Electronic Identification

(1)

(2)

ELID is an acronym for

El

ectronic

Id

entification

ELID was established on Sept 9, 1989 in Kuala

Lumpur, Malaysia, and is well known for supplying

Access Control Systems, Time Attendance

Systems and Integrated Security Management

Systems. She is one of the largest suppliers of

Access Control System in South East Asia.

Over the past 19 years, ELID has acquired

valuable expertise and experience in key

technologies related to the electronic identification

and integrated security management system

industry. ELID is committed to the continual

development of innovative new products year after

year.

Goal

We have progressed steadily to capture a

significant market share in South East Asia.

We aim to consolidate this, and extend our market

coverage throughout the world.

Vision

Our vision is to be a world-renowned manufacturer

of Electronic Identification Systems.

Mission

Our mission is to create original, innovative and

superior products at affordable prices and provide

genuine customer satisfaction as well as to

contribute to the well-being of society.

Belief

We believe that our greatest asset is our people.

Our people are behind our growth and success. No

matter how much capital, technology and

equipment we boast, it is bound to fail if human

resources are not developed. Therefore we strive

to “Make People Before Making Products”, and we

are committed to bring out the best in people

through comprehensive and systematic human

resource development programs.

Commitment

We will constantly challenge ourselves to be a

God-fearing, moral and ethical Company, whose

employees are honest and trustworthy, and uphold

high ethical standards in all their dealings.

(3)

Access Control System

EL360 Access Control System EL370 Access Control System EL1300 Access Control System EL1330 Access Control System EL22XX Access Control System

EL3000 Fingerprint Access Control System FC1205 Car Park Access Control System EL2205L Lift Access Control System

Time Recording Terminal

ET636 Time Recording Terminal ET630 Time Recording Terminal

ET1200 series Time Recording Terminal ET3100 Fingerprint Time Recording Terminal ET3000 Fingerprint Time Recording Terminal

Access Management Software

EsofWIN X3 EsofWIN2 E.WIN

Time Clock Interface Software

ETWIN DataCenter

E.SDK Time Clock Software Development Tool

Time Management Software

OnTime Single-shift Time Attendance Software EasyTime Single-shift Time Attendance Software Chronos Single-shift Time Attendance Software E.Time Multiple-shift Time Attendance Software OnTime Plus Multiple-shift Time Attendance Software

Reader/Keypad

Mifare Smart Card Reader HID Proximity Reader EM Proximity Reader Bar Code Reader Magnetic Reader Handkey Reader Keypad

Communicator/Converter

EL70T Communicator EL70B Communicator EL70D Communicator EL70U Communicator EL38 Communicator

EL78A LAN Terminal Server CV4823 Converter EA48 Converter EA52 Converter

Card

Miifare card HID Card EM Card Magnetic Card

Accessories

Power Supply & Transformer Metal Casing

(4)

EL360 Access Control System

The EL360 Single-Door Access Controller combines access controller, card reader and keypad, designed to work independently. Multiple units can be connected together such that programming and report generations are handled through a PC running an ELID access management software.

Storage capacity: Stores up to 2,000 users' IDs and 1,000 offline transactions Display and keypad: LED 7-segment display and 16-key keypad

Built-in proximity reading module (EM/HID/Mifare, depending on the type of card reader used)

Caters for timers and time zones, limiting access and users to different times of the day.

High security level while door is forced to open. The inputs and outputs are located on a separate module at the EZ6 which is mounted in a secure area.

Simple set-up programming with scroll-down menu within the controller Firmware can be updated in-circuit, through the serial download from the PC Equipped with a calendar clock chip to give accurate date and time

Battery back-up for internal data storage and time clock Communication Interface: RS485

Dimensions: 115(H)x90(W)x30(D) mm

Highlighted of EL360

MCU 8-bit CPU running at 40 MHz

Memory 2KB RAM, 32KB Flash, 64KB EEPROM Clock Real-time Clock with Lithium back-up Communication

Interface RS485 (2-wire)

Output 2 (Door Lock, General Purpose Output) Input 3 (Push Button, Door Sensor, Sensor

Input) In Reader Built-in Out Reader External Buzzer Built-in

Indicator LED 7-segment Tamper Switch Built-in

Power Supply 12 VDC Current Consumption 0.5A Operating Temperature (ºC) 0-50

Technical Specification Features

Card Database 2,000 Transaction Database 1,000

Card Format Wiegand 26-bit, Free Wiegand, proprietary

Operation Mode 3 (Card, Card + PIN, PIN)

Time Zone 10

Timer 24

Holiday 20

Adjustable Lock Release Time Yes Permanent Lock Release Yes Automatic Pin Disable Time

Zone

Yes Automatic Lock Release Time

Zone Yes

Inhibit Access Yes Continuous Swiping Yes

Keypad Lock Out Yes (PIN mode only) Baud Rate 2,400 to 9,600

(5)

Ordering Information

EL-0360-S02 EL360E/S Single Door Security Access System with built-in EM Proximity Reader, Keypad & EM Proximity Master Card in Silvery White Plastic Housing with Blue LED (w/o EZ6 & Power Supply Adapter)

EL-0360-B02 _{EL360E/B Single Door Security Access System with built-in EM Proximity} Reader, Keypad & EM Proximity Master Card in Black Plastic Housing with RED LED (w/o EZ6 & Power Supply Adapter)

(6)

Storage capacity: Stores up to 2,000 users' IDs and 1,000 offline transactions Display and keypad: 2x20-character backlit LCD display and 16-key keypad Built-in proximity reading module (EM/HID/Mifare, depending on the type of card reader used)

Caters for timers and time zones, limiting access and users to different times of the day

High security level while door is forced to open. The inputs and outputs are located on a separate module at the EZ6 which is mounted in a secure area Simple set-up programming with scroll-down menu within the controller Firmware can be updated in-circuit, through the serial download from the PC Equipped with a calendar clock chip to give accurate date and time

Battery back-up for internal data storage and time clock Communication Interface: RS485

Highlighted of EL370

Memory 2KB RAM, 32KB Flash, 64KB EEPROM Clock Real-time Clock with Lithium back-up Communication

Interface RS485 (2-wire)

Output 2 (Door Lock, General Purpose Output) Input 3 (Push Button, Door Sensor, Sensor

Input) In Reader Built-in Out Reader External Buzzer Built-in

Indicator 2x20-character LCD Tamper Switch Built-in

Power Supply 12 VDC Current Consumption 0.5A Operating Temperature (ºC) 0-50

Card Format Wiegand 26-bit, Free Wiegand, proprietary

Time Zone 10

Timer 24

Holiday 20

Zone Yes

Automatic Lock Release Time Zone

Yes Inhibit Access Yes Continuous Swiping Yes

EL370 Access Control System

The EL370 Single-Door Access Controller combines access controller, card reader and keypad. The features of the EL360 and EL370 are identical. The only difference is that the EL 370 has an LCD display whereby the EL360 has a 7-segment display.

(7)

EL-0370-S01 EL370E/S Single-Door Security Access System with built-in EM Proximity Reader, Keypad & EM Proximity Master Card in Silvery White Plastic Housing with GLCD display (w/o EZ6 & Power Supply Adapter)

EL-0370-B01 _{EL370E/B Single-Door Security Access System with built-in EM Proximity} Reader, Keypad & EM Proximity Master Card in Black Plastic Housing with GLCD display (w/o EZ6 & Power Supply Adapter)

(8)

Storage capacity: Stores up to 1,750 users’ IDs and 1,000 offline transactions Reader type: Supports various types of reader such as Magnetic, Proximity, Mifare Contactless Smart Card reader

Provision for Anti-passback, Automatic Lock Release Time Zone and Automatic PIN Disable Time Zone

Firmware can be updated in-circuit, through the serial download from the PC Equipped with a calendar clock chip to give accurate date and time

Battery back-up for internal data storage and time clock Communication interface: Multi-drop or RS485

Highlighted of EL1300

MCU 8-bit CPU running at 8 MHz Memory 512B RAM, 32KB Flash ROM, 16KB

EEPROM

Clock Real-time Clock with Lithium back-up Communication

Interface

Multi-drop or RS485 (2-wire)

Output 2 (Door Lock, General Purpose Output) Input 5 (Exit Push Button, Door Sensor, 3

Su-pervised Inputs) In Reader External

Out Reader External Buzzer Built-in Indicator Reader LED

Tamper Switch Built-in

Power Supply 15VAC input, 13.8V output, 1.5A output Current

Consumption

0.5A Operating

Temperature (ºC) 0-50

Card Database 1,750

Transaction Database 1,000

Card Format Wiegand 26-bit, Free Wiegand, ELID Magnetic, ABA

Time Zone 10

Timer 24

Holiday 20

Zone

Yes Automatic Lock Release Time

Zone Yes

Inhibit Access Yes Continuous Swiping

Anti-Passback Yes

EL1300 Access Control System

EL1300 Single Door Controller is designed for small to mid-sized enterprises. All functions can be programmed through its entry keypad unit. Multiple units can be connected together such that programming and report generations are handled through a PC running an ELID access management software.

(9)

EL-1300-003 EL1300 Single-Door Security Access System Module, 17VAC operation, with EM Proximity Master Card (w/o 1.5A Transformer, Reader, Keypad & Metal Housing)

(10)

Storage capacity: Stores up to 2,000 users’ IDs and 1,000 offline transactions Reader type: Supports various types of reader such as Proximity and Mifare Contactless Smart Card reader

Able to communicate with the PC through the Ethernet (EL1330 with LAN module)

Firmware can be updated in-circuit, through the serial download from the PC

Equipped with a calendar clock chip to give accurate date and time Battery back-up for internal data storage and time clock

Communication interface: Multi-drop or RS485 or Ethernet

Highlighted of EL1330

Memory 2KB RAM, 32KB Flash ROM, 32+32KB EEPROM

Interface

Multi-drop, RS485 (2-wire), or Ethernet (with LAN module)

Output 3 (Electric Lock, 2 General Purpose Outputs)

Input 6 (Exit Push Button, Door Sensor, 4 Supervised Inputs)

In Reader External

Out Reader External Buzzer Built-in Indicator Reader LED

Tamper Switch Built-in

Power Supply 15VAC input, 13.8V output, 1.5A output Current Consumption 0.5A Operating Temperature (ºC) 0-50

Card Format Wiegand 26-bit, Free Wiegand

Time Zone 10

Timer 24

Holiday 20

Zone Yes

Yes Inhibit Access Yes Continuous Swiping Yes

Anti-Passback Yes

EL1330 Access Control System

EL1330 is a single-door controller designed to work independently. The EL1330 replaces the popular EL1300 and offers a number of new features over EL1300. In addition to RS485 and ELID proprietary Multi-drop, the EL1330 offers option of using TCP/IP by plugging a LAN module on board. The numbers of inputs and outputs have been increased and a new MCU is used which operates 4 times faster than the EL1300.

(11)

EL-1330-001 EL1330 Single-Door Security Access System, 12VAC operation, with EM Proximity Master Card (w/o Power Supply Adapter, Reader, Keypad & Metal Housing) EA-TCPM-G02 TCPIP LAN Module (ZNE10T) built-in with RJ45 socket (for EL1330), 10M

(12)

Display and keypad: 2x20-character backlit LCD display and 16-key keypad Reader type: Supports various types of reader such as Magnetic, Bar Code, Proximity, Touch Memory, Mifare Contactless Smart Card reader

Provision for dual card entry, output activation mapped to input status changes, fast reading speed and tail tag alarm operation

Battery back-up for internal data storage and time clock Communication interface: Multi-drop

Highlighted of EL2200

EL2200 Access Control System

The EL2200 has established a solid reputation as an extremely reliable and versatile controller, easy-to-learn, easy-to-use and problem free. Various options and accessories allow the EL220X to be used for controlling doors (1 or 2 doors), elevators (up to 64 floors), car-park barriers (with Anti-passback) and time attendance.

EL2200

The EL2200 is packaged in a plastic casing, with display and keypad on the cover, allowing the unit to be wall-mounted at eye level, to facilitate programming and report viewing.

EL2205

The EL2205 is designed for mounting inside a metal panel together with power supply and back-up battery. The EL2205 can be expanded to become a 2-door, 2-reader controller by adding an EA2207 extension board.

Storage capacity: Stores up to 12,800 user-IDs and 4,000 offline transactions User Database Transaction Database

Standard EL220X 1,600 2,000

Standard EL220X 3,200 1,000

EL220X with extended memory 6,400 4,000 EL220X with extended memory 12,800 2,000

(13)

MCU 8-bit CPU Out Reader External Memory 32KB/128KB SRAM, 512 EEPROM Buzzer Built-in

Clock Real Time Clock with Lithium back-up Indicator 2x20-character LCD

Communication Interface Multi-drop Tamper Switch Built-in

Output 1 (On-board), 6 (Optional) Power Supply 15VAC input, 13.8V output, 2.5A output

Input 2 (On-board), 2 (Optional) Current Consumption 90Ma

In Reader External Operating

Temperature (ºC)

0-50 Technical Specification

Card Database 1,600 (Maximum 12,800) Automatic Pin

Disable Time Zone Yes Transaction Database 1,000 (Maximum 4,000) Automatic Lock

Release Time Zone Yes Card Format Wiegand 26-bit, Free Wiegand,

ELID Magnetic, ABA, Bar-Code Inhibit Access Yes Operation Mode 3 (Card, Card + PIN, PIN) Continuous Swiping Yes

Time Zone 10 Anti-Passback Yes

Timer 24 Dual Card Yes

Holiday 20 Keypad Lock Out Yes (PIN mode only)

Adjustable Lock

Release Time Yes Baud Rate 2,400

Permanent Lock Release

Yes Features

(14)

EL-2200-001 EL2200 Security Access System with LCD & EM Proximity Master Card in Plastic Hous-ing (w/o EP23 & Reader) - 212(H)x155(W)x55(D) mm

EL-2205-020 EL2205 Security Access System Module with LCD, Keypad & EM Proximity Master Card (w/o Power Supply, Reader & Metal Housing)

EA-2207-001 EA2207 Extension Board c/w Accessories for EL2205

(15)

Display and keypad: 2x16-character backlit LCD display and 16-key keypad Built-in proximity reading module (EM/HID/Mifare, depending on the type of card reader used)

High accurate fingerprint recognition

Fast verification time; suitable and effective for office or clean working environment

Multiple verification mode

High security level while door is forced to open. The inputs and outputs are lo-cated on a separate module at the EL3Z which is mounted in a secure area Simple set-up and enrolment programming with scroll-down menu within the controller

Battery back-up for internal data storage and time clock Communication interface: RS485 (4-wire)

Dimensions: 190(H) x 120(W) x 50(D) mm

Highlighted of EL3000

EL3000 Access Control System

The EL3000 FINGERFLEX Controller combines access controller, card reader and fingerprint recognition all-in-one compact and unique system designed after the shape of a human thumb.

Scanner: Silicon sensor. It provides accurate fingerprint recognition without being affected by skin texture and condition.

Storage capacity: up to 10,000 users and 10,000 offline transactions Verification Mode Storage Capacity (maximum)

Fingerprint only 89 users

ID + PIN, ID only 10,000 users ID + Fingerprint 3,600 users Card (Elid format) + Fingerprint 10,000 users

(16)

MCU Out Reader External

Memory Buzzer Built-in

Clock Real Time Clock with Lithium back-up Indicator 2x16-character LCD Fingerprint Sensor Silicon, 500 dpi Tamper Switch Built-in

Communication Interface

RS485 (4-wire) Power Supply 12V DC Output 1 (EM-Lock) Current Consumption 12V / 1 A Input 2 (Door Sensor, Push Button) Operating

Temperature (ºC)

-20°C and 70°C Additional I/O (EL3Z) 4-Input (non-supervise) and

6-Output Operating Humidity <85% In Reader Built-in

Technical Specification

User Database 10,000 (adjustable) Holiday 40 Transaction Database 10,000 Adjustable Lock

Release Time

Yes Verification Mode Fingerprint only (1:N), ID only, ID

+ Fingerprint (1:1), ID + PIN Permanent Lock Release Yes Verification Time < 1 second Automatic Pin/

Fingerprint Disable Time Zone

Yes

Enrollment Maximum 2 fingerprints enrollment per user

Yes False Rejection Rate <0.5% Inhibit Access Yes False Acceptance Rate <0.001% Continuous Swiping Yes Card Format Wiegand 26-bit, Free Wiegand Anti-Passback Yes

Time Zone 24 Baud Rate 2,400 to 57,600

Timer 24

(17)

EL-3000-001 ET3000/MF FINGERFLEX Time Terminal, Built-in with Mifare Contactless Reader in Plastic Housing (w/o PS) - 190(H)x120(W)x50(D) mm

EL-3000-002

EL-3000-003 EL3000/HID Fingerflex Biometric Access System, Built-in with HID Reader in Plastic Housing c/w Template Backup Manager Software (w/o PS) - 190(H) x120(W)x50(D) mm

EL3000/EM Fingerflex Biometric Access System, Built-in with EM Reader in Plastic Housing c/w Template Backup Manager Software (w/o PS) - 190(H) x120(W)x50(D) mm

(18)

Storage capacity: Stores up to 3,200 user-IDs and 2,000 offline transactions Display and keypad: 2x20-character backlit LCD display and 16-key keypad Reader type: Supports various types of reader such as Magnetic, Bar Code, Proximity, Mifare Contactless Smart Card reader

Comprehensive Anti-passback feature for car-park management Simple set-up programming with scroll-down menu within the controller Firmware can be updated in-circuit, through the serial download from the PC Equipped with a calendar clock chip to give accurate date and time

Dimensions: 381(H)x330(L)x91(W) mm

Highlighted of FC1205

CU 8-bit CPU

Memory 32KB/128KB SRAM, 512 EEPROM

Interface

Multi-drop

Output 1 (On-board), 6 (Optional)

Input 2 (On-board), 2 (Optional) In Reader External

Out Reader External

Buzzer Built-in

Power Supply 15VAC input, 13.8V output, 2.5A output

Current

Consumption 90Ma Operating

Card Database 3,200

Card Format Wiegand 26-bit, Free Wiegand, ELID Magnetic, ABA, Bar-Code

Operation Mode 1(Card)

Time Zone 10

Holiday 20

Permanent Lock Release Yes Inhibit Access Yes

Anti-Passback Yes

ATZ Mode Yes

Keypad Lock Out Yes (PIN mode only)

Baud Rate 2,400

FC1205 Car Park Access Control System

The FC1205 Car Park System caters for a small car park with one entry barrier and one exit barrier. The controller is housed in a sturdy metal cabinet. Programming can be done either via using the keypad at the controller panel or remotely via a PC.

(19)

EB-1205-001 FC1205 Car Park Access System for 1-Entry & 1-Exit Point c/w EL2205 Board, EP23 Power Supply, LCD, 16-keys Keypad for programming & Relay in Metal Housing, (w/o Master Card)

(20)

Storage capacity: Stores up to 2,700 user-IDs and 2,000 offline transactions Display and keypad: 2x20-character backlit LCD display and 16-key keypad Reader type: Supports various types of reader such as Magnetic, Bar Code, Proximity, Mifare Contactless Smart Card reader

Dimensions: 415(H)x405(W)x121(D) mm for each metal casing

Highlighted of EL2205L

MCU 8-bit HCMOS running at 4.9 Mhz Memory 32KB SRAM, 512B EEPROM Clock Real Time Clock with Lithium back-up Communication

Interface Multi-drop In Reader External Out Reader External Buzzer Built-in

Power Supply 15VAC input, 13.8V output, 2.5A output

Current Consumption

90mA excluding reader Operating

CPU MC68HC05C8 8-bit MPU Output 32 channels

Interface Relay 1 SPDT, 3A rating

Technical Specification Features

Card Format Wiegand 26-bit, Free Wiegand, ELID Magnetic, ABA, Bar-Code Operation Mode 3 (Card, Card + PIN, PIN)

Time Zone 10

Timer 24

Holiday 20

Zone

Yes Automatic Floor Time Zone Yes

Floor Zones 64

Inhibit Access Yes Continuous Swiping Yes

Dual Card Yes

Keypad Lock Out Yes (PIN mode only)

Baud Rate 2,400

EL2205L Lift Access Control System

The EL2205L Lift Access Controller extends control to elevators. One relay contact is provided for each floor that the lift serves. Maximum size is up to 64 floors. EL2205L consists of 3 parts. The main controller and power supply is housed in a single metal cabinet. Reader is usually mounted at the lift operation panel, while floor selection board with associated relays is separately mounted in another cabinet. Communication between floor selection unit and main controller may be up to 1 KM. Programming can be done either via using the keypad at the controller panel or remotely via a PC.

(21)

EL-2205-L16 EL2205L/16 Lift Access System (Reader Optional) For 1-16 Floors Comprising: (w/o Master Card)

1 x EL2205 Board, 2 x EP23 Power Supply 1.3A/12V, 1 x EB485 Board, 1 x EFD0016 Floor Selector (XS -1608-003), 1 x ES8A-1 Relay Board (16 points) & Mounted in metal casings x 2 (CS-1099)

1 x EL2205 Board, 2 x EP23 Power Supply 1.3A/12V, 1 x EB485 Board, 1 x EFD0032 Floor Selector (XS-1608-003), 3 x ES8A-1 Relay Board (32 points) & Mounted in metal casings x 2 (CS-1099) EL-2205-L48 EL2205L/48 Lift Access System (Reader Optional)

For 1-48 Floors Comprising: (w/o Master Card)

1 x EL2205 Controller, 1 x EP23 Power Supply 1.3A/12V, 1 x EB485 Board, 1 x EFD0032 Floor Selector (XS-1608-003), 1 x EP23 Power Supply 1.3A/12V, 3 x ES8A-1 Relay Board (32 points) & 1 x EFD0016 Floor Selector (XS-1608-003), 1 x EP23 Power Supply 1.3A/12V, 1 x ES8A-1 Relay Board (16 points) & Mounted in metal casings x 3 (CS-1099)

1 x EL2205 Board, 3 x EP23 Power Supply 1.3A/12V, 1 x EB485 Board, 2 x EFD0032 Floor Selector (XS-1608-003), 6 x ES8A-1 Relay Board (64 points) & Mounted in metal casings x 3 (CS-1099)

(22)

Storage capacity: Stores up to 6,000 offline transactions and unlimited user Displays: 128x64 pixel Graphical backlit LCD

Keypad: 4x4 matrix membrane keypad with feather-touch keys

Built-in proximity reading module ((EM/HID/Mifare, depending on the type of card reader used)

Basic access control function through the connection of relay output to an electric lock

Can integrate with third party time attendance software

Simple set-up programming with scroll-down menu within the controller Firmware can be updated in-circuit, through serial download from PC

Equipped with a calendar clock chip with on-board back-up battery to give accu-rate date and time

Battery back-up for internal data storage and time clock Communication interface: RS485

Dimensions:

Highlights of ET630

MCU 8-bit CPU running at 40 MHz Memory 2 x 256K-bit EEPROM

Clock Real Time Clock with Lithium back-up Communication

Interface

RS485 (2-wire) Output 1 (General Purpose) Input 1 (Exit Push Button) In Reader Built-in

Buzzer Built-in

Indicator Graphical backlit LCD, Buzzer Power Supply 9V-15V Current Consumption 200mA Operating Temperature (ºC) 0-55

Technical Specification Features

Card Database Unlimited (Time Clock), 500 (Door Access)

Card Format Wiegand 26-bit, Free Wiegand Operation Mode 1 (Card)

Mode of Database 3

Session 1

Job Code 99

Time Zone for Sounder 1 Timer for Sounder 7 Time per timer 30 Time Zone for Sounder 1 Timer for Sounder 30

Holiday 40

Adjustable Lock Release Time Yes Automatic Lock Release Time

Zone Yes

Baud Rate 2,400 to 9,600

ET630 Time Recording Terminal

ET630 is a versatile Time Recording Terminal with basic access control features and user friendly interface.

(23)

ET-0630-002 ET630 Time Recording Terminal, EM Reader c/w cable ET-0630- ET630 Time Recording Terminal, HID Reader c/w cable ET-0630- ET630 Time Recording Terminal, Mifare Reader c/w cable

(24)

Storage capacity: Stores up to 6,000 offline transactions and unlimited user Display: 128x64 pixels Graphical backlit LCD

Keypad: 4x4 matrix membrane keypad with feather-touch keys

Simple set-up programming with scroll-down menu within the controller Firmware can be updated in-circuit, through serial download from PC

Equipped with a calendar clock chip with on-board back-up battery to give accu-rate date and time

Battery back-up for internal data storage and time clock Communication interface: USB

Dimensions:

Highlights of ET636

MCU 8-bit CPU running at 40 MHz Memory 2 x 256K-bit EEPROM

Clock Real Time Clock with Lithium back-up Communication

Interface

USB In Reader Built-in Buzzer Built-in

Indicator Graphical backlit LCD, Buzzer Power Supply 5V USB power supply

Current Consumption 200mA Operating Temperature (ºC) 0-55

Card Database Unlimited (Time Clock)

Card Format Wiegand 26-bit, Free Wiegand

Operation Mode 1 (Card) Mode of Database 3

Session 1

Job Code 99

Time Zone for Sounder 1 Timer for Sounder 7 Time per timer 30

Holiday 40

ET636 Time Recording Terminal

ET636 is a versatile Time Recording Terminal simply designed for ease of use. The features of the ET630 and ET636 are identical. The only difference is the hardware setup for the system. ET636 is directly plugged into the PC via USB cable for data polling and power supplying.

(25)

ET-0636-001 ET636/E Time Recording Terminal with Stand (USB Communication), Chronos Software Installation CD, 10 EM Proximity Cards, USB Cable, Quick Start & User Manual contained in CD

ET-0636- ET636/H Time Recording Terminal with Stand (USB Communication), Chronos Software Installation CD, 10 HID Proximity Cards, USB Cable, Quick Start & User Manual contained in CD.

ET-0636- ET636/M Time Recording Terminal with Stand (USB Communication), Chronos Software Installation CD, 10 Mifare Proximity Cards, USB Cable, Quick Start & User Manual contained in CD

(26)

Storage capacity: Stores up to 10,000 offline transactions and unlimited user or 2,000 ID numbers.

Display: 2x20-character LCD and 4x7-segment LED display Keypad: 16-key keypad

Reader: Supports various types of reader such as Magnetic, Bar Code, Prox-imity, Touch Memory, Mifare Contactless Smart Card reader

Incorporated a complete set of diagnostic test routines Improved data storage integrity checking

Caters for 9 working sessions with In & Out selection respectively

Built-in firmware allows ET1200 to be used with Job Costing, and Meal Subsidy application software

Highlights of ET1200 series

MCU 8-bit HCMOS running at 4.9 Mhz Memory 32KB/128KB SRAM, 512 EEPROM Clock Real Time Clock with Lithium back-up Communication

Interface

Multi-drop

Output 1

Input 2

In Reader Built-in (except ET1205)

Buzzer LED

Indicator Built-in

Power Supply 240VAC input or 110VAC, 50 or 60Hz Internal Back-up

Battery 12V/1.2AH Sealed Lead Acid Battery Current Consumption 90Ma

Operating Temperature (ºC)

0-50

Card Database unlimited user or 2,000 ID numbers

Card Format Wiegand 26-bit, Free Wiegand, ELID Magnetic, ABA, Bar-Code Operation Mode 1 (Card)

Mode of Database 3

Session 9

Job Code 999

Time Zone for Sounder 18 Timer for Sounder 18

Holiday 20

Adjustable Lock Release Time

Yes

Auto Time Command Yes Baud Rate 2400-9600

ET1200 series Time Recording Terminal

The ET1200 Time Recording Terminal is housed in a sturdy metal cabinet. Power supply, including back-up battery (for 6 hours operation), lightning surge protector, and time operated relay output for linking to an external sounder are all built in.

(27)

ET-1241-001 ET1241 Time Clock c/w Extended Memory (10K transaction records), ER35

Infra Red Bar Code Reader, backlit LCD, EP23 Power Supply, 12V/1.3AH

Battery, Metal Housing & 1 set Barcode Master Card (2/5)

ET-1237-001 ET1237 Time Clock c/w Extended Memory (10K transaction records), ERM23

Proximity Reader, backlit LCD, EP23 Power Supply & 12V/1.3AH Battery in

Metal Housing .

ET-1233-001 ET1233 Time Clock c/w Extended Memory (10K transaction records), ERH23

Proximity Reader, backlit LCD, EP23 Power Supply, 12V/1.3AH Battery &

Metal Housing

ET-1201-001 ET1201 Time Clock c/w Extended Memory (10K transaction records),

Magnetic Reader, EP23 Power Supply & 12V/1.3AH Battery in Metal Housing

ET-1205-001 ET1205 Time Clock c/w Extended Memory (10K transaction records), backlit LCD, EP23 Power Supply & 12V/1.3AH Battery in Metal Housing (w/o Reader)

(28)

Scanner : Optical sensor

Storage capacity: Stores up to 30,000 offline transactions and 9,000 fingerprint templates

Display: 128x64 pixels Graphical backlit LCD Keypad: 16-key keypad

Support proximity reader

Fast verification time; suitable and effective for office or factory environment Enables enrolment of up to 10 fingerprints for each user

Simple set-up and enrolment programming with scroll-down menu within the controller

Battery back-up for internal data storage and time clock Communication Interface: RS485, TCP/IP LAN (optional) Dimensions: 180(H) x 150(W) x 50(D) mm

Highlights of ET3100

ET3100 Bioflex Fingerprint Time Recording Terminal

ET3100 is a user-friendly, reliable and cost-effective Optical Fingerprint Recognition Time Recording Terminal. It captures and stores fingerprint image as template and verifies each specific finger's unique ridge pattern for highly personalized identification. Therefore, abuse of time attendance through 'buddy punching' will never happen. The ET3100 also doubles up as a basic door access control system which secures your company's premises from unauthorized access.

MCU MC9S12GC128 Out Reader External

Memory 512kbytes SRAM Buzzer Built-in

Clock Real Time Clock with Lithium back-up

Indicator LED

Fingerprint Sensor Optical, 500 dpi Tamper Switch Built-in Communication Interface RS485, LAN (optional) Power Supply 12V DC Onboard Output 2 (EM-Lock, Sounder) Current Consumption 1.5A to 2.5A Onboard Input 2 (Door Sensor, Push

Button) Operating Temperature (ºC) 0°C - 55°C In Reader External Operating Humidity <85%

(29)

ET-3100-001 ET3100 Fingerprint Time Recording Terminal, c/w DataCenterFP BioFlex interface Software & Templete Backup Manager Software for ET3100 in CD only

ET-3100-L01 ET3100/L Fingerprint Time Recoring Terminal, built-in with TCP/IP, c/w DataCenterFP BioFlex interface Software & template Backup Manager Software for ET3100 in CD only

User Database 10,000 Session 9

Fingerprint Template

Database 9,000 templates Job Code 999

Transaction Database 30,000 Time Zone for Sounder 1 Verification Mode Fingerprint only (1:N), ID

only, ID + Fingerprint (1:1), ID + PIN

Timer for Sounder 4

Verification Time Average 1 second for 1000 fingerprint templates

Times per Timer 18 Enrollment Maximum 10 fingerprints

enrollment per user

Holiday 20

False Rejection Rate 1.4% Adjustable Lock Release

Time Yes

False Acceptance Rate 0.00001% Baud Rate 2,400 to 57,600

(30)

Display and keypad: 2x16-character backlit LCD display Keypad: 16-key keypad

Fast verification time; suitable and effective for office or clean working environment

Simple set-up and enrolment programming with scroll-down menu within the controller

Battery back-up for internal data storage and time clock Communication interface: RS485 (4-wire)

Dimensions: 190(H) x 120(W) x 50(D) mm

Highlights of ET3000

ET3000 Fingerprint Time Recording Terminal

The ET3000 combines time recording terminal, card reader and fingerprint recognition all-in-one compact and unique system designed after the shape of a human thumb.

Scanner: Silicon sensor. It provides accurate fingerprint recognition without being affected by skin texture and condition.

Storage capacity: up to 10,000 users and 10,000 offline transactions Verification Mode Storage Capacity (maximum)

Fingerprint only 89 users

ID + PIN, ID only 10,000 users ID + Fingerprint 3,600 users Card (Elid format) + Fingerprint 10,000 users

(31)

MCU Out Reader External

Memory Buzzer Built-in

Clock Real Time Clock with Lithium back-up Indicator LED, Buzzer Fingerprint Sensor Silicon, 500 dpi Tamper Switch Built-in Communication

Interface RS485 (4-wire) Power Supply 12V DC Output 1 (EM-Lock) Current Consumption 12V / 1 A Input 2 (Door Sensor, Push Button) Operating

Temperature (ºC) -20°C and 70°C Additional I/O (EL3Z) 4-Input (non-supervise) and

6-Output

Operating Humidity <85% In Reader Built-in

User Database 10,000 (adjustable) Timer 24

Transaction Database 10,000 Holiday 40

Verification Mode Fingerprint only (1:N), ID only, ID + Fingerprint (1:1), ID + PIN

Adjustable Lock Release Time

Yes Verification Time < 1 second Permanent Lock

Release

Yes Enrollment Maximum 2 fingerprints

enrollment per user Automatic Pin/Fingerprint Disable Yes False Rejection Rate <0.5% Automatic Lock

Release Time Zone

Yes False Acceptance Rate <0.001% Inhibit Access Yes

Session 9 Continuous Swiping Yes

Job Code 999 Anti-Passback Yes

Time Zone 24 Baud Rate 2,400 to 57,600

(32)

ET-3000-001 ET3000/MF FINGERFLEX Time Terminal, Built-in with Mifare Contactless Reader in Plastic Housing (w/o PS) - 190(H)x120(W)x50(D) mm

ET-3000-002 ET3000/EM FINGERFLEX Time Terminal, Built-in with EM Reader in Plastic Housing c/w Template Backup Manager Software (w/o PS) - 190(H)x120(W) ET-3000-003 _{ET3000/HID FINGERFLEX Time Terminal, Built-in with HID Reader in Plastic}

Housing c/w Template Backup Manager Software (w/o PS) - 190(H)x120(W)x50 (D) mm

(33)

System Requirement

Provides system access rights for different users

Simple setting of time zones, door-access levels and lift-floor access for card holders

Provides basic alarm monitoring features (Acknowledge, Disarm and Arm) Provides real-time activity monitoring, which means activities occurring at the controllers are reported immediately and displayed on the On-line Monitoring Screen or redirected to a printer connected to the PC

Report filtering up to 3 layers

The attendance records can be exported into text/Excel format which can be used for integration with third party software

Multiple-shift time attendance software (OnTime Plus) is an optional module that integrated into EsofWIN2 to monitor staff’s attendance effectively

Provides modem support module that supports Hayes compatible dial-up and leased line modems.

Available in English, Chinese, Malay and Portuguese

Highlights of EsofWIN2

EsofWIN2

The EsofWIN2 is a Windows-based single workstation access management software. EsofWIN2 is rich in features, offering an easy way to manage security of up to 64 controllers, and generate time attendance reports (together with OnTime single-shift time attendance software).

A powerful graphic user interface is provided, where devices and doors status appear as icons on floor-plan maps, and the icon changes as status of the device changes. It also allows pictures of users to be put into the database.

Processor Pentium IV or higher Operation

System Microsoft Windows 2000/XP or higher RAM 128 MB or higher

HDD 30 MB (Installation) 100 MB (Operation) Comm. Port 1

Printer Port 1

(34)

EW-EWIN-007 _{EsofWIN /0 Software, 1-4 Doors c/w FREE add-on OnTime in Software CD}

EK-0021-001 EsofWIN /1 Software Key (DB9), 1-16 Doors c/w FREE add-on OnTime in Software CD (Softkey, DB9)

EK-0027-001 EsofWIN /5 Software Key (DB9), up to 64 Doors, Modem Version c/w FREE add-on OnTime in Software CD (Softkey, DB9)

Optional Combination Software Key EsofWIN + OnTime Plus:

EK-0012-EKM EsofWIN /1 Single-User Access Management Software + OnTimePlus /3 Time Attendance Software (unlimited users), 1-16 Doors in CD (Softkey, DB9)

EK-0021-EKM EsofWIN /5 Single-User Access Management Software + OnTimePlus /3 Time Attendance Software (unlimited users), Modem Version, 1-64 Doors in CD (Softkey, DB9)

(35)

System Requirement

Administrator is able to access the full system whereby the user only can view the software only

Simple setting of time zones (maximum 10 time zones), door-access levels and lift-floor access for card holders

Available in English, Chinese

Highlights of EsofWIN X3

EsofWIN X3

The EsofWIN X3 is a simplified version of EsofWIN2 and only supports up to 8 doors. It provides most of the common features of EsofWIN2, but the GUI has been

redesigned to be particularly user friendly. It also has built-in single-shift time attendance software (EasyTime).

Processor Pentium IV or higher Operation

System Microsoft Windows 2000/XP or higher RAM 128 MB or higher

Printer Port 1

Display 800 x 600 (16 colours) or higher

EW-EWIN-X00 _{EsofWIN X3 Single-User} Access Management Software in CD only, 1-8 doors

(36)

System Requirement

Provides system access rights for different users

Provides a comprehensive audit trail reports of administrator/user’s actions Supports TCP/IP network’s setting

Simple setting of time zones, door-access levels and lift-floor access for card holders

Provides “Car Counting” facility

Report filtering up to 3 layers

Provides a built-in tiny web server module enabling the E.WIN information to be viewed through the standard web browsers anywhere at anytime easily

Multiple-shift time attendance software (E.Time) is an optional module that inte-grated into E.WIN to monitor staff’s attendance effectively

Provides modem support module that supports Hayes compatible dial-up and leased line modems

Available in English and Chinese

Highlights of E.WIN

E.WIN

The E.WIN is an enhanced version of EsofWIN2. It provides graphical user interface for data entry and information retrieval thus offering an easy way to manage security of up to 128 doors. It also has built-in single-shift time attendance software.

It is ideally designed with vast options and capabilities commonly required for a medium sized organization. E.WIN can be recognized easily as a key solution for security risks, enabling users with a peace of mind for a cost effective, robust and easily upgradeable system.

Processor Pentium IV or higher

Operation System Microsoft Windows 2000/XP or higher RAM 128 MB or higher

Printer Port 1

(37)

EW-EWIN-X00 E.WIN /0 Single-User Access Management Software for controlling 1-4 Doors, add-on OnTime Time Attendance Software (Single-Shift) in CD

EW-EWIN-D01 E.WIN /1 Single-User Access Management Software for controlling 16 Doors, add-on OnTime Time Attendance Software (Single-Shift) & E.WIN LAN Module in CD (Softkey, DB9)

Optional Software Modules for E.WIN

EW-EWIN-M01 E.WIN Time Management Module (E.Time), Multiple-Shift EW-EWIN-M02

EW-EWIN-M03

E.WIN Lift Access Module E.WIN Modem Module EW-EWIN-M05 E.WIN WEB Support Module

(38)

ETWIN

ETWIN is meant for users who have their own Time Attendance software, but do not

wish to write polling routines to talk to ELID Time Recording Terminals. ETWIN only works with ET1200 series. It provides an output file in text file format. Integration can be done through the output text file (LatestTrans.dat).

Standard, Modem & Terminal Server version are available in ETWIN.

EK-021T-RK1 ETWIN V2 /1 Software Key (USB), Standard Version, support 64 clocks c/w Software CD (w/o Serial Cable)

DataCenter

DataCenter is meant for users who have their own Time Attendance software, but do

not wish to write polling routines to talk to ELID Time Recording Terminals. DataCenter only works with ET630. It provides an output file in text file format. Integration can be done through the output text file (LatestTrans.dat).

EK-022T-RK1 ETWIN V2 /2 Software Key (USB), Standard + Modem Version, support 64 clocks c/w Software CD (w/o Serial Cable)

EK-023T-RK1 _{ETWIN V2 /3 Software Key (USB), Standard + Modem + Terminal Server} Version, support 64 clocks c/w Software CD (w/o Serial Cable)

(39)

E.SDK Time Clock Software Development Tool

E.SDK is a set of interface tools which allows the developers to develop their software using ELID’s Time Recording Terminals (ET1200 series, ET630, ET636 & ET3100). It allows integration with various software, making it versatile for many reasons.

The E.SDK consists of 3 parts: DLL, Command Line Application and GUI

Dynamic Link Library (DLL)

The Dynamic Link Library provides an Application Program Interface (API) prepared for development of the PC application that integrates the time clock functionalities. It supports various development tools: Microsoft Visual Basic 6.0 (or above), Borland Delphi, etc.

The E.SDK provides sample coding in Delphi Programming language and Visual Basic Programming language.

Graphical User Interface Application (GUI)

The Graphical User Interface Application on the other hand is a simple polling software. It provides an output file in text file format. Integration can be done through the output text file (LatestTrans.dat).

Highlights of DLL, Command Line

Synchronizes the time clock date and time with the PC date and time Downloads transactions from the time clock

Installs and deletes the card number from the time clock

Uploads, downloads and deletes fingerprint templates from the time clock Time clock settings: set sounder, set session, etc

System Requirement

HDD 10 MB (Installation) ? MB (Operation) Comm. Port 1

Printer Port 1

(40)

OnTime Single-shift Time Attendance Software

OnTime Time Management Software is a Windows-based software which works with ET1200 series Time Recording Terminals. The software allows clock data in the time recording terminals to be uploaded to the PC, and processed to generate attendance and overtime reports. These reports can also be exported for use by third party payroll software to generate overtime pay.

Highlights of OnTime Single-shift

Processor Pentium II or higher

Operation System Microsoft Windows 98 or higher RAM 64 MB or higher

HDD 3 MB (Installation) ? MB (Operation) Comm. Port 1

Printer Port 1

Display 800 x 600 (16 colours) or higher System Requirement

Implement access right to prevent unauthorized access

More than 7 predefined reports to record employees’ attendance Provides leave management to record leave taken

Attendance Records can be exported to Excel file (.xls) or text file (.txt) which can be used for integration with third party software

Employee’s information and clocks data in text file or Excel file can be imported to OnTime’s database for attendance reprocessing

Company name and logo can be personalized Support user definable staff database

Language Support: English

EK-010T-001 OnTime Time Attendance Software, Single-Shift, unlimited users in CD (with ET10 Softkey, DB9)

(41)

EasyTime Single-shift Time Attendance Software

EasyTime is a Window-based software written to monitor staff attendance effectively and conveniently for ET630 and ET636 Time Recording Terminal. EasyTime provides numerous reports on staff’s attendance status as well as exporting clock data to third party payroll system.

Highlights of EasyTime

Processor Pentium III or higher

Operation System Microsoft Windows 98 or higher RAM 128 MB or higher

Printer Port 1

Implement access right to prevent unauthorized access

More than 7 predefined reports to record employees’ attendance Provides leave management to record leave taken

Attendance Records can be exported to Excel file (.xls) or text file (.txt) which can be used for integration with third party software

Employee’s information and clocks data in text file or excel file can be imported to EasyTime’s database for attendance reprocessing

Company name and logo can be personalized

Support user definable staff database and user photo images Language Support: English

EW-ETD0-000 EasyTime Time Attendance Software (Single-shift) in CD only (no softkey)

(42)

Chronos Single Time Attendance Software

Chronos is a Window-based user friendly time attendance software written to monitor staff attendance effectively. Chronos works with all Elid Time Clocks and provides numerous reports on staff’s attendance status as well as exporting clock data to third party payroll system.

Highlights of Chronos

Printer Port 1

Provides a startup wizard which leads the user to complete the basic settings Implement access right to prevent unauthorized access

Provides real-time activity monitoring, which means In and Out transactions are reported immediately and displayed on Chronos

20 predefined reports to record employees’ attendance Provides leave management to record leave taken

Attendance of employees can be edited by the administrator

Provides a comprehensive audit trail reports of administrator/user’s actions Attendance Records can be exported to Excel file (.xls) or text file (.txt) which can be used for integration with third party payroll software to generate salary

Employee’s information and clocks data in Excel file or text file can be imported to Chronos’s database for attendance reprocessing

Support user definable staff database and user photo images

Language Support: English, Malay, Chinese Simplified, Chinese Traditional, Thai

EW-CNOS-000 Chronos Time Attendance Management Software in CD only, Single-shift, Standalone (no softkey)

(43)

E.Time Multiple-shift Time Attendance Software

E.Time is a Windows based Time Attendance Management software, designed to works with all Elid Time Clocks and monitor staff attendance effectively. It is suitable for use in a factory environment to track shift functions accurately.

Highlights of E.Time

Printer Port 1

Provides a startup wizard which leads the user to complete the basic settings Implement access right to prevent unauthorized access

Provides group scheduling and individual scheduling that helps divide employees into different working schedules

Provides real-time activity monitoring, which means In and Out transactions are reported immediately and displayed on E.Time

21 predefined reports to record employees’ attendance Provides leave management to record leave taken

Provides a comprehensive audit trail reports of administrator/user’s actions Attendance Records can be exported to Excel file (.xls) or text file (.txt) which can be used for integration with third party payroll software to generate salary

Employee’s information and clocks data in Excel file or text file can be imported to E.Time’s database for attendance reprocessing

Provides a migration tool for the existing users of EasyTime who wish to upgrade the time attendance software from EasyTime to E.Time

Support user definable staff database and user photo images

E.Time Time Management Software, 100 users (with Softkey, DB9)

EW-TIME-U02 E.Time Time Management Software, 500 users (with Softkey, DB9)

EW-TIME-U01

EW-TIME-U03 E.Time Time Management Software, 1000 users (with Softkey, DB9)

EW-TIME-U04 E.Time Time Management Software, unlimited users (with Softkey, DB9) EW-TIME-M01 E.Time LAN Module (program with E.Time

basic software)

(44)

OnTime Plus Multiple-shift Time Attendance Software

OnTimePlus is a Windows based Time Attendance Management software, designed to work with all Elid Time Clocks, for use in a factory environment to track shift functions accurately. It enhances and concentrates on collecting, processing, storing and analyzing of clock data, and provides comprehensive attendance reports, and reports that specifically customized by users.

Building up with a LAN ready mechanism, it allows for multiple workstations / multiple users. It prevents unauthorized access and limits the operator to designated functions only with implementation of access rights.

Highlights of OnTime Plus

Up to 25 workstations are available in the OnTime Plus, access the system any-where in the network

Implement access rights to prevent unauthorized access and limits the users to designated functions only

Provides a Web enable attendance enabling the attendance reports to be viewed anywhere at anytime easily

An user-friendly interface with the tree view on staff management

Provides multiple-shift scheduling and individual scheduling that helps divide employees into different working schedules

Provides real-time activity monitoring, which means In and Out transactions are reported immediately and displayed on OnTime Plus or redirected to a printer connected to the PC

User-defined reports and more than 20 predefined reports to record employees’ attendance

Provides leave management to record leave taken

Provides a comprehensive audit trail reports of administrator/user’s actions Attendance Records can be exported to text file (.txt) which can be used for inte-gration with third party payroll software to generate salary

Employee’s information and clocks data in text file or Excel file can be imported to OnTime Plus’s database for attendance reprocessing

Support user definable staff database with photo images Language Support: English, Chinese

(45)

Printer Port 1

OnTime Plus/3 Software Key (USB), unlimited users, up to 4 workstations c/w

EK-034T-RK1 _{OnTime Plus/4 Software Key (USB), unlimited users, up to 10 workstations c/w} Software CD (w/o Serial Cable)

EK-032T-RK1

EK-035T-RK1 OnTime Plus/5 Software Key (USB), unlimited users, up to 25 workstations c/w Software CD (w/o Serial Cable)

(46)

ER928

The ER928 is a Mifare ® Contactless Smart Card reader with built-in antenna. ER928 interfaces with external equipment via Wiegand signals.

Reader Type Mifare

Colour Beige

Power 12V

Current Consumption 150mA RF Frequency 13.56 Mhz

Reading Range ER928 & ER928/E: 3-5cm ER928/G: 1-5cm

Output Format Wiegand, Free Wiegand Status indication By LED and beeper Protection

Operating Temperature

Dimension 110(H)x44(W)x35(D) mm Weight

ER928 Mifare Contactless Card Reader, Beige (Wiegand 26-32 bits, Programmable), 3-5 cm reading range

ER-0928-G06 ER928/G Mifare Contactless Card Reader, Beige (Wiegand 26/32 bits), 1-5 cm reading range ER-0928-006

ER-0928-E06 ER928/E Mifare Contactless Card Reader, Beige (Wiegand Interface 40 bits, EMS Format), 3-5 cm reading range

(47)

ERH23L

This is a Short-range Proximity reader which will read all HID cards. It can be unobtrusively mounted on door mullions.

Reader Type HID

Colour Black

Power 5V

Current Consumption 50mA Transmit Frequency 125 Khz Reading Range Up to 5 inches Output Format Wiegand

Status indication By LED and beeper Protection

ERH23L Short Range Proximity Reader, Black (HID compatible)

ER-0023-0M7

HID Proximity Card

ERH923

This is a Short-range Proximity reader which will read all HID cards. The plastic hous-ing is designed to match with EK9S Keypad.

Reader Type HID

Colour Beige

Power 5V

Current Consumption 50mA Transmit Frequency 125 Khz Reading Range 3cm to 5cm Output Format Wiegand

Status indication By LED and beeper Protection

ERH923 Short Range 5 cm Proximity Reader, Beige (HID compatible)

(48)

ERM23

This is a Short-range Proximity reader which will read all EM cards.

Reader Type EM Output Format Wiegand

Colour Black Status indication By LED and beeper

Power 5V Protection

Current

Consumption 50mA Operating Temperature Transmit

Frequency

125 Khz Dimension 120(H)x44(W)x20(D) mm Reading

Range Up to 5 inches Weight System Requirement

ERM23 Short Range Proximity Reader, Black (EM compatible)

ER-0023-006

EM Proximity Card

ERM923

This is a Short-range Proximity reader which will read all EM cards. The plastic housing is designed to match with EK9S Keypad.

Reader Type EM Output Format Wiegand

Colour Beige Status indication By LED and beeper

Power 5V Protection

Current Consumption

50mA Operating Tem-perature Transmit

Frequency 125 Khz Dimension 110(H)x44(W)x35(D) mm Reading

Range Between 3cm to 5cm Weight System Requirement

ERM923 Short Range Proximity Reader, Beige (EM compatible)

ER-0923-006

ER-0923-E07 ERM923/E Short Range Proximity Reader, Beige (EM compatible, ELID Format)

(49)

ERM823

The ERM823 is a waterproofed Short-range Proximity reader, compatible with all ELID access controllers

ERM823/B Short Range Proximity Reader, Black (EM compatible)

ER-0823-G06

EM Proximity

Reader Type EM

Colour Black or Silver White

Power 5V

Current Consumption 80mA Transmit Frequency 125 Khz

Reading Range Between 3cm to 8sm Output Format Wiegand

Status indication By LED and beeper Protection Waterproof Operating Temperature

ER-0823-G07 ERM823/S Short Range Proximity Reader, Silvery White (EM compatible)

(50)

EK9R

The EK9R is a compact keypad with built-in EM proximity card reader. Functionally, it is equivalent to the EK9S with a built-in EM reading module. The keypad with reader is compatible with all ELID Access Controllers.

EK9R Serial Keypad (Rubber) with 4x7 Segment Display, Beige, built-in with EM reader

ER-0009-R01

Keypad c/w built-in EM Proximity Reader

Keypad 12-key membrane keypad Reading Speed

Display 4x7segment LED display Output Format Wiegand

Reader Type EM Status indication By LED and beeper Colour Beige Protection Surge protection

Power 5V Operating Temperature 0°C to 40°C Current Consumption 50mA Dimension 110(H)x90(W)x35(D) mm Transmit Frequency 125 Khz Weight Reading Range Between 3cm and 5cm

(51)

EK8R

The EK8R is a compact keypad with built-in EM proximity card reader. Functionally, it is the same as the EK9R, except that it has a different shape. The keypad with reader is compatible with all ELID Access Controllers.

EK8R/B Serial Keypad (Rubber) with 4x7 Segment Display, Black, built-in with EM reader

ER-0009-R02

Keypad c/w built-in EM Proximity Reader

Keypad 16-key membrane keypad Reading Speed

Display 4x7segment LED display Output Format Wiegand

Reader Type EM Status indication By LED and beeper Colour Black or Silvery White Protection Surge protection

Power 5V Operating Temperature 0°C to 40°C Current Consumption 270 mA Dimension 115(H)x90(W)x30(D) mm Transmit Frequency 125 Khz Weight Reading Range Between 3cm and 8cm

ER-0009-R03 EK8R/S Serial Keypad (Rubber) with 4x7 Segment Display, Sil-very White, built-in with EM reader

(52)

ER35 Reader, Infra Red Bar Code Swipe in Stainless Steel

ER-0035-002

Bar Code Reader

ER35

This is an Infra-red Swipe-type Bar Code reader packaged in a metal casing. It is designed to work with EL2200 series Door Access Controllers and ET1200 series Time Recording Terminals, and will read bar code cards encoded in 3-of-9 format or ELID 2-of-5 interleaved format.

Reader Type Bar Code Output Format

Colour Status indication By LED and beeper

Power Protection

Current

Consumption Operating Temperature

Resolution Medium (0.19 mm) Dimension 40(H)x35(L)x120(W) mm Reading

Range

Reliable reading over wide speed range

Weight

ER36

This is an Infra-red Swipe-type Bar Code reader packaged in a plastic casing. It will work with EL2200 series Door Access Controllers, and read bar code cards encoded in 3-of-9 format or ELID 2-of-5 interleaved format.

Keypad 12-key membrane keypad Reading Range Reliable reading over wide speed range Display 2 LED status display Output Format

Reader Type Bar Code Status indication By LED and beeper

Colour Protection

Power Operating

Temperature Current

Consumption Dimension 120(H)x120(L)x50(W) mm

Resolution Medium (0.19 mm) Weight

ER-0036-001 ER36 Reader, Infra Red Bar Code Swipe c/w Keypad in Plastic Housing
