WISE

Web Inside, Smart Engine

Rule Editing SMS

System Architecture

Ethernet Ethernet Ethernet Control Center Rule Engine IF-THEN-ELSE Warning light

I/O and Sensors

RTD sensor Thermometer On/Off Switch Pulse/Frequency Ethernet Email IP Camera ▲ WISE System Architecture Through Web browser, users can access Web server on WISE controllers to perform tasks such as logic rule edition and download. An IF-THEN-ELSE rule engine will be set up to manage and deploy logic rules for controllers. The rule engine will check whether the rules are valid or not and determine the execution of actions under specific conditions, for examples: setting up I/O channel values, perform Timer/Schedule tasks, sending Email/SMS message or sending CGI command under a specific condition. WISE series controller also provides wide range of hardware platforms and I/O modules that enable to support various I/O functions. It allows users to find best solutions to meet their requirements. In addition, through Modbus TCP/RTU protocol, SCADA package enables to control and monitor I/O channel or system status on WISE controller in real time. WISE-580x even provides more supports in I/O functions. It allows to connecting with a wide range of the XW-Board, I-7000 remote I/O modules and Modbus RTU slave modules; enables to freely choose the most suitable I/O modules. With the microSD card, it provides Data Logger function to real-time record the I/O channel data of the controller and allows to send the data files by FTP or Email at a scheduled time to the control center for further administration management or data analysis.

WISE Introduction

WISE (Web Inside, Smart Engine) is a product series developed by ICP DAS that functions as control units for use in remote logic control and monitoring in various industrial applications. WISE offers a user-friendly and intuitive web site interface that allows users to implement IF-THEN-ELSE control logic on controllers just a few clicks away; no programming is required. With its powerful and easy-to-use features, it will minimize the learning curve, shorten time to market and dramatically reduce the labor and cost spent on system development.

Applications

Building Automation Factory Automation Machine Automation Remote Maintenance/Diagnosis Environment Monitoring Facility Management

(3)

wise.icpdas.com

WISE

Features

IF-THEN-ELSE logic rules execution ability

WISE controller features an IF-THEN-ELSE logic rule engine, it offers up to 36 IF-THEN-ELSE rules for users to set up the logic content. After completing rule edition and downloading rules to the WISE controller, the rule engine will loop execute the rules in accordance with the execute order under specific conditions.

No extra software tool is required

WISE HMI interface runs on regular Web browsers. To edit control logic, it only requires a browser to connect to the Web server on WISE controller. No extra software tool installation is needed on the target PC. No more programming WISE provides user-friendly Web UI pages for editing control logic on the controllers. It enables to implement logic edition by a few clicks on the mouse to set up and deploy logic rules without writing a single line of code.

Offer various options for I/O channel settings

WISE offers various options for I/O channel settings; for example: noise filter for DI signals, deadband setting for AI signals, linear scale setting, temperature degree in Celsius or Fahrenheit setting, power on value setting for DO channel, pulse output setting and DI/DO counter setting, etc.

Provide Timer and Schedule operation

WISE features Timer and Schedule functions: It allows user to schedule specific date or time for control logic execution, or perform specific tasks such as time delay. With calendar user interface provided, Schedule setting can be more efficient and flexible.

CGI Command sending for surveillance system integration

WISE provides CGI commands sending function. It provides integrated access to a wide variety of Web devices and surveillance systems.

Recipe function for grouping a series of actions

In addition to 3 THEN actions and 3 ELSE actions settings WISE provides for each rule, Recipe function is provided for easily grouping a series of actions. A series of actions can be saved in a Recipe action and will be executed when the IF-THEN-ELSE condition is matched. ▲ WISE Web User Interface ▲ Click and get done! ▲ WISE Schedule setting page

(4)

wise.icpdas.com

WISE

Advanced P2P function between WISE controllers (WISE-71xx, WISE-790x and WISE-4000 only)

WISE offers P2P function that enables WISE controllers to directly communicate with other remote WISE controllers on networks. The controllers can freely share their status information such as I/O channel value, DI/DO counter or Internal Register to each others. The P2P operations can be incorporated into WISE logic rules as condition statements or action statements for condition evaluation criteria or action executions.

Real-time alarm notification & remote monitoring via SMS or Email

WISE supports SMS and Email functions for real-time message notification function. The message sending action can be added to the logic edition as part of logic control to provide real-time message notification to the related personnel when an event occurs.

Seamless integration with SCADA

WISE supports Modbus TCP/RTU protocol for users to perform real-time monitoring and control of the controllers. Through Modbus TCP/ RTU, it allows SCADA package seamlessly integrate with WISE and enables total solutions for remote monitoring and control.

Real-time receive and execute SMS command (WISE-5801 only)

WISE-5801 is equipped with SMS command receiving function. It allows to receive the SMS commands sent by specific phones numbers to perform tasks such as real-time I/O channel value monitoring, I/ O channel value modification and logic rules execution (triggered by SMS), etc.

Support Modbus RTU slave module (WISE-580x only)

WISE-580x allows to connect with devices that support Modbus RTU protocol for I/O monitoring. The ability to connect with Modbus RTU slave devices enables the flexibility and scalability for system implementation and allows to meet various requirements of the applications from the clients.

▲ Advanced P2P function

▲ Email function

▲ SMS alarm notification

Ethernet

Local Bus for XW-Board RS-232 for Serial HMI

Ethernet Analog I/O Module Temperature Measurement Module Digital I/O

Module Relay OutputModule

Counter/ Frequency Module E-mail Data Logger IP Camera

Rule Editing Control Center

RTD Sensor Thermometer Relay Output Pulse/Frequency

Analog Digital 0101001

ON/OFF Switch

WISE-5800 System Architecture

Warning Light RS-485 for I-7000 Series and Modbus RTU Slave Devices

(5)

wise.icpdas.com

WISE

IF-THEN-ELSE

Rule Engine

THEN / ELSE Actions

DO Channel ON, OFF, Pulse Output AO Channel

Change the value Internal Register DI Counter Reset DO Counter Timer Start, Reset Schedule SMS Send Email CGI Commands Recipe Execute P2P DO(On/Off), AO, IR

Data Logger Start, Stop, One-Time Log Rule Status Enable, Disable

Active I/O sending function (WISE-580x only)

In addition to the Modbus TCP/RTU slave function that enables SCADA software (or HMI device) to poll the I/O channels data of the WISE controller, now WISE-580x provides “Active I/O sending” function. Based on the “Active I/O sending” function, WISE-580x allows to send the I/O channels data of the controller actively to SCADA software (or HMI device) by event trigger (I/O channel data changed) or periodic cycle. This function will improve the efficiency of the data communication between WISE controller and SCADA software (or HMI device). Please note: The SCADA software (or HMI device) must provides Modbus TCP slave function to receive the I/O channels data sent by WISE. ▲ Active I/O sending function ▲ The overview of IF-THEN-ELSE rule engine IF Conditions DI Channel ON, OFF, ON to OFF, OFF to ON, Change AI Channel =, >, <, >=, <= (value) Internal Register DI Counter =, >, <, >=, <= (value), Change DO Counter Timer Timeout, Not Timeout Schedule In Range, Out of Range P2P DI, AI, DI counter, DO counter, IR Rule Status Enable, Disable

Data Logger operation (WISE-580x only)

With the microSD card, WISE-580x provides Data Logger function to real-time record the I/O channel data of the controller and sends the data files by FTP or Email to the control center for further administration management or data analysis.

(6)

wise.icpdas.com

WISE

Application Story

Greenhouse Automation Solution

Greenhouse cultivation represents a very important role in modern agriculture. As the greenhouse usually is equipped with various high-tech equipments, m a n a g e m e n t t e n d t o be very complex. A fully automated greenhouse control systems bring obvious benefit such as labor saving, but far more importantly, it enables

improved quality of produce and information gathering that will make difference between earning a profit or suffering substantial losses. WISE-5800 allows to connect to various I/O modules for thermocouple inputs that allow real-time monitoring of the temperature and humidity in the greenhouse; the DO module can be connected to various greenhouse facilities. It will real-time detect the greenhouse status and in response to sensors connected; the control system will automatically adjust vent position, fans, heating, fogging, shading, lighting, irrigation frequency, irrigation nutrient levels and CO2 levels, etc. WISE-5800 will tirelessly monitor the key environmental factors that affect crop quality and will make constant changes that a grower could not possibly achieve the same consistency level. In addition, WISE controller also support Modbus TCP protocol so that information can be instantly transmitted to the control center and makes real time monitoring of the overall status for each greenhouse more efficiently.

Tunnel Monitoring System

The security maintenance in a tunnel is a tough work and it is time-sensitive. For it always requires to monitor a wide range of areas in the tunnel, if all monitoring jobs only rely on manual operations when a disaster happened, it might cause delays and lead to huge losses. WISE-5800 allows to connect to various I/O modules and is able to response to the emergency in real-time. In this case, the WISE-5800 controllers are installed in various segments in the tunnel and are connected to smoke/ temperature sensors, warning lights, sprinklers, ventilation fans and other equipments. The logic rules that in response to emergency situations could be pre-set in WISE-5800, and when smoke and high temperature are detected, the fire fighting procedures will be triggered; the sprinklers will be automatically turned on to put out the fire; the ventilation fans will be started to take away the smoke; and will turn on the warning lights and open the security doors to guide people in the tunnel away from the emergency scene. The related information will be gathered in back-end control center, and will send out notification to all controllers in all segments of the tunnel for traffic control and management.

(7)

wise.icpdas.com

WISE

Facility Management System

As the advance in science and technology development, the power system and the network system have become essential parts of modern life. No matter in the buildings, factories, or even outdoors, there are always control rooms with devices installed for power and network management and control. Due to the control rooms are always filled with all kinds of expensive devices and usually under high loading operations; the monitoring of temperature and humidity, and power consumption management become important issues for the whole system. WISE-5801 can be used for monitoring the unmanned facility room. WISE-5801 allows to connect to ICP DAS I-7000 and Modbus RTU slave modules; therefore it is able to connect with thermometer, hygrometer, air conditioner, warning devices and power meters. Logic rules for daily regular maintenance in the control room can be set on WISE-5801, such as: ► When the room temperature is getting too high and being detected, the air conditioning equipments will be turned on and a real-time alarm message will be sent to related personnel. ► Set up the rotation schedule for air conditioning devices to take turns operating to ensure the air conditioning devices won’t be damaged due to prolonged operation. ► If an air conditioning device is detected to be damaged, the back-up air conditioning will be turned on for redundant operation and a real-time alarm message will be sent to related personnel. In addition, it allows to connect to WISE-5801 by SCADA software to perform the control, monitoring and collection of the I/O channel data of the facilities. And the power consumption of facilities in the control room can be statistically calculated in order to manage the electricity usage and cost as well. Modbus TCP Control Room

Disaster Prevention System

Devices Auto Shutdown when overheated, Restart when normal

TC-K Type Temp. Input

Email Internet Disaster Prevention System

In factories, most facilities and devices involved are all subject to overheating damage. From improper site wiring, lightning strikes, to overrun motors, a wide variety of overheating issues threaten systems and peripherals constantly. To ensure the safety of personals/devices, eliminate unnecessary machine downtime and achieve maximum productivity, it is necessary to build an automated system that enables real-time monitoring and disaster prevention. WISE controller provides a total solution for disaster prevention/monitoring system that will detect temperature for various devices in the factory in real time. It also enables communication between devices that will initiate immediately actions in response to emergencies. For example, in response to pre-set critical temperature threshold, the system will take actions such as auto-stop the devices, turn on the temperature reduction devices, and send alarm or email to the related personnel. WISE controller also support Modbus TCP protocol so that information can be instantly transmitted to the control center and makes response to emergencies and real time monitoring of the overall factory operation more efficiently.

(8)

wise.icpdas.com

WISE

Environment Monitoring System

As the advance of civilization causing heavy industrial and commercial activities, there are growing concerns about environmental issues; among them, wastewater treatment is one of the most emphasized areas for it involves complicated process and considerable number of devices needed during operations. In order to achieve reliable, high-performance, efficient and cost-effective result, automation approaches are essential to wastewater treatment solutions.

ICP DAS WISE-5801 controllers features real-time monitoring and reliable SMS function that is perfect for use in wastewater treatment applications. It takes only a few clicks to configure logic control that enables automation and optimization of wastewater treatment operations, such as: auto-detect the level of the sedimentation tank and response immediately based on the wastewater level. For example, when the wastewater level drops, the floodgate will be opened to load wastewater to desired level; and if the wastewater accumulates in the tank reaches a certain level, it will start the pumps to process treatment until the level decreases. In addition, WISE-5801 also allows sending SMS alarm message regarding current water level to the related personnel for immediately response.

Environment Management System

Pump Limit Switch Rain Gauge WISE-5801 IP Camera SMS

Production Line Management

Eliminating unnecessary machine downtime, e n s u r i n g m a x i m u m p r o d u c t i v i t y a n d maintaining appropriate stock are keys to successful product line management. WISE controller features flexible logic functions and is an easy-to-learn and easy-to-use tool for creating cutting edge applications that makes it easy to take full control of your product line management.ICP DAS offers full-range I/ O modules that works with WISE controller that enables to connect with product line devices in various applications. The logic engine on controllers make it possible to set up different automation process by just a few clicks, for example: by connecting conveyer to WISE controllers, it allows to hold the conveying of semi-finished product during the manufacturing process for further processing; measure productivities statistics, or notify the operators ready for next steps. In addition, WISE controller can also be set to detect and response immediately when an error occurs during the manufacturing process to avoid the waste of raw materials or equipment damage. WISE controller also support Modbus TCP protocol so that information can be instantly transmitted to the control center and makes real time monitoring the overall production line status more efficiently. Modbus TCP Product Line Management System

Control Room WISE-7126

WISE-7126 WISE-7142

(9)

wise.icpdas.com

WISE

Model Name WISE-7105 WISE-7115 WISE-7117 WISE-7118Z WISE-7119 WISE-7126

Pictures

OS MiniOS7

Built-in Software WISE Firmware

CPU 16-bit CPU

Ethernet Port 10/100 Base-TX with PoE (Power over Ethernet)

I/O Channel DI - - - 2 DO 4 - 4 6 4 2 AI 8 7 8 10 8 6 AO - - - 2 Over Voltage Protection 110 VDC/VAC - 240 Vrms 240 Vrms 240 Vrms 240 Vrms

Note _ThermistorSupport Support RTD - _{Thermocouple Input}Support

-ICP DAS provides various WISE controllers for users to choose from to meet their demands for use in various industrial applications:

Specification

Hardware

WISE-71xx Intelligent I/O Controller

Model Name WISE-7142 WISE-7144 WISE-7151 WISE-7152 WISE-7160 WISE-7167

Pictures

OS MiniOS7

CPU 16-bit CPU

Ethernet Port 10/100 Base-TX with PoE (Power over Ethernet)

I/O Channel

DI - 8 16 8 6

-DO _(Sink Type)16 _(Sink Type)8 - _{(Source Type)}8 _{(Power Relay)}6 _{(Power Relay)}8

(10)

-wise.icpdas.com

WISE

Model Name WISE-7901(D) WISE-7902(D) WISE-4000(D)

Pictures

OS MiniOS7

CPU 16-bit CPU

Ethernet Port 10/100 Base-TX with PoE (Power over Ethernet) 10/100 Base-TX

SMS - _{850/900/1800/1900 MHz}GPRS/GSM Quad-band I/O Function Support ICP DAS I/O expansion board (X-Board): X107,X109, X110, X111, X202, X203, X303, X304, X305, X308, X310, X324 Support ICP DAS FRnet remote I/O modules: FR-2053T, FR-2054T, FR-2057T 3 Digital inputs, 3 Digital outputs & 8 Analog inputs

Note WISE-790xD is WISE-790x with LED Display WISE-4000D is WISE-4000 _{with LCD Display}

WISE-790x Intelligent I/O Controller

WISE-4000 Intelligent SMS I/O Controller

WISE-580x Intelligent Data Logger (with SMS) I/O Controller

Model Name WISE-5800 WISE-5801

Pictures

OS MiniOS7

CPU 16-bit CPU

Ethernet Port 10/100 Base-TX

SMS - _{850/900/1800/1900 MHz}GPRS/GSM Quad-band

Data Logger Support period recording or event trigger recording with 2G microSD card

I/O Function

9 Support I/O expansion board (XW-Board) by local bus 9 Two options for remote I/O modules by RS-485 interface

• Support ICP DAS I-7000 series and DL series remote I/O modules (up to 16 ). • Support Modbus RTU slave modules (up to 10 )

(11)

wise.icpdas.com

WISE

Software

Model Name WISE-71xx WISE-790x WISE-4000

Pictures

I/O Function Built-in 7901 With X-Board,_{7902 With FRnet} Built-in

Rule Configuration Website Yes

IF-THEN-ELSE Logic Rule Yes

Internal Register Yes

Timer / Email / Recipe /

CGI Command Yes

Connect with SCADA or HMI Yes (Support Modbus TCP protocol)

Schedule - Yes Yes

SMS Operation - - Yes (SMS Alarm message _{sending only)}

SNTP Time Synchronization

-Data Logger

-Active I/O

-P2P Function Yes

Model Name WISE-5800 WISE-5801

Pictures

I/O Function XW-board, I-7000 & DL modules, Modbus RTU devices

Rule Configuration Website Yes

IF-THEN-ELSE Logic Rule Yes

Internal Register Yes

Timer / Email / Recipe /

CGI Command Yes

Connect with SCADA or HMI Yes(Support Modbus TCP& Modbus RTU protocol)

Schedule Yes(More Powerful)

SMS Operation - Yes (SMS Alarm message sending & _{SMS Command receiving)}

SNTP Time Synchronization Yes

Data Logger Yes

Active I/O Yes

P2P Function

-Note :Two utilities are provided for all WISE series controller : 9 WISE Rule Utility for logic rules import & export operation. 9 WISE Firmware Uploader for WISE firmware upgrade operation.

(12)

wise.icpdas.com

WISE

Why WISE ? 9 No extra software tool is required; all operations can be done through the Web browser 9 No programming is required. Dramatically reduce the labor and cost spent on system development 9 Provide various hardware platforms and wide range of I/O modules that allows users to find best solutions 9 IF-THEN-ELSE logic rules execution ability 9 Fully automation functions supported • I/O channel monitoring and control • Timer/Schedule operation • SMS/Email message sending, CGI command sending, SMS command receiving • Recipe function for group action operation • Seamless integration with SCADA through Modbus TCP/RTU protocol • Automatically perform data logger operation and send back data files • Active I/O operation for efficient data communication

The Real-Time automatic logic control & data recording controller in local site.
