MARCH 2015 | Volume 94 Number 3
HydrocarbonProcessing.com
SPECIAL REPORT: CORROSION CONTROL
35 How caustic stress leads to failures of incinerator caustic spray nozzles
E. Al-Zahrani, A. Al-Meshari and M. Maity
41 Extend heat exchanger lifecycle with hyper-duplex stainless steel
E. Perea
47 Evaluate the reliability of a reformer heater convection tube
H. Yoon, J. Nam and S. Kim
PLANT DESIGN
53 Determine the design metal temperature for a secondary reformer
B. K. Sharma
HEAT TRANSFER
55 Improve the operation of fired heaters
K. Malhotra
REFINING DEVELOPMENTS
61 Shale oil characterization optimizes refining process
S. Sayles
67 Update on the catalytic cracking process and standpipes—Part 1
P. K. Niccum
PROCESS CONTROL
73 Optimize online monitoring of base oil
H. Kim and G. Fannin
ROTATING EQUIPMENT
77 Contain ‘normal’ leakage from primary seals
R. Smith and S. Shaw
WHAT’S NEW IN CATALYSTS—SUPPLEMENT
C-84 2015 catalyst developments: Innovation and value creation
HP staff
Cover Image: Austrian OMV installed a SNOX plant, a fuel gas desulfurization process licensed by Haldor Topsøe, to remove SO2 and NOx from the flue gases of the power and steam generation facilities at its Schwechat refinery
near Vienna, Austria. The facilities are fired primarily with high-sulfur heavy residual oil. Photo courtesy of OMV.
DEPARTMENTS 4 Industry Perspectives 10 News 17 Industry Metrics 103 Innovations 106 Marketplace 108 Advertiser Index 109 Events 110 People COLUMNS 9 Editorial Comment
Downstream has good news for 2015
19 Reliability
Consider oil-resistant cable terminations to increase electric motor reliability
21 Project Management Energy efficiency: Getting in early pays off exponentially
23 Global
Latin America’s refinery product demand is decelerating
27 Petrochemicals
Fatal DuPont leak shows need for improved chemical safety systems
29 Engineering Case Histories Case 83: What are useful questions to ask before starting a vibration analysis?
31 Boxscore Construction Analysis How low oil prices are affecting new project announcements
