ANSI Watthour Meter Testing & Certification Programs

(1)

Laboratories, Inc.

First in Certification

ANSI

Watthour Meter

Testing & Certification Programs

By Jim Reed

Manager, Meter Accuracy Lab

and Manasi Bhandiwad

(2)

Accreditations and

Recognitions

• A2LA accredited to test to ANSI C12.1 and C12.20, Measurement

Canada for electricity metering

• First Nationally Recognized Testing Laboratory (NRTL)

• Only laboratory recognized by Measurement Canada to test

previously approved electricity meters which have been modified

• FCC designated Telecommunication Certification Body (TCB)

• Certification Body (CB) by Standards Council of Canada (SCC)

• Recognized as electricity sub meter testing laboratory for the Public

Service Commission of Maryland and New York State Department

(3)

Require

me

nts –

ANSI C12.1 for Electricity Meters

MET Laboratories, Inc.

Test 1 No Load Test 21 Effect of Current Surges in Ground Conductors

Test 2 Starting Load Test 22 Effect of Superimposed Signals (this test no longer required) Test 3 Load Performance Test 23 Effect of Voltage Variation- Secondary Time Base

Test 4 Effect of Variation of Power Factor Test 24 Effect of Variation of Ambient Temperature- Secondary Time Base Test 5 Effect of Variation of Voltage Test 25 Effect of Electrical Fast Transient/Burst *

Test 6 Effect of Variation of Frequency Test 25a Effect of Electrical Oscillatory SWC Test * Test 7 Equality of Current Circuits Test 26 Effect of Radio Frequency Interference

Test 8 Internal Meter Losses Test 27 Radio Frequency Conducted and Radiated Emission Test 9 Temperature Rise Test 28 Effect of Electrostatic Discharge (ESD) *

Test 10 Effect of Register Friction Test 29 Effect of Storage Temperature Test 11 Effect of Internal Heating Test 30 Effect of Operating Temperature * Test 12 Effect of Tilt Test 31 Effect of Relative Humidity * Test 13 Stability of Performance Test 32 Mechanical Shock

Test 14 Independence of Elements Test 33 Transportation Drop Test 15 Insulation * Test 34 Mechanical Vibration Test 16 Voltage Interruptions * Test 35 Transportation Vibration Test 17 Effect of High Voltage Line Surges * Test 36 Weather Simulation Test 18 Effect of External Magnetic Field Test 37 Salt-Spray

Test 19 Effect of Variation of Ambient Temperature Test 38 Raintightness

(4)

MET Meter Testing

Programs – 4 basic types

• ANSI Meter Certification Program

• All applicable tests performed on 3 meter samples

• Report of Compliance

• MET Meter Certification Program

• All applicable tests performed on 3 meter samples

• Report of Compliance and Certificate

• Annual continued compliance

• MET Meter Certification mark can be applied to meter

• Customer Specific Test Program

• Customer specifies the test program

• Report issued on the customer specific test program

• Pre-Test Program

(5)

MET Meter Certification -

Core ANSI C12 Require

me

nts

• MET will review the meter and its components,

including analyzing the implications of

communications module additions, and test to ANSI

C12.1 or ANSI C12.20 as appropriate for the meter

• Minimum of 3 meter samples must be submitted

for testing

• Detailed report of compliance and certificate

• Maintain database of certified meters on the MET

website

• Continued compliance annually checking meter

accuracy

• MET reviews firmware and hardware modifications to

determine if further testing is necessary

(6)

Considerations when Testing

Smart Meters

• ANSI C12.1 and C12.20 accuracy standards are written for testing revenue generation utility meters: all features of the meter should be exercised

– Adapt test methods to cover features of meters that may affect test results

– Must have a computer loaded with SW for communicating with the meter and for configuring for proper operation during testing.

– Provide adequate wait time to allow meters to fully boot-up prior to starting any test sequences

– Wireless communications modules must be configured to transmit at full output power to be sure full power will not affect accuracy

(7)

Accuracy Acceptance

Testing for Modified Meters

• All applicable tests that could be affected by the modification must be

performed on no less than 3 meter samples to determine full compliance • Engineering judgment can be used to determine a subset of tests that must be

performed to assure continued compliance with the requirements of the standard

• Modified meters are evaluated on a case by case basis to determine the tests that may be affected by the modification and therefore the tests that must be re-qualified after the modification

• Generally, previously tested meters are modified by changing things like the components or hardware changes that could affect the metrology of the meter,

(8)

Conditions that could affect

Accuracy

• Temperature and humidity cycling at the extremes can affect accuracy of

meters

• Noise / interference created by the AMI/AMR modules

• High current faults or line voltage surges

• Service switches not operating after test

• Improper calibration of the meter at test amps

• Wireless AMI/AMR modules must transmit at max power

• Harmonics (voltage and current) from other equipment

on the line

• Corrosion and water ingress

• Vibration

(9)

Most Common Failures for Accuracy and

Environmental Tests

• “As received” accuracy of the meter at full load, light load and power factor conditions (before any testing) is out of tolerance

• Accuracy performance under full range of current and power factor conditions (Tests #3 & #4) • Service switches in AMI meters weld closed or fragment open during the 7000A Overcurrent

Testing (Test #20)

• Accuracy problems during or after the Operating Temperature (Test #30)

• Circuit cards and connectors becoming damaged as a result of the transportation vibration, drop or mechanical vibration tests (Tests #32 - #35)

• Discoloration of displays during the weather simulation test (Test #36)

• Water entering the meter enclosure during the rain tightness test (Test #38)

• Meter Losses (Test #8) with AMI modules installed (module can be removed for test) • Communication problems

(10)

EMC Test

Methods/Configurations

The following ANSI C12.1 tests involve EMC test methods…

• Test 15: Insulation

• Test 16: Voltage Interruptions

• Test 17: Effect of High Voltage Line Surges-6kV

• Test 18: Effect of External Magnetic Field- 100A through 1m coil

• Test 21: Effect of Current Surges in Ground Conductors- 20ms/50ms

• Test 25: Effect of Electrical Fast Transients/Burst

• Test 25a: Effect of Electrical Oscillatory SWC

• Test 26: Effect of Radio Frequency Interference

• Test 27: Radio Frequency Conducted and Radiated Emissions

(11)

Common EMC Test Failures

• Leakage current exceeding 5mA on test #15

• Component damage or watt-hour reading increase during high voltage surge -test

#17

• Emissions measured exceed FCC Part 15 subpart B limits

• kWh on display changing by more than 1 LSD during radiated immunity test #26

• AMI/AMR module damage as a result of testing

(12)

EMC testing of smart meters

• Is the product that is sent for testing a good representation of a typical installation?

• Is there any voltage sensing circuitry that needs to be disabled for insulation testing?

• Will the design withstand 6kV/3kA Surges?

• Does the meter use PLC to communicate with the utility? Is this communicated to the lab?

(13)

Things to Consider

• Get familiarized with the standards-test setups and requirements

• Evaluate your product against the ANSI test requirements right from the design stage

• If your product is a sub-meter – get together with your buyer and get the test plan approved for the applicable tests

(14)

Optional Testing –

MET

Meter Certification

• Product Safety Compliance • HALT/HASS

– Highly Accelerated Life Testing:

• Agitate the product to help reveal design weaknesses – Highly Accelerated Stress Screening:

• Test program to screen production units • Failure Evaluation

– Helps identify problems that occur after installation • Utility Defined Requirements based on field failures

– Interoperability – Software

– Extreme Environments

• FCC certification for radio communications (AMI) modules • CT Accuracy Testing

(15)

Optional Testing –

MET

Meter Certification

• Product Safety Certification

– Utilities may request the meters be listed by an NRTL

– OSHA approved to test and certify meters to UL61010-1

– MET is approved by the Standards Council of Canada for standard CSA C22.2

No. 61010-1

– UL 2735 Standard for Safety of Electric Utility Meters

– NRTL requires follow-up Inspections 2 times

per year to ensure processes and

procedures have not changed

(16)

Optional Testing –

MET

Meter Certification

• HALT/HASS

– This is a testing process that agitates the product to help reveal any

design weaknesses.

– Through this evaluation manufacturers can:

• Discover design and process flaws

• Decrease development time and cost

• Eliminate design problems that may

occur later in the product’s life cycle

• Ship as a mature product

(17)

Utility Deployment Concerns

• Problem Areas

– Hardware (Disconnect Switches)

– Communication Modules

– Software/Firmware

– Installation methods

– Corrosion

• Additional tests beyond ANSI requirements

– Wider temperature ranges

– Operational criteria

– Higher peak surges

– Moisture testing

(18)

CT Accuracy Testing

• IEEE C57.13.6

• IEC 60044-1

• IEC 60044-6

• IEC 61869-2

• ANSI C12.11

(19)

Changes Coming for ANSI

C12.1-2015 Revision

• Adding 0.5% accuracy criteria

• Definitions – add definitions for Balanced Voltages

• Tighten accuracy criteria for portable and reference standards used for testing meters • Clarify performance requirements prior to testing

• Test 5 Voltage Variation – Added reference to C12.20 for wide ranging meters

• Test 9 Temperature Rise – Eliminated Empirical Rise and changed limits to fixed limits for temperature rise at the meter socket jaws

• Test 17 Line Surges – The accuracy check can be performed after both the ring wave and combination wave surges

• Test 25a SWC Test – Duration of test changed from 2 minutes to 2 seconds

• Tests 30 & 31 Op Temp & RH – Current range now defined and the accuracy checks can be performed after both tests are completed

• Section 5 for new and in-service utility meters updated for clarity

(20)

Other Electricity Meter

Test Programs

• Measurement Canada LMB-EG-07

– Specifications for Approval of Electricity Meters

• Mexico - CFE Meter Standards – recent revisions have transitioned more

toward general harmonization with IEC requirements rather than ANSI:

– CFE G0100-05 (April 2015) – Advanced Metering Infrastructure System (AMI) – CFE GWH00-09 (January 2015) - Interactive System Infrastructure and Measuring

Electricity

• IEC 62052-11 -

Electricity Metering equipment (AC) General requirements, tests and test conditions - Part 11: Metering equipment

• IEC 62053-21 -

Electricity metering equipment (a.c.) - Particular requirements - Part 21: Static meters for active energy (classes 1 and 2)

• IEC 62053-22 -

Electricity metering equipment (a.c.) - Particular requirements - Part 22: Static meters for active energy (classes 0,2 S and 0,5 S)

(21)

Benefits of a MET Meter

Certification

• Third party unbiased evaluation by industry recognized test lab

• Ensure all meters are consistently subjected to the appropriate

standards and requirements

• Monitor product changes through annual continuing compliance

program

• Public confidence of compliance to applicable

national standards

• Industry knowledge of updates to applicable standards

• Customizable test programs

(22)

Choose MET Meter

Certification!

Please contact us for more information:
