B TECHNICAL SPECIFICATIONS FOR

(1)

Exhibit B

TECHNICAL SPECIFICATIONS

FOR

Florida State Fire

College

Treatment and Removal of

Perfluorinated Compounds

(PFCs) from Drinking Water

Sterling L. Carroll, P.E. FL PE #46151

Florida Rural Water Association

2970 Wellington Circle ~ Tallahassee FL 32309 Telephone: 850-668-2746 ~ Fax: 850-893-4581

(2)

(3)

DIVISION 1

(6)

(7)

SECTION 01010 -- SUMMARY OF WORK

PART 1 -- GENERAL

1.1 GENERAL

A. The WORK to be performed under this Contract shall consist of furnishing all plant, tools, equipment, materials, supplies, and manufactured articles and for furnishing all transportation and services, including fuel, power, water, and essential communications, and for the performance of all labor, work, or other operations required for the fulfillment of the Contract in strict accordance with the Contract Documents. The WORK shall be complete, and all work, materials, and services not expressly shown or called for in the Contract Documents which may be necessary for the complete and proper construction of the WORK in good faith shall be performed, furnished, and installed by the CONTRACTOR as though originally so specified or shown, at no increase in cost to the OWNER.

1.2 WORK COVERED BY CONTRACT DOCUMENTS

A. The Florida State Fire College desires to install a treatment system to address the Perfluorinated Compounds (PFCs) contamination of raw water.

B. Florida State Fire College intends to construct the following components:

1. Granulated Activated Carbon (GAC) Filters with backwash to address the Perfluorinated Compounds (PFCs) contamination of raw water- The proposed GAC Filter system will consist

of 4 GAC filter tanks, each with a design capacity of 42 gallons per minute (GPM) in duplex/lag arrangement with 2 in series and 2 in parallel.

a. The first 2 tanks in parallel will provide Empty Bed Contact Time (EBCT) and the second two tanks in series will provide redundancy and allow a mid-point sampling tap. Each of the fiberglass GAC tanks is 48-inch by 72-inch back washable tank with 25 cubic feet (cu. ft.) (100 cu. ft. total) of GAC to provide an EBCT of 7 minutes based on an instantaneous flow rate of 1 GPM per 1.33 cu. ft. of media. A seven- minute EBCT should allow for 80- 90 percent (%) removal of perfluorinated compounds.

b. The proposed design of using larger mesh 8x30 GAC acid washed media (GC 8 x 30 AW) for more efficient high molecular weight organics followed by a smaller mesh 12x40 GAC acid washed media (GC 12 x 40 AW) more smaller organics will maximize bed life and removal efficiencies.

c. The activated carbon filters shall conform to NSF International Standard 61 as adopted in Rule 62-555.335, F.A.C.

d. Associated valves, pressure gauges, sample ports, fittings and appurtenances for the GAC filters.

2. Addition of Hydrogen Peroxide Feed System as a pre-oxidant to improve raw water quality-

Hydrogen peroxide (35 % concentration) will be added at the existing sodium hypochlorite injection point upstream of the ion exchange system. A hydrogen peroxide feed system, chemical feed pump, drum, and other appurtenances will be constructed in the existing chlorine building. The existing chlorine tubing connected to the existing injection point will be utilized to add hydrogen peroxide.

(8)

a. The chemical feed pump shall be proportionally flow paced to the existing well pump. Florida Rural Water Association (FRWA) will perform a jar test to ascertain the actual feed rate needed for hydrogen peroxide to oxidize / reduce impurities. The expected feed rate of between 3.0 to 5.0 mg/L is anticipated to use 1 to 1.5 gallons of hydrogen peroxide per month.

b. The hydrogen peroxide chemical feed pump proposed is a positive displacement, peristaltic-metering pump with anti-siphon protection, Stenner Model 45MHP2, #1 that provides 3 gallons per day (GPD) at 100 pounds per square inch (psi). The system will furnish and install a Stenner STS Series tank, 15-gallon chemical solution tank/holding tank. The hydrogen peroxides chemical feed system will be placed adjacent to the GAC filters under a roof (no walls). PVC, PTEE, and Polypropylene (low and high density) piping materials will be acceptable for hydrogen peroxide.

c. The FRWA ENGINEER shall be responsible to perform the hydrogen peroxide jar test at the Florida State Fire College WTP. The ENGINEER shall submit the required jar test report at the time of submitting a Certificate of Completion and Clearance Request to support the dosage of hydrogen peroxide and the sizing of the chemical feed pump. 3. Construction of a New Sodium Hypochlorite Injection location after the GAC filters, before the

point of entry (POE) to the distribution system- The existing sodium hypochlorite injection

location upstream of the ion exchange system will now be used to add hydrogen peroxide. a. The sodium hypochlorite feed system, chemical feed pump, drum and other

appurtenances will be relocated to the GAC filter area.

b. The chemical feed pump shall be proportionally flow paced to the new water meter. 4. Concrete Slab and Pole Barn for GAC Filter, Ion Exchange, etc. consisting of:

a. Expand the existing concrete slab to a minimum of 13’-6” x 22’-0”. The concrete slabs shall be 4-inch thick fiber-reinforced and welded wire mesh. Control joints shall be installed at least 10-feet center to center.

b. The Pole Barn shall be at least 15-ft x 24-ft with a partial wall placed such that the Chlorine Tank and GAC Filters are entirely out of the sun. The Pole Barn, footers, posts, roof and trusses shall be rated for hurricane winds with connections / straps to comply with standard building codes. The CONTRACTOR is required to obtain a Marion County

Building Department Permit.

c. Install 120 Volt single phase receptacles throughout the enclosure – a minimum of 4 receptacles.

d. Disturbed areas surrounding the site shall be regraded and reseeded. 5. Back Wash Collection and Recirculation System consisting of:

a. Backwash water line discharging into the top of backwash tank with an air gap provided b. Two (2) 2,500-gallon high density polyethylene or fiberglass backwash water tank to be constructed on a minimum 12-foot x 23-foot 4-inch thick fiber-reinforced and welded wire mesh concrete slab.

(9)

associated fittings operated by tank level indicators / floats. 6. Back Wash Recirculation System consisting of:

a. Associated 2-inch Schedule 80 PVC filter backwash pressure line to convey collected backwash water from the GAC filter system back to the head of the GAC Filters.

b. The system shall operate with floats in the tanks and when the GAC Filters are operational.

c. The expected quantity of the backwash water recycle is approximately 4,000 gallons per week.

1.3 CONTRACT METHOD

A. The WORK hereunder will be constructed under one contract.

B. The CONTRACTOR shall include the relevant provisions of the Contract as a part of all of its subcontract agreements.

1.4 WORK BY OTHERS

A. Concurrent Work by Other CONTRACTORS: No other CONTRACTORS will be present during the

performance of the WORK of this Contract.

1.5 WORK SEQUENCE

A. The CONTRACTOR's attention is directed to the fact that during the period of construction, no interruption in the water flow can be accommodated.

B. Access to the site is limited to the hours of 8:00 am through 7:00 pm during the WORK. C. The sequence of WORK shall be as follows:

1. Preconstruction Conference.

2. Mobilization (Bid Item 1). The CONTRACTOR shall submit the project schedule, Shop Drawings, Maintenance of Traffic Plan, Trench Safety Act, etc. to the ENGINEER. The CONTRACTOR shall start utility locates prior and during construction activities.

3. GAC Filter, Ion Exchange, Back Wash Collection and Recirculation System, etc., and Slab (Bid Items 7 and 8)

4. Install Granulated Activated Carbon (GAC) Filters with backwash, Hydrogen Peroxide Feed System, Relocate / Construct Sodium Hypochlorite Injection, Back Wash Collection and Recirculation System, and Connect GAC Filters to Existing Water System (Bid Items 4, 5, 6, 9 and 10) concurrently.

5. Install Back Wash Collection and Recirculation System (Bid Item 9) 6. Pole Barn (Bid Items 7 and 8)

7. The CONTRACTOR shall submit Project Record Documents (Bid Item 3), As-Builts, and Technical Operations Manual as required by Technical Specifications Section 01700, 01720, 13027, 15153, and 16622.

1.6 CONTRACTOR USE OF PROJECT SITE

(10)

on-site storage of materials, on-site fabrication facilities, and field offices.

1.7 OWNER USE OF THE PROJECT SITE

A. When the CONTRACTOR'S work involves rehabilitation of or extension to the existing facilities, the OWNER may utilize all or part of the existing site during the entire period of construction. The CONTRACTOR shall cooperate with the OWNER to minimize interference with the CONTRACTOR's operations and to facilitate the OWNER's operations. In any event, the OWNER shall be allowed access to the project site during the period of construction.

1.8 PROJECT MEETINGS

A. Preconstruction Conference: Prior to the commencement of WORK at the site, a preconstruction

conference will be held at a mutually agreed time and place which shall be attended by the CONTRACTOR, its superintendent, and its subcontractors as appropriate. Other attendees will be:  ENGINEER and the Resident Project Representative.

 Representatives of OWNER.

 Governmental representatives as appropriate.

 Others as requested by CONTRACTOR, OWNER, or ENGINEER.

B. Unless previously submitted to the ENGINEER, the CONTRACTOR shall bring to the conference one copy each of the following:

 Progress schedule.

 Procurement schedule of major equipment and materials and items requiring long lead time.  Shop Drawing/Sample/Substitute or "Or Equal" submittal schedule.

Bid Item Description Spec Section(s)

1 Mobilization (project schedule, utility locates, shop drawing submittals, maintenance of traffic plan,

etc.) 01300, 01505

2 Intentionally Omitted N/A

3

Project Record Documents, As-Builts by GPS Location, Technical Operations Manual, and Construction Photographs as required by Technical Specifications Section.

01300, 01700, 01720, 13027, 15153, and 16622

4

Granulated Activated Carbon (GAC) Filters with backwash to address the Perfluorinated

Compounds (PFCs) contamination of raw water conforming to NSF 61 per Rule 62-555.335, F.A.C.

11362, 02600

5 Hydrogen Peroxide Feed System consisting of a chemical feed pump, drum, and other

appurtenances in the existing chlorine building. 11192

6

Relocate / Construct Sodium Hypochlorite Injection located after the GAC filters, before the point of entry (POE) to the distribution system. The system with consist of a chemical feed pump, drum, tubing,

(11)

Bid Item Description Spec Section(s)

injection point, and other appurtenances. The chemical feed pump shall be proportionally flow paced to the new water meter.

7 Slab and Pole Barn for GAC Filter, Ion Exchange, etc. 02360, 02365 8 Concrete Slab and Pole Barn for Back Wash _{Collection and Recirculation System} 02360, 02365

9

Back Wash Collection and Recirculation System with backwash water line discharging into the top of backwash tank with an air gap provided, (2) 2,500-gal high density polyethylene or fiberglass

backwash water tanks to be constructed on a 12-foot x 23-12-foot concrete slab, (2) 50 gpm transfer pumps with isolation valves, check valves, supports and associated fittings operated by tank level indicators / floats.

11365, 11197

10

Connect GAC Filters to Existing Water System, complete with piping, fittings, gate valves, check valves, chlorine injection point, sample tap, meter, and appurtenances.

02600

 Schedule of values (lump sum price breakdown) for progress payment purposes.

C. The purpose of the conference is to designate responsible personnel and establish a working relationship. Matters requiring coordination will be discussed and procedures for handling such matters established. The complete agenda will be furnished to the CONTRACTOR prior to the meeting date, which may include the following:

 CONTRACTOR's tentative schedules.

 Transmittal, review, and distribution of CONTRACTOR's submittals.  Processing applications for payment.

 Maintaining record documents.  Critical work sequencing.

 Field decisions and Change Orders.

 Use of project site, office and storage areas, security, housekeeping, and OWNER's needs.  Major equipment deliveries and priorities.

 CONTRACTOR's assignments for safety and first aid.

D. The ENGINEER will preside at the preconstruction conference and will arrange for keeping the minutes and distributing the minutes to all persons in attendance.

E. Progress Meetings: The CONTRACTOR shall schedule and hold regular on-site progress meetings

at least monthly and at other times as requested by ENGINEER or as required by progress of the WORK. The CONTRACTOR, ENGINEER, and all subcontractors active on the site shall be represented

(12)

suppliers, manufacturers, and other subcontractors.

F. The ENGINEER shall preside at the meetings and provide for keeping and distributing the minutes. The purpose of the meetings will be to review the progress of the WORK, maintain coordination of efforts, discuss changes in scheduling, and resolve other problems which may develop.

1.9 FRWA ENGINEERING INSPECTION

A. The FRWA ENGINEER and WATER CIRCUIT RIDER will work with the OWNER (FRWA / OWNERS) to organize the Pre-Construction Meeting, issue the Notice to Proceed and provide services during construction. The FRWA ENGINEER will:

 Organize and lead the Preconstruction and Project Construction Meetings  Prepare the Notice to Proceed

 The FRWA ENGINEER and WATER CIRCUIT RIDER will provide periodic inspection of thework.  Evaluate / approve contractor shop drawings, etc.

 Provide interpretation the plans and specifications

 Periodic onsite representative for observation of the work.  Provide Construction Management training.

 Hold periodic Construction Conferences.

 Review progress payments and final payments and make recommendations, the Utility will be responsible for approving payments.

 All progress payments and final payments shall be subject to inspection and approval of up-to-date as-built drawings and receipt of warranties!

 Review and approve Change Orders  Final Certification & Closeout

 Punch Lists and Final / Partial Project Acceptance  Review contractor as-builts for Record Drawings  Final / Partial Certification(s)

1.10 FRWA / OWNERS INSPECTION

A. A FRWA / OWNERS INSPECTOR will be assigned to all utility projects and inspect the following: all construction; and preparation, fabrication or manufacture of components.

 The FRWA / OWNERS INSPECTOR will provide daily inspection of work progress and watch closely for substandard work. If any Utility Staff find or become aware of substandard work they should notify FRWA immediately so the work can be restored to acceptable conditions.  Attend the Preconstruction and Project Construction Meetings

 Attend Construction Management training with the FRWA ENGINEER.  Review progress payments and final payments and make recommendations.  Review Change Orders

(13)

 Review and prepare Punch Lists

 Review contractor as-builts for Record Drawings

B. The FRWA / OWNERS INSPECTOR is not authorized to revoke, alter or waive any requirements of the specifications and/or System Criteria, but is authorized and expected to call to the attention of ENGINEER and/or CONTRACTOR any failure of work or materials to conform to the drawings and specifications and/or System Criteria.

C. The FRWA / OWNERS INSPECTOR shall have the authority to reject materials or issue deficient work notices until questions of issue can be resolved to the System's satisfaction.

D. The FRWA / OWNERS INSPECTOR shall in no case act as a foreman, give advice or perform other duties for the ENGINEER and/or CONTRACTOR nor interfere with the management of the work. E. FRWA / OWNERS INSPECTOR will make routine passes to inspect such items as thrust blocks,

materials on site, and clearances between conflicting lines. Scheduled inspections are required for jacking and boring operations, setting of wet wells, lift station start-ups with manufacturer's representative present, any time a connection is to be made to the system and other times when deemed necessary by the Utility Services Department.

F. It shall be the ENGINEER or OWNER's responsibility to notify the Utility Services Department when ready for inspection. The ENGINEER or OWNER’s qualified representative shall be present at all scheduled tests and inspections. Prior to the "Final Inspection," all concerned parties shall inspect the project or facility to ensure quality workmanship and compliance with System standards. FRWA / OWNERS INSPECTOR will notify the ENGINEER and OWNER in writing ("Punch List") as to any problem or outstanding items required for final acceptance of the project. Upon completion of the "punch list" work, the ENGINEER or CONTRACTOR shall notify OWNER, and another inspection will be arranged. After all "punch list" items are completed including any leaks and/or cracks, the ENGINEER will conduct a "Final Inspection" of the completed work. The inspection party shall include the OWNER, the ENGINEER, and Utility Services Department representative. Final acceptance shall not occur until all "punch list" items are satisfactorily completed. Any overtime for Inspectors due to OWNER's scheduling will be billed to the OWNER and shall be reimbursed to the Utility Services Department.

G. CONTRACTOR shall give 48 hours’ notice to OWNER prior to beginning work.

H. No work shall be done between the hours of 6:00 p.m., and 6:00 a.m., nor on Saturday, Sunday, or legal holidays observed by OWNER without the written approval or permission of OWNER's ENGINEER and the Utility Services Director or designee.

I. The normal work shift for OWNER Inspectors is 7:00 am to 3:30 p.m. Any work done other than during the specified work shift or on Saturday, Sunday, or System holidays for which an inspector is required shall be considered overtime and shall be paid for by the CONTRACTOR. The necessity for the presence of an inspector will be determined by the Utility Services Department Director or his designated representative. Inspector overtime pay rates are available from the Utility Services Department by written request.

J. OWNER Holidays are: 1. New Year’s Day

(14)

3. Memorial Day 4. Independence Day 5. Labor Day

6. Veteran's Day 7. Thanksgiving Day

8. The day following Thanksgiving Day 9. Christmas Eve

10. Christmas Day

11. Others as adopted by the OWNER.

PART 2 -- PRODUCTS (Not Used) PART 3 -- EXECUTION (Not Used)

(15)

(16)

SECTION 01025 -- MEASUREMENT AND PAYMENT

1.1 SCOPE

A. Payment for the various items of the Bid Sheets, as further specified herein, shall include all compensation to be received by the CONTRACTOR for furnishing all tools, equipment, supplies, and manufactured articles, and for all labor, operations, and incidentals appurtenant to the items of work being described, as necessary to complete the various items of the WORK all in accordance with the requirements of the Contract Documents, including all appurtenances thereto, and including all costs of compliance with the regulations of public agencies having jurisdiction, including Safety and Health Requirements of the Occupational Safety and Health Administration of the U.S. Department of Labor (OSHA). No separate payment will be made for any item that is not specifically set forth in the Bid Schedule, and all costs therefor shall be included in the prices named in the Bid Schedule for the various appurtenant items of work.

1.2 MEASUREMENT FOR PAYMENT.

A. LUMP SUM items will be paid upon the percent completion for each item, all in accordance with the requirements of the Contract Documents.

B. Measurement for payment for LINEAL FOOT UNIT PRICE items will be based upon the actual lineal foot installed, all in accordance with the requirements of the Contract Documents.

C. Measurement for payment for EACH UNIT PRICE items will be based upon the actual number, each, installed, all in accordance with the requirements of the Contract Documents.

D. No separate payment will be made for fittings, surface restoration, resodding, pavement repair, grading, preparation of subgrade, furnishing and setting of expansion, joint material, disposal of excess materials, and all other appurtenant items for which separate payment is not specifically provided in the Bid Schedule(s) and the costs therefor shall be included in the prices named in the Bid Schedule(s) for the various appurtenant items of work.

E. The project shall include 9 pay items.

1. Insurance as required in the Contract Documents – not a separate pay item. 2. Bonds as required in the Contract Documents – not a separate pay item.

1.3 LUMP SUM ITEMS.

A. The following bid items shall be paid Lump Sum and each item shall be COMPLETE.

 Bid Item 1 ~ Mobilization (project schedule, survey, utility locates, shop drawing submittals, maintenance of traffic, etc.)

 Bid Item 3 ~ Project Record Documents, As-Builts by GPS Location, Technical Operations Manual, and Construction Photographs as required by Technical Specifications Section 01700, 01720, 13027, 15153, and 16622

 Bid Item 4 ~ Granulated Activated Carbon (GAC) Filters with backwash to address the Perfluorinated Compounds (PFCs) contamination of raw water conforming to NSF 61 per Rule 62-555.335, F.A.C.

 Bid Item 5 ~ Hydrogen Peroxide Feed System consisting of a chemical feed pump, drum, and other appurtenances in the existing chlorine building.

(17)

 Bid Item 6 ~ Sodium Hypochlorite Injection located after the GAC filters, before the point of entry (POE) to the distribution system.

 Bid Item 7 ~ Concrete Slab and Pole Barn for GAC Filter, Ion Exchange, etc.

 Bid Item 8 ~ Concrete Slab and Pole Barn for Back Wash Collection and Recirculation System.  Bid Item 9 ~ Back Wash Collection and Recirculation System consisting of 3-in backwash water

line discharging into the top of backwash tank with an air gap provided, two (2) 2,500-gal high density polyethylene or fiberglass backwash water tanks.

 Bid Item 10 ~ Connect GAC Filters to Existing Water System, complete with piping, fittings, gate valves, check valves, chlorine injection point, sample tap, meter, and appurtenances.

1.3 LINEAL FOOT UNIT PRICE ITEMS.

A. The following bid items shall be paid by Lineal Foot.  N/A

1.4 SQUARE YARD PRICE ITEMS.

A. The following bid items shall be paid by Square Yard.  N/A

1.5 EACH UNIT PRICE ITEMS.

A. The following bid items shall be paid Each Unit Price.  N/A

(18)

SECTION 01300 -- CONTRACTOR SUBMITTALS

1.1 GENERAL

Wherever submittals are required hereunder, all such submittals by the CONTRACTOR shall be submitted to the ENGINEER through the Resident Project Representative at the construction site for recording and forwarding to the ENGINEER.

1.2 SHOP DRAWING SUBMITTAL

A. Wherever called for in the Contract Documents, or where required by the ENGINEER, the CONTRACTOR shall furnish to the ENGINEER for review, by email to the ENGINEER and OWNER

(preferred). The term "Shop Drawings" as used herein shall be understood to include detail design

calculations, shop drawings, fabrication, and installation drawings, erection drawings, lists, graphs, operating instructions, catalog sheets, data sheets, and similar items.

1. Also see list of Submittals in Specification Section 01010 1.8.B., pages 01010-4 & 5.

B. All Shop Drawing submittals shall be accompanied by the ENGINEER's standard submittal transmittal form. This form may be obtained in quantity from the ENGINEER at reproduction cost. Any submittal not accompanied by such a form, or where all applicable items on the form are not completed, will be returned for resubmittal.

C. Normally, a separate transmittal form shall be used for each specific item or class of material or equipment for which a submittal is required. Transmittal of a submittal of various items using a single transmittal form will be permitted only when the items taken together constitute a manufacturer's "package" or are so functionally related that expediency indicates review of the group or package as a whole. A multiple-page submittal shall be collated into sets, and each set shall be stapled or bound, as appropriate, prior to transmittal to the ENGINEER.

D. Except as may otherwise be provided herein, the ENGINEER will return prints of each submittal to the CONTRACTOR with its comments noted thereon, within 5 calendar days following their receipt by the ENGINEER. It is considered reasonable that the CONTRACTOR shall make a complete and acceptable submittal to the ENGINEER by the second submission of a submittal item. The OWNER reserves the right to withhold monies due the CONTRACTOR to cover additional costs of the ENGINEER's review beyond the second submittal.

E. If the submittal is returned to the CONTRACTOR marked "NO EXCEPTIONS TAKEN," formal revision and resubmission of said submittal will not be required.

F. If the submittal is returned to the CONTRACTOR marked "MAKE CORRECTIONS NOTED," formal revision and resubmission of said submittal will not be required.

G. If the submittal is returned to the CONTRACTOR marked "AMEND-RESUBMIT," the CONTRACTOR shall revise said submittal and shall resubmit the required number of copies of said revised submittal to the ENGINEER.

H. If the submittal is returned to the CONTRACTOR marked "REJECTED-RESUBMIT," the CONTRACTOR shall revise said submittal and shall resubmit the required number of copies of said revised submittal to the ENGINEER.

(19)

submittals and returned copies to the CONTRACTOR marked either "NO EXCEPTIONS TAKEN" or "MAKE CORRECTIONS NOTED." Corrections indicated on submittals shall be considered as changes necessary to meet the requirements of the Contract Documents and shall not be taken as the basis of claims for extra work.

J. All CONTRACTOR shop drawing submittals shall be carefully reviewed by an authorized representative of the CONTRACTOR, prior to submission to the ENGINEER. Each submittal shall be dated, signed, and certified by the CONTRACTOR, as being correct and in strict conformance with the Contract Documents. In the case of shop drawings, each sheet shall be so dated, signed, and certified. No consideration for review by the ENGINEER of any CONTRACTOR submittals will be made for any items which have not been so certified by the CONTRACTOR. All non-certified submittals will be returned to the CONTRACTOR without action taken by the ENGINEER, and any delays caused thereby shall be the total responsibility of the CONTRACTOR.

K. The ENGINEER's review of CONTRACTOR shop drawing submittals shall not relieve the CONTRACTOR of the entire responsibility for the correctness of details and dimensions. The CONTRACTOR shall assume all responsibility and risk for any misfits due to any errors in CONTRACTOR submittals. The CONTRACTOR shall be responsible for the dimensions and the design of adequate connections and details.

1.4 Intentionally Omitted 1.5 Intentionally Omitted

1.6 RECORD DRAWINGS SUBMITTALS

A. The CONTRACTOR shall provide record drawings by using and redlining the ENGINEER’s drawings. B. Digital copies of the design documents will be provided only in Adobe pdf format.

C. The CONTRACTOR shall keep and maintain, at the job site, one record set of Drawings.

1. On these, it shall mark all project conditions, locations, configurations, and any other changes or deviations which may vary from the details represented on the original Contract Drawings, including buried or concealed construction and utility features which are revealed during the course of construction.

2. Special attention shall be given to recording the horizontal and vertical location of all buried utilities that differ from the locations indicated, or which were not indicated on the Contract Drawings.

3. Said record drawings shall be supplemented by any detailed sketches as necessary or directed to indicate, fully, the WORK as actually constructed.

4. These master record drawings of the CONTRACTOR's representation of as-built conditions, including all revisions made necessary by addenda, change orders, and the like shall be maintained up-to-date during the progress of the WORK.

D. In the case of those drawings which depict the detail requirement for equipment to be assembled and wired in the factory, such as motor control centers and the like, the record drawings shall be updated by indicating those portions which are superseded by change order drawings or final shop drawings, and by including appropriate reference information describing the change orders by number and the shop drawings by manufacturer, drawing, and revision numbers.

(20)

E. Record drawings shall be accessible to the ENGINEER at all times during the construction period and shall be delivered to the ENGINEER upon completion of the WORK.

F. Requests for partial payments will not be accepted if the record drawings are not kept current, and not until the completed record drawings, showing all variations between the WORK as actually constructed and as originally shown on the Contract Drawings or other Contract Documents, have been inspected by the ENGINEER.

G. Final payment will not be acted upon until the CONTRACTOR-prepared record drawings have been delivered to the ENGINEER. Said up-to-date record drawings may be in the form of a set of prints with carefully plotted information overlayed in pencil.

H. Upon substantial completion of the WORK and prior to final acceptance, the CONTRACTOR shall compete and deliver a complete set of record drawings to the ENGINEER for transmittal to the OWNER, conforming to the construction records of the CONTRACTOR. This set of drawings shall consist of corrected drawings showing the reported location of the WORK. The information submitted by the CONTRACTOR and incorporated by the ENGINEER into the Record Drawings will be assumed to be reliable, and the ENGINEER will not be responsible for the accuracy of such information, nor for any errors or omissions which may appear on the Record Drawings as a result.

1.7 CONSTRUCTION PHOTOGRAPHS SUBMITTAL

A. The CONTRACTOR shall provide construction photographs showing the regular progress of the WORK.

B. Starting when the WORK begins and continuing for as long as the WORK is in progress, not less than 12 exposures consisting of different subjects or angles of view each time, shall be taken from different locations in the project area at intervals not exceeding 2 weeks apart. All photographs shall be furnished to the ENGINEER within 2 weeks after each exposure.

C. Upon completion of the WORK, an additional 24 photographs, shall be made of the WORK and emailed to the ENGINEER and OWNER.

D. No separate payment will be allowed for construction photographs and all costs therefor shall be included in the overall bid for construction of the WORK.

(21)

(22)

SECTION 01400 -- QUALITY CONTROL

1.1 INSPECTION AT PLACE OF MANUFACTURE

A. Unless otherwise specified, all products, materials, and equipment shall be subject to inspection by the ENGINEER at the place of manufacture.

B. The presence of the ENGINEER at the place of manufacture, however, shall not relieve the CONTRACTOR of the responsibility for furnishing products, materials, and equipment which comply with all requirements of the Contract Documents. Compliance is a duty of the CONTRACTOR, and said duty shall not be avoided by any act or omission on the part of the ENGINEER.

1.2 SAMPLING AND TESTING

A. Unless otherwise specified, all sampling and testing shall be in accordance with the methods prescribed in the current standards of the ASTM, as applicable to the class and nature of the article or materials considered; however, the OWNER reserves the right to use any generally-accepted system of sampling and testing which, in the opinion of the ENGINEER will insure the OWNER that the quality of the workmanship is in full accord with the Contract Documents.

B. Any waiver by the OWNER of any specific testing or other quality assurance measures, whether or not such waiver is accompanied by a guarantee of substantial performance as a relief from the specified testing or other quality assurance requirements as originally specified, and whether or not such guarantee is accompanied by a performance bond to assure execution of any necessary corrective or remedial WORK, shall not be construed as a waiver of any requirements of the Contract Documents.

C. Notwithstanding the existence of such waiver, the ENGINEER reserves the right to make independent investigations and tests and failure of any portion of the WORK to meet any of the requirements of the Contract Documents, shall be reasonable cause for the ENGINEER to require the removal or correction and reconstruction of any such work in accordance with the Attachment 2, Statement of Work.

PART 2 -- PRODUCTS (Not Used) PART 3 – EXECUTION (Not Used)

(23)

(24)

SECTION 01505 -- MOBILIZATION

1.1 GENERAL

A. Mobilization shall include the obtaining of all permits; moving onto the site of all equipment, supplies, parts and other construction facilities; all as required for the proper performance and completion of the WORK. Mobilization shall include but not be limited to the following principal items:

 Moving on to the site of all CONTRACTOR's equipment required for first month operations.  Establishing fire protection system, if needed.

 Developing construction water supply.  Erecting Maintenance of Traffic.

 Providing on-site sanitary facilities and potable water facilities, if specified.  Arranging for and erection of CONTRACTOR's work and storage yard.  Obtaining all required permits.

 Posting all OSHA required notices and establishment of safety programs.  Have the CONTRACTOR's superintendent at the job site full time.

 _{Submittal of Preliminary Construction Schedule.}

B. Within 10 days of the Contractor’s receipt of the Notice to Proceed, the CONTRACTOR shall submit the following items to the ENGINEER for review:

1. A Preliminary Construction Schedule indicating the starting and completion dates of the various stages of the WORK.

2. A preliminary schedule of Shop Drawing, Sample, and proposed Substitutes or "Or-Equal" submittals.

3. A list of all permits and licenses the CONTRACTOR shall obtain indicating the agency required to grant the permit and the expected date of submittal for the permit and required date for receipt of the permit.

4. A preliminary schedule of values (lump sum price breakdown) for all of the WORK which will include quantities and prices of items aggregating the Contract Price and will subdivide the WORK into component parts in sufficient detail to serve as the basis for progress payments during construction. Such prices shall include an appropriate amount of overhead and profit applicable to each item of work which will be confirmed in writing by the CONTRACTOR at the time of submittal.

1.2 PAYMENT FOR MOBILIZATION

A. The CONTRACTOR's attention is directed to the condition that 5 percent of the total Contract Price will be deducted from any money due the CONTRACTOR as progress payments until all mobilization items listed above have been completed as specified. The aforementioned amount will be retained by the OWNER as the agreed, estimated value of completing all of the mobilization items listed. Any such retention of money for failure to complete all such mobilization items as a lump-sum item shall be in addition to the retention of any payments due to the CONTRACTOR as specified in Article 14 of Attachment 2, Statement of Work, of the Contract.

(25)

B. As soon as practicable after receipt of the Notice to Proceed, the CONTRACTOR shall submit a breakdown to the ENGINEER for approval, which shall show the estimated value of each major component of mobilization. When approved by the ENGINEER, the breakdown will be the basis for initial progress payments in which Mobilization is included.]

PART 2 -- PRODUCTS

A. The CONTRACTOR shall submit a Preliminary Construction Schedule listing mobilization and all major tasks. The following formats are acceptable: Critical Path Method (CPM), Program Evaluation and Review Technique (PERT), Gantt Charts, Microsoft Project Management, Primavera, Precedence Diagram Method (PDM) or the Arrow Diagram Method (ADM).

PART 3 -- EXECUTION (Not Used)

(26)

(27)

SECTION 01510 -- TEMPORARY UTILITIES

1.1 GENERAL

A. It shall be the CONTRACTOR's responsibility to provide plant and equipment that is adequate for the performance of the WORK under this Contract within the time specified. All plant and equipment shall be kept in satisfactory operating condition, shall be capable of safely and efficiently performing the required WORK, and shall be subject to inspection and approval by the OWNER's representative at any time within the duration of the Contract. All work hereunder shall conform to the applicable requirements of the OSHA Standards for Construction.

1.2 POWER AND LIGHTING

A. Power: The CONTRACTOR shall provide all necessary power required for its operations under the

Contract and shall provide and maintain all temporary power lines required to perform the WORK in a safe and satisfactory manner.

B. Construction Lighting: All WORK conducted at night or under conditions of deficient daylight shall

be suitably lighted to ensure proper WORK and to afford adequate facilities for inspection and safe working conditions.

C. Approval of Electrical Connections: All temporary connections for electricity shall be subject to

approval of the ENGINEER and the power company representative and shall be removed in like manner at the CONTRACTOR's expense prior to final acceptance of the WORK.

D. Separation of Circuits: Unless otherwise permitted by the ENGINEER, circuits separate from

lighting circuits shall be used for all power purposes.

E. Construction Wiring: All wiring for temporary electric light and power shall be properly installed

and maintained and shall be securely fastened in place. All electrical facilities shall conform to the requirements of Subpart K of the OSHA Safety and Health Standards for Construction.

1.3 WATER SUPPLY

A. General: The OWNER will furnish, without charge, reasonable quantities of water required by the

CONTRACTOR in performance of the WORK under the Contract; however, the CONTRACTOR shall provide all facilities necessary to convey the water from the OWNER-designated source to the points of use in accordance with the requirements of the Contract Documents.

B. Potable Water: All drinking water on the site during construction shall be furnished by the

CONTRACTOR and shall be bottled water or water furnished in approved metal dispensers. C. Water Connections: The CONTRACTOR shall not make connection to, or draw water from, any fire

hydrant or pipeline without first obtaining permission of the authority having jurisdiction over the use of said fire hydrant or pipeline and from the agency owning the affected water system. For each such connection made, the CONTRACTOR shall first attach to the fire hydrant or pipeline a valve and a meter, if required by the said authority, of a size and type acceptable to said authority and agency.

D. Removal of Water Connections: Before final acceptance of the WORK on the project, all temporary

connections and piping installed by the CONTRACTOR shall be entirely removed, and all affected improvements shall be restored to their original condition, or better, to the satisfaction of the

(28)

ENGINEER and to the agency owning the affected utility.

E. Fire Protection: The construction plant and all other parts of the WORK shall be connected with

the CONTRACTOR's water supply system and shall be adequately protected against damage by fire. Hose connections and hose, water casks, chemical equipment, or other sufficient means shall be provided for fighting fires in the temporary structures and other portions of the WORK, and responsible persons shall be designated and instructed in the operation of such fire apparatus so as to prevent or minimize the hazard of fire. The CONTRACTOR's fire protection program shall conform to the requirements of Subpart F of the OSHA Standards for Construction.

1.4 SANITATION

A. Toilet Facilities: Fixed or portable chemical toilets shall be provided wherever needed for the use

of employees. Toilets at construction job sites shall conform to the requirements of Subpart D, Section 1926.51 of the OSHA Standards for Construction.

B. Sanitary and Other Organic Wastes: The CONTRACTOR shall establish a regular daily collection of

all sanitary and organic wastes. All wastes and refuse from sanitary facilities provided by the CONTRACTOR or organic material wastes from any other source related to the CONTRACTOR's operations shall be disposed of away from the site in a manner satisfactory to the ENGINEER and in accordance with all laws and regulations pertaining thereto.

1.5 COMMUNICATIONS

A. Cell Phone Services: The CONTRACTOR shall provide and maintain at all times during the progress

of the WORK not less than one cell phone in good working at or near the site of the WORK included in the Contract. Each such telephone shall be connected to an established exchange for toll service and with all other telephones utilized by the CONTRACTOR.

(29)

SECTION 01550 -- SITE ACCESS AND STORAGE

1.1 HIGHWAY LIMITATIONS

A. The CONTRACTOR shall make its own investigation of the condition of available public and private roads and of clearances, restrictions, bridge load limits, and other limitations affecting transportation and ingress and egress to the site of the WORK. It shall be the CONTRACTOR's responsibility to construct and maintain any haul roads required for its construction operations.

1.2 TEMPORARY CROSSINGS

A. General: Wherever necessary or required for the convenience of the public or individual residents

at street or highway crossings, private driveways, or elsewhere, the CONTRACTOR shall provide suitable temporary bridges or steel plates over unfilled excavations, except in such cases as the CONTRACTOR shall secure the written consent of the individuals or authorities concerned to omit such temporary bridges or steel plates, which written consent shall be delivered to the ENGINEER prior to excavation. All such bridges or steel plates shall be maintained in service until access is provided across the backfilled excavation. Temporary bridges or steel plates for street and highway crossing shall conform to the requirements of the authority having jurisdiction in each case, and the CONTRACTOR shall adopt designs furnished by said authority for such bridges or steel plates, or shall submit designs to said authority for approval, as may be required.

B. Street Use: Nothing herein shall be construed to entitle the CONTRACTOR to the exclusive use of

any public street, alleyway, or parking area during the performance of the WORK hereunder, and it shall so conduct its operations as not to interfere unnecessarily with the authorized work of utility companies or other agencies in such streets, alleyways, or parking areas. No street shall be closed to the public without first obtaining permission of the ENGINEER and proper governmental authority. Where excavation is being performed in primary streets or highways, one lane in each direction shall be kept open to traffic at all times unless otherwise provided or shown. Toe boards shall be provided to retain excavated material if required by the ENGINEER or the agency having jurisdiction over the street or highway. Fire hydrants on or adjacent to the WORK shall be kept accessible to fire-fighting equipment at all times. Temporary provisions shall be made by the CONTRACTOR to assure the use of sidewalks and the proper functioning of all gutters, sewer inlets, and other drainage facilities.

C. The CONTRACTOR shall take all necessary precautions for the protection of the WORK and the safety of the public. All barricades and obstructions shall be illuminated at night, and all lights shall be kept burning from sunset until sunrise. The CONTRACTOR shall station such guards or flaggers and shall conform to such special safety regulations relating to traffic control as may be required by the public authorities within their respective jurisdictions. All signs, signals, and barricades shall conform to the requirements of Subpart G, Part 1926, of the OSHA Safety and Health Standards for Construction.

D. Street Closure: If closure of any street is required during construction, a formal application for a

street closure shall be made to the authority having jurisdiction at least 30 days prior to the required street closure in order to determine necessary sign and detour requirements.

(30)

adjacent to the WORK for its exclusive use during the term of the Contract as a storage and shop area for its construction operations relative to this contract.

B. The CONTRACTOR shall make its own arrangements for any necessary off-site storage or shop areas necessary for the proper execution of the WORK.

C. Lands to be furnished by the OWNER for camp sites, construction operation, concrete aggregate pits, roads and other purposes are [shown] [specified herein]. Should the CONTRACTOR find it necessary to use any additional land for its camp or for other purposes during the construction of the WORK, it shall provide for the use of such lands at its own expense

(31)

SECTION 01560 -- TEMPORARY ENVIRONMENTAL CONTROLS

1.1 EROSION AND SEDIMENT CONTROL

A. The CONTRACTOR shall furnish all labor, equipment, and means required and shall carry out effective measures wherever and as often as necessary to prevent its operation from producing erosion and sediment leaving the construction site and entering ditches, waterways, etc. The CONTRACTOR shall be responsible for any damage resulting from any erosion or sediment originating from its operations. The erosion and sediment abatement measures shall be continued until the CONTRACTOR is relieved of further responsibility by the ENGINEER.

B. The CONTRACTOR shall adhere to the EROSION AND SEDIMENT CONTROL DESIGNER AND REVIEWER MANUAL prepared for the Florida Department of Transportation & Department of

Financial Services, dated June 2007, and available at:

http://www.dep.state.fl.us/water/wetlands/docs/erp/FLErosionSedimentManual_6_07.pdf

1.2 DUST ABATEMENT

C. The CONTRACTOR shall furnish all labor, equipment, and means required and shall carry out effective measures wherever and as often as necessary to prevent its operation from producing dust in amounts damaging to property, cultivated vegetation, or domestic animals, or causing a nuisance to persons living in or occupying buildings in the vicinity. The CONTRACTOR shall be responsible for any damage resulting from any dust originating from its operations. The dust abatement measures shall be continued until the CONTRACTOR is relieved of further responsibility by the ENGINEER.

1.3 RUBBISH CONTROL

A. During the progress of the WORK, the CONTRACTOR shall keep the site of the WORK and other areas used by it in a neat and clean condition, and free from any accumulation of rubbish. The CONTRACTOR shall dispose of all rubbish and waste materials of any nature occurring at the WORK site and shall establish regular intervals of collection and disposal of such materials and waste. The CONTRACTOR shall also keep its haul roads free from dirt, rubbish, and unnecessary obstructions resulting from its operations. Disposal of all rubbish and surplus materials shall be off the site of construction in accordance with local codes and ordinances governing locations and methods of disposal, and in conformance with all applicable safety laws, and to the particular requirements of Part 1926 of the OSHA Safety and Health Standards for Construction.

1.4 SANITATION

A. Toilet Facilities: Fixed or portable chemical toilets shall be provided wherever needed for the use

of employees. Toilets at construction job sites shall conform to the requirements of Part 1926 of the OSHA Standards for Construction.

B. Sanitary and Other Organic Wastes: The CONTRACTOR shall establish a regular daily collection of

all sanitary and organic wastes. All wastes and refuse from sanitary facilities provided by the CONTRACTOR or organic material wastes from any other source related to the CONTRACTOR's operations shall be disposed of away from the site in a manner satisfactory to the ENGINEER and in accordance with all laws and regulations pertaining thereto.

(32)

1.5 CHEMICALS

A. All chemicals used during project construction or furnished for project operation, whether defoliant, soil sterilant, herbicide, pesticide, disinfectant, polymer, reactant or of other classification, shall show approval of either the U.S. Environmental Protection Agency or the U.S. Department of Agriculture. Use of all such chemicals and disposal of residues shall be in strict accordance with the printed instructions of the manufacturer.

1.6 CULTURAL RESOURCES

A. The CONTRACTOR's attention is directed to the National Historic Preservation Act of 1966 (16 U.S.C. 470) and 36 CFR 800 which provides for the preservation of potential historical architectural, archaeological, or cultural resources (hereinafter called "cultural resources").

B. The CONTRACTOR shall conform to the applicable requirements of the National Historic Preservation Act of 1966 as it relates to the preservation of cultural resources.

C. In the event potential cultural resources are discovered during subsurface excavations at the site of construction, the following procedures shall be instituted:

D. The ENGINEER will issue a Field Order directing the CONTRACTOR to cease all construction operations at the location of such potential cultural resources find.

E. Such Field Order shall be effective until such time as a qualified archaeologist can be called to assess the value of these potential cultural resources and make recommendations to the [State Water Resources Control Board Cultural Resources Officer].

F. If the archaeologist determines that the potential find is a bona fide cultural resource, at the direction of the State Water Resources Control Board Cultural Resources Officer, the CONTRACTOR shall suspend work at the location of the find under the provisions for changes contained in Articles 10, 11, and 12 of Attachment 2, Statement of Work.

(33)

SECTION 01600 -- MATERIALS AND EQUIPMENT

1.1 GENERAL

A. The word "Products," as used herein, is defined to include purchased items for incorporation into the WORK, regardless of whether specifically purchased for project or taken from CONTRACTOR's stock of previously purchased products. The word "Materials," is defined as products which must be substantially cut, shaped, worked, mixed, finished, refined, or otherwise fabricated, processed, installed, or applied to form units of work. The word "Equipment" is defined as products with operational parts, regardless of whether motorized or manually operated, and particularly including products with service connections (wiring, piping, and other like items). Definitions in this paragraph are not intended to negate the meaning of other terms used in Contract Documents, including "specialties," "systems," "structure," "finishes," "accessories," "furnishings," special construction," and similar terms, which are self-explanatory and have recognized meanings in the construction industry.

1.2 QUALITY ASSURANCE

A. Source Limitations: To the greatest extent possible for each unit of work, the CONTRACTOR shall

provide products, materials, or equipment of a singular generic kind from a single source.

B. Compatibility of Options: Where more than one choice is available as options for CONTRACTOR's

selection of a product, material, or equipment, the CONTRACTOR shall select an option which is compatible with other products, materials, or equipment already selected. Compatibility is a basic general requirement of product/material selections.

1.3 PRODUCT DELIVERY-STORAGE-HANDLING

A. The CONTRACTOR shall deliver, handle, and store products in accordance with manufacturer's written recommendations and by methods and means which will prevent damage, deterioration, and loss including theft. Delivery schedules shall be controlled to minimize long-term storage of products at site and overcrowding of construction spaces. In particular, the CONTRACTOR shall provide delivery/installation coordination to ensure minimum holding or storage times for products recognized to be flammable, hazardous, easily damaged, or sensitive to deterioration, theft, and other sources of loss.

1.4 TRANSPORTATION AND HANDLING

A. Products shall be transported by methods to avoid product damage and shall be delivered in undamaged condition in manufacturer's unopened containers or packaging.

B. The CONTRACTOR shall provide equipment and personnel to handle products, materials, and equipment by methods to prevent soiling and damage.

C. The CONTRACTOR shall provide additional protection during handling to prevent marring and otherwise damaging products, packaging, and surrounding surfaces.

1.5 STORAGE AND PROTECTION

A. Products shall be stored in accordance with manufacturer's written instructions, with seals and labels intact and legible. Sensitive products shall be stored in weather-tight enclosures and temperature and humidity ranges shall be maintained within tolerances required by

(34)

manufacturer's written instructions.

B. For exterior storage of fabricated products, they shall be placed on sloped supports above ground. Products subject to deterioration shall be covered with impervious sheet covering; ventilation shall be provided to avoid condensation.

C. Loose granular materials shall be stored on solid surfaces in a well-drained area and shall be prevented from mixing with foreign matter.

D. Storage shall be arranged to provide access for inspection. The CONTRACTOR shall periodically inspect to assure products are undamaged and are maintained under required conditions.

E. Storage shall be arranged in a manner to provide access for maintenance of stored items and for inspection.

1.6 MAINTENANCE OF STORAGE

A. Stored products shall be periodically inspected on a scheduled basis. The CONTRACTOR shall maintain a log of inspections and shall make said log available to the ENGINEER on request.

B. The CONTRACTOR shall verify that storage facilities comply with manufacturer's product storage requirements.

C. The CONTRACTOR shall verify that manufacturer-required environmental conditions are maintained continually.

D. The CONTRACTOR shall verify that surfaces of products exposed to the elements are not adversely affected and that any weathering of finishes is acceptable under requirements of Contract Documents.

1.7 MAINTENANCE OF LONG-TERM EQUIPMENT STORAGE

NTS: Specify the following for sensitive equipment in long-term storage. Expand to specify particular requirements, or specify in individual Sections.

A. For mechanical and electrical equipment in long-term storage, the CONTRACTOR shall provide a copy of the manufacturer's service instructions to accompany each item, with notice on enclosed instruction shown on exterior of package.

B. Equipment shall be serviced on a regularly scheduled basis, and a log of services shall be maintained and submitted as a record document to the ENGINEER.

(35)

SECTION 01700 -- PROJECT CLOSEOUT

PART 1 -- GENERAL 1.1 FINAL CLEANUP

A. The CONTRACTOR shall promptly remove from the vicinity of the completed work, all rubbish, unused materials, concrete forms, construction equipment, and temporary structures and facilities used during construction. Final acceptance of the WORK by the OWNER will be withheld until the CONTRACTOR has satisfactorily complied with the foregoing requirements for final cleanup of the project site.

1.2 CLOSEOUT TIMETABLE

A. The CONTRACTOR shall establish dates for equipment testing, acceptance periods, and on-site instructional periods (as required under the Contract). Such dates shall be established not less than one week prior to beginning any of the foregoing items, to allow the OWNER, the ENGINEER, and their authorized representatives sufficient time to schedule attendance at such activities.

1.3 TECHNICAL OPERATIONS MANUAL SUBMITTALS

The CONTRACTOR's attention is directed to the Project Record Documents, As-Builts and Technical Operations Manual Bid Item 18 and that ten (10) percent of the contract price will be deducted from any monies due the CONTRACTOR as progress payments, if at the 75 percent construction completion point, the approved Technical Operations Manuals have not been submitted in accordance with Section 01300, "CONTRACTOR SUBMITTALS" of the Technical Specifications. The aforementioned amount will be retained by the OWNER as the agreed, estimated value of the approved Project Record Documents, As-Builts and Technical Operations Manual is set at $5,000. Any such retention of money for failure to submit the approved Technical Operations Manuals on or before the 75 percent construction completion point shall be in addition to the retention of any payments due to the CONTRACTOR as specified in Article 14 of Attachment 2, Statement of Work.

1.4 FINAL SUBMITTALS

A. The CONTRACTOR, prior to requesting final payment, shall obtain and submit the following items to the ENGINEER for transmittal to the OWNER:

B. Written guarantees, where required.

C. Maintenance stock items; spare parts; special tools.

D. Certificates of inspection and acceptance by local governing agencies having jurisdiction.

E. Releases from all parties who are entitled to claims against the subject project, property, or improvement pursuant to the provisions of law.

1.5 MAINTENANCE AND GUARANTEE

A. The CONTRACTOR shall comply with the maintenance and guarantee requirements contained in Article 13 of Attachment 2, Statement of Work.

B. Replacement of earth fill or backfill, where it has settled below the required finish elevations, shall be considered as a part of such required repair work, and any repair or resurfacing constructed by the CONTRACTOR which becomes necessary by reason of such settlement shall likewise be considered as a part of such required repair work unless the CONTRACTOR shall have obtained a

(36)

statement in writing from the affected private owner or public agency releasing the OWNER from further responsibility in connection with such repair or resurfacing.

C. The CONTRACTOR shall make all repairs and replacements promptly upon receipt of written order from the OWNER. If the CONTRACTOR fails to make such repairs or replacements promptly, the OWNER reserves the right to do the WORK and the CONTRACTOR and his surety shall be liable to the OWNER for the cost thereof.

1.6 BOND

A. The CONTRACTOR shall provide a bond to guarantee performance of the provisions contained in Paragraph "Maintenance and Guarantee" above, and Article 13 of Attachment 2, Statement of Work.

(37)

SECTION 01720 -- PROJECT RECORD DOCUMENTS,

AS-BUILTS AND TECHNICAL OPERATIONS MANUAL

[Bid Item 3]

PART 1 - GENERAL

1.1 MAINTENANCE OF DOCUMENTS

A. Maintain at job site, one copy of each of the following as record documents:

1. Contract drawings. (Blueline, or blackline prints, as furnished by the ENGINEER, or printed from electronic format.)

2. Project Manual including Addenda/Bulletins. 3. Approved shop drawings and samples.

4. Modifications: Change Orders, Field Orders, Directives, and other written amendments to the Contract.

5. Field Test records.

B. Adhere to following guidelines for maintenance of record documents:

1. Store record documents in temporary field office, apart from documents used for construction purposes.

2. Provide files and racks for storage of record documents. 3. Maintain record documents in clean, dry and legible condition. 4. Do not use record documents for construction purposes.

5. Make the record documents available at all times for inspection by ENGINEER and other authorized users.

C. General Requirements

1. Progress Record Drawings:

a) During construction, CONTRACTOR shall keep a marked up-to-date set of record document drawings on the site as an accurate record of all deviations between the work as shown and as installed. These drawings shall be available to the OWNER and ENGINEER for inspection at any time.

b) The ENGINEER will provide to the CONTRACTOR one (1) set of Contract Drawings for the sole purpose of Progress Record Drawings. The CONTRACTOR shall be required to submit these drawings to the ENGINEER at each Progress meeting for review. The purpose of this submittal is to ensure that "As-Built" records are being kept up-to-date by the CONTRACTOR.

c) If these drawings are not kept up-to-date to the satisfaction of the OWNER or ENGINEER or the submission is not made by the requested day and time, retainage shall be held from the Contractor's Periodic Pay Estimate until a satisfactory submission is provided.

(38)

(39)

2. Progress Record Specifications:

a) During construction, CONTRACTOR shall keep on site a marked-up, up-to-date, set of record specifications annotated to clearly indicate all substitutions that are incorporated into the work. Where selection of more than one product is specified, annotation shall be available for inspection at any time by the OWNER or ENGINEER. 3. Final Record Specifications:

a) Upon completion of work, CONTRACTOR shall furnish the ENGINEER with a complete set of marked-up record specifications with "PROJECT RECORD DOCUMENTS" clearly printed on the cover.

b) The ENGINEER, at no extra cost, will furnish CONTRACTOR with a set of specifications for mark-up by CONTRACTOR. CONTRACTOR shall accurately and neatly transfer all annotations from progress record specifications to the final record specifications.

1.2 MARKING DEVICES

A. Provide fine ball-point colored pens for marking.

1.3 RECORDING

A. Label each record document 'RECORD DOCUMENT' in BOLD printed letters.

B. Within the title block on each drawing, update the Record Documents as the latest revision. Label each record document 'Field Conditions' and date each record drawing.

C. Keep record documents current.

D. Do not permanently conceal any work until required information has been recorded.

E. On the Record Contract Drawings, legibly mark to record actual construction, including but not limited to the following items:

1. Approximate location of ALL New Facilities – tanks, pumps, valves, fittings, etc.

F. On the Record Specifications and Addenda, legibly mark-up each Section to record actual information, including but not limited to the following items:

1. Manufacturer, trade name, catalog number, and supplier of each product and item of equipment actually installed.

2. Changes made by Change Order, Directive and other modifications. 3. Other matters not originally specified in the Contract Documents.

G. Shop drawings and samples: Maintain as record documents. Legibly annotate shop drawings and samples to record changes made after approval.

1.4 AUDIT

A. Project record documents will be reviewed periodically, as outlined within Paragraph 1.01 C. of this section, by the ENGINEER, who will use the current completeness of the record documents in evaluating the monthly progress payment request.

1.5 SUBMITTAL

(40)

1. Date

2. Project Title and number 3. Contractor's name and address

4. Title and number of each record document

5. Certification that each document as submitted is complete and accurate 6. Signature of Contractor, or its authorized representative.

1.6 UTILITY ACCEPTANCE

A. All new systems that will connect to a Utility Services Department facility will be dedicated to the Utility and shall fully adhere to Utility standards, unless written approval is obtained from the Utility Services Director.

B. the Utility Services Department will accept those facilities that lie within dedicated right-of-way, utility easements and property owned by the Utility and which connect to a Utility Services Department facility. The Utility will not operate, maintain or acquire ownership of any facilities unless they meet Utility standards. The Developer shall be responsible for seeing that Utility standards are met.

C. The project shall remain isolated from utility systems until the project or approved phase of the project is deemed acceptable by the Utility. No connections will be permitted to a Utility system until all required items for acceptance have been completed.

D. In order for the project to be accepted by Utility the following documentation is required: 1. Record drawings - one copy prepared and signed by the CONTRACTOR may be submitted

for review prior to final submittal. The record drawings will be reviewed by the Utility Services Department, and if there are any variations from the construction notes, the drawings may be rejected by the Utility and returned to the ENGINEER for correction prior to acceptance and activation of the system. The ENGINEER is required to provide an electronic data file of the as-built information to the Utility Services Department at the time of final acceptance.

2. Final release of liens from contractors, subcontractors, and suppliers.

3. Any other items (identified at the time application was made) which Utility requires for acceptance including recorded deeds, easements, rights of ingress and egress, itemized statement of net value, and three (3) copies of operation and maintenance manuals with manufacturers' warranties included.

1.7 SOURCE OF MAPS AND DESIGN DOCUMENTS

A. A.Digital copies of the design documents will be provided only in Adobe pdf format.

B. The OWNER will provide access to DiamondMaps.com a cloud-based GIS designed for water and wastewater systems. The link is https://diamondmaps.com/map.ashx?mid=4617. SHP (shapefiles), GPX, or CSV files can be exported from the existing GIS or GPS. Diamond Maps supports layers and imported back into Diamond Maps.

PART 2 - PRODUCTS

B TECHNICAL SPECIFICATIONS FOR

Exhibit B

TECHNICAL SPECIFICATIONS

FOR

Florida State Fire

College

Treatment and Removal of

Perfluorinated Compounds

(PFCs) from Drinking Water

Florida Rural Water Association

TABLE OF CONTENTS

DIVISION 1

SECTION 01010 -- SUMMARY OF WORK

SECTION 01025 -- MEASUREMENT AND PAYMENT

SECTION 01300 -- CONTRACTOR SUBMITTALS

SECTION 01400 -- QUALITY CONTROL

SECTION 01505 -- MOBILIZATION

SECTION 01510 -- TEMPORARY UTILITIES

SECTION 01550 -- SITE ACCESS AND STORAGE

SECTION 01560 -- TEMPORARY ENVIRONMENTAL CONTROLS

SECTION 01600 -- MATERIALS AND EQUIPMENT

SECTION 01700 -- PROJECT CLOSEOUT

SECTION 01720 -- PROJECT RECORD DOCUMENTS,

AS-BUILTS AND TECHNICAL OPERATIONS MANUAL

[Bid Item 3]
