DRAFT: ROBUST CONTROL SYSTEM DESIGN FOR MULTIVARIABLE PLANTSWITH LIGHTLY
DAMPED MODES
D. Nelson-Gruel, P. Lanusse, A. Oustaloup, V. Pommier
IMS - CNRS UMR 5218 – Bordeaux 1 University - ENSEIRB
LAPS Department - 351, cours de la libération Bât A4 -33405 Talence CEDEX -FRANCE Voice: (+33)5.40.00.36.27 – Fax: (+33)5.40.00.66.44
ABSTRACT
A robust controller design is proposed for the active suspension system bench-mark problem. The CRONE control system design used is extended to unstable multivariable plants with lightly damped modes and RHP zeros. Decoupling and stabilizing controller K, is achieved for the open-loop transfer matrix. Fractional order transfer functions are used to define all the components of the diagonal open-loop transfer matrix, β. In defining the fractional open-loop transfer function β0i some elements of the plants, G0 and its inverse
must be considered to achieve the stable controller. Optimisation provides the best fractional open-loop βopt. Finally, frequency domain system identification is used to find controller K=G0-1βopt.
KEY WORDS
lightly damped modes, MIMO, CRONE, control system, fractional order system, frequency domain
1 INTRODUCTION
The aim of the MIMO (multivariable) CRONE CSD (control system design) is to robustify the closed loop dynamic performance through a robust either damping factor, or a robust resonant peak of control. Fractional differentiation is used to define the optimal open-loop.
Three generations of CRONE control have been developed, successively extending the application field. The MIMO approach used here is based on the third generation of CRONE CSD (Oustaloup et Mathieu, 1999). It permits treating uncertain and unstable square nxn MIMO plants with RHP (right half plane) zeros and lightly damped modes (resonant frequencies). Section 2 and 3 briefly outlines the extension of the CRONE CSD methodology. Simulation is given in section 4.
2 CRONE CONTROL METHODOLOGY AND MIMO SYSTEMS
The aim of the CRONE CSD is to find a diagonal open-loop transfer matrix whose n elements are fractional order transfer functions. It is parametered to satisfy the four following objectives:
- perfect decoupling for the nominal plant, - accuracy specifications at low frequencies,
- required nominal stability margins of the closed loops (behaviours around the required cut-off frequencies),
- specifications on the n control efforts at high
frequencies. = ) ( β 0 0 0 ) ( β 0 0 0 ) ( β ) ( β 0 0 0 0 1 s s s s n i . (1)
After an optimisation of the diagonal open-loop transfer matrix (1), frequency-domain system identification is carried to obtain the fractional controller. Open-loop transfer functions β0i(s) are used to satisfy the three other objectives.
2.1. Definition of the diagonal open-loop transfer function elements
Open-loop transfer function behaviours can be described by using the third generation CRONE CSD methodology presented below. This generation of CRONE CSD uses complex non-integer order integration over a choosen frequency range [ωA,ωB]. The complex fractional order,
nf=a+ib allows creating a straight line of any direction in the Nichols chart which is called the generalized template figure (1).
figure 1: Generalized template in the Nichols plane. The real part of nf determines its phase location at frequency
ωcg, that is −ℜe(nf)π2, and the imaginary part determines its direction. The generalized template is described by the limitation in the operational plane Cj of the complex non-integer integrator transfer function:
j f C cg = n s s i ω β0 ( ) , (2) with: − s=σ j+ ω∈ Cj, − nf =a+ib∈ Ci.
This transfer function can be described as based on band-limited complex non-integer integration:
( )
( )b a s s C s i + + = l h sign ω ω β 1 1 0 ( )b -q b s s C e sign i l h g /i + + ℜ × ω ω 1 1 , (3) with − = h cg l cg ω ω ω ω arctan arctan b ch C , (4) and 2 / 1 2 2 1 1 + + = h cg l cg g ω ω ω ω C . (5)The corner frequencies are placed around the extreme frequencies ωA and ωB such that:
h B cg A l ω ω ω ω ω < < < < . (6) For stable and minimum phase plant the generalized template is taken account in the open-loop transfer function as follows:
( ) ( ) ( )
s
s
s
s
i i i i l 0 h 0(
)
β
=
β
β
β
, (7) with( )
i i i n i s C s l l l l + = ω 1 β , (8)the order nli fixes the accuracy of each closed-loop,
( )
i i i i n s C s h h h h + = 1 ω β , (9)the order nhi permits the elements of the controller to be proper.
This third generation CRONE control open-loop transfer function has been defined using the gain-crossover open-loop frequency; however this definition can be made using the closed loop resonant frequency too. Then ωrreplace ωcg.
2.2 Decoupling and optimised controller
Let G0 be the nominal plant transfer matrix such that
G0(s)=[gij(s)]i,j∈N and:
[ ]
N i i i d n diag diag K G i ∈ = = = 0 0 0 β β , (10) where:- gij(s)is a strictly proper transfer function,
- N=
{
1,...,n}
, - i i d n i = 0β the element of the ith column and row.
As mentioned above the aim of CRONE control for MIMO plants is to find a decoupling controller for the nominal plant.
G0 being not diagonal, the problem is to find a decoupling and stabilizing controller K (Vardulkis , 1987). This controller exists if and only if the following hypotheses are true:
[
0]
1exist 1: ( ) − s G H , (11)[
( )]
[
( )]
0 : 0 0 2 Z+G s ∩P+G s = H , (12)where Z+
[
G0(s)]
and P+[
G0(s)]
indicate the positive real partzero and pole sets. The controller K(s) is:
N i i i d n diag G G adj G K ∈ − = = 0 0 0 1 0 ) ( β , (13)
with adj(G0(s))=[G0ij(s)]T=[G0ji(s)], G0ij(s) the cofactor corresponding to element gij(s), and |G0| corresponding to determinant of G0(s). Thus: i G G k ji ij 0 0 0 β = ∀ ,i j∈N. (14)
The nominal sensitivity and the complementary sensitivity transfer function matrices are:
( )
s =[
I+( )
s]
− =diag[
S0i( )
s]
1≤i≤n 1 0 β S0 , (15) |β0i(jω
)|dB 0 -π 0 -π/2ω
cgω
Aω
B -aπ/2 f(b,a) argβ0i (jω
)3
( )
s =[
I+( )
s]
− 0( )
s =diag[
T0i( )
s]
1≤i≤n 1 0 β β T0 , (16) with( )
)) ( 1 ( ) ( 0 0 0 s s s T i i i β β + = , (17)( )
)) ( 1 ( 1 0 0 s s S i i β + = . (18)For plants other than the nominal, the closed-loop transfer matrices T(s) and S(s) are no longer diagonal. Each diagonal element Tii
( )
s and Sii( )
s could be interpreted as closed loop transfer functions coming from a scalar open-loop transfer function βii(s) called equivalent open-loop transfer function:) ( ) ( 1 ) ( 1 ) ( ) ( s S s S s T s T s ii ii ii ii ii − = − = β . (19)
For each nominal open-loop β0i(s), many generalized
templates can border the same required magnitude-contour of the Nichols chart or the same resonant peak
i
Mp0 . The
optimal one minimizes the robustness cost function:
(
)
2 1 min max∑
= − = n i i i M M J p p (20) where: • maxsup(
( ))
max ω ω j p Tii G M i = , (21) • minsup(
( ))
min ω ω j p Tii G M i = , (22)while respecting the following set of inequalites for ω∈R and
i, j∈N:
( )
ω( )
ω l j ij ij G T ≥T inf , (23)( )
ω( )
ω u j ij ij G T T ≤ sup , (24)( )
ω( )
ω u j ij ij G S S ≤ sup , (25)( )
ω( )
ω u j ij ij G KS KS ≤ sup , (26)( )
ω( )
ω u j ij ij G SG SG ≤ sup , (27)where G is thenominal and perturbed plant.
As the uncertainties are taken into account by the least conservative method, a non-linear optimization method must be used to find the optimal values of the independent parameters of the fractional open-loop.
3 CRONE CONTROL DESIGN FOR UNSTABLE MIMO PLANT WITH LIGHTLY DAMPED MODES
Let the nominal plant transfer matrix G0 be:
= ) ( ) ( ) ( ) ( ) ( ) ( 1 1 11 0 s g s g s g s g s g s G nn n ij n , (28) where: - gij(s)=g0ij(s)⋅hij(s),
- hij(s) is the transfer including the resonant modes and RHP zeros and poles.
The inverse of G0 is:
= ) ( ) ( ) ( ) ( ) ( ) ( 1 1 11 s p s p s p s p s p s P nn n ij n , (29) where: − pij(s)= p0ij(s)⋅mij(s),
− mij(s) is the transfer function including the resonant modes and RHP zeros and poles.
Thus the controller is:
) ( ) ( ) (s p s 0 s k i ij ij = ⋅β , (30) ) ( ) ( ) ( 0 0 s m s s p ij ij βi = ⋅ ⋅ (31) Now, (31) implies that some RHP zeros, unstable poles, and lightly damped modes of pij must appear in β0i for the controller to be achievable and stable. The aim of this section is to characterize this open-loop transfer matrix.
3.1. Lightly damped modes
Some resonant frequencies must be included in the open-loop transfer function β0i for the controller to be achievable and stable.
The first transfer matrix to consider is the input-disturbance sensitivity, T0K-1. Using (10): + ⋅ ⋅ = = − ) ( ) ( ) ( ) ( ) ( 0 0 0 1 0 s n s d s h s g s d G S K T i i ij i ij (32) this transfer function is resonant-free if
N j s h s d s d ij i i = ∀ ∈ ) ( ) ( ˆ ) ( . (33)
The denominator of the ith open-loop transfer function must satisfy all the following equations:
) ( ) ( ˆ ) ( ) ( ) ( ˆ ) ( ) ( ) ( ˆ ) ( 2 1 s h s d s d s h s d s d s h s d s d in i i i i i i i i = = = (34) and therefore: ) ( ) ( ˆ ) ( s H s d s d i i i = ∀i∈N, (35)
where, transfer functions Hi(s), have in common some lightly
damped modes of the ith row of G0.
The second transfer matrix to consider is input sensitivity KS. Using (10): + ⋅ ⋅ = = − ) ( ) ( ) ( ) ( ) ( 0 1 0 0 s n s d s n s m s p T G S K j j j ij ij , (36)
this transfer function is resonant-free if
N i s m s n s n ij j j = ∀ ∈ ) ( ) ( ) ( (37)
The numerator of the ith open-loop transfer function must satisfy all the following equations:
) ( ) ( ˆ ) ( ) ( ) ( ˆ ) ( ) ( ) ( ˆ ) ( 2 1 s m s n s n s m s n s n s m s n s n nj i j j j j j j j = = = (38) and therefore: ) ( ) ( ˆ ) ( s M s n s n j j j = ∀j∈N, (39)
where transfer functions Mj(s) have in common some lightly
damped modes of the jth column of G0-1.
Adding some lightly damped modes on the open-loop transfer functions causes resonant frequencies to appear on sensitivity and complementary sensitivity transfer functions. To attenuate their effect, transfer function Qj(s) is included in β0i(s) around each resonant frequency such that:
1 2 1 2 ) ( ' ' 2 ' 2 + + + + = j j j j j s s s s s Q ω ξ ω ω ξ ω , (40) where:
− ωj and ωj’ are frequencies close to the resonant
frequency,
− ξ and ξ’ are damping factors,
3.2. Unstable Poles and RHP zeros
Let ηz(a) be an integer ξ such that
(
)
ξ z s s a z s→ − ) (lim exists and is
non-zero (Tao,2005). So for a given z:
• a(s) has a ηz(a) order zero at z if ηz(a)>0, • a(s) has a ηz(a) order pole at z if ηz(a)<0, • a(s) has neither pole nor zero if ηz(a)=0.
Inevitably a transfer function is stable and minimum phase if and only if:
0 ) (a =
z
η ∀ z ∈ C+. (41)
In our case we need:
0 ) ( ij ≥ z k η ∀ ,i j∈N ∀ z ∈ C+ (42) With (18), (43)becomes:
[ ]
≥ i G G k ji z ij z 0 0 0 ) ( η β η , (43) N j i ∈ ∀ , ∀ z ∈ C+. Consequently:( )
( )
[ ]
ji z z z( 0i) η G0 η G0 η β ≥ − . (44)The ith open-loop transfer function must satisfy all the following equations:
( )
( )
[ ]
( )
( )
[ ]
( )
( )
[ ]
ni z z z i z z z i z z z G G G G G G i i i 0 0 0 2 0 0 0 1 0 0 0 ) ( ) ( ) ( η η η η η η η η η − ≥ − ≥ − ≥ β β β (45) and therefore:( )
G i( )
z z z i η η η (β0)≥ 0 − ∀i∈N, (46) with( )
(
( )
ji)
z N j i z minη G0 η ∈ = . (47)Equation (48) shows that the ith open-loop transfer function β0i(s) must have, for each z, an
(
s−z)
transfer function atorder
( )
i z β0
η . This order equals the order of z in G0 minus
the order of z common to all the elements of the column in
] [ 0 ji G . The sign of
( )
i zβ0η determines whether the transfer is
an RHP-zero or a unstable pole of β0i(s).
Finally, when all the zeros, poles, and lightly damped modes to be include in the ith open-loop transfer function are found:
( ) ( ) ( ) ( )
s s s s s( )
s s i i i i i i i l r z p h β0 ( )=β β β β0 β ( )β , (48) with:(
)
zik( )
i k i i C zi s k z z 0 1 β Nzi η β =Π
− = , (49)( )
pik( )
i k k i p i i p s s p e C i i k p p 0 1 β N jπ pi η β − + =Π
= Ψ − , (50)( )
∏
= = φ β 1 ) ( ) ( ) ( j j i i r Q s s M s H C s i r (51) where:− φ is the number of lightly damped modes to
integrate. − k i z is a z such that ηz
( )
β0i >0, − k i p is a z such that ηz( )
β0i <0, −( ) ( )
i i k i z z β0 η β0 η = if z is a zero of β0i(s),5 −
( )
( )
i i k i p β0 ηz β0 η =− if z is a pole of β0i(s), − i zN is the number of RHP zeros of β0i(s), −
i
p
N is the number of RHP poles of β0i(s),
−
∑
( )
= = Ψ i p N β 1 0 k pi ηpik i , −∑
( )
= = Ψ i z N β 1 0 k zi ηzik i .In addition, the controller must be proper and permit the rejection of low amplitude disturbances.
Thus using (30), the controller is proper if:
(
di(s))
(
Dp (s)) (
Np (s))
(
ni(s))
ij ij deg deg deg deg + ≥ + , (52) ∀ j ∈ N, with ) ( ) ( s p s p ij ij ij D N s p ( )= . As a consequence(
( ))
(
( ))
max(
(
p (s)) (
p (s))
)
N j i i s n s N ij Dijd deg deg deg
deg − ≥ −
∈ , (53)
and at high frequencies
(
)
i h i s n d ( ) = deg (54) and(
ni(s))
=Ψzi deg , (55) gives(
) (
)
(
() ())
max p s p s N j z hi i N ij D ij n ≥Ψ + deg −deg ∈ . (56)At low frequencies, disturbances are rejected if transfer function SG contains no poles at z=0 or
(
( ))
0(
0( ))
0 0 S s +η G s ≥ η . (57) and S(s) is equivalent to β0i(s) or(
S(s))
≈ 0(
0i(s))
=nli +Ψzi 0 η β η . (58) Also:(
G0(s))
0(
Ngij(s)) (
0 Dgij(s))
0 η η η = − , (59) with: ) ( ) ( s g s g ij ij ij D N s g ( )= . (60) Therefore:(
g (s)) (
g (s))
z li i N ij D ij n +Ψ ≥η0 −η0 , (61) ∀ j ∈ N. Finally:(
) (
)
(
ij ij)
i N j i g s g s z l N D n ≥ − −Ψ ∈ ( ) ( ) maxη0 η0 . (62) 4 APPLICATIONConsider the widely studied 2x2 active-suspension system (Bao-Tung Lin, 2006, Qing-Guo Wang, 2002 and Reinelt, 2000), given in figure 2. ⋅ Λ + + Λ + + = ) ( ) ( ) ( ) ( 2 1 1 1 2 1 1 1 2 1 2 2 2 1 s U s U K s B s M s B s B K s B s M s Y s Y , (63) where:
(
)
(
)
2 1 2 2 1 3 2 1 1 4 2 1M s B M M s M K M K s M + + + + = Λ(
)
1 2 1 1 1 2 1K K B s K K B + + + (64)M1=1 and M2=1.85 are the two masses; K1=0.8 and K2=1.25 are the spring elements of the suspension; and B1=0.8 is the damper. K2 is the uncertain element.
Figure 2: System model
4.1. Fractional complex definition of the nominal open-loop transfer matrix
a) RHP zeros, poles and lightly damped modes
The elements to include are:
− an RHP zero at order ηz=1.25
( )
β0i =1 for both loopsat z=1.25rad/s.This RHP zero is common to each column of G0-1;
− a lightly damped mode at 0.822rad/s with a damping
factor of 0.263 for the first loop, this mode is common to the first column of G0-1.
b) Spécifications
For all parametric states,the following must be satisfied: − zero steady-state error for both outputs,
− short as possible settling time, − perfect decoupling for both loops,
− first overshoot less than 20%.
With this specification some elements of the open-loop transfer matrix can be initialized. So, with the maximum relative degree of G0-1 (-1) and all elements to integrate in the
open-loop transfer matrix, nh must be greater than 3 for the
first loop, and greater than 1 for the second loop. A zero steady-state error for both loops causes nl to be equal to one.
To attenuate the effect of the damped mode and the steady oscillation (figure 3) transfer (40) was added to each
i 0
β
Figure 3: Simulation without feedback
c) Optimisation
Both open-loop parameter are now to be optimized. For the first loop the initial parameters are :
− ωr=0.05rad/s, − ωl=0.02rad/s, − ωh=0.5rad/s, − 01( ) = =2 r j ω ω ω β dB,
− ω'n=ωn=0.85rad/s, ξ’=0.1 and ξ=0.8 for equation
(40), for the second loop:
− ωr=0.02rad/s, − ωl=0.005rad/s, − ωh=1rad/s, − 01( ) = =8 r j ω ω ω β dB,
− ωn=1.2rad/s, ω’n=0.7rad/s, ξ=0.8 and ξ’=0.6 for
equation (40).
Taking into account all specifications, optimal values for the parameters of each fractional open-loop transfer function β0i are:
− for the first loop: K=3.6078, a=1.2532, b= -0.4602,
q=1 and C= 2.6792
− for the second loop: K= 18.3767, a= 1.3151, b=
0.4473, q= 2 and C= 4.1223
Figure 3 shows equivalent open-loop transfer functions
-600 -400 -200 0 -60 -40 -20 0 20 40 60 6 dB 3 dB 1 dB 0.5 dB 0.25 dB 0 dB -1 dB -3 dB -6 dB -12 dB -20 dB -40 dB -60 dB -800 -600 -400 -200 0 -150 -100 -50 0 50 100 6 dB 3 dB 1 dB 0.5 dB 0.25 dB 0 dB -1 dB -3 dB -6 dB -12 dB -20 dB -40 dB -60 dB -80 dB -100 dB -120 dB -140 dB
Figure 4: Equivalent open-loop transfer function (() nominal, (---) reparametered)
The final controller is found by frequency domain identification
4.2. Results
A simulation of the active suspension system is used to evaluate the controller performance. Inputs of the system are unit step and introduced at t=0s (first input), t=150s (second input); disturbances are 0.1 amplitude step and introduced at
t=400s (disturbance on the first loop) and t=600s (disturbance
on the second loop). The uncertain spring element K2 varies
between 0.5 and 2. The simulation results are shown in figure 5 for the nominal plant, and figure 6 for nominal and re-parametered plants. 0 500 1000 -0.5 0 0.5 1 1.5 y1 0 500 1000 -0.5 0 0.5 1 1.5 y2 0 500 1000 0 0.5 1 u1 0 500 1000 -0.5 0 0.5 1 1.5 u2
Figure 5 : Control performance of the active suspension system 100 200 300 400 500 600 0 100 200 300 400 500 600 0 0.05 0.1 0.15 0.2 0 -0.2 -0.15 -0.1 -0.05 0 0.05 offset y2 Steady-oscillation y1
7 0 500 1000 -0.5 0 0.5 1 1.5 y1 0 500 1000 -0.5 0 0.5 1 1.5 y2 0 500 1000 0 0.5 1 u1 nominal reparametered 0 500 1000 -1 0 1 2 3 u2
Figure 6 : Control performance of the active suspension system for reparametered state
Figure 5 and 6 show that all specifications are satisfied. Overshoot is almost equal to the imposed limit, but the decoupling specification is satisfied for the nominal plant and preserved for reparametered plants. Also the offset and the steady oscillation have been removed.
5. CONCLUSION
The multivariable CRONE approach is based on third generation CRONE control system design. Each open-loop transfer function β0i of the matrix β(s) is thus fractional. Frequency domain system identification and linear algebra are used to determine the final controller. For unstable multivariable plants with lightly damped modes and RHP zeros, some RHP poles, RHP zeros, and lightly damped modes of G0 or G0-1 can appear on K or on closed loop transfer
matrices. The controller would not be achievable and stable. So a method is therefore proposed for treating this kind of system and to determine a final stable and achievable controller. Adding some RHP zeros, RHP poles, and lightly damped modes in open-loop transfer functions before their optimization render the controller achievable and stable. The method used for the active suspension bench-mark problem. The control obtain is rapid and disturbances rejected.
A crone approach to unstable and non-square multivariable plants with RHP zeros, and lightly damped modes, is being investigated.
6 REFERENCES
Bao-Tung Lin, Wen-Nan Huang, Chin-Cheng Teng, «Design of controllers for MIMO active-suspension System Using
Combined QFT/H∞», 2006 CACS Automatic Control
Conference
Oustaloup Alain et Mathieu Benoit, «La commande CRONE», édition Hermes, 1999
Qing-Guo Wang, Yu Zhang, Min-Schen Chiu, «Decoupling internal model control for multivariable systems with multiple time delays», Chemical engineering Sciences, 2002.
Reinelt Wolfgang, «Robust control of a Two-Mass-Spring System subject to its Input Constraints», American Control Conference, Chicago, USA 28-30 June 2000
Spencer Jr B.F., S.J. Dyke and H.S. Deoskar, «Benchmark Problems in structural control Part I: Active Mass Driver System», Proceedings of the 1997 ASCE Structures Congress, Portland, Oregon, April 13-16,1997.
Tao L., W.D. Zhang, D.Y. Gu, «Decoupling control design processes with Time Delays», Acta Automatica Sinica Vol 31 No.6 2005.
Vardulkis A. I. G. - «Internal stabilization and decoupling in linear multivariable systems by unity output feedback compensation», IEEE Trans. on Autom. Control, 32, August, 1987.
