SIMPLY TOUCH. Usability Control Traceability ALL YOUR ACFRI CELLS ON SINGLE SENSITIVE DISPLAY

SIMPLY TOUCH

Usability • Control • Traceability

ALL YOUR ACFRI CELLS ON

SINGLE SENSITIVE DISPLAY

• Color & Sensitive interface 7’’ simple and intuitive. •Delivered in a IP65 box

• Driving 1 to 12 cells on the Simply Touch display

• Management of a single list of parameters • Securing parameters by access code

• Simultaneous multi-cell display in the genreal view

• Launching cycles on the individualized screens • Display of parameters at launch of the

cycle

•Simplified access to programming mode. •Multilingual interface french/english/spanish. • Complete control screen: Time/temperature/product.

1-CONTROL

GENERAL VIEW

› DISPLAY OF 4 CELLS PER PAGE

› Easier selection of cycles

CYCLE SELECTION VIEW

SIMPLY TOUCH

Ergonomie • Pilotage • Traçabilité

IP65

standard _{IP65 Stainless Steel} optional

3-CONTROL

› Resume of cycles with

conformity icon

› Room and Core temperature curves with

automatic calculation of cycle duration › Display of the product name

Historical

Cycle curve view

2-IDENTIFY

2-IDENTIFIER

› Resume of the current cycle - Recall of the settings

- defrosting alert

› Product identification

Product selection view

Current cycle view

2

2

2

2

-

I

I

I

D

D

D

D

E

E

EN

NTIFIER

•Real-time curve of the current cycle. • Automatic calculation of cycle

durations on curves. • History of cycles for all

connected cells. •Cycle conformity icon. •Defrosting alarm

•Display of defects for all connected cells. •Management of an editable product list.

•Product identification at the start of the cycle. •Adjustment of temperature conformity

thresholds.

ECK THE CONFOR

1 1

1

2 3

4

F

unctionality and traceability

• The stnd ard Simply 3 controller stays operational on each cell.

• Complete Instructions manuals in memory (Regulation, cleaning, good practices).

• Connection RJ45 between the cells & Simply Touch. • Recovery of cycle data by USB key or

ethernet.

•Dats export on html page.

• Fits with Acfrisoft software (2nd sem. 2018) • Update kits available for existing cells

› From Simply 1 and 2 to Simply 3 P12. › From Evolution to Simply 3 P12.

Typical configuration

1 Acfri cells equiped with a Simply 3 Controller (P12) 2 Power Supply 220volt for Simply Touch.

3 Connection Hub (RJ45) to connect

the Simply 3 controller(s) and the Simply Touch.

4 Ethernet output from Simply Touch.

ACFRI

Z.A des Bordes

- 8, rue Pierre Josse -

91070 B

ondoufle FRANCE

[email protected] - www.acfri.com

Video Tutorials Data sheets Price list Documentation News Reports

4

www.acfri.com

NOTICE SIMPLY TOUCH

SUMMARY

1 – LIST OF PRODUCT

S

2 – SETTINGS

3 – GENERAL VIEW – CONTROL OF CYCLE

4 – USB

1 - LIST OF PRODUCT

You can create or modify the product list directly from the touch 1-1 ACCESS CODE

Access code is 1234 1-2- PRODUCT WRITING

After editing a product, do not forget to save by pressing the floppy icon at the end of the line to save your changes.

2 - SETTINGS

2-1 USER SETTING

All user settings are editable from Simply touch.

The designation, the min and max values are also indicated, but not alternable.

After modifying a value, don't forget to save by pressing the floppy icon at the end of the line to save your changes. For more information on the meaning of the parameters, please refer to the Simpy 3 manual. - ACCESS CODE

2-2 SYSTEM SETTINGS

- ACCESS CODE

The access code is 5555 - NUMBER OF SIMPLY – X1

Indication of the number of Simply connected to the touch - CONFORMITY THRESHOLDS AND CYCLE TEMPERATURE – X4 à X7

The temperatures and the remarkable times allow to indicate the values of conformity of the cooling cycles.

- DEFROSTING THRESHOLDS – X2 à X3

The defrosting thresholds correspond to the color change level of the defrost button in the cell page.

- BAN MODES – X8 à X15

Prohibition or authorization of the modes (RCR, RSP, DCR …) for all controller connected to touch

- DEFECTS

2-3 FACTORY SETTINGS

- ACCESS CODE

- LANGUAGE CHOICE

3 - GENERAL VIEW – CYCLE CONTROL

Sight on the status of each connected cell - in green : no cycle

- in yellow : cycle in progress - in red : defect

3 – 1 - 1 CHOICE OF OPERATING MODE

For a cell in green, no cycle in progress

Choice of the operating mode of the cell, including program mode, defrosting mode and thawing modes.

COUNTDOWN MODE (CHILLING OR FREEZING )

Possibility to modify the duration of the cycle.

CORE PROBE MODE (CHILLING OR FREEZING )

Possibility to modify the end of cycle core temperature

PROGRAM MODE

3 – 1 - 2 PORDUCT SELECTION

Product selection and launch of the cycle

3 – 1 – 3 OPERATING STATE

Cycle in operation

- Probes temperature display - Reminder of settings

- Reminder of the seleceted product - Time information display

- Display of the time elapsed since the last defrosting - Possibility to display the curve of the current cycle

3-2 TRACEABILITY

Display of the different cycle (past or in progress.)

A green Mark if the cycle is compliant, or a red cross if the cycle is not compliant.

The conformity of the cycle is calculated in accordance with settings X4 at X7 (see chapter system settings)

4 - USB

Once the USB key is put in place and all Simply Standby, you can select one of the following 5 possibilities.

4 – 1 COPY OF THE CYCLES

Recovery of all the cycles in memory, in .csv files.

Recovered cycles are erased from SimplyTouch memory 4 – 2 IMPORT PRODUCTS

Importing a .csv file with the product list 4 – 3 IMPORT SETTINGS

Import a .csv file with the list of settings 4 – 4 EXPORT PRODUCT

Recovering a .csv file with the product list 4 – 5 EXPORT SETTINGS
