Module Overview
Backup and Restore
Copy Vertica Database
Online Recovery
Backup - Overview
Backup is the process of copying the actual data files to a specified location
• Vertica data and backup files are written once
− Once a file is written Vertica will not update it
• Number of files increase with each backup
• Tuple Mover keeps the number of files under control
− The TM ‘mergeout’ process consolidates smaller ROS containers into larger ones
• To backup, copy Vertica files to stable storage
− Can be direct attached storage, NFS mounts or SAN
Backup – When?
Backup is the process of copying the actual data files to a specified location
• Part of Regular Disaster Recovery Strategy
− Nightly, weekly, depending on business continuity requirements and resources
• After loading or altering a large volume of data
• Before Maintenance Tasks
− Upgrading to another version of Vertica − Dropping a Partition
Backup and Restore – Options
There are several ways to take a Vertica Backup
• Backup and Restore by Database
− Most common backup process
− Backs up the entire database which includes all the schemas and objects within them
• Backup and Restore by Schema
− Multi-tenant database with different backup frequency
− Multi-application cluster with different backup requirements /policies
• Backup and Restore by Table
− Can be used to backup some critical tables − Restore certain tables for QA / Testing
Vertica Backup Restore – VBR
vbr.py is a Python script located under /opt/vertica/bin
• Use vbr.py with various options to take backup and restore data
• Create a configuration file
− vbr.py --setupconfig
− Goes into interactive mode, gathers all parameters and creates the configuration file
• VBR parameters
− Database name, schema name, snapshot name, object names
Vertica Backup Restore – VBR
A few parameters explained
• Snapshot Name – stores all the files under that named directory
• Restore Points – number of
incremental
backups stored in addition to full backup
• Node
− Names of nodes in the cluster
− Data is backed up from each node of the cluster
• Backup Directory
− Location where the backup files are stored
VBR preparation
Steps and some prerequisites
• Backup location to be configured on all the nodes
• Verify database is running
• Ensure backup hosts are running if data is backed up to those hosts
− Backup can be done to the same cluster nodes
− Backup can also be done to a dedicated host which has the SAN storage
• Backup Directory Permissions / Contents
Performing a Backup
How to run the vbr.py script
• vbr.py --task backup --config-file <myconfigfile>
− Same command is used for full and incremental backups
• First run does a
full
backup
− All data files are copied to the sub-directory with the snapshot name
• Subsequent runs are
incremental
− Copies files which have changed since last backup − Files are only added or deleted, never modified
− Each incremental backup goes into a separate sub-directory with a timestamp − Each incremental backup also adds those files to the full backup
Performing a Restore
The same vbr.py script is used for restore
• vbr.py --task restore --config-file <myconfigfile>
− The configuration file is the same that is used for the Backup
• Restore can be specific
− Entire database, specific schema or table depending on the configuration file used − Vertica copies the files from backup location to the data directory location
• Some key features
− Vertica does not have the concept of transaction logging − There is no roll forward or roll back of transactions
Copy Vertica Database
This option of VBR copies the entire Database (cluster) to a target cluster
• When do we need
copycluster
?
− Maintain a warm-standby cluster for Disaster Recovery
− Provide an alternative cluster to a different set of users / applications
• Prerequisites
− Source and Target cluster must have same number of nodes
− Database, node names and dbadmin user have to be the same on both sides − Password-less ssh has to be established between all the nodes on both sides − Target database has to be shut down before starting the process
• vbr.py --task copycluster --config-file <cfgfile>
Node Recovery
Vertica is highly available MPP architecture, but nodes may go down…
• Node can recover from failure
− A node can rebuild its data set from other nodes in the cluster if the cluster is K-safe − In a full recovery the node rebuilds from scratch
• Incremental Recovery
− Node rebuilds from the current persisted state
− To speed up a full recovery, use a prior backup for the given node and perform incremental recovery
• RAID 10 is best practice
Monitor Recovery
• Monitor disk space
− df –h
− SELECT * FROM v_monitor.disk_storage;
• Monitor Recovery
− tail vertica.log
