Integrated LIGHTING. Solutions

(1)

Integrated

LIGHTING

Solutions

(2)

LINEAR LIGHTING TechZone®_Ceiling Systems

4

LINEAR LIGHTING Acoustical On-Center Linear Lighting

6

LINEAR LIGHTING Formations™_Lighting Cloud Kits

5 We understand the pain points of trying to

integrate lighting into the ceiling plane, while

being able to specify and maintain the crisp,

clean details you envision in the design.

Armstrong Ceiling Solutions has developed a

complete assortment of integrated linear, cove,

and downlight solutions to help create brilliant interior

spaces with consistent fit and finish using your favorite

Armstrong

®

ceiling panels and suspension systems.

Lighting

INTEGRATION

Made Easy

COVE LIGHTING Axiom®_Direct Light Coves

9

COVE LIGHTING Axiom®_Indirect Light Coves

10

LINEAR LIGHTING Drywall Linear Lighting

7

LINEAR LIGHTING T-BAR LED Smartlight™

(3)

LIGHTING

Partners

16

COVE LIGHTING

Axiom®_{Indirect Field} Light Coves

11

DOWNLIGHTING Intersection Downlighting

14

COVE LIGHTING Axiom®_Indirect Light Ledge

13

COVE LIGHTING

CurvedAxiom® _Indirect Light Coves

12

DOWNLIGHTING Center Cut Panel Downlighting

(4)

4

LINEAR LIGHTING

Create a sleek ceiling design with uninterrupted ribbons of light Alternate continuous lights and diffusers with other technical

services for a monolithic, uncluttered visual Ability to use with 4" and 6" configurations

TECHZONE

®

Ceiling Systems

Suprafine®/Interlude® Main Beam Yoke Yoke Light Fixture 6" x 48" TechZone Technical Panel Field 4' x 4' Panel 4' Cross Tee 6" x 48" TechZone® Technical Panel 6" x 48" Linear Diffuser Flexible Sprinkler Field 4' x 4' Panel

(5)

LINEAR LIGHTING

5

Variety of options – configurations, panels, sizes, trim color, lighting,

and applications – the possibilities are endless

Wide range of standard Axiom®_{trim and suspension system colors} adds a custom look in easy to specify kits

Kits come complete with our StrongBack™_{carrying channel,} eliminating 40% of the cables – minimizing visible wires

FORMATIONS

™

Lighting Cloud Kits

AX6VESTRWH

6" Axiom®_Vector® (Typ) A3 A5 A4 A6 Interlude XL6170 Cross Tee (Typ) Interlude 6100 Main Beam (Typ) A7 A8 STAC Single Tee Adapter Clip (Typ) SH2 Strong Back™ (Peak) (Typ) Hanger Wire Locations (Typ) A1 A2 Formations 10' x 10' Module AX4SPLICEB Splice Plate (Typ) AXCCLT Perimeter Trim Clip (Typ) AXSPLICE Splice Plate (Typ) 9' 11-7/8" 10' 4-9/16" 10' 9/16"

(6)

6

LINEAR LIGHTING

Continuous or non-continuous layouts – inspiring symmetry to match your building design

Zero interference – eliminates interference with mechanicals in the plenum Visually replaces main runner; aligns lighting with grid module

FastSize™_{Panels & Suspension Systems Program – sizes you need,} factory finished Main Beam Grid Adapter Grid Adapter Main Beam Grid Adapter Lighting Connector Bracket Hanger Wire Hanger Wire Cross Tee STAC STAC Light Fixture

On-Center

ACOUSTICAL

Linear Lighting

(7)

LINEAR LIGHTING

7

Seamless integration between drywall ceiling and lighting for

consistent fit and finish

Leverage LED in long runs to create a monolithic look – varying length and on-center spacing true to design intent

Light fixture installs from below ceiling to optimize ceiling heights

DRYWALL

Linear Lighting

LCBDGS4 Connector

Bracket install 2' from each end and 4' O.C.

DGSLL Aluminum Extrusion DGS Cross Tee Hanger Wire DGS Main Beam 5-1/8" DGS Opening Taping Flange

(8)

8

LINEAR LIGHTING

Zero plenum fixture with Armstrong®_XL®_{cross tee clips installs} like a standard cross tee for increased ceiling heights and seamless integration

Sleek energy efficient design reduces energy use up to 50% over conventional lighting

Maintain a uniform lighting design in your entire space, while achieving wall washing effects

= =

T-BAR LED

™

SmartLight

(9)

COVE LIGHTING

9

Pre-engineered for predictable lighting performance and perfect integration

Fully concealed design installs with all Armstrong®_acoustical and drywall suspension systems

Low profile design with plug and play lighting for shallow plenum corridors and entry areas

AXIOM

®

Direct Light Coves

Finished Wall 4-1/2" 1-5/8" Fixture by Others 4" 5/8" Gypsum Board Axiom Drywall Bottom Trim AXBTSTR Hold Down Clip AX-SPT-HDC Drywall Grid AX2HGC Hanger Wire to Structure Wall Attachment Clip

AXPWCCP2 AXDLC44 4" x 4" Cove AXTBC 4" 4-1/8"

4" Direct Light Cove Screw

attachment (16'' o.c.)

(10)

10

COVE LIGHTING

Variety of options from both wall and ceiling-to-ceiling light coves in a wide range of sizes

Acoustical and drywall designs with Axiom®_{Classic or} Axiom®_{Knife Edge}®_profiles

New Knife Edge®_{profile brings the acoustical panel out} to the edge of the cove

AXIOM

®

Indirect Light Coves

24" Max 6" Max

Armstrong Acoustical Grid Hanger Wire to Structure AXTBC Armstrong Drywall Grid System Hanger Wire to Structure 4-5/16" 8" 12-5/16" Armstrong Acoustical Lay-in Panel AXCCLT45 5-1/8" 1'-11/16" 5/8" Drywall 4-5/16" Light Fixture

(11)

COVE LIGHTING

11

Adjustability of the drywall vertical leg allows for field modification and ability to cut to the length desired

Designed with a notched channel for perfect integration with Axis Lighting, Vode Lighting, i2Systems®_{, and Litecontrol fixtures} Pre-manufactured corners

Easy to specify – control over finished aesthetics

AXIOM

®

Indirect Field Light Coves

Drywall Main Beam DW90 Clip DW90 Clip Hanger Wire to Structure

Suprafine Main Beam

Acoustical Tegular Panel

Reverse Angle Molding

Hanger Wire to Structure KAM (Optional)

for Easier Leveling of Axiom Cove Axiom Indirect Field Light Cove

Ceiling-to-Ceiling Knife Edge (AXIFLCCKD)

5/8" Gypsum Board AXCCLT45

Install Vertical Risers 4' O.C

(12)

Available for Axiom®_{Indirect Field Light Cove} and Axiom Indirect Light Ledge

Available in Axiom® Indirect Field Light Cove and Axiom® Indirect Light Ledge

Light Coves can now follow the curve of the design Part of the Sustain™_{portfolio and meets the most stringent}

sustainability compliance standards today 60" minimum inside and outside radii

CURVED

Axiom

®

Indirect Light Coves

DW90C

KAM12 DW90C 5-5/16" 4" AXTBC 5/8" Gypsum board

HD8906 Drywall main beam 48" O.C. XL8945 Drywall cross tee 16" O.C. Hanger wire to structure

Acoustical Tegular Panel Acoustical main beam Axiom Indirect Field Cove

Classic Curved Extrusion (AXIFL4CUR)

(13)

13

COVE LIGHTING

KAM Drywall grid main beam Drywall grid cross tee Hanger wire to structure

5/8" Drywall Axiom Indirect Light Ledge Ceiling-to-Ceiling Knife Edge Drywall (AXILLCCKD) Height and mounting location

of light ledge determined by architectural detail

5/8" Drywall 2-1/2"

Light (by others) Cut off screws to not

interfere with lights

Secure Light Ledge to wall 16" or 24" O.C. Tape bottom with mesh tape

and plaster weld

Do not screw In this area 20 ga. steel stud 7-5/16"

AXIOM

®

Indirect Light Ledge

Pre-engineered for predictable lighting performance and perfect integration

Part of the Sustain™_{portfolio and meets the most stringent} sustainability compliance standards today

Variety of options for both Ceiling-to-Wall and Ceiling-to-Ceiling light ledges

(14)

DOWNLIGHTING

14

Seamlessly integrate recessed downlights at the intersection of the grid Deliver the vision of symmetry and consistency in the design

Replace inconsistent finishes and edge details with clean, crisp factory-finished Calla®_{, Lyra}®_{, Ultima}®_{, and Optima}®_{notched panels}

INTERSECTION

Downlighting

Downlight Suspension Frame Main Beams 48" O.C. 22" Directional Cross Tee 4' Cross Tees

(15)

15

DOWNLIGHTING

Monolithic look with crisp, integrated lighting

Pre-cut downlight opening available for 3.5"or 5" square or round lights No on-site cuts needed

CENTER CUT

Panel Downlighting

Main Beams

48" O.C. 2' Cross Tees48" O.C. 4' Cross Tees

24" O.C.

Center Cut Panel

(16)

LIGHTING PARTNERS

16

Lighting Partners TechZone

®

Ceiling Systems DesignFlex

™

Ceiling System ACT

/Drywall

Linear Lighting T-BAR LED

Axiom

® Direct

Light Coves Axiom

® Indirect

Light Coves Axiom

® Indirect

Field Light Coves Axiom

® Indirect

Light Ledge Intersection Downlighting Center Cut Panel Downlighting Natural Lighting On-the-Grid Linear & Downlighting

• • • • • • • • • • • • • • • • • • • • • • • • • • •

All names listed on this page are trademarks, registered trademarks, or service marks of their respective owners.

Lighting
