BUILDING TECHNOLOGIES SMART BUILDING SOLUTIONS

(1)

BUILDING TECHNOLOGIES

SMART

BUILDING

SOLUTIONS

(2)

(3)

Interest in Smart Buildings Increases…

Inclination to the smart buildings which started in America

in 1980s has been increasing gradually in our country as

well as in the world due to the increase in the number of

high-rise buildings and the developments in the technology.

The most important reasons of this interest in smart

buildings are that they make life easier with the features

and advantages they have, they provide savings from

energy, time and labor force and they provide a safe, healthy

and enjoyable work environment for their workers.

Since the day we were founded as AE, we have been

providing service about smart building Technologies with

our experienced technical staff at home and abroad for over

21 years.

(4)

(5)

5

AE Building Technologies

(6)

6 www.aebina.com.tr

(7)

7

WE USE OUR INDUSTRY LEADING TECHNOLOGY PRODUCTS AND SYSTEM INTEGRATION SKILLS TO PROVIDE OPTIMAL SOLUTIONS.

06

ABOUT US

08

TIMELINE

10

OUR SERvICES

12

OUR REfERENCES

13

OUR QUALITy POLICy

13

OUR CERTIfICATES

14

UNITED TECHNOLOGIES

16

UTC fIRE & SECURITy

18

INTELLIGENT fIRE ALARM SySTEMS

20

CO GAS DETECTION SySTEMS

22

IP vIDEO SySTEMS

24

ANALOG CCTv SySTEMS

26

ACCESS CONTROL SySTEMS

28

fIBER OPTIC COMMUNICATIONS AND NETwORk

30

INTEGRATED SECURITy SOLUTIONS

32

INTEGRATED EMERGENCy

(8)

8 www.aebina.com.tr

AE Building Technologies Industry and Trade Limited

Company

AE was founded on 1992 to provide medium and

large scale building with complete services of Fire

Detection, CCTV, Card Pass Control, design of Security

and Integrated Building Control Systems, material

supply, equipment assembly, assembly supervision,

commissioning, technical education and service

maintenance.

AE is an engineering and commitment company

which has been providing services of Project design

in accordance with the NFPA fire codes and standards,

consultancy, material supply, assembly and spare

parts on fire detection and extinguishing since the

day it was founded.

Our Mission is to constitute optimal solutions with the

most qualified service about Fire and Security in Turkey

for enabling our customers to reach their aims.

Our Vision

is to become a leader company which can

meet all expectations of our Customers about security,

comfort and automation and which gives the most

qualified service in this respect.

AE

BUILDING TECHNOLOGIES

“The Smart

Building Systems

offered by AE Building

Technologies provides

innovative solutions

that increase comfort

and productivity in

the buildings using

the most current

technology.”

AE is a powerful business partner which can serve

you ALONE and which can collaborate with you in

(9)

fire alarm ip video and analog CCTv access control fiber and network

“AE helps the users

and allows the facility

managers to be able to

manage the building

easily with the smart

buildings it constructs.”

(10)

1992

1993

2004

golden times

altın zamanlar

UTC FIRE & SECURITY

START

CCTV SİSTEMLERİ

Foundation

AE was founded on 1992

to provide medium and

large scale building with

complete services of

Fire Detection, CCTV,

Access Control, design of

Security and Integrated

Building Control Systems,

material supply, equipment

assembly, assembly

supervision, commissioning,

technical education and

service maintenance.

Honeywell

AE signed Certified Star

Partner contract with

Honeywell regarding Fire

Detection, Access Control,

Security and CCTV systems

in 1993.

Istanbul

AE opened its Istanbul

Office in 2004 in order to

provide better and faster

service to its customers.

(11)

2006

2010

2008

Time Line

altın zamanlar

ENTEGRASYON

GEÇİŞ KONTROL

YANGIN ALGILAMA

Kazakhstan

AE opened its Kazakhstan

Office in 2006 in order to

provide on site service for

foreign projects.

Ge Security

AE signed Turkey and

Turkic Republics Approved

Business Partner Contract

with GE Security in 2008.

UTC Fire & Security

UTC Fire and Security

Company bought GE

Security Company in 2010.

AE signed Turkey and

Turkic Republics Approved

Business Partner Contract

with UTC Fire and Security

in 2010.

(12)

12 www.aebina.com.tr

As AE, we can provide service for you as ONE company to meet all your requirements

and to carry the required responsibility instead of the disorder to be created by the

separate material suppliers in your every kind of company whether big or small.

The products and services we provide will gain your buildings

Comfort • Security • Performance • Savings • Prestige.

As AE, we also provide the services and maintenance required for the continuity of

the systems. We get our strength to be able to provide you with the most qualified

service from our 21 years of experienced staff and fund of knowledge of our workers.

• Fire Alarm System

• High-Sensitivity Smoke Detection

(HSSD)

• Fire Suppression Systems

• Integrated Emergency

Announcement Systems (PA&GA)

• Nurse Call Systems

• IP Video and CCTV Systems

• Fiber Transformers

• Industrial PoE Network Systems

• Access Control Systems

• Integrated Security Systems

• Integrated Perimeter Security

Solutions

• Smart Building Automation Systems

• Smart Home Automation Systems…

Hİzmet Verdİğİmİz SİStemler

OUr SerVICeS

PRO

JECT PREP

ARA

TION

PERIODIC M

AINTENANCE

PRODUCT M

A

TERIAL SUPPL

Y

QU

ALIT

Y CONTROL

(13)

13

Hİzmet Verdİğİmİz SİStemler

• Selection of Systems or Products

• Design of Systems

• Constitution of Principle Chart

• Technical Documentation

• Supply of Equipment

• Supervisor Services for Assembly

• Cabling and Assembly Controls

• Test and Commissioning Works

• On Site Theoretic and Practical

Education of Users

• Periodic Maintenance and Repair

Services

OUr eNGINeerING SerVICeS

AE maintains its periodic services including

emergency services in every corner of Turkey with

its educated, experienced maintenance and service

personnel and in accordance with the maintenance

and repair contract signed with the customers

successfully.

Turn-Key Complete Weak Current System Solutions ●

Project consultancy and Project Preparation ●

Product and Material Supply ●

System Integration ●

After-sales Technical Service ●

Installation, Assembly, Test and Commissioning Services ●

Periodic Maintenance Services ●

Quality Control ●

QU

ALIT

Y CONTROL

SY

STEM INTEGRA

TION

TECHNICAL SER

VICE

INS

TALL

A

TION - A

SSEMBL

Y

TURN-KEY

(14)

OUr reFereNCeS

Be Here

AE completed hundreds of projects at home and abroad with its 21 years of weak

current system engineering experience, fund of knowledge and experience.

(15)

OUr QUAlItY POlICY

OUr CertIFICAteS

• Unconditional Customer Satisfaction

• Superior and Qualified Service

• Non-stop Technical Support and Service

• Honesty and Trust

• Productivity and Quality

• Environmental-friendly Products and Green

Building Solutions

• Service with the most advanced Technologies

and products used worldwide

(16)

Total number of workers: 220,914 Net Sales: 60.100 Billion USD

The 58th biggest company of the world

according to the 2012 Fortune 500 list…

“UTC is an

international

company regarded

as Market leader in

fields providing high

technology products

and services and it

carries on business in

a wide range. It invests

4 billion dollars for

R&D every year.”

(17)

O

tis is the first company to build an elevator. Elisha Graves Otis is the first person to actually start the elevator industry by inventing the first safety break and who founded the Otis Company. His invention allowed the buildings, and of course the dreams of the architects, to dispread through the sky and gave a new and striking shape to the silhouettes of today’s cities. Today, Otis is the leader elevator company of the world providing service to its customers in nearly all countries of the world with its over 150 years of history.

U

TC Fire and Security is a world leader company in fire and electronic security solutions which protects and guards humanity, your properties and assets. Its workers share a great responsibility to create a secure and reliable environment in living spaces with you. UTC Fire and Security provides solutions for the needs of different and various customers with its wide range of products including Fire Alarm, Burglar Alarm, Access Control and Video Monitoring systems.

P

ratt and Whitney is world’s leading aircraft engine, space impulsion systems and industrial gas turbines design, manufacturing and maintenance company. The company was founded by Francis Pratt and Amos Whitney in 1860. In 1925, Frederich Brant Rentschler, who was a pilot in World War I, meets this company while searching for capital and production plant to produce his first aircraft engine.

C

arrier is the first company

to perform air-conditioning. Willis Haviland Carrier obtained the patent of first air-conditioning device in 1902. “Air-cleaning appliance” was certified in 1906 and this was the first of the number of patents granted to Carrier. Carried was deemed as the father of air-conditioning with these inventions he made. In 1921, Carrier obtained the patent of centrifugal cooling machine. “Centrifugal cooler” was the first practical method of air-conditioning for large spaces.

H

amilton Sundstrand produces space industry satellite systems,

Technologies and flight hardware equipment for manned space works. It has been a part of all major space programs in space systems field for forty years. Manned space works is among its main working fields. UTC Aviation and Space Systems is one of the greatest suppliers of the world in technologically advanced aviation and defense products.

S

ikorsky was founded by Igor Sikorsky to produce and develop air crafts in 1925. In 1942, it dominated this field with the advanced helicopter design of Igor Sikorsky. They made helicopter use safe with the technology they developed and thus the company became one of the most important aviation companies of the world. Sikorsky helicopters were used in the first helicopter rescue operation of the world in 1944. Since 1944, it has saved the lives of over 2 million people with rescue operations.

Number of workers: 38,065 Net Sales: 6.9 Billion USD

(18)

UTC aims at providing solutions to every

need and segment with the wide range of

products it comprises.

UTC offers software and hardware in

different capacities from a small appliance

consisting of one building to the complex

appliances for giant institutions spreading

all over the world with its Fire and Security

solutions.

UTC Fire and Security systems are unique

in integration. Fire Alarm Systems, Access

Control Systems, IP and Analog Video

Systems easily communicate with central

management software and enhance the

system performance.

Thousands of buildings have the feature of

smart building due to UTC systems. These

buildings make residents comfortable

with the extraordinary comfort and

security provided while making managers

particularly comfortable with energy

savings and easy-to-use features, they

increase their profitability. If you want your

building to be comfortable, productive and

secure, and if you want all of these systems

to work integratedly and to be managed

from one single center, meet the high

technology UTC Smart Building Solutions.

(19)

Fiber and

Transmission Systems

IFS

Fiber Translators Network

Switch Family providing

Video, Voice, Contact, Data

Transmission

CCTC Systems

INTERLOGIX - PRISM

IP Based Video Solutions,

Analog CCTV Solutions,

High-End Video Management

Systems.

Life Safety Systems

ARITECH - EST

Smart Addressed Fire

Detection, Integrated Voice

Evacuation and Smoke Control,

Gas Detection, Fire Extinction

Systems

Access Control

Systems

ARITECH - LENEL CASI

Integration Platforms without

scale limit.

Burglar Alarm

Systems

ARITECH - LENEL

Cable Systems, Wireless

Systems, TCP/IP and GPRS

Integration

LENEL- OnGuard - FC Wnx

Advantages of UTC Systems

• UTC is one of the world’s biggest and most

reliable fire and security companies.

• The systems developed by UTC are way

ahead of the sector with their technical

features.

• All products offered to you have one brand:

UTC.

• World leader in Security Systems and

Control

• An international company with a wide

range of products to provide solutions in all

buildings and plants, no matter big or small.

• Systems and products required for your all

kinds of control needs.

• A company which is expert in its field and

leader in the world.

• Experience gained over years

• Service and maintenance in many places of

the world.

(20)

UTC Fire and Security is one of the companies having the widest range of products

about fire detection and warning systems in the world. UTC Smart Addresses

Fire Detection and Warning systems consist of new generation addressed fire

warning panels with EN54-13 certificate which can meet all requirements. UTC

provides separate solutions for fire detection warning and extinction systems

of small, medium and large scale buildings. The most effective protection is

provided with the systems designed in accordance with the intended purpose of

the buildings of any scale. Fire Control Panels with menus completely in Turkish

language are follow-ups of the innovative

technological solutions. New series

of panels are a panel series

that will greatly affect the

customers, integrator

companies, service

technicians and

final users with

their new look,

design and layout

and rich content.

INtellIGeNt AddreSSABle

FIre AlArm SYStemS

(21)

21

Integration with other systems

• Emergency Announcement System

• Sprinkler Water Extinguisher

• Gaseous Extinguisher

• Hood Extinguisher

• Elevators

• Fire Escape Doors

• Compression

• Air-conditioning Plants

• Exhaust Fans

• Fire and Smoke Dampers

• Smoke Exhaust Fans

• Smoke Exhaust Systems

• Automation System

• Electrical Boards…

“AE provides a complete fire

and security automation

platform with the central

management features,

integration possibilities in the

systems it installs.”

INtellIGeNt AddreSSABle

FIre AlArm SYStemS

(22)

“The System is designed for automatic control of

Carbon monoxide detection and exhaust fans in

parking garage areas.”

(23)

23

KM300 CO Control Panel can be used in big and small scale projects. Each section

controls a 4500 square meter area and CO detection up to 18000 square meter can be

realized using 4 quadrant panel.

Microprocessor based KMD300 detectors are used as Panel-compliant

site device. CO detection range is 0-300 ppm. Green light flashing on the

detector shows normal working situation. Constantly on red light visually

informs about CO density over 50 ppm. Blinking red light notifies error

situation.

CArBONmONOXIde

(CO) GAS deteCtION

(24)

It is time to pass from analog systems to

IP video solutions in Video processing…

IP VIdeO SYStemS

We can define IP High definition (Hd) cameras as the uptrend of recent years. the

most important factors why IP based solutions are required in nearly all of the

medium and large scale projects are the developments in IP video technology and

cheapening of It infrastructure costs.

UTC IP Video systems enable monitoring of the environment both indoors and outdoors

in every kind of buildings regardless of the size, monitoring of the remote and close

environment with the highest quality, the most effective method and the cheapest costs.

Closed loop television system to be integrated with the security centers constituted enables monitoring of all security systems of your security unit such as access control, fire safety all together. Digital video control systems are the most effective and easiest-to-use ways to watch, record, back up and remote access of the videos taken by the cameras. These systems allow monitoring of more than one places at the same time even if they are far from each other.

Again, smart motion perception feature, functional searching options, record and record

view facilities and superior video quality of these systems allow the security officers to

take precautions according to the event and intervene more effectively.

UTC IP Megapixel includes wide range of IP cameras which are compliant to ONVIF

and PSIA Standards and which can provide solutions of HD and Full HD resolutions

in its product portfolio.

(25)

“UTC IP video

systems constitute

management

flexibility with

advanced IP

Video Quality and

Performance and

provide an ideal

solution for today’s

(26)

CCTV systems are used commonly for monitoring workers and visitors

in the buildings, production control in factories, catching the thieves in

stores, banks and in customer relationships.

(27)

CCTV systems enables monitoring of all related systems of your security unit such as access control, fire, security together by being integrated with security centers constituted by closed loop television systems. Its functionality increases when works integrated with other systems.

UTC Fire and Security TruVision series recorders allow you to

enter into digital world in the most faultless

and productive way

possible. There are digital and

analog video jacks on TruVision series

DVRs.

This is the most suitable time to pass from analog to digital video processing. Although, many companies has made great

investments to analog camera and other video management systems and they are still investing. This is one clear reason why the designed UTC Fire and Security TruVision DVR series is in integration with your existing product

portfolio.

UTC Fire and Security T r u V i s i o n series recorders allow you to enter into digital world in the most faultless and productive way possible. There are digital and analog video jacks on TruVision series DVRs.

27

“UTC management

platform provides wide

range of possibilities in

CCTV due to the digital

recorder and family

of cameras for

(28)

PROTECT ALL OF ACCESS POINTS THAT REQUIRE SECURITY IN YOUR BUILDING.

Need for Access Control systems is gradually increasing particularly in our

country. Access Control systems, which were preferred generally in state

and banking sectors in the past have become the basic needs of commercial

projects, too.

ACCeSS CONtrOl

SYStemS

(29)

“The feeling

of security

constituted by

pass control

systems in today’s

prestigious

modern buildings

is very important

both for

companies and for

workers.”

29

UTC Access Control Systems provide a complete integrated security platform with

management features, integration possibilities and video monitoring solutions.

UTC pass control systems have a wide range of products with flexible and functional

using features and advanced operator interface from stand-alone units to infinite gate

combinations on the web, from one gate solutions to multiple gate solutions, from central

control of one building companies to multiple building companies.

The systems are designed particularly for each building according to the place of use, need

of security, number of users etc. A generally suggested comprehensive pass control system

is a computer based, interactive graphic indicating, with the capacity of controlling and

monitoring from multiple points on the web at the same time, extendible and easy-to-use

system.

(30)

FIBer OPtIC COmmUNICAtIONS

ANd NetWOrK

“UTC provides the

highest quality

possible in voice and

data transmission to

its customers with

IP based product

portfolio.”

(31)

31

IFS has fiber optic transmission products used in various market applications

all over the world and provides safe transmission of CCTV, fire detection, Access

Control and burglar alarm system signals through fiber optic in electronic

security sector.

IFS has a wide range of products you may need in fiber optic cable infrastructure

use and developed especially for electronic security applications. UTC is

preferred all over the world to provide its customers with the highest image

resolution possible having more than 300 analog and digital modulation with

IFS and voice and data transmission with IP based product portfolio.

Also, fiber optic transmission equipments are widely used especially in

international traffic applications (ITS) by providing data transmission for variable

electronic traffic signs (VMS) as well as video transmission. It is also preferred to

carry the signals of field equipments which have to work under heavy conditions

with building automation and control systems in the industrial field.

FIBer OPtIC COmmUNICAtIONS

ANd NetWOrK

(32)

32

“UTC provides the

most convenient

solution due to the

rich product portfolio

it has regarding

the management

platform, burglar

alarm and

(33)

33

Today, security is one of the basic needs of people due

to terrorism, theft, seizure, economic imbalances,

carelessness, direction lessness, unexpected events,

unpredictable situations. It is best to take precautions

early by understanding the risks before it is too late

because the losses that may result from the damaging

affects can be way costlier than the security system

installment cost.

UTC detectors detect danger immediately with their

high precision and inform the control room.

“AE provides service

about all electronic

security systems

and defense

Technologies you

may need from

plants to factories,

from city security to

border security.”

INteGrAted SeCUrItY

(34)

INteGrAted emerGeNCY

ANNOUNCemeNt eVACUAtION

SYStemS

Means of egress are optimally used with the

gradual evacuation scenarios…

First, the zones containing the people in the urgent danger area

are evacuated. After all people in the endangered areas are

transferred to the safe zone, adjacent zones

are evacuated gradually.

E

specially emergency announcement

and telephone systems integrated

solutions provide solutions not only for

detection but also for warning,

evacuation and providing

uninterrupted communication

in the event of fire. Emergency

announcement systems are

preferred to prevent panic and

gradually realize the evacuation

of the building in the event of

fire in places where people abound such

as hotels, Business Centers, Malls, high

residential buildings, Airports, Cinema and

Theater Complexes, Hospitals etc. With the

voice messages delivered automatically

according to the place where the

fire detected and the detector

type, or with the announces

delivered live via microphone from

the fire center or fire phones in

the building when necessary, it is

possible to change places of the

people inside in the desired level

and evacuate the building.

To avoid

loss of

life and

property...

(35)

(36)

www.aebina.com.tr

AE BUILDING TECHNOLOGIES INDUSTRy AND TRADE CO. LTD. Ankara Mustafa Kemal District, 2127 St. No: 14/5 Çankaya

B+90 312 219 55 22 (pbx) E+90 312 219 46 66

[email protected]

İstanbulEmirhan Road Dikilitaş St. No: 33/11 Beşiktaş

B+90 216 572 57 82 8+90 543 686 79 80

kazakhstanTulebaev St. 39/61, 050004 Almaata

B+7 727 273 07 27

All rights r

eserved. 1992-2013 AE Building T
