t p e
p = max⋅ − ,
whereθ is the time constant, which depends on the type, mass and location of the explosive. This is equal to the time needed for the pressure to be reduced by e number of times compared to pmax.
The following relations are available to calculate the time constant [5]: - for spherically shaped charge – TNT
24 , 0 3 1 3 1 4 10 ⎟ ⎟ ⎟ ⎠ ⎞ ⎜ ⎜ ⎜ ⎝ ⎛ ⋅ ⋅ = − Q R Q θ
- for cylindrically shaped charge – TNT 45 , 0 2 1 3 1 4 10 ⎟ ⎟ ⎟ ⎠ ⎞ ⎜ ⎜ ⎜ ⎝ ⎛ ⋅ ⋅ = − q R q θ , where
Q is the spherical-shaped charge mass, kg
q is the mass of a linear meter of cylindrically shaped charge, kg/m R is the distance from the centre of the charge to the sample, mm.
It could be seen from the relation between θ and the weight of the charge and the distance (in the logarithmic scale) that the larger R is the larger would θ be. This shows that the wavelength increases. When R is maintained constant θ increases when Q is increased. The following relations determine the maximum pressure, impulse and energy [6]:
2 3 1 max 980,6MN/m R Q A p D ≈ ⎟ ⎟ ⎟ ⎠ ⎞ ⎜ ⎜ ⎜ ⎝ ⎛ ⋅ = 2 3 1 3 1 / 6 , 980 MNs m R Q BQ J E ⋅ ⎟ ⎟ ⎟ ⎠ ⎞ ⎜ ⎜ ⎜ ⎝ ⎛ ⋅ = −
2 3 1 3 1 / 06 , 98 kJ m R Q CQ E F ⋅ ⎟ ⎟ ⎟ ⎠ ⎞ ⎜ ⎜ ⎜ ⎝ ⎛ ⋅ = where A, B, C, D, E and F are constant.
The progress of the detonation process in a water medium has a number of features, which are best manifested when exploding a spherically shaped charge. The powerful shock wave resulting from the detonation moves away from the centre of the explosion at a sonic speed. Resulting gaseous products form a gas bubble and expand at a constantly decreasing speed. This results in reduction of their pressure, which at a certain time becomes lower than the ambient pressure [6]. From this point the gaseous bubble begins to shrink until the pressure within it is higher than ambient pressure. As a result of the newly available super pressure the gaseous bubble again starts to expand, i.e. multiple pulsations result. If the gaseous bubble reaches the water surface before these pulsations have started a fountain is formed above it and anti-fountain mesh is used in this case positioned above water surface or explosion is performed at a depth of [7]:
3
9 Q h= ⋅
When the explosion is carried out under water the shock waves reverberating from the water surface would change direction and return as discharge waves. To avoid their strong effect the processed component should be positioned at a depth h where it would be first affected by the direct shock wave. The following relation determines this distance [7]:
m Q R Q h 24 , 0 2 1 3 min 2 1 11 , 0 10 5 , 3 ⎟ ⎟ ⎟ ⎠ ⎞ ⎜ ⎜ ⎜ ⎝ ⎛ ⋅ ⋅ ⋅ ⋅ ⋅ = ν ,
where v is the speed of sound under water.
3.2 Characteristics & Technological Features Of Hydro-Explosive
Deformation
Fig. 5 shows a scheme of hydro-explosive deformation: the flat sheet sample 1 is inserted between the die 2 and the clamp 3. When the charge 4 located at a distance R from the sample is blasted all abovementioned processes take place. When no special measures are taken (for example, installing a specifically shaped die) the component would have an approximately spherical shape with a depth h after the explosion. Some auxiliary devices include the pool 5, a crane mechanism, a vacuum system, etc.
The shock wave emits part of its energy to form the sample. The rest of the energy is carried away by the reverberated wave. As a result of this action the metal of the sample is given a high initial acceleration and then continues to move at a constant speed (80-300 m/s). In the general case, transverse and longitudinal elastic waves result in the deforming body [8]. As a result of the reverberation of these waves some radial waves are formed from the circumference, which move towards the center and leave the metal behind them in a uniform plastic flow state. A transverse plastic wave is formed close to the edges, which also moves
sample has the shape of a truncated cone in each deformation stage and the plastic forming section is ring-shaped. As a result of this the maximum deformation occurs in the centre of the sample.
The following relation determines the speed of spread of the transverse plastic wave [8]: s
m S /
σ
ν =
The impulse load also causes some structural changes in the sample material – grain braking, etc. These changes alter metal properties – reduce plasticity, corrosion resistance, increase strength characteristics, etc. Metals behaviour under such deformation conditions has not been sufficiently studied yet.
Impulse deformation also causes changes in metal elastic springing. Studies show that it exists and its value could be adjusted within certain limits by varying the size and location of the charge.
The basic technological parameters determining the progress of the deformation process are explosive charge size and the distance from the sample.
The mass of the explosion charge is determined by the relation between the energy needed for the deformation of the metal sample and the energy resulting from the explosive. Other analytical methods for determining the size of explosive charge are based on the theorem of preserving the momentum [8].
Having adopted a number of considerations and basing on the sonic field theory, R.B.Pichotovnikov recommends the following formulas for determining the mass of the explosive charge [8]:
- for spherically shaped charge
kg N QsR Q 8 , 0 2 8 , 1 1 ⎟⎟⎠ ⎞ ⎜⎜ ⎝ ⎛ ⋅ − = ν
- for linear charge
m kg M QsR Q / 1 8 , 0 2 55 , 0 ⎟⎟ ⎠ ⎞ ⎜⎜ ⎝ ⎛ ⋅ − = ν , where:
a is the plastic deformation energy per unit sample surface (the specific work).;
(
β)
ϕ
ν = ⋅1−e−
2 - pressure and flow rate ratio in the reverberated and direct wave;
ϕ - reverberation coefficient (0.936 for steel; 0.824 for aluminium alloys; 0.813 for titanium alloys); s - material thickness; s o ⋅ ⋅ ⋅ = ρ θ ν ρ β ρo - water density ρ - material density;
M and N - coefficients depending on the density of processed material: - for aluminium alloys
6 10 494 , 0 ⋅ − = N and M =79.7⋅10−6 - for titanium alloys
6 10 813 , 0 ⋅ − = N and M =79.7⋅10−6
The specific deformation work could be determined based on the diagram of summarized stress in degree approximation [9]:
a i
i β ε
σ = ⋅ , where
σ
i, ε
iare summarized stress and deformation, respectively;α
i, β
- approximation constants.The specific work would then be expressed by [9]: a a a + ⋅ = + 1 1 ε β
The deformed condition intensity should first be determined for each individual deformation and then determine specific work and charge size [7].
The shape of the charge could also influence the progress of the process. The best alternative is when the explosive charge has copied sample profile especially for flat samples. This could be accomplished using flat or ring-shaped charge and this could be located at a very small distance from the sample [9].
When a die is to be used provisions should be made to allow the air between the die and the sample to be released. This could either be accomplished by vacuum (for thinner components) or a groove system allowing the air to be released towards the walls of the die as the sample
References
1. C.D. Rakopoulos, E.G. Giakoumis, Second-law analyses applied to internal combustion engines operation. Progress in Energy and Combustion Science, Volume 32, Issue 1, 2006, Pages 2-47.
2. S.A. Tobias, The state of the art of high energy rate bulk forming. Journal of Mechanical Working Technology, Volume 9, Issue 3, May 1984, Pages 237-277.
3. A.J. Organ, The calibration of high energy-rate impact forming machines. International Journal of Machine Tool Design and Research, Volume 7, Issue 4, December 1967, Pages 325-349.
4. R.H. Brown, J.K. Russell, An experimental machine tool for cutting and high energy rate forming studies. International Journal of Machine Tool Design and Research, Volume 8, Issue 2, July 1968, Pages 73-82.
5. V. P. Astakhov, S. V. Shvets, A novel approach to operating force evaluation in high strain rate metal-deforming technological processes. Journal of Materials Processing Technology, Volume 117, Issues 1-2, 2 November 2001, Pages 226-237.
6. L.T. Chan, N.S. Ong, Design and development of an energy convertor for a mechanical press and its application to high speed forming. International Journal of Machine Tools and Manufacture, Volume 29, Issue 1, 1989, Pages 161-169.
7. A.G. Mamalis, A. Szalay, N. Göbl, I. Vajda, B. Raveau, Near net-shape manufacturing of metal sheathed superconductors by high energy rate forming techniques. Materials Science and Engineering B, Volume 53, Issues 1-2, 1 May 1998, Pages 119-124.
8. K. Ryttberg, M. Knutson Wedel, P. Dahlman, L. Nyborg, Microstructural evolution during fracture induced by high strain rate deformation of 100Cr6 steel. Journal of Materials Processing Technology, Volume 209, Issue 7, 1 April 2009, Pages 3325-3334. 9. D.J. Mynors, B. Zhang, Applications and capabilities of explosive forming. Journal of
CHAPTER 4.
Gear Drive Assembly
4.1 Explanatory
Epicyclical gearings are gear mechanisms where the gear rotates not only around its geometrical axis but along with it performs additional movement around the axis of the engaged gear, i.e. they provide complicated special movement [1]. The planet gears may be both internally and externally engaged with the so-called sun gears and their axes are supported in the planet carrier and together with the carrier are rotating around the geometrical axis of the sun gears [1]. When the sun gear is static, the mechanism is called planet-type. It is possible here to transfer movement from the sun gear to the planet carrier and vice versa. When it is possible to rotate the sun gear around its own axis, the mechanism is then called differential [1]. This mechanism allows rotating movement to be transferred from the sun gear to the planet carrier and to another sun gear or from the planet carrier to one or both sun gears, etc.
These types of gear mechanisms find a very wide application. They can be used as summing (subtraction) mechanisms, mechanisms for co-ordination of two movements, as mechanisms for compensating for the difference in angular speeds of two independent movements.
4.2 Operation principle
The sun gears 5 and 6 are seated in the body 1. They are the driving gears and receive their independent movement from the sprockets 8. The sun gears can either rotate in the same direction or in different directions at various angular speeds and are engaged with the planet gears 4 seated in the planet carrier. These are used to compensate for the difference in angular speeds and the directions of rotation of the sun gears [2].
The planet carrier is seated in the body 1. Its angular speed depends on the angular speeds of the sun gears and their direction of rotation. Its angular speed would be ω=0, provided that both sun gears have the same angular speed and opposite directions of rotation, and ω=max, when the sun gears have identical angular speed with identical sign [3]. In the first case, the planet carrier is static and the planet gears rotate and in the second case, the planet gears are static and the carrier rotates. Each difference in the angular speeds of the sun gears leads to a respective rotation of the carrier and planet gears regardless of the direction of rotation of the sun gears. The transmission ratios for the differential are determined by the equations in 4.3. The following are required for the seating of various parts due to the specificity of the differential gear [3]:
- provision of necessary kinematical accuracy (guaranteed side clearance); - provision of necessary geometrical precision (permanent center of engagement) The nut 7 is used for the purpose, which eliminates and adjusts side clearance and
Due to the fact that all gears are fixed and do not provide for axial shift except for the planet carrier, the clearance and their interrelation are ensured by carrier shift along its axis. The carrier is only fixed at the bearing inner diameter and is free at its outer diameter. This type of seating allows for some eventual temperature deformations to be compensated when the guaranteed side clearance has been ensured [4].
4.3 Design
calculations
1. Gear transmission ratio [2]
u
4
2. Gear module [2]
m te
2
3. Total angle of shaft interposition [2]
Σ
90 deg
.
4. Determining the angle of the pitch cone [3]
δ 1 atan
1
u
δ 1 14.036 deg
=
δ 2 atan u
( )
δ 2 75.964 deg
=
5. Number of gear teeth [3]z 1 16
z 2 z 1 u
.
z 2 64
=
6. Determining the tooth contour compensation [2]x 1 0.43
a
0.03
b
0.008
x τ1 a b u 2.5
.
(
)
x τ1 0.042
=
x 2
0.43
x τ2
x τ1
7. Determining the length of the pitch cone [2]
R e 0.5 m te
.
.
z 1
2z 2
2R e 65.97 mm
=
R m R e 1
.
ψ r
2
R m 57.723 mm
=
8. Determining the width of the gear ring [2]b
ψ r R e
.
9. Determining tooth height [2]
h e1 2 h' a c'
.
.
m te
h e1 4.8 mm
=
h e2 h e1
10. Determining tooth head height [2]
