ONE SURVEILLANCE PLATFORM TO PROTECT EVERYTHING

(1)

ONE SURVEILLANCE PLATFORM

TO PROTECT EVERYTHING

(2)

(3)

Simple, secure, and cost-effective

cloud video surveillance for one

to thousands of locations.

(4)

MARKETS

COMMERCIAL

+ Employee Safety

+ Asset Protection

+ Intrusion Prevention

+ Data Protection

+ Liability Reduction

+ Prosecution Control

+ Safety Compliance

+ Evidence Management

+ Central Management

+ Users/Roles Control

+ Use Existing Cameras

EDUCATION

+ Student Safety

+ Asset Protection

+ Intrusion Prevention

+ Data Protection

+ Prosecution Control

+ Safety Compliance

+ Evidence Management

+ Liability Control

+ Central Management

+ Users/Roles Control

+ Use Existing Cameras

RETAIL

+ Loss Prevention Control

+ Shrink Reduction

+ Customer Monitoring

+ Employee Performance

+ Liability Reduction

+ Prosecution Control

+ Safety Compliance

+ Evidence Management

+ Central Management

+ Users/Roles Control

+ Use Existing Cameras

RESTAURANT

+ Employee Monitoring

+ Shrink Reduction

+ Queue Monitoring

+ Liability Reduction

+ Evidence Management

+ Theft Control

+ Safety Compliance

+ Health Compliance

+ Central Management

+ Users/Roles Control

+ Use Existing Cameras

(5)

WHY SMARTVUE?

1. SIMPLEST TO SCALE

Plug and Play Thousands of Locations

2. EASIEST TO MANAGE

Point & Click Enterprise Management

3. FASTEST CLOUD

Blazingly Fast Performance Worldwide

4. MOST COST EFFECTIVE

(6)

(7)

SHAREVUE®

Collaborative Video Sharing

The fast, easy and secure way to collaboratively share

video clips with anyone, anywhere.

GEOVUE™

Global Mapping of Camera Locations

See surveillance locations on an interactive global

map and quickly monitor video and system status.

SITEVUE™

Interactive Camera Mapping and Surveillance Design

Design and monitor surveillance floor by floor with

point and click camera layout and viewing.

CONNECT API

Robust RESTful Application Programming Interface

Integrate analytics, access control, facial recognition

and customer tracking with a simple API.

CONTRIBUTE™

Social Surveillance On Demand

Instantly upload images, audio, and video from any

mobile device to share events in the cloud.

Smartvue® is a registered trademark of Smartvue Corporation. All other

trademarks are property of their respective owners.

SMARTVUE®

CLOUD SERVICES

CLOUDVUE®

Remote Video Management

Fast and secure remote video monitoring of one to

thousands of cameras from one web portal.

Cloudvue optimizes video delivery for any

bandwidth connection and works with any browser

on Windows® or Apple® computers and free Apps

for iOS, Win8, and Android™ devices.

CLOUDRIVE™

On Demand Cloud Video Storage and Playback

Secure, redundant cloud video storage and

management available on demand. Store video in

HD, low resolution, or both. Works with any Smartvue

S12 server or direct from any Smartvue HD camera.

COMMANDVUE®

Enterprise Management and Reporting

Commandvue delivers remote system management,

reporting, and trouble-shooting for up to thousands

of servers and cameras from one web browser portal.

The live dashboard delivers instant enterprise status

as well as mass upgrades, technical support, SMS

error alerts (such as camera failure) and reporting.

(8)

SMARTVUE®

HD NETWORK CAMERAS

High performance outdoor/indoor megapixel

HD cloud cameras in two cost effective models.

KEY FEATURES

• 3MP HD (2048 x 1536) H.264 Video

• IP66 Outdoor Weatherproof

• Night Vision with up to 30m IR Auto Cut

• PoE Power

• Motion Detection and Tamper Alarm

• Small Size and Elegant Form Factor

• Plug and Play Smartvue

®

S12 Server Support

• CloudDrive™ Support (Direct to Cloud Storage)

SMARTVUE®

HD CAMERAS

SVC-D3 3MP Dome

(9)

SMARTVUE® S12M

MICRO CLOUD SERVER

The world’s most cost-effective enterprise

surveillance for up to 6 cameras per location.

KEY FEATURES

• Cost Effective Surveillance Solution

• Built-In Solid State Video Storage

• ONVIF Support for Thousands of Cameras

• Cloudvue

®

for Blazingly Fast Remote Viewing

• On-Demand CloudDrive™ Storage

• Works with Any Apple or Windows Web Browser

• Free iPad, iPhone, Win8, and Android Apps

• 3 Year Limited Warranty

(10)

SMARTVUE® S12E

CLOUD SERVER

Plug and play HD video surveillance solution

for up to 30 cameras and 8TB of video storage.

KEY FEATURES

• Up to 8TB Surveillance Optimized Storage

• ONVIF Support for Thousands of Cameras

• Cloudvue

®

for Blazingly Fast Remote Viewing

• On-Demand CloudDrive™ Storage

• Works with Any Apple or Windows Web Browser

• Free iPad, iPhone, Win8, and Android Apps

• Plug-and-Play Installation on Any Network

• 3 Year Limited Warranty

(11)

SMARTVUE® S12F

CLOUD SERVER

Professional HD video surveillance solution

for up to 30 cameras and 20TB of video storage.

KEY FEATURES

• Up to 20TB Surveillance Optimized Storage

• ONVIF Support for Thousands of Cameras

• Cloudvue

®

for Blazingly Fast Remote Viewing

• On-Demand CloudDrive™ Storage

• Works with Any Apple or Windows Web Browser

• Free iPad, iPhone, Win8, and Android Apps

• Plug-and-Play Installation on Any Network

• 3 Year Limited Warranty

(12)

SMARTVUE® S12G

CLOUD SERVER

High capacity HD video surveillance system

for up to 100 cameras and 48TB of video storage.

KEY FEATURES

• Up to 48TB Surveillance Optimized Storage

• ONVIF Support for Thousands of Cameras

• Cloudvue

®

for Blazingly Fast Remote Viewing

• On-Demand CloudDrive™ Storage

• Works with Any Apple or Windows Web Browser

• Free iPad, iPhone, Win8, and Android Apps

• Plug-and-Play Installation on Any Network

• 3 Year Limited Warranty

(13)

SMARTVUE® S12R

CLOUD SERVERS

Enterprise HD extended storage surveillance

for Up to 100 cameras and 304TB of video storage.

KEY FEATURES

• Up to 304TB Surveillance Optimized Storage

• ONVIF Support for Thousands of Cameras

• Cloudvue

®

for Blazingly Fast Remote Viewing

• On-Demand CloudDrive™ Storage

• Works with Any Apple or Windows Web Browser

• Free iPad, iPhone, Win8, and Android Apps

• Plug-and-Play Installation on Any Network

• 3 Year Limited Warranty

(14)

HOW SMARTVUE® WORKS

Patent protected by 27 patents in the USA, China and EU. Smartvue® is a registered trademark of Smartvue Corporation. All other trademarks are property of their respective owners.

CLOUDVUE®

Monitor live video and search recorded video from one to thousands of locations worldwide. GEOVUE™

See locations and cameras on a global map to quickly monitor video and system status. SITEVUE™

Design and monitor surveillance floor by floor with point and click camera layout and viewing. SHAREVUE®

Collaborative video sharing to securelymanage, archive and share video events with anyone. CONTRIBUTE™

Capture video events from any mobile device to save to the cloud and share with anyone. CLOUDRIVE™

Cloud recording with redundant and secure storage and fast reliable remote access. CONNECT API™

RESTful API for Access Control, Analytics, Consumer Behavior, Counting, and more.

COMMANDVUE® Maintain, manage, and

trouble-shoot millions of servers and cameras from one dashboard. SMARTVUE® S12 Video Cloud Server with 1 to 240TB of Local HD Video Storage ANY DEVICE Responsive web UI for Mac/Win plus apps for iOS, Android, Win8. SWITCH PoE Switch or A2D Converter CAMERAS Thousands of ONVIF compatible cameras to choose from or keep existing analog cameras

CLOUD CAMERAS Direct camera to

cloud video recording. No servers required.

(15)

S12R CLOUD SERVER

Cameras 1-100 Integrated Storage: S12R64: 64TB HDD JBOD Expansion: SR12240TB: 240TB HDD Total Storage: 304TB RAID 5/6 CloudDrive™ Storage: Unlimited On Demand Intel® Processor

Size & Weight Width: 17.4” (443.2mm) Height: 3.47” (88.3mm) Length 25.6” (651.4mm) Weight (Base): 28.8lbs (13.1kg) Connections 2 X GbE 1000 ETH 6 X USB 2.0 1 X eSATA 1 X VGA Compliance

UL, FCC, CCC, GOST, CB, BSMI Operating Environment 5 to +35C (41F to 95F) Linux Operating System Power

Input 100-240V AC Three Year Limited Warranty

S12M CLOUD SERVER

Cameras 1-6 Integrated Storage: S12M64: 64GB SSD CloudDrive™ Storage: Unlimited On Demand ARM® Processor

Size & Weight Length 4.17” (106mm) Width 4.17” (106mm) Height 0.9” (23mm) Weight: .25lb. (4oz.) Construction

ABS and Aluminium Case Low Power Design Fanless

Silent Operation Connections 1 X 10/100 ETH RJ-45 1 X Hi-Speed USB 2.0 port HD Graphics HDMI 1.4 Compliance UL FCC RoHS CE Operating Environment 0°C to +55°C (32°F to 131°F) Linux Operating System Power

External DC Power 5V Three Year Limited Warranty

S12E CLOUD SERVER

Cameras 1-30 Integrated Storage: S12E1: 1TB HDD S12E2: 2TB HDD S12E3: 3TB HDD S12E4: 4TB HDD S12E6: 6TB HDD S12E8: 8TB HDD CloudDrive™ Storage: Unlimited On Demand Intel® Processor

Size & Weight Length 9.64” (245mm) Width 4.33” (110mm) Height 7.67” (195mm) Weight (Base): 6.7lbs (3.0kg) Construction

ABS and Aluminium Case Connections 2 X GbE 1000 ETH 2 X USB 3.0 + 5 X USB 2.0 1 X eSATA 1 X VGA Compliance

UL, FCC, RoHS, ISO, ASTM Operating Environment 5 to +40C (41F to 104F) Linux Operating System Power

AC Input 100V to 240V Three Year Limited Warranty

S12G CLOUD SERVER

Cameras 1-100 Integrated Storage: S12G8: 8TB HDD S12G12: 12TB HDD S12G16: 16TB HDD S12G20: 20TB HDD S12G24: 24TB HDD S12G28: 28TB HDD S12G32: 32TB HDD S12G40: 40TB HDD S12G48: 48TB HDD RAID 5 CloudDrive™ Storage: Unlimited On Demand

Size & Weight Width: 6.88” (175mm) Height: 12.2” (310mm) Length 9.64” (245mm) Weight (Base): 19.8lbs (9kg) Connections 2 X GbE 1000 ETH 2 X USB 3.0 + 5 X USB 2.0 1 X eSATA 1 X VGA Compliance

S12F CLOUD SERVER

Cameras 1-30 Integrated Storage: S12F10: 10TB HDD S12F12: 12TB HDD S12F16: 16TB HDD S12F20: 20TB HDD RAID 5 CloudDrive™ Storage: Unlimited On Demand Intel® Processor Size & Weight Height: 8.85” (225mm) Length 9.64” (245mm) Width: 6.88” (175mm) Weight (Base): 19.8lbs (9kg) Construction

ABS and Aluminium Case Connections 2 X GbE 1000 ETH 2 X USB 3.0 + 5 X USB 2.0 1 X eSATA 1 X VGA Compliance

(16)
